Motorola Solutions 89FT7040 PORTABLE MULTIBAND 2-WAY RADIO User Manual Stuffer for
Motorola Solutions, Inc. PORTABLE MULTIBAND 2-WAY RADIO Stuffer for
Contents
- 1. Users Manual
- 2. RF Safety Booklet
- 3. Stuffer for User Manual
Stuffer for User Manual
English
*PMR151*
© 2009 by Motorola, Inc. All Rights Reserved. 7/09
1301 E. Algonquin Rd., Schaumburg,
IL 60196-1078, U.S.A. PMR151
m
Manual revision
6875945M01-A
ASTRO® APX™ 7000
User Guide
This revision outlines changes that have occurred since the printing of your manual. Use this information to supplement your manual.
REVISION CHANGE:
Please use the following information to supplement your existing User Guide. The table that follows lists the pages attached to this
PMR and their related pages.
Page Section Section Title Description
105 Accessories Antennas Added four new antenna models to the list, namely
PMAS4000_, PMAE4065_, PMAT4000_ and PMAT4001_.
Added footnotes.
105 Accessories Batteries and Battery Accessories Added two accessories, namely NNTN7034_ and
NNTN7033_.
105 –
106
Accessories Carry Accessories Changed “Belt Clip Kit, 2.5", Plastic (Compatible with
Clamshell Batteries) (NTN8266_)” to “2.5" Belt Clip
(NTN8266_)”.
107 Accessories Audio Accessories Added a phrase “700/800 MHz band radio only,” to
accessories PMMN4059_, PMMN4060_ and PMMN4061_.
Added four new accessories to the list, namely RLN6424_,
PMLN5101_, PMMN4065_ and HMN4104_.
Stuffer_1.fm Page 1 Wednesday, July 8, 2009 11:16 AM
English
Accessories
Antennas
•800 MHz, GPS Antenna (NAF5085_)2,3
•700/800 MHz, VHF GPS Antenna (NAR6591_)2,3
•GPS Antenna (NAG4000_)
•UHF (380 – 520 MHz), 700/800 MHz, GPS (PMAS4000_)1,3
•UHF (380 – 520 MHz), GPS (PMAE4065_)1
•VHF Low (136 – 168 MHz), UHF (380 – 470 MHz), GPS
(PMAT4000_)1,2
•VHF High (155 – 174 MHz), UHF (380 – 470 MHz), GPS
(PMAT4001_)1,2
1 This antenna is not campatible with VHF/700/800 dual band radio.
2 This antenna is not compatible with UHF/700/800 dual band radio.
3 This antenna is not compatible with VHF/UHF dual band radio.
Batteries and Battery Accessories
•2000 mAh, IMPRESTM NiMH (FM), IP57 Rugged
(NNTN7035_)
•2000 mAh, IMPRES™ NiMH (FM), IP57 (NNTN7036_)
•2100 mAh, IMPRES™ NiMH (Standard), IP57 (NNTN7037_)
•2500 mAh, IMPRES™ Li-Ion, IP57 (NNTN7038_)
•2100 mAh, IMPRES™ NiMH (Standard), IP57 Rugged
(NNTN7573_)
•4000 mAh, IMPRES™ Li-Ion (Standard) (NNTN7034_)
•3900 mAh, IMPRES™ Li-Ion (FM) (NNTN7033_)
Carry Accessories
Belt Clips
•3" Belt Clip, Plastic (HLN6875_)
•2.5" Belt Clip (NTN8266_)
Belt Loops
•2.5" Swivel Belt Loop (PMLN5407_)
•2.75" Replacement Swivel Belt Loop (PMLN5408_)
•3" Swivel Belt Loop (PMLN5409_)
Carry Cases
•Nylon Carry Case with 3” Fixed Belt Loop and T-Strap, for
Short Radio (PMLN5322_)
105
Stuffer_1.fm Page 2 Wednesday, July 8, 2009 11:16 AM
English
•Hard Leather Carry Case with 3” Fixed Belt Loop, D-Rings,
and T-Strap, for Short Radio (PMLN5323_)
•Hard Leather Carry Case (High Activity) with 2.75” Swivel
Belt Loop, D-Rings, and T-Strap, for Short Radio
(PMLN5324_)
•Nylon Carry Case with 3” Fixed Belt Loop and T-Strap, for
Long Radio (PMLN5328_)
•Hard Leather Carry Case with 3” Fixed Belt Loop, D-Rings,
and T-Strap, for Long Radio (PMLN5329_)
•Hard Leather Carry Case (High Activity) with 2.75” Swivel
Belt Loop, D-Rings, and T-Strap, for Long Radio
(PMLN5330_)
•Carry Strap (NTN5243_)
•Carry Holder, Basic (PMLN5331_)
Chargers
•IMPRES™ Single-Unit (US Plug) (NNTN7080_)
•IMPRES™ Single-Unit (Euro Plug) (NNTN7081_)
•IMPRES™ Single-Unit (UK Plug) (NNTN7082_)
•IMPRES™ Single-Unit (Aust, NZ Plug) (NNTN7083_)
•IMPRES™ Single-Unit (Argentina Plug) (NNTN7084_)
•IMPRES™ Single-Unit (US Plug, Euro User Guide)
(NNTN7085_)
•IMPRES™ Single-Unit (Korean Plug) (NNTN7261_)
•IMPRES™ Multi-Unit, Display (Aust, NZ Plug) (NNTN7063_)
•IMPRES™ Multi-Unit, Display (US Plug) (NNTN7073_)
•IMPRES™ Multi-Unit, Display (UK Plug) (NNTN7074_)
•IMPRES™ Multi-Unit, Display (Argentina Plug) (NNTN7075_)
•IMPRES™ Multi-Unit, Display (US Plug, Euro User Guide)
(NNTN7076_)
•IMPRES™ Multi-Unit, Display (Korean Plug) (NNTN7077_)
•IMPRES™ Multi-Unit, Display (Euro Plug) (NNTN7086_)
•IMPRES™ Multi-Unit, Non-Display (US Plug) (NNTN7065_)
•IMPRES™ Multi-Unit, Non-Display (Euro Plug) (NNTN7066_)
•IMPRES™ Multi-Unit, Non-Display (UK Plug) (NNTN7067_)
•IMPRES™ Multi-Unit, Non-Display (Aust, NZ Plug)
(NNTN7068_)
•IMPRES™ Multi-Unit, Non-Display (Argentina Plug)
(NNTN7069_)
•IMPRES™ Multi-Unit, Non-Display (US Plug, Euro User
Guide) (NNTN7070_)
•IMPRES™ Multi-Unit, Non-Display (Korean Plug)
(NNTN7071_)
106
Stuffer_1.fm Page 3 Wednesday, July 8, 2009 11:16 AM
English
Audio Accessories
•Small Remote Speaker Microphone, IP54, 3.5 mm Jack,
Receive Only (PMMN4024_)
•Small Remote Speaker Microphone, IP54, 3.5 mm Jack
(PMMN4025_)
•Noise Canceling Remote Speaker Microphone, IP54, 3.5 mm
Jack (PMMN4062_)
•Public Safety Microphone, 700/800 MHz band radio only, 18
inch, IP55, 3.5 mm Jack (PMMN4059_)
•Public Safety Microphone, 700/800 MHz band radio only, 24
inch, IP55, 3.5 mm Jack (PMMN4060_)
•Public Safety Microphone, 700/800 MHz band radio only, 30
inch, IP55, 3.5 mm Jack (PMMN4061_)
•Heavy-Duty Headset (PMLN5275_)
•Lightweight Headset (RMN5058_)
•Earbud for Remote Speaker Microphone, 3.5 mm Jack,
Short Coiled Cable, Receive Only (RLN4885_)
•Earpiece with Translucent Tube for Remote Speaker
Microphone, 3.5 mm Jack, Short Coiled Cable, Receive Only
(RLN4941_)
•Ear Receiver for Remote Speaker Microphone, 3.5 mm Jack,
Short Coiled Cable, Receive Only (WADN4190_)
•1-Wire, Receive Only Earpiece, Black (RLN5878_)
•1-Wire, Receive Only Earpiece, Beige (RLN5879_)
•2-Wire, One Programmable Button, Black (RLN5880_)
•2-Wire, One Programmable Button, Beige (RLN5881_)
•2-Wire with Translucent Tube, One Programmable Button,
Black (RLN5882_)
•2-Wire with Translucent Tube, One Programmable Button,
Beige (RLN5883_)
•3-Wire with Translucent Tube, One Programmable Button,
Black (PMLN5111_)
•3-Wire with Translucent Tube, One Programmable Button,
Beige (PMLN5112_)
•Low Noise Kit (RLN5886_)
•High Noise Kit (RLN5887_)
•IMPRES™ Templer Transducer (PMLN5101_)
•Secondary Audio Accessory for Display Remote Speaker
Microphone (RLN6424_)
•Standard Large IP57 Remote Speaker Microphone
(PMMN4065_)
•IMPRES™ Display GCAI™ Submersible Remote Speaker
Microphone with Jack and Channel Selector (HMN4104_)
107
Stuffer_1.fm Page 4 Wednesday, July 8, 2009 11:16 AM
English
Notes
108
