User 02
PHYSICAL SPECIFICATIONS
Article number: 9927786
Dimensions (cm): Standard furniture: ca. 100 x 83 x 130 (l x w x h)
Height desk: ca. 75
Height ring (optional): 10 or 20
Material: Metal, MDF, vulkanit
Standard color: Wood Red U-225
Metal Ral 7016
Optional color: Any color at extra costs
Weight: ca. 70 kg
Function: Check-in, -out, combi
Check in of CDs/DVDs: Yes
ELECTRICAL SPECIFICATIONS
Supply voltage: 110 - 230 V, 50 - 60 Hz
Working voltage: Reader: 24 V - 12 V - 9 V
Power consumption: Max. 100 Watt
Leng th power cable: 1.8 m
HARDWARE SPECIFICATIONS
User interface: Touchscreen 15 inch
PC: Type: Industrial PC or Touch PC
Operating system: XP Embedded SP3
Connec tions: USB, Lan, VGA, Serial, Audio
Communication cable: Standard UTP
Printer: Ther mal, paper 80 mm
Compatibility: Software: Bibliocheck4 Selfservice
Reader: Nedap Prox. Reader, art. nr. 9934634
Antenna power (electrical): Max. 1 Watt
RF antenna power: 1.4 µW
Technology: RFID
Frequency: 13.56 MHz
Identifies: ISO 15693 / ISO 18000-3.1
EAS function: Yes, EAS-bits and/or AFI
Patron identification: Barcode card reader
ENVIRONMENTAL SPECIFICATIONS
Operational temperature: +10 / +45 °C
S t o r a g e t e m p e r a t u r e : 0 / + 5 5 ° C
WARRANTY / CERTIFICATES
Certificate: CE / EMC / FCC
Warranty: 1 year
Approvals of the power adaptor: - c UL us according to UL/CSA 60950-1
- Japan PSE
- CE according to EN60950-1
- FCC compliant
Version 1.0
Specifications are subject to change without notice
flexdesk
beyond the book
flexdesk
a new self-service experience
the flexdesk provides your library with a new self-service experience.
it contains a barcode, mifare or rfid reader to identify the user, an rfid-
reader for the check-in/out process and a touch screen for user interaction.
additionally, the flexdesk contains a printer for the receipts.
check-in and check-out
The Flexdesk can function as a check-in, check-out or combi station. This way you
can facilitate the whole lend and return process with just one desk. The Flexdesk
is equipped with a table-top reader. The reader is produced in such a way that only
items that are on top of the antenna are processed.
user-friendly
Because of the use of touch screens and user-friendly software, the Flexdesk can
easily be used by all ages. It enables the user to lend out and return books by
completing a few simple steps.
meeting your demands
The Flexdesk can be delivered in several colours and shapes, to meet your specific
demands.
benefits
- Check-in / Check-out or combined
- Simple user interface
- Several color and appearance options
- Robust; use of industrial electronics
- Remote service and support
contact
Nedap Librix
Parallelweg 2d
7141 DC Groenlo
The Neterlands
T +31 (0) 544 47 11 11
F +31 (0) 544 46 58 14
E info@nedaplibrix.com
www.nedaplibrix.com
541
750 / 850 / 950
699
Flexdesk front: Flexdesk side:
4 types of desks:
NOTE: Do not use these drawings for installation purposes. Ask your local supplier for technical drawings.
675
675
675
675
1000 1000
1000
1000
fcc and ic certifications
This device contains PROX READER with FCC-ID: CGDPROX1356 and IC: 1444A- PROX1356
Part 15.19(3) and RSS_Gen Labelling
This device complies with part 15 of the FCC Rules and to RSS-210 of Industry Canada.
Operating is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil se conforme aux normes RSS 210 exemptés de license du Industry Canada.
L’opération est soumis aux deux conditions suivantes :
(1) cet appareil ne doit causer aucune interférence, et
(2) cet appareil doit accepter n’importe quelle interférence, y inclus interférence qui peut
causer une opération non pas voulu de cet appareil.
Warning (part15.21)
Changes or modifications not expressly approved by party responsible for compliance
could void the user’s authority to operate the equipment.
