Centeron® Flexible Probe Radar Monitor Instruction Manual
Robertshaw Industrial Products Page 2
transmit more frequently than once every four hours and Monitors that are subjected to
prolonged exposure to extreme temperatures will exhibit reduced battery life.
2.3 Environmental Specifications
The following environmental specifications should be observed when installing the
Monitor:
• Operating Temperature Range: -40oC to +80oC (-40°F to +176°F)
• The Monitor housing is designed to meet or exceed NEMA 3.
• UV life: 10 years exposure to direct sunlight.
• Shock: The unit will withstand a one-meter drop test per UL 913.
• Chemical Exposure: The Centeron® Radar Monitor is designed for use in water,
ethylene glycol, oil, and common hydrocarbon fuels such as gasoline, gasoline /
ethanol blends, fuel oil, and diesel fuel. Wetted materials in this design include
polypropylene, 316 series stainless steel, Nitrile rubber, brass, and FEP Teflon. For
applications involving fluids other than those noted above contact the Robertshaw
Industrial Products Technical Support Group (refer to Section 5.5) before
installation.
• Pressure: The Centeron® Radar Monitor is designed for use on vented storage tanks
only. The maximum pressure inside the tank must not exceed 3 PSI. A special
adapter (sold separately) is required for use in pressurized applications up to 50 PSI.
2.4 Certifications
2.4.1 FCC Notice—Radio Frequency Communications
The Monitor generates and uses radio frequency energy. If not installed and used in
accordance with the manufacturer’s instructions, it may cause interference to radio and
television reception. The Monitor complies with the specifications in Part 15 of the FCC
Rules for Class B Computing Devices.
CAUTION: Robertshaw Industrial Products Division does not support field changes or
modifications to any of the Centeron® Level Monitoring System equipment unless they
are specifically covered in this manual. All adjustments must be made at the factory
under the specific guidelines set forth in our manufacturing processes. Any modification
to the equipment will void the manufacturer’s warranty and could void the user’s
authority to operate the equipment and render the equipment in violation of FCC Part 15,
Subpart C, 15.247.
CAUTION: This device is required to comply with FCC RF exposure requirements for
mobile transmitting devices. The FCC requires that the antenna(s) used for this
transmitter must be installed to provide a separation of at least 20 cm (8 inches) from
Centeron® Flexible Probe Radar Monitor Instruction Manual
Robert shaw Industrial Products Page 3
all persons and must not be co-located or operating in conjunction with any other
antenna
or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
2.4.2 Safety and Regulatory
The Monitor is designed to comply with UL Standards for Intrinsically Safe Apparatus
for use in Class I, Division 1, Group D locations. The Monitor conforms to UL 913 and
has been certified to CAN/CSA Standard C22.2 No. 157 and Standard C22.2 No. 94.
WARNING: SUBSTITUTION OF COMPONENTS MAY IMPAIR INTRINSIC
SAFETY.
AVERTISSEMENT: LA SUBSTITUTION DE COMPOSANTS PEUT
COMPROMETTRE LA SÉCURITÉ INTRINSÈQUE.
3.0 Installation
A Quick Installation Guide, which provides an overview of the Radar Monitor
installation procedure, was included with this product.
The following sections of this manual explain in detail the site selection and installation
process:
3.1 Radio Installation Guidelines
The Centeron® Radar Monitor contains sensitive measurement circuitry and a radio
transmitter. Large metal objects such as buildings and vehicles may affect the
transmission of radio signals. Electrical equipment may produce electronic noise that
could adversely affect signal quality.
§ Direct line of sight between the Centeron® Monitor and Controller will provide
optimum radio reception.
§ The Centeron® Monitor and Controller can communicate at distances up to one mile
under optimum line-of-sight conditions.
§ When obstructions such as walls, buildings, and vehicles exist between the
Centeron®
Monitor and Controller the distance between these units should be limited
to less than 500 feet.
