Nedap N V STOREIDG ANTI Pilferage device and UHF RFID reader User Manual 14r03 9964142 QR T ID Gate Version C 01 CGDSTOREIDG

N. V. Nederlandsche Apparatenfabriek NEDAP ANTI Pilferage device and UHF RFID reader 14r03 9964142 QR T ID Gate Version C 01 CGDSTOREIDG

14r03_9964142-QR-T-ID Gate-Version C.01 CGDSTOREIDG

Copyright © by N.V. Nederlandsche Apparatenfabriek NEDAP. No part of this drawing may be repro-
duced or distributed in any form or by any means, or stored in a data base or retrieval system without the
prior written permission of NEDAP.
doc. article no: 5278988
chk:
rev. : C.01
drw: CB 2013/06/13
sheet: 45.01 of 1
drawing: T5278-988
!D Gate
dimensions
GROENLO - HOLLAND
462
10 (oorpart)
1668
195,5 828,75
1024,25
300
150(2x)
60(2x)
13(6x)
70
100
57
sales oor stock room
orientation in the shop
all antennas
in the same
direction.
distance between antennas
1x !D Gate 1x Coax cable 3m/10ft
description:
quick reference !D Gate
AB
Power inserter
recommended - 2.0m / 6.5ft
absolute max. - 2.2m / 7ft
AB
AB
AB
AB
AB
AB
462mm / 18.2”
1668mm / 5.7ft
828.75mm / 2.7ft 195.5mm / 7.7”
1024.25mm / 3.4ft
100mm / 3.9”
57mm / 2.2”
70mm / 2.8”
Reinforced Concrete
Iron
Reinforced Concrete
Nylon Insulation ring
(included in installation set)
Retainer ring (not included in installationset)
Iron
Always mount an antenna insulated to the floor or wall
Nut (not included in installationset)
Nylon M10
(included in
installation set)
4x
M10
2
4
1
Metal M10
3
0403
Hilti-hit not included
Cleaning Hilti-hit Place nut
05
300
150
60
13
(6x)
90mm / 3.5”
ø 13mm / ø 0.5”
02
remove covers
01 drilling holes
Nut (not included in installationset)
Retainer ring (not included in installationset)
Nylon Insulation ring (included in installationset)
Always mount an antenna insulated to the oor or wall
300mm / 11.8”
150mm / 5.9” 13mm / 0.5”
60mm / 2.4”
processing unit
network IN
network OUT
USB service port
USB host
Power for Reader
Recommended to place in switch-room
power supply Out
In
Power supply 9561811. One needed for
every installed system. (not included)
1 Yellow Heartbeat
2 Green Disk access
3 Green Firmware running
1 2 3
+
-buzzer
Not compatible with IEEE 802.3a* standard
C
D
E
F
10
7
2
1
F
E
8
11
12
9
3
4
5
6
G
H
G
H
C
D
E
F
10
7
2
1
F
E
8
11
12
9
3
4
5
6
G
H
G
H
Led Blue Orange Red Green Green
-Firmware running Error RFID active Power
next
previous
!D Reader
1 Green Processing unit at output
2 Blue Blink No device at output or Lan- modem (in case of OST integration)
Blue Continuous Power inserter at output
3 Red Power error
coax cable 3m / 10ft 2x coax cable 3m / 10ft
no coax cable needed
recommended label free zone
1m / 3ft
required label free zone
1m / 3ft
1m / 3ft
1m / 3ft
2m / 6ft 2m / 6ft
0.5m / 1.5ft
0.5m / 1.5ft
place covers
230V
110V
connect voltage supply
Note :
The start up of all the
processes takes
approximately 3 minutes.
02
use rmware conguration quick reference.
next
coax-cable 3m/10ft
2 1
01
Minimum bending
radius = >60mm/2.4”
previous
coax cable
coax cable
RJ45 connector to ethernet
outlet - customer network.
processing unit
network IN
2
OUT
IN
note:
use only cat5e ethernet cable or better,
with all 8 wires connected.(straight cable)
1
processing unit
network IN
03
processing unit
network OUT RJ45 connector to ethernet
outlet - customer network.
2note:
use only cat5e ethernet cable or better,
with all 8 wires connected.(straight cable)
1
Model: !D Gate Region 2
FCC ID: CGDSTOREIDG IC: 1444A-STOREIDG
This device complies with part 15 of the FCC Rules and to RSS210 of Industry Canada.Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Cet appareil se conforme aux normes RSS 210 exemptés de license du Industry Canada.
L’opération est soumis aux deux conditions suivantes:
(1) cet appareil ne doit causer aucune interférence, et
(2) cet appareil doit accepter n’importe quelle interférence, y inclus interférence qui peut causer
une opération non pas voulu de cet appareil.
Les changements ou modications n’ayant pas été expressément approuvés par la partie
responsable de la conformité peuvent faire perdre à l’utilisateur l’autorisation de faire fonctionner le
matériel.
FCC and IC Radiation Exposure Statement:
This equipment complies with FCC and Canadian radiation exposure limits set forth for an uncon-
trolled environment. This equipment should be installed and operated with a minimum distance of
3.65 cm between the radiator and your body. This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Cet équipement est conforme a RSS-102 limites énoncées pour un environne-
ment non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale
de 3.65 cm entre le radiateur et votre corps.
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numérique de Classe B est conforme à la norme Canadienne ICES-003
