User manual
FCC ID : VA5JR120AM433
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
CAUTION :
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
IC : 7087A-R120AM
Statement
: The term “IC:” before the radio certification number only signifies
that Industry Canada technical specifications were met.
CAUTION
: The User that modifications to the unit may void the user’s
authority to operate the unit
USER’S GUIDE
User’s GUIDE
TABLE OF CONTENTS
Safety Information
Remote Button Functions
Remote Learning Routine
Keyless Entry
Alarm Mode
Trunk Release
Panic Mode
Optional Programmable Features
Ignition Lock
Passive Locking
Page 4
Page 4
Page 5
Page 5
Page 5
Page 6
Page 6
Page 7
Page 7
Page 7
Page 3
User’s GUIDE
Safety Information
Please take these safety precautions into consideration, under the following conditions :
Page 4
1. Servicing the vehicle
When servicing your automobile (i.e. changing the oil, washing your car), the
Magicar system should be in Valet Mode.
2. Loaning your vehicle to others
Whenever you loan your vehicle to an individual who is not familiar with Magicar,
please put the vehicle in Valet mode. This will prevent the vehicle barrower from
accidentally activating the Magicar auto-security system.
Page 5
Remote Learning Routine
The Magicar will allow up to three remotes to be programmed to one vehicle.
Please perform the following procedure to add or reprogram additional remotes.
Step1:
Activate Valet/ Programming mode by manually
turning the ignition on and off three times
(between Acc and
On)
with the key within a 7 second period.
The parking lights will flash once with successful completion of
this step.
Remote Button Functions
1
2
3
4
5
6
Lock0.5 sec
0.5 sec
0.5 sec
Unlock
Button Press Function
2 sec Panic, Press Lock to shut off Siren
Siren Chirps for Lock /Unlock - on/off
0.5 sec Passive Arming - on/off
2 sec Trunk Release
Note : " "
Means pressing the button for 2 seconds.
"
( )
"
Means simultaneously pressing the buttons.
"
( )
"
Means simultaneously pressing the buttons for 2 seconds.
To lock the vehicle, pressing the button for a 0.5 second.
To unlock the vehicle, press the button for a 0.5 second. If the pressing of the
lock/unlock buttons does not lock/unlock the doors, you will need to release the
button and try again, as the remote stops transmitting as soon as the LED stops
flashing. If the button is pressed for 2 seconds, it will panic the system.
Keyless Entry
Step2 :
Within a 7 second period after cycling the ignition for the 3rd time,
Press the button for a 0.5 second. The parking lights will flash
once to confirm that the transmitter has been programmed.
You can continue programming additional remotes. The parking lights
will flash two times when the programming mode has expired.
To arm the vehicle, press the button .
To disarm the vehicle, press the button.
If pressing the arm/disarm buttons does not arm/disarm the vehicle, you will need to
release the button and try again, as the remote stops transmitting as soon as the
LED stops flashing.
Press the buttons for a 0.5 second to mute the vehicle siren when
arming or disarming your vehicle. Keep in mind that your siren will still be activated
for all other modes(i.e.panic or alarm trigger) regardless of whether or not your siren
is in mute mode. The siren will be mute only when arming or disarming your vehicle.
Alarm Mode
When the alarm is armed, the starter kill function (an optional feature provided by
your installer) is activated. This feature disengages the starter mechanism on your
vehicle and prevents it from starting, even with a key.
Page 7Page 6
Note :
If you lose your remote after you have armed the vehicle, use your key
to open the door. The siren will go off. Turn the ignition on and off,
3 times with your key to shut down the alarm and put the system into
valet mode. You can cancel valet mode with a remote later on.
See: Valet mode, on page 7.
Trunk Release
Press the button for 2 seconds, in order to unlock and release your trunk door.
If pressing the trunk release button does not release the trunk, you will need to
release the button and try again, as the remote stops transmitting as soon as the
LED stops flashing.Note that the trunk release function will not only release the trunk
but will unlock the all doors as well.
Panic Mode
If Anti-Jacking option has been programmed (ask your dealer if you would
like to have this option) and the Ignition-Kill has been installed , Panic
Mode works as Anti-Jacking if the car key is in the ignition. Anti-Jacking
mode is activated while key is in the ignition,
a) the Siren will go off for 1.5 minutes, and b) Ignition-Kill will be activated
after the first 30 seconds. This is to give a 30 second warning to the
hijacker, then to disconnect the ignition to stop the vehicle.
Press the button for 2 seconds to enter Panic Mode. In this mode, the car will be
armed,if not armed already, and the siren will be activated and the parking lights will be
flashed. In order to disengage Panic Mode, press the button.
Then, press the button for a 0.5 second to unlock/ disarm your vehicle.
OPTIONAL PROGRAMMABLE FEATURES
Ignition Lock
These additional features may be programmed to the Magicar system by your
authorized Magicar dealer.
This programmable option enables your vehicle to automatically lock the doors once
the key is in the ignition for 30 Seconds.(Also you can lock the doors, If you step on
the brake pedal within 30 Seconds) In addition, the vehicle will automatically unlock
the doors when the key is pulled out of the ignition.
Passive Locking
You can turn this function on or off by pressing the buttons for a 0.5 sec-
ond. When setting to passive locking, your system will lock automatically 30 seconds
after all the car doors are closed.
