Mandolyn Electronic Technology RT601 Light Sensor User Manual RT100RT601 Manual

Mandolyn Electronic Technology Inc. Light Sensor RT100RT601 Manual

Users Manual

GETTING STARTED battery installation
COUNTDOWN TIMER RANDOM FUNCTION TROUBLESHOOTING
12
remove the battery cover from
the back of the timer
place two button cell batteries
between terminals observing
proper polarity then replace cover
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
3
57 9
2 4 6 8
10
1
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
3
2
1
short/long random
programmable random
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
2
1
43
LCD display seems “frozen”. Buttons
won’t respond.
Timer loses programs when unplugged
Programmed ON/OFF times don’t
execute
Programmed ON/OFF times don’t
execute at specified times.
Transmitter stops turning receiver on
and off.
Press reset button to reset timer.
Replace batteries.
Ensure that the program disable feature is
not enabled.
Ensure that the random function is not
enabled.
Use the LEARN function to reprogram the
receiver or check the batteries.
problem solution
TECHNICAL SPECIFICATIONS
Programmable Timer RCT100
Ratings: 120V AC, 15A
Max Load: 1800W resistive; 600W tungsten
Photocell Transmitter RT601
Transmission Range: up to 40m in open area
Transmission Frequency: 433.92 MHz
1
4
2
5
6
7
8
Press SET
Start ON or OFF select with
Press SET
Hour select with
Press SET
Minute select with
9
10
3
Press SET
Second select with
Press SET
The to-the-second countdown feature of this timer starts from the ON or OFF
position and counts down to zero when activated.
Press once from
LEARN
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
Stop countdown timer function with CD or ON/OFF
remove the battery cover from
the transmitter
place two AA size batteries into
compartment observing proper
polarity then replace cover 1
2
button descriptions
RANDOM
RESET
PHOTOCELL TRANSMITTER
2
Repeat and for additional timers (available at your local retailer).
Press and hold ON/OFF and
together on timer while
simultaneously pressing the RF
button on the transmitter. (The
green LED indicator on the
transmitter will flash when RF is
pressed).
1
1Plug timer into wall socket
2
LEARN
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
1
*1
PROGRAM SETTINGS
disable program/master disable
PROGRAM
ON/OFF CD
SET
RANDOM
RESET 1
3
57
2 4 6 8
PROGRAM
ON/OFF CD
SET
RANDOM
RESET 1
4
3
Press SET
Day select with
Press SET
Hour select with
Press SET
Minute select with
Press SET
Program select with
Press SET
Press ON/OFF to disable ( X )
For single disable select PROGRAM with
For master disable go to using
2
Press SET 3 times to exit (single disable)
OR press SET 4 times to exit (master)
CLOCK
Programs are arranged in a circular pattern
with the clock and countdown functions:
CLOCK Program 1-20 CD
Repeat steps to to undo disable ( X )
14
Press CD to start the countdown function
TIMING CONTROL DIAL
MODE SWITCH BRIGHTNESS DIAL
NEW CODE BUTTON
RF “TRANSMIT” BUTTON
LED INDICATOR
PHOTOCELL
The transmitter uses an intelligent code system to prevent interference
from other sources. But if you do experience such interference, you can
press the NEW CODE button to generate a new random house code.
However, after pressing the NEW CODE button, you will need to redo the
LEARNING procedure as described above.
The photocell transmitter can control multiple remote programmable timers.
PHOTOCELL TRANSMITTER
*
The LED INDICATOR of the transmitter will:
1Once you insert batteries into the transmitter, you will automatically enter
the user setting mode. This mode will last for two minutes in which you
can easily adjust the brightness or light sensitivity of the photocell sensor.
Alternately, you can press the RF button on the transmitter to enter the
user setting mode.
2In user setting mode, turn the BRIGHTNESS DIAL to adjust the light
sensitivity of the photocell sensor.
2
user setting mode
> TURN ON - when the photocell sensor detects that it is bright
Use the LED INDICATOR (on front of transmitter) as a reference, so that
you can fine tune the light sensitivity as desired.
> TURN OFF - when the photocell sensor detects that it is dark
*
1
2
*
1
learn function
PHOTOCELL TRANSMITTER
Transmits an “ON” command to the timer when photocell
senses a change from dark to bright. Transmits an “OFF”
command after the time delay as set by the Timing
Control Dial or when it turns from bright to dark.
3Once the learn function has been successfully executed,
the symbol will flash on the top right corner of the LCD
on the timer, every time the transmitter sends a signal or
when the RF button is pressed.
3
day mode / night mode
The photocell transmitter works by detecting the brightness level of its
surroundings and sends ON or OFF commands to the timer. The transmitter can
be set to trigger the timer to run for 30mins, 1, 2, 4, 6, 8, 10hrs or continuously,
and will automatically turn the timer OFF when the photocell senses a change
from dark to bright (in NIGHT mode) or bright to dark (in DAY mode).
Transmits an “ON” command to the timer when photocell
senses a change from bright to dark. Transmits an “OFF”
command after the time delay as set by the Timing
Control Dial or when it turns from dark to bright.
DAY MODE:
NIGHT MODE:
Turn TIMING CONTROL DIAL to select delay off time.
(30 minutes, 1, 2, 4, 6, 8, 10 hours, or continuous)
Slide MODE SWITCH: up for DAY mode
and down for NIGHT mode
2
2
This device complies with Part 15 of the FCC Rules and RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
FCC / RSS-210 COMPLIANCE
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including
interference that may cause undesired operation.
Flashing for short random
Flashing for long random
1
2Press RANDOM
3
Short random from
OR Long random from
CD
RND
LRND
-
* Short random 1-2 hours, long random 2-3 hours
1
2Press RANDOM
Set program 20 to desired random time
3
3
Select program 20 with
Solid for programmable
random
RND
* Programmable random only works with program 20; 1-2 hours
4
Deactivate random function with RANDOM or ON/OFF
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
1
1
2
3
57 9
2 4 6 8
10
CLOCK
Go to using
CLOCK
To activate/deactivate Daylight Saving Time (DST) function, press
and hold both and together for 3 seconds in mode;
solid for DST.
To toggle between 12/24 hour format, press RANDOM during
clock setting.
1
2
3
COUNTDOWN
SET
ON/OFF
PROGRAM
TIMER OPERATION
Programmable Timer Photocell Transmitter
RCT100 + RT601
Programmable Timer with
Wireless Photocell Transmitter
1
4
2
5
6
7
8
3
1
2
3
4
LEARN
PROGRAM
ON/OFF CD
SET
RANDOM
RESET
setting the clock
INSTRUCTION TO THE USER
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and if not installed and used in accordance with the
instructions , may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
PHOTOCELL TRANSMITTER
For safety, set the photocell transmitter to trigger the
lights ON inside your doorway at dusk.
For convenience, set the photocell transmitter to start
your coffee maker at first light.
For security, set the transmitter to activate lights in
your home while you are away (day or night).
For energy savings, set the transmitter to trigger your
timer for controlled periods of time.
To maximize functionality, combine the time settings of
the photocell transmitter with those of the
programmable timer to achieve your desired ON/OFF
applications.
20 ON/OFF settings
Countdown timer
3 random functions
12/24 hour clock
15A, 1800W (resistive)
433 MHz RF technology
Activates timer at dusk
or at dawn
Timing Control Dial -
(30mins, 1, 2, 4, 6, 8,
10hrs, or continuous
operation)
Brightness Dial - for light
sensitivity adjustment
Transmission range: up
to 40m in open area
1
4
2
5
6
7
8
Press SET
Day select with
Press SET
Hour select with
9
10
3
Press SET
Second select with
Press SET
Press SET
Minute select with
OWNERS
MANUAL
Congratulations on your
purchase of a UPM remote
control product. Please
take the time to read and
understand this manual so
you can begin to enjoy the
convenience and energy
saving benefits this product
has to offer.
PROGRAMMABLE TIMER
PHOTOCELL TRANSMITTER
applications
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
In order to maintain compliance with FCC regulations, shielded cables must
be used with this equipment. Operation with non-approved equipment or
unshielded cables is likely to result in interference to radio and TV reception.
The user is cautioned that changes and modifications made to the
equipment without the approval of manufacturer could void the user’s
authority to operate this equipment.
