Midland Radio PL450 PL1145/PL2245 Mobile Radio User Manual FCC ProLine1 2

Midland Radio Corporation PL1145/PL2245 Mobile Radio FCC ProLine1 2

Contents

FCC Proline 1 to 2

Sensitivity
12 dB SINAD .25 µV @12.5 kHz;
.28 µV @25 kHz
Selectivity >55 dB @12.5 kHz;
>60 dB @ 25 kHz
Intermodulation 55 dB @ 12.5 kHz; 60 dB @ 25 kHz
Spurious Response 60 dB 60 dB
Audio Output 500 mW (Int.) @ 8 Ω;
500 mW (Ext.) @ 8 Ω
(Method @ <10% THD level)
RF Output 1 Watt 2 Watts
Spurious and
Harmonic Emissions 43 dB 43 dB
Modulation 16K0F3E, 11K0F3E
FM Hum and Noise >34 dB @ 12.5 kHz;
>40 dB @ 25 kHz
Audio Distortion <5% <5%
Specifications are subject to change without notice.
Frequency Range (UHF) 8 Pre-programmed: 8 Pre-programmed:
464.5000 MHz, 464.5500 MHz, 467.7625 MHz
467.8125 MHz, 467.8500 MHz, 467.8750 MHz
467.9000 MHz, 467.9250 MHz
Channels 12
Channel Spacing 25 / 12.5 kHz 25 / 12.5 kHz
PLL Step 5.0 / 6.25 kHz 5.0 / 6.25 kHz
Channel Separation 3.425 MHz 3.425 MHz
Antenna Impedance 50 Ω50 Ω
Operating Voltage 7.2V DC Nominal 7.2V DC Nominal
Battery Life (with 750 mAh
NiMH battery) 14 Hours 11 Hours
(90-5-5 duty cycle) (90-5-5 duty cycle)
(with optional 1350 mAh
NiMH battery) 25 Hours 19 Hours
(90-5-5 duty cycle) (90-5-5 duty cycle)
Operating Temperature -22o F to +140o F (-30o C to +60o C)
Frequency Stability
(-30o C to +60o C) ± 5.0 ppm ± 5.0 ppm
Dimensions (H x W x D)
(with battery) 4-7/8" x 2-1/4" x 1-1/4"
(125 x 58 x 32 mm)
Weight (with 750 mAh
NiMH battery and antenna) 13.6 oz. (380 gm)
FCC Identifier O7KPL450 O7KPL450
FCC Compliance Parts 22, 74, 90 Parts 22, 74, 90, 95
IC Certification Number pending pending
StandardStandard
StandardStandard
Standard 810F810F
810F810F
810F Metho Metho
Metho Metho
Methodd
dd
d / Procedure / Procedure
/ Procedure / Procedure
/ Procedure
Light Rain 506.4 / Proc. II
Humidity 507.4 / Proc. I
Dust 510.4 / Proc. I
Vibration 514.4 / Proc. I
Shock 516.4 / Proc. I, IV
spespe
spespe
specc
cc
cii
ii
iff
ff
ficationsications
icationsications
ications
10828 NW Air World Drive
Kansas City, Missouri 64153
800-821-7848, Ext. 699 • Fax: 816/891-8815
www.topaz3.com
For more information, contact:
P/N: 680-120-2036
transmitter
(measurement procedures made per ANSI/TIA / EIA-603)
receiver (measurement procedures made per ANSI/TIA / EIA-603)
ProLine PL2245 / PL1145
UHF model UHF model
PL1145 PL2245
ISO 9002
Certification
featurfeatur
featurfeatur
features / functionses / functions
es / functionses / functions
es / functions
• 2 Channel, 2 Watt model PL2245;
1 Channel, 1 Watt model PL1145
• Programmable 12.5 kHz / 25 kHz channel spacing
• Meets MIL-STD810F specifications
• 38 Standard, 11 non-standard CTCSS tones
• Locking single-pin accessory connector
• TX Inhibit
• Time-out-timer
• Battery save circuitry
• Die-cast aluminum frame, polycarbonate cabinet
• Tri-color LED
• Spring steel belt clip
• Manufactured under ISO 9002 quality standards
• FCC Certified for use in U.S.A and its possessions
Batteries:Batteries:
Batteries:Batteries:
Batteries:
750 mAh NiMH Battery pack (ACC-201); 1350 mAh NiMH
Battery pack (ACC-202)
Antenna:Antenna:
Antenna:Antenna:
Antenna: UHF Antenna, 6", 465 MHz (ACC-146)
Chargers:Chargers:
Chargers:Chargers:
Chargers: Single unit desktop "slow" charger (ACC-410); Single unit
desktop "fast" charger (ACC-412)
Audio:Audio:
Audio:Audio:
Audio: Lapel speaker microphone with ear jack, locking connector
(ACC-726)
Carrying:Carrying:
Carrying:Carrying:
Carrying:
Belt clip (720-0000-003)
accessories / optionsaccessories / options
accessories / optionsaccessories / options
accessories / options
Supplier of Maxon®, Legacy and TruTalk products
MILMIL
MILMIL
MIL-STD methods / pr-STD methods / pr
-STD methods / pr-STD methods / pr
-STD methods / procedurocedur
ocedurocedur
ocedureses
eses
es
general
The ProLine PL1145 and PL2245 meet the following:
