Contents
- 1. User Manual 1
- 2. User Manual 2
User Manual 2
98
99
02
03
04
05
06
07
01
•
Phone Only:
Allows you to edit the lock code for Security. (The default lock code is the last
4 digits of your phone number.)
•
Calls & Services:
Allows you to edit the lock code for Restrictions. (The default lock code
is the last 4 digits of your phone number.)
5. If
Phone Only
is selected, enter the new four-digit code in the
Enter New
Code
eld. Enter the new four-digit code again in the
Re-enter New Code
eld to conrm your input, then press the OK Key [
SET
].
6. If
Calls & Services
is selected, enter the current lock code in the
Enter
Current Code
eld. Enter the new four-digit code in the
Enter New Code
eld. Enter the new four-digit code again in the
Re-enter New Code
eld,
then press the OK Key [
SET
].
RESTRICTIONS
Use the following procedure to congure Location Setting, Calls and Messages
restrictions.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
7. Security
.
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your
phone number.
3. Select
2. Restrictions
.
4. Enter the four-digit lock code again.
5. Select one of the following settings:
•
Location Setting:
Unlock Setting/Lock Setting.
•
Calls:
Incoming Calls/Outgoing Calls.
For Incoming Calls, set
Allow All
,
Contacts Only
or
Block All
.
For Outgoing Calls, set
Allow All
,
Contacts Only
or
Block All
.
•
Messages:
Incoming Messages/Outgoing Messages.
For Incoming Messages, set
Allow All
or
Block All
.
For Outgoing Messages, set
Allow All
or
Block All
.
6. Press the OK Key [
SET
].
PHONE LOCK SETTING
This setting species whether the phone should be locked whenever it is turned on.
Lock Mode prevents the unauthorized use of your phone. Once the phone is locked,
it is in restricted mode until the lock code is entered. You can still make emergency
calls.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
7. Security
.
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your
phone number.
3. Select
3. Phone Lock Setting
.
4. Select one of the following settings, then press the OK Key [
SET
].
•
Unlocked:
Phone is unlocked.
•
On Power Up:
Phone will lock when it is turned on.
LOCK PHONE NOW
Lock the phone now.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
7. Security
.
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your
phone number.
3. Select
4. Lock Phone Now
.
4. To unlock the phone from idle mode, then press the Right Soft Key
[
Unlock
] and enter the four-digit lock code.
RESTORE PHONE
To delete all User Data and restore all settings to their initial defaults:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
7. Security
.
2. Enter the four-digit lock code.
3. Select
5. Restore Phone
.
100
101
02
03
04
05
06
07
01
4. A conrmation message appears in the display, select
Yes
, and then press
the OK Key.
5. After reading the message that appears, press the OK Key.
6. Enter the four-digit lock code. The phone will turn o and then back on
again automatically.
SYSTEM SELECT
You can set your phone to search or roam on another network when you are not in your
home area. Leave this setting as default unless you want to alter the system selection as
instructed by your service provider.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
8. System Select
.
2. Select one of the following settings, then press the OK Key [
SET
].
•
Automatic:
Scans radio channels based on the Automatic setting.
•
Home Only:
Network is available only within your home area or home aliated area.
The automatic setting can be displayed as Automatic B and Automatic A depending
on PRL.
NAM SELECTION
Enables Auto NAM (Number Assignment Modules) or manually selects a NAM.
AUTO NAM
Automatically switches the phone to proper NAM when you have multiple NAM
registrations.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
9. NAM Selection
.
2. Select
1. Auto NAM
, then press the OK Key.
3. Select
On
or
O
, then press the OK Key [
SET
].
CHANGE NAM
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
7. Phone Settings
,
9. NAM Selection
.
2. Select
2. Change NAM
, then press the OK Key.
3. Press one of the following settings to select:
•
NAM1
: Set the phone to save the phone information that is set by default
•
NAM2
: Set the phone to save phone information that is set for the other phone
number
This setting is available only when you register two cell phone numbers on your
phone.
CALL SETTINGS
ANSWER OPTIONS
To determine how to answer an incoming call:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
1. Answer Options
.
2. Select
Any Key
or
Auto with Handsfree
, then press the OK Key [
MARK
].
Any Key is the default setting for this device.
3. Press the Left Soft Key
[
Done
].
•
Auto with Handsfree will function after about ve seconds.
•
Auto with Handsfree is available only when a headset or handsfree device is
connected.
•
To answer all incoming calls, press the SEND Key .
AUTO RETRY
To set a period of time the phone waits before automatically redialing when an
attempted call fails:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
2. Auto Retry
.
2. Select one of the following settings, then press the OK Key [
SET
].
10 Seconds
/
30 Seconds
/
60 Seconds
/
O
102
103
02
03
04
05
06
07
01
TTY MODE
You can attach a TTY device to your phone enabling you to communicate with parties
also using a TTY device. A phone with TTY support is able to translate typed characters
to voice. Voice can also be translated into characters and then displayed on the TTY.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
3. TTY Mode
.
2. Select one of the following settings, then press the OK Key [
SET
].
TTY Full
/
TTY + Talk
/
TTY + Hear
/
TTY O
ONE TOUCH DIAL
To initiate a speed dial call by holding down the speed dial digit:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
4. One Touch Dial
.
2. Select
On
or
O
, then press the OK Key [
SET
].
If One Touch Dial is disabled, a speed dial call will function by entering the speed dial
number on the QWERTY Keypad, and then press the SEND Key .
VOICE PRIVACY
Voice Privacy provides advanced voice encryption to prevent eavesdropping.
To turn the voice privacy feature On or O:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
5. Voice Privacy
.
2. Select
On
or
O
, then press the OK Key [
SET
].
DTMF TONES
To set the Key Tone length and touch tone playback speed:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
6. DTMF Tones
.
2. Select one of the following settings, then press the OK Key [
SET
].
•
Normal:
Sends out a tone for a xed period of time even if you continue to press the key.
•
Long:
Sends out a continuous tone for the duration the key is pressed and held.
ASSISTED DIALING
To set the Assisted Dialing feature On or O:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
8. Call Settings
,
7. Assisted Dialing
.
2. Press the Directional Key left or right to select
On
or
O
. To view the help
for
Assisted Dialing
, press the Right Soft Key
[
Help
].
3. When you set
Assisted Dialing
to
On
, press the Directional Key down and
then press the Left Soft Key
[
Set
] to edit
COUNTRIES
.
Press the Left Soft Key
[Details] to view the information.
4. Select the desired Country and press the OK key.
5. Press the OK Key to set
Assisted Dialing
.
MEMORY
PHONE MEMORY
Allows you to manage the memory usage for pictures, ringtones, sounds and contacts
on your Phone Memory.
PHONE MEMORY USAGE
To check the available Phone Memory capacity, used capacity and total capacity:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
9. Memory
,
1. Phone Memory
.
2. Select
1. Memory Usage
.
3. Press the OK Key to return to the previous screen.
DELETING AND MOVING FILES
To delete les stored in Phone Memory or to move les from Phone Memory to Card
Memory:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
9. Memory
,
1. Phone Memory
.
104
105
02
03
04
05
06
07
01
2. Press the Directional Key up or down to select
My Pictures
,
My
Ringtones
,
My Sounds
or
My Contacts
, then press the OK Key.
3. Press the Right Soft Key
[
Options
].
4. Select
1. Erase
to delete a le.
5. Select a le, press the OK Key [
MARK
] or the Right Soft Key
[
Mark
All
],
then press the Left Soft Key
[
Done
].
6. Select
Yes
and press the OK Key.
PHONE INFO
MY NUMBER
To view your phone number:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
0. Phone Info
,
1. My Number
.
2. The following information appears:
Mobile Device Number (MDN)
/
Mobile Identication Number (MIN)
/
Verizon Wireless
SW/HW VERSION
To view your device HW/SW information:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
0. Phone Info
,
2. SW/HW Version
.
2.
Software Version
/
PRL Version
/
ERI Version
/
Browser Version
/
Media
Center Version
/
MSUI Version
/
HW Version
/
MEID
are displayed.
3. Press the OK Key to return to the previous screen.
ICON GLOSSARY
To view all the icons and their meanings:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
0. Phone Info
,
3. Icon Glossary
.
2. Press the OK Key to return to the previous screen.
Please refer to Display Indicators on page 14 for more details about the icons.
SOFTWARE UPDATE
The Software Update option allows you to download and update the software in your
phone automatically. Only the internal software is updated; Contact entries or other
information saved to your phone will NOT be deleted.
STATUS
Check the latest Software Download/Update status.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
0. Phone Info
,
4. Software Update
.
2. Select
1. Status
.
CHECK NEW
To check Download Server for new Software updates:
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
,
0. Phone Info
,
4. Software Update
.
2. Select
2. Check New
.
SET - UP WIZARD
The Set-up Wizard menu allows you to set the following menus for Settings & Tools
with simple operation.
1. From idle mode, press the
[
MENU
], then select
9. Settings & Tools
.
2. Select
Set-up Wizard
, then press the OK Key.
•
CALL SOUNDS:
Select
Ring Only
,
Vibrate Only
,
Ring and Vibrate
or
Be Silent
, then press
the OK Key [
SET
] or press the Right Soft Key
[
Skip
] to go to the next
setting. If you select
Ring Only
or
Ring and Vibrate
, the ringtone selection
screen will be displayed. Select a desired ringtone, then press the OK Key
[
SET
].
106
TXT8035PP
5
Tunes & Tones
Games
Mobile Web
Browse & Download
Extras
Media Center Info
MENU FUNCTION
Your phone provides a unique feature - Media Center - that enables
you to download ringtones, wallpapers, games and more from your
network to your phone. Please contact your service provider for the
availability of these services.
•
DISPLAY THEMES:
Select
White
,
Modern Olive
or
Amoled
, then press the OK Key [
SET
] or
press the Right Soft Key
[
Skip
] to go to the next setting. To preview
the selected display theme, press the Left Soft Key
[
Preview
].
•
MENU LAYOUT:
Select
Tab, List
and
Grid
, then press the OK Key [
SET
] or press the Right
Soft Key
[
Skip
] to go to the next setting. To preview the selected Main
Menu Layout, press the Left Soft Key
[
Preview
].
•
CLOCK FORMAT:
Select
Analog
,
Large Analog
,
Digital 12
,
Large Digital 12
,
Digital 24
,
Large
Digital 24
or
O
, then press the OK Key [
SET
] or press the Right Soft Key
[
Skip
] to complete set-up. To preview the selected clock format, press
the Left Soft Key
[
Preview
].
108
109
02
03
04
05
06
07
01
TUNES & TONES
The Tunes & Tones menu allows you to manage ringtones, and sound les. It also allows
you to get new ringtones.
GET NEW RINGTONES
To connect to
Media Center
and download new ringtones:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
1. Get New Ringtones
.
2. If you have not downloaded any ringtones or ringtone applications previously,
press
1. Get New Applications
and follow the prompts.
V CAST TONES
V CAST
Tones application lets you preview and buy from Verizon Wireless’ extensive
catalog of
Ringback Tones
. Download, manage, preview, and play the latest Tones
content right from your mobile device
1. From idle mode, press the
[
MENU
], then select
1.Media Center
,
1.Tunes & Tones
,
1. Get New Ringtones
,
V CAST
.
2. Select Install and follow the on-screen prompts.
GET RINGBACK TONES
To connect to Media Center and Download new ringback tones:
1. From idle mode, press the
[
MENU
], then select
1.Media Center
,
1. Tunes & Tones
,
2. Get Ringback Tones
.
2. Follow the on-screen prompts.
MY RINGTONES
TO PLAY DOWNLOADED TUNES OR TONES:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
3. My Ringtones
.
2. Select the tune or tone you want to play, then press the OK Key [
PLAY
].
3. To stop, press the OK Key [
STOP
].
TO ERASE DOWNLOADED TUNES OR TONES:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
3. My Ringtones
.
2. Select the tune or tone you want to erase, then press the Right Soft Key
[
Options
].
3. Select
1. Erase
, then select
Yes
and press the OK Key.
The preloaded Ringtones cannot be erased.
TO ASSIGN DOWNLOADED TUNES OR TONES:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
3. My Ringtones
.
2. Select the desired ringtone, then press the Left Soft Key
[
Set
As
].
3. Select one of the following options, then press the OK Key.
•
1. Ringtone:
Set as a ringtone. A conrmation message appears.
•
2. Contact ID:
The
SET AS CONTACT ID
screen appears. Select the Contact you want to
assign the ringtone to, then press the OK Key.
•
3. Alert Sounds:
Press the corresponding number key to set the ringtone for one of
the following:
All Messages
/
TXT Message
/
Multimedia Message
/
Voicemail
MY SOUNDS
To select a desired sound:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
4. My Sounds
.
2. Highlight the desired sound, then press the OK Key [
PLAY
] to hear the sound.
Press the OK Key [
STOP
] to stop playing the sound.
3. Press the Right Soft Key
[
Options
] to access the following options:
•
Send:
Allows you to send the sound with a picture message.
110
111
02
03
04
05
06
07
01
•
Send via Email:
Allows you to send the sound via Email.
•
To Online Album:
Allows you to upload the selected tone to the online server.
•
Rename:
Renames the sound.
•
Lock
/
Unlock:
Locks or unlocks the selected sound in your phone.
•
Erase:
Deletes the sound.
•
Erase All:
Deletes all the sounds from your phone.
•
File Info:
Displays information about the selected sound.
Preloaded sound options: Send, To Online Album and File Info. The preloaded sounds
cannot be erased or renamed.
RECORDING NEW SOUNDS
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
4. My Sounds
.
2. Press
1. Record New
.
3. Press the OK Key to begin recording. When done, press the OK Key [
STOP
] to
nish recording. The recording is automatically saved to your My Sounds list.
4. Your recording is saved with a number. To rename your recording, scroll to it
with the Directional Key in the My Sounds menu, then press the Right
Soft Key
[
Options
].
5. Press
4. Rename
.
6. Press and hold the CLR Key to erase the number, enter the new name for
your recording, then press the OK Key.
SETTING SOUNDS
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
1. Tunes & Tones
,
4. My Sounds
.
2. Select the sound you want to set, press the Left Soft Key
[
Set As
], then
select one of the following options and press the OK Key.
•
Ringtone:
Set as a ringtone. A conrmation message appears.
•
Contact ID
: The
SET AS CONTACT ID
screen appears. Select the Contact you want to
assign the ringtone to, then press the OK Key.
•
Alert Sounds:
Press the corresponding number key to set the ringtone for one of the
following options:
All Messages
/
TXT Message
/
Multimedia Message
/
Voicemail
GET NEW PICTURES
To connect to Media Center and download a variety of Pictures (images):
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
2. Pictures
2. Select
1. Get New Pictures
,
1. Get New Applications
, then follow the
on-screen prompts.
The downloaded application will be included in the list when you access:
1. Get New Pictures > 1. Get New Applications.
MY PICTURES
The My Pictures menu allows you to view all the pictures you have taken, store selected
images in your phone, send pictures to the Online Album, delete images and access
additional picture options.
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
2. Pictures
,
2. My Pictures
.
2. Select the desired picture, then press the Right Soft Key
[
Options
] to
access the following options.
•
Send:
Allows you to send a picture with following options:
Picture Message
/
To Online Album
/
Via Email
/
Via Bluetooth
•
Set As:
Assigns the selected picture to display for specic tasks (
Wallpaper
/
Picture ID
).
•
Take Picture:
Take a new picture.
•
Get New Pictures:
Download various pictures.
•
Manage Pictures:
To manage your picture les with following options:
Erase
/
Lock
/
Unlock
•
Rename:
Rename the selected picture.
112
113
02
03
04
05
06
07
01
•
File Info:
Displays the following information about the selected picture:
File Name
/
Date
/
Time
/
Resolution
/
Size
DELETING A PICTURE
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
2. Picture
,
2. My Pictures
.
2. Select the picture you want to erase, then press the Left Soft Key
[
Erase
].
3. “
ERASE PICTURE FROM MY PICTURES AND SETTINGS?
” will appear on
your display.
4. Select
Yes
and press the OK Key. A conrmation message appears.
TAKE PICTURE
1. To access the camera, press the Camera Key .
If the keypad is locked, unlock the keypad by pressing the OK Key. Press the Camera
Key
to access the camera viewnder.
2. Point the camera lens at your subject. You can check the picture framing
through the display screen.
• Press the Directional Key
left or right to zoom in or out (except when resolution
is set to 1280x960).
• Press the Right Soft Key
[
Options
], and choose from the following:
1. Resolution:
1280x960 / 640x480 / 320x240 / 160x120
2. Self Timer:
O / 3 Seconds / 5 Seconds / 10 Seconds
3. Brightness:
Press the Directional Key
left or right to adjust the brightness from the
following: -2 / -1 / 0 / +1 / +2
4. White Balance:
Press the Directional Key
left or right to select from the following:
Auto / Sunny / Cloudy / Tungsten / Fluorescent / Darkness
5. Shutter Sound:
Allows you to select the shutter sound from the following:
Shutter / Silent / Say “Cheez” / Ready! 123
6. Color Eects:
Press the Directional Key
left or right to select color eects from the
following: Normal / Antique / Black and White / Negative
7. Capture Mode:
Press the Directional Key
up or down to select
Landscape
or
Portrait
,
then press the OK Key.
3. Press the OK Key [
TAKE
] to take the picture.
4. After taking the picture, it will be displayed. To save the picture, press the
Left Soft Key
[
Save
]. To take another picture without saving the picture
you just took, press the Right Soft Key
[
Erase
]. To send the picture to
someone, press the OK Key [
SEND
].
ONLINE ALBUM
To access Online Album:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
2. Picture
,
4. Online Album
.
2. Follow the on-screen prompts.
GAMES
DOWNLOADING NEW GAMES
To download games and applications:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
3. Games
.
2. Select
1. Get New Applications
, then press the OK Key.
3. Follow the on-screen prompts.
PLAYING DOWNLOADED GAMES
1. To play the game you downloaded, from the Games menu, select the game
then press the OK Key [
PLAY
] to run the application.
DELETING A DOWNLOADED GAME
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
3. Games
.
114
115
02
03
04
05
06
07
01
2. Select the application you want to remove, then press the Right Soft Key
[
Options
].
3. Select
Erase
or
Cancel Subscr.
and press the OK Key. With
Yes
highlighted,
press the OK Key to remove the application.
Applications may vary by wireless device model.
MOBILE WEB
Now you can access news, sports, weather and Email from your phone. Mobile Web
keeps you updated by providing access to up-to-date information when you subscribe
to Internet service with your service provider. Please contact your service provider for a
list of available websites and service details.
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
4. Mobile Web
.
Shortcut:
From idle mode, press the Directional Key
up to access Mobile Web.
2. Follow the on-screen prompts.
BROWSE & DOWNLOAD
DOWNLOADING NEW APPLICATIONS
To download tools that can help you navigate to entertainment spots, restaurants, and
provide you with up-to-date weather information:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
5. Browse & Download
.
2. Select
1. Get New Applications
, then press the OK Key.
3. Follow the on-screen prompts.
Links to download Backup Assistant, Mobile Email, Bing Search and VZ Navigator are
preloaded on your phone.
EXTRAS
DOWNLOADING NEW APPLICATIONS
To download Applications:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
,
6. Extras
.
2. Select
1. Get New Applications
, then press the OK Key.
3. Follow the on-screen prompts.
MEDIA CENTER INFO
To view Application Memory, Phone Memory, View Log and Help information:
1. From idle mode, press the
[
MENU
], then select
1. Media Center
.
2. Press the Right Soft Key
[
Info
].
3. Select one of the following options, then press the OK Key.
App. Memory
/
Phone Memory
/
View Log
/
Help
117
02
03
04
05
06
07
01
TXT8035PP
6
This chapter addresses Voicemail, TXT, Picture, Video,
Voice Messaging functions including:
MESSAGING MENU
When a New Message Arrives
New Message
Messages
Inbox
Sent
Drafts
Erase All
Voicemail
Mobile IM
Email
Chat
Settings
WHEN A NEW MESSAGE ARRIVES
1. The following display appears when a new message arrives.
2. To display the message, select
View Now
and then press the
OK Key.
NEW MESSAGE
TXT MESSAGE
1. From idle mode, press the Left Soft Key
[
Message
], then select
New
Message
and press the OK Key. Or from idle mode, press the
[
MENU
],
then press
2. Messaging
,
1. New Message
.
2. Select
1. TXT Message
.
Shortcut:
From idle mode, press the TXT Composer Key .
3. Under
To
, input the phone number or email address of the recipient, then press
the OK Key.
• By pressing the Right Soft Key
[
Add
], you can choose from the following:
1. From Contacts:
Search for a phone number which is stored in the Contact List.
2. Recent Calls:
Search for a phone number which is stored in the Recent Calls menu.
3. Groups:
Search for a group stored in the Groups menu.
4. To Contacts:
Save the number or email address to the Contact List that you have
entered in the To eld.
4. Under
Text
, input your message.
• By pressing the Right Soft Key
[
Options
], you can choose from the following:
1. Insert Quick Text:
Inserts predened sentences in the text message.
2. Save As Draft:
Save the text message to Drafts.
3. Add:
Allows you to add a Graphic, Sound or Name Card.
4. Format Text:
Allows you to edit Alignment, Font Size, Font Style, Font Color or
Background Color.
5. Priority Level:
Select High or Normal, then press the OK Key.
6. Cancel Message:
Cancel the message and select whether to save it in Drafts.
5. When completed, press the OK Key [
SEND
] to send the text message.
118
119
02
03
04
05
06
07
01
PICTURE MESSAGE
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
1. New
Message
.
2. Select
2. Picture Message
.
3. Under
To
, input the phone number or email address of the recipient, then press
the OK Key.
• By pressing the Right Soft Key
[
Add
], you can choose from the following:
1. From Contacts:
Search for a phone number which is stored in the Contact List.
2. Recent Calls:
Search for a phone number which is stored in the Recent Calls menu.
3. Groups:
Search for a group stored in the Groups menu.
4. To Online Album:
Send the picture message to your Online Album.
5. To Contacts:
Save the number or email address to the Contact List that you have
entered in the To eld.
4. Under
Text
, input your message, then press the Directional Key down.
5. Under
, press the Left Soft Key
[
My Pics
] to select the picture you
would like to send, then press the OK Key. Press the Directional Key down.
6. Under
Sound
, press the Left Soft Key
[
Sounds
] to select the sound you
would like to send, then press the OK Key. Press the Directional Key down.
7. Under
Name Card
, press the Left Soft Key
[
Add
], select
1. My Name
Card
or
2. From Contacts
, then press the OK Key. Select the desired card and
press the OK Key. Press the Directional Key down.
8. Under
Subject
, input the message subject.
9. Press the Right Soft Key
[
Options
] to access the following:
•
Preview:
Shows the picture message before it is sent.
•
Save As Draft:
Save the picture message to Drafts.
•
Insert Quick Text:
Inserts predened sentences in the picture message.
•
Add Slide:
Allows you to insert multiple picture messages.
•
Priority Level:
Select High or Normal, then press the OK Key.
•
Remove Picture:
Removes an inserted picture from the Picture eld.
•
Remove Sound:
Removes an inserted sound from the Sound eld.
•
Remove Name Card:
Removes an inserted name card from the Name Card eld.
•
Remove Slide:
Removes an inserted slide message.
•
Cancel Message:
Cancel the message and select whether to save it in Drafts.
10. When completed, press the OK Key [
SEND
] to send the picture message.
VOICE MESSAGE
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
1. New
Message
.
2. Select
3. Voice Message
.
3. Press the OK Key to start recording a voice memo, then press the OK Key [
STOP
]
to nish recording and insert the voice memo into the voice message.
4. Under
To
, input the phone number or email address of the recipient, then press
the OK Key.
• By pressing the Right Soft Key
[
Add
], you can choose from the following:
1. From Contacts:
Search for a phone number which is stored in the Contact List.
2. Recent Calls:
Search for a phone number which is stored in the Recent Calls menu.
3. Groups:
Search for a group stored in the Groups menu.
4. To Contacts:
Save the number or email address to the Contact List that you have
entered in the To led.
5. Under
Text
, input your message, then press the Directional Key down.
6. Under
Name Card
, press the Left Soft Key
[
Add
], select
1. My Name
Card
or
2. From Contacts
, then press the OK Key. Select the desired card, press
the OK Key. Swipe the Directional Key down.
7. Under
Subject
, input the message subject.
8. Press the Right Soft Key
[
Options
] to access the following:
•
Review:
Shows the voice message before it is sent.
•
Save As Draft:
Save the voice message to Drafts.
•
Insert Quick Text:
Inserts predened sentences in the voice message.
•
Priority Level:
Select High or Normal, then press the OK Key.
•
Remove Recording:
Removes an inserted recording from the Voice eld.
•
Remove Name Card:
Removes an inserted name card from the Name Card eld.
•
Cancel Message:
Cancel the message and select whether to save it in Drafts.
120
121
02
03
04
05
06
07
01
9. When completed, press the OK Key [
SEND
] to send the voice message.
MESSAGES
The
Messages
menu is displayed when
Messages View
is set to
By Contacts
which
is the default setting. All received and sent messages are stored under the
Messages
menu by contact name.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
2. Messages
.
2. Select a message and press the OK Key [
OPEN
] to view the message.
To reply to the sender, press the Left Soft Key
[
Reply
], select
1. TXT
Message
,
2. Picture Message
or
3. Voice Message
, then press the OK Key.
3. Press the Directional Key up or down to highlight the text entry eld, enter
the message and press the OK Key [
SEND
] to reply. Or press the Directional
Key up or down to highlight the message contents, press the Directional
Key left or right to view the next or previous message. Press the OK Key
[
OPEN
] to view the message with full screen or press the Left Soft Key
[
Reply
] to reply to the sender.
4. While viewing the message with full screen, press the OK Key [
Reply
/
SEND
]
to reply or send the message. To erase the message, press the Left Soft Key
[
Erase
], select
Yes
, then press the OK Key.
5. When navigating through the
Messages
menu, press the Right Soft Key
[
Options
] to display the following available options. Options are dependent on
the message type and may be dierent from each eld.
•
Erase Sent
/
Received:
Allows you to delete unlocked sent and received messages.
•
Erase Drafts:
Allows you to delete unlocked messages stored in Drafts.
•
Erase All Messages:
Allows you to delete unlocked messages stored in your phone.
•
Erase:
Deletes the message.
•
Add To Contacts:
Saves the phone number to the Contact List.
•
Manage Messages:
Allows you to manage messages with following options:
-
Erase:
Deletes the messages.
-
Lock:
Locks the messages.
-
Unlock: Unlocks the messages.
-
Mark as Read
/
Mark as Unread:
Marks the messages as read or unread.
•
Sort Alphabetically
/
Sort By Time:
Sorts the list in alphabetical order or by time.
•
Messaging Menu:
Returns to the previous Messaging screen.
•
Insert Quick Text:
Inserts predened sentences in the message.
•
Save As Draft:
Save the message to Drafts.
•
Add:
Allows you to add a Graphic, Sound or Name Card.
•
Format Text:
Allows you to edit Alignment, Font Size, Font Style, Font Color or Background
Color.
•
Add Recipient:
Allows you to add multiple recipients in the To eld.
•
Priority Level:
Select High or Normal, then press the OK Key.
•
Cancel Message:
Cancels the message and select whether to save it in Drafts.
•
Play Again:
Replays the sound attached to a picture or voice message.
•
Forward:
Forwards the message to another recipient.
•
Reply w. copy:
Allows you to reply to the recipient including the original message.
•
Save Picture:
Allows you to save the attached picture to your phone.
•
Save Graphic:
Allows you to save the attached graphic to your phone.
•
Save Sound:
Allows you to save the attached sound to your phone.
•
Save as Ringtone:
Allows you to save the sound to your phone as a ringtone.
•
View Name Card:
Shows the attached name card.
•
Save Name Card:
Allows you to save the attached name card to your phone.
•
Set As:
Allows you to set the attached picture as Wallpaper or Picture ID, and attached
sound as Ringtone, Contact ID or Alert Sounds.
•
Save As Quick Text:
Allows you to save the received message as quick text.
•
Lock / Unlock:
Locks or unlocks the message.
•
Extract Addresses:
Allows you to extract contacts from the message, then you can save
them to the Contact List, make a call or send the message.
•
Message Info:
Shows the message information.
•
Reply to All:
Allows you to reply to all senders.
•
Resend:
Resends the message.
122
123
02
03
04
05
06
07
01
INBOX
The
Inbox
menu is displayed when
Messages View
is set to
By Time
. The
Inbox
manages received text, picture and web alert messages.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
2. Inbox
.
2. Select a message and press the OK Key [
OPEN
] to view the message.
To delete the message, press the Left Soft Key
[
Erase
], select
Yes
, then
press the OK Key.
3. Press the Directional Key left or right to view the next or previous
message.
4. To reply to the sender, press the OK Key [
Reply
], select
1. TXT Message
,
2. Picture Message
or
3. Voice Message
, then press the OK Key.
5. When navigating through the
Inbox
menu, press the Right Soft Key
[
Options
] to display the following available options. Options are dependent on
the message type and may be dierent from each eld.
•
Erase Inbox:
Allows you to delete unlocked messages stored in the Inbox.
•
Erase Sent:
Allows you to delete unlocked messages stored in Sent.
•
Erase Drafts:
Allows you to delete unlocked messages stored in Drafts.
•
Erase All:
Allows you to delete unlocked messages stored in your phone.
•
Reply:
Allows you to reply to the recipient.
•
Reply w. copy:
Allows you to reply to the recipient including the original message.
•
Forward:
Forwards the message to another recipient.
•
Add To Contacts:
Saves the phone number to the Contact List.
•
Extract Addresses:
Allows you to extract contacts from the message, then you can save
them to the Contact List, make a call or send the message.
•
Message Info:
Shows the message information.
•
Manage Inbox:
Allows you to manage messages with following options:
Erase:
Deletes the messages.
Lock:
Locks the messages.
Unlock:
Unlocks the messages.
Mark as Read:
Marks the messages as read.
Mark as Unread:
Marks the messages as unread.
•
Sort By Sender:
Sorts the list by sender.
•
Sort By Time:
Sorts the list by time.
•
Sort By Size:
Sorts the list by size.
•
View By Contacts:
Changes the Messages View setting to By Contacts.
•
Play Again:
Replays the sound attached to a picture or voice message.
•
Erase:
Deletes the message.
•
Save Picture:
Allows you to save the attached picture to your phone.
•
Save Graphic:
Allow you to save the attached graphic to your phone.
•
Save Sound:
Allows you to save the attached sound to your phone.
•
Save as Ringtone:
Allows you to save the sound to your phone as ringtone.
•
View Name Card:
Shows the attached name card.
•
Save Name Card:
Allows you to save the attached name card to your phone.
•
Set As:
Allows you to set the attached picture as Wallpaper or Picture ID, and attached
sound as Ringtone, Contact ID or Alert Sounds.
•
Save As Quick Text:
Allows you to save the received message as quick text.
•
Lock
/
Unlock:
Locks or unlocks the message.
SENT
The
Sent
menu is displayed when
Messages View
is set to
By Time
.
Sent
manages
already sent or waiting to be sent messages.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
3. Sent
.
2. Select a message and press the OK Key [
OPEN
] to view the message. To delete
the message, press the Left Soft Key
[
Erase
], select
Yes
, then press the
OK Key.
3. Press the Directional Key left or right to view the next or previous
message.
4. To send the message, press the OK Key [
SEND
].
5. When navigating through the Sent menu, press the Right Soft Key
[
Options
] to display the following available options. Options are dependent on
the message type and may be dierent from each eld.
124
125
02
03
04
05
06
07
01
•
Reply to All:
Allows you to reply to all senders.
•
Forward:
Forwards the message to another recipient.
•
Resend:
Resends the message.
•
Lock
/
Unlock:
Locks or unlocks the message.
•
Add To Contacts:
Saves the phone number to the Contact List.
•
Erase Sent:
Allows you to delete unlocked messages stored in Sent.
•
Message Info:
Shows the message information.
•
Play Again:
Replays the sound attached to a picture or voice message.
•
Erase:
Deletes the message.
•
Save As Quick Text:
Allows you to save the received message as quick text.
•
View Name Card:
Shows the attached name card.
DRAFTS
The
Drafts
menu manages draft messages. If message composition is interrupted by a
voice call or other events, the message being composed is automatically saved in Drafts.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
3. Drafts
.
2. Select a message and press the OK Key [
EDIT
] to edit the message. To delete
the message, press the Left Soft Key
[
Erase
], select
Yes
, then press the
OK Key.
3. When navigating through
Drafts
menu, press Right Soft Key
[
Options
]
to display the following available options.
•
Send:
Sends the message.
•
Lock
/
Unlock:
Locks or unlocks the message.
•
Add To Contacts:
Saves the phone number to the Contact List.
•
Erase Drafts:
Allows you to delete unlocked messages stored in Drafts.
ERASE ALL
To erase all messages stored in your phone:
1. From idle mode, press the
[
MENU
], then select
2. Messaging
.
2. Press the Right Soft Key
[
Options
] to display the following available
options. Options are dependent on the
Messages View
setting.
•
Erase Sent / Received:
Select All Messages or Only Read Messages, then press the OK Key.
•
Erase All
/
Erase All Messages:
Select All Messages including Unread or All except Unread
Messages, then press the OK Key.
3. A conrmation message appears.
Locked messages cannot be erased.
VOICEMAIL
The
Voicemail
menu shows the number of new voicemail message recorded in your
voicemail box.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
5. Voicemail
.
2. To delete information about new voicemail, press the Left Soft Key
[
Clear
], select
Yes
, then press the OK Key.
ACCESSING YOUR VOICEMAIL BOX
1. From idle mode, press the
[
MENU
], select
2. Messaging
,
4. Voicemail
, then press the OK Key [
CALL
]. Or dial *86 and press the SEND
Key .
2. Follow the prompts to enter your password and retrieve your messages.
Shortcut:
From idle mode, press and hold 1
to access your voicemail box.
126
127
02
03
04
05
06
07
01
MOBILE IM
Mobile IM menu allows you to send and receive instant messages using one of the
following messenger services:
• AIM
• WL Messenger
• Yahoo!®
LAUNCHING MOBILE IM
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
5. Mobile IM
.
2. Follow the on-screen prompts.
EMAIL
The
Email
menu allows you to send and receive Email using Mobile Web.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
6. Email
.
2. Select
Mobile Email
or
Mobile Web Mail
, then press the OK Key.
•
Mobile Email:
Connects to Mobile Web via Brew Smartlink.
•
Mobile Web Mail:
Connects to Mobile Web via WAP Browser.
3. Follow the on-screen prompts.
CHAT
The
Chat
menu allows you to chat with Internet Messenger users.
1. From idle mode, press the
[
MENU
], then select
2. Messaging
,
7. Chat
.
2. The Browser launches.
3. Select one of the displayed chat rooms, then press the OK Key.
4. Follow the on-screen prompts.
SETTINGS
The
Settings
menu allows you to congure settings for messages sent or received on
your phone. To access message settings:
1. From idle mode, press the
[
MENU
], then select
2.
Messaging
.
2. Press the Left Soft Key
[
Settings
] to display available menus.
3. Select one of the following menus, then press the OK Key.
MESSAGES VIEW
1. Select
By Time
or
By Contacts
, then press the OK Key.
•
By Time:
Sorts received and sent messages into Inbox and Sent folders by time.
•
By Contact:
Groups all received and sent messages by each contact.
ENTRY MODE
Allows you to set the default Entry Mode for messaging. For example, if Abc mode is set
to Entry Mode, its icon will appear in the text entry eld as default.
1. Select
Abc
,
ABC
or
123
, then press the OK Key.
AUTO SAVE SENT
1. Select
On
,
O
or
Prompt
, then press the OK Key.
•
On:
All sent messages are saved in Sent.
•
O:
All sent messages are not saved in Sent.
•
Prompt:
The Yes or No dialogue box will be displayed after sending a message.
AUTO ERASE INBOX
Allows you to set whether Inbox messages are deleted automatically when new
messages arrive and Inbox is full.
1. Select
On
or
O
, then press the OK Key.
•
On:
The oldest message will be deleted from the Inbox automatically once full.
•
O:
The oldest message will not be deleted automatically from the Inbox once full.
MESSAGING FONT SIZE
Allows you to set the message font size.
128
129
02
03
04
05
06
07
01
1. Select
Normal
or
Large
, then press the OK Key.
TXT AUTO VIEW
1. Select
On
or
O
, then press the OK Key.
•
On:
TXT messages are displayed automatically when received.
•
O:
TXT messages are displayed by going into the Inbox, or by responding to the message
prompt.
MULTIMEDIA AUTO RECEIVE
1. Select
On
or
O
, then press the OK Key.
•
On:
Picture and Voice messages are downloaded autatically.
•
O:
Picture and Voice messages must be retrieved from the inbox or by responding to the
message prompt
QUICK TEXT
Allows you to create a new Quick Text or edit the predened Quick Text.
1. To create a new Quick Text, press the Right Soft key
[
Options
], then select
1. New
. Enter the new text and press the OK Key [
SAVE
].
2. To edit the predened Quick Text, select the Quick Text from the list, then press
the OK Key [
EDIT
].
3. To change the Quick Text position, press the Right Soft Key
[
Options
],
then select
2. Move
. Press the Directional Key up or down to scroll to
desired position, then press the OK Key [
SAVE
].
4. To erase a saved Quick Text, press the Left Soft Key [
Erase
]. Select
Yes
and
press the OK Key.
VOICEMAIL #
1. Enter a new voicemail number or edit the voicemail number then press the
OK Key.
2. Press the Left Soft Key
[
Add
], then select
1. Add Wait
or
2. Add 2-Sec
Pause
. Please refer to
page 31
for more details on
PAUSE/WAIT FEATURE
.
CALLBACK #
Allows you to use or edit the default callback number so that the recipient can callback
or reply.
1. Select
On
or
O
, then press the OK Key.
2. If
On
is selected, enter a new callback number then press the OK Key.
SIGNATURE
Allows you to create a signature that can be automatically inserted at the end of each
message.
1. To deactivate Signature function, select
None
and press the OK Key.
2. To insert a Signature, select
Custom
, enter your signature in the text entry eld
then press the OK Key.
DELIVERY RECEIPT
Allows you to set delivery receipts for sent messages.
1. Select
On
or
O
, then press the OK Key.
•
On:
Request to receive the delivery acknowledgement.
•
O:
No delivery acknowledgement will be sent.
131
02
03
04
05
06
07
01
TXT8035PP
7
This chapter addresses the safety guidelines and precautions to follow when
operating your phone. Before operating your phone,
please be aware of all the safety details.
This chapter contains the terms and conditions of services and
the warranty for your phone. Please review them thoroughly.
SAFETY AND WARRANTY
Safety Information for Wireless Handheld Phones
Safety Information for FCC RF Exposure
SAR Information
Hearing Aid Compatibility (HAC) for Wireless
Telecommunications Devices
FDA Consumer Update
Avoid Potential Hearing Loss
FCC Compliance Information
12 month Limited Warranty
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES
READ THIS INFORMATION BEFORE USING YOUR HANDHELD
PORTABLE CELLULAR TELEPHONE
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio transmitter
and receiver. When it is ON, it receives and also sends out radio frequency (RF)
signals. In August 1996, the Federal Communications Commissions (FCC) adopted
RF exposure guidelines with safety levels for handheld wireless phones. Those
guidelines are consistent with the safety standards previously set by both U.S. and
international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations of the
relevant scientic literature. For example, over 120 scientists, engineers, and
physicians from universities, government health agencies, and industry reviewed
the available body of research to develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines (and those standards).
1*: American National Standards Institute.
2*: National Council on Radiation Protection and Measurements.
3*: International Commission on Nonionizing Radiation Protection.
ANTENNA SAFETY
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modications, or attachments could impair call quality, damage the
phone, or result in violation of FCC regulations. Please contact your local dealer for
replacement antenna.
132
133
02
03
04
05
06
07
01
Do not use the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact your local
dealer for replacement antenna.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in some
states. Remember, safety comes rst. Check the laws and regulations on the use
of phones in the areas where you drive. Always obey them. Also, if using your
phone while driving, please:
• Give full attention to driving. Driving safely is your rst responsibility.
• Use hands-free operation, if available.
• Pull o the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing, and
auto answer modes.
An airbag inates with great force. DO NOT place objects, including both installed
or portable wireless equipment, in the area over the airbag or in the air bag
deployment area. If in-vehicle wireless equipment is improperly installed and the
air bag inates, serious injury could result.
WARNING:
Failure to follow these instructions may lead to serious personal injury and
possible property damage.
ELECTRONIC DEVICES
Your wireless handheld portable telephone is a low power radio transmitter and
receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.
Most modern electronic equipment is shielded from RF energy. However, certain
electronic equipment may not be shielded against the RF signals from your wireless
phone. Therefore, use of your phone must be restricted in certain situations.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a minimum
separation of six (6”) inches be maintained between a handheld wireless
phone and a pacemaker to avoid potential interference with the pacemaker.
These recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with pacemakers:
• ALWAYS keep the phone more than six inches from your pacemaker when
the phone is turned on.
• Do not carry the phone in a breast pocket.
• Use the ear opposite the pacemaker to minimize the potential for
interference.
• If you have any reason to suspect that interference is taking place, turn your
phone OFF immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of
such interference, you may want to consult your service provider (or call the customer
service line to discuss alternatives).
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of your device
to determine if they are adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining this information. Turn your
phone OFF in healthcare facilities when any regulations posted in these areas instruct
you to do so. Hospitals or healthcare facilities may be using equipment that could be
sensitive to external RF energy.
134
135
02
03
04
05
06
07
01
VEHICLES
RF signals may aect improperly installed or inadequately shielded electronic
systems in motor vehicles. Check with the manufacturer or its representative
regarding your vehicle. You should also consult the manufacturer of any equipment
that has been added to your vehicle.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC regulations prohibit using your phone while in the air. Turn your phone OFF
before boarding an aircraft. Always request and obtain prior consent and approval of
an authorized airline representative before using your phone aboard an aircraft.
Always follow the instructions of the airline representative whenever using your
phone aboard an aircraft, to prevent any possible interference with airborne
electronic equipment.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when in a
“blasting area” or in areas posted: “Turn o two-way radio.” Obey all signs and
instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive atmosphere and
obey all signs and instructions. Sparks in such areas could cause an explosion or re
resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly
marked. They include fueling areas such as gas stations; below deck on boats;
fuel or chemical transfer or storage facilities; vehicles using liqueed petroleum
gas (such as propane or butane); areas where the air contains chemicals or
particles, such as grain, dust, or metal powders; and any other area where you
would normally be advised to turn o your vehicle’s engine.
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of equipment. Before
operating, read all instructions and cautionary markings on (1) USB AC Adapter
(2) Battery and (3) Product Using Battery.
Failure to follow the directions below could result in serious bodily injury and/or
property damage due to battery liquid leakage, re or rupture.
•
DO NOT use this equipment in an extreme environment where high temperature
or high humidity exists.
•
DO NOT abuse the equipment. Avoid striking, shaking or shocking. When not
using, lay down the unit to avoid possible damage due to instability.
•
DO NOT expose this equipment to rain or spilled beverages.
•
DO NOT use unauthorized accessories.
•
DO NOT disassemble the phone or its accessories. If service or repair is required,
return unit to an authorized PCD cellular service center. If unit is disassembled,
the risk of electric shock or re may result.
•
DO NOT short-circuit the battery terminals with metal items etc.
136
137
02
03
04
05
06
07
01
SAFETY INFORMATION FOR FCC RF EXPOSURE
WARNING! READ THIS INFORMATION BEFORE USING
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of the United
States with its action in Report and Order FCC 96-326 adopted an updated safety
standard for human exposure to radio frequency electromagnetic energy emitted
by FCC regulated transmitters. Those guidelines are consistent with the safety
standard previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these international
standards.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the back of the
phone kept 2 cm. from the body. To maintain compliance requirements, use only
belt-clips, holsters or similar accessories that maintain a 2 cm separation distance
between the user’s Body and the back of the phone, including the antenna.
The use of belt-clips, holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and should
be avoided.
For more information about RF exposure, please visit the FCC website at
http://www.fcc.gov.
SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency
(RF) energy set by the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientic organizations
through periodic and thorough evaluation of scientic studies. The standards
include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specic Absorption Rate, or SAR. The SAR limit set
by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting
at its highest certied power level in all tested frequency bands. Although the
SAR is determined at the highest certied power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested
and certied to the FCC that it does not exceed the limit established by the
government adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by the
FCC for each model. The highest SAR value for this model phone when tested for
use at the ear is 0.915 W/Kg and when worn on the body, as described in this user
138
139
02
03
04
05
06
07
01
guide, is 0.628 W/Kg. (Body-worn measurements dier among phone models,
depending upon available accessories and FCC requirements). While there may
be dierences between the SAR levels of various phones and at various positions,
they all meet the government requirement for safe exposure.
The SAR testing for Body-worn operation was performed with a belt clip that
provided a 20mm separation. The User’s Manual indicates that any holsters/clips
used with this device should contain no metallic components.
The FCC has granted an Equipment Authorization for this model phone with
all reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines.
SAR information on this model phone is on le with the FCC and can be found
under the Display Grant section of
http://www.fcc.gov/oet/ea
after searching
on JYCTOW.
Additional information on Specic Absorption Rates (SAR) can be found on the
Cellular Telecommunications Industry Association (CTIA) web-site at
http://www.ctia.org/
.
* In the United States and Canada, the SAR limit for mobile phones used by the
public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional protection for the
public and to account for any variations in measurements.
HEARING AID COMPATIBILITY (HAC) FOR WIRELESS
TELECOMMUNICATIONS DEVICES
PCD’S COMMITMENT
PCD believes that all of our customers should be able to enjoy the benets of
digital wireless technologies.
We are committed to providing a selection of compatible devices for our
customers who wear hearing aids.
THIS PHONE HAS A HAC RATING OF M4
WHAT IS HEARING AID COMPATIBILITY?
The Federal Communications Commission has implemented rules and a rating
system designed to enable people who wear hearing aids to more eectively
use these wireless telecommunications devices. The standard for compatibility
of digital wireless phones with hearing aids is set forth in American National
Standard Institute (ANSI) standard C63.19. There are two sets of ANSI standards
with ratings from one to four (four being the best rating): an “M” rating for
reduced interference making it easier to hear conversations on the phone when
using the hearing aid microphone, and a “T” rating that enables the phone to be
used with hearing aids operating in the telecoil mode thus reducing unwanted
background noise.
HOW WILL I KNOW WHICH WIRELESS PHONES ARE HEARING AID
COMPATIBLE?
The Hearing Aid Compatibility rating is displayed on the
wireless phone box.
A phone is considered Hearing Aid Compatible for acoustic
coupling (microphone mode) if it has an “M3” or “M4” rating. A
digital wireless phone is considered Hearing Aid Compatible for
inductive coupling (telecoil mode) if it has a “T3” or “T4” rating.
HOW WILL I KNOW IF MY HEARING AID WILL WORK WITH A PARTICULAR
DIGITAL WIRELESS PHONE?
You’ll want to try a number of wireless phones so that you can decide which
works the best with your hearing aids. You may also want to talk with your
140
141
02
03
04
05
06
07
01
hearing aid professional about the extent to which your hearing aids are immune
to interference, if they have wireless phone shielding, and whether your hearing
aid has a HAC rating.
FOR MORE INFORMATION ABOUT HEARING AIDS AND DIGITAL WIRELESS
PHONE
•
FCC Hearing Aid Compatibility and Volume Control –
http://www.fcc.gov/cgb/dro/hearing.html
•
Hearing Loss Association of America –
http://www.hearingloss.org/learn/cellphonetech.asp
•
CTIA –
http://www.accesswireless.org/hearingaid/
•
Gallaudet University, RERC –
http://tap.gallaudet.edu/voice
FDA CONSUMER UPDATE
U.S. FOOD AND DRUG ADMINISTRATION CENTER
FOR DEVICES AND RADIOLOGICAL HEALTH
CONSUMER UPDATE ON WIRELESS PHONES
1. Do wireless phones pose a health hazard?
The available scientic evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very
low levels of RF when in the idle mode. Whereas high levels of RF can produce
health eects (by heating tissue), exposure to low level RF that does not produce
heating eects causes no known adverse health eects. Many studies of low
level RF exposures have not found any biological eects. Some studies have
suggested that some biological eects may occur, but such ndings have not
been conrmed by additional research. In some cases, other researchers have
had diculty in reproducing those studies, or in determining the reasons for
inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has authority to take action if
wireless phones are shown to emit radiofrequency energy (RF) at a level that
is hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientic
data do not justify FDA regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the following:
•
Support needed research into possible biological eects of RF of the type
emitted by wireless phones;
•
Design wireless phones in a way that minimizes any RF exposure to the user that
is not necessary for device function;
and
•
Cooperate in providing users of wireless phones with the best possible
information on possible eects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for dierent aspects of RF safety to ensure coordinated eorts at the
federal level. The following agencies belong to this working group:
•
National Institute for Occupational Safety and Health
•
Environmental Protection Agency
•
Federal Communications Commission
142
143
02
03
04
05
06
07
01
•
Occupational Safety and Health Administration
•
National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure.
FCC relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base stations are
typically thousands of times lower than those they can get from wireless phones.
Base stations are thus not the subject of the safety questions discussed in this
document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless
phones can expose the user to measurable radiofrequency energy (RF) because
of the short distance between the phone and the user’s head. These RF exposures
are limited by Federal Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health and safety agencies.
When the phone is located at greater distances from the user, the exposure to
RF is drastically lower because a person’s RF exposure decreases rapidly with
increasing distance from the source. The so-called “cordless phones,” which have
a base unit connected to the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conicting results, and many studies
have suered from aws in their research methods. Animal experiments
investigating the eects of radiofrequency energy (RF) exposures characteristic of
wireless phones have yielded conicting results that often cannot be repeated in
other laboratories. A few animal studies, however, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor development used animals
that had been genetically engineered or treated with cancer-causing chemicals
so as to be predisposed to develop cancer in the absence of RF exposure. Other
studies exposed the animals to RF for up to 22 hours per day. These conditions are
not similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health.
Three large epidemiology studies have been published since December 2000.
Between them, the studies investigated any possible association between the use
of wireless phones and primary brain cancer, glioma, meningioma, or acoustic
neu-roma, tumors of the brain or salivary gland, leukemia, or other cancers. None
of the studies demonstrated the existence of any harmful health eects from
wireless phone RF exposures. However, none of the studies can answer questions
about long-term exposures, since the average period of phone use in these
studies was around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people
actually using wireless phones would provide some of the data that are needed.
Lifetime animal exposure studies could be completed in a few years. However,
very large numbers of animals would be needed to provide reliable proof of a
cancer promoting eect if one exists. Epidemiological studies can provide data
144
145
02
03
04
05
06
07
01
that is directly applicable to human populations, but 10 or more years’ follow-up
may be needed to provide answers about some health eects, such as cancer.
This is because the interval between the time of exposure to a cancer-causing
agent and the time tumors develop - if they do -may be many, many years. The
interpretation of epidemiological studies is hampered by diculties in measuring
actual RF exposure during day-to-day use of wireless phones. Many factors aect
this measurement, such as the angle at which the phone is held, or which model
of phone is used.
6. What is FDA doing to nd out more about the possible health eects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the eects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World
Health Organization International Electromagnetic Fields (EMF) Project since its
inception in 1996. An inuential result of this work has been the development
of a detailed agenda of research needs that has driven the establishment of
new research programs around the world. The Project has also helped develop
a series of public information documents on EMF issues. FDA and the Cellular
Telecommunications & Internet Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientic oversight, obtaining input from experts
in government, industry, and academic organizations. CTIA-funded research is
conducted through contracts to independent investigators. The initial research
will include both laboratory studies and studies of wireless phone users. The
CRADA will also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
7. How can I nd out how much radiofrequency energy exposure I can get
by using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures.
FCC established these guidelines in consultation with FDA and the other
federal health and safety agencies. The FCC limit for RF exposure from wireless
telephones is set at a Specic Absorption Rate (SAR) of 1.6 watts per kilogram
(1.6 W/kg). The FCC limit is consistent with the safety standards developed by
the Institute of Electrical and Electronic Engineering (IEEE) and the National
Council on Radiation Protection and Measurement. The exposure limit takes
into consideration the body’s ability to remove heat from the tissues that absorb
energy from the wireless phone and is set well below levels known to have
eects. Manufacturers of wireless phones must report the RF exposure level for
each model of phone to the FCC. The FCC website (
http://www.fda.gov
(under
“c” in the subject index, select
Cell Phones > Research
).)
gives directions for
locating the FCC identication number on your phone so you can nd your
phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leadership of FDA
scientists and engineers. The standard, “Recommended Practice for Determining
the Spatial-Peak Specic Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the rst
consistent test methodology for measuring the rate at which RF is deposited
in the heads of wireless phone users. The test method uses a tissue-simulating
model of the human head. Standardized SAR test methodology is expected to
146
147
02
03
04
05
06
07
01
greatly improve the consistency of measurements made at dierent laboratories
on the same phone. SAR is the measurement of the amount of energy absorbed
in tissue, either by the whole body or a small part of the body. It is measured in
watts/kg (or milliwatts/g) of matter. This measurement is used to determine
whether a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that
there is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
reduce RF exposure.
•
If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since the
exposure level drops o dramatically with distance.
For example, you could use a headset and carry the wireless phone away from
your body or use a wireless phone connected to a remote antenna. Again, the
scientic data do not demonstrate that wireless phones are harmful. But if you
are concerned about the RF exposure from these products, you can use measures
like those described above to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientic evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure
to radiofrequency energy (RF), the measures described above would apply to
children and teenagers using wireless phones. Reducing the time of wireless
phone use and increasing the distance between the user and the RF source will
reduce RF exposure. Some groups sponsored by other national governments
have advised that children be discouraged from using wireless phones at all.
For example, the government in the United Kingdom distributed leaets
containing such a recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain tumors or other ill
eects. Their recommendation to limit wireless phone use by children was strictly
precautionary; it was not based on scientic evidence that any health hazard
exists.
11. What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers
and debrillators from wireless telephones. This test method is now part of
a standard sponsored by the Association for the Advancement of Medical
instrumentation (AAMI). The nal draft, a joint eort by FDA, medical device
manufacturers, and many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that cardiac pacemakers and
debrillators are safe from wireless phone EMI. FDA has tested hearing aids for
interference from handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE).
This standard species test methods and performance requirements for hearing
aids and wireless phones so that that no interference occurs when a person
uses a “compatible” phone and a “compatible” hearing aid at the same time. This
standard was approved by the IEEE in 2000. FDA continues to monitor the use
of wireless phones for possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct testing to assess the
interference and work to resolve the problem.
148
149
02
03
04
05
06
07
01
12. Where can I nd additional information?
For additional information, please refer to the following resources:
•
FDA web page on wireless phones
(
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm
)
•
Federal Communications Commission (FCC) RF Safety Program
(
http://www.fcc.gov/oet/rfsafety
)
•
International Commission on Non-Ionizing Radiation Protection
(
http://www.icnirp.de
)
•
World Health Organization (WHO) International EMF Project
(
http://www.who.int/peh-emf/en/
)
•
National Radiological Protection Board (UK)
(
http://www.hpa.org.uk/radiation/
)
AVOID POTENTIAL HEARING LOSS
Prolonged exposure to loud sounds is the most common cause of preventable
hearing loss. Some scientic research suggests that using portable audio devices,
and cellular telephones, at high volume settings for long durations may lead
to permanent noise-induced hearing loss. This includes the use of headphones
(including headsets, earbuds and Bluetooth® or other wireless devices). Exposure
to very loud sound has also been associated in some studies with tinnitus (a
ringing in the ear), hypersensitivity to sound and distorted hearing. Individual
susceptibility to noise-induced hearing loss and other potential hearing problems
varies.
The amount of sound produced by a portable audio device varies depending on
the nature of the sound, the device, the device settings and the headphones. You
should follow some commonsense recommendations when using any portable
audio device:
•
Set the volume in a quiet environment and select the lowest volume at which
you can hear adequately.
•
When using headphones, turn the volume down if you cannot hear the people
speaking near you or if the person sitting next to you can hear what you are
listening to.
•
Do not turn the volume up to block out noisy surroundings. If you choose to
listen to your portable device in a noisy environment, use noise-cancelling
headphones to block out background environmental noise.
•
Limit the amount of time you listen. As the volume increases, less time is
required before your hearing could be aected.
•
Avoid using headphones after exposure to extremely loud noises, such as
concerts, that might cause temporary hearing loss. Temporary hearing loss
might cause unsafe volumes to sound normal.
•
Do not listen at any volume that causes you discomfort. If you experience ringing
in your ears, hear mued speech or experience any temporary hearing diculty
after listening to your portable audio device, discontinue use and consult your
doctor.
150
151
02
03
04
05
06
07
01
YOU CAN OBTAIN ADDITIONAL INFORMATION ON THIS SUBJECT FROM
THE FOLLOWING SOURCES:
AMERICAN ACADEMY OF AUDIOLOGY
11730 Plaza America Drive, Suite 300
Reston, VA 20190
Voice: 800-AAA-2336
Email: infoaud@audiology.org
Internet:
http://www.audiology.org
NATIONAL INSTITUTE ON DEAFNESS AND OTHER COMMUNICATION
DISORDERS NATIONAL INSTITUTES OF HEALTH
31 Center Drive, MSC 2320
Bethesda, MD USA 20892-2320
Voice: (301) 496-7243
Email: nidcdinfo@nidcd.nih.gov
Internet:
http://www.nidcd.nih.gov/health/hearing
NATIONAL INSTITUTE FOR OCCUPATIONAL SAFETY AND HEALTH
1600 Clifton Rd
Atlanta GA 30333. USA
Voice: 1-800-CDC-INFO (1-800-232-4636)
Internet:
http://www.cdc.gov/niosh/topics/noise/default.html
FCC COMPLIANCE INFORMATION
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class
B digital device pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful Interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if Not installed and used in accordance with the instructions, may
cause harmful Interference to radio communications. However, there is no
guarantee that interference will not occur in a particular Installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet of a circuit dierent from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for assistance.
CAUTION:
Changes or modication not expressly approved by the party responsible
for Compliance could void the user’s authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal
cables.
152
153
02
03
04
05
06
07
01
12 MONTH LIMITED WARRANTY
Personal Communications Devices, LLC. (the “Company”) warrants to the original
retail purchaser of this handheld portable cellular telephone, that should this
product or any part thereof during normal consumer usage and conditions, be
proven defective in material or workmanship that results in product failure within
the rst twelve (12) month period from the date of purchase, such defect(s)
will be repaired or replaced (with new or rebuilt parts) at the Company’s option,
without charge for parts or labor directly related to the defect(s).
The antenna, keypad, display, rechargeable battery and battery charger, if
included, are similarly warranted for twelve (12) months from date of purchase.
This Warranty extends only to consumers who purchase the product in the United
States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident, mishandling,
neglect, unauthorized alteration, misuse, improper installation or repair or
improper storage;
(b) Product whose mechanical serial number or electronic serial number has been
removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive temperatures or
extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or other product
not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such as framing
and nonoperative parts;
(f) Product damaged from external causes such as re, ooding, dirt, sand,
weather conditions, battery leakage, blown fuse, theft or improper usage of
any electrical source.
The Company disclaims liability for removal or reinstallation of the product,
for geographic coverage, for inadequate signal reception by the antenna or for
communications range or operation of the cellular system as a whole.
When sending your wireless device to Personal Communications Devices for
repair or service, please note that any personal data or software stored on the
device may be inadvertently erased or altered. Therefore, we strongly recommend
you make a back up copy of all data and software contained on your device before
submitting it for repair or service. This includes all contact lists, downloads (i.e.
third-party software applications, ringtones, games and graphics) and any other
data added to your device. In addition, if your wireless device utilizes a SIM or
Multimedia card, please remove the card before submitting the device and store
for later use when your device is returned, Personal Communications Devices
is not responsible for and does not guarantee restoration of any third-party
software, personal information or memory data contained in, stored on, or
integrated with any wireless device, whether under warranty or not, returned to
Personal Communications Devices for repair or service.
To obtain repairs or replacement within the terms of this Warranty, the product
should be delivered with proof of Warranty coverage (e.g. dated bill of sale),
the consumer’s return address, daytime phone number and/or fax number and
complete description of the problem, transportation prepaid, to the Company at
the address shown below or to the place of purchase for repair or replacement
processing. In addition, for reference to an authorized Warranty station in your
area, you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 416-695-3060).
154
155
02
03
04
05
06
07
01
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO
THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE
COMPANY’S LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR
THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED
TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY
WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE
OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR AN
SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY
OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL
NOT BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR
LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company any liability
other than expressed herein in connection with the sale of this product.
Some states or provinces do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or consequential
damage so the above limitation or exclusions may not apply to you. This Warranty
gives you specic legal rights, and you may also have other rights, which vary
from state to state or province to province.
IN USA:
Personal Communications Devices.
555 Wireless Blvd.
Hauppauge, NY 11788
1-800-229-1235
IN CANADA:
PCD Communications Canada LLC.
5535 Eglinton Avenue West, Suite 234
Toronto, Ontario
M9C 5K5
1-800-465-9672
156
157
NOTE
158
159
NOTE
160
