FCC Permissive Change Application for Motorola i886-Series Transceivers FCC ID: IHDP56LL1

iDEN, Motorola Inc., 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN

Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3)

The attached User’s Manual is the final production-intended version of the generic Motorola

International English User Manual. This guide will be adapted to carrier-specific versions, but the key

information herein will be retained. Translations into other languages will also be done to support the

needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to,

placing this product onto the market. Selected portions of the User Guide can be found as indicated

below:

8.1 Safety and Regulatory Section: Page 45

8.2 Part 15B Declaration of Conformity: Page 50

8.3 Specific Absorption Rate (SAR) Data: Page 49

8.4 Guidance for use with Hearing Aids: Page 13, 54

12 Push-to-Talk

Push-to-Talk

one or more, talk to them all

Private calls

Private calls are push-to-talk calls between two people.

Make and answer private calls

To make a private call:

•Enter the recipient’s PTT

number.

Tip: The first contact in

Contacts contains your PTT

number.

•Select > Contacts, and select a contact that

has a PTT number.

To talk, press and hold the PTT Button. To listen,

release the PTT Button.

To answer a private call, press the PTT Button after the

caller has stopped talking.

To end a private call, press End/Power or do

nothing. The call will end after a few seconds.

PTT timeout

You can extend the automatic timeout of a PTT call by

about 30 seconds using the Resume PTT setting.

PTT

Button

Find it: > Settings > Call settings > Push to

Talk settings > Resume PTT

One touch PTT

You can customize the PTT Button for quick access to

push-to-talk functions.

Find it: > Settings > Call settings > Push to

Talk settings > One Touch PTT

Tip: You can add the One Touch PTT widget to your

home screen. See “Widgets” on page 7.

Call alerts

Use call alerts to tell someone you want to speak to

them.

options

Off Tu r n o ff One Touch PTT.

Launch PTT

Contacts List

Open a list of push-to-talk

contacts on your phone.

PTT a selected

contact

Start a private call with the

selected contact.

PTT the most

recent

number

Start a push-to-talk call with the

most recent PTT number in the

Call log.

13Push-to-Talk

To send a call alert:

•Enter a PTT ID, and press Menu/Lock > Send

Alert. When prompted, press the PTT Button.

•Select > Contacts, and select a contact

containing a PTT ID. Select Send Alert, and press

the PTT Button when prompted.

When you receive a call alert, you can:

• Answer: Push PTT Button to begin a private call

with the sender.

• Later: Store the call alert to Notifications.

• Dismiss: Dismiss the call alert.

Note: Call alerts will automatically be moved to

Notifications after a few minutes of inactivity. You

won’t be able to make phone calls or private calls

until the call alert is moved, or you’ve chosen one of

these options.

Push to send

During a private call, you can send contacts, photos,

events, or your contact info.

Find it: Menu/Lock > Share contact, Share

picture, Share event, or Share my info

Switch from a private call to a phone call

For longer calls, you can switch from a private call to a

phone call if the private call recipient has a phone

number stored in Contacts.

During a private call, press Menu/Lock > Call

contact.

Unanswered calls

If you receive an error when making a private call, or

press End/Power to end an incoming or outgoing

private call before it’s answered, you can send an

automatic text message to the other caller.

Find it: > Settings> Call settings > Auto Text

reply > Incoming call or Outgoing call

Group calls

Need to talk to more than one person at a time? With

group calls you can talk to up to 20 people at a time.

Note: To store groups on your phone you need a

group-call-capable SIM card. Contact your service

provider for more information.

To create a group, select > Contacts >

Menu/Lock > New Group, and select the group

members. Select Save to save it in your contacts.

Note: If you don’t enter a name for the group, it will be

stored as “Group”.

14 Push-to-Talk

To make a group call, select > Contacts, select

the group you wish to call and press the PTT Button.

Talkgroups

Have a larger audience than 20 people? Talkgroups are

the solution.

Note: Availability of Talkgroups, and the maximum

number of Talkgroup members, is dependent on your

service provider. Contact your service provider to

establish a Talkgroup.

Join a Talkgroup

Before you can make a Talkgroup call, you’ll need to

join the Talkgroup.

1Select > Contacts, and press

Menu/Lock > Enter Talkgroup. Name the

Talkgroup and enter the Talkgroup number. Select

Done.

2Select the Talkgroup in your contacts.

3Select Join.

Make a Talkgroup call

•Enter the Talkgroup number and press the PTT

Button.

Tip: Talkgroup numbers begin with a #. For example

#155.

•Select > Contacts, select the Talkgroup and

press the PTT Button.

Set push-to-talk speaker

You can listen to push-to-talk calls

through your phone’s speaker or

earpiece. Press Speaker to turn

the speaker on or off.

Speaker Key

15MOTOtalk™

MOTOtalk™

Note: This feature may not be offered by your service

provider.

MOTOtalk allows for off-network calls between

MOTOtalk enabled phones and Family Radio Service

products.

Note: Range will vary based on terrain, man-made

structures and atmospheric conditions.

MOTOtalk lets you:

•Use code or private mode operation

•Use up to 10 channels and 15 codes

•Communicate with standalone MOTOtalk radios

Note: You can’t use MOTOtalk with older Family Radio

Service products.

Some features and main menu items are unavailable

while in MOTOtalk:

•On-network phone or PTT calls

•Data transmission

•Incoming message notification

•Datebook

•Call forwarding

•Call alerts

Switch to MOTOtalk

1Select > Mototalk.

2Select Enter Mototalk.

Exit MOTOtalk

To switch to network mode, select > Mototalk

>Exit Mototalk.

Talk range

While in MOTOtalk mode, phones should be a

minimum of 6 feet apart.

Channels and codes

Note: When making a code call, all parties that are on

your code and channel can hear your conversation.

Set channels and codes

To set a channel:

1From the home screen, press Menu/Lock

>Tune Mototalk.

2Select the channel field, scroll to a channel and

press to select it.

3Select Done.

To set a code:

16 MOTOtalk™

1From the home screen, press Menu/Lock

>Tune Mototalk.

2Select the code field, scroll to a code and press

to select it.

3Select Done.

Make code calls

To make a code call:

1Press and hold the PTT Button. Begin speaking after

you hear the MOTOtalk tone.

2Release the PTT Button to listen.

If you receive an error message, it may mean:

•No one is on your channel or code.

•You are out of range.

Receive code calls

After hearing the MOTOtalk tone, you have 6 seconds

to reply before the call times out.

To reply to the call, press and hold the PTT Button.

Note: A MOTOtalk call can be ended at any time by

pressing End/Power .

Receive all MOTOtalk calls

If you set the code to Receive All, your phone can

receive MOTOtalk transmissions from any phone that

is set to the same channel, regardless of the code

(1-15). When you receive transmissions with the code

set to Receive All, the code that the transmission was

received on will replace Receive All on the display.

Note: You cannot initiate a code call when the code is

set to Receive All.

To set the code to Receive All:

1From the home screen, press Menu/Lock

>Tune Mototalk.

2Select the code field, scroll to Receive All and press

to select it.

3Select Done to return to the home screen.

Private MOTOtalk calls

If you want to have a private conversation without

other parties listening in, you can make a private

MOTOtalk call. The person you are calling must be in

MOTOtalk and set to the same channel to receive your

call.

17MOTOtalk™

Private only

To set MOTOtalk to ignore code calls, so that you only

make or receive private MOTOtalk calls, set your code

to Private Only.

To set the code to Private Only:

1From the home screen, press Menu/Lock

>Tune Mototalk.

2Select the code field, scroll to Private Only and

press to select it.

3Select Done to return to the home screen.

Make a private MOTOtalk call

1Enter the Personal Telephone Number (PTN) of the

person you want to call on your channel. If the PTN

is more than 10-digits, enter the last 10-digits of the

PTN, or scroll to a number or name in Contacts or

Call log.

2Press and hold the PTT Button. Begin speaking after

your phone emits the MOTOtalk tone.

3Release the PTT Button to listen.

The number or name of the person you are calling will

appear in the display.

If you receive an error message:

•The PTN you entered is invalid.

•The person that you are trying to reach is in network

mode.

•The person that you are trying to reach is set to a

different channel.

•The person that you are trying to reach is out of

range.

Receive a private MOTOtalk call

The number or name of the person who is calling will

appear in the display.

To reply, press and hold the PTT Button.

End code calls and private MOTOtalk calls

Code calls and private MOTOtalk calls will end

automatically after 6 seconds of inactivity.

Note: A private or code MOTOtalk call can be

interrupted during the 6 second idle time by another

code call or private call.

Make emergency calls while in MOTOtalk

If you attempt to make an Emergency 911 call while in

MOTOtalk mode, your phone will automatically exit

MOTOtalk mode and attempt to find a network signal.

If you are out of network coverage your phone will not

be able to make an emergency 911 cellular call until

you go back into the network coverage area.

18 Web

You must wait until the phone reconnects to the

network before attempting to make an emergency 911

cellular call.

MOTOtalk mode alert

Have an alert sound notify you that you have used

MOTOtalk for a specified interval

1From the home screen, press Menu/Lock

>Tune Mototalk.

2Select the Mototalk Mode Alert field, and choose

a time interval for the alert.

Web

you don’t need a PC to surf

Quick start: Browser

Find it: > Browser

Note: If you can’t connect, contact your service

provider.

Connect

Your phone uses the mobile phone network (over the

air) to automatically connect to the Web.

Opera Mini

Back

Forward

Reload

Start Page

Exit

New Tab

Press Menu/Lock and

press the Navigation Key down

twice to open a menu where

you can open your bookmarks,

a new window and more.

19Web

Note: Your service provider may charge to surf the

Web or download data.

Select web links

When you select a link, your

phone outlines it and goes to

that page. If you highlight the

link, then press and hold ,

your phone shows options, like

Open in new tab.

Browser options

Press Menu/Lock to see browser options:

options

Bookmarks Add, delete and manage

bookmarks.

Feeds View and manage RSS feeds.

History View and clear your browser’s

history.

Saved Pages Save Web pages.

Downloads View your downloads.

Zoom

To zoom in to an area of the Web page you’re viewing,

use the Navigation Key to move the magnifier box over

it and press . To zoom out, press Back .

Settings Open your browser’s settings

menu.

Find in Page Search Web pages for words or

phrases.

Help Open your browser’s help menu.

options

Search www.opera.com

Opera Press Releases RSS feed

Opera Mini Overview Opera Mini 4 Opera Mini 5 Beta Download Demo Help Developer

Fast Savings Full Web Opera Link

Experience the full internet

with the fastest mobile phone

browser in the world

Web pages are compressed by

up to 90% of their original size,

saving your time and money.

Access your favorite Web sites

as you do on a desktop browser

for a better mobile internet

experience.

Synchronize your bookmarks

and Speed Dial between mobile

phones or a computer.

Opera >> Opera Mini

Get Opera

PC, Mac & Linux

Mobile phones

Devices

Add=ons

Opera Link

Opera Unite

Opera Mail

Opera Turbo

Opera Dragonfly

Opera Widgets

Community

My Opera

Forums

Blogs

Choose Opera

Developer

Campus Crew

Press

Press releases

Press resources

Opera Video

Fast facts

FAQ

SMW report

Business

Overview

Solutions

Customers

Awards

Newsletter

Useful links

Support

Documentation

Knowledge Base

Site map

Job opportunities

Contact

English

we’re here to help

Crash recovery

In the unlikely event that your phone stops responding

to key presses, try a quick reset. Remove the back

cover and battery (“Assemble & charge” on page 3),

then replace and switch your phone on as usual.

Reset

To reset your phone to factory settings and erase all

the data on your phone, select > Settings

>Privacy > Master Clear.

Warning: All data on your phone will be deleted.

Service & repairs

If you have questions or need assistance, we're here

to help.

Go to www.motorola.com/repair (United States),

where you can select from a number of customer care

options. You can also contact the Motorola Customer

Support Center at 1 (800) 453-0920 (United States) or

1 (877) 483-2840 (TTY, TDD United States for hearing

impaired).

41Troubleshooting

Update my phone

Stay up to date with the latest software updates for

your phone. You can check, download, and install

updates using your phone or your computer:

•Using your phone:

You may get an automatic notification of an available

update on your phone. Follow the instructions to

download and install.

To manually check for updates, select

>Settings > About phone > System updates.

Your phone downloads any updates over your

mobile network. Remember, these updates can be

quite large (25MB or more) and may not be available

in all countries. If you don’t have an unlimited data

plan, or mobile network updates are not available in

your country, you can update using a computer.

•Using your computer:

On your computer, go to

www.motorola.com/support and check the

“Software” links. If an update is available, simply

follow the installation instructions.

42 Troubleshooting

Safety, Regulatory & Legal

Battery Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most battery issues arise from improper handling of batteries, and particularly from

the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to

change the form of your battery.

• Don’t let the mobile device or battery come in contact with water.*

Water

can get into the mobile device’s circuits, leading to corrosion. If the mobile device

and/or battery get wet, have them checked by your service provider or contact

Motorola, even if they appear to be working properly.*

• Don’t allow the battery to touch metal objects.

If metal objects, such as

jewelry, stay in prolonged contact with the battery contact points, the battery

could become very hot.

• Don’t place your mobile device or battery near a heat source.*

Excessive

heat can damage the mobile device or the battery. High temperatures can cause

the battery to swell, leak, or malfunction. Therefore:

• Don’t dry a wet or damp battery with an appliance or heat source

, such as

a hair dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the battery or mobile device.*

Dropping these items,

especially on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or

battery has been damaged from dropping or high temperatures.

* Note:

Always make sure that the battery compartment is closed and secure to

avoid direct exposure of the battery to any of these conditions.

Important: Use Motorola Original products for quality assurance and

safeguards.

To aid consumers in identifying authentic Motorola batteries from

non-original or counterfeit batteries (that may not have adequate safety protection),

Motorola provides holograms on its batteries. Consumers should confirm that any

battery they purchase has a “Motorola Original” hologram.

Motorola recommends you always use Motorola-branded batteries and

chargers.

Motorola mobile devices are designed to work with Motorola batteries.

If you see a message on your display such as

Invalid Battery

Unable to Charge

, take the following steps:

•

Remove the battery and inspect it to confirm that it has a “Motorola Original”

hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorized service center.

Important:

Motorola’s warranty does not cover damage to the mobile device caused

by non-Motorola batteries and/or chargers.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

Proper battery disposal is not

only important for safety, it benefits the environment. Consumers may recycle their

used batteries in many retail or service provider locations. Additional information on

proper disposal and recycling may be found on the Web:

•

www.motorola.com/recycling

•

www.rbrc.org/call2recycle/

(in English only)

Disposal:

Promptly dispose of used batteries in accordance with local

regulations. Contact your local recycling center or national recycling

organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery Charging

Notes for charging your product’s battery:

•

When charging your battery, keep it near room temperature. Never expose

batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when

charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

032375o

43Troubleshooting

•

Motorola batteries and charging systems have circuitry that protects the battery

from damage from overcharging.

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel

of a vehicle. Using a mobile device or accessory for a call or other application while

driving may cause distraction. Using a mobile device or accessory may be prohibited

or restricted in certain areas, always obey the laws and regulations on the use of

these products.

While driving, NEVER:

•

Type or read texts.

•

Enter or review written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Use a handsfree device if available or required by law in your area.

•

Enter destination information into a navigation device

before

driving.

•

Use voice activated features (such as voice dial) and speaking features (such as

audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories

in the vehicle.

•

End your call or other task if you cannot concentrate on driving.

Remember to follow the “Smart Practices While Driving” in this guide and at

www.motorola.com/callsmart

(in English only).

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to

flashing lights, such as when playing videos or games. These may occur even if a

person has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such

occurrences, please consult with your physician before playing videos or games or

enabling a flashing-lights feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following symptoms occur:

convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or

disorientation. It is always a good idea to hold the screen away from your eyes,

leave the lights on in the room, take a 15-minute break every hour, and stop use if

you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended

periods of time may affect your hearing. The louder the volume sound

level, the less time is required before your hearing could be affected.

To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you.

If you experience hearing discomfort, including the sensation of pressure or fullness

in your ears, ringing in your ears, or muffled speech, you should stop listening to the

device through your headset or headphones and have your hearing checked.

For more information about hearing, see our Web site at

direct.motorola.com/hellomoto/nss/AcousticSafety.asp

(in English

only).

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering

finger-written characters, you may experience occasional discomfort in your hands,

arms, shoulders, neck, or other parts of your body. If you continue to have discomfort

during or after such use, stop use and see a physician.

[Nov0109]

Small Children

Keep your mobile device and its accessories away from small children.

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

44 Troubleshooting

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if

the product is dropped on a hard surface or receives a substantial impact. If glass

breaks, do not touch or attempt to remove. Stop using your mobile device until the

glass is replaced by a qualified service center.

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and

can include fueling areas, such as below decks on boats, fuel or chemical transfer or

storage facilities, or areas where the air contains chemicals or particles, such as

grain dust, or metal powders.

When you are in such an area, turn off your mobile device, and do not remove,

install, or charge batteries unless it is a radio product type especially qualified for

use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL

approved). In such areas, sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in

accordance with local laws. Contact your local regulatory

authorities for more information.

032374o

032376o

032375o

Radio Frequency (RF) Energy

Exposure to RF Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives

and transmits RF energy. When you communicate with your mobile device, the

system handling your call controls the power level at which your mobile device

transmits.

Your mobile device is designed to comply with local regulatory requirements in your

country concerning exposure of human beings to RF energy.

RF Energy Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF

energy does not exceed the guidelines set forth in the relevant standards, always

follow these instructions and precautions:

•

When placing or receiving a phone call, hold your mobile device just like you

would a landline phone.

•

If you wear the mobile device on your body, always place the mobile device in a

Motorola-supplied or approved clip, holder, holster, case, or body harness. If you

do not use a body-worn accessory supplied or approved by Motorola and are not

using the mobile device in the intended use positions along side the head in the

Do not dispose of your battery or mobile device with your

household waste. See “Recycling” for more information.

For indoor use only.

Listening at full volume to music or voice through a headset may

damage your hearing.

Symbol Definition

phone mode or in front of the face in the two-way radio mode, keep the device at

least 2.5 centimeters (1 inch) from your body when transmitting.

•

Using accessories not supplied or approved by Motorola may cause your mobile

device to exceed RF energy exposure guidelines. For a list of Motorola-supplied

or approved accessories, visit our Web site at:

www.motorola.com

Two-Way Radio Operation

Your radio product has been designed and tested to comply with national and

international standards and guidelines regarding human exposure to RF

electromagnetic energy, when operated in the two-way mode (at the face, or at the

abdomen when using an audio accessory) at usage factors of up to 50% talk/50%

listen.

Transmit no more than the rated duty factor of 50% of the time. To transmit (talk),

push the PTT button. To receive calls, release the PTT button. Transmitting 50% of

the time or less, is important because this radio generates measurable RF energy

only when transmitting (in terms of measuring for standards

compliance).

When using your radio product as a traditional two-way radio,

hold the radio product in a vertical position with the

microphone 2.5 to 5 centimeters (1 to 2 inches) away from

the lips

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external

sources if inadequately shielded, designed, or otherwise configured for RF energy

compatibility. In some circumstances, your mobile device may cause interference

with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do

so.

In an aircraft, turn off your mobile device whenever instructed to do so by airline

staff. If your mobile device offers an airplane mode or similar feature, consult airline

staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator,

consult your physician before using this mobile device.

Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the

implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential

for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place.

Read and follow the directions from the manufacturer of your implantable medical

device. If you have any questions about using your mobile device with your

implantable medical device, consult your healthcare provider.

Portable Radio Product Operation and

EME Exposure

Your Motorola radio product is designed to comply with the following national and

international standards and guidelines regarding exposure of human beings to radio

frequency electromagnetic energy (EME):

•

United States Federal Communications Commission, Code of Federal

Regulations; 47 CFR part 2 sub-part J.

•

American National Standards Institute (ANSI) / Institute of Electrical and

Electronics Engineers (IEEE). C95. 1-1992.

•

Institute of Electrical and Electronics Engineers (IEEE). C95. 1-2005 Edition.

•

International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998.

•

Ministry of Health (Canada). Safety Code 6. Limits of Human Exposure to Radio

frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz,

1999.

•

Australian Communications Authority Radio communications (Electromagnetic

Radiation - Human Exposure) Standard 2003.

•

ANATEL, Brazil Regulatory Authority, Resolution 303 (July 2, 2002) “Regulation of

the limitation of exposure to electrical, magnetic, and electromagnetic fields in

the radio frequency range between 9 kHz and 300 GHz.” “Attachment to

Resolution 303 from July 2, 2002."

Specific Absorption Rate (IEEE)

SAR (IEEE)

Your model wireless phone meets the governmental

requirements for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed and

manufactured to not exceed limits for exposure to radio frequency (RF) energy set by

the Federal Communications Commission (FCC) of the U.S. Government and by the

Canadian regulatory authorities. These limits are part of comprehensive guidelines

and establish permitted levels of RF energy for the general population. The

guidelines are based on standards that were developed by independent scientific

organizations through periodic and thorough evaluation of scientific studies. The

standards include a substantial safety margin designed for the safety of all persons,

regardless of age or health, and to account for any variations in measurements.

The exposure standard for mobile devices employs a unit of measurement known as

the Specific Absorption Rate (SAR). The IEEE SAR limit set by the FCC and by the

Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one

gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC

and by Industry Canada with the mobile device transmitting at its highest certified

power level in all tested frequencies. Although the SAR is determined at the highest

certified power level, the actual SAR level of the mobile device while operating can

be below the maximum value. This is because the mobile device is designed to

operate at multiple power levels so as to use only the power required to reach the

network. In general, the closer you are to a wireless base station, the lower the

power output.

Before a mobile device is available for sale to the public in the U.S. and Canada, it

must be tested and certified to the FCC and Industry Canada that it does not exceed

the limit established by each government for safe exposure. The tests are performed

in positions and locations (e.g., at the ear and worn on the body) submitted to the

FCC and available for review by Industry Canada. The highest SAR value for this

mobile device when tested for use at the head is 0.87 W/kg, and when worn on the

body, as described in this guide, is 1.08 W/kg. Body-worn measurements can differ,

depending upon available accessories and regulatory requirements. The SAR

information includes the Motorola testing protocol, assessment procedure, and

measurement uncertainty range for this product.

While there may be differences between the SAR levels of various mobile devices

and at various positions, they meet the governmental requirements for safe

exposure. Please note that improvements to this product model could cause

differences in the SAR value for later products; in all cases, products are designed to

be within the guidelines.

Additional information on SAR can be found on the Cellular Telecommunications

& Internet Association (CTIA) Web site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site:

http://www.cwta.ca

Specific Absorption Rate (ICNIRP)

SAR (ICNIRP)

Your model wireless phone meets international

guidelines for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed to not exceed

the limits for exposure to radio waves recommended by international guidelines.

These guidelines were developed by the independent scientific organization ICNIRP

and include safety margins designed to assure the protection of all persons,

regardless of age and health, and to account for any variations in measurements.

The guidelines use a unit of measurement known as the Specific Absorption Rate

(SAR). The ICNIRP SAR limit for mobile devices used by the general public is 2 watts

per kilogram (W/kg), and the highest SAR value for this mobile device when tested

at the head is 0.60 W/kg. As mobile devices offer a range of functions, they can be

used in other positions, such as on the body as described in this guide. In this case,

the highest tested SAR value is 0.78 W/kg. The tests are carried out in accordance

with international guidelines for testing. The SAR information includes the Motorola

testing protocol, assessment procedure, and measurement uncertainty range for this

product.

As SAR is measured utilizing the mobile device’s highest transmitting power, the

actual SAR of this mobile device while operating is typically below that indicated

above. This is due to automatic changes to the power level of the mobile device to

ensure it only uses the minimum level required to reach the network.

While there may be differences between the SAR levels of various mobile devices

and at various positions, they meet the governmental requirements for safe

exposure. Please note that improvements to this product model could cause

differences in the SAR value for later products; in all cases, products are designed to

be within the guidelines.

The World Health Organization has stated that present scientific information does

not indicate the need for any special precautions for the use of mobile devices. They

note that if you want to reduce your exposure, then you can do so by limiting the

length of calls or using a handsfree device to keep the mobile device away from the

head and body.

Additional Information can be found on the Web sites of the World Health

Organization (

http://www.who.int/emf

) or Motorola Mobility, Inc.

(

http://www.motorola.com/rfhealth

Information from the World Health

Organization

WHO Informat ion

“Present scientific information does not indicate the need for any special

precautions for the use of mobile phones. If you are concerned, you may want to

limit your own or your children’s RF exposure by limiting the length of calls or by

using handsfree devices to keep mobile phones away from your head and body.”

Source: WHO Fact Sheet 193

Further information:

http://www.who.int/peh-emf

FCC Declaration of Conformity

FCC DoC

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party Name: Motorola Mobility, Inc.

Address: 8000 West Sunrise Boulevard,

Plantation, FL 33322 USA

Phone Number: 1 (800) 453-0920

Hereby declares that the product:

Product Name: i886

Model Number: H86XAH6JR7AN

FCC ID: IHDP56LL1

Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a),

15.107(d) and section 15.109(a)

FCC Notice to Users

FCC Notice

The following statement applies to all products that have received FCC

approval. Applicable products bear the FCC logo, and/or an FCC ID in the

format FCC ID:xxxxxx on the product label.

Motorola has not approved any changes or modifications to this device by the user.

Any changes or modifications could void the user’s authority to operate the

equipment. See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation. See 47 CFR Sec. 15.19(3).

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Industry Canada Notice to Users

Indust ry Canada Not ice

Operation is subject to the following two conditions: (1) This device may not cause

interference and (2) This device must accept any interference, including interference

that may cause undesired operation of the device. See RSS-GEN 7.1.5. This Class B

digital apparatus complies with Canadian ICES-003.

GPS & AGPS

Your mobile device can use Global Positioning System (GPS) signals for

location-based applications. GPS uses satellites controlled by the U.S. government

that are subject to changes implemented in accordance with the Department of

Defense policy and the Federal Radio Navigation Plan. These changes may affect

the performance of location technology on your mobile device.

Your mobile device can also use Assisted Global Positioning System (AGPS), which

obtains information from the cellular network to improve GPS performance. AGPS

uses your wireless service provider's network and therefore airtime, data charges,

and/or additional charges may apply in accordance with your service plan. Contact

your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the

approximate location of a mobile device. Mobile devices which are connected to a

wireless network transmit location-based information. Devices enabled with GPS or

AGPS technology also transmit location-based information. Additionally, if you use

applications that require location-based information (e.g. driving directions), such

applications transmit location-based information. This location-based information

may be shared with third parties, including your wireless service provider,

applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS

technology in your mobile device to tell the emergency responders your approximate

location.

AGPS has limitations and

might not work in your area

. Therefore:

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

Performance Tips

•

Go outside and away from underground locations, covered vehicles, structures

with metal or concrete roofs, tall buildings, and foliage. Indoor performance

might improve if you move closer to windows, but some window sun shielding

films can block satellite signals.

•

Move away from radios, entertainment equipment, and other electronic devices.

Navigation

When using navigation features, note that mapping information, directions and

other navigational data may contain inaccurate or incomplete data. In some

countries, complete information may not be available. Therefore, you should visually

confirm that the navigational instructions are consistent with what you see. All

drivers should pay attention to road conditions, closures, traffic, and all other factors

that may impact driving. Always obey posted road signs.

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their ac-

cessories in the areas where you drive. Always obey them. The use of these

devices may be prohibited or restricted in certain areas—for example,

handsfree use only may be required. Go to

www.motoro-

la.com/callsmart

(in English only) for more information.

Your mobile device lets you communicate by voice and data—almost anywhere,

anytime, wherever wireless service is available and safe conditions allow. When

driving a car, driving is your first responsibility. If you choose to use your mobile

device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed

dial, redial and voice dial.

If available, these features help you to place your

call without taking your attention off the road.

• When available, use a handsfree device.

If possible, add an additional layer

of convenience to your mobile device with one of the many Motorola Original

handsfree accessories available today.

• Position your mobile device within easy reach.

Be able to access your

mobile device without removing your eyes from the road. If you receive an

incoming call at an inconvenient time, if possible, let your voicemail answer it for

you.

• Let the person you are speaking with know you are driving; if necessary,

suspend the call in heavy traffic or hazardous weather conditions.

Rain,

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

Jotting down a

“to do” list or going through your address book takes attention away from your

primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your

car is not moving or before pulling into traffic.

If you must make a call while

moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be

distracting.

Make people you are talking with aware you are driving and

suspend conversations that can divert your attention away from the road.

• Use your mobile device to call for help.

Dial 911 or other local emergency

number in the case of fire, traffic accident, or medical emergencies (wherever

wireless phone service is available).

• Use your mobile device to help others in emergencies.

If you see an auto

accident, crime in progress, or other serious emergency where lives are in

danger, call 911 or other local emergency number (wherever wireless phone

service is available), as you would want others to do for you.

• Call roadside assistance or a special non-emergency wireless

assistance number when necessary.

If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal, a minor traffic accident where

no one appears injured, or a vehicle you know to be stolen, call roadside

assistance or other special non-emergency wireless number (wherever wireless

phone service is available).

Privacy & Data Security

Motorola understands that privacy and data security are important to everyone.

Because some features of your mobile device may affect your privacy or data

security, please follow these recommendations to enhance protection of your

information:

• Monitor access

—Keep your mobile device with you and do not leave it where

others may have unmonitored access. Lock your device’s keypad where this

feature is available.

• Keep software up to date

—If Motorola or a software/application vendor

releases a patch or software fix for your mobile device that updates the device’s

security, install it as soon as possible.

• Secure Personal Information

—Your mobile device can store personal

information in various locations including your SIM card, memory card, and

phone memory. Be sure to remove or clear all personal information before you

recycle, return, or give away your device. You can also backup your personal data

to transfer to a new device.

Note:

For information on how to backup or wipe data from your mobile device,

go to

www.motorola.com/support

• Online accounts

—Some mobile devices provide a Motorola online account

(such as MOTOBLUR). Go to your account for information on how to manage the

account, and how to use security features such as remote wipe and device

location (where available).

• Applications

—Install third party applications from trusted sources only.

Applications can have access to private information such as call data, location

details and network resources.

• Location-based information

—Location-based information includes

information that can be used to determine the approximate location of a mobile

device. Mobile phones which are connected to a wireless network transmit

location-based information. Devices enabled with GPS or AGPS technology also

transmit location-based information. Additionally, if you use applications that

require location-based information (e.g. driving directions), such applications

transmit location-based information. This location-based information may be

shared with third parties, including your wireless service provider, applications

providers, Motorola, and other third parties providing services.

• Other information your device may transmit

—Your device may also transmit

testing and other diagnostic (including location-based) information, and other

non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola.

If you have further questions regarding how the use of your mobile device may

impact your privacy or data security, please contact Motorola at

privacy@motorola.com

, or contact your service provider.

Use & Care

Use & Ca re

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity,

sweat, or other liquids. If it does get wet, don’t try to accelerate drying

with the use of an oven or dryer, as this may damage the mobile device.

extreme heat or cold

Avoid temperatures below 0°C/32°F or above 45°C/113°F.

microwaves

Don’t try to dry your mobile device in a microwave oven.

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other

inappropriate materials.

cleaning solutions

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol

or other cleaning solutions.

shock and vibration

Don’t drop your mobile device.

protection

To help protect your mobile device, always make sure that the battery

compartment and any connector covers are closed and secure.

Recycling

Mobile Devices & Accessories

Please do not dispose of mobile devices or electrical accessories (such as chargers,

headsets, or batteries) with your household waste, or in a fire. These items should

be disposed of in accordance with the national collection and recycling schemes

operated by your local or regional authority. Alternatively, you may return unwanted

mobile devices and electrical accessories to any Motorola Approved Service Center

in your region. Details of Motorola approved national recycling schemes, and further

information on Motorola recycling activities can be found at:

www.motorola.com/recycling

Packaging & Product Guides

Product packaging and product guides should only be disposed of in accordance with

national collection and recycling requirements. Please contact your regional

authorities for more details.

California Perchlorate Label

Perchlorat e Label

Some mobile phones use an internal, permanent backup battery on the printed

circuit board that may contain very small amounts of perchlorate. In such cases,

California law requires the following label:

Perchlorate Material – special handling may apply when the battery is recycled or

disposed of. See

www.dtsc.ca.gov/hazardouswaste/perchlorate

There is no special handling required by consumers.

Hearing Aid Compatibility with Mobile

Phones

Hearing Aid Compatibility

Some Motorola phones are measured for compatibility with hearing aids. If the box

for your particular model has “Rated for Hearing Aids” printed on it, the following

explanation applies.

When some mobile phones are used near some hearing devices (hearing aids and

cochlear implants), users may detect a buzzing, humming, or whining noise. Some

hearing devices are more immune than others to this interference noise, and phones

also vary in the amount of interference they generate.

The wireless telephone industry has developed ratings for some of their mobile

phones, to assist hearing device users in finding phones that may be compatible

with their hearing devices. Not all phones have been rated. Phones that are rated

have the rating on their box or a label on the box. To maintain the published Hearing

Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment

battery model.

The ratings are not guarantees. Results will vary depending on the user’s hearing

device and hearing loss. If your hearing device happens to be vulnerable to

interference, you may not be able to use a rated phone successfully. Trying out the

phone with your hearing device is the best way to evaluate it for your personal

needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to

generate less interference to hearing devices than phones that are not labeled. M4

is the better/higher of the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more

usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than

unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing

devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference.

Your hearing device manufacturer or hearing health professional may help you find

results for your hearing device. The more immune your hearing aid is, the less likely

you are to experience interference noise from mobile phones.

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software

stored in semiconductor memories or other media. Laws in the United States and

other countries preserve for Motorola and third-party software providers certain

exclusive rights for copyrighted software, such as the exclusive rights to distribute

or reproduce the copyrighted software. Accordingly, any copyrighted software

contained in Motorola products may not be modified, reverse-engineered,

distributed, or reproduced in any manner to the extent allowed by law. Furthermore,

the purchase of Motorola products shall not be deemed to grant either directly or by

implication, estoppel, or otherwise, any license under the copyrights, patents, or

patent applications of Motorola or any third-party software provider, except for the

normal, non-exclusive, royalty-free license to use that arises by operation of law in

the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of

the Copyright Laws of the United States and other countries. This device is intended

solely for copying non-copyrighted materials, materials in which you own the

are uncertain about your right to copy any material, please contact your legal

advisor.

Open Source Software Information

OSS Info rmation

For instructions on how to obtain a copy of any source code being made publicly

available by Motorola related to software used in this Motorola mobile device, you

may send your request in writing to the address below. Please make sure that the

request includes the model number and the software version number.

MOTOROLA MOBILITY, INC.

OSS Management

600 North US Hwy 45

Libertyville, IL 60048

USA

The Motorola website

opensource.motorola.com

also contains information

regarding Motorola's use of open source.

Motorola has created the

opensource.motorola.com

website to serve as a

portal for interaction with the software community-at-large.

To view additional information regarding licenses, acknowledgments and required

please press Menu Key >

Settings

About Phone

Legal information

Open source licenses

. In addition, this Motorola device may include

self-contained applications that present supplemental notices for open source

packages used in those applications.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of

America and Canada. The Governments of the United States of America and Canada

may restrict the exportation or re-exportation of this product to certain destinations.

For further information contact the U.S. Department of Commerce or the Canadian

Department of Foreign Affairs and International Trade.

Product Registration

Registration

Online Product Registration:

www.motorola.com/us/productregistration

Product registration is an important step toward enjoying your new Motorola

product. Registering permits us to contact you for product or software updates and

allows you to subscribe to updates on new products or special promotions.

Registration is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service

of your Motorola Personal Communications Product you will need to provide a copy

of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Motorola Limited Warranty

(International)

Warr ant y

What Does this Warranty Cover?

MOTOROLA warrants the MOTOROLA manufactured iDEN Communication Products

listed below (“Product”) against defects in material and workmanship under normal

use and service for a period of time from the date of purchase as scheduled below:

Rechargeable Batteries will be replaced during the applicable warranty period if:

•

the battery capacity falls below 80% of rated capacity, or

•

the battery develops leakage.

MOTOROLA, at its option, will at no charge either repair the Product (with new or

reconditioned parts, in compliance with local legislation), replace it (with a new or

reconditioned Product, in compliance with local legislation), or refund the purchase

price of the Product during the warranty period provided it is returned in accordance

with the terms of this warranty. Replaced parts or boards are warranted for the

balance of the original applicable warranty period. All replaced parts of Product

shall become the property of MOTOROLA.

This express limited warranty is extended by MOTOROLA to the original end user

purchaser only and is not assignable or transferable to any other party. This is the

Products Covered Length of Coverage

iDEN Subscriber Digital

Mobile and Portable Units

One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

Product Accessories

(manufactured by or under

license from MOTOROLA).

One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

Batteries One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

complete warranty for the Product manufactured by MOTOROLA. MOTOROLA

assumes no obligations or liability for additions or modifications to this warranty

unless made in writing and signed by an officer of MOTOROLA. Unless made in a

separate agreement between MOTOROLA and the original end user purchaser,

MOTOROLA does not warrant the installation, maintenance or service of the

Product.

MOTOROLA cannot be responsible in any way for any ancillary equipment not

furnished by MOTOROLA which is attached to or used in connection with the

Product, or for operation of the Product with any ancillary equipment, and all such

equipment if expressly excluded from this warranty. Because each system which

may use the Product is unique, MOTOROLA disclaims liability for range, coverage, or

operation of the system as a whole, or any portion of the system not produced by

MOTOROLA, under this warranty.

General Provisions:

This warranty sets forth the full extent of MOTOROLA’S responsibilities regarding

the Product, Repair, replacement or refund of the purchase price, at MOTOROLA’S

options, is the exclusive remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER

EXPRESS WARRANTIES. IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED

WARRANTY TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW. IN NO

EVENT SHALL MOTOROLA BE LIABLE FOR DAMAGES IN EXCESS OF THE

PURCHASE PRICE OF THE PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME,

INCONVENIENCE, COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER

INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE

OR INABILITY TO USE SUCH PRODUCT, TO THE FULL EXTENT SUCH MAY BE

DISCLAIMED BY LAW.

How to Get Warranty Service:

You must provide proof of purchase (bearing the date of purchase and Product item

serial number) in order to receive warranty service and, also, deliver or send the

Product item, transportation and insurance prepaid, to an authorized warranty

service location. Warranty service will be provided by MOTOROLA through one of its

authorized warranty service locations. If you first contact the company which sold

you the Product (e.g., dealer or communication service provider), it can facilitate your

obtaining warranty service.

What This Warranty Does Not Cover:

•

Defects or damage resulting from use of the Product in other than its normal and

customary manner.

•

Defects or damage from misuse, accident, water, or neglect.

•

Defects or damage from improper testing, operation, maintenance, installation,

alteration, modification, or adjustment.

•

Breakage or damage to antennas unless caused directly by defects in material

workmanship.

•

A Product subjected to unauthorized Product modifications, disassembles or

repairs (including, without limitation, the audition to the Product of

non-MOTOROLA supplied equipment).

•

Product which has had the serial number removed or made illegible.

•

Rechargeable batteries if:

Any of the seals on the battery enclosure of cells are broken or show evidence of

tampering.

The damage or defect is caused by charging or using the battery in equipment or

service other than the Product for which it is specified.

•

Freight costs to the repair depot.

•

A Product which, due to illegal or unauthorized alteration of the

software/firmware in the Product, does not function in accordance with

MOTOROLA’S published specifications or the local type acceptance labeling in

effect for the Product at the time the Product was initially distributed from

MOTOROLA.

•

Scratches or other cosmetic damage to Product surfaces that does not effect the

operation of the Product.

•

Normal and customary wear and tear.

•

Exclusion for defects or damage arising from use of the products in connection

with non-MOTOROLA equipment.

Patent and Software Provisions:

MOTOROLA will defend, at its own expense, any suit brought against the end user

purchaser to the extent that it is based on a claim that the Product or parts infringe a

patent, and Motorola will pay those costs and damages finally awarded against the

end user purchaser in any such suit which are attributable to any such claim, but

such defense and payments are conditioned on the following:

•

That MOTOROLA will be notified promptly in writing by such purchaser of any

notice of such claim;

•

That MOTOROLA will have sole control of the defense of such suit and all

negotiations for its settlement or compromise; and

•

Should the Product or parts become, or in MOTOROLA’S opinion be likely to

become, the subject of a claim of infringement of a patent, that such purchaser

will permit MOTOROLA, at its option and expense, either to procure for such

purchaser the right to continue using the Product or parts or to replace or modify

the same so that it becomes non infringing or to grant such purchaser a credit for

the Product or parts as depreciated and accept its return. The depreciation will

be an equal amount per year over the lifetime of the Product or parts as

established by MOTOROLA.

MOTOROLA will have no liability with respect to any claim of patent infringement

which is based upon the combination of the Product or parts furnished hereunder

with software, apparatus or devices not furnished by MOTOROLA, nor will

MOTOROLA have any liability for the use of ancillary equipment or software not

furnished by MOTOROLA which is attached to or sued in connection with the

Product or any parts thereof. In no event shall MOTOROLA be liable for any

incidental, special or consequential damages arising from any claim of patent

infringement or alleged infringement.

Laws in the United States and other countries preserve for MOTOROLA certain

exclusive rights for copyrighted MOTOROLA software, such as the exclusive rights

to reproduce in copies and distribute copies of such MOTOROLA software.

MOTOROLA software may be used in only the Product in which the software was

originally embodied and such software in such Product may not be replaced, copied,

distributed, modified in any way, or used to produce any derivative thereof. No other

use including, without limitation, alteration, modification, reproduction, distribution,

or reverse engineering of such MOTOROLA software or exercise or rights in such

MOTOROLA software is permitted. No license is granted by implication, estoppel or

otherwise under MOTOROLA patent rights or copyrights.

Motorola Limited Warranty for the United

States and Canada

Warr ant y

What Does this Warranty Cover?

Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES AND SOFTWARE

PURCHASED IN THE UNITED STATES OR CANADA.

Subject to the exclusions contained below, Motorola Mobility, Inc. warrants its

Motorola iDEN Digital Mobile and Portable Handsets ("Products"),

Motorola-branded or certified accessories sold for use with these Products

("Accessories") and Motorola software contained on CD-Roms or other tangible

media and sold for use with these Products ("Software") to be free from defects in

materials and workmanship under normal consumer usage for the period(s) outlined

below.

This limited warranty is a consumer's exclusive remedy, and applies

as follows to new Products, Accessories and Software purchased by

consumers in the United States or Canada, which are accompanied by this

written warranty:

Products Covered Length of Coverage

Products as defined above. One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

Accessories as defined

above.

One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

Products or Accessories that

are Repaired or Replaced.

The balance of the original warranty or

for ninety (90) days

from the date

returned to the consumer, whichever is

longer.

What is Not Covered? (Exclusions)

Normal Wear and Tear.

Periodic maintenance, repair and replacement of parts

due to normal wear and tear are excluded from coverage.

Ornamental Decorations.

Ornamental decorations such as emblems, graphics,

rhinestones, jewels, gemstones and their settings, and other decorative elements,

are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of their

rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

Defects or damage that result from: (a) improper operation,

storage, misuse or abuse, accident or neglect, such as physical damage (cracks,

scratches, etc.) to the surface of the product resulting from misuse; (b) contact with

liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like,

extreme heat, or food; (c) use of the Products or Accessories for commercial

purposes or subjecting the Product or Accessory to abnormal usage or conditions; or

(d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or damage that result

from the use of Non-Motorola branded or certified Products, Accessories, Software

or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification.

Defects or damages resulting from

service, testing, adjustment, installation, maintenance, alteration, including without

limitation, software changes, or modification in any way by someone other than

Motorola, or its authorized service centers, are excluded from coverage.

Altered Products.

Products or Accessories with (a) serial numbers or date tags

that have been removed, altered or obliterated; (b) broken seals or that show

Software

as defined above.

Applies only to physical defects

in the media that embodies the

copy of the software (e.g.

CD-ROM, or floppy disk).

Ninety (90) days from the date of

purchase.

Products Covered Length of Coverage

evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming

or non-Motorola housings, antennas, or parts, are excluded from coverage.

Communication Services.

Defects, damages, or the failure of Products,

Accessories or Software due to any communication service or signal you may

subscribe to or use with the Products, Accessories or Software is excluded from

coverage.

Software Embodied in Physical Media.

No warranty is made that the software

will meet your requirements or will work in combination with any hardware or

software applications provided by third parties, that the operation of the software

products will be uninterrupted or error free, or that all defects in the software

products will be corrected.

Software NOT Embodied in Physical Media.

Software that is not embodied in

physical media (e.g. software that is downloaded from the internet), is provided "as

is" and without warranty.

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price

of any Products, Accessories or Software that does not conform to this warranty. We

may use functionally equivalent reconditioned/refurbished/pre-owned or new

Products, Accessories or parts. No data, software or applications added to your

Product, Accessory or Software, including but not limited to personal contacts,

games and ringer tones, will be reinstalled. To avoid losing such data, software and

applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other

Information

To obtain service or information, please call:

Motorola iDEN Customer Services: 1-800-453-0920 or 954-723-4910

TTY: 877-483-2840

Or visit us online at

www.motorola.com/repair

(United States) or

www.motorola.com/support

(Canada).

You will receive instructions on how to ship the Products, Accessories or Software,

at your expense, to a Motorola Authorized Repair Center. To obtain service, you must

include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase;

(b) a written description of the problem; (c) the name of your service provider, if

applicable; (d) the name and location of the installation facility (if applicable) and,

most importantly; (e) your address and telephone number.

What Other Limitations are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE

THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS

LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS

PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO

EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT

(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF

THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL,

SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR

PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR

APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION

WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR

SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental

or consequential damages, or limitation on the length of an implied warranty, so the

above limitations or exclusions may not apply to you. This warranty gives you

specific legal rights, and you may also have other rights that vary from state to state

or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola certain

exclusive rights for copyrighted Motorola software such as the exclusive rights to

reproduce and distribute copies of the Motorola software. Motorola software may

only be copied into, used in, and redistributed with, the Products associated with

such Motorola software. No other use, including without limitation disassembly of

such Motorola software or exercise of the exclusive rights reserved for Motorola, is

permitted.
