USER MANUAL
MYOENO SCAN
Instructions:
1. Press the button on the top of the
product. A light will flash in the slot at the
bottom of the product.
2. Using your smartphone, launch the
MYOENO application.
3. After creating your user account,
click the “TEST A WINE” icon.
4. A Bluetooth activation request will
appear. Accept it. A green checkmark will
appear in the “BLUETOOTH® ACTIVE” icon.
5. The first time you connect your
smartphone to MyOeno Scan, click on the
icon at the top right of the screen. A list of
nearby Bluetooth® devices will appear. If it
does not appear, click “SEARCH”.
6. Select your MyOeno Scan, shown as
MYOENO-XXXXX. When the connection is
established, a checkmark will appear in the
“CONNECTED DEVICE” icon.
7. When the device is connected, it will
calibrate automatically (succession of
green, red, and blue colors), then the light
will remain green.
Please note, if the MyOeno Scan slot turns
yellow and starts to recalibrate, you are in
an environment with too much and/or
changing light. To avoid this, set down your
MyOeno Scan and position it so that it is
not exposed to direct and/or unstable light.
8. When the scan light is solid green,
dip the device’s slot completely into the
wine. The measurement is performed
automatically.
Please note, if the immersion lasts more
than five (5) seconds, the measurement
conditions are not optimal (the
environment has too much and/or
changing light). Be careful not to move
your MyOeno Scan around in your glass
and do not expose it to direct and/or
unstable light.
9. When the MyOeno Scan slot is fully
immerged for a few seconds, the triangle
that characterizes the wine will appear on
your smartphone, and you can remove
MyOeno Scan from the wine. Please note,
you must have an internet connection and
you need to have completed all the wine
identification fields in order to “CONFIRM”
your tasting form. If you do not have the
information required to fill in all of the
fields (Domain, Vintage, Country, Region
Designation), enter “--“.
10. Press the button to turn off the
product, or return to step 3 to test another
wine.
Recharging:
If the MyOeno Scan starts flashing red, it
needs to be recharged using the USB cable
provided. As it recharges, MyOeno Scan
flashes green. When the charge is
complete, the light is solid green.
In the “TEST A WINE” function, when the
connection is established, the MyOeno
Scan battery level is indicated at the
bottom right of the screen.
Maintenance/Cleaning:
We recommend that you clean your
MyOeno Scan after every use by immersing
it in a glass of water. Do not clean your
MyOeno Scan with abrasive material or
solvents.
Before turning on the MyOeno Scan, make
sure that the slot (measuring area) is clean
and dry using the microfiber cloth
provided. This ensures proper
calibration, and reliable and reproducible
measurements.
The information provided by MyOeno
Scan:
STRENGTH: Mix between the alcoholic
strength and the body of the wine /
TANNINS: Sensation of astringency / ACIDITY:
Sensation of acidity. These parameters are
shown on a 100-point scale.
CELLARING POTENTIAL: Estimation of the
bottle’s aging potential.
EVOLUTION: Information about the youth of
the wine. Shown on a 100-point scale. The
higher the value, the more the wine has
evolved (aged).
To contact us:
contact@myoeno.com
Safety instructions:
- The upper part of the MyOeno Scan device
(the micro-USB connector and power button)
should not be exposed to dripping or splashing
water. / - If the product’s power cord gets
damaged, have it repaired by the manufacturer,
the after-sales service, or any other party with a
similar qualification in order to avoid any
danger. / - In the event that the product
malfunctions, it must be replaced because it is
not repairable. / - The device is not intended for
use by people (including children) with reduced
sensory or mental abilities, or by people
without experience or knowledge, unless an
intermediary responsible for their safety
provides supervision or instructions concerning
the use of the device. / - Children should not
play with MyOeno Scan and should be under
adult supervision. / - The device is intended for
use in temperate climates only. / - The ambient
temperature for use is between 0° C and 35° C.
/ - The device mustn’t be exposed to excessive
heat such as sun, fire, or the like. / - The battery
must not be replaced by the user. Do not
connect the device to a USB 3.0 port to
recharge the battery. / - The external circuits
used to charge the product must have a SELV
system (Safety Extra Low Voltage) and be
limited power sources according to chapters 2.2
and 2.5 of the IEC standards 60950-1:2005 (2nd
Edition) + Am 1: 2009 + Am 2: 2013 and EN
60950-1: 2006 + Am 11: 2009 + Am 1: 2010 +
Am 12: 2011 + Am 2: 2013. / - The European
Directive 2019/13/EU on Waste Electrical and
Electronic Equipment (WEEE) states that used
appliances should not be discarded along with
the normal flow of municipal waste. Used
appliances must be collected separately in order
to optimize the recovery rate and recycling of
the materials that compose them, and to
reduce the impact on human health and the
environment.
The crossed-out trash can symbol is affixed to
all products to remind people of the separate
collection requirements.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation. / Caution: the user that changes or
modifications not expressly approved by the
party responsible for compliance could void the
user's authority to operate the equipment. /
"NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instruction, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct interference by
one or more of the following measures: -
Reorient or relocate the receiving antenna. -
Increase the separation between the equipment
and receiver. -Connect the equipment into an
outlet on circuit different from that to which
the receiver is connected. -Consult the dealer or
an experienced radio/TV technician for help.
This device complies with FCC radiation
exposure limits set forth for general population.
This device must not be co-located or operating
in conjunction with any other antenna or
transmitter.
Symbol
Meaning
The CE marking indicates
compliance with European
directives.
Selective sorting of waste for
recycling electrical and
electronic equipment within
the European Union. In
accordance with the WEEE
Directive 2002/96/EC: this
material should not be
treated as household waste.
