Contents
Users Guide Part 2
51
Contacts
Displaying the Contacts list sorted by last
name/first name
You can choose to sort the Contacts list by contact’s last name or
first name.
d Main menu > Contacts > Advanced > Display by
1. Select First name or Last name
Memory status
You can see the amount of memory available in the Contacts list.
d Main menu > Contacts > Advanced > Memory status
Copying contacts
You can copy all the contacts from SIM card to phone, or from phone
to SIM card.
Copying all the contacts from SIM card to phone
d Main menu > Contacts > Advanced > Copy all from SIM
1. “Copy?” 7 [0]9[5] (Yes)
Copying all the contacts from phone to SIM card
d Main menu > Contacts > Advanced > Copy all to SIM
1. “Only Name and Number fields can be copied. Continue?”
7 [0]9[5] (Yes)
Note: The amount of memory for SIM storage depends on your SIM card.
To decrease the amount of phone memory used, delete unwanted data or
store data on your PC (see “CD-ROM” on page 152).
VS7_AAA.book Page 51 Wednesday, August 3, 2005 5:10 PM
52
Contacts
Deleting Phone Contacts
You can delete all the contacts stored in your phone.
d Main menu > Contacts > Advanced > Delete all
1. “Delete all contacts in phone?” 7 [5] (Yes)
2. “Are you Sure?” 7 [5] (Yes)
Service numbers
If your SIM card includes SDN (Service Dialling Number), you can
call a service number by selecting from the list.
SDN enables you to access special services provided by your
network operator, such as customer support, emergency services,
etc.
d Main menu > Contacts > Service numbers
1. [192] to scroll to the required item 7 [0]9[5] (Call)
VS7_AAA.book Page 52 Wednesday, August 3, 2005 5:10 PM
53
Messages
Messages menu structure
Note: There are several ways to select items from menu lists. See “Menu
selection method” on page 26.
Create new........................ 54
SMS message........................ 55
MMS message ....................... 58
Inbox ................................. 60
SMS ....................................... 61
MMS....................................... 62
Archive.............................. 64
SMS ....................................... 64
MMS....................................... 64
Web mail*1........................ 65
Chat*1................................ 66
Voicemail...........................66
Call Voicemail .........................66
Set mailbox number................66
Messages settings ...........67
SMS........................................67
MMS ....................................... 68
Memory status ..................69
SMS........................................69
MMS ....................................... 69
*1
VS7_AAA.book Page 53 Wednesday, August 3, 2005 5:10 PM
54
Messages
Creating a new message
Messaging types
SMS
Short Message Service allows you to send and receive
short text messages on any network that has roaming
agreement. (Dependent on the recipient’s phone
parameters.) With the Illumination feature, you can
express special feelings in a message.
MMS
Multimedia Messaging Service allows you to send
messages containing text, pictures, sound and video
clips from your phone to other MMS-enabled phones or
e-mail addresses. The recipient can play it as a slide
show.
Note: The message centre number for SMS should be preprogrammed on
the SIM card. Changing this number (see Message centre setting on
page 67) may cause failure of a text message.
Your phone may have already been set with an MMS profile when
purchased. To change the settings of the profile, see Advanced setting on
page 68.
Sending or editing of a forward locked picture/sound clip/video clip indicated
by the icon ( ) is restricted.
VS7_AAA.book Page 54 Wednesday, August 3, 2005 5:10 PM
55
Messages
Creating an SMS message
d Main menu > Messages > Create new > SMS message
1. Create text message 7 [0]
See “Text entry” on page 36 for entering text.
2. To enter recipient’s phone number directly: Enter number
To select recipient’s phone number from Contacts: [0] 7
Highlight the required contact 7 [5] (Select) 7 If the card has
several phone numbers stored, [192] to scroll to the required
number 7 [0]9[5] (Select)
3. [0] to send the message
Creating an Illumination message with emoticons
With the Illumination feature, you can express special feelings in a
message. The Indicator/Illumination Light responds to the
pictographs in an Illumination message and light in combinations of
colours and light patterns when you receive and view an Illumination
message.
d Main menu > Messages > Create new > SMS message
1. Create text message
2. [5] (Options) 7 Select Templates
3. Select Illumination templates
4. Select the required emoticon
See “Emoticon list” on page 56.
To preview the Illumination of the messages you create:
[5] (Options) 7 Select Preview illumination
Note: Only recipients who have an Illumination message capable phone
can view messages with Illumination.
VS7_AAA.book Page 55 Wednesday, August 3, 2005 5:10 PM
56
Messages
Emoticon list
• Pattern A: [Firefly] flickers slowly for about 4 seconds.
• Pattern B: [Flash] flickers fast for about 3 seconds.
• Pattern C: [Beam] lights for about 3 seconds.
Emoticon Indicator
Colour
Light
Pattern Emoticon Indicator
Colour
Light
Pattern
:-)
Colour 3
A\^o^/
Colour 3
A
:-D (^_^)
>:-<
B
\(>o<)/
B:-|| (>-<#)
:e
Colour 6
^3^
Colour 60:-) A(o^-^o) A
:-P C(e~o~e)
:'( Colour 1 B(;_;) Colour 1 B
:-( A(T_T) A
:-/
Colour 5
(?_?)
Colour 5:-S B(>_<) B
:-[ C(-_-; C
:-> Colour 2 A(^w^) Colour 2 A
8-)
B
^&^
B=:-)
Colour 4
(@_@)
Colour 4:-0 (eoe)
:() Cp(^-^)p A
:-IColour 7 (-_-) Colour 7 C
I-( A(_ _)Zzz A
;-) Colour 8 (^_~)" Colour 8
VS7_AAA.book Page 56 Wednesday, August 3, 2005 5:10 PM
57
Messages
Options
When creating a text message, the following options are available by
pressing [5] (Options).
Send Send the text as an SMS message.
Send to many Send the text to more than one recipients.
Preview illumination Preview illumination message.
Templates
Select Illumination templates to create an
illumination message or User templates to use
the stored text templates.
Count message
The long message may be divided into several
messages. You can check the concatenated
message number.
Save Save the message in Unsent folder.
Use contacts Access Contacts menu to use Contacts data.
Copy/Cut/Paste Copy, cut or paste the text.
Add symbol Show the Symbol list from which you can select
any symbol available on your phone.
Input method Select the input method.
T9 on/off Turn On or Off the predictive dictionary.
Input language Select a language you wish to write in.
My dictionary Add words to the internal dictionary.
Exit Exit the text edit mode.
VS7_AAA.book Page 57 Wednesday, August 3, 2005 5:10 PM
58
Messages
Creating an MMS message
d Main menu > Messages > Create new > MMS message
1. Select Add picture, Add text, Add sound or Add video
2. If Add text is selected: Create text message 7 [0]
See “Text entry” on page 36 for entering text.
If Add picture/Add sound/Add video is selected: Select the
required item stored to My Media 7 [5] (Select)
You can also download new files, take new pictures, record new sound
or video clips for the MMS message.
3. To add more than one picture, text, sound or video clip, [192]
to scroll to Slides 7 [0] 7 [0]9[5] (Yes)
4. Repeat steps 1-3 if required
To send the message:
5. [5] (Options) 7 Select Send
6. [192] to scroll to Add subject 7 [0]
7. Enter subject 7 [0]
8. [192] to scroll to Add recipient 7 [0]
9. Select From contacts, Enter number or Enter email address
10. If From contacts is selected: Highlight the required contact 7
[5] (Select) 7 If the card has several numbers stored, [192]
to scroll to the required number 7 [0]9[5] (Select)
If Enter number/Enter email address is selected: Enter
number/email address 7 [0]
11. [192] to scroll to Send 7 [0]
Note: When you select Add video and record a new video clip in step 2,
the recording time is fixed to For MMS sending.
You cannot attach a video clip together with a picture file or sound clip to one
slide.
For downloading contents, visit http://box.panasonic.com/
VS7_AAA.book Page 58 Wednesday, August 3, 2005 5:10 PM
59
Messages
Slide options
When Slides is highlighted, the following options are available by
pressing [5] (Options).
Receiving messages
Receiving SMS messages
When you receive a new SMS message, the message icon ( ) is
displayed along with a tone, illumination, and/or vibration. The SMS
notification also appears on the standby screen. When One push
SMS setting is set to On (see page 67), new SMS messages can be
displayed by opening the flip. You can also check received SMS
messages on the Front display.
Reading SMS messages
When an SMS notification is displayed on the standby screen:
1. [0]9[5] (View)
If there is more than one notification, [192] to scroll to New SMS before
step 1.
If there is one SMS message, the message is automatically displayed.
2. If there is more than one SMS message, [192] to scroll to the
required message header in SMS Inbox 7 [0]
3. When the message is displayed, [0] to show the message
details (sender’s number, date, message centre’s number) if
required
Add new Add a new slide.
Send Send the MMS message after entering subject
and recipient number or address.
Slide duration Specify duration of the slide.
Remove slide Remove the slide from the MMS message.
Preview slide Preview the MMS message as a slide.
VS7_AAA.book Page 59 Wednesday, August 3, 2005 5:10 PM
60
Messages
Receiving MMS messages
When you receive a new MMS message, the message icon ( ) is
displayed along with a tone, illumination, and/or vibration. The
received MMS messages are stored in Inbox.
Reading MMS messages
To read the received MMS messages, see “MMS Inbox” on page 62.
Inbox
Inbox stores received SMS and MMS messages.
d Main menu > Messages > Inbox
Numbers in brackets show the number of
unread messages and the total number of
messages in each inbox.
Note: If you do not want to receive MMS messages automatically, select
Never in Auto download setting (see page 68). In this case, you will receive
a message notification first, and then you will need to receive messages
manually.
VS7_AAA.book Page 60 Wednesday, August 3, 2005 5:10 PM
61
Messages
SMS Inbox
SMS message icons
Reading SMS messages
d Main menu > Messages > Inbox > SMS
1. [192] to scroll to the required message header 7 [0]
2. [0] to show the message details (sender’s number, date,
message centre’s number) if required
Options
When viewing the list of messages or the selected message, the
following options are available by pressing [5] (Options).
*1Available only when viewing the selected message.
*2Available only when viewing the list of messages.
Unread message Read message
Reply Create reply message in SMS or MMS.
Forward Forward the selected message.
Call Call the sender’s number.
Add to contacts Store the sender’s number to Contacts.
Use detail*1
Use phone number, e-mail or web address in the
selected message to call, create message, add to
Contacts, etc.
Delete Delete the selected message.
Delete all*2Delete all the SMS messages.
View illumination*1Check the illumination of the message.
VS7_AAA.book Page 61 Wednesday, August 3, 2005 5:10 PM
62
Messages
MMS Inbox
MMS message icons
Reading MMS messages
d Main menu > Messages > Inbox > MMS
1. [192] to scroll to the required message header 7 [0]
Options in the message list
When viewing the list of messages, the following options are
available by pressing [5] (Options).
Unread message MMS notification
Read message
Reply Create reply message by SMS or MMS.
Reply to all Create reply message to all recipients.
Forward Forward the selected message.
Call Call the sender’s number.
Add to contacts Store the sender’s number or e-mail address to
Contacts.
Delete Delete the selected message.
Delete all Delete all the MMS messages and notifications.
Protect/Unprotect Protect or unprotect the selected message.
Details Show details for the selected message.
Note: Sending or editing of a forward locked file indicated by the icon ( )
is restricted.
VS7_AAA.book Page 62 Wednesday, August 3, 2005 5:10 PM
63
Messages
Options while viewing messages
When viewing the message, the following options are available by
pressing [5] (Options).
*1
Options for notification
When the notification is highlighted, the following options are
available by pressing [5] (Options).
Reply Create a reply message by SMS or MMS.
Reply to all Create a reply message to all the recipients.
Play again Play the selected message.
Message font size*1Select the required font size.
Save picture Save the attached picture to My Media.
Save sound Save the attached sound clip to My Media.
Save video Save the attached video clip to My Media.
Use detail
Use the phone number, e-mail or web address in
the selected message to call, create message,
add to Contacts, etc.
Attached files Show the attached files.
Receive Receive new messages.
Forward Forward the message.
Reject Delete the notification from the message list and
the message from the server.
Call Call the sender’s number.
Delete all Delete all the MMS messages and notifications.
Protect/Unprotect Protect or unprotect the message.
Details Show details for the selected message.
VS7_AAA.book Page 63 Wednesday, August 3, 2005 5:10 PM
64
Messages
Archive
Archive stores SMS and MMS messages that are sent or waiting to
be sent.
Viewing messages
d Main menu > Messages > Archive > SMS or MMS
1. Select the required folder
2. [192] to scroll to the required message 7 [0]
Options for SMS
In Sent and Unsent folders, the following options are available by
pressing [5] (Options).
*1Available only when viewing the selected message.
*2Available only when viewing the list of messages.
SMS
Sent Store sent SMS messages.
Unsent Store undelivered and unfinished SMS
messages.
MMS
Sent Store sent MMS messages.
Outbox Store undelivered MMS messages.
Drafts Store unfinished MMS messages.
Send Send the selected message.
Call Call the sender’s number.
Use detail*1
Use phone number, e-mail or web address in the
selected message to call, create message, add to
Contacts, etc.
Delete Delete the selected message.
Delete all*2Delete all the SMS messages in the folder.
View illumination*1Check the illumination of the message.
VS7_AAA.book Page 64 Wednesday, August 3, 2005 5:10 PM
65
Messages
Options for MMS
In Sent, Outbox and Drafts folders, the following options are
available by pressing [5] (Options).
*1Available only in Sent folder.
*2Available only in Outbox and Drafts folder.
Web mail
Web mail is an innovative service that lets you stay up-to-date with
all of your messages. You need to subscribe to this service. For
further information, contact your service provider.
Connecting to internet mail
d Main menu > Messages > Web mail
Your phone is connected to the Internet via a WAP connection to
retrieve e-mail messages.
1. Follow the screen contents
Edit Edit the selected message.
Forward*1Forward the selected message.
Send*2Send the selected message.
Delete Delete the selected message.
Delete all Delete all the messages in the folder.
Protect/Unprotect Protect or unprotect the selected message.
Details Show details for the selected message.
VS7_AAA.book Page 65 Wednesday, August 3, 2005 5:10 PM
66
Messages
Chat
Chat lets you enjoy the fun of instant messaging wherever you are.
It’s the fun way to chat on-line. For further information, contact your
service provider.
d Main menu > Messages > Chat
1. Follow the screen contents
Voicemail
Voicemail is a network service which allows callers, who could not
reach you, to leave voice messages. You may need to subscribe to
this service. For further information, contact your service provider.
Retrieving stored voice messages
When a new voice message is stored, an alert sounds and ( )
appears on the display, and you receive an SMS notification.
When an SMS notification is displayed on standby screen:
1. [0]9[5] (Call)
2. Follow the recorded instructions
OR
d Main menu > Messages > Voicemail > Call Voicemail
1. Follow the recorded instructions
Changing the voice mailbox number
d Main menu > Messages > Voicemail > Set mailbox number
1. Enter new voice mailbox number 7 [0]9[5] (Ok)
Shortcut: You can also press and hold [A] in standby mode to call your
voice mailbox.
VS7_AAA.book Page 66 Wednesday, August 3, 2005 5:10 PM
67
Messages
Messages settings
SMS settings
d Main menu > Messages > Messages settings > SMS
1. Select the required setting
*1
Message lights
Decide whether or not you want the Indicator/
Illumination Light to illuminate when receiving an
illumination message.
Message lights view
Decide whether or not you want the Indicator/
Illumination Light to illuminate when viewing an
illumination message.
Message centre Edit the message centre number.
Message type Select the required message type.
Validity period
Set a time period for the message centre to
attempt message delivery. Select 1 hour, 12
hours, 1 day, 1 week, 1 month, 3 months or
Maximum.
Delivery report Select On to receive delivery reports.
Store sent SMS Select On to store sent messages to the Sent
folder.
Message font size*1Select the required font size.
Bearer type Select the data bearer type.
One push SMS Select On to display new SMS messages by
opening the flip.
VS7_AAA.book Page 67 Wednesday, August 3, 2005 5:10 PM
68
Messages
MMS settings
d Main menu > Messages > Messages settings > MMS
1. Select the required setting
*1
Reports
Select Request read (check if the other party has
read the message), Send read (inform the other
party that you have read the message when
asked), Request delivery (check if the other party
has received the message) or Send delivery
(inform the other party that you have received the
message when asked).
Priority Select Low, Normal or High for the message
priority level.
Validity period
Set a time period for the message centre to
attempt message delivery. Select 1 day, 7 days or
Maximum.
Auto download
Select Always on (messages are retrieved
automatically after receiving message
notifications), On when home (messages are
retrieved automatically in your service area) or
Never (messages are retrieved manually).
Player mode
Select Auto (display MMS slides, or playback
video/sound clips automatically) or Manual
(display MMS slides, or playback video/sound
clips manually).
Message font size*1Select the required font size.
Advanced
If required, edit the information on Message
server, WAP profiles, Fetch on server*1 and
Anonymous reject*1. Select Information to view
MMS software information.
VS7_AAA.book Page 68 Wednesday, August 3, 2005 5:10 PM
69
Messages
Memory status
You can see the amount of memory available for storing messages.
d Main menu > Messages > Memory status > SMS or MMS
Note: To decrease the amount of phone memory used, delete unwanted
data or store data on your PC (see “CD-ROM” on page 152).
VS7_AAA.book Page 69 Wednesday, August 3, 2005 5:10 PM
70
Camera
Camera menu structure
Note: There are several ways to select items from menu lists. See “Menu
selection method” on page 26.
Picture............................... 71
Video ................................. 77
VS7_AAA.book Page 70 Wednesday, August 3, 2005 5:10 PM
71
Camera
You can take a picture with the built-in camera, and send them via
MMS, Infrared or Bluetooth, or use them as wallpaper. You can also
attach a picture to a contact stored in your phone.
Picture preview screen
Icons on picture preview screen
- Zoom level (1-25)
Picture size (Ultra large/Extra large/Large/
Medium/Small/Main display/Front display)
Image quality (Super fine/Fine/Normal)
Multi shot mode
Self timer (5 or 10 seconds delay)
Night mode
Photo light
- Brightness level (-2, -1, ±0, +1, +2)
VS7_AAA.book Page 71 Wednesday, August 3, 2005 5:10 PM
72
Camera
Taking a picture
d Main menu > Camera > Picture
1. The display acts as a viewfinder. Move the phone around to
frame your subject
2. [0]9[U] to capture the image
Operations after taking a picture
To save the image to My Media: [5] (Save)9[U]
You can save the image by pressing [U] whether the flip is open or closed.
To return to the preview screen without storing the image: [6]
(Delete)
To send the captured image via MMS: [0] 7 See “Creating an MMS
message” on page 58
Taking a self-portrait
You can take your self-portrait using Front display.
d Main menu > Camera > Picture
1. Close the flip. Look at yourself in Front display
2. [U] on the side of the phone
3. The image appears on both the Main display and the Front
display. For further operation, see “Operations after taking a
picture” on page 72
Shortcut: To directly open the picture preview screen, press and hold [U]
in standby mode.
Caution: To avoid impairing camera performance, DO NOT leave the
phone with the camera facing direct sunlight.
VS7_AAA.book Page 72 Wednesday, August 3, 2005 5:10 PM
73
Camera
Zoom
[1]9[O] to zoom in one level
[2]9[P] to zoom out one level
You can also press and hold the keys to quickly reach the required
zoom level.
Adjusting the brightness level
The picture brightness indicator shows the current brightness level.
[4] to increase the brightness level
[3] to decrease the brightness level
Taking close-up pictures
You can take sharp pictures from a close distance by using Macro
Mode. (Macro focus range: 10 cm)
Slide the Macro Mode Switch to ( ) before taking close-up pictures.
Note: To send a picture via infrared or Bluetooth, or use as wallpaper, save
the image once, and then go to My Media. (See “Pictures” on page 132.)
If the camera is left in certain conditions including the preview screen and
capture screen for 3 minutes, the phone automatically exits Picture mode. If
left in the preview screen, but with the options menu displayed, the phone
remains in this state.
If certain situations such as receiving calls occur during camera operation,
the phone exits Camera mode. If a captured image is on the screen, it is
saved to My Media.
Note: Zoom function may not be available when the picture size is set to
Ultra large 1600x1200.
VS7_AAA.book Page 73 Wednesday, August 3, 2005 5:10 PM
74
Camera
Viewing pictures
Pictures taken with the built-in camera are saved to My Media. To
view the saved pictures, see “Viewing pictures” on page 132.
Picture settings
In the preview screen, the following options are available by
pressing [5] (Options).
Picture size
Select the required size from Ultra large
1600x1200, Extra large 1280x960, Large
640x480, Medium 320x240, Small 160x120,
Main display 240x320 or Front display 96x64.
Image quality Select the required quality from Super fine, Fine
or Normal.
Photo light Select On to light up your subject before snapping
a picture.
Night mode Select On to take a picture in low light conditions.
Multi shot mode 15 continuous shots is available. See “Continuous
shooting” on page 76.
Effect Select the required colour from Normal, Sepia,
Monochrome or Negative.
Self timer Select the amount of time delay you require for
shooting from Off, 5 seconds or 10 seconds.
Shutter sound Select the required sound from Pattern 1-5.
Switch to video Switch from Picture mode to Video mode.
Available space
Show the number of files which can be saved in
the current picture size and image quality. You
can see the number of files which can be saved in
other image qualities by pressing [5] (Quality),
and in other picture sizes by pressing [192].
Set to default Reset the current picture settings to default.
Help Show direct key operation in the preview screen.
VS7_AAA.book Page 74 Wednesday, August 3, 2005 5:10 PM
75
Camera
Direct key operation
You can change the picture settings by pressing one of the numeric
keys which correspond to the functions as follows. Some functions
are depicted by the icon. See “Icons on picture preview screen” on
page 71.
[A]: Switch to video
[S]: Picture size
[D]: Image quality
[F]: Multi shot mode
[G]: Self timer
[H]: Night mode
[I]: Effect
[L]: Help
[r]: Photo light
Adding a picture to Contacts card
If a picture is attached to a Contact card, it appears on the screen
when the contact calls you.
To attach a picture to a contact, save the image once, and then go to
Contacts. See “Adding contacts” on page 44.
VS7_AAA.book Page 75 Wednesday, August 3, 2005 5:10 PM
76
Camera
Continuous shooting
In Multi shot mode, you can capture a succession of 15 images with
just one press. When you set Multi shot mode on, the picture size is
fixed to Medium 320x240 and Night mode off.
d Main menu > Camera > Picture
1. [5] (Options) 7 Select Multi shot mode
2. Select On
3. [0]9[U] to shoot
The captured images are displayed as thumbnails.
To view the captured images:
[1929394] to scroll to the required thumbnail 7 [0]
You can view the next image by pressing [4] or [2], and the
previous image by pressing [3] or [1].
To save a captured image:
1. When the required thumbnail is highlighted or the required
image is displayed on the screen, [5] (Options) 7 Select
Save this one only
The picture is stored to My Media.
To save all the captured images:
1. In thumbnail screen or when one of the images is displayed on
the screen, [5] (Options) 7 Select Save all pictures
OR
When one of the images is displayed on the screen, [0]
All the pictures are stored to My Media.
Note: You cannot take pictures in Multi shot mode when the phone is
closed. Once you close the phone, Multi shot mode is switched off.
Note: All the captured images are also saved by pressing [U] on thumbnail
screen or when one of the images is displayed on the screen.
VS7_AAA.book Page 76 Wednesday, August 3, 2005 5:10 PM
77
Camera
Video
You can record video clips with the built-in camera, and send them
via MMS, infrared or Bluetooth.
Video preview screen
Icons on video preview screen
- Zoom level (1-25)
Recording time
(Extended video/For MMS sending)
Self timer (5 or 10 seconds delay)
Photo light
- Brightness level (-2, -1, ±0, +1, +2)
VS7_AAA.book Page 77 Wednesday, August 3, 2005 5:10 PM
78
Camera
Recording a video clip
d Main menu > Camera > Video
1. Main display acts as a viewfinder. Move the phone around to
frame your subject
2. [0]9[U] to start recording
3. Video recorder records until reaching the clip size limit or until
you press [0]9[U]9[5] (Stop)
4. Select the required action
Playback Playback the recorded video clip.
Save to My Media Save the recorded video clip to My Media.
Send as MMS
Attach the recorded video clip to an MMS
message. See “Creating an MMS message” on
page 58.
Caution: To avoid impairing camera performance, DO NOT leave the
phone with the camera facing direct sunlight.
Note: To send a video clip via infrared or Bluetooth, save the video clip
once, and then go to My Media. (See “Videos” on page 139.)
If the video is left in the preview screen or a recorded video clip is displayed
for 3 minutes, the phone automatically exits Video mode. If left in preview
screen, but with the options menu displayed, the phone remains in this state.
If certain situations such as receiving calls occur during camera operation,
the phone exits Camera mode. The recording ends automatically, and the
already recorded video clip is saved to My Media.
VS7_AAA.book Page 78 Wednesday, August 3, 2005 5:10 PM
79
Camera
Zoom
[1]9[O] to zoom in one level
[2]9[P] to zoom out one level
You can also press and hold the keys to quickly reach the required
zoom level.
Adjusting the brightness level
The video clip brightness indicator shows the current brightness
level.
[4] to increase the brightness level
[3] to decrease the brightness level
Playing video clips
Recorded video clips are saved to My Media. To play the saved
video clips, see “Playing video clips” on page 139.
Note: You cannot change the zoom level while recording.
Note: You cannot change the brightness level while recording.
VS7_AAA.book Page 79 Wednesday, August 3, 2005 5:10 PM
80
Camera
Video settings
In the preview screen, the following options are available by
pressing [5] (Options).
Direct key operation
You can change the video settings by pressing one of the numeric
keys which correspond to the functions as follows. Some functions
are depicted by the icon. See “Icons on video preview screen” on
page 77.
[A]: Switch to picture
[S]: Recording time
[G]: Self timer
[I]: Effect
[L]: Help
[r]: Photo light
Recording time Select the video recording time from Extended
video or For MMS sending.
Photo light Select On to light up your subject before recording
a video clip.
Effect Select the required colour from Normal, Sepia,
Monochrome or Negative.
Self timer Select the amount of time delay you require for
recording from Off, 5 seconds or 10 seconds.
Switch to picture Switch from Video mode to Picture mode.
Available space
Show the number of files which can be saved in
the current recording time. You can see the
number of files which can be saved in other
recording time by pressing [5] (RecTime).
Help Show direct key operation in the preview screen.
VS7_AAA.book Page 80 Wednesday, August 3, 2005 5:10 PM
81
Browser
Browser menu structure
Setting up your Browser
Your phone’s WAP (Wireless Application Protocol) browser allows
you to access services supported by the network such as news,
weather reports, sports, etc.
Before Internet services can be accessed, you need to subscribe to
your service provider to enable the relevant configuration
information. (Your service provider may have already completed the
connection settings. To configure the WAP profile settings, see
“WAP profiles” on page 87.)
Note: There are several ways to select items from menu lists. See “Menu
selection method” on page 26.
Note: Modifying the preinstalled settings without accurate knowledge may
cause a failure in connection.
PANASONIC BOX
VS7_AAA.book Page 81 Wednesday, August 3, 2005 5:10 PM
82
Browser
Viewing the contents
Opening Browser
d Main menu > Browser
The off-line menu is displayed. You will not be
connected until you choose a menu.
1. [192] to scroll to the required menu 7
[0]
The phone is connected to the web site.
Online status icons
Closing Browser
1. [5] (Options) 7 Select Exit browser
Shortcut: You can directly access Browser by pressing [6] ( ) in
standby mode.
Non-secure CSD
connection
Non-secure GPRS
connection
Secure CSD connection Secure GPRS
connection
VS7_AAA.book Page 82 Wednesday, August 3, 2005 5:10 PM
83
Browser
Browser options
While Browser is on-line or off-line, the following options are
available.
d Main menu > Browser [Off-line]
OR
d Main menu > Browser > Required menu [On-line]
1. [5] (Options) 7 Select the required option
*1Available only when the web page is displayed.
*2Available only when the web page has the image, melody or video
contents.
Select Select the required item.
Bookmarks Go to the bookmark list.
Enter address Go to URL entry.
Save media*1*2The image in contents is saved to My Media.
Set as bookmark*1The displayed URL is saved to the bookmark list.
Service Inbox Open Service Inbox.
Reload page*1Reload this page.
Advanced
Go to homepage, clear the cache, view or send
the current URL, or view the current WAP
information.
Settings Edit WAP profiles/Push access settings or view
the security information.
Exit browser*1Terminate the browser.
VS7_AAA.book Page 83 Wednesday, August 3, 2005 5:10 PM
84
Browser
Bookmarks
Once you bookmark your favourite page or a frequently accessed
page, you can jump to the page quickly. You can also categorise the
bookmarked pages into 10 folders and rename each folder.
While off-line or on-line:
1. [5] (Options) 7 Select Bookmarks
2. [192] to scroll to the required bookmark folder 7 [0]
3. [192] to scroll to the required bookmark
4. To load the URL: [0]
To select the required option: [5] (Options)
Renaming a bookmark folder
[192] to scroll to the required bookmark folder 7 [5] (Options) 7
Select Rename 7 Enter a new folder name 7 [0]
Deleting all bookmarks
In the bookmark list:
[5] (Options) 7 Select Delete all 7 [5] (Yes)
All the saved bookmarks are deleted, and the folder names return to
the default.
Go to page Jump to the web page.
Add bookmark Add to the bookmark list.
Edit Edit the selected bookmark name and URL.
Move to Move the selected bookmark to another folder.
Delete Delete the selected bookmark.
Send bookmark Send the bookmarked URL via SMS or MMS.
Delete all in folder Delete all the bookmarks in the folder.
VS7_AAA.book Page 84 Wednesday, August 3, 2005 5:10 PM
85
Browser
Enter address
You can directly go to the required web page by entering the URL.
While off-line or on-line:
1. [5] (Options) 7 Select Enter address
2. Enter URL 7 [0]
Save media
Images, melodies or videos on the web page can be saved to My
Media.
When the web page is displayed:
1. [5] (Options) 7 Select Save media
2. [0]9[5] (Select) to save
Set as bookmark
You can save the URLs of your favourite pages in Bookmarks.
When the web page is displayed:
1. [5] (Options) 7 Select Set as bookmark
2. Enter title 7 [0]
3. [192] to scroll to the required folder 7 [0]9[5] (Save)
Note: Panasonic is not responsible for the performance of downloaded
contents or possible corruption of phone software.
VS7_AAA.book Page 85 Wednesday, August 3, 2005 5:10 PM
86
Browser
Service Inbox
View WAP Push message and go to URL.
While off-line or on-line:
1. [5] (Options) 7 Select Service Inbox
2. To load the URL: [0]
To select the required option: [5] (Options)
*1Available only when text and URL are delivered from your service
provider.
Reload page
Current page can be reloaded.
When the web page is displayed:
1. [5] (Options) 7 Select Reload page
Go to page Jump to the web page.
View message*1View the message.
Delete Delete the message.
VS7_AAA.book Page 86 Wednesday, August 3, 2005 5:10 PM
87
Browser
Advanced
While off-line or on-line:
1. [5] (Options) 7 Select Advanced
2. Select the required option
*1Available only when the web page is displayed.
Settings
WAP profiles
If no settings are present, contact your service provider.
You can check or edit the current WAP profile settings, or add new
WAP profile settings.
d Main menu > Browser [Off-line]
1. [5] (Options) 7 Select Settings
2. Select WAP profiles
3. [192] to scroll to the required profile
4. [5] (Options) 7 Select Activate, Edit or Delete
5. If Edit is selected, you can edit the following information:
Profile name, Homepage, Proxy IP, Proxy port, Use proxy
and Data connections
Home Jump to the set-up homepage.
Clear cache Delete the contents stored in the cache.
View current URL*1View the URL of the current page.
Send current URL*1Send the URL of the current page via SMS or
MMS.
WAP information View WAP browser information.
Note: You need to configure GPRS or CSD before configuring the WAP
profile settings. See “Data connections” on page 116.
VS7_AAA.book Page 87 Wednesday, August 3, 2005 5:10 PM
88
Browser
Push access
Set up Push access to receive WAP messages.
While off-line or on-line:
1. [5] (Options) 7 Select Settings
2. Select Push access
3. Select Service indication, Service loading or Other
messages
4. Select On or Off
Security
View security information.
While off-line or on-line:
1. [5] (Options) 7 Select Settings
2. Select Security
3. Select the required item
*1Available only while secure connection.
Certificates Select Certificate 1-20.
Current certificate*1View the current certificate.
Session info*1View session information.
VS7_AAA.book Page 88 Wednesday, August 3, 2005 5:10 PM
89
Settings
Settings menu structure
Note: There are several ways to select items from menu lists. See “Menu
selection method” on page 26.
Phone settings ................. 90
Profiles ................................... 90
Language ............................... 91
Time and date ........................ 91
Illuminations ........................... 92
Key settings............................ 93
Master reset ........................... 95
Display settings ............... 96
Main display ........................... 96
Front display........................... 97
Main menu icons .................... 98
Themes .................................. 99
Backlight time......................... 99
Sounds & alerts ............... 99
Assign ringtone ...................... 99
Incoming volume .................. 100
Message alert......................... 99
Message volume .................. 100
Warning tone ........................ 100
Startup tone.......................... 100
Shutdown tone ..................... 100
Vibration alert ....................... 100
Calls.................................101
Call diverts............................101
Call waiting ........................... 102
Any key answer ....................102
Active flip .............................. 103
Auto answer..........................103
Send my number ..................103
Call duration .........................103
Service charge*1*2................104
Connectivity....................105
Infrared .................................105
Bluetooth .............................. 107
Synchronisation*2................. 112
Cell Broadcast ...................... 114
GSM network........................ 115
Data connections.................. 116
Security ...........................117
PIN entry............................... 117
Change PIN2........................ 118
Fixed dial .............................. 118
Call barring ........................... 118
*1
*2
VS7_AAA.book Page 89 Wednesday, August 3, 2005 5:10 PM
90
Settings
Phone settings
Profiles
You can switch among different profiles in your phone, each with a
distinct combination of alert method, ringtone, etc. Profiles are set up
for use in the following environments:
Activating a profile
d Main menu > Settings > Phone settings > Profiles
1. [192] to scroll to the required profile
2. [0]
OR
[5] (Options) 7 Select Activate
Setting a profile
You can personalise the individual settings within a profile. For
further details about the individual settings, see “Sounds & alerts” on
page 99.
d Main menu > Settings > Phone settings > Profiles
1. [192] to scroll to the required profile
2. [5] (Options) 7 Select Edit
3. Select the required item
4. Select the required setting
Normal For everyday settings.
Silent For formal occasions.
Meeting For meetings.
Outdoor For noisy environments.
Car For driving occasions.
VS7_AAA.book Page 90 Wednesday, August 3, 2005 5:10 PM
91
Settings
Language
You can change the language used for display messages and/or text
entry. Automatic uses the language dictated by the country/region
code of the SIM card.
d Main menu > Settings > Phone settings > Language >
Display language or Input language
1. Select Automatic or the required language
Time and date
You can set your Home clock and Away clock.
Home clock
You can set the current time and date on your phone.
d Main menu > Settings > Phone settings > Time and date >
Home clock
1. Select the required setting
Away clock
You can set Away clock to display the time in the area you choose.
d Main menu > Settings > Phone settings > Time and date >
Away clock
1. Select the required setting
Set date & time Enter the time 7 [2] 7 Enter the date
Home area Select your home area.
Summer time Select On to activate the summer time mode.
Set time zone Select the required area.
Summer time Select On to activate the summer time mode.
VS7_AAA.book Page 91 Wednesday, August 3, 2005 5:10 PM
92
Settings
Choosing clock
You can choose either Home clock or Away clock to be displayed on
your phone.
d Main menu > Settings > Phone settings > Time and date >
Select clock > Home clock or Away clock
Display format
You can select the required display format for the date and time.
d Main menu > Settings > Phone settings > Time and date >
Display format > Time or Date
1. To set Time format: Select 24 hour or 12 hour
To set Date format: Select the required format (DD=date,
MM=month, YY=year)
Illuminations
The Indicator/Illumination Light flashes or beams when you receive
calls/messages, have a conversation, the flip is closed, the battery is
charging or data is transferred.
d Main menu > Settings > Phone settings > Illuminations
1. Select the required event
Incoming
Select the required colour or Off.
Message
In conversation
Flip close
Charging Select On or Off.
Data transfer
Note: You can check the Flip close illumination by pressing [O9P] while
the phone is in standby mode with the flip closed.
VS7_AAA.book Page 92 Wednesday, August 3, 2005 5:10 PM
93
Settings
Key settings
Key tone
You can change the key tone.
d Main menu > Settings > Phone settings > Key settings > Key
tone
1. Select the required tone
Key volume
You can change the key tone volume.
d Main menu > Settings > Phone settings > Key settings > Key
volume
1. [1929394] to scroll to the required volume 7 [0]9[5]
(Select)
Key backlight
If you set the key backlight to off, you can maintain longer battery
life.
d Main menu > Settings > Phone settings > Key settings > Key
backlight
1. Select On or Off
VS7_AAA.book Page 93 Wednesday, August 3, 2005 5:10 PM
94
Settings
Keyguard
Keyguard prevents any keys from being accidentally pressed e.g.
when the phone is being carried. When Keyguard is enabled, the
Keyguard icon ( ) appears on the display. When a call is
received, Keyguard is temporarily disabled and you can answer the
call.
To enable Keyguard:
d Main menu > Settings > Phone settings > Key settings >
Keyguard
1. “Would you like to lock keypad?” 7 [0]9[5] (Yes)
OR
In standby mode:
1. Press and hold [0]
2. “Would you like to lock keypad?” 7 [0]9[5] (Yes)
To disable Keyguard:
When () appears on the display:
1. [0] 7 “Would you like to unlock?” 7 [0]9[5] (Yes)
Shortcut keys
Navigation key [1929394] can be used as a Shortcut key. It is
possible to assign a specific menu to Navigation key so that you can
access the menu directly from standby mode.
d Main menu > Settings > Phone settings > Key settings >
Shortcut keys
1. Select Navigation up, Navigation right, Navigation down or
Navigation left
2. Select the required menu
Note: Emergency calls can still be made with the Keyguard enabled but
there is no indication that you are dialling the number.
VS7_AAA.book Page 94 Wednesday, August 3, 2005 5:10 PM
95
Settings
Master reset
You can reset your phone to the factory settings, except for the
settings for Language, Time and date, and Calendar. User data such
as contacts, messages, call logs and data stored in My Media
remains on the phone.
Password is required for master reset. The factory set password is
0000.
Resetting
d Main menu > Settings > Phone settings > Master reset >
Reset settings
1. “Would you like to reset all phone settings?” 7 [0]9[5]
(Yes)
2. Enter the password 7 [0]9[5] (Ok)
Changing the password
d Main menu > Settings > Phone settings > Master reset >
Password setting
1. Enter the current password 7 [0]9[5] (Ok)
2. Enter a new password 7 [0]9[5] (Ok)
3. Enter the new password again 7 [0]9[5] (Ok)
VS7_AAA.book Page 95 Wednesday, August 3, 2005 5:10 PM
96
Settings
Display settings
Main display
You can change the wallpaper, brightness and position of the
operator name on the Main display.
Wallpaper
You can change the wallpaper on the standby screen.
d Main menu > Settings > Display settings > Main display >
Wallpaper
1. Select My Media or Download*1
2. [1929394] to scroll to the required wallpaper
3. To set: [5] (Select)
To view and set: [0] 7 [0]9[5] (Select)
Brightness
You can adjust the brightness of the display.
d Main menu > Settings > Display settings > Main display >
Brightness
1. [192] to adjust the brightness level 7 [0]9[5] (Select)
Operator name
You can change the position of your operator name on the standby
screen.
d Main menu > Settings > Display settings > Main display >
Operator name
1. Select Default, Upper left or Lower left
*1
VS7_AAA.book Page 96 Wednesday, August 3, 2005 5:10 PM
97
Settings
Front display
You can change the wallpaper, contrast and clock display on the
Front display.
External wallpaper
You can change the wallpaper on the Front display.
d Main menu > Settings > Display settings > Front display >
External wallpaper
1. Follow the procedures of Wallpaper in Main display on page
96.
Contrast
You can adjust the contrast of the Front display.
d Main menu > Settings > Display settings > Front display >
Contrast
1. [192] to adjust the contrast 7 [0]9[5] (Select)
Clock display
You can change the clock display style.
d Main menu > Settings > Display settings > Front display >
Clock display
1. Select Clock and Date or Digital
VS7_AAA.book Page 97 Wednesday, August 3, 2005 5:10 PM
98
Settings
Main menu icons
You can change menu icons or the background on Main menu
screen.
Changing icons
To change menu icons:
d Main menu > Settings > Display settings > Main menu icons
1. [1929394] to scroll to the required menu icon 7 [0]
2. Select My Media or Download*1
3. [1929394] to scroll to the required image
4. To set: [5] (Select)
To view and set: [0] 7 [0]9[5] (Select)
To change the background:
d Main menu > Settings > Display settings > Main menu icons
1. [5] (Options) 7 Select Attach full image
2. Repeat steps 2-4 in “To change menu icons:” on page 98
*1
Setting back to default
d Main menu > Settings > Display settings > Main menu icons
1. [5] (Options) 7 Select Set to default
2. “Would you like to set default?” 7 [0]9[5] (Yes)
Note: For downloading contents, visit http://box.panasonic.com/
VS7_AAA.book Page 98 Wednesday, August 3, 2005 5:10 PM
99
Settings
Themes
You can change the colour theme of the display.
d Main menu > Settings > Display settings > Themes
1. Select the required colour theme
Backlight time
You can set the length of time the display is illuminated by the
backlight.
d Main menu > Settings > Display settings > Backlight time
1. Select 10 seconds, 30 seconds or 60 seconds
Sounds & alerts
Ringtone/Message alert
You can change the tone and/or the volume of the ringtone for
incoming calls and the Message alert for incoming messages.
Changing the ringtone/Message alert
d Main menu > Settings > Sounds & alerts > Assign ringtone or
Message alert
1. Select My Media or Download*1
2. [192] to scroll to the required tone
3. [0] to listen to the tone 7 [6] (Cancel) to stop the tone and
return to the previous screen
4. [5] (Select)
*1
Note: For downloading contents, visit http://box.panasonic.com/
VS7_AAA.book Page 99 Wednesday, August 3, 2005 5:10 PM
100
Settings
Changing the ringtone/Message alert volume
d Main menu > Settings > Sounds & alerts > Incoming volume
or Message volume
1. [1929394] to adjust the volume (Volume 0-4, Step tone) 7
[0]9[5] (Select)
Warning tone
The Warning tone informs you of low battery.
d Main menu > Settings > Sounds & alerts > Warning tone
1. Select On or Off
Startup tone/Shutdown tone
The Startup tone sounds after switching on the phone, while the
Shutdown tone sounds after switching off the phone.
d Main menu > Settings > Sounds & alerts > Startup tone or
Shutdown tone
1. Select On or Off
Vibration alert
The phone does not ring but vibrates to inform you of incoming calls
and messages if you switch on vibration alert.
d Main menu > Settings > Sounds & alerts > Vibration alert
1. Select On or Off
VS7_AAA.book Page 100 Wednesday, August 3, 2005 5:10 PM
101
Settings
Calls
Call diverts
Voice, fax and data calls can be diverted to different numbers in
different situations. For example, you can divert calls to your voice
mailbox when you are out of reach.
Voice calls can be diverted in the following situations:
d Main menu > Settings > Calls > Call diverts
1. Select Divert voice, Divert all fax or Divert all data
(If Divert all fax or Divert all data is selected, go to step 3.)
2. Select the divert situation
3. Select Direct input or From contacts
4. If Direct input is selected: Enter the phone number to divert to
7 [0]
If From contacts is selected: Highlight the required contact 7
[5] (Select) 7 If the card has several phone numbers stored,
[192] to scroll to the required number 7 [0]9[5] (Select)
When the setting is enabled, the divert icon () is displayed on the
standby screen.
All calls Divert all incoming voice calls.
When busy Divert incoming voice calls when a call is in
progress.
When no reply Divert incoming voice calls if call is not answered.
When unreachable Divert incoming voice calls when phone is not in a
coverage area.
VS7_AAA.book Page 101 Wednesday, August 3, 2005 5:10 PM
102
Settings
To cancel each setting/check each status:
d Main menu > Settings > Calls > Call diverts
1. Select Divert voice 7 [192] to scroll to the required divert
situation
OR
[192] to scroll to Divert all fax or Divert all data
2. [5] (Options) 7 Select Off or Status
To cancel all the settings/check all the statuses:
d Main menu > Settings > Calls > Call diverts
1. Select Cancel all or Status all
Call waiting
If Call waiting is switched on, another call can be received while on a
call and multiple calls can be made.
d Main menu > Settings > Calls > Call waiting
The current status is displayed.
To accept the current status:
1. [0]
To change the setting:
1. [5] (Options) 7 Select Activate or Deactivate
The current status is displayed.
2. [0] to accept the current status
Any key answer
Calls can be answered by pressing any key except [Y], [0], [6]
(Cancel), [U], [O] and [P].
When Any key answer is off, calls can only be answered by pressing
[q] or [5] (Accept).
d Main menu > Settings > Calls > Any key answer
1. Select On or Off
VS7_AAA.book Page 102 Wednesday, August 3, 2005 5:10 PM
103
Settings
Active flip
You can answer a call by opening the phone and end a call by
closing the phone.
When Active flip is off, you need to press the appropriate key to
answer or end the call. When you are using a headset, you can
continue your conversation even while the phone is closed.
d Main menu > Settings > Calls > Active flip
1. Select On or Off
Auto answer
When you use the optional Personal Handsfree earpiece, you can
answer a call automatically.
d Main menu > Settings > Calls > Auto answer
1. Select On or Off
Send my number
You can choose whether or not to show your name and/or number to
another phone. You can comply with your network’s own setting if
you select Network set.
d Main menu > Settings > Calls > Send my number
1. Select Network set, On or Off
Call duration
You can check the duration of incoming or outgoing calls.
d Main menu > Settings > Calls > Call duration
1. Select Incoming or Outgoing
2. To reset the counter, [0]9[5] (Reset)
3. “Reset?” 7 [0]9[5] (Yes)
VS7_AAA.book Page 103 Wednesday, August 3, 2005 5:10 PM
104
Settings
Service charge
Cost left
You can check the remaining call units available if Max cost is set.
d Main menu > Settings > Calls > Service charge > Cost left
Call meter
You can check the total costs of calls made.
d Main menu > Settings > Calls > Service charge > Call meter
To reset the counter:
1. [0]9[5] (Reset) 7 “Reset total cost?” 7 [0]9[5] (Yes)
2. Enter the PIN2 code 7 [0]9[5] (Ok)
Price/unit
You can set your personal rate of the cost that the service provider
charges for one unit of call time.
d Main menu > Settings > Calls > Service charge > Price/unit
1. [0]9[5] (Edit) 7 Enter the PIN2 code 7 [0]9[5] (Ok)
2. Enter the currency 7 [0]
3. Enter the value 7 [0]9[5] (Ok)
To enter a decimal point: [r]
Max cost
You can set the maximum cost of calls allowed.
d Main menu > Settings > Calls > Service charge > Max cost
1. [0] 7 Enter the PIN2 code 7 [0]9[5] (Ok)
2. Enter the credit limit 7 [0]9[5] (Ok)
To disable the Max cost:
In step 1, [5] (Options) 7 Select Disable 7 [0]9[5] (Yes) 7
Enter the PIN 2 code 7 [0]9[5] (Ok)
VS7_AAA.book Page 104 Wednesday, August 3, 2005 5:10 PM
105
Settings
Connectivity
Infrared
You can transfer data between your phone and other infrared
enabled devices using an infrared wavelength connection.
You can send Contacts card, calendar events, and pictures/sound
clips/video clips stored in My Media.
Preparing for infrared connection
Place your phone and the other device
within the effective range of 20 cm.
• Verify there are no obstructions
between the two devices. Nearby
activated infrared devices may cause
interference.
• Ensure that the infrared ports of the
devices point at each other.
• On the receiving device, activate the Infrared port.
• If the other device is a computer, you need to set up infrared
connection on the computer. (Example: For Windows XP, Start >
Control Panel > Printers and Other Hardware > Wireless Link >
Infrared tab > All others to send files to your computer using
infrared communications)
Note: Some downloaded files may be protected under copyright laws.
These files should not be sent.
Caution: Though invisible to the eye, do not point the infrared beam at
anyone’s eyes.
Infrared Port
VS7_AAA.book Page 105 Wednesday, August 3, 2005 5:10 PM
106
Settings
Sending data via infrared
Prepare for infrared connection as described in “Preparing for
infrared connection” on page 105.
1. Select the item you wish to send
2. [5] (Options) 7 Select Send via
3. Select Infrared
The phone automatically begins infrared connection.
A confirmation message is displayed when complete.
Receiving data via infrared
Prepare for infrared connection as described in “Preparing for
infrared connection” on page 105.
To activate infrared:
You need to activate the infrared function before receiving data.
When infrared is set to on, the infrared icon ( ) appears on the
display. If infrared is unused for 10 minutes or the phone is once
switched off, it is automatically set to off and ( ) disappears.
d Main menu > Settings > Connectivity > Infrared
1. Select On
To receive data via infrared:
When ( ) is displayed, sender can begin transfer of data.
1. When transfer is started, “Would you like to receive data?” 7
[0]9[5] (Yes) to receive the data
2. When transfer is complete, “Data received” 7 Return to
standby screen 7 Received file name is displayed 7 [0]9[5]
(Save) to save the data
The received data is stored in respective menus or files.
VS7_AAA.book Page 106 Thursday, August 4, 2005 11:55 AM
107
Settings
Bluetooth® wireless technology
You can send and receive pictures, video and sound clips, etc.
between Bluetooth devices such as mobile phones and computers.
Use a Bluetooth headset or handsfree to talk wirelessly on your
phone whilst the phone is in your pocket or purse.
Setting up Bluetooth
You must first set up Bluetooth connections before using it for the
first time. Thereafter, go to Settings to switch Bluetooth setting on
and change your phone’s visibility to other Bluetooth devices.
d Main menu > Settings > Connectivity > Bluetooth > Settings
1. Select the required setting
*1To conserve battery life and avoid unwanted connections, “Show phone”
in Visibility is of 5 minutes duration.
Note: Although Bluetooth devices can connect within a 10 metre range,
walls or other nearby barriers may cause interference.
Check with local authorities before using Bluetooth wireless technology as
some countries may restrict the use of Bluetooth devices.
Keeping Bluetooth setting “On” consumes battery power more rapidly. To
conserve battery power, select Off in Bluetooth setting when not in use
(see page 107).
Bluetooth on/off Select On or Off.
Phone name
Use the default name or enter a name for your
phone that other devices will see when they
search for your phone.
Visibility*1
Choose Show phone to allow other Bluetooth
devices to find your phone when searching, or
select Hide phone to keep other Bluetooth
devices from finding it during a search.
VS7_AAA.book Page 107 Wednesday, August 3, 2005 5:10 PM
108
Settings
Pairing with other devices
Before you can transfer information between two Bluetooth devices,
they need to find each other and set up a connection. This is
referred to as “pairing”.
Ensure that the device in which you want to pair is switched on, and
its Bluetooth setting is activated.
If the other device is a computer, you need to set up Bluetooth
connection on the computer. (Example: For Windows XP, Start >
Control Panel > Printers and Other Hardware > Wireless Link >
Bluetooth tab > All others to send files to your computer using
Bluetooth communications)
d Main menu > Settings > Connectivity > Bluetooth > Paired
devices
1. “No paired device add new device?” 7 [5] (Ok)
The phone begins searching for devices and notifies you when it finds
the other device
2. [192] to scroll to the required device
3. [5] (Options) 7 Select Pair device
4. Enter the Pass key, if requested 7 [5] (Ok)
You may need to enter Pass keys on the both sides of connecting
devices
5. “Make device trusted?” 7 [5] (Yes)
Note: The Pass key may be between 1 and 16 digits except where stated
in the connecting device (normally headset) instructions when a 4 digit Pass
key is specified.
Making the device “trusted” on step 5 can cause future connections to occur
without notice. This may enable trusted devices to access your Contacts list
and data folders without prompting. You are advised to “trust” only your own
devices to avoid being prompted each time a call is received.
VS7_AAA.book Page 108 Wednesday, August 3, 2005 5:10 PM
109
Settings
Setting up the Bluetooth headset
The Bluetooth headset gives you wireless, handsfree operation.
Before you can use the headset you need to pair the headset and
the phone.
After switching on Bluetooth on the phone the Bluetooth icon ( )
appears on the screen. You now need to set up the headset.
1. Switch on the headset
See the headset instructions.
2. Make the headset discoverable
See the headset instructions.
3. On the phone, follow the instructions “Pairing with other
devices” on page 108
4. To receive calls on a Bluetooth headset: Highlight the device
name 7 [5] (Options) 7 Select Connect
OR
Press the button on the headset
() appears on the screen when the headset is connected.
See the headset instructions.
Once the headset and phone are connected, you can answer calls using
the headset. If the headset is on when you receive a call, the headset
rings. For information on how to answer a call with the headset, see the
headset instructions. To make a call with the headset, also see the
headset instructions.
VS7_AAA.book Page 109 Wednesday, August 3, 2005 5:10 PM
110
Settings
Sending/receiving data via Bluetooth
You can send and receive Contacts cards as business cards,
Calendar events, pictures, video and sound clips via Bluetooth.
To send data via Bluetooth:
1. Ensure that the receiving device is made visible
2. Highlight the item you wish to send
3. [5] (Options) 7 Select Send via
4. Select Bluetooth
If the phone has already searched for devices, it shows the list of
discovered devices.
If the phone has not yet searched, the phone automatically searches for
Bluetooth devices nearby, and displays the list of discovered devices.
[6] (Cancel) to stop search.
5. [192] to scroll to the intended device in the list 7 [5]
(Options)
6. Select Select
Connecting message appears, then when other device accepts, a
confirmation message displays when transfer is complete.
If the other device cannot receive data, an error message appears.
To receive data via Bluetooth:
1. Ensure that your phone’s Bluetooth is on and made visible
2. When transfer starts, “Would you like to receive data?” 7
[0]9[5] (Yes) to receive the data
3. When transfer is complete, “Data received” 7 [0]9[5] (Save)
to save the data
The received data is stored in respective menus or files.
Note: The phone may not allow you to copy, modify, transfer or forward
some copyrighted images, ringtones or other contents.
Note: Confirmation is required first if the paired device is not set as
authorised.
VS7_AAA.book Page 110 Wednesday, August 3, 2005 5:10 PM
