OMNIKEY CM5125 Inductive TAG-Reader User Manual
OMNIKEY GmbH Inductive TAG-Reader Users Manual
OMNIKEY >
Users Manual
Prox Smart Card Reader Technology
CardMan®5125 User's Manual
Copyright © OMNIKEY 2005 (May 2005)
Reproduction, adaptation or translation without prior written permission is prohibited,
except as allowed under the copyright laws.
The information contained in this document is subject to change without notice
CardMan 5125
User's Manual
English
If you have any technical problems or other questions please contact
our help desk: support@omnikey.com
For latest drivers, visit our homepage: http://www.omnikey.com
User's Manual - English
2Prox Smart Card Reader CardMan 5125
Introduction
This manual describes the physical behaviour, short data sheet and
conformities of OMNIKEY's CardMan 5125, a combined contact
and contactless smart card reader.
To install your CardMan 5125 please follow the steps as described
in the “CardMan 5125 Installation Guide”.
If you are developing applications using CardMan 5125, please refer
to the “CardMan 5125 Developer’s Guide”.
For other detailed informations please contact the OMNIKEY
support: support@omnikey.com
Box content
•Smart Card Reader with fixed USB cable.
•This manual
The required drivers for operating your reader can be found in the
internet at http://www.omnikey.com
Overview
The CardMan 5125 is a dual interface PC-linked reader that reads
125Khz Prox (RFID) contactless smart cards and virtually any
contact smart card. The dual interface feature economically
supports end-user environments where both contactless and
contact smart card technology may be in use.
The CardMan 5125 is a USB plug and play device. The USB cable is
fixed to the reader. To connect the reader with your PC, plug the
USB connector to an unused USB port of your computer.
When the reader is working the LED on the right is lighting up
green. If the reader is not working consult the “CardMan 5125
Installation Manual” for driver setup.
For using a contact card, put the card with the contacts facing up, in
the reader. For contactless operation, hold the card next to the logo
on top of the reader.
When the reader is exchanging data with the card (reading or
writing) the LED on the right is blinking red.
User's Manual - English
RFID Smart Card Reader CardMan 5125 3
Short Data Sheet
Dimensions 80 mm x 67 mm x 28 mm
(3.15" x 2,64" x 1,1")
Weight (including standard base
and adapter)
190 gr
(6.7 oz.)
Operating temperature 10-55°C (50-131°F)
Operating humidity 10-90% rH
Composition ABS
PC Connector cable 180 cm (6ft)
Contact Interface Durability 100,000 Insertions
Meantime between failure (MTBF) 500,000 Hours
Host Interface USB 2.0 CCID
(also supports 1.1)
Host Data Transmission speed 12 Mbps (USB 2.0 Full Speed)
Power supply Bus powered
Conformance Information
CE Marking
The shipped version of this device complies with the
requirements of the directives 89/336/EWG,
73/23/EWG and 1999/5/EG.
FCC:
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution:
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
