Planex Communications inc. Bluetooth headset Users Manual

Users Manual

LL
6. How to wear it firmly
7. Make a call.
To make a call, dial through your mobile phone.
8. Reject a call.
Touch 2 Sec
If you can't wear it firmly, use the ear hook as assist
---------- ----------
microphone toward jaw
----------
Left-ear use
Right-ear use
11. Voice dialing
12. Redial last number
13. Volume control.
1.When you have a incoming call
just “touch” the Talk key ,after you
hear the ring from the headset.
2.You can also click MFB key to receiving a call
When you finish a call; touch the
Talk key 1 Sec. ----end the call.
10. End a call.
Click
Double-Click
Touch 1 Sec
----------
You can adjust the headset volume
during a call.
9. Answer a call.
Mute & un-mute
Touch
---------- ----------
----------
1.When during call press the “ Volume up & Down" key
; you will hear a “ Do-lu-do-do" sound,
then your voice won't be heard.
2.Click the Volume up or Volume Down key again, you will
hear the " Beep " sound to un-mute the microphone.
simultaneously
1.The headset should be under
"Connected mode". By double-click
the MFB key, after you hear a " Do-
Do " sound from the headset, then it
will redial again.
2.This function depends on the
specification of your mobile phone.
1.The headset should be under
"Connected mode", click the MFB
key; then you can make the " Voice
dialing " by the mobile phone's
operation instruction..
2.This function depends on the
specification of your mobile phone.
When you hear the in-coming
call rings from your headset;
touch the Talk key touch panel
(logo area)for 2 Sec, when you
hear the " Do Do" sound than
release it. ---Reject a call.
Inserted
completely
Cap the ear tip
X
Parallel
The salient insert
in the little hole
X
Inserted
Incompletely
Inserted
Incompletely
Inserted
Incompletely
The ear tip must insert to ear bone completely.
Ringing.....
Ringing.....
3. Turn on/ Turn off
4. Pairing with your mobile phone
It need to pair with your Bluetooth device, first time.
5. How to wear the headset
4. "BT-06HS-T” will show on certain items in your mobile phone.
5. Key in pairing pin code "0000”press " yes" , the indicator
light will turn from the blue/red flashing status into blue
flashing, it means the pairing has been successful.
7.Now the headset has been in the "connected mode".
you may receive or dial the phone call.
5 Sec
- Stand-by mode-------
blue light flash once every 5 Sec.
- C
blue light flash two times every 5 Sec.
- Active call mode-----
blue light flash three times every 5 Sec.
- low battery-----
red light flash.
onnected mode----
Choose the ear tip size
Choose the ear plug size
Power on - blue light flashing.
Power off - red light flashing then off.
Red blue
1.Before pairing, make sure your
headset is off.
2.Press the MFB key for at least
5 sec; the blue and red light
flashing alternately it means the
headset is in the “pairing mode".
3.Please ensure that your mobile
phone is provided the Bluetooth
Function, and activate the function.
3 Sec
Press the MFB key for about
3 Sec, to turn on and turn off.
10cm~1m
The pairing
distance Devices found
BT-06HS-T
large one on headset already
Over 7 .
Over 7 Day
Within 90 ~120Mins.
10 meters(open space)
Handsfree / Headset .
Bluetooth V2.1
hrs
s.
0 ~ 55 'C
0% ~ 90% (non-concrete status)
5V DC, 00~240V AC adapter
Specification of the Headset
1. Charging the Headset
1. At least for 4 hours when first time charging,
2. When charging, the red light on; fully charged the light
will be off.
2. Introduction of the product
Bluetooth Headset
User Manual
BT-06HS-T
Bluetooth Standard
Talktime
Standby time
Charging time
Supported Bluetooth profiles
Operating temperature range
Storage temperature
Operation range
Power Supply
USB
Port
Charging Plug
light indicator
(logo area)
Volume up
MFB /Volume down
Speaker
Ear tip
Ear plug
Hook point
Charging Port
Microphone
Talk key touch panel
Model: BT-06HS-T
FCC ID. : SJ9-BT-06HS-T
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATIONS IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
( 1 ) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE
( 2 ) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFEERENCE THAT MAY UNDESIRED OPERATION.
Made in Taiwan Brand Name:PCI
User guide
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment. (Example - use only shielded interface cables
when connecting to computer or peripheral devices).
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment.
