Users Manual
128-9297
1 of 4
1
PATENTED: www.voxxintl.com/company/patents
FEATURES :
2 Programmable RF Transmitter
Single Channel Receiver (capable of accepting 4 transmitters)
External Receiver Antenna w/PushButton Switch & LED
On-Board Start Relay
On-Board Accessory Relay
On-Board Ignition 1 Relay
On-Board Ignition 2 Relay
Ignition 2 Relay Selectable On or Off During Cranking
On-Board Parking Light Relay
Ignition 3 / Shock By-Pass / GM VAT Output (relay required)
Tach Signal Learning Circuit
Two ( + ) and Two ( - ) Safety Shutdown Circuits
Alarm By-Pass Output
Accessory Outputs
(Pulse Before & After Start, During Crank & After Shut Down)
Selectable Steady or Flashing Parking Lights for Run Indication
Selectable 5, 10, 15, 20, 45, and 60 Minute Run Time
Car Finder Mode
Optional Door Unlock Feature For Vehicles Equipped With Power Doors
(Only operational while running under control of the remote start unit.)
Single Channel Remote Car Starter
Model PRO9056E
Owner’s Manual
128-9297
2 of 4
2
REMOTE STARTING THE VEHICLE
This will not start the vehicle if any one of the following situations exists:
The vehicle's hood lid is opened.
The gear shift selector is not in Park.
The brake pedal is depressed.
The safety control switch is in the Off position.
1) To start the vehicle, press and release the transmitter button two
times within 2 seconds. The vehicle will start and remain running for the
pre-programmed run cycle. As a visual indication, the parking lights will
ash or remain on depending on the setting by your installation center.
2) When you arrive at the vehicle, turn the ignition key to the ON
position (not the spring loaded start position), then step on the brake
pedal to disengage the remote starter. The vehicle will continue to run,
but now on its own power.
NOTE: The engine will stop running before the pre-programmed
run cycle has expired if you perform any one of the following
functions:
-Press and the button on the keychain transmitter two times within 2 seconds
-Depress the brake pedal
-Open the vehicle's hood
-Place the unit in the safety control disabled mode.
PUSH-BUTTON LED RECEIVER
VALET/OVERRIDE/SAFETY CONTROL SWITCH
The Push-Button LED switch located in the receiver allows you to temporarily dis-
able the remote starting function of the system. This recommended whenever the
vehicle is being serviced. To place the system in the service mode:
1) With the system disarmed/unlocked, and the ignition switch off, Press and
Hold the Push-Button, found on the windsheild receiver, in.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED begins to ash two short ashes followed by one long ashes and
continues this pattern until returned to normal mode of operation.
This puts the unit into the R/S Override mode indicating that the remote start is in
the service mode and will not start from RF or any other input Posse or other-
wise.
To Exit R/S Override Mode
1) With the system disarmed, Press and Hold the Push-Button, found on the
windsheild receiver, in.
2) Turn the ignition switch on, off, on, off, on, off.
3) The LED turns off indicating that the R/S unit is fully functional once again.
128-9297
3 of 4
3
UNLOCKING THE VEHICLE:
If you have electric door lock, and the Optional Unlock feature was added, with
the vehicle running under command of the remote start unit, press and hold the
transmitter button for 3 seconds until the doors unlock.
CAR FINDER MODE:
Anytime the vehicle is not running under control of the remote start unit, within
operating range of the vehicle, press and hold the push-button of the hand held
transmitter for 4 seconds to activate the car nder mode. The vehicle lights will
ash for 30 seconds or until the push-button is again pressed and released.
TELEMATIC UPGRADE:
This system has the ability to have a telematic upgrade module connected to it.
This is an upgrade that can give you control of certain functions of your vehicle
from a Telephone, or in some cases a computer interface. Please check with
your installation center for most recent Telematic Upgrades. If you had a Telem-
atic Upgrade installed, the manual supplied with the upgrade unit will provide an
operator's manual advising of the features of the system and means available to
control these features of your vehicle.
PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1)
Transmitter Model Name, 141BPR Is Also Found On Back Of
Transmitter Case. Use Battery CR2032
1) Turn the ignition key to the on position.
2) Press and release the valet/programming switch 3 times (Siren Chirps).
3) Press the Button of each transmitter you want programmed until you hear a
chirp from the horn or siren.
4) Turn the ignition switch off.
The above action programs the Start button for the one button start systems.
Note: Some systems will not have a audible sound associated with program-
ming,,,for these systems the lights will ash.
128-9297
4 of 4
4
To purchase replacement transmitters
or to get additional product information go to:
www.pursuitcarsecurity.com
© 2014 Voxx Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-9297
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry
Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
NOTE: The manufacturer is not responsible for any radio or TV interference caused
by unauthorized modications to this equipment. Such modications could
void the user’s authority to operate the equipment
Transmitter Battery Replacement
1) Locate and remove the "00" point philips head screw on the back of the transmitter case.
2) Carefully separate the front case from the rear.
3) Slide the CR2032 battery out from under the battery clip and dispose of properly.
4) Install the new battery with the (+) side facing up away from the circuit board.
5) Close the case and reassemble in reverse of disassembly
FUNCTION SETTING CHART
To be completed by installer
Run Time 5 Min 10 Min 15 Min 20 Min 45 Min 60 Min
While Running Unlock Yes No
Lights Pulse Steady
