SPECTRA Technologies SR300 Contactless Reader User Manual SR300 InstallationGuide Booklet CE FCC
SPECTRA Technologies Holdings Co. Ltd. Contactless Reader SR300 InstallationGuide Booklet CE FCC
User Manual
SR300CONTACTLESS CARD READER
Installation Guide
Version 1.0 SPECTRA Technologies
ISO9001 : 2008
20002812 QM08
SPECTRA Technologies
ISO14001 : 2004
20002812 UM
SR300
1
Installation Guide
SR300
Layout & Function Descriptions of SR300
1
1.1 Main Unit & Accessories
Contactless Card Reader
Desktop Stand (Optional)
All-in-one Connection Cable
Screws for Desktop Stand (Optional)
Power Adaptor (Optional) - provides
8.5V DC supply
2
1.2
Features at a Glance
SR300
LCD Display
Capacitive Sensing
Button
Status Displaying
LED
Card Reading Area
Cable Cover - Unless repairing
engineer, please do not open the cover
and unplug the cable connector
Warning !
Reset Button
SAM Card Door
Screw Holes for
Desktop Stand
Installation Guide
3
1.3 Types of All-in-one Connection Cable
2
RS232 Communication Port
Power Adaptor - provides
8.5V DC supply
SR300
Installation Guide
4
1.4
Installation of SAM Card
SR300
1
2
SAM Card - for version equipped with SAM card reader only
Installation Guide
5
1.5
Assembling of
Desktop Stand
SR300
1
3
2
Install Desktop Stand by screwing
the screws provided
Adjust the required angle
Tight fastening the lateral
screws to fix the reader
Installation Guide
6
How to Operate
2
2.1
Turn On Procedure
Power is on whenever plugged.
Transaction operation is ready.
SR300
Installation Guide
7
Safety & Maintenance
3
3.1
Basic Safety Practice
3.2
Safety Warning
While using SR300 and its accessories,
please follow the safety instruction to avoid
fire, electric shock and personal injury.
Read this instruction in detail
Disconnect the power and accessories before
cleaning, use dry flannelette and soft brush
for cleaning
Do not place the unit near water
Do not spray any liquid onto the unit
Put the unit on stable platform to avoid
damage by drop
Keep the unit away from high temperature and
poor ventilation area
Ensure electricity supply is safe and stable
To avoid electric shock, do not disassemble
the unit by yourself. Send it to agency for
repairing if necessary
Do not use SR300 and its accessories during
explosive gas leakage
For the following cases, disconnect power,
other accessories and send for repairing,
~ Damage on power cable or plug
~ Liquid get into pinpad
~ Pinpad gets wet in raining
~ Still abnormal function after following all the
instruction mentioned
~ Pinpad broken
~ Pinpad obvious abnormal
Using the provided cable or power adaptor
to power the reader
SR300
Installation Guide
8
3.3
Location for Installation
3.4
Maintenance
Should be safe and convenient for operators
and users
Should be placed on stable working platform
or mounted on wall securely for power and
accessories connection
Good ventilation and should have 20cm
space around the pinpad
DO NOT expose PR608 in following
environment
~ Near electrical appliance with high frequency
EM wave such as air conditioner, electric fan,
motor, neon sign etc.
~ Liquid container such as water trough, sink,
pond etc.
~ High temperature or humidity place
~ High containing of VOC, salty and dusty area
~ Sunlight or high thermal radiation area
~ Near demagnetizing system and magnetic
security system
SR300 has been designed to provide stable
service for users with less maintenance.
In order to ensure best performance, we
suggested the followings.
Avoid exposing in sunlight, high temperature,
high humidity and dusty area
Keep in dry, clean and tidy environment
Do not keep in extreme hot and cold place
Do not disassemble the AC/DC power adaptor
Do not shake and thrash the pinpad heavily
Cleaning of SR300
Use flannelette to remove dust on pinpad
Use mild alcohol to remove stubborn stains
If possible, use low pressure blower to blow
out dust on keypad
Use flannelette or lens cleaning paper to
clean the display
Send for repairing
If it is necessary to send back SR300 for
repairing, please contact agency, pack the
pinpad properly (use original packing material
if possible) to avoid damage during
transportation
SR300
Installation Guide
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the followingmeasures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
