Qolsys QS1100 wireless door/window sensor to be used in the Qolsys IQ home security system User Manual
Qolsys, Inc. wireless door/window sensor to be used in the Qolsys IQ home security system
Qolsys >
User Manual
IQ DOOR/WINDOW- INSTALLATION MANUAL
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 1 OF 6
© Last revised 2/27/15 All rights reserved
The Qolsys IQ Door/Window is a sleek, high-
performance wireless sensor that detects opening
and closing of doors, windows and anything else
which opens and closes (drawers, cabinets, etc). It
works seamlessly with the Qolsys IQPanel.
1 Door/Window Sensor
1 Magnet
6 screws
1 large strip of double sided adhesive
1 small strip of double sided adhesive
PRODUCT FEATURES
PARTS INCLUDED
IQ DOOR/WINDOW
Wireless signal range: 600ft (200M),open air.
Code outputs: tamper, tamper restore, alarm (primary open),
alarm restore (primary close), external alarm (secondary
wired open), external restore (secondary wired closed), low
battery.
Transmitter frequency : 319.5MHZ
Unique code ID
Supervisory keep-alive interval: 70 minutes.
RF output power!91.1dBuV +/- 5% at 3m
TECHNICAL SPECIFICATIONS
•Low profile
•Supports one or two doors, windows, etc.
•Primary wireless magnet contact and secondary wired
contact
•Internal or external reed switch
•Easy, wire-free installation
•Secondary (optional) sensor (external wired Door/Window
sensor)
•Advanced circuit technology resulting in ultra-low power
consumption
•Easy to install Batteries
•Over 5 years of battery life
•Tamper Detection
•Supervisory health messaging
•Sensor Open and Close detection
6
IQ DOOR/WINDOW- INSTALLATION MANUAL
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 2 OF 6
© Last revised 2/27/15 All rights reserved
!"#$%&'&()'*)%*#+'#%'&()',##+'
-+./)'.%,'&()'/.0%)&'#%'&()'
,##+1'2-'&()'*)%*#+'3*'$*),'#%'
,#$45)',##+*6'/#$%&'&()'*)%*#+'
#%'&()'5).*&7$*),',##+'.%,'&()'
/.0%)&'#%'&()'/#*&7$*),',##+1'
!2-'8#**345)6'5#9.&)'*)%*#+*'
:3&(3%';<<'-&1'=><'/?'-+#/'&()'
8.%)51'
!@(35)'.'&+.%*/3A)+'/.B'(.C)'.'
+.%0)'#-'D<<'E1'=F<<'/?'#+'
/#+)'#$&'3%'&()'#8)%6'&()'
)%C3+#%/)%&'.&'&()'3%*&.55.&3#%'
*3&)'9.%'(.C)'.'*30%3G9.%&')H)9&'
#%'&+.%*/3&&)+'+.%0)1'I#/)7'
J/)*'.'9(.%0)'3%'*)%*#+'
#+3)%&.J#%'9.%'()58'#C)+9#/)'
.,C)+*)':3+)5)**'9#%,3J#%*1'
!".K)'*$+)'&()'.530%/)%&'.++#:'
#%'&()'/.0%)&'8#3%&*'&#'&()'
.530%/)%&'/.+K'#%'&()'*)%*#+."
!L5.9)'*)%*#+*'.&'5).*&'D'3%1'
=;M1FN'9/?'.4#C)'&()'O##+'&#'
.C#3,',./.03%0'&()/1'
!PC#3,'/#$%J%0'*)%*#+*'3%'
.+).*':()+)'&()B':355'4)'
)Q8#*),'&#'/#3*&$+)'#+':()+)'
&()'*)%*#+'#8)+.&3%0'
&)/8)+.&$+)'+.%0)'
#-'<'&#';F<RS'=<'&#'NTRU?':355'4)'
)Q9)),),1'
!V*)'*8.9)+*'=%#&'3%95$,),?'&#'
K))8'*)%*#+*'.%,'/.0%)&*'
.:.B'-+#/'/)&.5'#+'/)&.5539'
*$+-.9)*'*$9('.*'-#35':.558.8)+1'
!PC#3,'/#$%&3%0'*)%*#+*'3%'
.+).*':3&('.'5.+0)'W$.%&3&B'#-'
/)&.5'#+')5)9&+39.5':3+3%06'*$9('
.*'.'-$+%.9)'#+'$J53&B'+##/
GUIDELINES
Be sure to align the triangle guides on the sensor and magnet as shown. This will
enable the proper contact between the sensor and magnet. When closed, the
magnet should be within .4” of the sensor for optimum sensitivity.
PLACEMENT AND SPACING
BATTERY ACTIVATION
To activate the batteries in the sensor, remove the cover and pull out the plastic tabs
between the batteries and the contacts.
Please note: the sensor will not operate the reed switch and external contact header
simultaneously.
X./8)+'*:3&9(
YQ&)+%.5'
9#%&.9&'
().,)+
Z.A)+B'
+)&)%J#%'
9538*
IQ DOOR/WINDOW- INSTALLATION MANUAL
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 3 OF 6
© Last revised 2/27/15 All rights reserved
MOUNTING WITH PROVIDED ADHESIVE
IQ DOOR/WINDOW- INSTALLATION MANUAL
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 4 OF 6
© Last revised 2/27/15 All rights reserved
PROGRAMMING THE IQ DOOR/WINDOW
X()'-#55#:3%0'*&)8*',)*9+34)'0)%)+.5'0$3,)53%)*'-#+'8+#0+.//3%0'=5).+%3%0?'&()'*)%*#+'3%&#'&()'2]'L.%)51'[)-)+'&#'
&()'2]'L.%)5^*'3%*&.55.&3#%'3%*&+$9&3#%*'-#+'9#/85)&)'8+#0+.//3%0',)&.35*1'
From the home screen of
the IQ panel, touch the
“Settings” icon
Y%&)+'&()'3%*&.55)+'8.**9#,)1''
_)-.$5&'3%*&.55)+'8.**9#,)'3*';;;;1 2
Touch the “Installation” app Touch the “Security Sensors” app
3 4
Touch the “AutoLearn
Sensor” app
X./8)+'&()'*)%*#+'4B'8+)**3%0'&()'
&.4'.%,'53E3%0'#H'&()'9#C)+1''5 4
A chime will sound X#$9('`aKb
6 7
8
Check the auto-populated fields to ensure accuracy.
Customize device settings as desired.
9
Create custom names by selecting “Sensor name” and
choosing “Custom description.” A keyboard will
appear, allowing you to type the name of your choice
into the field.
10 Click “Add” to complete the process
IQ DOOR/WINDOW- INSTALLATION MANUAL
BATTERY REPLACEMENT
To replace batteries:
•Push tab on side of sensor and lift off cover.
•Place fingernail or small screwdriver under the battery and gently lift
up. The battery should release easily. Remove old battery. Replace
with a new battery by putting one end under the golden battery
retention clip. Gently push toward the opposite side until the the
battery snaps into place under the black plastic.
•Repeat this process for the second battery.
•Close cover by snapping the cover back onto the sensor.
L$*('&#'+)/#C)'
*)%*#+'9#C)+
X./8)+'
*:3&9(
YQ&)+%.5'
9#%&.9&'
().,)+
Z.A)+B'
+)&)%J#%'9538*
3V CR2032 Lithium
(2 batteries per sensor)
5+ years battery life
BATTERY TYPE
Operating Temperature: -10C~50C
Relative Humidity: 5-95% Non-Condensing
Storage Temperature: -40-80C
ENVIRONMENTAL CHARACTERISTICS
SUPPORT
Sensor: 3.25H x 1.3W x 1D in. (8x3x1.5 cm)
Magnet: 1.3H x 0.435W x 0.312D in. (3.3 x 1.1 x 0.79 cm)
PHYSICAL SPECIFICATIONS
GOT QUESTIONS?
CONTACT TECH SUPPORT
TechSupport@Qolsys.com
?
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 5 OF 6
© Last revised 2/27/15 All rights reserved
IQ DOOR/WINDOW- INSTALLATION MANUAL
IMPORTANT INFORMATION
15.21
§ 15.21 Information to user.
The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes
or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
CAUTION:! Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
!
15.105(b)
§ 15.105 Information to the user.
!
(b) NOTE: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
RSS-GEN Section 8.4
8.4 User manuals for licence-exempt radio apparatus shall contain the following text, or an equivalent notice that shall be
displayed in a conspicuous location, either in the user manual or on the device, or both:
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Document#: IQDW-IM-02-15
Revision#: 2/27/15
Issue Date: FEB 2015
Qolsys Product #: QS-1100-P01
Firmware : 0A_20121130
Conforms to ANSI/UL Std. 634
Certified to ULC Sub. C634
