Copy a Lumenetix Lamp
• Use the Gray Card
included in the Light
Commissioning Tool
• Hold the Gray Card in the
center of the beam of the lamp
to be copied. The ideal distance
from the lamp is 4 feet (120 cm)
• Aim the light commissioning tool at the center
of the Gray Card
• Press and hold COPY for two seconds.
The Display will read “Copy”
Select the Target Lamp
• Press the TARGET button
• The active lamp will blink green
• To target a different lamp in the wireless network,
continue to press TARGET until the desired lamp
blinks green
For assistance with the operation
of the Light Commissioning Tool,
please visit www.lumenetix.com
Instruction Manual
Light Commissioning Tool
Model Number LCT Zero
Lamp On and OffSelect a LampIntroduction Inserting the Batteries Network Scan
3 x AAA
• Remove the battery case on the back of the
remote control by pushing the tab in and sliding
the cover down
• Insert 3 AAA batteries ensuring that the positive
and negative terminals are correctly matched
• Replace the battery case
SCAN
SELECT
COPY TARGET
CALIBR A TION
PASTE
SCAN / SELECT POWER
BRIGHTNESS UP CCT UP
CCT DOWN
DISPLAY
PASTE
BRIGHTNESS DOWN
COPY
TARGET
REMOTE CONTROL
Scan the Wireless Network
to Discover Lamps
• Aim the remote control at the lamp(s)
and press and hold SELECT until the display
indicates that the light commissioning tool is
scanning the network to discover all lamps
• After a few seconds, the active lamp will flash
• The display indicates the quantity of lamps
discovered on the network
Light Commissioning Tool Functions
• Wirelessly controls araya lamp power on/off,
brightness, and color temperature
• Copy and Paste – copy a Lumenetix lamp and
paste it onto a Lumenetix lamp
• Calibration – Compensates for different LED
aging characteristics
• The active lamp in the network flashes in
Network Scan
• To access another lamp in the network, press
SELECT again. The next lamp in the network
will flash.
• Continue to press SELECT until the desired
lamp flashes
• The display will update to indicate the lamp
within the network
SELECT
SCAN
SELECT
COPY TARGET
CALIBRATION
PASTE
SCAN
SELECT
SCAN
SCAN
SELECT
COPY TARGET
CALIBRATION
PASTE
SELECT
SCAN
SELECT
LAMP ON / OFF
HOLD 2 SEC
CCT 3000K
DIM 100%
SCAN
SELECT
SCAN
SELECT
COPY TARGET
CALIBR ATION
PASTE
LAMP ON / OFF
CCT 3000K
DIM 100%
SCAN
SELECT
SCAN
SELECT
Increasing the Brightness
• The brightness can be
adjusted from 5% to 100% in increments of 1%
• Press the brightness UP key to increase the brightness
• The selected dimming level is shown in the display
Decreasing the Brightness
• The lamp can be dimmed from 100% to 5% in
increments of 1%
• Press the brightness DOWN key to dim the lights
• The selected dimming level is shown in the display
Adjusting Color Temperature (CCT)
Increasing the Color
Temperature
• The color temperature
can be adjusted from
2700K to 4200K in
increments of 100K
• Press the CCT UP key
to increase the color temperature
• The selected color temperature is shown in the display
Decreasing the Color Temperature
• The color temperature can be adjusted from 4200K
to 2700K in increments of 100K
• Press the Color Temperature DOWN key to decrease
the color temperature
• The selected color temperature is shown in the display
SELECT
SCAN
SELECT
COPY TARGET
CALIBRATION
PASTE
COPY
HOLD 2 SEC
COPY TARGET
CALIBR ATION
PASTE
TARGET
SCAN
SELECT
Paste
• Use the Gray Card included in the Light
Commissioning Tool
• Hold the Gray Card in the center of the beam
of the lamp to be pasted. The ideal distance
from the lamp is 4 feet (120 cm)
The distance that the gray card was held from
the lamp that was copied should be equal to
the distance that the gray card is held from
the lamp to be pasted
• Aim the light commissioning tool at the center
of the Gray Card
• Press and hold PASTE for two seconds.
The Display will read “Paste”
• Keep the Light Commissioning Tool steadily
pointed at the Gray Card until the lamp flashes
twice, indicating that the operation is complete
• The brightness and color temperature will be
shown in the display
COPY TARGET
CALIBRATION
PASTE
PASTE
SCAN
SELECT
HOLD 2 SEC
CALIBRATION
COPY TARGET
CALIBR ATION
PASTE
SCAN
SELECT
• Press the SELECT button to access the active lamp
in the network
• The active lamp will flash
• To access other lamps in the wireless network,
continue to press SELECT until the desired lamp
blinks amber
• Simultaneously press the COPY and PASTE buttons
• The lamp will begin calibration of the LEDs
• Upon completion the lamp will flash twice
• Press the POWER button and the selected lamp
will turn on
• The brightness and color temperature will be
shown in the display
• To turn the lamp off, press the POWER button
• If the lamp does not light, check the dimming
level and adjust to the desired brightness (see
next page)
BRIGHTNESS UP
BRIGHTNESS DOWN
COPY TARGET
CALIBRATION
PASTE
SCAN
SELECT
Selecting the Lamp to Copy
• Using the SCAN SELECT
button, select the light to be copied
• The active lamp will flash
• To access another lamp in the wireless
network, press SELECT again (the next lamp
in the network will flash)
• Continue to press SELECT until the desired
lamp flashes
CCT UP
CCT DOWN
COPY TARGET
CALIBRATION
PASTE
SCAN
SELECT
