47
Meter Settings 5
Target Ranges
Your healthcare professional can tell you what blood glucose range is appropriate for you. It is very
important to stay within your target range.
Target Ranges can be set from a lower limit of 60–100mg/dL to an upper limit of 101–300 mg/dL.
Options Function
O Arrow symbols for above, within, or below target ranges do not appear with the
blood glucose results.
Single Range Set lower limit and upper limit for the target range.
You will be prompted to turn on Patterns if desired (see the Patterns section of this
chapter for details).
2 Ranges Set lower limits and upper limits for Before meal and After meal target ranges.
You must mark your blood glucose results with a comment for the meter to detect
above, within, or below Before Meal or After Meal test results (see the Adding
Comments to Blood Glucose Results section in the chapter Blood Glucose Tests
for details).
You will be prompted to turn on Patterns if desired (see the Patterns section of this
chapter for details).
When Target Ranges is On, the following symbols appear with blood glucose results.
Symbol Meaning
The blood glucose result is below the target range.
The blood glucose result is within the target range.
The blood glucose result is above the target range.
Target Ranges
52926_07414587001_EN.indb 47 6/2/16 2:53 PM
48
Meter Settings
5
Target Ranges is highlighted.
Press .
Press or to adjust the lower limit of the Before Meal target
range. Press to set and move to the next field.
Continue to set the upper limit for the Before Meal target range and
the lower and upper limits for the After Meal target range. Press .
Press or to highlight Off,
Single Range, or 2 Ranges.
Press to select an option (the
example here is 2 Ranges).
3
54
Turn the meter on by briefly
pressing . From Main Menu,
press to highlight Settings.
Press .
1
Press to highlight More
Options. Press .
2
WARNING
This function is no substitute for hypoglycemia training by your healthcare professional.
Target Ranges
52926_07414587001_EN.indb 48 6/2/16 2:53 PM
49
Meter Settings 5
The appears next to the
option you selected.
Press to return to the
previous menu.
6
The meter may prompt you to turn on Patterns.
Press or to highlight Yes or No.
Press to set the option and return to the previous menu (see the
Patterns section of this chapter for details).
Target Ranges
52926_07414587001_EN.indb 49 6/2/16 2:53 PM
50
Meter Settings
5
NOTE
Analyzing your blood glucose results stored in the meter is an eective way for you and your
healthcare professional to determine how well you are controlling your diabetes. This analysis is a
valuable tool for making improvements to your diabetes management. Use care when adding
comments to blood glucose results. Incorrect comments can cause inaccurate patterns to be detected
by the meter when Patterns is On.
Patterns
A Pattern is detected by the meter when 2below‑target (Low Pattern) or 3above‑target (High Pattern)
test results with the same comment are detected within a 7‑day period.
• The meter does NOT detect a pattern for the "Other" comment added to blood glucose results.
• It is very important to have the correct time and date set in the meter. Having the correct time and date
setting helps ensure accurate interpretation of information by you and your healthcare professional.
• Only blood glucose results marked with comments will be included in Patterns. If LO or HI test results
are marked with comments, the results become part of Patterns (see the chapter Blood Glucose Tests
for more details).
• Target Ranges must be set in the meter to use Patterns. If Target Ranges are not set, the meter prompts
you to set them.
Patterns
52926_07414587001_EN.indb 50 6/2/16 2:53 PM
51
Meter Settings 5
Press to highlight More
Options. Press .
2
Press to highlight Patterns.
Press .
3
Turn the meter on by briefly
pressing . From Main Menu,
press to highlight Settings.
Press .
1
This message appears if
Target Ranges is O:
Press to highlight Yes. Press
.
(To turn Patterns O, select No.
Press to return to Patterns.)
Target Ranges appears on the
display. (See the Target
Ranges section of this chapter
for details on setting target
ranges).
Press to highlight On. Press
to move to the option.
Press .
4
Patterns
52926_07414587001_EN.indb 51 6/2/16 2:53 PM
52
Meter Settings
5
If Patterns is On and a new
pattern is detected with a blood
glucose result, a message
appears on the display.
Press to select Details to
view the blood glucose results
that make up that pattern.
Press to highlight View
Later.
Press to return to the
previous screen.
or
Patterns
52926_07414587001_EN.indb 52 6/2/16 2:53 PM
53
Meter Settings 5
Reminders
You can set up to 4general test Reminders per day to remind you to test. A series of beeps sound and
is displayed for Reminders set in the meter.
Reminders:
• turn o by inserting a test strip or pressing any button.
• are postponed until the next test reminder if a test was performed within 15minutes of a test reminder.
• do not appear/beep if the meter is on at the test reminder time (including when the meter is connected
to a USB cable).
• do not appear/beep if the meter is connected and communicating to a Continua Certified
®
manager.
• do not beep if the meter’s beeper is set to o.
• do not appear/beep if the batteries need to be replaced.
Set Reminders
• Reminder times are pre‑set in the meter for 8:00am, 12:00pm, 6:00pm, and 10:00pm. You may
change reminder times by following the instructions below.
• If a general test Reminder is set for the same time as a Post Meal reminder, the Post Meal reminder will
appear/beep instead of the general Reminder (see the Post Meal Reminders section of this chapter for
details).
Turn the meter on by briefly
pressing . From Main Menu,
press to highlight Settings.
Press .
Press to highlight More
Options. Press .
Press or to highlight
Reminders. Press .
123
Reminders
Reminders
52926_07414587001_EN.indb 53 6/2/16 2:53 PM
54
Meter Settings
5
Pre‑set reminder times appear
on the display. Press to
highlight a reminder time. Press
.
The pre‑set reminder time
appears. Press or to
select On or Off. Press to
move to the option.
To change the Reminder time
shown:
Press to highlight Edit time.
Press .
Press or to adjust each
field. Press to move to the
next field. Press to return to
the previous menu.
4 5
Reminders
52926_07414587001_EN.indb 54 6/2/16 2:53 PM
55
Meter Settings 5
A indicates the reminder is
set for the time shown and
automatically set to On. To turn
the reminder off, press to
highlight Off.
Press to return to Reminders.
The reminder time appears.
Press to continue to set
additional reminders or press
to return to More Options.
6 7
Reminders
52926_07414587001_EN.indb 55 6/2/16 2:53 PM
56
Meter Settings
5
Post Meal Reminders
Post Meal reminders can be set to remind you to test again later when you add a Before Meal comment
to a blood glucose result. When a reminder occurs, a series of beeps sound and is displayed.
Post Meal reminders:
• turn o by inserting a test strip or pressing any button.
• are postponed until the next test reminder if a test was performed within 15minutes of a test reminder.
• do not appear/beep if the meter is on at the test reminder time (including when the meter is connected
to a USB cable).
• do not appear/beep if the meter is connected and communicating to a Continua Certified
®
manager.
• do not beep if the meter’s beeper is set to o.
• do not appear/beep if the batteries need to be replaced.
Set Post Meal Reminders
• Adding a Before Meal comment to a blood glucose result sets a Post Meal reminder in the meter.
• Marking blood glucose results with a Post Meal comment provides more information about your test
results to help you and your healthcare professional in the management of your diabetes.
• Talk to your healthcare professional to determine your Post Meal test time.
• Select 1hour, 1.5hours, or 2hours for Post Meal reminders to occur.
Post Meal Reminders
52926_07414587001_EN.indb 56 6/2/16 2:53 PM
57
Meter Settings 5
Post Meal Reminders
Turn the meter on by briefly
pressing . From Main Menu,
press to highlight Settings.
Press .
Press to highlight More
Options. Press .
Press to highlight Post
Meal. Press .
123
52926_07414587001_EN.indb 57 6/2/16 2:53 PM
58
Meter Settings
5
Post Meal Reminders
Press or to highlight On.
Press to move to the
option.
Press to highlight Edit time.
Press .
Press or to highlight
1hour, 1.5hours, or 2hours
after a meal for Post Meal
reminders to occur.
Press to move to the
option.
Press to set and return to
the previous menu.
456
52926_07414587001_EN.indb 58 6/2/16 2:53 PM
59
Meter Settings 5
Last Result
Turn the meter on by briefly
pressing . From Main Menu,
press to highlight Settings.
Press .
O – only the current blood glucose result 1 appears.
On – the previous blood glucose result 2 appears with the current
blood glucose result.
1
2
1
Last Result
Select whether the previous blood glucose result appears with the current blood glucose result.
Test results older than 24hours do not appear.
52926_07414587001_EN.indb 59 6/2/16 2:53 PM
60
Meter Settings
5
Last Result
Press to highlight More
Options. Press .
Press to highlight Last
Result. Press .
2 3
Press or to highlight On
or Off. Press to move to
the option.
Press to set the option and
return to the previous menu.
4
52926_07414587001_EN.indb 60 6/2/16 2:53 PM
