User Manual

Quick Start Guide
Cisco RV340W Router
Package Contents
•Cisco RV340W Router
•Power Adapter
•Ethernet Cable
•This Quick Start Guide
•Pointer Card
•Technical Support Contact Card
•Console RJ-45 Cable
2 Cisco RV340W Router Quick Start Guide
Welcome
The Cisco RV340W series of routers provide reliable internet access
connectivity for small businesses. All of the Cisco RV340W series models
supports two connections to one internet service provider, delivering high
performance by using load balancing, or to two different providers to
deliver business continuity.
•Dual Gigabit Ethernet WAN ports allow load balancing and business
continuity.
•Affordable, high-performance Gigabit Ethernet ports enable rapid
transfer of large files, supporting multiple users.
•Dual USB ports support a 3G/4G modem or flash drive. The WAN can
also fail over to the 3G/4G modem connected to the USB port.
•SSL VPN and site-to-site VPN enable highly secure connectivity
•Stateful packet inspection (SPI) firewall and hardware encryption
provide strong security.
•A 4 LAN port switch and a WLAN access point.
This Quick Start Guide describes how to install your Cisco RV340W and
launch the web-based Device Manager.
Installing the Cisco RV340W
To prevent the device from overheating or being damaged:
• Ambient Temperature—Do not operate the device in an area that
exceeds an ambient temperature of 104°F (40°C).
•Air Flow—Be sure that there is adequate airflow around the device. If
wall mounting the firewall, make sure that the heat dissipation holes are
to the side.
• Circuit Overloading—Adding the device to the power outlet must not
overload that circuit.
•Mechanical Loading—Be sure that the device is level, stable and
secured to avoid any hazardous conditions and prevent it from sliding
or shifting out of position. Do not place anything on top of the firewall,
as the excessive weight may damage it.
1
Cisco RV340W Router Quick Start Guide 3
Desktop Mounting
For desktop mounting, place the device on a flat surface so that it sits on its
four rubber feet.
WARNING
For safety, ensure that the heat dissipation holes are facing
sideways
.
4 Cisco RV340W Router Quick Start Guide
Cisco RV340W Features
Front Panel
PWR Off when the device is powered off.
Solid green when the device is powered on and
booted.
Flashing green when the device is booting up.
DIAG Off when the system is on track to bootup.
Slow blinking red (1Hz) when the firmware
upgrade is in progress.
Fast blinking red (3Hz) when the firmware
upgrade is failing.
Solid red when the system failed to boot-up with
both active and inactive images or in rescue
mode.
LINK/ACT of
WAN1, WAN2 and
LAN1-4
Off when there is no Ethernet connection.
Solid green when the GE Ethernet link is on.
Flashing green when the GE is sending or
receiving data.
GIGABIT of WAN1,
WAN2 and LAN1-
4
Solid green when at 1000M speed.
Off when at non-1000M speed.
DMZ Solid green when the DMZ is enabled.
Off when the DMZ is disabled.
VPN Off when no VPN tunnel is defined, or all defined
VPN tunnels have been disabled.
Solid green when at least one VPN tunnel is up.
Flashing green when sending or receiving data
over VPN tunnel.
Solid amber when no enabled VPN tunnel is up.
2
Cisco RV340W Router Quick Start Guide 5
Back Panel
POWER—Toggles power to the device on or off.
12VDC (2.5A)—Power port that connects the device to the provided
12VDC, 2.5 amp power adapter.
USB 1—Type A USB port that supports flash drives and 3G/4G/LTE USB
dongles. Caution: Use only the power supply provided with the device;
using other power supplies may cause the USB dongle to fail.
Console Port—The router console port is designed for a serial cable
connection to a terminal or a computer that is running a terminal emulation
program.
Wireless LED is on when the internal access point is
enabled.
LED is off when the internal access point is
disabled.
USB1 and USB2 Off when no USB device is connected, or is
inserted but not recognized.
Solid green when the USB dongle is connected
to the ISP successfully. USB storage is
recognized.
Flashing green when sending or receiving data.
Solid amber when the USB dongle is recognized
but fails to connect to ISP (no IP address is
assigned). The USB storage access has errors.
RESET To reboot, or reboot and restore defaults:
•To reboot the router and retain the current
configuration, press and hold RESET for 3
seconds to 10 seconds (maximum), using a
paper clip or a pen tip.
•To reboot the router and restore to the
factory default settings, press and hold in the
RESET button for more than 10 seconds.
Changes made to the original configuration
of the router are lost.
6 Cisco RV340W Router Quick Start Guide
Side Panel
USB 2—Type A USB port that supports flash drives and 3G/4G/LTE USB
dongles. Caution: Use only the power supply provided with the device;
using other power supplies may cause the USB dongle to fail.
Kensington Lock Slot - Lock slot on the right side to secure the device
physically, using the Kensington lock-down equipment.
Cisco RV340W Router Quick Start Guide 7
Connecting the Equipment
Connect a configuration terminal (PC) to the device by using a LAN port.
The terminal must be in the same wired subnetwork as the device to
perform the initial configuration. As part of the initial configuration, the
device can be configured to allow remote management.
To connect a computer to the device:
STEP 1Power off all equipment, including the cable or DSL modem, the
computer, and this device.
STEP 2Use an Ethernet cable to connect your cable or DSL modem to the
WAN port on this device.
STEP 3Connect another Ethernet cable from one of the LAN (Ethernet)
ports to the Ethernet port on the computer.
STEP 4Power on the WAN device and wait until the connection is active.
STEP 5Connect the power adapter to the 12VDC port of this device.
CAUTION Use only the power adapter that is supplied with the device.
Using a different power adapter could damage the device or
cause the USB dongles to fail.
The power switch is on by default. The power light on the front
panel is solid green when the power adapter is connected
properly and the device is finished booting.
STEP 6Plug the other end of the adapter into an electrical outlet. Use the
plug (supplied) specific to your country.
STEP 7Continue with the instructions in the Using the Setup Wizard to
configure the device.
3
8 Cisco RV340W Router Quick Start Guide
Using the Setup Wizard
The Setup Wizard and Device Manager are supported on Microsoft
Internet Explorer, Mozilla Firefox, Apple Safari, and Google Chrome.
To configure the device using the Setup Wizard, follow these steps:
STEP 1Power on the PC that you connected to the LAN1 port in Step 3 of
the Connecting Equipment section. Your PC becomes a DHCP
client of the device and receives an IP address in the 192.168.1.xxx
range.
STEP 2Launch a web browser.
STEP 3In the address bar, enter the default IP address of the device,
https://192.168.1.1. A site security certificate message is
displayed. The Cisco RV340W uses a selfsigned security
certificate. This message appears because the device is not
known to your computer.
STEP 4Click Continue to this website to continue. The sign-in page
appears.
STEP 5Enter the username and password. The default username is cisco.
The default password is cisco. Passwords are case-sensitive.
STEP 6Click Log In. The Router Setup Wizard is launched.
STEP 7Follow the on-screen instructions to set up your device. The Router
Setup Wizard should detect and configure your connection. If it is
unable to do so, it asks you for information about your internet
connection. Contact your ISP for this information.
STEP 8Change the password as instructed by the Router Setup Wizard or
follow the instructions in the Changing the Administrator Username
and Password section. Log in to the device with the new username
and password.
NOTE We recommend that you change the password. You are
required to change the password before enabling features such as
remote management.
The Device Manager Getting Started page appears. It displays the
most common configuration tasks.
STEP 9Click one of the tasks listed in the navigation bar to complete the
configuration.
444
Cisco RV340W Router Quick Start Guide 9
STEP10 Save any additional configuration changes and log out of the
device manager.
Changing the Administrator Username and Password
To change the Administrator username and password on the device:
STEP 1From the Getting Started page, select Change Administrator
Password or select System Configuration > User Accounts from
the navigation bar.
STEP 2Check a username from the Local User Membership list and click
Edit.
STEP 3Enter the Username.
STEP 4Enter the Password.
STEP 5Confirm the Password.
STEP 6Check Group (admin, oper, test-group) in the Password Strength
Meter.
STEP 7Click Save.
Troubleshoot Your Connection
If you cannot access your device by using the Setup Wizard, the device
may not be reachable from your computer. You can test network
connections by using ping on a computer running Windows:
STEP 1Open a command window by using Start > Run and enter cmd.
STEP 2At the Command window prompt, enter ping and the device IP
address. For example, ping 192.168.1.1 (the default static IP
address of the device).
If you can reach the device, you should get a reply similar to the
following:
Pinging 192.168.1.1 with 32 bytes of data:
Reply from 192.168.1.1: bytes=32 time<1ms TTL=128
If you cannot reach the device, you should get a reply similar to the
following:
Pinging 192.168.1.1 with 32 bytes of data:
Request timed out.
10 Cisco RV340W Router Quick Start Guide
Possible Causes and Resolutions
Bad Ethernet connection:
Check the LEDs for the proper indications. Check the connectors of the
Ethernet cable to ensure that they are firmly plugged into the device
and your computer.
Wrong or conflicting IP address:
Verify that you are using the correct IP address of the device.
Verify that no other device is using the same IP address as this device.
No IP route:
If the router and your computer are in different IP subnetworks, remote
access must be enabled. You need at least one router on the network
to route the packets between the two subnetworks.
Unusually long access time:
Adding new connections may take 30–60 seconds for the affected
interfaces and LAN to become operational.
Cisco RV340W Router Quick Start Guide 11
Where to Go From Here
For EU Lot 26 related test results, see www.cisco.com/go/eu-lot26-results
Support
Cisco Support
Community
www.cisco.com/go/smallbizsupport
Cisco Support and
Resources
www.cisco.com/go/smallbizhelp
Phone Support Contacts www.cisco.com/en/US/support/
tsd_cisco_small_business
_support_center_contacts.html
Cisco Firmware
Downloads
www.cisco.com/go/smallbizfirmware
Select a link to download firmware for Cisco
products. No login is required.
Cisco Open Source
Request
www.cisco.com/go/
smallbiz_opensource_request
Cisco Partner Central
(Partner Login Required)
www.cisco.com/web/partners/sell/smb
Product Documentation
Cisco RV340 www.cisco.com/go/RV340W
5
Americas Headquarters
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates
in the U.S. and other countries. To view a list of Ciscotrademarks, go to this URL:
www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their
respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (1110R)
© 2016 Cisco Systems, Inc. All rights reserved.
78-100852-01

Navigation menu
