Psion 7505BTSDCMHC25 Handheld Computer User Manual users guide BT radio

Psion Inc Handheld Computer users guide BT radio

users guide BT radio

MODEL: PSIONBTL169
INSTALLATION INSTRUCTIONS
The bluetooth module, model number PSIONBTL169, and the bluetooth antenna need to be soldered
to the printed circuit board using following information:
Preliminary Specification Number : SP-6LCS-B
p.2/20
Preliminary & Confidential
< Specification may be changed by Murata without notice >
Murata Manufacturing Co., Ltd.
6. Dimensions, Marking and Terminal Configurations
Dimensions
(Unit : mm)
Mark Dimension Mark Dimension Mark Dimension
L 6.65 +/- 0.30 W 6.15 +/- 0.30 T 1.5 max.
a1 0.3 +/- 0.1 a2 0.3 +/- 0.1 a3 1.2 +/- 0.1
b1 0.725 +/- 0.200 b2 0.2 +/- 0.2 b3 1.225 +/- 0.200
b4 0.2 +/- 0.2 c1 0.6 +/- 0.1 c2 0.6 +/- 0.1
c3 1.0 +/- 0.2 e1 0.3 +/- 0.1 e2 0.3 +/- 0.1
e3 0.35 +/- 0.1 e4 0.4+/-0.1 e5 0.4+/-0.1
m1 0.3+/-0.1 m2 0.3+/-0.1 L1 6.55+/-0.30
(9) (8) (7) (6) (5) (4) (3) (2) (1)
(28)
(27)
(26)
(25)
(24)
(23)(22)(21)(20)(19)(18)(17)(16)(15)
(14)
(13)
(12)
(11)
(10)
b1
c2
b4
e1
a2
a3
e2
a1
c1
c3
b3
LT
W
<Top View> <Bottom View><Side View>
1pin index
(1) (9)
(10)
(14)(24)
(28)
(23) (15)
L1
e3
b2
(32) (31)
(30) (29)
m1
e4
e5
m2
Integrated Antenna Solutions 5
Product Specication AE030097-C
Comata 2.4 GHz SMD Antenna
. Antenna Dimensions
Batch No
YY=Year
WW=Week No
I
S
G
M
H
W
L
N
JF
K
L W H G F S I J K M N
Length Width Height Ground Feed Solder
12.8 ±0.3 3.6 ±0.2 3.3±0.2 1.2±0.1 1.2±0.1 1.2±0.1 3.0±0.1 0.65±0.25 1.0±0.1 6.9±0.2 0.3±0.1
Dimensions in millimeters
9 Antenna Foot print
Copper area
Soldering pads
Transparent area
N
S
KL
GFM
I
G F S I K L M N
Ground Feed Solder
1.2±0.1 1.2±0.1 1.2±0.1 3.0±0.1 1.0±0.1 6.9±0.2 0.4±0.1 0.5±0.1
Dimensions in millimeters
