CORRECTED Revised Manual infor for Antenna Info
Mode of Operation: Mobile Mine Vehicle
Antenna Type: Internal Quad Vivaldi
Model Number: n/a
MFG: Modular Mining Systems
3289 E. Hemisphere Loop
Tucson, AZ. 85706
Antenna Gain: 6 dBi
Antenna Pattern: 190 AZ, 28 EL
Antenna EIRP:
Minimum Configuration Below:
Cable Length: None
Cable Type: n/a
Cable Loss:
Insertion Loss: 1.5dB
Mode of Operation: Access Point (Repeater)
Antenna Type: Vertical Omni
Model Number: DB906SN-T
MFG: Decibel Products
P.O. Box 569610
Dallas TX 75247-3701
Antenna Gain: 8 dBi
Antenna Pattern: Omni AZ, 15 EL
Antenna EIRP:
Minimum Configuration Below:
Cable Length: 30 Feet
Cable Type: LMR-400
Cable Loss: 6.69 dB /100 ft
Insertion Loss: 2.0 dB
