MOVON MF280 BLUETOOTH MONO HEADSET User Manual MF280 manual Do not print ai
MOVON Corporation BLUETOOTH MONO HEADSET MF280 manual Do not print ai
MOVON >
Users Manual
HEADSET
MF280
WIRELESS
User Manual
MF280 Headset Ear hook Car A/C power
3 di erent size ear bud
User manual
Charger adapter
(Small, Medium, Large)
Charge the battery
Connect an adapter to the charging port of the headset and plug into power outlet
or automobile (or any standard 12V~14V). When charging is completed, charging
.
What’s in the box?
Getting to know the MF280
-1- English English
[NOTE] Please use supplied power adaptor only.
Before using Hands-free, You must charge this product
Don’t use if hands-free is being charged.
Charging by Adapter : If Adaptor added, the Indication LED will be RED.
Low Battery Warning : When the battery is low, the Indication LED will be
turned into Red and you can hear a beep every 30
seconds. Once hear a beep, please charge immediately.
about 10 minutes
Using your MF280
TURNING ON/ OFF
Power On Power O -2-
Charging
Port
Multifunction Button
LED
Volume Button
Microphone
Ear Bud
Speaker
PAIR THE MF280 TO YOUR MOBILE PHONE
1. Set your mobile phone to Bluetooth discoverable mode. (visibility on)
2. Turn the MF280 on. rst time, MF280 will go to pairing
mode. (LED will blink Blue and Red)
Or Press the Multifunction button for 4 sec until LED blink as Blue & Red
3. Search the MF280 via y rm it when the connection
rmation message appears on your mobile phone.
PIN number is “0000” (4 zeros)
SIMPLE PAIRING: If your mobile phone supports Bluetooth core spec 2.1, you
don’t need to put PIN number to pair. (This function is only available
when your mobile phone supports Bluetooth version 2.1)
EASY PAIRING: If you use headset for the rst time, headset will go pairing
mode directly.
MAKING A CALL
1. Last call-Redialing : Press Multifunction button.
2. Voice Dial : Press MFB for about 2 seconds, then voice dialing is activated on the
phone. If you want to cancel Voice dialing, press the MFB for about
2seconds during the Voice dial mode.
[NOTE] Please make sure that the phone supports the voice dialing feature.
(See you phone’s manual for detail instruction)
If you dial with phone, call will be transferred to headset automatically.
You must transfer a call depending on your mobile phone. Please check you
phone’s manual for details.
ANSWERING A CALL
Press Multifunction button.
REJECTING A CALL
Press Multifunction button for about 2 seconds.
ENDING A CALL
Press the Multifunction button during the call or just press the “End” button on
the phone.
-3- -4-
English English
Active Dev List
Model Name
MF280
Input PIN Code
0000
TRANSFERRING A CALL
To transfer a call from Headset to your mobile phone and vice versa, press the
Multifunction button during the call for about 2 seconds.
ADJUSTING VOLUME
You can adjust the Volume by pressing the Volume up (+) or down button (-)
during the call.
MIC MUTE
If you press the volume down (-) button for about 2 seconds, the microphone will
be muted and you will hear a beep every 5 sec during the mute.
[NOTE] The MIC muted mode can be deactivated by pressing Volume down button (-) for 2 sec. again.
CALL WAITING
Before using Call-waiting through the hands-free, check if the mobile phone
supports hands-free pr le function. Further, be aware that “Call hold” and
“Multiparty” functions are available only through network operator.
1. Answering a second call/putting a rst call into waiting mode
: Press the Multifunction button twice.
2. Ending a 1st call and Answering 2nd call
: Press the Multifunction button to end the 1st call, then press Multifunction
button to answer 2nd call.
3. Rejecting a second call while answering 1st call
: Press the Multifunction button for 2 sec.
4. Switching 1st call to 2nd call
: Press the Multifunction button twice and vice versa.
[NOTE] Three way calling will not be supported on Multi-point connected mode.
MULTI-POINT: Using the MF280 with two phones
[NOTE] Some mobile phones are not available for multipoint.
1. Multi-point Connect
rst. After then search MF280 from each
mobile phones at the same time.
Please connect rst mobile phone. Once the connection is completed, please
connect the second mobile phones.
[NOTE] Some mobile phones need to connection process at the same time.
2. Making a call [via second mobile phone]
Press the Volume Down (-) button for about 2 seconds for last call-redialing
from the second mobile phone.
Press the Volume Up (+) button for about 2 seconds to activated the voice
dialing of the second mobile phone.
[NOTE] Making a call via the rst mobile phone, please follow the same instruction as described on
“MAKING A CALL”.
-5- -6-
English English
3. Receiving and Rejecting a call
Please use the general rules as you receive / reject calls.
[NOTE] erent ring tones.
CHECKING THE BATTERY LEVEL
Press the Volume up (+) or Volume down (-) button twice, then MF280 will
announce the Battery level.
RESET
Press the MFB and Volume down button for 4 sec until you hear a beep. Then all
device information will be reset.
STATUS INDICATION
1. LED Indication
Status LED Indication
Power On Blue LED blinks 3 times
Pow
Pairing Mode Blue & Red LED blinks repeatedly
Connectable Mode Blue LED blinks 1 time every 5 seconds
Connected Mode Blue LED blinks 2 times every 5 seconds
Active Call Mode Blue LED blinks 3 times every 5 seconds
Charging Red LED turns On
-7- -8-
Charging Complete
2. Voice Announcement
Status Voice Announcement
Power On Power on
Connected Connected
Disconnected Disconnected
Battery level: 70%~100% Battery High
Battery level: 30%~70% Battery Medium
Battery level: 10%~30% Battery Low
SPECIFICATIONS
Model Name MF280
Bluetooth Core Spec cation 3.0
le HFP 1.5/HSP
Carrier Frequency 2400 MHz to 2483.5 MHz
Modulation Method GFSK, 1Mbps, 0.5BT Gaussian
Maximum Data Rate Asynchronous : 2178.1 kbps / 177.1 kbps
Synchronous : 1306.9 kbps / 1306.9 kbps
Bluetooth Class Class 2
Hopping 1600 hops/sec, 1MHz Channel Space
Transmit Power 1 dBm
Coverage Range 10 Meters
Receiver Sensitivity -83 dBm / 0.1 % BER
Continuous Talk Time 6 hours
Standby Time 200 hours
Weight 10g
Dimension 18.1(H) x 51.3(L) x 9.5(H) mm
Charging Voltage DC 5.0 ~ 5.3 V
Charging Time 1.5 Hours
Operating Temperature -10° to +50°C
Storage Temperature -20° to +80°C
Battery Lithium polymer 3.7V 90mAH
SAFETY AND GENERAL INFORMATION
1. Please read this guidebook carefully and follow the instruction.
2. To avoid any damage or malfunction of the unit, do not drop it from high place.
3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water,
moisture and other liquid directly, then do not operate it normally to avoid any electrical shock,
explosion and damage of the unit.
4. Do not place or keep the unit near the heat sources such as direct sun light, radiators, stoves or other
apparatus which produce heat. It may cause explosion, degrade of performance and reduce
battery life.
5. Do not modify, repair & disassemble unit at discretion (especially batter y: it may cause an explosion.
6. Do not place the heavy objects on the unit.
7. Use only supplied and approved charger.
8. Replacement or ser ed service center or manufacturer.
9. Unplug this unit when unused for long period of time or during lightening storms.
[CAUTIONS] ELECTRIC SHOCK HAZARD
The battery used in this device may pr re or chemical burn if mis-treated.
FCC WARNING
This equipment may generate or use radio frequency energy cations to this equipment may
cause harmful interfer cations are expressly approved in the instruction manual. The user
could lose the authority to operate this equipment if an unauthoriz cation is made.
[NOTE] This equipment has been tested and found to comply with the limits for a Class B digital device,
purchant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a cir erent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.”
FCC RF Radiation Exposure Statement
1.
FCC Notice
1. Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including inter ference that may cause undesired
operation of the device.
This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
EU
This product is CE marked according to the provision of the R&TTE Directive (99/5/EC).
Here by MOVON Corporation, declares that this product is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC. Please note that this product uses radio
frequency bands not harmonized within EU. Within the EU this product is intended to be used in Austria,
Belgium, Denmark, Finland, France,Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal,
Spain, Sweden, United Kingdom and within EFTA in Iceland, Norway and Switzerland. Bluetooth is a trademark
owned by the Bluetooth SIG, Inc.
WARRANTY
The condition of this warranty and our responsibilities under this warranty are as follows:
Supplier’s warranty is non-transferable. And this warranty is limited to the original purchaser only.
You must be able to prove the date of original purchase of the unit with a dated receipt.
The warranty is not applicable if the product has been subject to physical abuse, improper
installation, modi cation or repair by unauthorized third party.
The responsibility of supplier’s products shall be limited to the repair or replacement of the product
at it’s sole discretion.
cally exempt from any warranty are limited-life consumable components subject to normal
wear and tear such as batteries, decorates and other accessories.
A supplier will not take any responsibility if the failure of the unit has resulted from accident, abuse,
misuse or any unauthorized repair, modi cation or disassemble.
Modi cation and repair of the unit should be done by authoriz ed service personnel,
center or returned to the manufacturer.
This warranty gives y c legal rights and you may also have other rights which vary under
local laws.
WEEE SYMBOL INFORMATION
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems) This marking
shown on the product or its literature, indicates that it should not be disposed with other household wastes at
the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product or their local government
ce, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
[IMPORTANT NOTE] To comply with RF exposure requirements, this device may not be co-located
with any other transmitter or antenna.
