Ohsung Electronics URCZR2 ZR-2 Repeater User Manual
Ohsung Electronics Co., Ltd. ZR-2 Repeater
User Manual
http://www.emc2000.co.kr
FCC TEST REPORT
Report No.: EMC-FCC-R0066
EMC compliance Ltd. Page: 1 of 1
480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea
82 31 336 9919 (Main) 82 31 336 4767 (Fax)
This test report shall not be reproduced except in full, Without the written approval.
Appendix 6.
User manual
ZR-2 Repeater Owner’s Manual ©2012 Universal Remote Control, Inc.
The information in this manual is copyright protected. No part of this
manual may be copied or reproduced in any form without prior written
consent from Universal Remote Control, Inc.
UNIVERSAL REMOTE CONTROL, INC. SHALL NOT BE LIABLE FOR
OPERATIONAL, TECHNICAL OR EDITORIAL ERRORS/OMISSIONS
MADE IN THIS MANUAL.
The information in this manual may be subject to change without prior
notice.
URC - Control the Experience is a registered trademark of Universal
RemoteControl, Inc.
All other brand or product names are trademarks or registered trademarks
of their respective companies or organizations.
ZR-2 REPEATER
Page 1
Introduction
Thank you for purchasing the ZR-2 Repeater. The ZR-2 is used to extend
the operational range between Total Control products that work on URC’s
2.4 GHz RF network, such as the TRC-780 and to the MRX Advanced
System Controller. Once joined to an MRX, it wirelessly repeats
communication between a Total Control remote and an MRX Advanced
System Controller.
Features and Benefits
Wirelessly extend the range between TC 2.4 GHz products
Additional ZR-2 Repeaters can be joined to extend the RF signal to every
corner of the home, or small office.
Compact size allows for easy installation
Seamless integration with the Total Control System
Parts Guide
The ZR-2 Repeater includes:
1 - ZR-2 Repeater
1 - Owner’s Manual
ZR-2 Front and Rear Panel Descriptions
The front and rear panel consists of:
Power LED: When illuminated this light indicates the ZR-2 is powered.
Status LED: The LED shows the RF signal strength between the ZR-2 and
the MRX Advanced System Controller. Pressing the Test buttonon the rear
of the unit refreshes the signal strength.
When the LED is:
OFF: There is no signal to communicate between Total Control
products. Press the Test button to reconnect to the MRX Advanced
System Controller.
Orange: Poor signal strength. URC recommends relocatingthe unit for
strong signal reception.
Green: Receiving optimal signal strength.
Data LED: The Data LED flashes as the ZR-2 Repeater transmitsdata.
Test: Press to obtain the current signal strength status between the ZR-2 and
the MRX Advanced System Controller.
USB: INSTALLER ONLY!! Used for updating the unit’s firmware.
ZR-2 REPEATER
Page 2
POWER LED
STATUS LED
USB
TEST
DATA LED
Specifications
RF Frequency: 2405 ~ 2480 MHz(Two-way RF)
Effective Range: Typically 50-75 ft, depending on environment
Size: L x D x H = 2.559" x 0.984" x 1.968"
Weight: 2 oz.
Power Supply: 100 ~ 240V~, 50/60Hz, 0.3A
USA Limited Warranty Statement
Your Universal Remote Control, when delivered to you in new condition,
is warranted against defects in materials or workmanship as follows:
UNIVERSAL REMOTE CONTROL, INC. warrants this product against
defects in material or workmanship for a period of one (1) year and as set
forth below. Universal Remote Control will, at its sole option, repair
theproduct using new or comparable rebuilt parts, or exchange the product
for a comparable new or rebuilt product. In the event of a defect, these are
your exclusive remedies.
This Limited Warranty covers only the hardware components packaged
with the Product. It does not cover technical assistance for hardware or
software usage and it does not cover any software products whether or not
contained in the Product; any such software is provided "AS IS" unless
expressly provided for in any enclosed software Limited Warranty.
ZR-2 REPEATER
Page 3
500 Mamaroneck Avenue, Harrison, NY 10528
Phone: (914)835-4484 FAX: (914) 835-4532
www.universalremote.com
OCE-0133A Rev 01
275
55
70
To obtain warranty service, you must deliver the product, freight prepaid,
in its original packaging or packaging affording adequate protection to
Universal Remote Control at the address provided in the Owner's Manual.
It is your responsibility to backup any macro programming, artwork,
software or other materials that may have been programmed into your
unit. It is likely that such data, software, or other materials will be lost
during service and Universal Remote Control will not be responsible for
any such damage or loss. A dated purchase receipt, Bill of Sale, Installation
Contract or other verifiable Proof of Purchase is required. For product
support and other important information visit Universal Remote Control's
website: http://www.UniversalRemote.com or call the Customer Service
Center (914) 835-4484. ZR-2 REPETER UPDATE
This Limited Warranty only covers product issues caused by defects in
material or workmanship during ordinary consumer use. It does not cover
product issues caused by any other reason, including but not limited to
product issues due to commercial use, acts of God, third-party installation,
misuse, limitations of technology, or modification of or to any part of the
Universal Remote Control product. This Limited Warranty does not cover
Universal Remote Control products sold as USED, AS IS, REFURBISHED,
so-called “B STOCK” or consumables(such as batteries). This Limited
Warranty is invalid if the factory-applied serial number has been altered or
removed from the product. This Limited Warranty is valid only in the
United States of America. This LimitedWarranty specifically excludes
products sold by unauthorized resellers.
LIMITATION OF REMEDIESUNIVERSAL REMOTE CONTROL SHALL
ZR-2 REPEATER
Page 5
NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OFANY EXPRESS OR IMPLIED WARRANTY
OR CONDITION ON THIS PRODUCT. IN NO EVENT SHALL
UNIVERSAL REMOTE CONTROLBE LIABLE, WHETHER IN CONTRACT
OR IN TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS
OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR
SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA,
SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE
TO THEFULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY
LAW.
EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, THERE IS
NO OTHER WARRANTY EXPRESSED OR IMPLIED. UNIVERSAL
REMOTE CONTROL WILL NOT BE HELD RESPONSIBLE FOR STATE-
MENTS MADE BY OTHERS CONCERNING THE MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT.
Some states or jurisdictions do not allow the exclusion or limitation of
incidental or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusionsmay not apply
to you. This Limited Warranty gives you specific legal rights and you may
have other rights which vary from state to state or jurisdiction to
jurisdiction.
REV020708
ZR-2 REPEATER
Page 6
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different fromthat to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
ZR-2 REPEATER
Page 7
Warning!
Changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment.
Note : The manufacturer is not responsible for any Radio or TV interference
caused by unauthorized modifications to this equipment. Such
modifications could void the user's authority to operate the equipment.
FCC Caution
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the authority to operate equipment.
The antenna(s) used for this transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Federal Communication Commission (FCC) Radiation Exposure
Statement
This remote device is approved as a hand-held and hand-operated only
portable(relative to hand) device which is normally operated at 20 cm from
a person’s body.
ZR-2 REPEATER
Page 8
ZR-2 Repeater
Owner’s Manual
