Introduction 1
Introduction 1
1Introduc tion
Welcome to the world of Motorola digital mobile
communications! We are pleased that you have chosen the
Motorola 3G mobile phone.
Note: Your phone may not appear exactly as the phone
images below and throughout this manual. However all key
locations, sequences, and functions are the same.
www.motorola.com
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s network.
Additionally, certain features may not be activated by your
service provider, and/or the provider's network settings may
limit the feature’s functionality. Always contact your service
provider about feature availability and functionality. All
features, functionality, and other product specifications, as
well as the information contained in this user's guide are
based upon the latest available information and are believed
to be accurate at the time of printing. Motorola reserves the
right to change or modify any information or specifications
without notice or obligation.
Left Soft Key
Video Call Key
Volume Keys
Smart Key
Navigation Key
Navigate menus
Vodafone live!
Centre Key
Open menus,
select menu
items.
Right Soft Key
Camera Key
Clear/Back Key
Power/End Key
Turn on & off,
hang up, exit
menus.
Internal Camera
Lens
Send Key
Make & answer
calls
Accessory Connector Port
Insert battery charger
& phone accessories.
Volume Keys
Scroll and adjust volume.
Smart Key
Camera Key
External Camera Lens
External Display
See incoming call information, use as
camera viewfinder when flip is closed.
Touch-Sensitive Audio Player Keys
Previous track
Play/Pause
Next track
V1100.3G.UG.book Page 1 Wednesday, August 9, 2006 4:19 PM
1 Introduction
2 Introduction
MOTOROLA and the Stylised M Logo are registered in the US
Patent & Trademark Office.
The Bluetooth trademarks are owned by their proprietor and
used by Motorola, Inc. under license.
Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S.
and other countries.
All other product or service names are the property of their
respective owners.
© Motorola, Inc., 2006.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and
third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software.
Accordingly, any copyrighted software contained in the
Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any licence under the
copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-
exclusive, royalty-free licence to use that arises by operation
of law in the sale of a product.
While features may be subject to change without notice,
every effort is made to ensure that user manuals reflect
product functionality revisions. However, in the unlikely
event that your manual version does not fully reflect the
functionality of your product, please let us know. You may
also be able to access up-to-date versions of our manuals in
the consumer section of our Motorola web site, at
http://
www.motorola.com
.
V1100.3G.UG.book Page 2 Wednesday, August 9, 2006 4:19 PM
Contents 2
Contents 3
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
EU Conformance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Recycling Information . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing the USIM, SIM, or Memory Card . . . . . . . . 14
Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
User Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Battery Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Using Your Charger. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . 18
Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing the Call Alert . . . . . . . . . . . . . . . . . . . . . . . . 20
Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . 20
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Taking and Sending a Photo . . . . . . . . . . . . . . . . . . . . 29
Using Photos and Pictures . . . . . . . . . . . . . . . . . . . . . 31
Sending a Postcard. . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Recording Video Clips. . . . . . . . . . . . . . . . . . . . . . . . . 34
Using Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Making Video Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using and Transferring Files . . . . . . . . . . . . . . . . . . . . . 39
Playing or Viewing Media Files . . . . . . . . . . . . . . . . . . 39
Sending Media Files . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Audio Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Radio DJ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Connecting Your Phone to Another Device . . . . . . . . . 43
Connecting a Memory Card to your computer . . . . . . 47
Phone Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Vodafone live! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Vodafone live!. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Ticker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Learning to Use Your Phone. . . . . . . . . . . . . . . . . . . . . . 54
Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Using the 5-Way Navigation Key. . . . . . . . . . . . . . . . . 57
2Contents
V1100.3G.UG.book Page 3 Wednesday, August 9, 2006 4:19 PM
2Contents
4 Contents
Using Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
External Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Using the Handsfree Speaker . . . . . . . . . . . . . . . . . . . 59
Changing a Code, PIN, or Password . . . . . . . . . . . . . . 59
Locking and Unlocking Your Phone . . . . . . . . . . . . . . 60
If You Forget a Code, PIN, or Password . . . . . . . . . . . 61
Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Storing Your Name and Phone Number . . . . . . . . . . . 62
Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . 62
Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Ring & Event Lights . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . 63
Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 64
Setting Display Appearance. . . . . . . . . . . . . . . . . . . . . 64
Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . 65
Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . 66
Changing the Active Line. . . . . . . . . . . . . . . . . . . . . . . 66
Viewing Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Redialling a Number . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . 67
Returning an Unanswered Call . . . . . . . . . . . . . . . . . . 68
Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Putting a Call On Hold or Mute . . . . . . . . . . . . . . . . . . 69
Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Calling an Emergency Number . . . . . . . . . . . . . . . . . . 70
Dialling International Numbers . . . . . . . . . . . . . . . . . . 70
Calling With Speed Dial. . . . . . . . . . . . . . . . . . . . . . . . 71
Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Phone Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Navigation Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . 75
SAR Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
V1100.3G.UG.book Page 4 Wednesday, August 9, 2006 4:19 PM
Safety and General Information 3
Safety Information 5
3Safet y Informat ion
IMPORTANT INFORMATION ON SAFE AND EFFICIENT
OPERATION. READ THIS INFORMATION BEFORE USING
YOUR PHONE.1
3.1 Exposure To Radio Frequency (RF)
Energy
Your phone contains a transmitter and a receiver. When it is
ON, it receives and transmits RF energy. When you
communicate with your phone, the system handling your call
controls the power level at which your phone transmits.
Your Motorola phone is designed to comply with local
regulatory requirements in your country concerning
exposure of human beings to RF energy.
3.2 Operational Precautions
To assure optimal phone performance and make sure human
exposure to RF energy is within the guidelines set forth in the
relevant standards, always adhere to the following
instructions.
3.2.1 External Antenna Care
If your phone has an external antenna, use only the supplied
or Motorola-approved replacement antenna. Unauthorised
antennas, modifications, or attachments could damage the
phone and/or may result in non-compliance with local
regulatory requirements in your country.
Do NOT hold the external antenna when the phone is IN USE.
Holding the external antenna affects call quality and may cause
the phone to operate at a higher power level than needed.
3.2.2 Phone Operation
When placing or receiving a phone call, hold your phone as
you would a fixed line phone.
3.2.3 Body-Worn Operation: Voice
Communication
To maintain compliance with RF energy exposure guidelines, if
you wear a phone on your body when transmitting voice
communications, always place the phone in a Motorola-
supplied or approved clip, holder, holster, case, or body
harness for this phone, if available. Use of accessories not
3.Safet y and Gene ral Informat ion
V1100.3G.UG.book Page 5 Wednesday, August 9, 2006 4:19 PM
3.2.4 Safety and General Information
6 Safety Information
approved by Motorola may exceed RF energy exposure
guidelines.
If you do not use one of the body-worn accessories approved
or supplied by Motorola, and are not using the phone held in
the normal use position, ensure the phone and its antenna
are at least 2.5 centimetres (1 inch) from your body when
transmitting.
3.2.4 Data Operation
When using any data feature of the phone, with or without an
accessory cable, position the phone and its antenna at least
2.5 centimetres (1 inch) from your body.
3.2.5 Approved Accessories
Use of accessories not approved by Motorola, including but
not limited to batteries, antennas, and convertible covers,
may cause your phone to exceed RF energy exposure
guidelines. For a list of approved Motorola accessories, visit
our website at www.motorola.com.
3.3 RF Energy Interference/Compatibility
Note: Nearly every electronic device is susceptible to RF
energy interference from external sources if inadequately
shielded, designed, or otherwise configured for RF energy
compatibility. In some circumstances your phone may cause
interference.
Note: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
3.3.1 Facilities
Turn off your phone in any facility where posted notices
instruct you to do so. These facilities may include hospitals
or health care facilities that may be using equipment that is
sensitive to external RF energy.
V1100.3G.UG.book Page 6 Wednesday, August 9, 2006 4:19 PM
Safety and General Information 3.3.2
Safety Information 7
3.3.2 Aircraft
Turn off your wireless device whenever instructed to do so
by airline staff. If your device offers a flight mode or similar
feature, consult airline staff about use in flight. If your device
offers a feature that automatically turns on the phone, then
turn off this feature before boarding an aeroplane or entering
an area where the use of wireless devices is restricted.
3.3.3 Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum
separation of 15 centimetres (6 inches) be maintained
between a handheld wireless phone and a pacemaker.
Persons with pacemakers should:
•ALWAYS keep the phone more than 15 centimetres
(6 inches) from your pacemaker when the phone is
turned ON.
•NOT carry the phone in the breast pocket.
•Use the ear opposite the pacemaker to minimise the
potential for interference.
•Turn OFF the phone immediately if you have any reason
to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may want
to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from RF energy. Your physician may be able to
assist you in obtaining this information.
3.4 Use While Driving
Check the laws and regulations on the use of phones in the
area where you drive. Always obey them.
When using your phone while driving, please:
•Give full attention to driving and to the road. Using a
phone may be distracting in certain circumstances.
Discontinue a call if you can’t concentrate on driving.
V1100.3G.UG.book Page 7 Wednesday, August 9, 2006 4:19 PM
3.5 Safety and General Information
8 Safety Information
•Always use handsfree operation.
•Pull off the road and park before making or answering
a call if driving conditions so require.
Responsible driving best practices can be found in the
“Wireless Phone Safety Tips” at the end of this guide and/or
at the Motorola website: www.motorola.com/
callsmart.
3.5 Operational Warnings
3.5.1 For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air
bag deployment area. Air bags inflate with great force. If a
phone is placed in the air bag deployment area and the air
bag inflates, the phone may be propelled with great force and
cause serious injury to occupants of the vehicle.
3.5.2 Gas or Petrol Stations
Obey all posted signs with respect to the use of radio
equipment in gas or petrol stations. Turn off your wireless
device if instructed by authorised staff.
3.5.3 Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a
potentially explosive atmosphere. Do not remove, install, or
charge batteries in such areas. Sparks in a potentially
explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres
referred to above include fuelling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, areas
where the air contains chemicals or particles, such as grain,
dust, or metal powders. Areas with potentially explosive
atmospheres are often but not always posted.
3.5.4 Blasting Caps and Areas
To avoid possible interference with blasting operations, turn
OFF your phone when you are near electrical blasting caps, in
a blasting area, or in areas posted “Turn off electronic
devices.” Obey all signs and instructions.
V1100.3G.UG.book Page 8 Wednesday, August 9, 2006 4:19 PM
Safety and General Information 3.5.5
Safety Information 9
3.5.5 Damaged Products
If your phone or battery has been submerged in water,
punctured, or subjected to a severe fall, do not use it until
you take it to a Motorola Authorised Service Centre to
determine if it has been damaged. Do not attempt to dry it
with an external heat source, such as a microwave oven.
3.5.6 Batteries and Chargers
Batteries can cause property damage and/or bodily injury
such as burns if a conductive material such as jewellery,
keys, or beaded chains touch exposed terminals. The
conductive material may complete an electrical circuit (short
circuit) and become hot. Take care when handling a charged
battery, particularly when placing it inside a pocket, purse, or
other container with metal objects. Use only Motorola
Original™ batteries and chargers.
Caution: To avoid risk of personal injury, do not dispose of
your battery in a fire.
Your battery, charger, or phone may contain symbols,
defined as follows:
Symbol Definition
Important safety information will follow.
Your battery or phone should not be
disposed of in a fire.
Your battery or phone may require
recycling in accordance with local laws.
Contact your local regulatory authorities
for more information.
Your battery or phone should not be
thrown in the rubbish bin.
Your phone contains an internal lithium
ion battery.
Do not let your battery, charger, or
mobile device get wet.
Listening at full volume to music or voice
through a headset may damage your
hearing.
032374o
032376o
032375o
032377o
032378o
Li Ion BATT
V1100.3G.UG.book Page 9 Wednesday, August 9, 2006 4:19 PM
3.6 Safety and General Information
10 Safety Information
3.6 Choking Hazards
Your phone or its accessories may include detachable parts,
which may present a choking hazard to small children. Keep
your phone and its accessories away from small children.
3.7 Glass Parts
Some parts of your mobile device may be made of glass.
This glass could break if the product is dropped on a hard
surface or receives a substantial impact. If glass breaks, do
not touch or attempt to remove. Stop using your mobile
device until the glass is replaced by a qualified service
centre.
3.8 Seizures/Blackouts
Some people may be susceptible to epileptic seizures or
blackouts when exposed to flashing lights, such as when
watching television or playing video games. These seizures
or blackouts may occur even if a person never had a previous
seizure or blackout.
If you have experienced seizures or blackouts, or if you have
a family history of such occurrences, please consult with
your doctor before playing video games on your phone or
enabling a flashing-lights feature on your phone. (The
flashing-light feature is not available on all products.)
Parents should monitor their children's use of video games
or other features that incorporate flashing lights on the
phones. All persons should discontinue use and consult a
doctor if any of the following symptoms occur: convulsion,
eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the
following safety precautions:
•Do not play or use a flashing-lights feature if you are
tired or need sleep.
•Take a minimum of a 15-minute break hourly.
•Play in a room in which all lights are on.
•Play at the farthest distance possible from the screen.
•Repetitive Motion Injuries
V1100.3G.UG.book Page 10 Wednesday, August 9, 2006 4:19 PM
Safety and General Information 3.9
Safety Information 11
3.9 Caution About High Volume Usage
Listening at full volume to music or voice through
a headset may damage your hearing.
3.10 Repetitive Motion injuries
When you repetitively perform actions such as pressing keys
or entering finger-written characters, you may experience
occasional discomfort in your hands, arms, shoulders, neck,
or other parts of your body. Follow these instructions to
avoid problems such as tendonitis, carpal tunnel syndrome,
or other musculoskeletal disorders:
•Take a minimum 15-minute break every hour of game
playing.
•If your hands, wrists, or arms become tired or sore
while playing, stop and rest for several hours before
playing again.
•If you continue to have sore hands, wrists, or arms
during or after play, stop playing and see a doctor.
1. The information provided in this document supersedes the
general safety information in user’s guides published prior to
January 28, 2005.
V1100.3G.UG.book Page 11 Wednesday, August 9, 2006 4:19 PM
4 EU Conformance
12 EU Conformance
4EU Co nformance
European Union Directives Conformance Statement
Hereby, Motorola declares that this product is in compliance
with
•The essential requirements and other
relevant provisions of Directive 1999/5/EC
•All other relevant EU Directives
The above gives an example of a typical Product Approval
Number.
You can view your product's Declaration of Conformity
(DoC) to Directive 1999/5/EC (the R&TTE Directive) at
www.motorola.com/rtte - to find your DoC, enter the product
Approval Number from your product's label in the "Search"
bar on the Web site.
IMEI: 350034/40/394721/9
0168
Type: MC2-41H14
Product
Approval
Number
V1100.3G.UG.book Page 12 Wednesday, August 9, 2006 4:19 PM
Recycling Information 5
Recycling Information 13
5Recycling Information
5.1 Caring for the Environment by
Recycling
When you see this symbol on a Motorola product,
do not dispose of the product with household
waste.
5.2 Recycling Mobile Phones and
Accessories
Do not dispose of mobile phones or electrical accessories,
such as chargers or headsets, with your household waste. In
some countries or regions, collection systems are set up to
handle electrical and electronic waste items. Contact your
regional authorities for more details. If collection systems
aren’t available, return unwanted mobile phones or electrical
accessories to any Motorola Approved Service Centre in your
region.
V1100.3G.UG.book Page 13 Wednesday, August 9, 2006 4:19 PM
6Basics
14 Basics
6Basics
6.1 About This Guide
This guide describes the basic features of your Motorola
mobile phone.
To obtain another copy of this guide, see the Motorola Web
site at:
www.hellomoto.com
A Quick Start Guide for this product is also available.
6.1.1 Optional Features
This label identifies an optional network, SIM card, or
subscription-dependent feature that may not be
offered by all service providers in all geographical
areas. Contact your service provider for more
information.
6.1.2 Optional Accessories
This label identifies a feature that requires an optional
Motorola Original™ accessory.
6.2 Installing the USIM, SIM, or Memory
Card
Caution: Do not bend or scratch your card. Avoid exposing
your card to static electricity, water, or dirt.
Turn off your phone and remove your battery before you
install or remove a SIM card.
Your 3G USIM (Universal Subscriber Identity Module) Card
contains your phone number, service details, and contacts
list/message memory. Your phone can use GSM SIM
(Subscriber Identity Module) cards, but not all features will
be available.
12
V1100.3G.UG.book Page 14 Wednesday, August 9, 2006 4:19 PM
Memory Card 6.3
Basics 15
6.3 Memory Card
Insert the Memory Card next
to the SIM card. To remove
the memory card, slide it out.
The Memory Card provides
you with a larger storage
capacity than the Phone
Memory. When you download
pictures, sounds, video clips,
or Java applications, they are
saved to the Memory Card.
Note: If you download a copyrighted file and store it on your
memory card, you can use the file only while your memory
card is inserted in your phone. You cannot send, copy, or
change copyrighted files.
To show the amount of free space on the Memory Card:
When you look at a list of files in My Files, the icon next to it
shows whether it is stored on your memory card or your
internal memory.
Note: A key over the icon indicates that the file has a
copyright lock that keeps you from saving it on external
memory, forwarding it, or editing it.
If you have a TransFlash removable memory card, the
use of an SD adapter allows you to use it in other
devices that are compatible with SD cards (for
example, digital cameras, laptops, mp3-players).
Find the Feature s>Settings > Phone Status
>Storage Devices
Press To
1Shighlight the memory card
2ssee the memory card information
= stored on internal
memory
= stored on memory
card
V1100.3G.UG.book Page 15 Wednesday, August 9, 2006 4:19 PM
6.4 User Memory
16 Basics
6.4 User Memory
Your phone stores any content that you add, like ringtones or
games, in user memory. Your service provider may store
some content in user memory before you receive the phone.
6.5 Battery Tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
•Always use Motorola Original batteries and
battery chargers. The warranty does not
cover damage caused by non-Motorola
batteries and/or chargers.
•New batteries or batteries stored for a long time may
take more time to charge.
•When charging your battery, keep it near room
temperature.
•When storing your battery, keep it uncharged in a cool,
dark, dry place, such as a refrigerator.
•Never expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your phone
with you when you leave your vehicle.
•It is normal for batteries to gradually wear down and
require longer charging times. If you notice a change in
your battery life, it is probably time to purchase a new
battery.
Contact your local recycling centre for proper battery
disposal.
Warning: Never dispose of batteries in a fire because they
may explode.
Before using your phone, please read the battery safety
information in the Safety and General Information section
included in this guide.
V1100.3G.UG.book Page 16 Wednesday, August 9, 2006 4:19 PM
Installing the Battery 6.6
Basics 17
6.6 Installing the Battery
Your phone is designed to use only
Motorola Original™ batteries and accessories.
6.7 Using Your Charger
The battery charger shipped with this device is specifically
designed for use with Motorola 3G mobile phones. Other
chargers might take longer to charge your battery or cause
your calls to fail during charging.
For best performance, please use the following charger kits
with this device:
•SPN5189 and SPN5190 Chargers.
12
3
V1100.3G.UG.book Page 17 Wednesday, August 9, 2006 4:19 PM
6.8 Charging the Battery
18 Basics
6.8 Charging the Battery
New batteries are shipped partially charged. Before using
your phone, please install and fully charge the battery as
described below. Some batteries perform best after several
full charge/discharge cycles.
Tip: You can safely leave the charger connected to your
phone after charging is complete. This will not damage the
battery.
6.9 Turning Your Phone On
Action
1Plug the charger
into your phone.
2Plug the other end of the charger into the appropriate
electrical outlet.
3When your phone indicates Charge Complete, remove the
charger.
Action
1Press and hold for 2
seconds or until the display
turns on.
2If you want to start in Flight Mode, see “Flight Mode” on
page 93 for more details.
3If you want to use a User Account, press S to scroll
to the User Account you want. Then press the Select
key to select the account from the list (stored on the
SIM card).
4If you are prompted, enter your SIM card PIN code
and press the Ok key to unlock the SIM card.
Caution: If you enter an incorrect PIN code 3 times in
a row, your SIM card is disabled and your phone
displays SIM Blocked.
V1100.3G.UG.book Page 18 Wednesday, August 9, 2006 4:19 PM
Adjusting Volume 6.10
Basics 19
6.10 Adjusting Volume
Press the up or down volume keys to:
•increase or decrease earpiece
volume during a call
•increase or decrease speakerphone
volume during a call
•turn off an incoming call alert
•increase or decrease the ringer volume setting when
the home screen is visible
Tip: At the lowest volume setting, press the down
volume key once to switch to vibrate alert. Press it
again to switch to silent alert. Press the up volume key
to cycle back to vibrate alert, then ring alert.
To change your ringer volume when your phone is closed,
see page 59.
6.11 Making a Call
To make video calls, see page 36.
5If you are prompted, enter your four-digit unlock code
and press Ok key to unlock the phone.
Tip: The unlock code is originally set to 1234. Your
service provider may change this number before you
receive your phone.
6To turn off your phone, press and hold for 2
seconds.
Action
Press To
1keypad keys dial the phone number
2make the call
3end the call and “hang up” the phone
when you are finished
or
to “hang up” close the flip
V1100.3G.UG.book Page 19 Wednesday, August 9, 2006 4:19 PM
6.12 Answering a Call
20 Basics
Note: You can make an emergency call even when the phone
is locked, or when a SIM card is not inserted (see page 70).
6.12 Answering a Call
When you receive a call, your phone rings and/or vibrates
and displays an incoming call message.
6.13 Changing the Call Alert
To set your Ring Style, press s > Ring Styles or Settings
>Ring Styles (see page 62).
Shortcut: In the home screen, press the volume keys up or
down to quickly change your ring style profile. With your
phone closed, press a volume key to see your ring style
profile, press the smart key to change it, then press a volume
key to store the change.
Shortcut: Press and hold # to quickly change to silent
style. Press and hold # again to change back to previous
ring style.
6.14 Viewing Your Phone Number
To view your phone number from the home screen, press
K#.
While you are on a call, press Options > My Tel. Numbers.
Note: Your phone number must be stored on your SIM card
to use this feature. To store your phone number on the SIM
card, see page 62. If you do not know your phone number,
contact your service provider.
Press To
1open the flip
or
answer the call
Divert or divert the call to your voicemail or call
divert number, as though your line
was busy
2end the call and “hang up” the phone
when you are finished
V1100.3G.UG.book Page 20 Wednesday, August 9, 2006 4:19 PM
Entering Text 6.15
Basics 21
6.15 Entering Text
Some features require you to enter information. The
message centre lets you compose and send text messages.
6.15.1 Choosing a Text Entry Mode
Multiple text entry modes make it easy for you to enter
names, numbers, and messages. The mode you select
remains active until you select another mode.
Press # in any text entry screen to select one of the
following entry modes:
6.15.2 Setting Up a Text Entry Mode
To set your primary and secondary text entry modes, press
Options > Text Setup in a text entry view, select Primary Text or
Secondary Text, and choose:
Options Send To
For indicator
descriptions,
see following
section.
Flashing
cursor
indicates
insertion point.
Press the Options key to open the
sub-menu.
After you enter
text press the
Send To
key to
enter recipients.
Msg SMS:0
or Your Primary text entry mode can be set to any
iTAPTM or tap mode.
or Your Secondary text entry mode can be set to any
iTAP or tap mode, or set to None if you
don’t want a secondary entry mode.
WNumeric mode enters numbers only.
Symbol mode enters symbols only.
iTAP Let the phone predict each word as you press
keys (see page 25).
Tap Enter letters and numbers by pressing a key
one or more times.
V1100.3G.UG.book Page 21 Wednesday, August 9, 2006 4:19 PM
6.15.3 Using Tap Mode
22 Basics
Using Capitalisation
Press 0 in any text entry screen to change text case. The
following indicators show capitalisation status:
Text Entry Mode Indicators
When you select the Primary or Secondary text entry mode, the
following indicators identify the text entry setting:
Two other indicators identify Numeric (W) or Symbol () entry
modes.
6.15.3 Using Tap Mode
This is the standard mode for entering text on your phone.
Regular Tap mode cycles through the letters and number of
the key you press. Tap Extended also cycles through additional
symbols as shown in the chart on page 24.
Tap Extended Enter letters, numbers, and symbols by
pressing a key one or more times.
None Hide the Secondary setting (only available for
Secondary Setup).
= no capital letters = capitalise next letter
only
= all capital letters
Primary Second.
Tap, no capital letters
Tap, capitalise next letter only
Tap, all capital letters
iTAP, no capital letters
iTAP, capitalise next letter only
iTAP, all capital letters
Primary Second.
V1100.3G.UG.book Page 22 Wednesday, August 9, 2006 4:19 PM
Using Tap Mode 6.15.3
Basics 23
In a text entry screen, you can press # to switch entry
mode. If you don’t see Vg or Vm then press Options
>Text Setup to set tap mode as your primary or secondary text
entry mode. To enter text in tap mode, press a keypad key repeatedly to
cycle through the letters and number on the key. Repeat this
step to enter each letter.
When you enter 3 or more characters in a row, your phone
may guess the rest of the word. For example, if you enter prog
you might see:
Press To
1A keypad key one
or more times
select a letter, number, or symbol
2keypad keys enter remaining characters
Tip: Press S right to accept a
word completion, or * to insert
a space.
Options Send To
Msg SMS:4
Block cursor
indicates
highlighted
character.
After 2 seconds,
character is
accepted and
cursor moves to
next position.
Press the
Options
key to
open the sub-menu.
Press the
Send To
key to enter the
recipient.
T
Press
K
to
delete character
to left of
insertion point.
V1100.3G.UG.book Page 23 Wednesday, August 9, 2006 4:19 PM
6.15.3 Using Tap Mode
24 Basics
If you want a different word (such as progress), continue
pressing keypad keys to enter the remaining characters.
•Press S left or right to move the flashing cursor to
the left or right in a text message.
•The first character of every sentence is capitalised. If
necessary, press S down to force the character to
lowercase before the cursor moves to the next
position.
•If you enter or edit information and do not want to save
the changes, press to exit without saving.
Character Chart
Use this chart as a guide for entering characters with
Tap Extended.
Options Send To
Msg SMS:4
This is a prog ram
Flashing
cursor
indicates
insertion point.
Press
S
right
to accept
program
, or
press
*
to
reject it and
enter a space
after
prog
.
1. ? ! , @ ' - _ : ; ( ) & ` " ~ 1 0 ¿ ¡ ^ % £ $ ¥ ¤
£
+ x
* / \ | [ ] = > < # §
2a b c 2 á à â ä ã ç
3d e f 3 é è ê ë
4g h i 4 í î ï
5j k l 5
6m n o 6 ñ ó ò ô ö õ œ
7p q r s 7
8t u v 8 ú ù û ü
9w x y z 9
0change text case, for capital letters
*enter a space (hold to enter a return)
#change text entry mode (hold for default)
V1100.3G.UG.book Page 24 Wednesday, August 9, 2006 4:19 PM
Using iTAP™ Mode 6.15.4
Basics 25
Note: This chart may not reflect the exact character set
available on your phone. In an email address or URL editor,
1 first shows common characters for that editor.
6.15.4 Using iTAP™ Mode
Press # in a text entry view to switch to iTAP mode. If you
don’t see or , press Options > Text Setup to set iTAP
mode as your primary or secondary text entry mode.
iTAP™ software provides a predictive text entry mode that
lets you enter a word using one keypress per letter. This can
be faster than Tap, because your phone combines the
keypresses into common words.
Tip: Your phone has a text tutorial which should help you
with any problems.
For example, if you press 7764, letter combinations
that match your key presses display:
•If you want a different word (such as Progress), continue
pressing keypad keys to enter the remaining
characters.
•To enter numbers quickly, press and hold a number
key to temporarily switch to numeric mode. Press the
number keys to enter the numbers you want. Enter a
space to change back to iTAP mode.
•Press 1 to enter punctuation or other characters.
Find the Feature Options >Text Setup > Text Tutorial
Options Send To
Msg SMS:4
Prog ram
Press
S
down to see a
list of word
options.
Press
Options
key to open
message
options.
Press
Send To
key when the
message is
complete.
Press
S
up
to accept
Program
, or
press
*
to
enter
Prog
and
a space.
V1100.3G.UG.book Page 25 Wednesday, August 9, 2006 4:19 PM
6.15.5 Using Numeric Mode
26 Basics
Entering Words
In a text entry screen, you can press # to switch entry
modes. An indicator shows which mode is active (see
page 22). If iTAP mode is not available as the Primary or
Secondary entry mode, see page 21.
If you enter a word your phone does not recognise, the
phone stores it to use as one of your word options. When
you fill memory space for unrecognised words, your phone
deletes the oldest words to add new words.
6.15.5 Using Numeric Mode
In a text entry screen, press # to switch entry modes until
the W (Numeric) indicator displays.
Press To
1keypad keys (one
press per letter)
show possible letter
combinations
If alternative combinations are
available then an arrow appears
below the letters.
2S up or down go to the previous or next
available predicted words
Press and hold S up or down
to display a popup window
showing the next four predicted
words. You can scroll up and
down through this list and then
press Select to accept the
highlighted word.
3S right accept the predicted word
4S left move the cursor back one letter
5s
or
select a word
You can press keypad keys to
add more letters to the end of
the combination.
*enter the highlighted
combination when it spells a
word
A space is automatically inserted
after the word.
Press To
V1100.3G.UG.book Page 26 Wednesday, August 9, 2006 4:19 PM
Using Symbol Mode 6.15.6
Basics 27
Press keypad keys to enter the numbers you want. When you
finish entering numbers, press # to switch to another entry
mode.
6.15.6 Using Symbol Mode
In a text entry screen, press # to switch entry modes until
the (Symbol) indicator displays.
6.15.7 Deleting Letters and Words
Place the cursor to the right of the text you want to delete,
and then:
6.15.8 Copying, Cutting, and Pasting Text
From a text entry screen:
Press To
1S left, right, up
or down
highlight the symbol you want
2S down view more symbols
Options Send To
Msg 450
.?!
,@ ‘
-_:
3s or the
corresponding
number key
enter the highlighted symbol
*enter a space (hold to enter a
return)
#change text entry mode (hold for
default)
Action
Press K to delete the last letter.
Press and hold K to clear the entire message.
Find the Feature Options >Editing Options
Press To
V1100.3G.UG.book Page 27 Wednesday, August 9, 2006 4:19 PM
6.15.8 Copying, Cutting, and Pasting Text
28 Basics
Note:
•Paste only displays once you have cut or copied some
text.
•Undo only displays once you have cut, copied or pasted
some text.
•Copy All Text also displays in the menu (press
Options)
when you are viewing details for a Contacts entry, Calendar
event, Vodafone live! page, text message, or Call Log entry.
Highlighting Text
In a text editor, to highlight and copy or cut text:
Text remains on your clipboard, available to paste, until you
copy or cut other text or until you turn off your phone.
Option Description
Copy Text Copy the text you are about to highlight
(see “Highlighting Text” on page 28).
Cut Text Cut the text you are about to highlight
(see “Highlighting Text” on page 28).
Copy All Text Copy all text in the editor.
Cut All Text Cut all text in the editor.
Paste Paste the text you cut or copied.
Delete Delete the selected text.
Undo Undo the last copy, cut, or paste in the
current text editor.
Find the Feature Options >Editing Options > Copy Text or
Cut Text
Press To
1Sscroll to the beginning of the text
you want to copy or cut
2Start key turn on the highlighting marker
3Sscroll to the end of the text you
want to copy or cut
4Copy key
or
Cut key
copy or cut the text you selected
You can now paste the text in
another location or file.
V1100.3G.UG.book Page 28 Wednesday, August 9, 2006 4:19 PM
Camera 7
Camera 29
7Camer a
You can do much more with your phone than make and
receive calls! This section describes your phone’s camera
and video camera features.
7.1 Taking and Sending a Photo
To activate your phone’s camera, press the camera key on
the top right side of your phone (see page 1 for exact
location), or select the camera icon on the main menu.
The active viewfinder image displays.
Point the camera lens at the photo subject.
Note: If you select Store Only you can select Print and Store to
print the picture over a Bluetooth connection, see page 44.
Area display
image options
Options Back
Press
S
up or
down to scroll
through available
options.
Press
S
left or
right to set
value for
available
options.
Open the
Pictures Menu
.
Go back to
previous
screen
Press
S
to
display the
image options.
Press To
1s or the
camera key
take a photo
Tip: Press * to turn the light on or
off
2Options
>Store Only
store the photo
or
Options > Send
or Send key
send the photo in a message
or
Options
>Discard
delete the photo and return to active
viewfinder
V1100.3G.UG.book Page 29 Wednesday, August 9, 2006 4:19 PM
7.1.1 Self Portrait
30 Camera
Press
Options
to open the Pictures Menu when the camera is
active. The menu can include the following options:
Tip: To assign a stored picture to a contacts entry, open the
entry and press
Options > Edit Contact >Picture. You cannot
assign pictures to entries stored on your SIM card.
7.1.1 Self Portrait
If you close your phone while the viewfinder is active, the
external display shows the image. Press the volume keys to
zoom, or press the camera key to capture and store the
image.
Option Description
Go To Pictures View pictures and photos stored on
your phone.
Go To Video Mode Capture and view videos stored on your
phone.
Internal View/
External View
Switch between the internal (self-
portrait) and external cameras.
Light On/Off Turn the camera light on and off.
Note: The light stays on until you take a
picture, receive a phone call, or select
Light Off.
Auto-Timed Capture Set a timer for the camera to take a
photo.
Camera Setup Open the setup menu to adjust picture
and video settings.
Switch Storage
Device
Choose to store and see pictures
on your phone or memory card.
Free Space View memory space available for
storing pictures.
Exposure Adjust exposure of the picture.
Option Description
V1100.3G.UG.book Page 30 Wednesday, August 9, 2006 4:19 PM
Using Photos and Pictures 7.2
Camera 31
7.2 Using Photos and Pictures
You can send your photos to other mobile phone users or
email addresses, assign photos to specific contacts entries,
and use them as wallpaper or screen saver images.
7.2.1 Downloading Pictures
Your phone may contain predefined photos, pictures, and
animations. You can download and store additional images
on your phone.
If you are unable to establish a network connection with
Vodafone live!, contact your service provider.
Note: The files that you download or receive as attachments
might have a copyright lock that keeps you from forwarding
them.
To download a picture from Vodafone live!, see page 49. To
store a picture from a message, see page 78.
7.2.2 Viewing and Managing Pictures
Note: Some files might have a copyright lock that keeps you
from saving them on external memory, forwarding them, or
editing them.
To view a photo, picture, or animation stored on your phone:
Tip: You can change the way your picture list displays using
the Pictures Setup option in the Pictures Menu.
Find the Feature s>My Files > Pictures
Press To
1S up or down scroll to the picture
2sview the picture
Press and hold s to go to full
screen view. Press and hold s
to return to normal view.
3S
or
view the next/previous picture
Options open the Pictures Menu to perform
other options
V1100.3G.UG.book Page 31 Wednesday, August 9, 2006 4:19 PM
7.3 Sending a Postcard
32 Camera
Press
Options
to open the Pictures Menu from the picture list. The
menu can include the following options:
Note: Send and Manage are only available for photos you have
taken or pictures you have downloaded.
7.3 Sending a Postcard
The Vodafone Postcard service allows you to send a picture
as an MMS, which will be delivered as a real postcard to a
street address. You can send a picture that you have just
taken, or a picture already saved to your phone. You can also
include a personal greeting to the postcard.
.
Option Description
Hide Hide the picture.
View Details: View picture information.
View Free Space: View memory space
available for storing pictures.
Add to Album Add picture to your album.
Create New Capture a new picture or create an
album of stored pictures.
Filter by Filter pictures by Storage Location.
Send Insert selected picture in a new
message.
Apply As Set the picture as your phone’s
Wallpaper or Screen Saver, or a Contacts
Entry.
Print Print the picture.
Print Index Details of printed pictures.
Manage Select from Rename, Delete, Move or
Copy To for the current picture.
Select Multipe to Select more than one picture to Add to
Album, Delete, Move, Copy or Print.
Pictures Setup Open the setup menu to adjust picture
and video settings.
Find the Feature s>Messaging > Create Message
>Postcard
Press To
1Options > Insert choose a picture to send
Option Description
V1100.3G.UG.book Page 32 Wednesday, August 9, 2006 4:19 PM
Inserting a new address entry 7.3.1
Camera 33
7.3.1 Inserting a new address entry
If your Contacts does not have the intended recipient’s
address, insert a new address by selecting Address and then
Options > Enter Address. Define the following information:
2keypad keys enter your greeting text
Note: The maximum length for
the greeting text is 200
characters.
If the intended recipient already contains complete address
information in the contacts, do the following:
3Address select the address of the
recipient from your Contacts
Note: Only contact entries that
contain complete address
information will show in the list.
See “Inserting a new address
entry” on page 33 for inserting a
new address entry.
4S up or down scroll to the name of the person
you wish to send the postcard to
5s centre key select the recipient’s name
Note: You can select more than
one recipient for your postcard.
Press To
6Send send the postcard when you
have inserted the picture and the
recipient(s) address(es)
Option Description
First Name: enter the recipient’s first name
(mandatory)
Last Name: enter the recipient’s last name
(mandatory)
Additional
Information:
enter any other information
Address: enter the house name or number and
street name (mandatory)
City: enter the city name (mandatory)
State: enter the state name (optional)
Press To
V1100.3G.UG.book Page 33 Wednesday, August 9, 2006 4:19 PM
7.4 Recording Video Clips
34 Camera
Once you have entered all mandatory fields, press Done. Press
Send to send the postcard.
7.4 Recording Video Clips
To record a video on your phone:
The active viewfinder image displays.
Note: Your phone’s external camera light blinks during a
video call, to let people around you know that they might be
in your video.
Note: The number of clips remaining is only an estimate.
Point the camera lens at the video subject, then:
Postal Code: enter the postal code (optional)
Country: enter the country name (optional)
Find the Feature s>Camera >Options
>Go To Video Mode
Option Description
Press To
1s or the
camera key
start the video
Tip: You can press the Pause key to
pause video capture.
2Stop key stop the video
VIDEO
CLIP
AREA
Area displays
video options
Options Back
Press
S
up or
down to scroll
through available
options.
Press
S
left or
right to set value
for available
options. Open the
Videos Menu
.
Back to
previous
screen.
Press
S
to
display the
video options.
V1100.3G.UG.book Page 34 Wednesday, August 9, 2006 4:19 PM
Using Video Clips 7.5
Camera 35
Press
Options
to open the Videos Menu when the camera is active.
The menu can include the following options:
7.5 Using Video Clips
You can download video clips with Vodafone live!, and
receive video clips in multimedia messages.
7.5.1 Downloading Video Clips
To download a video clip with Vodafone live!, see page 49.
To store a video clip from a message, see page 78.
7.5.2 Viewing and Managing Video Clips
To play a video clip stored on your phone:
3Options
>Store Only
to store the video
To play a stored video, see page 35.
or
Send key to send the video in a message
or
Options
>Discard
delete the video and return to active
viewfinder
Option Description
Preview Preview video.
Go To Videos View videos stored on your phone.
Internal View/
External View
Switch between the internal (self-
portrait) and external cameras.
Videos Setup Open the setup menu to adjust picture
and video settings.
View Free Space See how much memory remains for
storing videos.
Press To
Find the Feature s>My Files > Videos
Press To
1S up or down scroll to the video clip
2sstart video clip playback
V1100.3G.UG.book Page 35 Wednesday, August 9, 2006 4:19 PM
7.6 Making Video Calls
36 Camera
During video clip playback, press
Options
to open the
Videos Menu to perform various operation on the video: 7.6 Making Video Calls
With your phone you can make a video call to someone else
who has a video phone and see each other while you talk.
Please note that both parties participating in the video call
have to be on the 3G network and in the 3G coverage area.
7.6.1 Making a Video Call
A quick guide to making a video call:
Option Description
Play Full Screen Stretch the video to fill the display.
Tip: A video can also be viewed in full
screen by pressing the key #.
Send Insert selected video in a new
message.
New Video Capture a new video.
View Details: View video information.
View Free Space: View memory space
available for storing videos.
Manage Select from Rename, Delete, Move or
Copy To for the current video.
Mark Current: Mark the current video to
move, copy, assign or delete it.
All: Mark all videos to move, copy,
assign or delete them.
Videos Setup Open the setup menu to adjust video
settings.
Press To
1keypad keys dial the phone number
2make the call
3end the call and “hang up” the phone
when you are finished
V1100.3G.UG.book Page 36 Wednesday, August 9, 2006 4:19 PM
Making a Video Call 7.6.1
Camera 37
Options During an Active Video Call
Swapping Views
During an active video call, there are two video areas on your
phone display. The primary video area shows your image (or
the selected Camera Off Image) and the secondary video area
shows your recipient’s image. You can swap between the
video areas to place your image onto the secondary video
area, and the recipient’s image onto the primary video area.
Selecting Applications
During an active video call, you can access other
applications, such as Contacts, Calendar, My Files or Vodafone live!
You can also send and receive messages during a video call
or start a new video call.
Video Call Menu
Some of the options accessed from the Video Call Menu during
an active call include the following:
Press To
Swap View swap between the primary and
the secondary video area during
a video call
Press To
More Apps access other applications during
a video call
Find the Feature Options >Video Call Menu
Press To
More Apps access applications during an
active call, such as Contacts,
Calendar or Vodafone live!
Camera On/Camera Off change whether you want the
Camera to be on or off
External View/Internal View If the Camera is on, select the
view from which the image is
captured.
Hold/Resume If the Camera is off, put audio on
hold to be able to e.g. change
different image as your
Camera Off Image. Select Resume to
return to the Video Call Menu.
V1100.3G.UG.book Page 37 Wednesday, August 9, 2006 4:19 PM
7.6.2 Recording a Video Call
38 Camera
7.6.2 Recording a Video Call
Note: Recording of phone calls is subject to varying country
laws regarding privacy and recording of phone
conversations. Always obey the laws and regulations on the
use of this feature.
You can record a video call as a video clip. During a video call:
Note: Video recording requires video compatibility with the
other caller’s video phone.
Audio Mute/Unmute Audio stop sending video image
temporarily. Select Unmute Audio to
resume sending the video image
Swap View change between the primary and
secondary video area on your
phone display
Brightness/Contrast adjust the brightness/contrast
level of the display. This does not
affect the outgoing video image.
Setup set up camera settings:
Mirror: Camera captures a
“mirror” image (only applicable
in Internal View)
Status Icons: Turn status icons On/
Off in the viewfinder
Lighting Conditions: Setup the
display: Automatic, Sunny, Cloudy,
Indoor, or Night
Press To
Press To
1Options
>Record
start recording the call
Your phone displays Recording. It
records incoming video and incoming
and outgoing audio.
2Options > Stop stop recording and store the video
clip
The recording stops automatically if
the call ends or you reach your video
capture or memory limit.
To view the video clip see page 35.
V1100.3G.UG.book Page 38 Wednesday, August 9, 2006 4:19 PM
Using and Transferring Files 8
Using and Transferring Files 39
8Using a nd Transferring Files
You can store, send, and play music, videos, and other media
files on your phone.
8.1 Playing or Viewing Media Files
To play music:
For more about playing music files, see page “Audio Player”
on page 40.
To play or view other media, follow the instructions above
but replace My Music with the type of media you want.
Tip: You can listen to tunes on your way. Use flight mode to
make your phone safe to use even while you’re on a plane.
See page 93.
8.1.1 Viewing a full screen picture
To view a picture without any icons showing on the screen:
8.2 Sending Media Files
To send music:
Highlight the file you want to send and press Options > Send
>in Message.
To send other media, follow the instructions above but
replace My Music with the type of media you want.
Find the Feature s> My Files > My Music
and select the file you want
to play
Press To
s and hold view as full screen
S left or right scroll through all the pictures as
full screen
s and hold return to normal view
Find the Feature s> My Files > My Music
V1100.3G.UG.book Page 39 Wednesday, August 9, 2006 4:19 PM
8.2.1 Store and Use Protected Content
40 Using and Transferring Files
8.2.1 Store and Use Protected Content
If you try to play a copyrighted file, it might ask you to
download a license. Some licenses only let you play a file for
a certain number of times or days. You cannot send, copy, or
change copyrighted files.
For example, a license may allow you to play the content of
your download five times or use the content for three days
before it expires.
To download a file, see page 51. To activate downloaded
copyrighted files:
You can see a file’s Status, Type, Activation, and Counts remaining.
8.2.2 Create a Playlist
Open a song list, and press the center key s to select each
song you want. After you press the Done key, enter a name for
your list.
To hear your playlist, highlight it under Playlists and press
Options > Play.
8.3 Audio Player
You can’t use the audio player with a USB cable connected to
your phone.
Hide the audio player by pressing Options > Hide. This lets you
use other phone features while the song plays.
Find the Feature s> Organiser & Tools > Licence List
Find the Feature s> My Files > My Music > Playlists
> Create New Playlist
Find the Feature s> Music/My Files > My Music >
All Tracks select the file you
want to play
Press To
s play or pause
S left or right skip back or forward
S up or down change volume
S up continue playing
V1100.3G.UG.book Page 40 Wednesday, August 9, 2006 4:19 PM
Play Music With Your Phone Closed 8.3.1
Using and Transferring Files 41
Press S up or down to highlight an option:
To download songs to your phone, see page 51. To copy
files between your phone and a computer, see page 43.
Note: Your phone cannot play MP3 files that have a bit rate
higher than 128 kbps. If you try to download or play one of
these files, your phone might show you an error or ask you
to delete the file. Metadata information is not supported for
MP4 formatted files.
8.3.1 Play Music With Your Phone Closed
You can close your phone while you listen to music. When
your phone is closed, the external display shows the song
artist, title, and time. To control your music playback:
•Press the volume keys to adjust the volume.
•Press the smart key to open the audio player menu.
Press the volume keys to scroll through the menu, and
press the smart key to select a menu item.
•Press and hold the smart key to lock or unlock the side
keys.
•The controls close after 4 seconds, if you don’t use
them.
Option Description
All Tracks Show and play individual songs.
Note: All of your phone’s songs appear in
this list. Some songs do not have any
Artist, Album, or Genre information, so they
don’t appear in those lists.
Recently Played Shows tracks you played recently.
Playlists Create or play a playlist.
Artists Select an artist to show or play their
songs.
Albums Select an album to show or play its
songs.
Genres Select a type of music to show or play
songs.
Composers Select a composer to show or play
songs.
V1100.3G.UG.book Page 41 Wednesday, August 9, 2006 4:19 PM
8.4 Mobile TV
42 Using and Transferring Files
You can also use touch sensitive audio player keys on the
front of the phone:
8.4 Mobile TV
To watch Mobile TV:
Your phone connects to the Mobile TV server and live pictures
are displayed on your phone.
Some Mobile TV channels require you to subscribe to
the service. Visit www.vodafone.com for additional
information about the subscription services Vodafone
offers.
During Mobile TV viewing, press Options to open the menu. Press
S up or down to highlight an option:
Press To
Next track
Play/pause
Previous track
Find the Feature s> Entertainment > Mobile TV
Option Description
View Fullscreen Video Video content is displayed fullscreen.
Pause Video, Play
Video, Stop Video
Video content is paused, played,
stopped.
Open Open items such as: Home, Web Address,
Bookmark, History, Swap, and Message.
Page You can Forward, Refresh, and Add to
Bookmarks the current page.
Display Select the display options such as:
Scan Page, Zoom In, Zoom Out, Reset Zoom, Fit
to Screen, Fit to Screen Off, Full Screen
(Content Mode), and Full Screen Off (Content
Mode).
Properties You can View URL and Certificates
information.
Setup Opens the setup menu to adjust Mobile
TV settings.
Help Displays Mobile TV help information.
Exit Closes Mobile TV.
V1100.3G.UG.book Page 42 Wednesday, August 9, 2006 4:19 PM
Radio DJ 8.5
Using and Transferring Files 43
8.5 Radio DJ
Radio DJ requires you to subscribe to the service. Visit
www.vodafone.com for additional information about
the subscription services Vodafone offers.
To listen to Radio DJ:
Your phone connects to the Radio DJ server, and you can listen
to music.
During Radio DJ listening, press Options to open the menu. Press
S up or down to highlight an option:
You can close your phone while you listen to Radio DJ for a
list of controls available, see page 41.
8.6 Connecting Your Phone to Another
Device
You can connect your phone to a computer or hand-
held device using a USB cable or a Bluetooth
connection.
Note: Not all devices are compatible with all types of
connections. Check your external device for specifications.
The use of wireless devices and their accessories may be
prohibited or restricted in certain areas. Always obey the
laws and regulations on the use of these products.
To make data calls through a connected computer, see
page 88.
Find the Feature s> Music > Radio DJ
Option Description
My Channels Listen to your defined channel(s).
RDJ Channels Listen to channels predefined by your
operator.
Compilations Select an artist to show or play songs.
My Wishlist Create a list of songs you wish to
purchase.
My Account Display the status of your account.
V1100.3G.UG.book Page 43 Wednesday, August 9, 2006 4:19 PM
8.6.1 Setting Up a Cable Connection
44 Using and Transferring Files
8.6.1 Setting Up a Cable Connection
Attach a Motorola Original™ USB cable to the phone and
external device as follows.
Note: Check your computer or hand-held device to determine
the type of cable you need.
8.6.2 Setting Up a Wireless Connection
Your phone supports BluetoothTM wireless pairing (also
called linking or bonding). You can pair your phone with a
Bluetooth headset or car kit, or pair your phone with a
computer to exchange and synchronise files.
Note: The use of wireless devices and their accessories may
be prohibited or restricted in certain areas. Always obey the
laws and regulations on the use of these products.
Turning Bluetooth Power On or Off
If Bluetooth Power is On, your phone can automatically pair
with the handsfree device you have used before. Just turn on
the device or move it near the phone.
Once you connect your phone to a Bluetooth device, your
phone "recognises" that device in the future. If a recognised
device starts a Bluetooth link with your phone, the Bluetooth
status icon appears at the top of your display.
Note: To extend battery life, use the above procedure and set
Bluetooth Power to Off when not in use. Your phone will not
pair with devices until you set Bluetooth Power back to On and
pair your phone with the devices again.
Action
1Plug the end of the
cable with the
Motorola logo into
the phone’s
accessory
connector port.
Make sure that the
logo and the phone
are both facing you.
2Plug the other end (the USB connection) into the USB
port on the device.
Find the Feature s>Connectivity > Bluetooth
>Setup > Power > On
V1100.3G.UG.book Page 44 Wednesday, August 9, 2006 4:19 PM
Setting Up a Wireless Connection 8.6.2
Using and Transferring Files 45
Pairing With a Headset or Handsfree Device
Before you try to pair your phone with a device, make sure
the device is on and ready in pairing or bonding mode (see
the user’s guide for the device). For maximum Bluetooth
security, you should always pair Bluetooth devices in a safe,
private environment.
Your phone lists the devices it finds within range. Highlight a
device in the list and:
When your phone is paired, the Bluetooth indicator
shows in the home screen.
Shortcut: After you have paired with a device, you can pair
with it again by pressing Options > Use Bluetooth during a phone
call or while playing a sound file.
Note: You can’t play some copyrighted files over a Bluetooth
connection.
Tip: Want to know more about your headset or car kit? For
specific information about a device, refer to the instructions
that came with it.
Copying Objects to Another Device
You can use Bluetooth pairing to copy a media object,
contacts entry, calendar event, or bookmark from
your phone to a computer or other device.
Note: You cannot copy a copyrighted object.
1On your phone, highlight the object you want to copy to
the other device.
2Press Options and select Manage > Copy (for media objects),
Manage > Send (for calendar events), or Share > Contact (for
contact entries).
3Select a recognised device name, or [Look For Devices] to
search for the device where you want to copy the object.
Find the Feature s> Connectivity > Bluetooth
>[Add Audio Devices]
Press To
1Select select the device
2Yes or Ok pair with the device
3keypad keys enter the device passkey (such as
0000) if necessary, and then press the
Ok key
V1100.3G.UG.book Page 45 Wednesday, August 9, 2006 4:19 PM
8.6.2 Setting Up a Wireless Connection
46 Using and Transferring Files
Sending Objects to a Printer
You can use Bluetooth pairing to send a picture,
message, contacts entry or datebook view from your
phone to a printer.
Note: You cannot print message Templates or a contacts Mailing
List.
Tip: After you capture a picture in the camera, you can select
Options and press Print.
1Highlight the object on your phone that you want to print
2Press Options > Print. In the Calendar, you can print the
month, week or day.
3If available, choose additional objects or print options.
4Select a recognised printer name listed in the Printers
menu, or [Look For Devices] to search for the device to which
you want to send the object.
Note: You you see Service Not Supported when you try to print,
select, Options > Manage > Copy > Bluetooth instead. Always use
this option to print 4x6 photos.
Advanced Bluetooth Features
A device is recognised after you pair with it once (see
page 44).
Features
Make
phone
visible to
other
device
Allow another Bluetooth device to
discover your phone:
s > Connectivity > Bluetooth > Find Me
Pair with
recognised
device
Pair your phone with a recognised
handsfree device:
s > Connectivity > Bluetooth > Add Audio Devices >
device name
Drop
pairing
with device
Highlight the device name and press
the Drop key.
Switch to
recognised
device
during call
During a call press
Options > Use Bluetooth to switch to a
recognised headset or car kit.
Your phone connects automatically, or
shows a list of devices you can select.
V1100.3G.UG.book Page 46 Wednesday, August 9, 2006 4:19 PM
Connecting a Memory Card to your computer 8.7
Using and Transferring Files 47
8.7 Connecting a Memory Card to your
computer
For details on installing a memory card see “Memory Card”
on page 15.
You can access your phone’s memory card with a PC.
Note: When your phone is connected to a computer, you can
only access the memory card through the computer.
On your phone:
1Press s > Connectivity > USB > Memory Card. This directs
the USB connection to your memory card.
2Attach the Motorola Original USB cable to the accessory
port on your phone and to an available USB port on your
computer.
On your computer:
1Open your “My Computer” window, where your phone’s
memory card shows as a ‘Removable Disk’ icon.
2Click on the ‘Removable Disk’ icon to access the files on
your phone’s memory card.
Play sound
files on a
recognised
headset
While playing a sound file press
Options > Use Bluetooth to switch to a
recognised headset.
Your phone connects automatically, or
shows a list of devices you can select.
Note: You cannot play some copyrighted
files over a Bluetooth connection.
Move
multimedia
object to
device
Move a multimedia object to another
device.
Highlight the object, press Options > Manage >
Move, select the device name.
Caution: Moving an object deletes the
original object from your phone.
Set
Bluetooth
options
Highlight the device name, press
s > Connectivity > Bluetooth > Setup
Features
V1100.3G.UG.book Page 47 Wednesday, August 9, 2006 4:19 PM
8.8 Phone Updates
48 Using and Transferring Files
3To store the desired files onto the memory card, drag
and drop them as follows:
music files: > mobile > audio
screen savers: > mobile > picture
wallpapers: > mobile > picture
video clips: > mobile > video
4When you finish, remove the device by selecting the
‘Safely Remove Hardware’ icon in the system tray at the
bottom of your computer screen. Then select ‘USB Mass
Storage Devices’ and ‘Stop’.
5Select ‘USB Mass Storage Device’ then ‘OK’.
On your phone:
To return to Data as your USB default connection, press:
s > Connectivity > USB > Data Connection
8.8 Phone Updates
Sometimes we think of ways to make your phone’s
software faster or more efficient after you have
purchased your phone. You can find out if your phone
can be updated and register for free update notifications at:
http://www.hellomoto.com/support/update
Note: Software updates do not affect your contacts entries or
other personal entries. If you receive a software update but
choose to install it later, see page 89.
V1100.3G.UG.book Page 48 Wednesday, August 9, 2006 4:19 PM
Vodafone live! 9
Vodafone live! 49
9Vodaf one live!
9.1 Vodafone live!
Your phone has been customised to give access to Vodafone
live!. Visit www.vodafone.com for additional information
about the services Vodafone live! offers.
To connect to the Vodafone live! service, press the Vodafone
live! key on your handset. If you have any problems
connecting to Vodafone live!, please contact Vodafone.
You have the following options while browsing:
You can also download pictures, videos, ringtones and
games from Vodafone live! and install them on your phone.
The Vodafone live! service allows you to access Web pages
and Web-based applications on your phone. If necessary,
please contact Vodafone to configure your phone.
Your phone will use a High Speed Downlink Packet Access
(HSDPA) 3G broadband connection or a 3G connection when
available. These connections bring improved quality, sound,
pictures and videos, as well as increased speed when
downloading games and ringtones. The HSDPA connection
is indicated by a indicator and the 3G connection by a
indicator.
Note: The availability of HSDPA may depend on the coverage
at your location and/or your service provider.
Alternatively, your phone may use a high-speed General
Packet Radio Service (GPRS) network connection. This type
of connection is identified by a (GPRS) indicator in the
Find the Feature Press to connect
or
s>Vodafone live!
>Vodafone live!
Option Description
Go to the live! Homepage
Enter URL Go to a requested page.
Shortcuts View a list of shortcuts you have created.
Saved Pages View a list of pages you have saved.
History View a list of recently viewed pages.
Browser Settings Change Vodafone live! settings.
Option Description
V1100.3G.UG.book Page 49 Wednesday, August 9, 2006 4:19 PM
9.1.1 Starting Vodafone live!
50 Vodafone live!
home screen that disappears when you start Vodafone live!.
If you see an (in-call) indicator during a Vodafone live!
session, your phone is using a standard voice connection.
The type of network connection your phone uses depends on
your service provider’s network. Your network connection
charges may vary depending on the type of connection used.
Note: Some features on your phone might open Vodafone
live! automatically.
9.1.1 Starting Vodafone live!
Shortcut: If you open a text message with a Web address
(URL) embedded in it, you can press
s>Go To to launch
Vodafone live! and go directly to the URL.
If you are unable to establish a network connection with
Vodafone live!, contact your service provider.
Press To
1
or
Press s > Vodafone live!
>Vodafone live!
start Vodafone live!
2S up or down scroll to a shortcut, service
or application
3Select key select the item
V1100.3G.UG.book Page 50 Wednesday, August 9, 2006 4:19 PM
Interacting With Web Pages 9.1.2
Vodafone live! 51
9.1.2 Interacting With Web Pages
9.1.3 Downloading Objects From a Web Page
You can download pictures, sounds, or other objects from a
Web page by selecting the link. You can store media objects
on your phone, and use them as wallpaper images, screen
saver images and event alerts.
Note:
•The files that you download or receive as attachments
might have a copyright lock that keeps you from
forwarding them.
•If you receive a call during the download, press the
More Apps key to answer the call without ending the
download.
•To end a download in progress, press .
9.1.4 Running Vodafone live! in the
Background
Some phones are set up to run Vodafone live! in the
background when the phone registers with a network. This
lets your phone display information services messages sent
by your service provider (such as stock updates, news
headlines, or sports scores). These types of services
typically are available through subscription from your service
provider.
Press To
S up or down scroll through text, or highlight a
selectable item
Select key select the highlighted item
keypad keys, followed
by the Ok key
enter information
Tip: If you make a mistake, press
K to delete the last letter, or
press and hold K to clear all
letters.
Back key go back to the previous page
Options open the Browser Menu
V1100.3G.UG.book Page 51 Wednesday, August 9, 2006 4:19 PM
9.2 Ticker
52 Vodafone live!
Setting Up Vodafone live! Messages
9.2 Ticker
This feature may not be available in all countries.
Ticker sends news headlines to your phone. If you are
interested in the item, you can click on the headline to view
the full article with the browser.
If there are no new messages then the headlines are hidden.
You can press the Ticker key to make them appear. They
automatically reappear when a new headline is received.
9.2.1 Turning Ticker On and Off
Note: When you turn off Ticker, you may also be asked if you
want to turn off cell broadcast. If you do this, then when you
reactivate Ticker you’ll also need to confirm that you want to
turn cell broadcast back on.
9.2.2 Setting Up Ticker
You can set up Ticker to suit your requirements.
Setting Ticker Speed
Set the speed at which the incoming headlines scroll across
your screen.
Find the Feature s>Messaging
>Browser Messages
Options
> Browser Message Setup >
Service
Option Description
Off Stop all Vodafone live! messages.
Receive All Allow all Vodafone live! messages.
Restricted Allow only Vodafone live! messages
from your service centre number.
Find the Feature s>Settings > Personalise
>Home Screen > Ticker
>Switch On/Off
Find the Feature s>Settings > Personalise
>Home Screen > Ticker >Ticker
Settings
V1100.3G.UG.book Page 52 Wednesday, August 9, 2006 4:19 PM
Setting Up Ticker 9.2.2
Vodafone live! 53
Selecting Channels
Choose the channels that send you headlines.
Selecting Number of Messages
Select how many messages are displayed on the home
screen.
Find the Feature s>Settings > Personalise
>Home Screen > Ticker
>Channel Subscription
Find the Feature s>Settings > Personalise
>Home Screen > Ticker
>Number of Messages
V1100.3G.UG.book Page 53 Wednesday, August 9, 2006 4:19 PM

Navigation menu
