Panasonic Corporation of North America Common Trigger Box Users manual
Contents
Users manual
WV-TW37003P
POWER WIRELESS
Bluetooth
Bluetooth PAIRFD
CLEAR
ON OFF
ON
ANT
OFF
RESET
Operating Instructions
Common Trigger Box
Model No.
WV-TW37003
Preface
• The Common Trigger Box can be installed
in the car. By connecting with Pairing Dock
(option: WV-TW37004), pairing between the
BWC and Common Trigger Box is enabled,
and the BWC can be charged.
•By connecting the Common Trigger Box
and BWC via Bluetooth® communication,
the recording of BWC can be triggered by
external input. Also, the BWC’s operating
information can be informed to the external
devices.
• The Common Trigger Box can be connected
with the existing model SA366 via Wireless
LAN communication.
The model number and serial number of this
product may be found on the surface of the
unit.
You should note the model number and serial
number of this unit in the space provided and
retain this book as a permanent record of your
purchase to aid identification in the event of
theft.
Model No.
Serial No.
For U.S.A
WARNING:
• The installation shall be carried out in accor-
dance with all applicable installation rules.
• The connections should comply with local
electrical code.
•To prevent fire or electric shock hazard, do
not expose this apparatus to rain or mois-
ture.
• The apparatus should not be exposed to
dripping or splashing and no objects filled
with liquids, such as vases, should be
placed on the apparatus.
CAUTION:
• Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.
• Power source
To reduce the risk of fire or electric shock and annoying interference, use the recommended
accessory Panasonic MK 3 Lind Distribution Box & Cables only.
Mfr. Part#: ARB-PAPDC2462-3951
• Antenna requirements
Common Trigger Box (WV-TW37003) must be used with following antenna.
ANTENNA PLUS External 2.4 GHz and 5 GHz Wi-Fi antenna: AP-W-Q-S2-RP-BL or ANTENNA
PLUS External 2.4 GHz and 5 GHz Wi-Fi antenna: AP-W-M-S2-RP-WH.
Note:
The 20 cm {7-7/8 inches} minimum separation must be maintained between users and the
antenna. It is desirable that the antenna is located at least 1 m {40 inches} away from other Wi-Fi
antennas to avoid the interference.
• Before attempting to connect or install this
product, please read these instructions care-
fully and save this manual for future use.
• The model number is abbreviated in some
descriptions in this manual.
• For information about the installation about
this product, refer to the installation guide
provided by your contact dealer.
For U.S.A.
[Part 15 Subpart C ]
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment
and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed
and operated keeping the radiator at least 20cm or more away from person’s body.
[Part 15 Subpart E]
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC,
through the digital and analog baseband, and finally to the RF chip. Several special packets are
initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF
transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only
while one of the aforementioned packets is being transmitted. In other words, this device
automatically discontinue transmission in case of either absence of information to transmit or
operational failure.
Frequency Tolerance: ±20 ppm
MEDICAL:
Consult the manufacturer of any personal medical devices, such as pacemakers, to determine if they
are adequately shielded from external RF (radio frequency) energy. (The unit operates in the
frequency range of 2.412 GHz to 2.462 GHz, and the power output level is 0.1 watts.)
Do not use the unit in health care facilities if any regulations posted in the area instruct you not to do
so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF
(radio frequency) energy.
For Canada
[RSS-Gen]
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired opera-
tion of the device.
This radio transmitter (IC Number: 216A-WVTW37003) has been approved by Industry Canada to
operate with the antenna types listed below with the maximum permissible gain indicated. Antenna
types not included in this list, having a gain greater than the maximum gain indicated for that type, are
strictly prohibited for use with this device.
Antenna type: AP-W-Q-S2-RP-BL or AP-W-M-S2-RP-WH.
Gain: -0.8dBi (2.4GHz band), -8.1dBi(5GHz band)
Le présent émetteur radio (IC Number: 216A-WVTW37003) a été approuvé par Industrie Canada
pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain admissible maximal.
Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué,
sont strictement interdits pour l'exploitation de l'émetteur.
Type d’antenne: AP-W-Q-S2-RP-BL or AP-W-M-S2-RP-WH.
Gain: -0.8dBi (2.4GHz bande), -8.1dBi (5GHz bande)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
Specifications
Basic
Ambient temperature: –10°C to +50°C {14°F to 122°F}
Ambient operating humidity: 10% to 90% (no condensation)
Dimensions: 240 mm (W) x 88 mm (H) x 41 mm (D)
{9-7/16 inches (W) x 3-15/32 inches (D) x 1-5/8 inches (H)}
Mass: Approx. 700 g {1.54 lbs}
* With fixing plate
Wireless LAN
Communication Standard: IEEE802.11 a/b/g/n/ac
Access Control: CSMA/CA
Frequency Band(STA): 2.4 GHz band (ISM)
2412 to 2462 MHz, 5 MHz step 11ch
5.8 GHz band
5745 to 5825 MHz, 20 MHz step 5ch
5755 MHz, 5795 MHz (40 MHz BW), 5775 MHz (80 MHz BW)
SISO: 1x1, 1 stream
Antenna Connectors: RP-SMA Jack (Female)
Bluetooth
Bluetooth standard: Bluetooth Low Energy (Ver. 4.1)
Frequency band: 2.4 GHz
Modulation system: Frequency Hopping Spread Spectrum (FH-SS)
Profile: GATT/GAP
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Panasonic Corporation is under license.
CAN ICES-3(A)/NMB-3(A)
For Canada
[RSS-102]
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment
and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be
installed and operated keeping the radiator at least 20 cm or more away from person’s body.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques
(RF) CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une distance de 20 cm
ou plus entre le radiateur et le corps humain.
[RSS-247]
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz
and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN
devices.
Les radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité)
pour les bandes 5250-5350 MHz et 5650-5850 MHz, et ces radars pourraient causer du brouillage
et/ou des dommages aux dispositifs LAN-EL.
Panasonic System Communications
Company of North America,
Unit of Panasonic Corporation
of North America
www.panasonic.com/business/
For customer support, call 1.800.528.6747
Two Riverfront Plaza, Newark, NJ 07102-5490
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario, L4W 2T3 Canada
(905)624-5010
www.panasonic.ca
© Panasonic System Networks Co., Ltd. 2017
PGQX2144ZA NSh1216-0 Printed in Japan
Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying documents means that
used electrical and electronic products must not be mixed with general household
waste.
For proper treatment, recovery and recycling of old products, please take them to
applicable collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any
potential negative effects on human health and the environment.
For more information about collection and recycling, please contact your local
municipality.
Penalties may be applicable for incorrect disposal of this waste, in accordance with
national legislation.
: Direct current symbol
Precautions
Refer installation work to the dealer.
Installation work requires technique and experience. Failure to observe this may cause injury, or
damage to the product. Be sure to consult the dealer.
Caution:
• THE DC IN TERMINAL SHALL BE INSTALLED NEAR THE EQUIPMENT AND SHALL BE EASILY
ACCESSIBLE.
Standard accessories
Operating Instructions (this document) ...................................1 pc.
Warranty card ........................................................................1 pc.
Fixing plate ............................................................................1 pc.
Common Trigger Box fixing screw (of them, 1 for spare) .....5 pcs.
