• Wireless programmable output
• Compatible with all models of smoke generators,
sirens, strobes, garage doors, etc.
• Dual tamper
• Lithium powered - 4 years battery life
Description
The IRT Input Relay Transmitter is a battery operated, wireless,
radio controlled dry contact designed for use in Videofied®
security systems.
The relay transmitter is intended for triggering wired devices
when a specific event is occuring on the control panel.
The IRT consist of a dry contact with S2View® spread spectrum,
Videofied, interactive, encrypted wireless circuitry for secure
two-way communications with the control panel.
A dual tamper function provides detection for both wall and
cover tamper.
The transmitter must be installed with a wired device to be
triggered when a programmed event is occurring on the control
panel.
For example triggering a smoke generator upon intrusion or
opening a garage door when the system is disarmed.
The IRT is as a normally-open remote switch. It is powered by
one lithium battery that can last up to four years, depending on
the amount of activity.
The relay transmits a check-in signal every eight minutes that
includes its unique identification code along with the tamper
status, serial number, date of manufacture, software version and
battery status.
Features
> S2View® - Spread Spectrum, Videofied, Interactive, AES
Encrypted Wireless technology provides optimum signal
integrity and security.
> Supervised - transmits a check-in/status signal every 8
minutes indicating tamper status, serial number, date of
manufacture, software revision and battery status.
> Dual tamper - provides detection for both wall and cover
tamper.
> Programmable radio output - provides a normally-open
(NO) dry (no power) contact.
> Lithium battery - up to four years battery life.
SPECIFICATION SHEET
DOC. - REF. 229-IRT
MODIF. DATE : NOVEMBER 2016
VERSION : 08.XX.XX
1
INDOOR RELAY TRANSMITTER IRT200 IRT601 IRT702
2
www.videofied.com
SPECIFICATION SHEET INDOOR RELAY TRANSMITTER IRT200 IRT601 IRT702
Battery Type C - CR123A - Lithium battery
Nominal voltage 3 V
Low battery limit 2.8 V
Estimated battery life Up to 3 years
Current consumption
Standby (1h average) 45 µA
Max 35 mA
Panel compatibility W panels
ELECTRICAL PROPERTIES
Trigger properties Open-collector
RF S2View® technology
Radio type Spread spectrum RF bidirectional
Operating frequency
• 868MHz - IRT200 (Europe, Africa, Asia)
• 915MHz - IRT601 (Americas)
• 920MHz - IRT702 (Australia, Chile, Peru, Paraguay)
Transmission security AES algorithm encryption
Supervision Radio, batteries, tamper
Radio antenna Integrated
RADIO PROPERTIES
BOX
Physical properties
Material ABS UL94-V0
Dimensions 79.3 mm x 35 mm x 24.6 mm
Weight 32 g (without battery)
Installation / Mounting
Wall mounting 2 screws
Box sealing 1 screw
Environmental properties
Operating temperature -10°/+55°C
Max relative humidity 75%, without condensing
STANDARDS AND CERTIFICATIONS
868MHz (IRT 200)
Compliant with the annex IV of the R&TTE Directive 1999/5/EC
915MHz (IRT 601)
USA FCC Part 15C
Canada IC RSS-247 Issue 1
920MHz (IRT 702)
Australia RCM AS/NZS4268
Tamper
Tamper detection
Cover and wall tamper
