Motorola Mobility T56AS1 Portable Cellular Transceiver User Manual AS EX08

Motorola Mobility LLC Portable Cellular Transceiver AS EX08

Exhibit 8C Updated Users Manual RESPONSE TO 18898

APPLICANT: MOTOROLA FCC ID: IHDT56AS1

EXHIBIT 8C

INSTRUCTION MANUAL

A preliminary draft copy of the Users Manual follows:

Note:

This updated manual includes responses to FCC Correspondence Reference Number: 18898.

PRELIMINARY

This is a preliminary version of the Phoenix TDMA user

guide. In particular, color-coded text describes new

R1.1 features that have not been reviewed with the

software. Please use this draft as reference only. It is

not yet ready for review. If you want to provide

feedback, contact John Weidner.

Phoenix TDMA

(R1.1)

Wireless Telephone

User’s Guide

Draft

April 11, 2001

PRELIMINARY

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola V

Series 60t wireless phone.

Earpiece

Headset Jack

Insert headset

accessory for

hands-free use.

Status Light

See incoming call

and service status.

Volume Keys

Adjust earpiece

and ringer volume.

Smart Key

Select menu items,

send and end calls.

Voice Key

Record voice notes,

phonebook and

shortcut names.

Display

Microphone

Accessory

Connector Port

Insert charger and

phone accessories.

Power Key

Right Soft Key

Perform functions

identiﬁed by right

display prompt.

Menu Key

End Key

End phone calls,

exit menu system.

Scroll Key

Move through

menus and lists.

Left Soft Key

Perform functions

identiﬁed by left

display prompt.

Send Key

Send and answer

calls, view recent

dialed calls list.

PRELIMINARY

Personal Communications Sector

600 North U.S. Highway 45

Libertyville, Illinois 60048

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

MOTOROLA, the Stylized M Logo and all other trademarks

indicated as such herein are trademarks of Motorola, Inc. ® Reg.

U.S. Pat. & Tm. Off. TrueSync is a trademark of Starﬁsh, Inc., a

wholly owned independent subsidiary of Motorola, Inc. All other

product or service names are the property of their respective

owners.

Computer Program Copyrights

The Motorola products described in this manual may include Motorola

computer programs stored in semiconductor memories or other media

Laws in the United States and other countries preserve for Motorola,

Inc. certain exclusive rights to the copyrighted computer programs,

including the exclusive right to copy, reproduce, modify, decompile,

disassemble, and reverse-engineer the Motorola computer programs in

any manner or form without Motorola's prior written consent.

Furthermore, the purchase of Motorola products shall not be deemed to

grant either directly or by implication, estoppel, or otherwise, any

license or rights under the copyrights, patents, or patent applications of

Motorola, except for a nonexclusive license to use the Motorola product

and the Motorola computer programs with the Motorola product.

Manual number: 6809435A45-O

Cover number: 8988485L07-O

PRELIMINARY

✂

Menu Map

Main Menu

• Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

• Phonebook

• Datebook

• Quick Dial

• Radio

• Messages

• Voicemail

• Text Msgs

• Browser Alerts

• Quick Notes

• Outbox

• Drafts

• Shortcuts

• Voice Notes

• Browser

• Settings

(see next page)

Note:

This is the standard phone

menu layout. You or your service

provider may have changed the

menu layout or changed some

feature names. Not all features

may be available for all users.

For example, the

Radio

feature

on the main menu (left) is

displayed only when the FM

Stereo Radio Headset accessory

is plugged into the accessory

connector port on your phone

(see phone illustration, page 1).

Shortcuts

Change display zoom:

Press

, then

press and hold

Lock/unlock keypad:

Press

Display my phone number:

Press

Go to dialed calls list:

Press

PRELIMINARY

✂

Settings Menu

•

Ring/Vibrate

• Alert

•

Alert

Detail

•

Phone Status

• My Tel. Number

• Battery Meter

• Other Information

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Security

• Phone Lock

• Lock Keypad

• Lock Application

• Talk Secure

• Restrict Calls

• New Passwords

•

Other Settings

• Personalize

• Main Menu

• Keys

• Greeting

• Banner

• Quick Dial

• Initial Setup

• Time and Date

• Auto PIN Dial

• Auto Redial

• Backlight

• Status Light

• Zoom

• Scroll

• Animation

• Language

• Battery Save

• Contrast Setting

• DTMF

• Master Reset

• Master Clear

• Network

• Car Settings

• Headset

PRELIMINARY

Contents

Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Safety and General Information. . . . . . . . . . . . . . . . . . . 12

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Sending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . 23

About Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Changing the Zoom Setting . . . . . . . . . . . . . . . . . . . . . . . 27

Status Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

External Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Sending and Receiving Calls. . . . . . . . . . . . . . . . . . . . . . 33

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Talk Secure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . . 35

Dialing an Emergency Number When the Phone is Locked 35

Entering Numbers in the Notepad . . . . . . . . . . . . . . . . . . 36

Contents

PRELIMINARY

Muting the Ring or Vibrate Alert . . . . . . . . . . . . . . . . . . . . 36

Terminating an Incoming Call . . . . . . . . . . . . . . . . . . . . . 37

Dialing With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Dialing With One-Touch Dial . . . . . . . . . . . . . . . . . . . . . . 38

Dialing a Number In a Text Message . . . . . . . . . . . . . . . . 39

Additional Dialing Features . . . . . . . . . . . . . . . . . . . . . . . 40

Using Features While On a Call . . . . . . . . . . . . . . . . . . . 42

Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . . . . . 43

Additional On-Call Features . . . . . . . . . . . . . . . . . . . . . . . 44

Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . . . . . 46

Entering Feature Information . . . . . . . . . . . . . . . . . . . . . . 47

Entering Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Predictive Text Entry with iTAP™ Software . . . . . . . . . . . . 54

Menu Feature Descriptions. . . . . . . . . . . . . . . . . . . . . . . 59

Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Viewing the Received Calls or Dialed Calls List . . . . . . . . . 70

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Call Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Viewing and Resetting Call Times . . . . . . . . . . . . . . . . . . . 74

Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Fields in a Phonebook Entry Form . . . . . . . . . . . . . . . . . . 76

Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . 77

Recording a Voice Name For a Phonebook Entry . . . . . . . . 79

Contents

PRELIMINARY

Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . 80

Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . 82

Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . 82

Checking Phonebook Capacity . . . . . . . . . . . . . . . . . . . . . 83

Synchronizing with TrueSync Software . . . . . . . . . . . . . . . 83

Setting Up the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . 84

Datebook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Week View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Day View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Event View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Storing a New Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Changing Event Information . . . . . . . . . . . . . . . . . . . . . . 88

Copying an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Deleting an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Turning the Radio On and Off . . . . . . . . . . . . . . . . . . . . . 91

Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Sending and Receiving Calls With the Radio On . . . . . . . . 92

Messages—Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Storing Your Voicemail Number . . . . . . . . . . . . . . . . . . . . 94

Receiving a New Voicemail Message . . . . . . . . . . . . . . . . 94

Listening to a Voicemail Message . . . . . . . . . . . . . . . . . . . 95

Messages—Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Setting Up the Text Message Inbox . . . . . . . . . . . . . . . . . . 96

Receiving a Text Message . . . . . . . . . . . . . . . . . . . . . . . . 97

Reading, Locking, or Deleting a Text Message . . . . . . . . . . 98

Sending a Text Message . . . . . . . . . . . . . . . . . . . . . . . . . 100

Sending a Text Message to More Than One Person . . . . . 102

Contents

PRELIMINARY

Sending a Quick Note Text Message . . . . . . . . . . . . . . . . 103

Sending a Quick Note to More than One Person . . . . . . . 105

Viewing the Status of Sent Text Messages . . . . . . . . . . . 106

Shortcuts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Standard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

User-Settable Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . 107

Creating a Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Using Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Voice Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . 111

Viewing the Voice Notes List . . . . . . . . . . . . . . . . . . . . . 112

Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Locking and Unlocking a Voice Note . . . . . . . . . . . . . . . 115

Deleting a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Micro-Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Starting a Micro-Browser Session . . . . . . . . . . . . . . . . . . 117

Interacting With Web Pages . . . . . . . . . . . . . . . . . . . . . . 118

Adjusting Your Settings. . . . . . . . . . . . . . . . . . . . . . . . . 119

Ring/Vibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . 127

Customizing a Soft Key Function . . . . . . . . . . . . . . . . . . 127

Hands-Free Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Data and Fax Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Connecting Your Phone to an External Device . . . . . . . . 131

Sending a Data or Fax Call . . . . . . . . . . . . . . . . . . . . . . . 133

Receiving a Data or Fax Call . . . . . . . . . . . . . . . . . . . . . 134

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Assigning a New Code or Password . . . . . . . . . . . . . . . . 137

Contents

PRELIMINARY

If You Forget a Code or Password . . . . . . . . . . . . . . . . . . 138

Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . 139

Locking and Unlocking Your Keypad . . . . . . . . . . . . . . . . 140

Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Activating Talk Secure . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Programming Instructions . . . . . . . . . . . . . . . . . . . . . . 151

Speciﬁc Absorption Rate Data . . . . . . . . . . . . . . . . . . . 152

FDA Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Export Law Assurances . . . . . . . . . . . . . . . . . . . . . . . . . 171

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Wireless Phone Safety Tips . . . . . . . . . . . . . . . . . . . . . . 185

PRELIMINARY

About This Guide

Using Your Phone’s Features

This user guide introduces you to the many features in your

Motorola V phone. A reference guide for your phone is also

available that explains the phone’s features in more detail. To

obtain a copy of the reference guide or another copy of this user

guide, see the Motorola Web site at:

http://motorola.com/consumer/manuals

or contact the Motorola Customer Call Center at

1-800-331-6456 in the United States or 1-800-461-4575 in

Canada.

Navigating To a Menu Feature

You can access many of your phone’s features through the menu

system. This guide shows you how to navigate to a speciﬁc menu

feature as follows:

The > symbol means that you should scroll to and select the

feature. This example shows that you must press M, scroll to

and select Recent Calls, then scroll to and select Dialed Calls

to view the dialed calls list.

Find the Feature

M> Recent Calls

> Dialed Calls

About This Guide

PRELIMINARY

Optional Features

Features marked with this label are optional network

and/or subscription-dependent features. These

features may not be offered by all service providers in

all geographical areas. Contact your service provider

for information about availability.

Optional Accessories

Features marked with this label require the use of an

optional Motorola Original™ accessory.



PRELIMINARY

Safety and General

Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT

OPERATION. READ THIS INFORMATION BEFORE USING YOUR

PHONE.

RF Operational Characteristics

Your phone contains a transmitter and a receiver. When it is ON,

it receives and transmits radio frequency (RF) energy. The phone

operates in the frequency range of .

When you communicate with your phone, the system handling

your call controls the power levels at which your phone

transmits. The output power level typically may vary over a range

from ____ watts to ____ watts in analog mode and ____ watts

to ____ watts in digital mode.

Exposure To Radio Frequency Energy

Your Motorola phone is designed to comply with the following

national and international standards and guidelines regarding

exposure of human beings to radio frequency electromagnetic

energy (EME):

• United States Federal Communications Commission, Code

of Regulations; 47 CFR part 2 sub-part J

• American National Standards Institute (ANSI) / Institute of

Electrical and Electronic Engineers (IEEE) C95. 1-1992

• Institute of Electrical and Electronic Engineers (IEEE) C95.1-

1999 Edition

Safety and General Information

PRELIMINARY

• National Council on Radiation Protection and

Measurements (NCRP) of the United States, Report 86,

1986

• International Commission on Non-Ionizing Radiation

Protection (ICNIRP) 1998

• National Radiological Protection Board of the United

Kingdom 1995

• Ministry of Health (Canada) Safety Code 6. Limits of Human

Exposure to Radiofrequency Electromagnetic Fields in the

Frequency Range from 3 kHz to 300 GHz, 1999

• Australian Communications Authority

Radiocommunications (Electromagnetic Radiation-Human

Exposure) Standard 1999

To assure optimal phone performance and make sure human

exposure to radio frequency electromagnetic energy is within the

guidelines set forth in the above standards, always adhere to the

following procedures:

Portable Phone Operation and EME

Exposure

Antenna Care

Use only the supplied or an approved replacement

antenna. Unauthorized antennas, modiﬁcations, or

attachments could damage the phone and may violate FCC

regulations.

Safety and General Information

PRELIMINARY

Do NOT hold the antenna when the phone is in use.

Holding the antenna affects call quality and may cause the

phone to operate at a higher power level than needed.

Phone Operation

When placing or receiving a phone call, hold your phone as you

would a wireline telephone. Speak directly into the

microphone.

Body-Worn Operation

To maintain compliance with FCC RF exposure guidelines, if you

wear a phone on your body when transmitting, always place the

phone in a Motorola-supplied or approved clip, holder,

holster, case, or body harness. Use of

non-Motorola-approved accessories may exceed FCC RF

exposure guidelines. If you do not use a body-worn

accessory, and are not holding the phone in the normal

use position at the ear, ensure the phone and its

antenna are at least one inch (2.5 centimeters) from

your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an

accessory cable, position the phone and its antenna at

least one inch (2.5 centimeters) from your body.

Approved Accessories

For a list of approved Motorola accessories, visit our website at

www.motorola.com.

Safety and General Information

PRELIMINARY

Electromagnetic Interference/

Compatibility

Note: Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded,

designed, or otherwise conﬁgured for electromagnetic

compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility

conﬂicts, turn off your phone in any facility where posted notices

instruct you to do so. Hospitals or health care facilities may be

using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an

aircraft. Any use of a phone must be in accordance with

applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

The Health Industry Manufacturers Association recommends that

a minimum separation of 6 inches (15 centimeters) be

maintained between a handheld wireless phone and a

pacemaker. These recommendations are consistent with the

independent research by, and recommendations of, Wireless

Technology Research.

Persons with pacemakers should:

Safety and General Information

PRELIMINARY

• ALWAYS keep the phone more than six inches

(15 centimeters) from your pacemaker when the phone is

turned ON.

• NOT carry the phone in the breast pocket.

• use the ear opposite the pacemaker to minimize the

potential for interference.

• turn OFF the phone immediately if you have any reason to

suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing

aids. In the event of such interference, you may want to consult

your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the

manufacturer of your device to determine if it is adequately

shielded from RF energy. Your physician may be able to assist

you in obtaining this information.

Safety and General

Use While Driving

Check the laws and regulations on the use of phones in the area

where you drive. Always obey them.

When using your phone while driving, please:

• give full attention to driving and to the road.

• use hands-free operation, if available.

Safety and General Information

PRELIMINARY

• pull off the road and park before making or answering a

call if driving conditions so require.

Operational Warnings

For Vehicles With an Air Bag

Do not place a portable phone in the area over an air bag or in

the air bag deployment area. Air bags inﬂate with great force. If

a portable phone is placed in the air bag deployment area and

the air bag inﬂates, the phone may be propelled with great force

and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially

explosive atmosphere, unless the phone is a model speciﬁcally

identiﬁed as being “Intrinsically Safe” for use in such areas (for

example, Factory Mutual, CSA, or UL Approved). Do not remove,

install, or charge batteries in such areas. Sparks in a potentially

explosive atmosphere can cause an explosion or ﬁre resulting in

bodily injury or even death.

Note: The areas with potentially explosive atmospheres referred

to above include fueling areas such as below decks on boats,

fuel or chemical transfer or storage facilities, areas where the air

contains chemicals or particles such as grain, dust, or metal

powders, and any other area where you would normally be

advised to turn off your vehicle engine. Areas with potentially

explosive atmospheres are often but not always posted.

Safety and General Information

PRELIMINARY

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF

your phone when you are near electrical blasting caps, in a

blasting area, or in areas posted: “Turn off two-way radio.” Obey

all signs and instructions.

Operational Cautions

Antennas

Do not use any portable phone that has a damaged

antenna. If a damaged antenna comes into contact with your

skin, a minor burn can result.

Batteries

All batteries can cause property damage and/or bodily injury

such as burns if a conductive material such as jewelry, keys, or

beaded chains touches exposed terminals. The conductive

material may complete an electrical circuit (short circuit) and

become quite hot. Exercise care in handling any charged battery,

particularly when placing it inside a pocket, purse, or other

container with metal objects.

ITC01-027

PRELIMINARY

Getting Started

What’s in the Box?

Your digital wireless phone typically comes equipped with a

battery and a charger. Other accessory options can customize

your phone for maximum performance and portability..

To purchase Motorola Original™ accessories, please contact the

Motorola Customer Call Center at 1-800-331-6456 in the

United States or 1-800-461-4575 in Canada.

Installing the Battery

Before you can use your phone, you need to install and charge

the battery.

Your phone is designed to be used only with Motorola

Original batteries and accessories. We recommend that

you store batteries in their protective cases when not

in use.

Do This

Remove the battery from its protective clear plastic case.

If the phone’s battery door

is already in place, push

down the battery door

release latch and lift the

battery door off of the

phone.

Release

latch

Getting Started

PRELIMINARY

Charging the Battery

Before you can use your phone, you need to install and charge

the battery.

Insert the battery, printed

arrows ﬁrst, into the

battery compartment and

push down.

Insert the ridge at the

bottom of the battery door

into the base of the

phone, then push the door

down and snap it into

place.

Do This

Plug the travel charger

into your phone with the

release tab facing up.

Plug the other end of the travel charger into the

appropriate electrical outlet.

Do This

Getting Started

PRELIMINARY

Turning Your Phone On

When your phone indicates that the battery is fully

charged (Charge Complete), press the release tab and

remove the travel charger.

Do This To

Open your phone expose the keypad

Press and hold P

(the power key)

turn on your phone

If necessary, enter

your four-digit unlock

code and press

OK (+)

unlock your phone

The unlock code is originally set

to 1234. (For more information,

see “Locking and Unlocking Your

Phone” on page 139.)

Do This

Power

key

Getting Started

PRELIMINARY

Sending a Call

To call a number, your phone must be turned on, be unlocked,

and have a network connection with adequate signal strength.

Ending a Call

Do This To

Extend the antenna optimize signal reception

Tip: Your phone uses a two-stage

antenna that must be fully extended

for proper operation. You may have

to pull on the antenna a second time

to extend the antenna to its

maximum length.

Press the keypad

keys

dial the phone number (up to 32

digits)

Tip: If you make a mistake, press

DELETE (-) to delete the last

digit, or press and hold

DELETE (-) to clear all digits.

Press N

(send key)

send the call

Press To

O (end key) end the call

Getting Started

PRELIMINARY

Receiving a Call

To receive a call, your phone must be turned on and have a

network connection with adequate signal strength. If your phone

is locked, you must unlock the phone to answer the call.

When you receive a call, your phone rings and/or vibrates and

displays an incoming call message.

Displaying Your Phone Number

From the idle display:

Press To

N or ANSWER (+)answer the call

Press To

M #see your phone number

PRELIMINARY

About Your Phone

See page 1 for a diagram of your phone that describes basic

phone components.

Display

The top section of the display shows phone status indicators. The

following illustration shows some of the common indicators that

you may see at the top of the display when using your phone.

Messages, phone numbers, and menu options appear in the

middle of the display. Text labels at the bottom corners of the

display show the current soft key functions. A M (menu) indicator

in the bottom center of the display indicates that you can open

the main menu or a feature sub-menu to see more options. For

more information about the soft key and menu key labels, see

“Using the Menu” on page 45.

Some of the phone functions described in this guide must be

performed from the idle display. The term

idle display

refers to

the standard display that you see when your phone is on and

ready to use, when you are

not

on a call or using the menu

system.

About Your Phone

PRELIMINARY

➊ Signal Strength Indicator Shows the strength of your

phone’s connection with the network.

You cannot send or receive calls when the “no signal” indicator

is displayed.

➋ In Use Indicator Appears when a call is in progress.

➌ Roam Indicator Appears when your phone uses another

network system outside your home network. When you leave

your home network area, your phone

roams

or seeks another

network.

Strong 5 4 3 2 1 j No signal

12:00am

➐

Clock

➏

Battery

Level

Indicator

➒

Digital/Analog

Signal Indicator

➋

In Use

Indicator

➌

Roam

Indicator

➍

Message Waiting

Indicator

➎

Voice Message

Waiting Indicator

➑

Menu Indicator

➓

Alert Setting

Indicator

➊

Signal

Strength

Indicator

About Your Phone

PRELIMINARY

➍ Message Waiting Indicator Appears when

your phone receives a text message.

➎ Voice Message Waiting Indicator Appears

when you receive a voicemail message.

➏ Battery Level Indicator Shows the amount of charge left

in your battery. The more segments visible, the greater the

charge.

Recharge your battery as soon as possible when you see the

Low Battery warning message.

➐ Clock Shows the current time.

➑ Menu Indicator Indicates that you can press M to open

a menu. See “Using the Menu” on page 45.

➒ Digital (F) or Analog (I) Signal Indicator Shows

whether you are receiving a digital or analog signal.

➓ Alert Setting Indicator Shows the current selected alert.

The default alert setting is a ringer.

High E D C B Empty

w Loud ring x Soft ring

y Vibrate u Ring and vibrate

t Silent

About Your Phone

PRELIMINARY

Changing the Zoom Setting

You can set your phone’s display to show either three lines or

two lines of text plus soft key labels. Three lines of text display

more information, while two lines increase text size.

To change the display view, press M once, then press and

hold M again within two seconds of the ﬁrst press.

You can also adjust the zoom setting from the menu. See the

“Zoom” item on page 67.

Status Light

The status light tells you when

you have an incoming call or

message, or when your phone is

roaming

(using a non-home

system). The light changes color

to indicate different states:

By default, the status light indicator is turned off to extend

battery life. See the “Status Light” item on page 67 to turn on

the status light.

Indication State

alternating red/green incoming call

ﬂashing green in service, home system

ﬂashing yellow roaming, non-home system

ﬂashing red no service

alternating yellow/green text or voicemail message received

Status

light

About Your Phone

PRELIMINARY

Note: Turning on the status light will substantially reduce your

phone’s

standby time

(the length of time that your phone’s

battery retains power when the phone is turned on but is not in

use).

Volume Keys

Use the upper and lower

volume keys to adjust your

phone’s earpiece and

ringer volume.

You can also use the volume keys to scroll up or down through

menus and lists.

To change keypad volume, see “Select a Ring/Vibration for a

Speciﬁc Event” on page 120.

When Press To

During a call volume keys increase or decrease

earpiece speaker volume

From the idle

display (with

ﬂip opened)

volume keys increase or decrease ringer

volume

Volume

keys

About Your Phone

PRELIMINARY

Smart Key

The smart key gives you

another way to perform

many basic phone

functions. It’s called the

smart key because it

anticipates the next action

you are likely to perform.

For example, if you highlight an item and press the smart key, the

smart key selects the highlighted item. You can use the smart key

to send and end calls, select menu items, toggle features on and

off, and open your phonebook. The smart key usually performs

the same function as the right soft key (+).

Note: The smart key only provides an optional way to do some

things faster. It is never

the only way

to perform a task.

You can also use the smart key to perform speciﬁc functions in

the external display when the ﬂip is closed. See the following

section for details.

External Display

When your phone is on and the ﬂip is closed, the external display

shows the time and date. It also displays messages to notify you

of events (like incoming calls) that need your attention.

Smart

key

External

display

About Your Phone

PRELIMINARY

Set Phone Alert

To change your phone’s alert in the external display:

Return an Unanswered Call

When you cannot answer a call, your phone keeps a record of

your unanswered calls and displays the message

X Missed Calls, where X is the total number of missed calls.

When you see the X Missed Calls message in the external

display:

Note: Because the microphone and earpiece are unavailable

when the phone is closed, you must use a headset or other

hands-free device with this feature.

Press To

volume keys scroll to Alert

smart key select an alert type

volume keys return to the idle display

Press To

smart key see the received calls list

volume keys scroll through the list and select a call

that you want to return

smart key send the call

About Your Phone

PRELIMINARY

Battery Use

Caution: To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals.

To maximize your battery’s performance:

• Always use Motorola approved batteries and battery

chargers. The phone warranty does not cover damage

caused from using non-Motorola batteries and/or battery

chargers.

• New batteries or batteries that have been stored for long

periods of time may require a longer charge time.

• Maintain the battery at or near room temperature when

charging.

• Do not expose batteries to temperatures below -10°C

(14°F) or above 45°C (113°F). Always take your phone with

you when you leave your vehicle.

• When you do not intend to use a battery for a while, store it

uncharged in a cool, dark, dry place, such as a refrigerator.

• Over extended periods of time, batteries gradually wear

down and require longer charging times. This is normal. If

you charge your battery regularly and notice a decrease in

talk time or an increase in charging time, then it is probably

time to purchase a new battery.

• The more you talk on the phone or use phone features (like

sending text messages), the less standby time your battery

has. You can also extend battery life by turning off the

status light. (See the “Status Light” item on page 67.)

About Your Phone

PRELIMINARY

The rechargeable batteries that power this product

must be disposed of properly and may need to be

recycled. Refer to your battery’s label for battery type.

Contact your local recycling center for proper disposal methods.

Never dispose of batteries in a ﬁre because they may explode.

PRELIMINARY

Sending and Receiving

Calls

For basic instructions on how to send a call, end a call, and

receive a call, see page 22 of the “Getting Started” section.

Redialing a Number

If you hear an ordinary busy signal, the phone number you dialed

is busy.

Using Automatic Redial

If the network is busy, you hear a fast busy signal, and your

phone displays the message Call Failed.

With automatic redial, your phone repeats the call attempt over

the next four minutes.

When the call goes through, your phone rings or vibrates once,

displays Redial Successful, and then connects the call

automatically.

Press To

O hang up

N redial the busy number

Press To

N or RETRY (+)activate automatic redial

Sending and Receiving Calls

PRELIMINARY

You must activate automatic redial in order to use the feature.

See the “Auto Redial” item on page 67 to turn on automatic

redial.

Caller ID

The

calling line identification

(caller ID) feature lets

you see who is calling before you answer.

• If the caller’s name is stored in your phonebook, the phone

automatically displays the name. Otherwise, the phone

displays the caller’s phone number.

• If caller ID information is not available, your phone displays

the message Incoming Call.

Talk Secure

When

talk secure

is activated, your phone always tries to use a

high-security connection to prevent others from intercepting

your calls. To activate the secure connection feature, see

“Activating Talk Secure” on page 142.

Note: If a high-security connection is not available, your phone

uses a standard connection. Your phone displays the message

Line Not Secure when using a standard connection, unless

caller ID or other information already ﬁlls the display.

Sending and Receiving Calls

PRELIMINARY

Returning an Unanswered Call

Your phone keeps a record of your unanswered calls. When you

cannot answer a call, your phone displays:

• the T (missed call) indicator

• the message X Missed Calls Y Unknown, where X is the

total number of missed calls and Y is the number of missed

calls for which caller ID information is not available.

Dialing an Emergency Number When

the Phone is Locked

Your service provider may program one or more emergency

phone numbers that you can call even if your phone is locked or

restricted.

When you see Enter Unlock Code in the display:

Press To

VIEW (+) see the received calls list, with the

most recent call at the top

S scroll through the list and select a call

that you want to return

N send the call

Press To

keypad keys dial the emergency number (such as

911)

N call the emergency number

Sending and Receiving Calls

PRELIMINARY

Entering Numbers in the Notepad

Your phone stores the most recent string of digits entered on the

keypad in a temporary memory location called the

notepad

These digits can be the last phone number that you called, or a

phone number that you simply entered but did not call. These

digits remain in the notepad even when you turn off the phone.

You can use the notepad to store a phone number that you

intend to call later (such as a phone number told to you by the

other party during a call). To retrieve these digits, see “Using the

Notepad” on page 72.

Muting the Ring or Vibrate Alert

You can mute your phone’s incoming call alert before answering

the call.

While the phone is ringing or vibrating:

To specify a ring or vibration type, see “Ring/Vibrate” on

page 119.

Press To

either volume key turn off the ring or vibration alert

Sending and Receiving Calls

PRELIMINARY

Terminating an Incoming Call

While the phone is ringing or vibrating:

Depending on your phone settings and the type of subscription

you have with your service provider, the call may be forwarded to

another number, or the calling party may hear a busy signal.

Dialing With Speed Dial

The

speed dial

feature lets you dial any phonebook entry with a

minimal number of keypresses.

Whenever you store an entry in your phonebook, the entry is

assigned a unique speed dial number. If you know the speed dial

number for the phonebook entry you want to call, you can use

the speed dial feature.

To make an entry in the phonebook or view an existing entry’s

speed dial number, see “Storing a Phonebook Entry” on

page 77.

Press To

O or IGNORE (-)cancel the incoming call

Press To

keypad keys enter the one-, two-, or three-digit

speed dial number for the entry you

want to dial

# submit the number

N call the entry

Sending and Receiving Calls

PRELIMINARY

Dialing With One- Touch Dial

You can call phonebook entries 2 through 9 with the push of a

single key. Just press and hold the one-digit speed dial number

for one second.

It is recommended that you reserve location 1 in the phonebook

for storing your voicemail number. In many cases, your service

provider has already stored your voicemail number in location 1.

If your voicemail number is not accessible by pressing and

holding the 1 key, complete the following steps:

To store entries in locations 2 through 9 in the phonebook, see

“Storing a Phonebook Entry” on page 77.

Do This To

Store your voicemail number in

phonebook location number 1

(see “Storing a Phonebook

Entry” on page 77)

enable the 1 key

voicemail shortcut

Complete the instructions for

“Storing Your Voicemail Number”

on page 94

enable voicemail soft

key and menu

shortcuts

Sending and Receiving Calls

PRELIMINARY

Dialing a Number In a Text Message

If you receive a text message with an embedded

phone number, you can dial the number directly.

Note: You must set up your inbox before opening

text messages. See “Setting Up the Text Message

Inbox” on page 96.

If the message contains more than one phone number, press S

to scroll to a number and then press SELECT (+) to dial.

Find the Feature

M> Messages > Text Msgs

Press To

S scroll to the message with the

number

M open the Text Msg Menu

S scroll to Call Back

SELECT (+) dial the number in the message

Sending and Receiving Calls

PRELIMINARY

Additional Dialing Features

In addition to pressing numbers on your keypad, you can insert

numbers or characters and send calls in a variety of ways.

While dialing (with digits visible in the display):

Do This To

Press M and

then scroll to and

select one of the

following:

•Insert Pause

(to insert a p)

•Insert Wait

(to insert a w)

•Insert 'n'

(to insert an n)

insert a special character when

making a call that requires you to dial

and send additional digits (for

example, to make a calling card call,

or to retrieve messages from an

answering machine):

•Pause tells your phone to wait

until the call connects before it

sends the next digit(s) in a series.

•Wait tells your phone to wait

until the call connects, and then

to prompt you before it sends the

next digit(s).

•'n' tells your phone to stop and to

prompt you for a number before it

sends the next digit(s).

Press M

> Attach Number

attach a number from the phonebook

or recent calls list to the end of the

digits you entered

Press M

> Send Message

create a text message addressed to

the number entered

Sending and Receiving Calls

PRELIMINARY

You can also call numbers using these features:

Do This To Call

Press and release the voice key

on the right side of your phone

and say the entry’s name (in

two seconds).

a phone number using the

voice dial feature

See “Recording a Voice

Name For a Phonebook

Entry” on page 79.

Press M > Recent Calls

> Received Calls or

Dialed Calls >

entry to call

a missed call or a number

from a call you recently

dialed or received

Voice

key

PRELIMINARY

Using Features While On a

Call

Using Call Waiting

If you subscribe to call waiting, an alert tone sounds

while you are on a call to indicate that you have

received a second call.

To put the ﬁrst call on hold and answer the second call:

To end the ﬁrst call and answer the second call:

Press To

N answer the new call

N switch back to the ﬁrst call

Press To

O end the current call

Your phone rings to signal the new

call.

N answer the new call

Using Features While On a Call

PRELIMINARY

Making a Three- Way Call

During a call, you can call and connect a third party

so that the three of you can talk together. You cannot

do this if you already have a call on hold.

During a call:

Press To

keypad keys enter the third person’s number

N call the number and connect the new

person

N connect the two calls

O end the entire call

Using Features While On a Call

PRELIMINARY

Additional On- Call Features

While you are on a call, you can perform the following tasks:

Do This To

Press MUTE (+)

(if available)

Press M > Mute

mute a call

Press SPEAKER (+)

(if available)

Press M

> Spkrphone On

activate an attached

speakerphone

(hands-free mode)

Press M

> My Tel. Number

see your phone number

Press M > Send Tones send a number to the network

as DTMF tones, for credit card

calling or password entry

To activate DTMF tones, see the

“DTMF” item on page 68.

PRELIMINARY

Using the Menu

Navigating to a Feature

You can access many of your phone’s features by using these

keys to move through the menu system:

Main Menu

Recent Calls

Phonebook

EXIT SELECT

Menu Key

Enter the menu

system, or open

a sub-menu, when

appears in the

bottom center of

the display.

Right Soft Key

Perform the

function shown

in the lower

right corner of

the display

(usually

SELECT

the highlighted

menu item).

Left Soft Key

Perform the

function shown

in the lower left

corner of the

display (usually

EXIT

BACK

Scroll Key

Move up or

down through

menus and lists.

* and #

Cycle through

and set the

value of the

highlighted

menu item.

End Key

Exit the menu

system without

making changes,

return to the

idle display.

Volume Keys

Move up or

down through

menus and lists.

Using the Menu

PRELIMINARY

This guide shows you how to navigate to a speciﬁc menu feature

as follows:

The > symbol means that you should scroll to and select the

feature. This example shows that you must press M, scroll to

and select Recent Calls, then scroll to and select Dialed Calls

to see the dialed calls list.

Selecting a Feature Option

Some features require you to select an item from a list:

Select an item by highlighting it. Use one of the following

approaches:

• Press S to scroll up or down to the item you want.

• In a numbered list, press a number key to highlight the

item.

Find the Feature

M> Recent Calls

> Dialed Calls

Dialed Calls

10) John Smith

9) Mary Smith

BACK VIEW

Press

BACK

(

)

to go back to the

previous screen.

A sub-menu is

available. Press

to open

the sub-menu.

Highlighted

item

Press

VIEW

(

) to view

details of the highlighted item.

STORE

(

) appears if you can

store the item in your phonebook.

Using the Menu

PRELIMINARY

• In an alphabetized list, press a key multiple times to cycle

through the letters on the key and highlight the closest

matching list item.

Entering Feature Information

Features such as the phonebook and datebook require you to

enter information to ﬁll in an entry’s details:

• Enter numbers or text with the keypad. (See “Entering Text”

on page 49.)

• When an item has a list of possible values, press * or #

to scroll through and select a value.

• When an item has a list of possible numeric values, press a

number key to set the value.

• If you enter or edit information and then decide that you do

not want to save your changes, press O to exit without

saving.

Entry Details

Name:John Smith

No.:2125551212

CANCEL CHANGE

Press

scroll down

to additional

items.

Press

CANCEL

(

) to exit

without making changes.

DONE

(

) appears when you

enter or edit information. Press

DONE

(

) to save your changes.

Press

CHANGE

(

)

to edit the selected

information.

Highlighted

item

Using the Menu

PRELIMINARY

The message center lets you compose and send text messages.

(See “Entering Text” on page 49.) A

flashing cursor

shows you

where the text will appear:

When you enter text, the ﬂashing cursor changes to a

block

cursor

, and the soft key functions change:

Msg:

CANCEL BROWSE

Press

BROWSE

(

)

to view and

insert a name,

number, or

message from

previously

stored

information.

Press

CANCEL

(

)

to exit without

making changes.

Flashing

cursor

indicates

insertion

point.

Press

to open the

sub-menu.

Msg:

DELETE OK

Press

(

)

to accept and

store the text.

Press

DELETE

(

) to

delete the character to the

left of the insertion point.

Block

cursor

indicates

current

highlighted

character.

After two seconds, the block

cursor reverts to a ﬂashing cursor

and moves to the next position.

PRELIMINARY

Entering Text

Various text entry methods make it easy for you to enter names,

numbers, email addresses, and text messages on your phone.

You can enter all characters (letters, numbers, and symbols)

using the standard tap method. Other text modes let you easily

enter numbers and symbols, or insert text already stored on your

phone. Finally, a predictive text mode lets you enter text

messages with a minimum of keypresses.

Choosing a Text Mode

To activate a text mode, press M from any text entry screen

and select the text mode from the Entry Method menu:

Note: The text mode you select remains active until you change

it by selecting another mode.

iTAP Let the phone predict each word as you enter it,

then choose the word from a list (see “Predictive

Text Entry with iTAP™ Software” on page 54).

Tap Method Enter characters one at a time by pressing the

key for the letter, number, or symbol (see “Tap

Method” on page 50). This is the standard mode

for entering text on your phone.

Numeric Enter only the number that appears on each key.

Symbol Enter symbols only (see “Symbol Mode” on

page 53).

Browse Browse through your phonebook and recent

calls lists to select a name or number to enter.

Entering Text

PRELIMINARY

Tap Method

Tap method is the default standard mode for entering text on

your phone.

To activate tap method from any text entry screen, press M

and select the Tap Method menu option.

To enter text using the tap method:

Do This To

Press a number

key one or more

times

cycle through the characters

associated with the key and select

the character you want (see the

“Character Chart” on page 52).

Continue to press

number keys

enter the rest of the characters in the

text message

Press OK (+) accept and store the text when you

are ﬁnished

Entering Text

PRELIMINARY

General Text Entry Rules

Use the keypad to enter letters, numbers, symbols, and other

characters with the tap method. Press the same key repeatedly

to cycle through available characters (see the “Character Chart”

on page 52):

Msg:

CANCEL BROWSE

Move ﬂashing

cursor to the

left or right in

text message.

Move ﬂashing

cursor up or

down one line

in text message,

or change

character in

block cursor

to uppercase

or lowercase.

Press a number

key to enter text

at ﬂashing cursor

location.

Press a number

key as many times

as necessary to

enter the desired

character.

Press and hold

a number key to

cycle between

uppercase and

lowercase

characters.

Entering Text

PRELIMINARY

• If you do not press a key for two seconds, the character in

the block cursor is accepted, and the cursor moves to the

next position.

• The ﬁrst character of every sentence is capitalized unless

you manually change it. (Hold the number key or press S

down to force the character to lowercase while it is

highlighted by the block cursor.)

Character Chart

Use this chart as a guide for entering spaces, numbers, letters,

symbols, and other characters with the tap method. Press and

hold a key to cycle between uppercase and lowercase characters.

space

. 1 ? ! , @ _ & : ; " - ( ) '

¿ ¡ % £ $ ¥

2 a b c 2 ä å à α β ç

3 d e f 3 ∆ é è Φ

4 g h i 4 Γ

5 j k l 5 Λ

6 m n o 6 ñ ö ø ò Ω

7 p q r s 7 Π ß ∑

8 t u v 8 Θ ü ù

9 w x y z 9 Ξ Ψ

0 + - 0 x * / = > < # §

Entering Text

PRELIMINARY

Symbol Mode

Your phone provides an alternate way to ﬁnd and enter symbol

characters in a text message. You can view and select from a

variety of available symbols.

To activate symbol mode from any text entry screen, press M

and select the Symbol menu option.

To enter a symbol in symbol mode:

Do This To

Press a number

key one time

display its symbol options (see the

“Symbol Chart” on page 54)

The symbols associated with the key

you pressed are shown at the bottom

of the display. If necessary, press

other keypad keys to ﬁnd the symbol

you want.

Press * or #

the number key

multiple times

highlight the symbol you want

Press

SELECT (+)

add the highlighted symbol to the

text area at the top of the display

Entering Text

PRELIMINARY

Symbol Chart

Use this chart as a guide for entering symbols in symbol mode.

Predictive Text Entry with iTAP™

Software

iTAP™ software provides a predictive text entry method that lets

you enter the letters of a word using only one keypress per letter.

You must activate iTAP software prior to entering letters. You can

do this from any text entry screen by pressing M and

selecting the iTAP menu option.

space

. ? ! , @

_ & : ; " - ( ) '

¿ ¡ % £ $ ¥

2 @ _ \

3 / : ;

4 " & '

5 ( ) [ ] { }

6 ¿ ¡ ~

7 < > =

8 $ £ ¥

9 # % *

0 + - 0 x * / =

> < # §

Entering Text

PRELIMINARY

Enter Words

To enter a word:

Do This To

Press a number

key one time

enter the ﬁrst letter of the word

The letters associated with the key

you pressed are shown at the bottom

of the display.

Press number keys

(one per letter)

enter the rest of the word

Alternative words and letter

combinations are shown at the

bottom of the display based on the

keys you press. These word choices

are updated with each keypress.

When you have

entered all the

letters of the

word, press

* or #

locate and highlight the word you

want

Press

SELECT (+)

add the highlighted word to the text

area at the top of the display

A space is automatically inserted

after the word.

Entering Text

PRELIMINARY

For example, to spell the word “act,” press 2 2 8. The

display shows:

Enter Novel Words

You may enter a word that is not in the iTAP software dictionary.

If you enter all the letters of a word but the word is not

displayed:

Do This To

Press DELETE (-)

one or more times

delete one or more letters until

you see a letter combination

that matches the start of the

word

Press * or # highlight the letter or letter

combination

Press SELECT (+),

then press *

shift the text entry cursor to the

left and “lock” the selected

portion of the word

Press

SELECT

(

) to

insert the highlighted word

at the insertion point.

Press

DELETE

(

)

to clear the last letter

entered.

Flashing

cursor

indicates

insertion

point.

Press

and

to scroll and see

additional word

choices.

Cat Act Bat Abu }

DELETE SELECT

Entering Text

PRELIMINARY

Punctuation

The iTAP software automatically adds a space after each word.

When you enter punctuation, this space is removed. To use

punctuation:

Capitalization

The ﬁrst word of a sentence is automatically capitalized, with

following words in lowercase. To set or adjust character

capitalization:

Continue entering

letters and highlighting

letter combinations

spell the word

Press To

1 or 0enter punctuation or other characters

as shown in the “Character Chart”

on page 52

Press To

Schange the words to initial character

capitalized, all uppercase characters,

or all lowercase characters

Do This To

Entering Text

PRELIMINARY

Enter Numbers

To enter a number:

Delete Letters and Words

Place the cursor to the right of the text that you want to delete,

and then do the following:

Do This To

Enter the ﬁrst digit

and then highlight

put the iTAP software in number

entry mode

Press number keys add digits to the number

Press

SELECT (+)

enter the number at the insertion

point

Do This To

Press DELETE (-) delete one letter at a time

Continue to hold

DELETE (-)

delete the entire message

PRELIMINARY

Menu Feature Descriptions

This chapter describes all of your phone’s features in order of the

menu map shown on pages 3–4. Some descriptions also include

page numbers where you can ﬁnd more detailed information.

If you would like to learn more about a speciﬁc feature, a

reference guide for your phone is also available. To obtain a copy

of the reference guide or another copy of this user guide, see the

Motorola Web site at:

http://motorola.com/consumer/manuals

or contact the Motorola Customer Call Center at

1-800-331-6456 in the United States or 1-800-461-4575 in

Canada.

Main Menu

ECENT

ALLS

Received Calls

M> Recent Calls

> Received Calls

View a list of recently received calls. See “Viewing the

Received Calls or Dialed Calls List” on page 70.

Dialed Calls

M> Recent Calls

> Dialed Calls

View a list of recently dialed calls. See “Viewing the

Received Calls or Dialed Calls List” on page 70.

Menu Feature Descriptions

PRELIMINARY

Notepad

M> Recent Calls

> Notepad

Call or store the last number entered on the keypad. See

“Entering Numbers in the Notepad” on page 36 and

“Using the Notepad” on page 72.

Call Times

M> Recent Calls

> Call Times

View call timers that track time spent on your last call,

dialed calls, received calls, all calls since reset, and all calls

total. See “Call Times” on page 73.

HONEBOOK

M> Phonebook

Store names and numbers as entries in your phonebook,

then call numbers by selecting them from the phonebook

list. See “Phonebook” on page 76.

ATEBOOK

M> Datebook

Use the datebook calendar to schedule and review your

appointments. See “Datebook” on page 85.

UICK

IAL

M> Quick Dial

Dial pre-programmed numbers. Your service

provider may program your phone with one or

more quick dial numbers, such as the customer

service number. You can call them by selecting them from

the quick dial list.

Note: Your service provider may use a different name for

this feature.

Menu Feature Descriptions

PRELIMINARY

ADIO

M> Radio

Listen to FM radio stations with the optional

Motorola Original™ FM Stereo Radio Headset

accessory. This menu feature is displayed only

when the FM Stereo Radio Headset is plugged into the

accessory connector port on your phone. See “Radio” on

page 91.

ESSAGES

M> Messages

Adjust message settings, view and manage the

various types of messages your phone can receive

and/or send:

Voicemail Listen to your recorded voice

messages. See “Messages—

Voicemail” on page 94

Text Msgs Send and receive text messages. See

“Messages—Text” on page 96

Browser Alerts Read alert messages received by your

micro-browser

Quick Notes Select and send pre-written messages

from the quick notes list. See “Sending

a Quick Note Text Message” on

page 103

Outbox View all outgoing text messages,

delivered and undelivered

Drafts Store and edit text messages that you

have written but not sent



Menu Feature Descriptions

PRELIMINARY

HORTCUTS

M> Shortcuts

Create keypad or voice shortcuts to menu features. See

“Shortcuts” on page 107.

OICE

OTES

M> Voice Notes

Use the voice key to record messages and phone calls. See

“Voice Notes” on page 111.

ROWSER

M> Browser

Access Web pages and run Web-based

applications. The micro-browser delivers WAP

(Wireless Application Protocol) pages from your

service provider directly to your phone. See

“Micro-Browser” on page 117.

Settings Menu

ING

IBRATE

Alert

M> Settings

> Ring/Vibrate

> Alert

Select a type of ring or vibration alert for incoming calls and

messages. See “Ring/Vibrate” on page 119.

Alert Detail

M> Settings

> Ring/Vibrate

Alert

Detail

Change details about the ring or vibration alert.

Alert

represents the name of the current alert setting. See

“Ring/Vibrate” on page 119.

Menu Feature Descriptions

PRELIMINARY

HONE

TATUS

My Tel. Number

M> Settings

> Phone Status

> My Tel. Number

View, enter, and edit your name and phone number.

Battery Meter

M> Settings

> Phone Status

> Battery Meter

View a detailed battery charge meter.

Other Information

M> Settings

> Phone Status

> Other Information

View the phone’s feature speciﬁcations (if available from

the service provider).

ONNECTION

Connect your phone to a computer or hand-held

device to send and receive data and fax calls on

the connected device. See “Data and Fax Calls” on

page 131.

Incoming Call

M> Settings

> Connection

> Incoming Call

Specify the format for the next incoming call. You can select

Fax In Only, Data In Only, or Normal. See “Receiving a

Data or Fax Call” on page 134.



Menu Feature Descriptions

PRELIMINARY

N-

ALL

ETUP

Set the features that are active during a call, such as the

in-call timer and call answering options.

In-Call Timer

M> Settings

> In-Call Setup

> In-Call Timer

Adjust call timer display and beep settings. You can set your

timer to beep at a selected interval during your calls. (60

seconds is the default.) You can also turn on or off a display

timer during calls as follows:

Answer Options

M> Settings

> In-Call Setup

> Answer Options

Turn call answering options on or off:

ECURITY

Phone Lock

M> Settings > Security

> Phone Lock

Lock and unlock your phone. See “Locking and Unlocking

Your Phone” on page 139.

Time Display the elapsed time for the

current call

Off No in-call timer display

Multi-Key Answer by pressing any key

Open to Answer Answer by opening the ﬂip

Menu Feature Descriptions

PRELIMINARY

Lock Keypad

M> Settings > Security

> Lock Keypad

Lock and unlock your keypad. See “Locking and Unlocking

Your Keypad” on page 140.

Lock Application

M> Settings > Security

> Lock Application

Lock and unlock speciﬁc phone applications (such as

phonebook or datebook). When an application is locked,

users must enter the unlock code to use the application.

Talk Secure

M> Settings > Security

> Talk Secure

Activate a secure connection to prevent others from

intercepting your calls. See “Talk Secure” on page 34 and

“Activating Talk Secure” on page 142.

Restrict Calls

M> Settings > Security

> Restrict Calls

Restrict incoming and outgoing calls. See “Restricting

Calls” on page 140.

New Passwords

M> Settings > Security

> New Passwords

Change your unlock code (originally set to 1234) or your

security code (originally set to 000000). See “Assigning a

New Code or Password” on page 137.

Menu Feature Descriptions

PRELIMINARY

THER

ETTINGS

Personalize

M> Settings

> Other Settings

> Personalize

Set several personal phone options:

Initial Setup

M> Settings

> Other Settings

> Initial Setup

Set many basic phone options:

Main Menu Change the order of the main menu

(See “Reordering Menu Items” on

page 127.)

Keys Change the functions of the soft keys

and smart key in the idle display (See

“Customizing a Soft Key Function” on

page 127.)

Greeting Change the text displayed when you

turn on your phone

Banner Change the text that appears in the

idle display

Note: Banner text does not appear in

your phone’s external display.

Quick Dial Change quick dial number(s)

Time and Date Set the phone’s time and date

Menu Feature Descriptions

PRELIMINARY

Auto PIN Dial Some networks require an

authenticating PIN to allow

outgoing calls. Use this

feature to automatically dial

your PIN.

Auto Redial Use this option to turn on or turn off

the automatic redial feature. When

you turn on automatic redial, your

phone automatically redials calls that

fail due to network conditions. (See

“Using Automatic Redial” on

page 33.)

Backlight Set the amount of time that the

display backlight remains on, or turn

off the backlight to conserve battery

power

Status Light Turn the status light off (to conserve

battery power) or on

Zoom Switch between three lines

(Zoom Out) and two lines (Zoom In) of

display text

Scroll Force the cursor to stop or wrap

around when it reaches the top or

bottom of a list in the display

Animation Turn animation off (to conserve battery

power) or on. Animation makes your

phone’s menus move smoothly as you

scroll up and down.

Menu Feature Descriptions

PRELIMINARY

Network

M> Settings

> Other Settings

> Network

View and adjust your phone’s network settings.

Your service provider registers your phone to a network. You

can view information about the current network, change

how your phone searches for a network, and turn on/off

Language Set the language for phone menus

Battery Save Adjust the phone’s power usage

characteristics to conserve power

Contrast

Setting

Adjust the contrast setting for your

display

DTMF Set DTMF tones on or off

Master Reset Reset all options back to their original

factory settings

except

for the unlock

code, security code, and lifetime timer

Master Clear Reset all options back to their original

factory settings

except

for the unlock

code, security code, and lifetime timer,

and

clear all user settings and entries

Note: This option

erases all

user-entered information

stored in

your phone’s memory, including

phonebook and datebook entries.

Once you erase the information, it

cannot be recovered.

Menu Feature Descriptions

PRELIMINARY

alerts that indicate when a call is dropped or network

registration changes.

Car Settings

M> Settings

> Other Settings

> Car Settings

Adjust hands-free car kit settings.

You can set your phone to route calls directly to the car kit

when it detects a connection, and automatically answer

calls after two rings. See “Hands-Free Use” on page 128.

Headset

M> Settings

> Other Settings

> Headset

Set your phone to automatically answer calls after

two rings when connected to a headset. See “Hands-Free

Use” on page 128.



PRELIMINARY

Recent Calls

You can use the recent calls menu to view received calls or dialed

calls, retrieve the last number stored in the notepad, and view or

reset call times.

Viewing the Received Calls or Dialed

Calls List

Your phone keeps lists of the numbers from calls you recently

received and dialed, even if the calls did not connect. The lists

are sorted from newest to oldest entries. The oldest entries are

deleted as new ones are added. Each entry tells you the person’s

number (or name, if available) and whether the call connected or

not. You can call, store, or delete the numbers on these lists.

Shortcut: Press N to go directly to the dialed calls list from the

idle display.

To open the recent calls menu:

Find the Feature

M> Recent Calls

Press To

S scroll to Received Calls or

Dialed Calls

SELECT (+) select Received Calls or

Dialed Calls

S scroll to an entry you want to call,

store, or delete

Note: < means the call connected.

Recent Calls

PRELIMINARY

The Last Calls Menu includes the following options:

N call the entry’s number

Tip: Press and hold N for two

seconds to send the entry number as

DTMF tones. To activate DTMF tones,

see the “DTMF” item on page 68.

+ view the entry’s details if View

appears above the + key, or store

the entry’s details in the phonebook if

Store appears above the + key

M open the Last Calls Menu to

perform other procedures as

described in the following list

Option Description

Store Create a phonebook entry with the

selected number in the No. ﬁeld. (This

option is not available if STORE appears

above the + key, or if the number is

already stored as a phonebook entry.)

Delete Delete the entry. (This option is not

available if DELETE appears above the

- key.)

Delete All Delete all entries in the current list.

Press To

Recent Calls

PRELIMINARY

Using the Notepad

Your phone uses a notepad to store the most recent string of

digits entered—either for a phone number that you called or for

a number that you entered but did not call.

To call the number stored in the notepad, press N from the idle

display.

Send Message Create a new text message, with the

selected number in the Tel No. ﬁeld. See

“Sending a Text Message” on page 100.

Add Digits Add digits to the end of the selected

number.

Attach Number Attach another number from the

phonebook or recent calls list to the end of

the selected number.

Send Tones Send the selected number to the network

as DTMF tones, for credit card calling or

password entry. (This option is available

only during an active call.)

To activate DTMF tones, see the “DTMF”

item on page 68.

Option Description

Recent Calls

PRELIMINARY

To create a phonebook entry or perform other operations with

the number:

Call Times

Your phone tracks and records call times. Use the recent calls

menu to view and reset a call timer.

Network connection time

is the elapsed time from the moment

you connect to your service provider's network to the moment

you end the call by pressing O. This time includes busy signals

and ringing.

The amount of network connection time you track on

your resettable timer may not equal the amount of time

for which you are billed by your service provider. For

billing information, please contact your service provider

directly.

Find the Feature

M> Recent Calls > Notepad

Press To

M open the Dialing Menu (to attach a

number or insert a special character).

See “Additional Dialing Features” on

page 40.

STORE (+) create a new phonebook entry, with

the notepad number copied into the

No. ﬁeld. See “Storing a Phonebook

Entry” on page 77.

Recent Calls

PRELIMINARY

You can view the approximate network connection time elapsed

during the following calls:

Viewing and Resetting Call Times

To view a call timer:

Timer Description

Last Call Time spent on the last call dialed or

received. You cannot reset this timer.

Dialed Calls Total time spent on dialed calls since the

last time you reset this timer.

Received Calls Total time spent on calls received since the

last time you reset this timer.

All Calls Total time spent on dialed and received

calls since the last time you reset this

timer.

Lifetime Total time spent on all calls on this phone.

You cannot reset this timer.

Find the Feature

M> Recent Calls

Press To

S scroll to Call Times

SELECT (+) open the list of timers

S scroll to the timer you want

SELECT (+) view the recorded time

Recent Calls

PRELIMINARY

To reset the call timer:

Press To

RESET (+) reset the time (if available)

YES (-) conﬁrm the reset

PRELIMINARY

Phonebook

You can store a list of names and phone numbers or email

addresses in your phone’s electronic phonebook. You can view

these entries and call them directly from your phone. For email

addresses, you can send a text message directly from your

phone.

To see the list of names stored in your phonebook, press

M > Phonebook from the idle display. Scroll to a name and

press VIEW (+) to view details of the phonebook entry as

shown in the following display.

Fields in a Phonebook Entry Form

$*Carlo Emrys

2154337215

Speed No.15

BACK EDIT

Entry’s phone

number or

email address

Type

indicator

identiﬁes

number type:

Work

Home

Main

Mobile

Fax

Pager

[

Voice Name

indicator

indicates a recorded voice name Entry’s

Name

Edit

entry

Press

to open the

Phonebook

Return

to list

Entry’s speed

dial number

Phonebook

PRELIMINARY

Storing a Phonebook Entry

A phone number or email address is required for a phonebook

entry. All other information is optional.

Shortcut: Enter a phone number in the idle display, then press

STORE (+) to create a phonebook entry with the number in

the No. ﬁeld. Go directly to step 3 in the following procedure to

enter additional information and store the entry.

Enter Information

Find the Feature

M> Phonebook

M> New

Press To

S scroll to Phone Number or

Email Address

SELECT (+) select the type of entry

CHANGE (+) select Name

keypad keys enter a name for the phonebook

entry (see “Entering Text” on

page 49)

OK (+) store the name

CHANGE (+) select No. or Email

keypad keys enter the phone number or email

address

OK (+) store the phone number or email

address

Phonebook

PRELIMINARY

CHANGE (+) select Type

Note: This option is not available for

email entries. Your phone

automatically applies an [ (email)

type indicator when you enter an

email address.

S scroll to the type of phone number

SELECT (+) select the number type

RECORD (+)

Go to step 13 if

you do not want

to record a voice

name for the entry

record a voice name for the entry, if

desired

See “Recording a Voice Name For a

Phonebook Entry” on page 79.

S scroll to Speed No., the number to

speed dial

the entry

The next available speed dial number

is assigned to a new phonebook

number by default.

CHANGE (+) select Speed No. if you want to

change it

keypad keys enter a different speed number, if

desired

Press To

Phonebook

PRELIMINARY

Complete Phonebook Entry

When you are ﬁnished entering information for a phonebook

entry:

Recording a Voice Name For a

Phonebook Entry

You can record a voice name when you create a new phonebook

entry, or when you edit a previously stored phonebook entry. This

lets you use voice dial to call the number without dialing (see

“Voice Dial” on page 81).

Tip: Make your voice recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth, and

OK (+) save the modiﬁed speed number

If your chosen speed number is

already assigned to another entry,

you are asked if you want to replace

that entry.

SELECT (+) select MORE if you want to create

another entry with the same Name

Note: You must enter a name and

number to use this option.

Press To

DONE (-) store the entry and return to the

phonebook list

Press To

Phonebook

PRELIMINARY

speak directly into the phone’s microphone in a normal tone of

voice.

Dialing a Phonebook Entry

You can use the phonebook list, voice dial, speed dial, or

one-touch dial to call a number (or send a text message to an

email address) stored in your phonebook. To use speed dial, see

Find the Feature

M> Phonebook

Do This To

Press S scroll to the entry that needs a

voice name

Press VIEW (+) display the entry’s detailed view

Press EDIT (+) edit the phonebook entry

Press S scroll to Voice Name

Press RECORD (+) begin the recording process

The phone displays Press Voice

key then say name.

Press and release the

voice key on the right

side of your phone and

say the entry’s name (in

two seconds)

record the voice name

The phone displays Press Voice

Key then REPEAT name.

Press the voice key and

repeat the name

conﬁrm the voice name

The phone displays Trained:

Voice Name.

Phonebook

PRELIMINARY

“Dialing With Speed Dial” on page 37. To use one-touch dial,

see “Dialing With One-Touch Dial” on page 38.

Phonebook List

To call a number or send email to an entry in the phonebook list:

Voice Dial

To call a number or send an email using voice dial:

Find the Feature

M> Phonebook

Press To

S scroll to the entry you want to call

N send the call (for a phone number)

open a new message form with the

entry’s address in the To ﬁeld (for an

email address)

Do This Result

Press and release the

voice key on the right

side of your phone and

say the entry’s name (in

two seconds).

Your phone goes to the entry in

the phonebook list, repeats the

voice name, waits two seconds,

then automatically dials the call

(for a phone number) or opens a

new message form (for an email

address).

Phonebook

PRELIMINARY

Editing a Phonebook Entry

Edit a phonebook entry by following the procedures described in

“Storing a Phonebook Entry” on page 77.

Deleting a Phonebook Entry

To delete a phonebook entry:

Find the Feature

M> Phonebook

Press To

S scroll to the entry you want to edit

VIEW (+) display the entry’s detailed view

EDIT (+) edit the phonebook entry

Find the Feature

M> Phonebook

Press To

S scroll to the entry you want to delete

M open the Phonebook Menu

S scroll to Delete

SELECT (+) select Delete

YES (-) conﬁrm the deletion

Phonebook

PRELIMINARY

Checking Phonebook Capacity

You can check your phonebook’s capacity to see how many

entries you have used and how many more are available.

To check the phonebook capacity for your phone:

Synchronizing with TrueSync Softwa re

You can synchronize phonebook entries between your

phone and computer or hand-held device with

TrueSync® software, a Motorola accessory product. See

the TrueSync user guide for more information.

Find the Feature

M> Phonebook

Press To

M open the Phonebook Menu

S scroll to Ph Book Capacity

SELECT (+) select Ph Book Capacity

The phone displays the number of

entries that are in use and the

number that are empty.



Phonebook

PRELIMINARY

Setting Up the Phonebook

You can set up your phone to sort your phonebook list by speed

dial number (the standard), name, or voice dial.

Tip: The voice dial sort is identical to the name sort, except that

the entries with voice name tags appear ﬁrst.

Find the Feature

M> Phonebook

Press To

M open the Phonebook Menu

S scroll to Setup

SELECT (+) select Setup

S scroll to Sort by

CHANGE (+) select Sort by

S scroll to the entry you want

SELECT (+) select the entry you want

PRELIMINARY

Datebook

The datebook is a calendar that lets you schedule and organize

events such as appointments and meetings. You can review your

schedule of events for the week or by the day, and have the

datebook play a reminder alarm for speciﬁc events. To schedule

or see events:

The datebook is organized by

views

—from the week view, to the

day view, to a view of a speciﬁc event.

Week View

When you open the datebook, your phone displays a calendar

for the week. Lines or ﬁlled boxes under each day indicate that

events have been scheduled.

Find the Feature

M> Datebook

EXIT VIEW

{15 NOV-21 NOV }

Go to

selected day

Exit the

datebook

Untimed

event

12 hour

window One-hour event

Days of week

(press

to select)

Full day (12-hour)

event scheduled

S M T W T F S

Press

to open

the

Datebook Menu

Datebook

PRELIMINARY

Day View

Select a day in the week view and press VIEW (+) to see the

day’s events. You can store, edit, view, copy, and delete any

event from the day view.

Event View

Select an event in the day view and press VIEW (+) to open

the detailed event view. You can edit, copy, and delete events

from the event view.

{THU 19-NOV }

• Joe’s B-day

9:00 A Marie,...

BACK VIEW

Day of week

Show event

details

Return to

previous screen

Untimed

event

Alarm

Event

Down scroll

arrow

Press

to open

the

Datebook Menu

A THU 9:00am

Marie, mtg about

new product

BACK EDIT

Day and time

Edit eventReturn to

previous screen

Event details

Alarm

Down scroll

arrow

Press

to open

the

Datebook Menu

Datebook

PRELIMINARY

Storing a New Event

A title is required for a datebook event. All other information is

optional.

See “Selecting a Feature Option” on page 46 for instructions on

scrolling to and selecting options.

Find the Feature

M> Datebook >

day

M> New

Press To

CHANGE (+) select Title

keypad keys enter a title for the event (see

“Entering Text” on page 49)

OK (+) store the event title

S scroll to other ﬁelds and enter

information as necessary

Other ﬁelds let you enter start time,

duration, date, repeating events, and

reminder alarm.

DONE (-) store the new event and return to the

day view

Datebook

PRELIMINARY

Changing Event Information

To change information about an existing event:

Find the Feature

M> Datebook

Press To

* or #scroll to the scheduled event day

VIEW (+) display the day view

S scroll to the event you want to

change

VIEW (+) display the event view

EDIT (+) edit the event

S scroll to the detail you want to

change

CHANGE (+) edit the information

keypad keys enter the new information

DONE (-) store the information and return to

the day view

Datebook

PRELIMINARY

Copying an Event

To copy information from a current event to a new event:

Find the Feature

M> Datebook

Press To

* or #scroll to the scheduled event day

VIEW (+) display the day view

S scroll to the event to copy

M open the Datebook Menu

S scroll to Copy

SELECT (+) copy the event

YES (-) conﬁrm the copy

Your phone assumes that you want to

change the date, and displays the

Date ﬁeld.

keypad keys enter the date information

} (+)move to the month, day, and year

DONE (-) save the copy of the event

DONE (-) return to the day view

Datebook

PRELIMINARY

Deleting an Event

Find the Feature

M> Datebook

Press To

* or #scroll to the scheduled event day

VIEW (+) display the day view

S scroll to the event to delete

M open the Datebook Menu

S scroll to Delete

SELECT (+) select Delete

For non-repeating events, go to

step 7. For repeating events, the

phone displays a delete event

menu:

S scroll to This Event Only or

Repeat Events

SELECT (+) select the event(s) to delete

YES (-) conﬁrm the deletion

The phone brieﬂy displays a

Deleted: message and returns you

to the day view.

PRELIMINARY

Radio

You can use your phone to tune, store presets, and

listen to FM radio stations when the optional Motorola

Original™ FM Stereo Radio Headset accessory is

plugged into the phone’s accessory connector port.

Turning the Radio On and Off

Alternatively, you can use the following procedure:

Note: The Radio (+) soft key option and Radio menu feature

are displayed only when the FM Stereo Radio Headset is plugged

into the accessory connector port.

Tuning a Station

Press To

Radio (+) turn the radio on and off

Press To

M open the menu

S scroll to Radio

On (+) or Off (+) turn the radio on or off

Do This To

Press S

Press and hold S

scroll up or down to the next frequency

scroll up or down to the next available

stereo station



Radio

PRELIMINARY

Storing a Preset

To store a station to a preset that you can recall later:

Selecting a Preset

To select a preset radio station:

Sending and Receiving Calls With the

Radio On

Your phone interrupts the radio signal and rings or vibrates as

usual to notify you of an incoming call, message, or other event.

When you receive a call:

Do This To

Press and hold a number

key (1 to 9)

assign its preset number to the

tuned station

Press To

a number key (1 to 9) tune the station stored at that

preset location

Do This To

Press IGNORE (-) ignore the call

Press ANSWER (+)

Press the button on the

FM Stereo Radio Headset

microphone

answer the call

Note: You can use the FM

Stereo Radio Headset

microphone to converse with

the other party during a call

Radio

PRELIMINARY

To end the call and resume the FM broadcast:

Turn the radio off before dialing outgoing calls from the phone

keypad. You do not have to turn off the FM radio feature to dial

emergency numbers, or numbers selected from your phonebook

or other lists.

Tip: To dial a recently called number, press N or the button on

the FM Stereo Radio Headset microphone to go to the dialed

calls list. For more information, see “Recent Calls” on page 70.

Do This To

Press O

Press and hold the button

on the FM Stereo Radio

Headset microphone

end the call

PRELIMINARY

Messages—Voicemail

You can listen to your voicemail messages by calling

your network voicemail phone number. Voicemail

messages are stored on the network—not on your

phone. Contact your service provider for more details.

Storing Your Voicemail Number

Store your voicemail number in your phone to make it faster and

easier to use voicemail. Your voicemail number is provided by

your service provider.

Receiving a New Voicemail Message

When you receive a voicemail message, your phone displays

New VoiceMail &. (Some networks only indicate when you

have messages, whether they are new or not.) If reminders are

turned on, your phone sends a reminder every ﬁve minutes until

you close the new message notiﬁcation, listen to the message, or

turn off your phone. (See “Reminders” on page 126.)

Find the Feature

M> Messages

M> VoiceMail Setup

Press To

keypad keys enter the phone number for your

voicemail

OK (+) store the number

Messages—Voicemail

PRELIMINARY

From the new message notiﬁcation:

Listening to a Voicemail Message

To listen to your voicemail messages at any time:

Your phone calls the voicemail phone number you stored. If you

do not have a voicemail number stored, the phone guides you

through storing a number.

Do This To

Press CALL (+) call your voicemail phone number

and listen to the message

Find the Feature

M> Messages > VoiceMail

PRELIMINARY

Messages—Text

Text messages are brief messages that you can send

and receive (such as Where are we meeting?).

Received messages appear on your phone display or

in your text message inbox.

You must set up the text message inbox

before

you can send and

receive these messages. The total number of messages the inbox

can hold depends on the length of the messages, and the

number of other messages and drafts stored in your phone.

Setting Up the Text Message Inbox

Find the Feature

M> Messages

M> Text Msg Setup

Press To

S scroll to Srvce Center No.

CHANGE (+) change the Srvce Center No.

which is provided by your service

provider

keypad keys enter the phone number for the

service center that handles your

outgoing messages

OK (+) store your service center number

CHANGE (+) change the Expire After period

keypad keys enter the expiration period—the

number of days your network tries to

send unreceived messages

OK (+) store the expiration period

Messages—Text

PRELIMINARY

Receiving a Text Message

Note: You must set up the text message inbox before you can

receive text messages.

When you receive a new message, your phone displays New

Message X and gives an alert. If reminders are turned on, your

phone sends a reminder every ﬁve minutes until you close the

new message notiﬁcation, read the message, or turn off your

phone. (See “Reminders” on page 126.)

When your inbox is full, any new message replaces the oldest

unlocked message.

CHANGE (+) change the Cleanup setting

S scroll to the period of time that

messages stay in your inbox

SELECT (+) select the cleanup period

If you select Custom, continue.

Otherwise, the procedure is

complete.

S change the entry for the number or

label

* or #switch between the number and the

label

DONE (-) store the custom cleanup period after

you ﬁnish entering all information

Press To

Messages—Text

PRELIMINARY

From the new message notiﬁcation:

Reading, Locking, or Deleting a Text

Message

You can open your text message inbox to read, lock, or delete

messages at any time.

Messages in the text message inbox are sorted from newest to

oldest. The oldest messages are deleted as new ones are added.

If you want to save a message, you should lock it to prevent it

from being overwritten as new messages are received.

Press To

READ (+) open the message (or your text

message inbox if there are multiple

messages)

Find the Feature

M> Messages > Text Msgs

Press To

S scroll to the message you want

(d = unread and urgent,

o = read, f = read and locked)

READ (+) open the message

Messages—Text

PRELIMINARY

The Text Msg Menu includes the following options:

SAVE (-)

DELETE (+)

close the message without changes

delete the message

open the Text Msg Menu to perform

other procedures as described in the

following list

Option Description

Call Back Call the number in the message header or

the message text.

Go To Go to a Web address (URL) in the

message.

Reply Open a new text message, with the

message’s Reply To number or email

address in the To ﬁeld.

Forward Open a copy of the text message, with an

empty To ﬁeld.

Lock/Unlock Lock or unlock the message.

Delete

Delete All

Delete the message or all inbox messages.

Press Yes (-) to conﬁrm the deletion.

Press To

Messages—Text

100

PRELIMINARY

Sending a Text Message

To create and send a new text message:

Store Number Open a new phonebook entry with the

message’s embedded number in the No.

ﬁeld.

Store Address Open a new phonebook entry with the

message’s embedded email address in the

Email ﬁeld (if more than one address is

embedded, you can select one from a list).

Create Message Open a new text message window.

Setup Open the inbox setup menu.

Find the Feature

M> Messages > Text Msgs

M> Create Message

Press To

CHANGE (+) select To

keypad keys enter the phone number or email

address where you want to send the

message

Note: To send the message to

multiple recipients, see “Sending a

Text Message to More Than One

Person” on page 102.

OK (+) store the number or email address

CHANGE (+) select Msg

Option Description

101

Messages—Text

PRELIMINARY

keypad keys enter the text message (see “Entering

Text” on page 49)

OK (+) store the text message

Note: Message length is limited.

When 40 or fewer characters remain,

a two-digit counter at the top of the

display shows how many are left.

CHANGE (+) select Priority

S scroll to the priority you want

SELECT (+) set the priority

CHANGE (+) select Call

keypad keys enter the number you want your

recipient to call back (the message’s

From ﬁeld)

OK (+) store the number

DONE (-) ﬁnish the message

Your phone displays

Send Message Now?

YES (-)

NO (+)

send the message

cancel the message or save it as a

draft

Press To

Messages—Text

102

PRELIMINARY

Sending a Text Message to More Than

One Person

You can create and send a single text message to multiple

recipients. To create the message:

Find the Feature

M> Messages > Text Msgs

M> Create Message

Press To

CHANGE (+) select To

BROWSE (+) open the Browse Menu

S scroll to Phonebook

SELECT (+) select Phonebook

S scroll to a phone number or email

address where you want to send the

message

ADD (+) add the number or address to the

group of message recipients

Note: To add more recipients, scroll

to and select other phone numbers

and/or email addresses from the

phonebook list.

DONE (-) close the phonebook list and return

to the To ﬁeld in the text message

window

103

Messages—Text

PRELIMINARY

Sending a Quick Note Text Message

Quick notes are short, pre-written text messages that you

can create, select, edit, and send quickly (for example,

Meet me at ...).

To send or save a quick note message:

OK (+)

store the numbers/addresses and

complete the other message ﬁelds

(for details, see “Sending a Text

Message” on page 100)

open the To Menu to browse for

more phone numbers or email

addresses

• Press S to scroll to Browse

• Press SELECT (+) to open the

Browse Menu and repeat this

procedure for the additional

numbers/addresses

Find the Feature

M> Messages > Quick Notes

Press To

S scroll to the quick note

M open the Quick Note Menu to

perform other procedures as

described in the following list

Press To

Messages—Text

104

PRELIMINARY

The Quick Note Menu includes the following options:

Option Description

Create Message Open an editor where you can create a

new quick note.

Enter text and press OK (+) to save it

as a quick note.

Edit Open an editor where you can edit the

selected quick note.

Edit the quick note text and press

OK (+) to save your changes.

Delete Delete the selected quick note.

Send Open a new message, with the selected

quick note text in the Msg ﬁeld.

Complete the other ﬁelds in the message

(for details, see “Sending a Text Message”

on page 100).

To send the quick note to multiple

recipients, see “Sending a Quick Note to

More than One Person” on page 105.

105

Messages—Text

PRELIMINARY

Sending a Quick Note to More than

One Person

To send a quick note text message to multiple recipients:

Find the Feature

M> Messages > Quick Notes

Press To

S scroll to the quick note

M open the Quick Note Menu.

S scroll to Send

SELECT (+) select Send

CHANGE (+) select To

BROWSE (+) open the Browse Menu

S scroll to Phonebook

SELECT (+) select Phonebook

S scroll to a phone number or email

address where you want to send the

message

ADD (+) add the number or address to the

group of message recipients

Note: To add more recipients, scroll

to and select other phone numbers

and/or email addresses from the

phonebook list.

DONE (-) close the phonebook list and return

to the To ﬁeld in the quick note text

message window

Messages—Text

106

PRELIMINARY

Viewing the Status of Sent Text

Messages

Text messages that you send are stored in the outbox. To view

the contents of your outbox:

Messages are sorted from newest to oldest. The following icons

indicate message status:

OK (+)

store the numbers/addresses and

complete the other message ﬁelds

(for details, see “Sending a Text

Message” on page 100)

open the To Menu to browse for

more phone numbers or email

addresses

• Press S to scroll to Browse

• Press SELECT (+) to open the

Browse Menu and repeat this

procedure for the additional

numbers/addresses

Find the Feature

M> Messages > Outbox

á = Sending in progress o = Delivered

m = Sending failed n = Read by recipient

Press To

107

PRELIMINARY

Shortcuts

Your phone includes several pre-programmed shortcuts. You can

create additional shortcuts, if you like, to mark frequently used

menu items.

Standard Shortcuts

The following shortcuts are pre-programmed in your phone. You

cannot edit or delete these shortcuts.

User- Settable Shortcuts

You can create shortcuts to many menu features and

applications. A shortcut takes you directly to the menu item, or

performs the menu action (if applicable).

Do This To

Press M, then

press and hold M

(within two seconds)

zoom in/out your phone’s display

view

(See “Changing the Zoom Setting”

on page 27.)

Press M *lock/unlock your keypad

Press M #display your phone number

Press Ngo to the dialed calls list

(See “Recent Calls” on page 70.)

Shortcuts

108

PRELIMINARY

Creating a Shortcut

You can assign a keypad shortcut, or both a keypad shortcut

and

a voice shortcut to a menu item.

A voice shortcut lets you go directly to a menu item by saying its

shortcut name.

Tip: Make your voice recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth, and

speak directly into the phone’s microphone in a normal tone of

voice.

Do This To

Press Menter the menu system

Scroll to the item to

which you want to

assign a shortcut

highlight the menu item

Press and hold Mopen the shortcut editor

The phone displays:

Assign Shortcut for:

“

Item

”?

where

Item

is the name of the

item you selected.

Press YES (-) view shortcut options

109

Shortcuts

PRELIMINARY

Press CHANGE (+)

Press DONE (-)

Press S

change the keypad shortcut

number, if necessary

select the default keypad

shortcut number and close the

shortcut editor if you do not

want to assign a voice shortcut

scroll to Voice if you want to

assign a voice shortcut

Press RECORD (+) begin the recording process

The phone displays Press Voice

key then say voice shortcut.

Press and release the

voice key on the right

side of your phone and

say the shortcut’s name

(in two seconds)

record the shortcut name

The phone displays Press Voice

key then REPEAT voice

shortcut.

Press and release the

voice key and repeat

the name

conﬁrm the shortcut name

The phone displays Trained:

Voice Shortcut

Press DONE (-) close the shortcut editor

Do This To

Shortcuts

110

PRELIMINARY

Using Shortcuts

You can use a shortcut from the idle display, while on a call, or

while scrolling through a menu.

Use a Keypad Shortcut

If you know the shortcut number:

Select a Shortcut From the List

To select a shortcut from the shortcut list:

Use a Voice Shortcut

To use a voice shortcut:

Press To

M open the menu

the shortcut’s number go to the menu item, or perform

the menu action

Find the Feature

M> Shortcuts

the shortcut you want

Do This To

Press Mopen the menu

Press and release the

voice key on the right

side of your phone and

say the shortcut’s name

(in two seconds)

go to the menu item, or perform

the menu action

111

PRELIMINARY

Voice Notes

The voice note feature lets you record personal messages or

phone calls. You can play back a voice note at any time. There

are no pre-recorded voice notes on your phone.

Recording a Voice Note

Use this procedure to record a voice note when the idle display is

visible, or use it during a phone call to record the call. Your

phone plays an alert tone to notify the other party that the call is

being recorded.

Note: Recording phone calls is subject to varying state and

federal laws regarding privacy and recording of conversations.

Tip: Make your voice recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth, and

speak directly into the phone’s microphone in a normal tone of

voice.

Do This Result

Press and hold the voice

key on the right side of

your phone for the duration

of the recording.

A tone sounds in the

earpiece and the phone

displays the Recording

Voice Note message.

Speak your voice message

into the phone.

The phone records the

message and displays a

recording timer.

Release the voice key to

stop recording.

The phone displays the voice

notes list number and the

total recording time.

Voice Notes

112

PRELIMINARY

Viewing the Voice Notes List

The voice notes list shows all your voice notes along with other

important information and features.

New Voice Note appears at the end of the list or by itself if no

voice notes are stored. Select New Voice Note to view

instructions on how to record a new voice note.

Playing a Voice Note

To play a recorded voice note:

Find the Feature

M> Voice Notes

Find the Feature

M> Voice Notes

Press To

S scroll to the voice note

PLAY (+) play the voice note

Voice Notes

2)2:20pm 6/1/00

1)4:05am 4/1/00

EXIT PLAY

Press

to open the

Voice Notes Menu

Play the

highlighted

voice note

Return to

previous screen

Time/date

recorded

Down scroll

arrow

Locked

voice note

113

Voice Notes

PRELIMINARY

When an optional Motorola Original™ headset accessory or FM

Stereo Radio Headset accessory is connected to your phone,

voice note playback is automatically routed to the headset.

Tip: You can play a voice note while taking a call. It won’t be

transmitted to the other party.

Playback Screen

While the voice note is playing, the playback screen is displayed.

Erase

voice note

Return to

screen

Voice note

number

Press

fast forward

Press

to rewind

Voice Note 3

{}

SAVE DELETE

Indicates

% played

Press

to open the

Voice Notes Menu

Voice Notes

114

PRELIMINARY

Voice Note Controls

While playing back a voice note, press these keys to do the

following:

Stop playback

and return to

voice notes list.

Stop playback

and go to

Voice

Notes Menu

Stop playback

and scroll

up/down to

next voice note.

Rewind three

seconds, resume

playing.

Press and hold

to rewind to the

beginning.

When playback is

complete, press to

restart.

Fast forward

three seconds,

resume playing.

Press any number

key to alternately

stop and start

playback.

If the voice note

is locked, stop

playback and

unlock voice note.

Press and hold

to fast forward

to end.

If the voice note

is unlocked, stop

playback and

display

Delete

Voice Note?

115

Voice Notes

PRELIMINARY

Locking and Unlocking a Voice Note

You can prevent a voice note from being accidentally deleted by

locking it. To delete a locked voice note, you must ﬁrst unlock it.

You can also lock or unlock a voice note while playing it back.

When the playback screen is displayed:

Playback stops when you lock or unlock a voice note. Press any

number key to resume playback.

Find the Feature

M> Voice Notes

Press To

S scroll to the voice note you want to

lock or unlock

M open the Voice Notes Menu

S scroll to Lock or Unlock

SELECT (+) lock or unlock the voice note

Press To

M open the Voice Notes Menu

S scroll to Lock or Unlock

SELECT (+) lock or unlock the voice note

Voice Notes

116

PRELIMINARY

Deleting a Voice Note

You can delete a single unlocked voice note or all unlocked voice

notes. To delete a locked voice note, you must ﬁrst unlock it. See

“Locking and Unlocking a Voice Note” on page 115.

Notes:

• You can always press NO (+) to cancel deletion.

• A deleted voice note cannot be recovered.

Find the Feature

M> Voice Notes

Press To

S scroll to the voice note you want to

delete

M open the Voice Notes Menu

S scroll to Delete or Delete All

SELECT (+) select the highlighted option

The phone displays

Delete Voice Note X?, or

Delete All Voice Notes?

YES (-) delete the selected voice note, or

delete all voice notes

117

PRELIMINARY

Micro-Browser

The micro-browser lets you access Web pages on

your phone. Contact your service provider to set up

access, if necessary.

Starting a Micro- Browser Session

To open the micro-browser:

The micro-browser displays the home page set up by your service

provider.

Shortcut: If you open a text message with a Web address (URL)

in it, you can go directly to the URL by selecting M > Go To.

If you are unable to establish a network connection with the

micro-browser, contact your service provider.

Find the Feature

M> Browser

Press To

S scroll to a bookmark or service

SELECT (+) select the service

Micro-Browser

118

PRELIMINARY

Interacting With Web Pages

You can perform the following operations on a Web page:

Do This To

Press Sscroll through a text message

Press S and then

SELECT (+)

scroll through and select items in a

list

Press keypad keys

and then OK (+)

enter requested information

Press S to scroll to a

phone number on a Web

page, then press N

call the number from the

micro-browser

Press *go back to the previous Web page

119

PRELIMINARY

Adjusting Your Settings

You can adjust a wide variety of phone settings to suit your

needs.

Ring/Vibrate

Your phone rings or vibrates to notify you of an incoming call,

message, or other event. This ring or vibration is called an

alert

You can use a standard alert for all events, or set different alert

types for different events. The alert setting indicator in your

display shows the current standard alert setting:

Select a Ring/Vibration for All Events

w Loud ring x Soft ring

y Vibrate u Ring and vibrate

t Silent

Find the Feature

M> Settings > Ring/Vibrate

> Alert

Press To

S scroll to the alert you want to use

SELECT (+) select the alert

The phone displays the

Changed: Alert message.

Adjusting Your Settings

120

PRELIMINARY

Select a Ring/Vibration for a Speciﬁc Event

You can select the alert that your phone uses for a speciﬁc event

(such as an incoming call) from 32 different preset tones and

vibrations. When you select a ring or vibration alert for a

specific

event, it overrides the default alert set for

all

events.

Tip: This feature also lets you set the ringer volume and keypad

volume.

Find the Feature

M> Settings > Ring/Vibrate

Alert

Detail

Press To

S scroll to the event for which you want

to set a new alert

CHANGE (+) select the event

The phone displays the list of

available alerts.

S scroll to the alert you want for the

event

SELECT (+) select the alert

The phone displays the

Changed:

Event Alert

message.

121

Adjusting Your Settings

PRELIMINARY

Use the My Tones Feature

The my tones feature lets you create up to 32 custom alert tones

for your phone. The tones you create appear in the list of

available alerts (see “Select a Ring/Vibration for a Speciﬁc

Event” on page 120).

Creating a Tone

Find the Feature

M> Settings > Ring/Vibrate

> My Tones

M> New Tone

Press To

CHANGE (+) select Notes

keypad keys enter notes for the tone (see

“Entering Notes” on page 122)

OK (+) store the notes

CHANGE (+) select Name

keypad keys enter the name for the tone

OK (+) store the name

DONE (-) store the tone

Adjusting Your Settings

122

PRELIMINARY

Entering Notes

To create a new tone, use the keypad keys to enter each note.

Press a key multiple times to cycle through its available notes or

options (pitch, octave, or length). The default setting for a new

tone is a quarter note in octave two.

Key Phone Display Description

1 1 set octave one

2 set octave two

3 set octave three

2 A note A

B note B

C note C

3 D note D

E note E

F note F

4 G note G

R rest

7 # sharp

b ﬂat

8 V vibrate (one second)

0 h half note or half rest

w whole note or whole rest

q quarter note or quarter rest

123

Adjusting Your Settings

PRELIMINARY

Enter a note as follows:

Task Action

Change the

octave

Set the new octave (1, 2, or 3)

before

selecting the note. The new octave applies

to the note and all following notes until

you change it again.

Select the note

(required)

Press a keypad key to enter a note.

Change a note to

a sharp or ﬂat

Enter a sharp or ﬂat (# or b)

after

selecting

the note.

Some sharps and ﬂats are played as

standard notes. For example, B# is the

same as C. Press S to scroll to valid notes

when entering a new note.

Change a note’s

length

Set the new length (h, w, or q)

after

selecting the note. The new length applies

to the note and all following notes until

you change it again.

Add a rest Enter one or more rests (R characters) as

needed in the tone sequence. You can set

the length of the rest

after

the rest, just as

you can for a note.

Listen to a new

tone as you

compose it

Press M to enter the Compose Menu,

and select Play All to play the notes you

have entered.

Adjusting Your Settings

124

PRELIMINARY

Example

Press the following keys to play this sequence of notes and rests

in octave three: C (quarter note), E ﬂat (quarter note), half rest,

and G (whole note):

Playing a Tone

Press To Phone Display

1 1 1set octave three 3

2 2 2enter a quarter

note C

3 3 7 7enter a quarter

note E ﬂat

4 4 0enter a

half rest

4 0 0enter a whole

note G

Find the Feature

M> Settings > Ring/Vibrate

> My Tones

Press To

S scroll to the tone you want

M open the My Tones Menu

S scroll to Play

SELECT (+) select Play

The phone displays the playback

meter and plays the tone.

125

Adjusting Your Settings

PRELIMINARY

Editing a Tone

You cannot edit the standard tones included with your phone. To

edit a custom tone that you created:

Deleting a Tone

You cannot delete the standard tones included with your phone.

To delete a custom tone that you created:

PLAY (+)

CANCEL (-)

play the tone again

return to the my tones list

Find the Feature

M> Settings > Ring/Vibrate

> My Tones

Press To

S scroll to the tone you want to edit

EDIT (+) open the tone details

S scroll to the details you want to edit

(Name or Notes)

CHANGE (+) select the details you want to edit

keypad keys enter new text or notes (see

“Entering Notes” on page 122)

OK (+) store the details

Find the Feature

M> Settings > Ring/Vibrate

> My Tones

Press To

Adjusting Your Settings

126

PRELIMINARY

Reminders

Reminders are alerts that ring or vibrate to notify you about a

voicemail or text message that you have received, or a datebook

event that you have scheduled.

To set or turn off reminders:

Press To

S scroll to the tone you want

M open the My Tones Menu

S scroll to Delete

SELECT (+) select Delete

YES (-) conﬁrm the deletion

Find the Feature

M> Settings > Ring/Vibrate

Alert

Detail > Reminders

Press To

S scroll to the reminder alert you want:

Beep, Vibrate, or Off

Beep or Vibrate sets the

corresponding reminder alert type.

Off turns off all reminders.

SELECT (+) select the reminder alert

127

Adjusting Your Settings

PRELIMINARY

Reordering Menu Items

You can customize the order of the items in your phone’s main

menu, depending upon your usage.

Customizing a Soft Key Function

You can relabel the soft keys (- and +) and the smart key

to access different main menu items from the idle display.

Find the Feature

M> Settings

> Other Settings

> Personalize > Main Menu

Press To

S scroll to the menu item you want to

move

GRAB (+) grab the menu item you want to

move

S move the item up or down the menu

INSERT (+) insert the item in the new location

Find the Feature

M> Settings

> Other Settings

> Personalize > Keys

Press To

S scroll to Left, Right, or Smart

CHANGE (+) open the key editor

S scroll to the new key function

Adjusting Your Settings

128

PRELIMINARY

Hands- Free Use

You can purchase an optional Motorola Original™

hands-free car kit or headset for your phone. These

accessories provide alternative ways for you to use your

phone without using your hands.

Note: The use of wireless devices and their accessories may be

prohibited or restricted in certain areas. Always obey the laws

and regulations on the use of these products.

Automatic Answer

When you activate automatic answer and connect your phone to

a car kit or headset, your phone automatically answers calls after

two rings.

CHANGE (+) conﬁrm the new function

The key will have the new function

whenever the phone is idle.

Find the Feature

M> Settings

> Other Settings

Press To

S scroll to Car Settings or Headset

SELECT (+) select the feature

S scroll to Auto Answer

CHANGE (+) select Auto Answer

S scroll to On or Off

Press To



129

Adjusting Your Settings

PRELIMINARY

Automatic Hands-Free

You can set up your phone to automatically route calls to a car

kit when it detects a connection.

Power-Off Delay

When your phone is connected to a car kit, you can set it to stay

on for a speciﬁed time period after you switch off the ignition.

This keeps your phone from draining your vehicle battery by

staying on indeﬁnitely, but leaves your phone on long enough

that you do not have to re-enter your unlock code when you

make short stops.

SELECT (+) conﬁrm the setting

Find the Feature

M> Settings

> Other Settings

> Car Settings

> Auto Handsfree

Press To

S scroll to On or Off

SELECT (+) conﬁrm the setting

Find the Feature

M> Settings

> Other Settings

> Car Settings

> Power-Off Delay

Press To

Adjusting Your Settings

130

PRELIMINARY

Caution: If you select Continuous, the phone does not power

off when you turn off the ignition. Be careful not to accidentally

drain your vehicle battery if you select this option.

Charger Time

When your phone is connected to a car kit, you can set it to

charge itself for a speciﬁed time period after you switch off the

ignition. This helps ensure that the phone battery gets fully

charged while the vehicle is parked.

Press To

S scroll to the time delay option you

want

SELECT (+) conﬁrm your selection

Find the Feature

M> Settings

> Other Settings

> Car Settings

> Charger Time

Press To

S scroll to the charge time option you

want

SELECT (+) conﬁrm your selection

131

PRELIMINARY

Data and Fax Calls

A Motorola Original™ data kit lets you transfer data

between your phone and a computer or other external

device. You can:

• synchronize data between your phone and an external

device with TrueSync® software, a Motorola accessory

product. See the TrueSync user guide for more information.

• use your phone as a wireless modem to connect to the

Internet

• use your phone to send and receive data and fax calls on

your computer or hand-held device.

For more information about Motorola Original data kits, see the

Motorola Web site at:

http://www.motorola.com/dataaccessories

Connecting Your Phone to an External

Device

Connect your phone to an external device (such as a computer or

hand-held device) using a serial cable or a USB cable.

Set Up a Cable Connection

Attach a serial cable or Motorola Original USB cable to the

phone and external device as follows.

Note: Check your computer or hand-held device to determine

the type of cable you need.



Data and Fax Calls

132

PRELIMINARY

Attaching a Serial Cable

Use the interchangeable head on the Motorola Multi-Connect

Serial Cable to connect a computer, Palm III device, or Palm V

device to your phone.

Do This

Plug the serial cable

into the detachable

head. Make sure

that the Motorola

logo on the

detachable head

and the metal

shielding on the

serial cable plug are

both facing you.

With the Motorola

logo and the phone

both facing you,

plug the detachable

head into your

phone’s accessory

connector port.

Plug the other end of the cable into the serial interface

connection on the external device and tighten the screws.

133

Data and Fax Calls

PRELIMINARY

Attaching a USB Cable

Install the Software

Install the software from the CD-ROM that comes with your

Motorola Original data kit. See the data kit’s user guide for more

information.

Sending a Data or Fax Call

You can connect your phone to a computer or hand-held device

to send data or a fax from the connected device.

Use this feature to transfer data from your computer onto

another device, and to synchronize phonebook and datebook

information between your phone, computer, and/or hand-held

device.

Do This

Plug the end of the

cable with the

Motorola logo into

your phone’s

accessory connector

port. Make sure that

the logo and the

phone are both

facing you.

Plug the other end—the USB connection—into the USB

port on the external device.

Data and Fax Calls

134

PRELIMINARY

Connect your phone (see “Connecting Your Phone to an External

Device” on page 131) and do the following:

Receiving a Data or Fax Call

You can connect your phone to a computer or hand-held device

to receive data or a fax.

Use this feature to transfer data to your computer from another

device.

Do This To

Check the phone make sure that the phone is

connected and powered on

Open the

application on

your computer

place the call through the application

(such as dial-up-networking or fax)

Note: You cannot dial data or fax

numbers through your phone’s

keypad. You must dial them through

your computer.

End the transfer

on your computer

close the call and connection when

the transfer is complete

135

Data and Fax Calls

PRELIMINARY

Set Up Your Phone

Before you receive a data or fax call, you must conﬁgure your

phone for the incoming call type and connect the phone to the

device that will receive the call.

Note: You cannot answer incoming voice calls when your phone

is in data or fax mode. Any voice calls you receive are treated as

unanswered calls. You must reset your phone to voice mode to

return these calls. See “Reset Normal Voice Operation” on

page 136 and “Returning an Unanswered Call” on page 35.

Find the Feature

M> Settings > Connection

> Incoming Call

Do This To

Press

CHANGE (+)

select the Next Call menu option

Press S scroll to Data In Only or

Fax In Only

Selecting either of these options

mutes the earpiece and routes the

next incoming call to the connected

device.

Press

SELECT (+)

set the format for the next incoming

call

Connect your

phone to the

device

enable the data or fax transfer

(See “Connecting Your Phone to an

External Device” on page 131.)

Data and Fax Calls

136

PRELIMINARY

Transfer the Data or Fax

Your phone notiﬁes you when the data or fax call arrives, and

transfers the call to the connected device. You must use the

application running on the connected device to answer the call.

End the Data/Fax Connection

When the data or fax transfer is complete:

Reset Normal Voice Operation

After you receive a data or fax call, you

must

reset your phone to

resume normal voice operations. You cannot receive voice calls

when your phone is in data or fax mode.

Your phone also reverts to normal voice operations when you

turn it off and then turn it back on.

Do This To

End the call from the

connected device

close the connection

Find the Feature

M> Settings > Connection

> Incoming Call

Do This To

Press

CHANGE (+)

select the Next Call menu option

Press S scroll to Normal

Press

SELECT (+)

reset your phone to make and receive

regular voice calls

137

PRELIMINARY

Security

Assigning a New Code or Password

Your phone’s four-digit unlock code is originally set to 1234, and

the six-digit security code is originally set to 000000 at the

factory. Your service provider may reset these numbers before

you receive your phone.

If your service provider has

not

reset these numbers, we

recommend that you change them to prevent other users from

accessing your personal information or modifying your phone

settings. The unlock code must contain four digits, and the

security code must contain six digits. Be sure to make a note of

the new numbers.

Notes:

• Your service provider may retain your phone’s security code

for customer service purposes. In this case, you will not be

able to use phone features that require you to enter the

security code (such as master clear, master reset, and the

unlock code bypass feature).

• If the only password you can change is the unlock code, the

New Passwords menu is unavailable and the Unlock Code

option appears on the Phone Lock menu. In this case, open

the unlock code editor by selecting: M > Settings

> Security > Phone Lock > Unlock Code.

To change a code or password:

Find the Feature

M> Settings > Security

> New Passwords

Security

138

PRELIMINARY

If You Forget a Code or Password

If you forget your security code (originally set to 000000),

contact your service provider.

If you forget your unlock code, try entering 1234 or the last four

digits of your phone number. If that does not work, do the

following when you see the Enter Unlock Code message:

Press To

S scroll to the code or password you

want to change

CHANGE (+) select the code or password

keypad keys enter your old code

If you do not know your code, see “If

You Forget a Code or Password” on

page 138.

OK (+) submit your old code

keypad keys enter the new code

OK (+) assign the new code

keypad keys re-enter the new code

OK (+) conﬁrm the new code

Press To

M go to the unlock code bypass screen

keypad keys enter your security code

OK (+) submit your security code

139

Security

PRELIMINARY

Locking and Unlocking Your Phone

You can lock your phone manually or set your phone to lock

automatically whenever you turn it off.

When you try to use a locked phone, it asks you to enter the

unlock code. A locked phone still rings or vibrates for incoming

calls or messages,

but you must unlock it to answer

You can make emergency calls on your phone even when it is

locked. See “Dialing an Emergency Number When the Phone is

Locked” on page 35.

Lock Your Phone Manually

Set Your Phone to Lock Automatically

You can set your phone to lock every time you turn it off:

Find the Feature

M> Settings > Security

> Phone Lock > Lock Now

Press To

keypad keys enter your four-digit unlock code

OK (+) lock the phone

Find the Feature

M> Settings > Security

> Phone Lock

> Automatic Lock > On

Press To

keypad keys enter your four-digit unlock code

OK (+) set the phone to lock automatically

Security

140

PRELIMINARY

Unlock Your Phone

At the Enter Unlock Code prompt:

Locking and Unlocking Your Keypad

You can lock your phone keypad to prevent accidental use. This

feature is useful in situations where an accidental keypress might

inadvertently dial an emergency number or one-touch dial

number (for example, when carrying your phone in a purse or

pocket).

Note: Incoming calls and messages unlock the keypad.

Restricting Calls

You can stop all outgoing or incoming calls, or you can restrict

them to the numbers stored in your phonebook.

An incoming call that is restricted is treated as an unanswered

call, and is added to the received calls list.

Press To

keypad keys enter your four-digit unlock code

The unlock code is originally set to

1234. If necessary, see “If You Forget

a Code or Password” on page 138.

OK (+) unlock your phone

Press To

M *lock or unlock your keypad

141

Security

PRELIMINARY

Notes:

• You can still place calls to emergency numbers when

outgoing calls are restricted.

• Your phone still receives incoming text messages when

incoming calls are restricted.

Tip: The phonebook application is not locked when you restrict

calls to numbers stored in the phonebook. To prevent a user

from adding (and then calling) a new phonebook entry, you may

want to lock the phonebook application under these

circumstances. See the “Lock Application” item on page 65.

Find the Feature

M> Settings > Security

> Restrict Calls

Press To

keypad keys enter your four-digit unlock code

OK (+) open the restrict calls menu

S scroll to Outgoing Calls or

Incoming Calls

CHANGE (+) select Outgoing Calls or

Incoming Calls

CHANGE (+) change the Allow setting

S scroll to All, None, or Phonebook

SELECT (+) select the calls you want to allow

Security

142

PRELIMINARY

Activating Talk Secure

Your phone can attempt to send your calls using a high-security

connection, to prevent others from intercepting them. For more

information, see “Talk Secure” on page 34.

You can specify whether you prefer to use a secure connection or

not:

Find the Feature

M> Settings > Security

> Talk Secure

Press To

S scroll to Preferred or Off

SELECT (+) switch talk secure on or off

143

PRELIMINARY

Troubleshooting

Check these questions ﬁrst if you have problems with your

phone:

Question Answer

Is your phone set

up correctly?

Press M #. If you do not see your

phone number, contact your service

provider.

Is your battery

charged? Do you

see B in the

display?

The battery level indicator should have

at least one segment showing (C). If

it does not, recharge your battery. (See

“Charging the Battery” on page 20 and

“Battery Use” on page 31.)

Does the handset

have a signal?

Do you see j in

the display?

Make sure that your antenna is fully

extended. The signal strength indicator

should have at least one segment

showing (1). If it does not, move to an

area with a stronger signal to use your

phone.

Is the earpiece

volume too low?

While on a call, press the upper volume

key on the side of your phone.

Is the other party

unable to hear

you?

Make sure that your antenna is fully

extended and that your phone is not

muted. Press UNMUTE (+) if

necessary to unmute the phone.

Also, make sure that your phone’s

microphone is not blocked by its

carrying case or a sticker.

Troubleshooting

144

PRELIMINARY

The following refer to speciﬁc problems:

Has the phone

been damaged,

dropped, or

gotten wet?

Dropping your phone, getting it wet, or

using a non-Motorola battery or battery

charger can damage the phone. The

phone’s limited warranty does not cover

liquid damage or damage caused from

using non-Motorola accessories.

Was a

non-Motorola

battery or

battery charger

used?

Problem Solution

My phone was

stolen. To whom

should I report

this?

Report a stolen phone to the police and

to your service provider (the company

that sends you your monthly wireless

service bill).

I forgot my

password.

See “If You Forget a Code or Password”

on page 138.

I pressed the

power key, but

nothing

happened.

Be sure to press and hold P until the

display appears and you hear an

audible alert (this could take a couple of

seconds). If nothing happens, check

that a charged battery is installed. (See

“Installing the Battery” on page 19.)

Question Answer

145

Troubleshooting

PRELIMINARY

The display says:

Enter Unlock

Code. How do I

unlock my

phone?

Enter the factory-preset unlock code

(1234), or the last four digits of your

phone number. (See “Locking and

Unlocking Your Phone” on page 139.) If

this fails, call your service provider (the

company that sends you your monthly

wireless service bill).

My phone asks

for an unlock

code when I try

to open a

feature.

The application you want is locked. If

you own the phone but do not know

the unlock code, see “If You Forget a

Code or Password” on page 138.

My phone does

not ring.

If you see t or y in the display,

then the ringer is turned off. See

“Ring/Vibrate” on page 119.

I tried to place a

call and heard an

alternating high/

low tone.

Your call did not reach the wireless

system. You may have dialed the

number too soon after turning the

phone on. Wait until the display says

Ready before making a call.

Problem Solution

Troubleshooting

146

PRELIMINARY

I cannot send/

receive calls.

Make sure that your antenna is fully

extended and that you have a phone

signal (see the “Signal Strength

Indicator” item on page 25). Avoid

electrical or radio interference, and

obstructions such as bridges, parking

garages, or tall buildings.

Your phone also may have the

Restrict Calls feature turned on. If

you know the unlock code, you can

change this setting in the security menu

(M > Settings > Security).

My phone has

poor reception

and drops calls.

Make sure that your antenna is fully

extended and is not bent or damaged.

Also, make sure you have a phone

signal (see the “Signal Strength

Indicator” item on page 25). Stay clear

of any obstructions such as bridges,

parking garages, or tall buildings.

I cannot hear

others on my

phone.

While on a call, press the upper volume

key on the left side of your phone. Your

phone display should show the volume

increasing.

Also, make sure that your phone’s

earpiece is not blocked by its carrying

case.

Problem Solution

147

Troubleshooting

PRELIMINARY

I cannot open my

inbox.

Before you can use text or information

services messages, you must set up the

appropriate inbox. See “Setting Up the

Text Message Inbox” on page 96.

How do I see the

calls I sent or

received?

To see the most recent calls you dialed

or received, open the “Recent Calls”

lists:

M> Recent Calls

> Received Calls

Dialed Calls

My phone will

not send

voicemail

commands,

passwords, or

other codes.

Your phone sends commands and

passwords as DTMF tones. You can set

your phone’s DTMF tones to be On or

Off. If you have trouble sending

numbers, try changing your DTMF

setting.

From the idle display, press:

M> Settings

> Other Settings

> Initial Setup

> DTMF

Press S to scroll to On.

Press SELECT (+) to select it.

Problem Solution

Troubleshooting

148

PRELIMINARY

My phone’s

display is too

dark.

You can use the Contrast Setting

feature (see page 68) to change the

level of contrast in your phone display.

You can also use the Backlight feature

(see page 67) to change the length of

time that your phone’s backlight display

stays on.

My battery didn’t

last as long as I

expected. What

can I do to

extend battery

life?

Your battery’s performance is affected

by charge time, feature use,

temperature changes, and other factors.

For tips on extending your battery life,

see “Battery Use” on page 31.

I am unable to

record a voice

note, voice

name, or voice

shortcut

Try moving to a quieter location to make

your voice recording. Hold the phone

about four inches (10 centimeters) away

from your mouth, and speak directly

into your phone’s microphone in a

normal tone of voice.

Problem Solution

149

Troubleshooting

PRELIMINARY

I plugged the

data cable into

my phone but my

phone did not

beep. How do I

know if the data

cable is ready to

go?

The beep indicates that you are set up

correctly. If you did not hear a beep,

make sure that both ends of the data

cable are connected—the smaller end

to your phone and the larger end to

your computer.

Finally, your computer may have

deactivated the port to save power. Try

opening an application that uses the

port, like a fax or dial-up application,

and your computer will automatically

activate the port.

My phone

beeped when I

attached the

data cable, but

my fax and data

applications

don’t work.

You must be in an area with digital

coverage. Check your phone’s display

for the digital signal indicator (F).

Some wireless networks may not

support data or fax transmission. If you

see the digital indicator, but you are

roaming on an unfamiliar network, this

may be the case.

Also, remember that data and fax

transmission usually requires a

subscription. Call your service provider

for more information.

Problem Solution

Troubleshooting

150

PRELIMINARY

When sending

data with the

data cable, why

does the

computer show a

connection rate

of 19200 Kbps?

19200 Kbps is the data transfer rate of

the connection between your computer

and the phone. The rate of the

connection between your phone and

the network is displayed on your phone,

and will be either 14400 or 9600 Kbps.

I can’t end my

data call by

closing the

application on

my computer.

What can I do?

Try pressing O on your phone. Also try

disconnecting the cable or turning off

the phone. If possible, always close the

connection through your computer.

These alternative methods may disrupt

the application on your computer.

I launched the

micro-browser

but the display

says: Service Not

Available.

You may be in an area without service.

If you have wireless service, look in the

display for the digital signal indicator

(F). If you do not see the indicator, you

may be in an area that has only analog

service or no service at all. If you see the

digital signal indicator, you may be

connected to a digital network that

does not support Internet access.

I launched the

micro-browser

but the display

says: Data Server

Unavailable.

Try again in a few minutes. The servers

may be temporarily busy.

Problem Solution

151

PRELIMINARY

Programming Instructions

Follow this procedure if you need to program your phone’s

phone number.

Note: Programming is normally done by a trained technician at

the site of purchase. Users should not make changes other than

ones in the following procedure.

Before programming, ask your service provider for your:

• 10-digit MIN (Mobile Identiﬁcation Number)

• 8- to 15-digit IMSI (International Mobile Service Identiﬁer)

• 8- to 15-digit MDN (Mobile Directory Number)

Do This To

Press 7 4 6 6 3

# M M

(These keys spell P-H-O-N-E

+ # M M).

open the user activation

Press SELECT (+) select NAM1

Press the keypad keys for the

10-digit MIN

open the MIN display and

enter the new MIN

Press OK (+) store the new MIN

Similarly, enter appropriate numbers for the IMSI and

MDN

Press DONE (-) close the NAM1 list

Press BACK (-) close the user activation

152

PRELIMINARY

Speciﬁc Absorption Rate

Data

This model phone meets the government’s

requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed the emission limits for

exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the U.S. Government. These

limits are part of comprehensive guidelines and establish

permitted levels of RF energy for the general population. The

guidelines are based on standards that were developed by

independent scientiﬁc organizations through periodic and

thorough evaluation of scientiﬁc studies. The standards include a

substantial safety margin designed to assure the safety of all

persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a

unit of measurement known as the Speciﬁc Absorption Rate, or

SAR. The SAR limit set by the FCC is 1.6 W/kg.1 Tests for SAR are

conducted using standard operating positions reviewed by the

FCC with the phone transmitting at its highest certiﬁed power

level in all tested frequency bands. Although the SAR is

determined at the highest certiﬁed power level, the actual SAR

level of the phone while operating can be well below the

maximum value. This is because the phone is designed to

operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are to a

wireless base station antenna, the lower the power output.

153

Before a phone model is available for sale to the public, it must

be tested and certiﬁed to the FCC that it does not exceed the

limit established by the government-adopted requirement for

safe exposure. The tests are performed in positions and locations

(e.g., at the ear and worn on the body) as required by the FCC

for each model. The highest SAR value for this model phone

when tested for use at the ear is 1.27 W/kg

, and when worn on

the body, as described in this user guide, is 1.24 W/kg.

(Body-worn measurements differ among phone models,

depending upon available accessories and FCC requirements).

While there may be differences between the SAR levels of

various phones and at various positions, they all meet the

government requirement.

The FCC has granted an Equipment Authorization for this model

phone with all reported SAR levels evaluated as in compliance

with the FCC RF exposure guidelines. SAR information on this

model phone is on ﬁle with the FCC and can be found under the

Display Grant section of:

http://www.fcc.gov/oet/fccid

after searching on FCC ID IHDT56AS1.

1.In the United States and Canada, the SAR limit for mobile phones used by

the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional

protection for the public and to account for any variations in measurements.

2.The SAR information provided to the FCC includes the FCC-accepted

Motorola testing protocol, assessment procedure, and measurement

uncertainty range for this product.

154

PRELIMINARY

The U.S. Food and Drug

Administration's Center for Devices

and Radiological Health Consumer

Update on Mobile Phones

FDA Update

FDA has been receiving inquiries about the safety of mobile

phones, including cellular phones and PCS phones. The following

summarizes what is known—and what remains unknown—

about whether these products can pose a hazard to health, and

what can be done to minimize any potential risk. This

information may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio frequency energy (i.e.,

radio frequency radiation) in the microwave range while being

used. They also emit very low levels of radio frequency energy

(RF), considered non-signiﬁcant, when in the stand-by mode. It

is well known that high levels of RF can produce biological

damage through heating effects (this is how your microwave

oven is able to cook food). However, it is not known whether, to

what extent, or through what mechanism, lower levels of RF

might cause adverse health effects as well. Although some

research has been done to address these questions, no clear

picture of the biological effects of this type of radiation has

emerged to date. Thus, the available science does not allow us to

conclude that mobile phones are absolutely safe, or that they are

unsafe. However, the available scientiﬁc evidence does not

demonstrate any adverse health effects associated with the use

of mobile phones.

155

PRELIMINARY

What kinds of phones are in question?

Questions have been raised about hand-held mobile phones, the

kind that have a built-in antenna that is positioned close to the

user's head during normal telephone conversation. These types

of mobile phones are of concern because of the short distance

between the phone's antenna—the primary source of the RF—

and the person's head. The exposure to RF from mobile phones

in which the antenna is located at greater distances from the

user (on the outside of a car, for example) is drastically lower

than that from hand-held phones, because a person's RF

exposure decreases rapidly with distance from the source. The

safety of so-called “cordless phones,” which have a base unit

connected to the telephone wiring in a house and which operate

at far lower power levels and frequencies, has not been

questioned.

How much evidence is there that hand-held mobile

phones might be harmful?

Brieﬂy, there is not enough evidence to know for sure, either

way; however, research efforts are on-going. The existing

scientiﬁc evidence is conﬂicting and many of the studies that

have been done to date have suffered from ﬂaws in their

research methods. Animal experiments investigating the effects

of RF exposures characteristic of mobile phones have yielded

conﬂicting results. A few animal studies, however, have

suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. In one study, mice

genetically altered to be predisposed to developing one type of

cancer developed more than twice as many such cancers when

they were exposed to RF energy compared to controls. There is

much uncertainty among scientists about whether results

obtained from animal studies apply to the use of mobile phones.

156

PRELIMINARY

First, it is uncertain how to apply the results obtained in rats and

mice to humans. Second, many of the studies that showed

increased tumor development used animals that had already

been treated with cancer-causing chemicals, and other studies

exposed the animals to the RF virtually continuously—up to 22

hours per day.

For the past ﬁve years in the United States, the mobile phone

industry has supported research into the safety of mobile

phones. This research has resulted in two ﬁndings in particular

that merit additional study:

In a hospital-based, case-control study, researchers looked

for an association between mobile phone use and either

glioma (a type of brain cancer) or acoustic neuroma (a

benign tumor of the nerve sheath). No statistically

signiﬁcant association was found between mobile phone

use and acoustic neuroma. There was also no association

between mobile phone use and gliomas when all types of

types of gliomas were considered together. It should be

noted that the average length of mobile phone exposure in

this study was less than three years.

When 20 types of glioma were considered separately,

however, an association was found between mobile phone

use and one rare type of glioma, neuroepithelliomatous

tumors. It is possible with multiple comparisons of the same

sample that this association occurred by chance. Moreover,

the risk did not increase with how often the mobile phone

was used, or the length of the calls. In fact, the risk actually

decreased with cumulative hours of mobile phone use.

Most cancer causing agents increase risk with increased

exposure. An ongoing study of brain cancers by the

157

PRELIMINARY

National Cancer Institute is expected to bear on the

accuracy and repeatability of these results.1

Researchers conducted a large battery of laboratory tests to

assess the effects of exposure to mobile phone RF on

genetic material. These included tests for several kinds of

abnormalities, including mutations, chromosomal

aberrations, DNA strand breaks, and structural changes in

the genetic material of blood cells called lymphocytes. None

of the tests showed any effect of the RF except for the

micronucleus assay, which detects structural effects on the

genetic material. The cells in this assay showed changes

after exposure to simulated cell phone radiation, but only

after 24 hours of exposure. It is possible that exposing the

test cells to radiation for this long resulted in heating. Since

this assay is known to be sensitive to heating, heat alone

could have caused the abnormalities to occur. The data

already in the literature on the response of the

micronucleus assay to RF are conﬂicting. Thus, follow-up

research is necessary.2

FDA is currently working with government, industry, and

academic groups to ensure the proper follow-up to these

industry-funded research ﬁndings. Collaboration with the

Cellular Telecommunications Industry Association (CTIA) in

particular is expected to lead to FDA providing research

recommendations and scientiﬁc oversight of new CTIA-funded

research based on such recommendations.

Two other studies of interest have been reported recently in the

literature:

Two groups of 18 people were exposed to simulated mobile

phone signals under laboratory conditions while they

158

PRELIMINARY

performed cognitive function tests. There were no changes

in the subjects' ability to recall words, numbers, or pictures,

or in their spatial memory, but they were able to make

choices more quickly in one visual test when they were

exposed to simulated mobile phone signals. This was the

only change noted among more than 20 variables

compared.3

In a study of 209 brain tumor cases and 425 matched

controls, there was no increased risk of brain tumors

associated with mobile phone use. When tumors did exist in

certain locations, however, they were more likely to be on

the side of the head where the mobile phone was used.

Because this occurred in only a small number of cases, the

increased likelihood was too small to be statistically

signiﬁcant.4

In summary, we do not have enough information at this point to

assure the public that there are, or are not, any low incident

health problems associated with use of mobile phones. FDA

continues to work with all parties, including other federal

agencies and industry, to assure that research is undertaken to

provide the necessary answers to the outstanding questions

about the safety of mobile phones.

What is known about cases of human cancer that

have been reported in users of hand-held mobile

phones?

Some people who have used mobile phones have been

diagnosed with brain cancer. But it is important to understand

that this type of cancer also occurs among people who have not

used mobile phones. In fact, brain cancer occurs in the U.S.

population at a rate of about 6 new cases per 100,000 people

159

PRELIMINARY

each year. At that rate, assuming 80 million users of mobile

phones (a number increasing at a rate of about 1 million per

month), about 4800 cases of brain cancer would be expected

each year among those 80 million people, whether or not they

used their phones. Thus it is not possible to tell whether any

individual's cancer arose because of the phone, or whether it

would have happened anyway. A key question is whether the

risk of getting a particular form of cancer is greater among

people who use mobile phones than among the rest of the

population. One way to answer that question is to compare the

usage of mobile phones among people with brain cancer with

the use of mobile phones among appropriately matched people

without brain cancer. This is called a case-control study. The

current case-control study of brain cancers by the National

Cancer Institute, as well as the follow-up research to be

sponsored by industry, will begin to generate this type of

information.

What is FDA's role concerning the safety of mobile

phones?

Under the law, FDA does not review the safety of radiation-

emitting consumer products such as mobile phones before

marketing, as it does with new drugs or medical devices.

However, the agency has authority to take action if mobile

phones are shown to emit radiation at a level that is hazardous

to the user. In such a case, FDA could require the manufacturers

of mobile phones to notify users of the health hazard and to

repair, replace or recall the phones so that the hazard no longer

exists.

Although the existing scientiﬁc data do not justify FDA

regulatory actions at this time, FDA has urged the mobile phone

160

PRELIMINARY

industry to take a number of steps to assure public safety. The

agency has recommended that the industry:

• support needed research into possible biological effects of

RF of the type emitted by mobile phones

• design mobile phones in a way that minimizes any RF

exposure to the user that is not necessary for device

function

• cooperate in providing mobile phone users with the best

possible information on what is known about possible

effects of mobile phone use on human health

At the same time, FDA belongs to an interagency working group

of the federal agencies that have responsibility for different

aspects of mobile phone safety to ensure a coordinated effort at

the federal level. These agencies are:

• National Institute for Occupational Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

• Occupational Health and Safety Administration

• National Telecommunications and Information

Administration

The National Institutes of Health also participates in this group.

In the absence of conclusive information about any

possible risk, what can concerned individuals do?

If there is a risk from these products—and at this point we do

not know that there is—it is probably very small. But if people

are concerned about avoiding even potential risks, there are

simple steps they can take to do so. For example, time is a key

161

PRELIMINARY

factor in how much exposure a person receives. Those persons

who spend long periods of time on their hand-held mobile

phones could consider holding lengthy conversations on

conventional phones and reserving the hand-held models for

shorter conversations or for situations when other types of

phones are not available.

People who must conduct extended conversations in their cars

every day could switch to a type of mobile phone that places

more distance between their bodies and the source of the RF,

since the exposure level drops off dramatically with distance. For

example, they could switch to:

• a mobile phone in which the antenna is located outside the

vehicle

• a hand-held phone with a built-in antenna connected to a

different antenna mounted on the outside of the car or built

into a separate package

• a headset with a remote antenna to a mobile phone carried

at the waist

Again, the scientiﬁc data do not demonstrate that mobile

phones are harmful. But if people are concerned about the radio

frequency energy from these products, taking the simple

precautions outlined above can reduce any possible risk.

Where can I ﬁnd additional information?

For additional information, see the following Web sites:

Federal Communications Commission (FCC) RF Safety

Program (select “Information on Human Exposure to RF Fields

from Cellular and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

162

PRELIMINARY

World Health Organization (WHO) International Commission

on Non-Ionizing Radiation Protection (select Qs & As):

http://www.who.int/emf

United Kingdom, National Radiological Protection

Board:

http://www.nrpb.org.uk

Cellular Telecommunications Industry Association (CTIA):

http://www.wow-com.com

U.S. Food and Drug Administration (FDA) Center for Devices

and Radiological Health:

http://www.fda.gov/cdrh/consumer/

1. Muscat et al. Epidemiological Study of Cellular Telephone Use and

Malignant Brain Tumors. In: State of the Science Symposium;1999 June 20;

Long Beach, California.

2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other

laboratory assays. In: Annual Meeting of the Environmental Mutagen

Society; March 29, 1999, Washington, D.C.; and personal communication,

unpublished results.

3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey,

A. Effect of a 915-MHz simulated mobile phone signal on cognitive function

in man. Int. J. Radiat. Biol., April 8, 1999.

4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular

telephones and the risk for brain tumors: a case-control study. Int. J. Oncol.,

15: 113-116, 1999.

FDA020400

163

PRELIMINARY

Warranty

Limited Warranty for Motorola Personal

Communications Products Purchased in the

United States and Canada

I. What This Warranty Covers

• Products. Defects in materials and workmanship in wireless

cellular telephones, pagers, and/or two-way radios, and

certain accessories that are sold with them, such as the

battery, battery charger and holster manufactured and/or

sold by Motorola (Products).

• Batteries. Defects in materials and workmanship in

batteries that are manufactured by Motorola and/or sold

with Products are covered by this warranty only if the fully-

charged capacity falls below 80% of rated capacity or they

leak.

• Software. Physical defects in the media that tangibly

embodies each copy of any software supplied with the

Products.

Warranty

164

PRELIMINARY

II. What the Period of Coverage Is

From the date the Products are purchased by the ﬁrst end-user:

• Products. The warranty is for one year. Exception: The

warranty for Spirit GT series and Talkabout series two-way

radio accessories is for 90 days.

• Software. The warranty is for 90 days.

• Repairs/Replacements. The warranty is for the balance of

the original warranty or for 90 days from the date you

receive it, whichever is longer.

III. Who is Covered

This warranty extends to the ﬁrst end-user purchaser, only.

IV. What We Will Do to Correct Warranty Problems

At no charge to you, we have the option to repair or replace the

Products or software that do not conform to the warranty, or to

refund the Products’ purchase price. We may use functionally

equivalent reconditioned/refurbished/pre-owned or new

Products or parts. No software updates are provided.

V. How to Get Warranty Service

Please call:

USA

Cellular 1-800-331-6456

Paging 1-800-548-9954

Two-Way 1-800-353-2729

TTY (Text Telephone) 1-888-390-6456

165

Warranty

PRELIMINARY

You will receive instructions on how to ship the Products to

Motorola. You must ship the Products to us with freight, duties

and insurance prepaid. Along with the Products you must

include: (a) a copy of your receipt, bill of sale or other

comparable proof of purchase; (b) a written description of the

problem; (c) the name of your service provider (if this Product

requires subscription service); (d) the name and location of the

installation facility (if applicable) and, most importantly; (e) your

address and telephone number. If requested, you must also

return all detachable parts such as antennas, batteries and

chargers. RETAIN YOUR ORIGINAL PROOF OF PURCHASE.

We will ship repaired or replacement Products at our expense for

the freight and insurance, but at your expense for any duties. If

additional information is needed, please contact us at the

telephone number listed above.

VI. What This Warranty Does Not Cover

• Products that are operated in combination with ancillary or

peripheral equipment or software not furnished by

Motorola for use with the Products (“ancillary equipment”),

or any damage to the Products or ancillary equipment as a

result of such use. Among other things, “ancillary

equipment” includes batteries, chargers, adaptors, and

power supplies not manufactured or supplied by Motorola.

Any of these voids the warranty.

Canada

All Products 1-800-461-4575

TTY (Text Telephone) 1-888-390-6456

Warranty

166

PRELIMINARY

• Someone other than Motorola (or its authorized service

centers) tests, adjusts, installs, maintains, alters, modiﬁes or

services the Products in any way. Any of these voids the

warranty.

• Rechargeable batteries that: (a) are charged by other than

the Motorola-approved battery charger speciﬁed for

charging such batteries; (b) have any broken seals or show

evidence of tampering; (c) are used in equipment other

than the Product for which they are speciﬁed; or (d) are

charged and stored at temperatures greater than 60

degrees centigrade. Any of these voids the warranty.

• Products that have: (a) serial numbers or date tags that

have been removed, altered or obliterated; (b) board serial

numbers that do not match each other, or board serial

numbers that do not match the housing; or (c)

nonconforming or non-Motorola housings or parts. Any of

these voids the warranty.

• Defects or damage that result from: (a) use of the Products

in a manner that is not normal or customary; (b) improper

operation or misuse; (c) accident or neglect such as

dropping the Products onto hard surfaces; (d) contact with

water, rain, extreme humidity or heavy perspiration; (e)

contact with sand, dirt or the like; or (f) contact with

extreme heat, or spills of food or liquid.

• Physical damage to the surface of the Products, including

scratches, cracks or other damage to a display screen, lens

or other externally exposed parts.

167

Warranty

PRELIMINARY

• Failure of Products that is due primarily to any

communication service or signal you may subscribe to or

use with the Products.

• Coil cords that are stretched or that have any broken

modular tabs.

• Products that are leased.

Flat-rate repair rates may apply to Products not covered by this

warranty. To obtain information about Products needing repairs

that are not covered by this warranty, please call the telephone

number previously listed. We will provide information on repair

availability, rates, methods of payment, where to send the

Products, etc.

VII. Some Other Limitations

This is Motorola’s complete warranty for the Products,

and states your exclusive remedies. This warranty is

given in lieu of all other express warranties. Implied

warranties, including without limitation, the implied

warranties of merchantability and ﬁtness for a

particular purpose, are given only if speciﬁcally

required by applicable law. Otherwise, they are

speciﬁcally excluded.

No warranty is made as to coverage, availability, or

grade of service provided by the Products, whether

through a service provider or otherwise.

No warranty is made that the software will meet your

requirements or will work in combination with any

hardware or applications software products provided

Warranty

168

PRELIMINARY

by third parties, that the operation of the software

products will be uninterrupted or error free, or that all

defects in the software products will be corrected.

In no event shall Motorola be liable, whether in

contract or tort (including negligence) for damages in

excess of the purchase price of the Product, or for any

indirect, incidental, special or consequential damages

of any kind, or loss of revenue or proﬁts, loss of

business, loss of information or data, or other ﬁnancial

loss arising out of or in connection with the ability or

inability to use the Products, to the full extent these

damages may be disclaimed by law.

VIII. Patent and Software Provisions

At Motorola’s expense, we will defend you, and pay costs and

damages that may be ﬁnally awarded against you, to the extent

that a lawsuit is based on a claim that the Products directly

infringe a United States patent. Our obligation is conditioned on:

(a) you notifying us promptly in writing when you receive notice

of the claim; (b) you giving us sole control of the defense of the

suit and all negotiations for its settlement or compromise; and

likely to become, the subject of a claim of infringement of a

United States patent, you permit us, at our option and expense,

either to: procure for you the right to continue using the

Products; replace or modify them so that they become non-

infringing; or grant you a credit for such Products, as

depreciated, and accept their return. The depreciation will be an

equal amount per year over the lifetime of the Products, as

established by Motorola.

169

Warranty

PRELIMINARY

Motorola will have no liability to you with respect to any claim of

patent infringement that is based upon the combination of the

Products or parts furnished under this limited warranty with

ancillary equipment, as deﬁned in VI., above.

This is Motorola’s entire liability with respect to

infringement of patents by the Products.

Laws in the United States and other countries preserve for

Motorola and other third party software providers certain

exclusive rights for copyrighted software, such as the exclusive

rights to reproduce in copies and distribute copies of such

software. The software may be copied into, used in and

redistributed with only those Products that are associated with

such software. No other use, including without limitation,

disassembly or reverse engineering of such software or exercise

of exclusive rights in such software is permitted.

IX. State Law and Other Jurisdiction Rights

Some states and other jurisdictions do not allow the exclusion or

limitation of incidental or consequential damages, or limitation

on the length of an implied warranty, so the above limitations or

exclusions may not apply to you.

This warranty gives you speciﬁc legal rights, and you may also

have other rights, which vary from jurisdiction to jurisdiction.

To obtain information on Motorola Personal Communications

Products, including warranty service, accessories and optional

Extended Warranties on selected Products, please call:

Warranty

170

PRELIMINARY

To correspond with Motorola about the Products, please write us

http://www.motorola.com

or at:

USA

Cellular 1-800-331-6456

Paging 1-800-548-9954

Two-Way 1-800-353-2729

TTY (Text Telephone) 1-888-390-6456

Canada

All Products 1-800-461-4575

TTY (Text Telephone) 1-888-390-6456

In the USA:

Motorola, Inc.

600 North U.S. Highway 45

Libertyville, IL 60048

In Canada:

Motorola Canada Limited

5875 Whittle Road

Mississauga, ON L4Z 2H4

171

PRELIMINARY

Export Law Assurances

This product is controlled under the export regulations of the

United States of America and Canada. The Governments of the

United States of America and Canada may restrict the

exportation or re-exportation of this product to certain

destinations. For further information contact the U.S.

Department of Commerce or the Canadian Department of

Foreign Affairs and International Trade.

172

PRELIMINARY

Index

accessories

optional 11, 91, 113, 128,

131

standard 19

accessory connector port 1

Add Digits feature 72

alert

creating 121–126

deﬁned 119

indicators 26, 119

muting 36

reminders 126

setting 119

setting in external display

type, selecting 120

alert setting indicator

deﬁned 26, 119

illustration 25

animation 67

antenna 22

application, locking 65

appointments.

See

datebook

Attach Number feature 40,

auto PIN dial 67

automatic redial

turning on/off 67

using 33–34

backlight 67

banner text 66

battery

car kit charger time 130

charging 20–21

extending battery life

27–28, 31–32, 67,

148

installing 19–20

level indicator 25, 26

meter 63

block cursor, deﬁned 48

browse text mode 49

browser alerts 61

browser.

See

micro-browser

calendar.

See

datebook

call

adding digits after phone

number 72

alert type, selecting 120

alert, creating 121–126

alert, muting 36

173

Index

PRELIMINARY

call (continued)

alert, setting 119

alert, setting in external

display 30

answer options 64

answering 23

call waiting 42

calling card 40

canceling 37

data call, setting 63

dialed calls list 41, 70–72

dialing 22

emergency number 35

ending 22

fax call, setting 63

ignoring 37

in-call timer 64

incoming call type, setting

muting 44

placing 22

preﬁx digits, inserting 40

privacy 34, 142

received calls list 41, 70–72

receiving 23

restricting 140–141

secure connection 34, 142

sending 22

speakerphone, activating

call (continued)

terminating 37

three-way call 43

timing 73–74

unanswered call 30, 35

voice dial 41

Call Failed message 33

call timers

described 73–74

resetting 75

viewing 74

call waiting 42

caller ID 34, 35

calling card call 40

calling line identiﬁcation.

See

caller ID

car kit

automatic answer 128–129

automatic hands-free 129

charger time 130

power-off delay 129–130

clock

deﬁned 26

illustration 25

codes.

See

passwords

computer

connecting to phone

131–133

synchronizing data 83, 131

contrast, display 68

Index

174

PRELIMINARY

cursor 48

customer service, calling 60

customizing the menu 127

data call

connecting to external

device 63, 131–133

incoming call format, setting

receiving 134–136

sending 133–134

date, setting 66

datebook

adding an event 87

alarm 87

calendar 85

changing event information

copying an event 89

day view 86

deleting an event 90

event view 86

reminders 87, 126

week view 85

Datebook Menu 85, 86

default passwords 137

dialed calls list 41, 70–72

dialing a number 22

digital/analog signal indicator

deﬁned 26

illustration 25

display

animation 67

backlight 67

banner text 66

contrast 68

described 24–26

greeting 66

idle display 24

illustration 25

language 68

zoom setting 27, 67

drafts folder 61

DTMF tones 44, 68, 71, 72,

147

earpiece

illustration 1

volume, adjusting 28

email address

phonebook entry 76

storing in phonebook

77–79

email, sending 80–81,

100–103

emergency number 35

175

Index

PRELIMINARY

end key

functions 1, 22

menu functions 45

ending a call 22

Enter Unlock Code message

138, 140

event alert 120

external device

connecting to phone

131–133

synchronizing data 83, 131

external display 29–30

factory settings, resetting 68

fax call

connecting to external

device 63, 131–133

incoming call format, setting

receiving 134–136

sending 133–134

ﬂashing cursor, deﬁned 48

ﬂip

external display and 29

open to answer call 64

turning the phone on 21

FM Stereo Radio Headset 61,

91–93, 113

greeting, display 66

hands-free mode

automatic answer 128–129

automatic call routing 129

charger time 130

deﬁned 128

external display and 30

power-off delay 129–130

speakerphone, activating

headset

automatic answer 128–129

FM Stereo Radio Headset

61, 91–93, 113

use with external display 30

headset jack 1

high-security connection 34,

142

idle display, deﬁned 24

ignoring a call 37

in use indicator

deﬁned 25

illustration 25

inbox, text message 96–100

in-call timer 64

Index

176

PRELIMINARY

incoming call

canceling 37

ignoring 37

terminating 37

type, setting 63

Incoming Call message 34

indicators

alert setting 25, 26, 119

battery level 25, 26

digital/analog signal 25, 26

in use 25

menu 24, 25

message waiting 25, 26

missed call 35

ring alert 26, 119

roam 25

signal strength 25

silent alert 26, 119

vibrate alert 26, 119

voice message waiting 25,

voice name 76

iTAP software

activating 54

capitalization 57

deleting text 58

entering numbers 58

entering words 55–57

punctuation 57

key

end 1, 22, 45

left soft key 1, 45, 127–128

lock 140

menu 1, 23, 45

power 1, 21

right soft key 1, 45,

127–128

scroll 1, 45

send 1, 22, 23, 70

smart 1, 29

voice 1, 80, 111

volume control 1, 28, 45

keypad

answering calls 64

volume, setting 120

language, setting 68

Last Calls Menu

opening 71

options 71–72

left soft key

customizing 127–128

functions 1, 45

Line Not Secure message 34

lock

applications 65

keypad 140

177

Index

PRELIMINARY

lock (continued)

phone 139–140

voice notes 115

lock application feature 65

loud ring alert 26, 119

making a call 22

master clear 68

master reset 68

customizing 127

Datebook Menu 85, 86

entering text 47–48, 49–58

features 59–69

language, setting 68

Last Calls Menu 71–72

lists 46–47

locking applications 65

My Tones Menu 124, 126

navigating 10, 45–46

Phonebook Menu 76

Quick Note Menu 103–104

rearranging features 127

scroll feature 67

Text Msg Menu 99–100

using features 10, 46–48

Voice Notes Menu 112,

113, 114

menu indicator

deﬁned 24, 26

illustration 25

menu key 1, 23, 45

message

browser alert 61

deleting 98–100

dialing number from 39

drafts folder 61

inbox setup 96–97

locking 98–100

outbox 61, 106

quick note 103–106

reading 98–100

receiving 97–98

reminders 94

reminders, text message

97, 126

reminders, voicemail 126

sending 40, 100–103

status 106

voicemail 94–95

message waiting indicator

deﬁned 26

illustration 25

micro-browser

browser alerts 61

call a number from 118

deﬁned 117

functions 118

Index

178

PRELIMINARY

micro-browser (continued)

go back to previous page

118

starting 117

microphone 1

missed call indicator 35

missed call, dialing 41

Missed Calls message 30,

muting a call 44

my telephone number 44, 63

my tones 121–126

My Tones Menu 124, 126

’n’ character 40

network settings 68–69

notepad

deﬁned 36

entering digits 36

retrieving digits 72–73

number, viewing your own 63

numeric text mode 49

one-touch dial

deﬁned 38

voicemail number 38

one-touch dialing 38

optional accessory, deﬁned 11

optional feature, deﬁned 11

outbox 61, 106

passwords

changing 137

default 137

if you forget a password

138

pause character 40

phone

accessories, optional 11

accessories, standard 19

alert, muting 36

answer options 64

connecting to external

device 63, 131–133

date, setting 66

erase user-entered

information 68

feature speciﬁcations 63

ﬂip 21

keypad, answering calls with

keypad, locking and

unlocking 140

language, setting 68

locking 139–140

muting a call 44

network settings 68–69

one-touch dialing 38

179

Index

PRELIMINARY

phone (continued)

passwords 137, 138

reset all options 68

secure connection 34, 142

security code 138

speciﬁcations 63

speed dial, using 37

startup greeting 66

text in idle display 66

time, setting 66

turning on/off 21

unlock code 138

unlocking 21, 139–140

voice dial 41

phone number

adding digits after 72

attaching to preﬁx digits 40

attaching two numbers 72

redialing 33

sending text message to 40

storing in phonebook

77–79

viewing your own 23, 44,

voice dial 41

phonebook

attaching two numbers 72

capacity, checking 83

deleting an entry 82

dialing a number 80–81

phonebook (continued)

editing an entry 82

email address 76

entry name 76

ﬁelds 76

number type indicator 76

one-touch dialing 38

phone number 76

preﬁx digits, inserting 40

sending an email 80–81

sorting entries 84

speed dial number 37, 76,

78–79

speed dial, using 37

storing an entry 77–79

synchronizing entries 83,

131

voice name entry 79–80

voice name indicator 76

Phonebook Menu 76

PIN code, dialing automatically

power key 1, 21

predictive text entry

activating 54

capitalization 57

deleting text 58

entering numbers 58

entering words 55–57

punctuation 57

Index

180

PRELIMINARY

privacy, call 34, 142

quick dial

setting number 66

using 60

quick note 103–106

Quick Note Menu 103–104

radio 91–93

received calls list 41, 70–72

receiving a call 23

recent calls 70–72

adding digits after phone

number 72

attaching two numbers 72

redial

automatic redial 33–34

busy number 33

reminders

datebook 87

setting 126

text message 97, 126

voicemail message 94, 126

restricting calls 140–141

right soft key

customizing 127–128

functions 1, 45

ring alert

creating 121–126

indicators 26, 119

muting 36

setting 119

setting in external display

type, selecting 120

ring and vibrate alert

indicator 26, 119

muting 36

ringer

setting 119

setting in external display

volume, adjusting 28, 120

roam indicator

deﬁned 25

illustration 25

scroll feature 67

scroll key 1, 45

secure connection 34, 142

security code 138

send key 1, 22, 23, 70

sending a call 22

short message service.

See

text

message

181

Index

PRELIMINARY

shortcuts

creating 108–109

standard 107

using 110

signal strength indicator

deﬁned 25

illustration 25

silent alert indicator 26, 119

smart key

customizing 127

deﬁned 29

functions 29

illustration 1

SMS.

See

text message

soft keys

customizing 127–128

functions 45

illustration 1

soft ring alert 26, 119

speakerphone 44

speed dial

changing number 78–79

number, deﬁned 37

sorting phonebook entries

by 84

using 37

standby time

deﬁned 28

increasing 31

status light 1, 27–28, 67

symbol text mode 53–54

symbols, entering 53–54

synchronizing data 83, 131

Talk Secure feature 34, 142

tap method text entry 50–52

telephone number, viewing

your own 63

text

block cursor 48

browse mode 49

character chart 52

entering from keypad

49–58

entry mode, changing 49

ﬂashing cursor 48

iTAP software predictive text

entry 54–58

numeric mode 49

symbol chart 54

symbol mode 53–54

tap method 50–52

text message

deleting 98–100

dialing number from 39

inbox setup 96–97

locking 98–100

quick note 103–106

reading 98–100

Index

182

PRELIMINARY

text message (continued)

receiving 97–98

reminders 97, 126

sending 40, 100–103

status 106

text mode, changing 49

Text Msg Menu

opening 99

options 99–100

three-way call 43

time, setting 66

timers

described 73–74

resetting 75

viewing 74

travel charger

charging phone battery 20

TrueSync 83, 131

unlock

keypad 140

phone 139–140

unlock code 138

vibrate alert

indicator 26, 119

muting 36

setting 119

vibrate alert (continued)

setting in external display

type, selecting 120

voice dial

dialing a number 41, 81

recording voice name

79–80

sending an email 81

voice key

dialing a number 41

functions 1

recording a voice name 80

recording a voice note 111

voice message waiting

indicator 25, 26

voice name

deﬁned 79

phonebook indicator 76

recording 79–80

voice note

deﬁned 111

deleting 116

locking and unlocking 115

playback controls 114

playback screen 113

playing 112–114

recording 111

viewing voice notes list 112

183

Index

PRELIMINARY

Voice Notes Menu 112, 113,

114

voice shortcut

creating 108–109

deﬁned 108

using 110

voicemail

dialing with one-touch dial

number, storing 94

receiving 94–95

volume

earpiece 28

keypad 120

ringer 28, 120

volume keys 1, 28, 45

wait character 40

warranty 163–170

Web pages

functions 118

viewing 117

zoom setting 27, 67

U.S. patent Re. 34,976

Index

184

PRELIMINARY

185

✂

PRELIMINARY

Wireless Phone Safety Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

beneﬁts of wireless phones, one that every user

must uphold.

When driving a car, driving is your ﬁrst

responsibility. If you ﬁnd it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

following tips:

Get to know your Motorola wireless phone and its

features such as speed dial and redial. If available,

these features help you to place your call without taking your

attention off the road.

When available, use a hands-free device. If possible,

add an additional layer of convenience to your wireless

phone with one of the many Motorola Original™ hands-free

accessories available today.

186

✂

PRELIMINARY

Position your wireless phone within easy reach. Be

able to access your wireless phone without removing your

eyes from the road. If you receive an incoming call at an

inconvenient time, if possible, let your voice mail answer it

for you.

Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy trafﬁc

or hazardous weather conditions. Rain, sleet, snow, ice,

and even heavy trafﬁc can be hazardous.

If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers

while driving. Jotting down a “to do” list or going through

your address book takes attention away from your primary

responsibility—driving safely.

Dial sensibly and assess the trafﬁc; if possible, place

calls when you are not moving or before pulling into

trafﬁc. Try to plan calls when your car will be stationary. If

you need to make a call while moving, dial only a few

numbers, check the road and your mirrors, then continue.

Do not engage in stressful or emotional

conversations that may be distracting. Make people

you are talking with aware you are driving and suspend

conversations which have the potential to divert your

attention away from the road.

Use your wireless phone to call for help. Dial 9-1-1 or

other local emergency number in the case of ﬁre, trafﬁc

accident or medical emergencies.*

187

✂

PRELIMINARY

Use your wireless phone to help others in

emergencies. If you see an auto accident, crime in progress

or other serious emergency where lives are in danger, call

9-1-1 or other local emergency number, as you would want

others to do for you.*

Call roadside assistance or a special non-emergency

wireless assistance number when necessary. If you see

a broken-down vehicle posing no serious hazard, a broken

trafﬁc signal, a minor trafﬁc accident where no one appears

injured, or a vehicle you know to be stolen, call roadside

assistance or other special non-emergency wireless number.*

* Wherever wireless phone service is available.

188

✂

PRELIMINARY

Check the laws and regulations on the use of

wireless telephones and their accessories in the

areas where you drive. Always obey them. The

use of these devices may be prohibited or

restricted in certain areas.

For more information,

please call

1-888-901-SAFE

or visit the

CTIA Web site at

Motorola Mobility T56AS1 Portable Cellular Transceiver User Manual AS EX08

Motorola Mobility LLC Portable Cellular Transceiver AS EX08

Contents

Exhibit 8C Updated Users Manual RESPONSE TO 18898

Navigation menu

Namespaces

Views

Navigation
