Regulatory Info
AP-4000MR-LR Safety and Regulatory Information
2
Copyright
© 2006 Proxim Corporation. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179; 6,006,090;
5,809,060; 6,075,812; 5,077,753. This user’s guide and the software described in it are copyrighted with all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any
means without the written permission of Proxim Corporation.
Trademarks
ORiNOCO and Proxim are registered trademarks, and the Proxim logo is a trademark, of Proxim Wireless Corporation.
All other trademarks mentioned herein are the property of their respective owners.
ORiNOCO AP-4000MR-LR Safety and Regulatory Compliance Information
P/N 72930/3 August 2006
Products Covered in the Guide AP-4000MR-LR Safety and Regulatory Information
1
Products Covered in the Guide
This document contains important safety and regulatory compliance information for the following products:
Please see the following sections for more information:
•Safety Information
•FCC Compliance Information
•Information for Professional Installers
•Certification Summary
IMPORTANT!
Visit http://support.proxim.com for the latest safety and regulatory compliance information for this product.
Please read this document before installing and using your product, and save these instructions.
Product Model Numbers
ORiNOCO Tri-Mode Ruggedized Access Point AP-4000MR-LR 8670-MR-LR-US
Safety Information AP-4000MR-LR Safety and Regulatory Information
2
Safety Information
This product has been evaluated to, and complies with, the Safety requirements of UL60950:2000, and IEC60950:1999;
the Standards for the Safety of Information Technology Equipment. When using this device, basic safety precautions
should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following:
• Operate and install this product as described in this manual. This device must be installed and used in strict
accordance with the manufacturer's instructions.
• This product is suitable for installation in air handling spaces (plenum).
• Use only the AC/DC power supply adapter provided. For replacement, contact your local supplier or distributor.
• To avoid the risk of electric shock from lightning, do not use this product during an electrical storm.
• Installation of this product must conform to local regulations and codes.
• When using this product with an external antenna, see the installation documentation provided with the antenna
system.
• No user serviceable parts; all repairs and service must be handled by a qualified service center.
FCC Compliance Information AP-4000MR-LR Safety and Regulatory Information
3
FCC Compliance Information
This device operates in the 2.4 GHz and 5.75 - 5.85 bands in compliance with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept
any interference received, including interference that may cause undesired operation.
To comply with the FCC radio frequency exposure requirements, the following antenna installation and device operating
configurations must be satisfied:
•Product models using external antennas require professional installation.
• The antennas used for professional installation must be fixed-mounted on indoor/outdoor permanent structures with a
separation distance of at least 123 cm from all persons.
• Antennas must not be co-located and must not operate in conjunction with any other antenna or transmitter.
Modifications
Changes or modifications to this device that are not expressly approved by the manufacturer of the product could void the
user’s authority to operate the equipment.
Warnings
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection again harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
and correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Information for Professional Installers AP-4000MR-LR Safety and Regulatory Information
4
Information for Professional Installers
Adjusting Tx Output Power
Use the following formula in combination with the table of EIRP limits to calculate system transmit power (based on EIRP
limits):
Tx Power Allowed (dBm) = EIRP Limit (dBm) + CL (dB) – G (dB)
where:
Tx Power = Output power measured at the antenna input
EIRP Limit = EIRP limits specified below
CL = Coax cable loss including loss of connectors
G = Antenna Gain
Antenna Types and Maximum Gain
Professional installers should select only the antenna types listed in the following table, with gain not exceeding the listed
maximum gain for each type.
Frequency (GHz) EIRP Limit (dBm)
2.4 - 2.4835 36
5.725 - 5.850 36
Frequency Band Antenna Type Maximum Gain (dBi)
2.4 GHz Omni 12
Flat Panel 14
Sector 17
5 GHz Omni 12
Panel 28
Sector 18
Certification Summary AP-4000MR-LR Safety and Regulatory Information
5
Certification Summary
Country Certification/Reference Number
USA HZB-4000LR
Canada 1856A-AP4000MRLR
