User Manual
User Manual
5-5 Togoshi 6 Chome, Shinagawa-Ku, Tokyo 142-8511 Japan
Product Name: WLAN Complete Module
Model number: VRL4149-0601F
GENERAL
This product is a 2.4/5GHz Wireless Communication module that uses WLAN (Wireless
LAN) technology.
This Module enables the host device to connect with the Wireless LAN Access Point.
SPEC
・RF Standard : 802.11b, 802.11g, 802.11n (2.4/5GHz), 802.11a
・ Operation Temperature Range : -20℃ to +70℃
・ External Dimensions Remote control: 35mm x 27mm x 3.1mm
・ Receiver I/F: SDIO
・ Frequency Range:
2412MHz～2462MHz (5MHz interval, 11 Channels) (FCC/IC)
2412MHz～2472MHz (5MHz interval, 13 Channels) (CE)
5180MHz～5320MHz (20MHz interval, 8 Channels) (FCC/IC/CE)
5500MHz～5700MHz (20MHz interval, 11 Channels) (FCC/IC/CE)
(Except 5600MHz～5650MHz in Canada)
5745MHz～5825MHz (20MHz interval, 5 Channels) (FCC/IC)
INFORMATION
Information below must be printed on the set product and the manual of the set product.
Contains FCC ID: GT3FC016
Contains IC: 3683A-FC016
Common in USA-Federal Communications Commission (FCC) and Industrial
Canada (IC RSS-Gen Category Ⅰ)
User Manual
5-5 Togoshi 6 Chome, Shinagawa-Ku, Tokyo 142-8511 Japan
※Over 5mm is recommended as a height of CE marking.
Over 5mm
User Manual
5-5 Togoshi 6 Chome, Shinagawa-Ku, Tokyo 142-8511 Japan
SETUP
FPC CABLE
20Pin Connector
To HOST Device
Insert direction
User Manual
5-5 Togoshi 6 Chome, Shinagawa-Ku, Tokyo 142-8511 Japan
Regulatory Information
Manual Information
The following text shall be placed on the manual of end product.
RF Exposure Appliance
The available scientific evidence does not show that any health problems are associated with using low power
wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe.
Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being
used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that
does not produce heating effects causes no known adverse health effects. Many studies of low-level RF
exposures have not found any biological effects. Some studies have suggested that some biological effects
might occur, but such findings have not been confirmed by additional research. Wireless LAN
module(VRL4149-0601F) has been tested and found to comply with FCC/IC radiation exposure limits set forth
for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of
the IC radio frequency (RF) Exposure rules.
Les connaissances scientifiques dont nous disposons n’ont mis en évidence aucun problème de santé associé
à l’usage des appareils sans fil à faible puissance. Nous ne sommes cependant pas en mesure de prouver que
ces appareils sans fil à faible puissance sont entièrement sans danger. Les appareils sans fil à faible puissance
émettent une énergie fréquence radioélectrique (RF) très faible dans le spectre des micro-ondes lorsqu’ils
sont utilisés. Alors qu’une dose élevée de RF peut avoir des effets sur la santé (en chauffant les tissus),
l’exposition à de faibles RF qui ne produisent pas de chaleur n’a pas de mauvais effets connus sur la santé. De
nombreuses études ont été menées sur les expositions aux RF faibles et n’ont découvert aucun effet
biologique. Certaines études ont suggéré qu’il pouvait y avoir certains effets biologiques, mais ces résultats
n’ont pas été confirmés par des recherches supplémentaires. Wireless LAN module(VRL4149-0601F) a été
testé et jugé conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices d'exposition et
d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC.
User Manual
5-5 Togoshi 6 Chome, Shinagawa-Ku, Tokyo 142-8511 Japan
USA-Federal Communications Commission (FCC) Only
PART 15
FPC Cable for connection
Regulation for using 5.47-5.725 GHz
PART 15 Subpart C and Subpart E
Industrial Canada (IC RSS-Gen and ICES-003) Only
Regulation for using 5.15-5.25 GHz
Regulation for using 5.25-5.35 GHz and 5.65GHz-5.85GHz
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
A FPC Cable must be used for connection to the host com
p
uter.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
5.15-5.25GHz band is restricted to indoor operations only.
La bande 5 150-5 250 MHz est restreints à une utilisation à l’intérieur.
5.47-5.725GHz band is restricted to indoor operations only. This module is used for a particular printer.
