MINEW TECHNOLOGIES E6 Digital Broadcasting Device (Light sensor beacon) User Manual

SHENZHEN MINEW TECHNOLOGIES CO., LTD. Digital Broadcasting Device (Light sensor beacon) Users Manual

Manual

TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 1
Minew Technologies
E6 Light Sensor Beacon
Datasheet V1.0.0
L
Li
ig
gh
ht
t
S
Se
en
ns
so
or
r
B
Be
ea
ac
co
on
n
D
Da
at
ta
as
sh
he
ee
et
t
V
V1
1.
.0
0.
.0
0
Ordering Code
Description
E6-6001A
Black casing, CE&FCC certified BLE module with a simple light sensor and
anti-dismantlement switch, includes 1pc 230mAh CR2032 coin battery, RoHS
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 2
Minew Technologies
E6 Light Sensor Beacon
Datasheet V1.0.0
The light sensor beacon E6 is the latest basic IoT sensor device with the light sensor and an
anti-dismantlement switch. The hardware is based on the ultra-low power consumption BLE chipset
nRF52832 and the firmware is compatible with the leverage Bluetooth 5.0 technology.
The light sensor beacon E6 is designed for the commercial advertising, indoor location-based service and
specialized for the asset management and tracking application.
FEATURES
- Programmed Minew basic IoT firmware
- Included a light sensor
- Included an anti-dismantlement switch
- The max. 50 meters advertising distance
- Ultra-low power consumption chipset nRF52832
- Small size, ultrasonic assembling technology
- Easy to print the logo on the center of top case;
CERTIFICATIONS
- iBeacon MFi License (iBC-14-00582)
- FCC Regulation (FCC Part 15.)
- CE Regulations (Included EN300328/301489/60950/62479)
E6 Light sensor Beacon
Image 1
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 3
Minew Technologies
E6 Light Sensor Beacon
Datasheet V1.0.0
ELECTRONIC PARAMETERS
Item
Remarks
Case Color
Null
Battery Model
230mAh, 3.0V
Operation Voltage
DC
Transmission Circuit
Tested at 0dBm transmission power
Transmission Range
Maximum
Light sensor
Null
Broadcasting Interval
Null
Antenna
On board / PCB Antenna
Accessories
1pc, high-strength, 3M brand;
Net Weight
With battery but without package
Size
Null
TECHNICAL SUPPORT
Item
Version
File Name
Updated Date
Datasheet
V1.0.0
E6 Light Sensor Beacon Datasheet_V1.0.0.pdf
8th April, 2017
2nd Development
V1.0.0
E6 Light Sensor Interface Document_V1.0.0.pdf
8th April, 2017
APP Tools
---
nRFConnect
---
PACKING INFORMATION
Image 2
Details
Inner Box (foam)
Carton
Quantity (E6)
100pcs per package box
1000pcs per carton
Net Weight
0.65kg
6.5Kg
Gross Weight
0.7Kg
7.0Kg
Size
30.5 x 11 x 7.5 cm
32 x 23 x 40 cm
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 4
Minew Technologies
E6 Light Sensor Beacon
Datasheet V1.0.0
APPDENDIX
1. J-LINK Programmer Kit;
2. Over-the-Air Function;
Please contact Minew sales team to ask more related information if needed.
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement. Minew
team reserves the right to explain all the terms of this datasheet.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction.
