USERS MANUAL 3
Watching a movie
58
USING THE DISPLAY FUNCTION
hgfZCV
During playback, press the INFO button on the remote
control.
If the Blu-ray Disc has the PIP feature, press the INFO
button in the PIP section to display PIP-related
information.
Press the
▲▼
buttons to select the desired item.
Press the
◄ ►
buttons to make the desired setup change
and then press the ENTER button.
You may use the number buttons of the remote control
to directly access a title, chapter or to start the playback
from a desired time.
To make the screen disappear, press the INFO button
again.
If you are playing contents from the info menu, some functions may not be enabled depending on the disc.
Title : To access the desired title when there is more than one in the disc. For example, if there is more than
one movie on a Blu-ray Disc/DVD, each movie will be identifi ed as a Title.
Chapter: Most Blu-ray Disc/DVD discs are recorded in chapters so that you can quickly fi nd a specifi c chapter.
Audio : Refers to the fi lm's soundtrack language. A Blu-ray Disc can contain up to 32 audio languages and a
DVD up to 8.
Playing Time : Allows playback of the fi lm from a desired time. You must enter the starting time as a reference.
The time search function does not operate on some discs.
Subtitle : Refers to the subtitle languages available in the disc. You will be able to choose the subtitle
languages or, if you prefer, turn them off from the screen. A Blu-ray Disc can contain up to 255 subtitle
languages, and a DVD up to 32.
Angle : When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE
function.
PIP Video/ PIP Audio : You can make PIP Video or PIP Audio settings if the current title of a Blu-ray Disc
appears in the PIP section. The PIP Video / PIP Audio options, however, will be disabled with a Blu-ray Disc
that does not support the PIP feature.
Picture Mode : This function enables you to adjust video quality when you are connected to a TV via HDMI.
- Dynamic : Choose this setting to increase Sharpness.
- Normal : Choose this setting for most viewing applications.
- Movie : This is the best setting for watching movies.
- User : The user can adjust the sharpness and noise reduction function respectively.
1.
•
2.
3.
•
4.
M
BD Info
§
Change
s
Select
Title : 000/034
Chapter : 000/002
Playing Time : 00:00:06
Audio : 1/1 ENG Multi CH
Subtitle : NONE
Angle : 01/01
Picture Mode : Normal
BD Info
§
Change
s
Select
Title : 000/034
Chapter : 000/002
Playing Time : 00:00:06
Audio : 1/1 ENG Multi CH
Subtitle : NONE
Angle : 01/01
Video PIP
: 01/01
Audio PIP
: 1/1 ENG 2CH
Picture Mode : Normal
<INFO menu for the PIP section>
HT-BD8200_XAA_0528-3.indd 58HT-BD8200_XAA_0528-3.indd 58 2009-05-30 2:59:092009-05-30 2:59:09
59
ENG ● WATCHING A MOVIE
USING THE DISC MENU & POPUP/TITLE MENU
Using the Disc Menu hZ
During playback, press the DISC MENU button on the
remote control.
Press the
▲▼◄ ►
buttons to make the desired selection,
then press the
►
or ENTER button.
The Disc menu setup items may vary from disc to disc.
Depending on the disc, the Disc Menu may not be available.
Using the Title Menu Z
During playback, press the TITLE MENU button on the remote control.
Press the
▲▼◄ ►
buttons to make the desired selection, then press the ENTER button.
The Title menu setup options may vary from disc to disc.
Depending on the disc, the Title Menu may not be available.
Title Menu will only be displayed if there are at least two titles on the disc.
Playing the Title List gf
With the unit in Stop mode/Playback mode, press the
DISC MENU or TITLE MENU button.
Press the
▲▼
buttons to select an entry you want to play
from Title List, then press the
►
or ENTER button.
The selected entry (title) will be played back.
- Go to Playlist -
To go to the Playlist, press the RED(A) button.
Using the Popup Menu h
During playback, press the POPUP MENU button on the
remote control.
Press the
▲▼◄ ►
buttons or ENTER button to select
the desired menu.
The Popup menu setup options may vary from disc to
disc.
Depending on the disc, the Popup Menu may not be available.
1.
2.
•
M
1.
2.
•
M
1.
2.
1.
2.
•
M
3 4 5 6 7 8 9 10 11 12 13 14 15
▼
PLAY MOVIE LANGUAGES SCENE SELECTIONS PREVIEWS
3 4 5 6 7 8 9 10 11 12 13 14 15
▼
MAIN MENU AUDIO SET UP SUBTITLES SCENE SELECTIONS
CD
CD
BD-RE
BD-RE
Video
Music
Setup
Title 008 00:04:36
Title 009 00:04:17
Title 010 00:04:11
Title 011 00:04:07
Title 012 00:04:46
Title 013 00:04:21
Title 014 00:03:43
◄
Page
HT-BD8200_XAA_0528-3.indd 59HT-BD8200_XAA_0528-3.indd 59 2009-05-30 2:59:152009-05-30 2:59:15
Watching a movie
60
REPEAT PLAY
Repeat the current chapter or title.
Repeat playback hgfZCV
During playback, press the REPEAT button on the remote
control. Repeat screen appears.
Press the
▲▼
buttons to select Chapter or Title.
Blu-ray Disc/DVD repeats play by chapter or title.
To return to normal play, press the REPEAT button again,
then press the
▲▼
buttons to select Off.
Depending on the disc, the Repeat function may not be available.
Using the A-B Repeat function hgfZCV
Press the REPEAT A-B button on the remote control
during playback.
Press the REPEAT A-B button at the point where you
want repeat play to start (A).
Press the REPEAT A-B button at the point where you
want repeat play to stop (B).
To return to normal play, press the CANCEL button.
Point B cannot be set until 5 seconds of playback has elapsed from point A.
1.
2.
•
3.
M
1.
2.
3.
4.
M
Repeat Off
► Repeat A-B
00:18:41 / 01:34:37
REPEAT A B
Off
Exit
DVD
DVD
HT-BD8200_XAA_0528-3.indd 60HT-BD8200_XAA_0528-3.indd 60 2009-05-30 2:59:202009-05-30 2:59:20
61
ENG ● WATCHING A MOVIE
SELECTING THE AUDIO LANGUAGE hgfZ
You can select a desired audio language quickly and easily with the AUDIO button.
Using the AUDIO button
Press the AUDIO button during playback. The Audio
changes when the button is pressed repeatedly.
The audio languages are represented by abbreviations.
To remove the Audio bar, press the CANCEL or
RETURN button.
Using the INFO button
During playback, press the INFO button on the remote
control.
Press the
▲▼
buttons to select Audio language.
Press the
◄ ►
buttons on the remote control to select the desired audio language.
This function depends on what audio languages are encoded on the disc and may not be
available.
A Blu-ray Disc can contain up to 32 audio languages and a DVD up to 8.
Depending on the disc type, you can use the AUDIO button to change the audio soundtrack
as well as the audio language.
Some Blu-ray Discs may allow you to select either the multi-channel LPCM or Dolby digital
audio soundtrack in English.
Information about the primary / secondary mode will be also displayed if the Blu-ray Disc
has a PIP section.
Use the ◄ ► button to switch between primary and secondary audio modes.
The ◄ ► indicator will not be displayed on the screen if the PIP section does not contain
any PIP audio settings.
SELECTING THE SUBTITLE LANGUAGE
You can select a desired subtitle quickly and easily with the SUBTITLE button.
Using the SUBTITLE button hZ
Press the SUBTITLE button. The subtitle changes when
the button is pressed repeatedly. The subtitle languages
are represented by abbreviations.
To remove the Subtitle bar, press the CANCEL or
RETURN button.
1.
•
2.
1.
2.
3.
M
1.
2.
Audio 1/4 ENG Dolby Digital Multi CH
Subtitle 0/2 Off
HT-BD8200_XAA_0528-3.indd 61HT-BD8200_XAA_0528-3.indd 61 2009-05-30 2:59:212009-05-30 2:59:21
Watching a movie
62
SELECTING THE SUBTITLE LANGUAGE
Using the INFO button
During playback, press the INFO button on the remote control.
Press the
▲▼
buttons to select Subtitle.
Press the
◄ ►
buttons on the remote control to select the desired subtitle language.
Depending on the Blu-ray Disc / DVD, you may be able to change the desired subtitle in
the Disc Menu.
Press the DISC MENU button.
This function depends on what subtitles are encoded on the disc and may not be available
on all Blu-ray Discs/DVDs.
A Blu-ray Disc can contain up to 255 subtitle languages and a DVD up to 32.
Information about the primary / secondary mode will be also displayed if the Blu-ray Disc
has a PIP section.
This function changes both the primary and secondary subtitles at the same time.
The total number of subtitles is the sum of the primary and secondary ones.
CHANGING THE CAMERA ANGLE
When a Blu-ray Disc/DVD contains multiple angles of a particular scene, you can use the ANGLE function.
Using the ANGLE function hZ
During playback, press the INFO button on the remote
control.
Press the
▲▼
buttons to select Angle.
Press the
◄ ►
buttons or you can use the number buttons
on the remote control to select the desired angle.
If the disc has only one angle, this feature won’t work. Currently, very few discs have this
feature.
Depending on the disc, these functions may not work.
1.
2.
3.
M
1.
2.
3.
M
DVD-Vedio Info
Title
Chapter
Playing Time
Audio
Subtitle
Angle
: 001/006
: 003/016
: 00:11:14
: ENG Multi CH
: ENG
: 01/01
Change
Move
HT-BD8200_XAA_0528-3.indd 62HT-BD8200_XAA_0528-3.indd 62 2009-05-30 2:59:212009-05-30 2:59:21
63
ENG ● WATCHING A MOVIE
PIP (PICTURE IN PICTURE) SETTINGS
The PIP feature allows you to view additional content (such as commentaries) in a small screen window while the
movie is playing.
Using the PIP button h
If the current Blu-ray Disc features the PIP function, you
can use the PIP button to turn PIP On or Off.
Each time you press the PIP button, you can toggle
between
PIP On
and
PIP Off
.
You can change detailed settings of the PIP feature in the INFO menu (see page 58:
selection of secondary audio, video stream and subtitle etc.).
If you switch from PIP Video, PIP Audio will change automatically in accordance with PIP
Video.
If the Blu-ray Disc supports only PIP Audio, you can just press the PIP button to turn the
secondary audio on or off.
BD-LIVE™
The Blu-ray Home Theater supports BD-LIVE which enables you to enjoy a variety of interactive service contents
provided by the disc manufacturer through network connection.
Using the BD-LIVE Disc
Connect the network (see pages 30~31) and check the network setup (see pages 53~57).
Insert a Blu-ray disc that supports BD-LIVE.
Select the contents provided by the disc manufacturer to enjoy the BD-LIVE.
The way you use BD-LIVE and the features may differ, depending on the disc.
To use BD-LIVE, you must insert a mimimum 1GB USB memory device into one of the
USB slots.
1.
2.
M
1.
2.
3.
M
HT-BD8200_XAA_0528-3.indd 63HT-BD8200_XAA_0528-3.indd 63 2009-05-30 2:59:222009-05-30 2:59:22
Watching a movie
64
USING THE INSTANT STREAMING FEATURE PROVIDED BY NETFLIX
This Blu-ray Home Theater supports the Netfl ix streaming service which enables you to enjoy various movies via
network connection. Before enjoying this feature, you must perform the LAN connection (see page 28).
With the unit in Stop mode/No Disc mode, press the
MENU button.
Press the
▲▼
buttons to select Netfl ix, then press the
ENTER or
►
button.
If you don't have an account, select "no-start my FREE
trial" and subscribe to http://netfl ix.com/samsung from
your computer. A user with existing account can select the
"yes-activate instant streaming from Netfl ix".
If you have an existing account, you will see the next
window if Yes was selected. Select "I'm now a member".
You can also start Netfl ix streaming by pressing the RED(A) button on your remote control
while the Samsung logo screen is displayed.
Video quality of the Netfl ix contents (SD or HD) depends on the network speed and the
original bit rate of the Netfl ix contents
When you use the Netfi x streaming sevice with this Blu-ray Home Theater, refer to the LAN
connection.
(See pages 28~29)
In order to activate your Blu-ray Home Theater with Netfl ix with the code provided, you will
need an active LAN connection to both a PC and your player. To connect the network with
Blu-ray Home Theater, refer to the pages 28~29.
1.
2.
3.
4.
M
http://net ix.com/samsung
http://net ix.com/samsung
HT-BD8200_XAA_0528-3.indd 64HT-BD8200_XAA_0528-3.indd 64 2009-05-30 2:59:222009-05-30 2:59:22
65
ENG ● WATCHING A MOVIE
To add a movie to the Instant Queue list of this Blu-ray
Home Theater, select the "Add to Instant" button on the
Netfl ix "Watch Instantly" web page using your PC.
Movies you added to the Instant Queue from the web are
listed.
Press the ENTER button of the remote control and select
a movie to display the next screen.
To add the movie in Instant Queue list of this Blu-ray
Home Theater, you can select "Add to Instant" button
on "Watch Instantly" page of Netfl ix web site using your
PC.
Press the PLAY button to start the playback, and the initial
buffering of the streamed data is shown.
Press the SCAN button to select a scene of your choice.
To stop the movie or go to the instant movie list, press
the upper arrow or Stop button.
For more information on the Netfl ix Instant Streaming feature visit http:www.netfl ix.com/
help/tv or login to your Netfl ix account and click "Help" at the top of the page.
5.
6.
•
7.
8.
•
M
Actor or Actress name1 Actor or Actress name2
Name
Movie 1
e
Exit
HT-BD8200_XAA_0528-3.indd 65HT-BD8200_XAA_0528-3.indd 65 2009-05-30 2:59:252009-05-30 2:59:25
Watching a movie
66
DIVX PLAYBACK
The functions discussed on this page apply to DivX disc playback only.
Skip Forward/Back D
During playback, press the #, $ button.
Goes to the next fi le whenever you press the
$
button,
if there are over 2 fi les on the disc.
Goes to the previous fi le whenever you press the
#
button, if there are over 2 fi les on the disc.
Fast Playback D
During playback, press the , button.
To play back the disc at a faster speed, press the or
button during playback.
Each time you press either button, the playback speed
will change as follows:
2x 4x 8x.
Audio Display D
Press the AUDIO button.
If there are multiple audio languages on a disc, you can
toggle between them.
Each time you press the button, your selection will toggle
between AUDIO (1/N, 2/N ...).
Subtitle Display D
Press the SUBTITLE button.
Each time you press the button, your selection will toggle
between SUBTITLE (1/N, 2/N ...) and SUBTITLE OFF.
If the disc has only one subtitle fi le, it will be played
automatically.
See number 2 (Caption Function) below for more details
concerning Subtitle usage with DivX discs.
•
•
•
•
•
•
•
•
HT-BD8200_XAA_0528-3.indd 66HT-BD8200_XAA_0528-3.indd 66 2009-05-30 2:59:282009-05-30 2:59:28
67
ENG ● WATCHING A MOVIE
DivX(Digital internet video express)
DivX is a video fi le format developed by Microsoft and is based on MPEG4 compression technology to
provide audio and video data over the Internet in real-time.
MPEG4 is used for video encoding and MP3 for audio encoding so that the users can watch a movie at
near DVD-quality video and audio.
Supported Formats
This product only supports the following media formats.If both video and audio formats are not
supported, the user may experience problems such as broken images or no sound.
Supported Video Formats
Format AVI
Supported Versions DivX3.11 ~ DivX5.X, XviD
Supported Audio Formats
Format MP3 AC3
Bit Rate 56 ~ 320 kbps 128 ~384kbps
Sampling Frequency 32 ~ 48kHz 44.1/48kHz
This product supports up to 720x480 pixels.
When you play a disc whose sampling frequency is higher than 48khz or 320kbps, you may
experience shaking on the screen during playback.
Qpel and gmc is not supported.
Caption Function
You must have some experience with video extraction and editing in order to use this feature
properly.
To use the caption function, save the caption fi le (*.smi) in the same fi le name as that of the DivX
media fi le (*.avi) within the same folder.
Example. Root Samsung_007CD1.avi
Samsung_007CD1.smi
"ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an
offi cial DivX Certifi ed device that plays DivX video. Visit www.divx.com for more
information and software tools to convert your fi les into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certifi ed® device must be registered
in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate
the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete
the registration process and learn more about DivX VOD.
DivX Certifi ed to play DivX video up to HD 1080p, including premium content"
1.
•
•
•
2.
•
•
•
HT-BD8200_XAA_0528-3.indd 67HT-BD8200_XAA_0528-3.indd 67 2009-05-30 2:59:292009-05-30 2:59:29
Listening to music
68
BUTTONS ON THE REMOTE CONTROL USED FOR AUDIO CD
(CD-DA)/ MP3 DISC PLAYBACK
PAUSE button : Pauses playback.
SKIP ( ) button : During playback, moves to the next page in the
Music List or moves to the next track in the Playlist.
PLAY button : Plays the currently selected track.
▲▼ buttons : Selects a track(song) in the Music List or Playlist.
COLOR buttons
RED(A) button : Selects the Play Mode(Repeat) during playback.
GREEN(B) button : Go to Playlist from Music List.
YELLOW(C) button : Playlist play.
◄ ► buttons
◄ : Plays the applicable track, according to the current position.
► : Moves to the menu.
ENTER button : Plays the selected track (song).
STOP button : Stops a track(song).
SKIP ( ) button : If you pressed this button after three seconds of
playback, the current track will be replayed from the beginning. But, if
you pressed this button within three seconds after playback starts, the
previous track will be played.
Used to move to the previous page in the Music List or Playlist.
REPEAT AUDIO CD(CD-DA) & MP3
During playback, press the REPEAT or RED(A) button repeatedly to select the repeat mode you want.
When playing an Audio CD(CD-DA) :
When playing an MP3 disc :
Normal (Audio CD(CD-DA)/MP3): Tracks on a disc are played in the order in which they were
recorded on the disc.
Repeat Track (Audio CD(CD-DA)/MP3)
Repeat Folder (MP3)
Random (Audio CD(CD-DA)/MP3)
- When playing an Audio CD(CD-DA): The random option plays a disc’s tracks in random order.
- When playing an MP3 disc : The random option plays a folder’s fi le in random order.
Repeat All (Audio CD(CD-DA)): All tracks are repeated.
- To return to normal playback -
Press the REPEAT or
RED(A)
button repeatedly to return to normal playback.
1.
2.
3.
4.
5.
•
•
•
6.
7.
8.
9.
•
•
•
•
•
RETURN
ENTER
A B C D
MENU
EXIT
INFO
0
STOP PLAY
RETURN
HT-BD8200_XAA_0528-3.indd 68HT-BD8200_XAA_0528-3.indd 68 2009-05-30 2:59:292009-05-30 2:59:29
69
ENG ● LISTENING TO MUSIC
PLAYING AN AUDIO CD(CD-DA)/MP3
AF
Insert an Audio CD(CD-DA) or an MP3 Disc into the disc
tray.
For an Audio CD, the fi rst track will be played
automatically.
For an MP3 disc, press the
▲▼
buttons to select
Music, then press the ENTER button.
(You can listen to mp3 fi les using a USB storage device)
To move to the Music List, press the STOP or RETURN
button.
The Music List screen is displayed on your TV.
Press the
▲▼
buttons to select the track you want to
play, then press the ENTER button.
Audio CD(CD-DA)/MP3 Screen Elements
Displays the media type.
Current track (song)
Displays the number of the track currently being played.
Play Status Bar.
Displays the repeat status.
Displays the current play index, total track number.
Current /Total Play Time.
Displays available COLOR buttons.
1.
•
•
2.
3.
❖
CD
CD
► TRACK 001 1/18
00:02:24 / 00:05:57
A
Play Mode
CD
CD
► TRACK 001 1/18
00:02:24 / 00:05:57
a
Play Mode
Video
◄ Music
Setup
CD
CD
B
Playlist
Page
TRACK 001 00:04:08 ►
TRACK 002 00:03:41
TRACK 003 00:03:17
TRACK 004 00:03:36
TRACK 005 00:03:47
TRACK 006 00:03:50
TRACK 007 00:03:54
◄
HT-BD8200_XAA_0528-3.indd 69HT-BD8200_XAA_0528-3.indd 69 2009-05-30 2:59:302009-05-30 2:59:30
Listening to music
70
Playlist
AF
You can create a playlist with up to 99 tracks.
Insert an Audio CD(CD-DA) or an MP3 Disc into the disc
tray.
For an Audio CD, the fi rst track will be played
automatically.
For an MP3 disc, press the
▲▼
buttons to select
Music, then press the ENTER button.
(You can listen to mp3 fi les using a USB storage device)
To move to the Music List, press the GREEN(B) or
RETURN button.
The Music List screen is displayed.
Press the GREEN(B) button to go to the Playlist.
Press the
▲▼
buttons to select a track, then press the
ENTER button to add it to the Playlist. Repeat this
procedure to add additional tracks.
If there is an undesired track in the playlist, press the
►▲▼
button to select that track, and then press the
ENTER button.
The selected track will be deleted.
Press the YELLOW(C) button to play the selected tracks.
When the track is fi nished, the next track will automatically
play.
To edit the Playlist, press the STOP or RETURN button.
To go to the Music List, press the RETURN button.
MP3 & JPEG Simultaneous playback AGF
You can enjoy listening to MP3 fi les while you simultaneously
view JPEG fi les.
When you play MP3 fi le, press the BLUE(D) button.
The slide show speed screen will be displayed.
Select the desired slide show speed.
To operate this function, you have to select the folder containing both music and photo
fi les.
When you play MP3 and JPEG fi les simultaneously, audio drop may occur according to
bitrate of MP3, size of JPEG image and method of encoding.
1.
•
•
2.
3.
4.
5.
•
6.
7.
8.
1.
2.
M
Video
◄ Music
Setup
CD
CD
CD
CD
B
Playlist
Page
TRACK 001 00:04:08
TRACK 002 00:03:41
TRACK 003 00:03:17 ►
TRACK 004 00:03:36
TRACK 005 00:03:47
TRACK 006 00:03:50
TRACK 007 00:03:54
TRACK 008 00:03:57
TRACK 009 00:03:59
◄
Video
◄ Music
Setup
CD
CD
TRACK 001
TRACK 002
TRACK 003
TRACK 004
TRACK 005
TRACK 006
TRACK 007
◄
Original ★ Playlist
B
Music List
C
Playlist play Add
Play
Video
◄ Music
Setup
CD
CD
◄
Original ★ Playlist
B
Music List
C
Playlist play Add
Play
TRACK 001
TRACK 002
TRACK 003
TRACK 004
TRACK 005
TRACK 006
TRACK 007
01.TRACK 001
02.TRACK 002
03.TRACK 003
CD
CD
►
001. SONG01.mp3
1/18
00:02:24 / 00:05:57
a
Play Mode
d
Slide Show
HT-BD8200_XAA_0528-3.indd 70HT-BD8200_XAA_0528-3.indd 70 2009-05-30 2:59:342009-05-30 2:59:34
71
ENG ● LISTENING TO MUSIC
USING THE INTERNET RADIO FEATURE PROVIDED BY PANDORA
Pandora provides music personalized to your taste.
With the unit in Stop mode/No Disc mode, press the
MENU button.
Press the
▲▼
buttons to select Pandora, then press the
ENTER or
►
button.
Pandora’s initial screen appears.
To run Pandora, you need to input the activation code at
<http://www.pandora.com/samsung> page with your PC.
After inputting the activation code, you may have to create
a new account if you don't have one yet.
If you already have an account, you can use the existing
account.
It automatically shows the list of stations created from the
web or player, and plays music.
Press the RED(A) button while the highlight is on the
station list to display the create station window.
Enter the keyword and press the BLUE(D) button to
display the search result.
(The station keyword entered should be a music genre,
artist, music title, etc.)
1.
2.
3.
4.
5.
6.
PANDORA
®
internet radio
PANDORA
®
internet radio
OK
Listen to radio that is personalized to your tastes.
Go to http://www.pandora.com/samsung
and enter XXXXXXXX to activate.
Enjoy music you know and discover music you’ll love.
It’s easy and FREE !
Please activate your device to continue.
Station Title 6
Station Title 5
Station Title 4
Station Title 3
Station Title 2
Station Title 1
Pandora
Song Title 1
Song Title 6
Song Title 2
Song Title 3
Song Title 4
Song Title 5
SongTitle 1
By : Musician
On : Album
Station List
Highlight
Station Title 6
Station Title 5
Station Title 4
Station Title 3
Pandora
Mirror, Set Me Free
Loreta And Desire
Misty
Isabelle
Melancholia
SongTitle 1
musician
Station Title 2
Station Title 1 Days Past
«
Number
s
Select
²
Return
Create a New Station
a
Back Space
b
Space
c
Clear
d
Create
AB
A B C D E F G H I J K L M N O P
Q R S T U V W X Y Z a b c d e f
g h i j k l m n o p q r s t u v
w x y z 1 2 3 4 5 6 7 8 9 0 – _
+ = . ~ ! @ # $ % ^ & ( ) / ? |
Station Title 5
Station Title 5
Station Title 4
Station Title 3
Pandora
The Winner Takes
Melancholia
SongTitle 1
musician
Station Title 2
Station Title 1
a
Select
b
Return
New Search
Matching
Bb
Bbcca
Abbma
aBbbba
aaaBan
Booooke
Acccaake
Song List
A
Create Station
B
Delete Station
C
QuickMix
Exit
A
Create Station
B
Delete Station
C
QuickMix
Exit
A
Create Station
B
Delete Station
C
QuickMix
Exit
HT-BD8200_XAA_0528-3.indd 71HT-BD8200_XAA_0528-3.indd 71 2009-05-30 2:59:442009-05-30 2:59:44
Listening to music
72
USING THE INTERNET RADIO FEATURE PROVIDED BY PANDORA
Press the GREEN(B) button while the highlight is on the
station list to delete the selected station.
You can edit your song list by using color buttons of the
remote control while the highlight is on the song list.
RED(A) : Thumbs Up. By indicating your preference to
the server, it plays more songs you love.
GREEN(B) : Thumbs Down. By indicating your dislike
to the server, it plays fewer songs you don’t like.
YELLOW(C) : Bookmark. It bookmarks the selected
song.
-
The bookmarked songs can be found on your PC by visiting www.pandora.com and viewing
"My Profi le".
BLUE(D) : Sleep Song. It excludes the selected song from the station for a month.
The www.pandora.com server refl ects the changes made on your player.
In order to activate your Blu-ray Home Theater with Pandora music with the code
provided, you will need an active LAN connection to both a PC and your player. To
connect the network with Blu-ray Home Theater, refer to the pages 28~29.
For further information on Pandora service or to unsubscribe the Pandora service, email
"samsung-support@pandora.com".
7.
8.
•
•
•
•
M
Station Title 5
Station Title 4
Station Title 3
Pandora
Song Title 1
Song Title 1
By : Musician
On : Album
Station Title 2
Station Title 1
!
Are you sure you want to delete this station?
Abba Radio
Delete Cancel
A
Create Station
B
Delete Station
C
QuickMix
Exit
Station Title 6
Station Title 5
Station Title 4
Station Title 3
Pandora
Song Title 5
Song Title 2
Song Title 3
Song Title 4
Song Title 5
Song Title 1
By : Musician
On : Album
Station Title 2
Song Title 1
Station Title 1
A
Thumbs Up
B
Thumbs Down
C
Bookmark
D
Sleep Song
Exit
HT-BD8200_XAA_0528-3.indd 72HT-BD8200_XAA_0528-3.indd 72 2009-05-30 2:59:452009-05-30 2:59:45
73
ENG ● VIEWING A PICTURE
Viewing a picture
VIEWING A PICTURE
Insert a JPEG disc into the Disc Slot .
The Menu screen is displayed.
Press the
▲▼
buttons to select Photo, then press the
ENTER button.
The Photo List is displayed.
Press the
▲▼
buttons to select a picture.
To see the next page, press the SKIP ( ) button.
To see the previous page, press the SKIP ( ) button.
SLIDE SHOW/SPEED
To setup, follow steps 1 and 2 above.
Press the BLUE(D) button.
The slide show starts.
When the SlideShow starts, press the BLUE(D) button to
adjust the play speed.
Each time you press the button, the play speed will
increase accordingly.
- To stop the Slide Show -
Press the STOP or RETURN button.
ROTATE
To setup, follow steps 1 and 3 above.
Press the ENTER button.
Use the RED(A) and GREEN(B) buttons to rotate the image in a
desired direction.
1.
•
2.
•
3.
•
•
3.
•
4.
•
4.
5.
➞➞
D
Speed
CD
CD
►
KE.JPG 03/07
CD
CD
_____1_.JPG 03/07
A r90° B u90° C Zoom D Speed
Slide Show
CD
CD
D
Slide Show
◄
Video
Music
◄ Photo
Setup
..
08 JUL 2000
127 KB
►
BEACH.
JPG
17 JUL 2000 27 KB
KE.
JPG
10 JUL 2000 194 KB
KE2.
JPG
10 JUL 2000 191 KB
MBHONG.
JPG
20 JUL 2000 30 KB
NEW_BEE.
JPG
08 JUL 2000 76 KB
_______1_.
JPG
18 JUL 2000 17 KB
HT-BD8200_XAA_0528-3.indd 73HT-BD8200_XAA_0528-3.indd 73 2009-05-30 2:59:462009-05-30 2:59:46
Viewing a picture
74
ZOOM
To setup, follow steps 1 to 3 in "Viewing a Picture" on page 73.
Press the ENTER button.
Press the YELLOW(C) button.
Use the YELLOW(C) or ZOOM button to zoom the image in/out.
- To move the area -
Press the
▲▼◄ ►
buttons to the area you want to enlarge.
- To stop the Zoom -
Press the YELLOW(C) button.
GO TO PHOTO LIST
To setup, follow steps 1 to 3 in "Viewing a Picture" on page 73.
Press the ENTER button.
To go Photo List, press the RETURN or STOP button.
4.
5.
6.
4.
5.
CD
CD
_____1_.JPG 03/07
A r90° B u90° C Zoom D Speed
Slide Show
C Zoom Move
x2
CD
CD
BEACH.JPG 03/07
A r90° B u90° C Zoom D Speed
Slide Show
CD
CD
D
Slide Show
◄
Video
Music
◄ Photo
Setup
..
08 JUL 2000
127 KB
BEACH.
JPG
17 JUL 2000 27 KB
►
KE.
JPG
10 JUL 2000 194 KB
KE2.
JPG
10 JUL 2000 191 KB
MBHONG.
JPG
20 JUL 2000 30 KB
NEW_BEE.
JPG
08 JUL 2000 76 KB
_______1_.
JPG
18 JUL 2000 17 KB
HT-BD8200_XAA_0528-3.indd 74HT-BD8200_XAA_0528-3.indd 74 2009-05-30 2:59:512009-05-30 2:59:51
75
ENG ● USING THE USB FUNCTION
PLAYING MEDIA FILES USING THE USB HOST FEATURE
You can enjoy media fi les such as pictures and music saved on an MP3 player, USB memory stick or digital camera.
Connect the USB device to the USB port on the side of the unit.
USB Connected appears on the display screen and then disappears.
USB icon is displayed on the Setup Menu.
Safe USB Removal
To prevent damage to the data stored in the USB device, perform safe removal before disconnecting
the USB cable.
Press the YELLOW(C) button. The display will show Now. You can remove USB safely.
Remove the USB cable.
Skip Forward/Back
During playback, press the
#
,
$
button.
When there is more than one fi le and you press the
$
button,
the next fi le is selected.
When there is more than one fi le and you press the
#
button,
the previous fi le is selected.
1.
2.
3.
•
•
•
•
Using the USB function
HT-BD8200_XAA_0528-3.indd 75HT-BD8200_XAA_0528-3.indd 75 2009-05-30 2:59:542009-05-30 2:59:54
Using the USB function
76
USB Host Specifi cation
USB Host Specifi cation
• Supports USB 1.1 or USB 2.0 compliant devices.
• Supports devices connected using the USB A type cable.
• Supports UMS (USB Mass Storage Device) V1.0 compliant devices.
• Supports the device of which the connected drive is formatted in the FAT(FAT,
FAT16, FAT32) fi le system.
Non-compliance
•
Does not support a device that requires installing a separate driver on the PC (Windows).
• Does not support connection to a USB hub.
•
A USB device that is connected using the USB extension cable may not be recognized.
• A USB device requiring a separate power source needs to be connected to the
player with the separate power connection.
Operational Limitations
• If the connected device has multiple drives (or partitions) installed, only one drive
(or partition) can be connected.
• A device supporting USB 1.1 alone may cause a difference in the picture quality,
depending on the device.
USB Devices that can be used with the Home Theater
USB Storage Device
MP3 Player
Digital Camera
Removable HDD
Removable HDDs equipped with less than 160 Gbytes are supported. Removable HDDs
equipped with 160Gbytes or more may not be recognized, depending on the device.
If the connected device does not work due to insuffi cient power supply, you can use a separate
power cable to supply power so that it can work properly. The connector of the USB cable may
differ, depending on the manufacturer of the USB device.
USB card Reader: One slot USB card reader and Multi slot USB card reader.
Depending on the manufacturer. the USB card reader may not be supported.
If you install multiple memory devices into a multi card reader, you may experience problems.
Supported fi le Formats
Format File name File
extension Bit rate Version Pixel Sampling
Frequency
Still Picture JPG JPG .JPEG – – 640x480 –
Music MP3 .MP3 80~384kbps – – 44.1kHz
CBI (Control/Bulk/Interrupt) is not supported.
Digital Cameras that use PTP protocol or require additional program installation when connected to a
PC are not supported.
A device using NTFS fi le system is not supported. (Only FAT 16/32 (File Allocation Table 16/32) fi le
system is supported.)
Does not operate with Janus enabled MTP (Media Transfer Protocol) devices.
1.
2.
3.
4.
•
•
5.
•
•
•
•
•
•
HT-BD8200_XAA_0528-3.indd 76HT-BD8200_XAA_0528-3.indd 76 2009-05-30 2:59:552009-05-30 2:59:55
77
ENG ● RADIO
LISTENING TO RADIO
Press the TUNER button to select the FM band.
Tune in to the desired station.
Automatic Tuning 1 : When the SKIP ( ) button is
pressed, a preset broadcast station is selected.
Automatic Tuning 2 : Press and hold the
TUNING/CH () button to
automatically search for active
broadcasting stations.
Manual Tuning : Briefl y press the TUNING/CH ()
button to increase or decrease the frequency incrementally.
Main Unit
Press the FUNCTION button to select the FM band.
Select a broadcast station.
Automatic Tuning 1 : Press the STOP ( ■ ) button to select PRESET and then press the
SKIP ( ) button to select the preset station.
Automatic Tuning 2 : Press the STOP ( ■ ) button to select MANUAL and then press and hold
the SKIP ( ) button to automatically search the band.
Manual Tuning : Press the STOP ( ■ ) button to select MANUAL and then briefl y press the
SKIP ( ) button to tune in to a lower or higher frequency.
Mono/Stereo
Press the MO/ST button to listen in Mono/Stereo.
Each time the button is pressed, the sound switches
between STEREO and MONO.
In a poor reception area, select MONO for a clear,
interference-free broadcast.
PRESETTING STATIONS
Example : Presetting FM 89.10 in the memory
Press the TUNER button to select the FM band.
Press the
TUNING/CH ()
button to select <89.10>.
Press the TUNER MEMORY button.
NUMBER fl ashes in the display.
Press the
SKIP ( )
button to select preset number.
You can select between 1 and 15 presets.
Press the TUNER MEMORY button again.
Press the TUNER MEMORY button before
NUMBER
disappears from the display.
NUMBER
disappears from the display and the station is stored in memory.
To preset another station, repeat steps 2 to 5.
To tune in to a preset station, press the SKIP ( ) button on the remote control to select a channel.
1.
2.
•
•
•
1.
2.
•
•
•
•
•
1.
2.
3.
•
4.
•
5.
•
•
6.
•
Radio
HT-BD8200_XAA_0528-3.indd 77HT-BD8200_XAA_0528-3.indd 77 2009-05-30 2:59:552009-05-30 2:59:55
Using an iPod
78
You can enjoy playback of your iPod using the supplied remote control.
LISTENING TO MUSIC
You can play music fi les stored in the iPod player by connecting it to the
Blu-ray Home Theater.
Connect the iPod dock connector to the iPod jack on the Blu-ray
Home Theater.
Place the iPod in the Dock.
Your iPod is automatically turned on.
“iPod Connected” message appears on the TV screen.
Press the MENU button on the remote control.
Press the
W,T buttons on the remote control to select iPod mode.
Press the X,S,T buttons on the remote control to select Music and
press the ENTER button.
The Music categories appear.
Press the S,T buttons desired category and press the ENTER button.
The music list appears on your TV.
Press the S,T buttons to select the music fi le to play and
press the ENTER button.
The music will start with a new screen which shows the
song title, time, artist, and progress bar.
You can use the remote control or main unit to control
simple playback functions such as PLAY, PAUSE, STOP,
/ , / and REPEAT.
Press the RED(A) button to select a desired play mode.
iPod Playback Screen Elements
Displays the media type.
Current track (song)
Displays the number of the track currently being played.
Play Status Bar.
Displays the repeat status.
Displays the current play index, total track number.
Current /Total Play Time.
Displays available COLOR buttons.
1.
2.
•
•
3.
4.
5.
•
6.
•
7.
•
8.
•
❖
► My love 6/186
00:00:11 / 00:03:34
A
Play Mode
Using an iPod
Video
Music
Setup
B
Playlist
Page
TRACK 001 ►
TRACK 002
TRACK 003
TRACK 004
TRACK 005
TRACK 006
TRACK 007
◄
►
HT-BD8200_XAA_0528-3.indd 78HT-BD8200_XAA_0528-3.indd 78 2009-05-30 3:00:002009-05-30 3:00:00
79
ENG ● USING AN iPod
To move to the Music List and select a track:
Press the MENU or STOP button.
It stops playing and returns to the music list.
Press the
S,T
buttons to select the fi le you want to play and press the ENTER button.
Press the RETURN or
W
button to return to the parent menu.
iPod Music categories
File information including the artist name, album name, music title and genre will be displayed according
to the ID3 Tag information on the appropriate music fi le.
Now Playing : Plays a recently played fi le or moves to the playback screen of the current fi le.
Artists : To play by artist.
Songs : To play in numeric or alphabetical order
Playlists : To play by Playlist.
Albums : To play by album.
Genres : To play by genre.
Composer : To play by composer.
See page 24 for compatible iPods.
Compatibility depends on the software version of your iPod.
The category list may differ, depending on the iPod model.
What is an ID3 Tag?
This is what is attached to an MP3 to carry information relevant to the fi le such as
the title, artist, album, year, genre and a comment fi eld.
1.
•
2.
•
M
HT-BD8200_XAA_0528-3.indd 79HT-BD8200_XAA_0528-3.indd 79 2009-05-30 3:00:042009-05-30 3:00:04
Using an iPod
80
WATCHING A MOVIE
You can play video fi les stored in the iPod player by connecting it to the Blu-ray Home Theater.
Connect the iPod dock connector to the iPod jack on the Blu-ray
Home Theater.
In the iPod screen, move to Videos > Settings and set the TV Out
option to On.
Place the iPod in the Dock.
“iPod Connected” message appears on the TV screen.
Press the
W,T buttons on the remote control to select iPod mode.
Press the X,S,T buttons on the remote control to select Video and
press the ENTER button.
Press the S,T buttons on the remote control to select Movies and press
the ENTER button.
The video list appears on your TV.
Press the S,T buttons to select the video fi le to play and press the
ENTER button.
Video fi le of the iPod player will be played on the TV screen.
You can use the remote control or main unit to control simple playback
functions such as PLAY, PAUSE, STOP, / and / .
If you press the PREV button within 2 seconds after the playback,
the player will play previous fi le.
If you press the PREV button 2 seconds or later after the playback, the player will move to the
start screen of the current fi le.
Press the NEXT button to play next fi le.
To move to the Video List and select a fi le:
Press the MENU or STOP button.
It stops playing and returns to the video list.
Press the
S,T
buttons to select the fi le you want to play
and press the ENTER button.
Press the RETURN or
W
button to return to the parent
menu.
See page 24 for compatible iPods.
Compatibility depends on the software version of your iPod.
You must have the VIDEO output connected to your TV to view iPod video (See page 23).
If you want to iPod video via VIDEO output, if HDMI CEC is set to on, turn it off.
When the current fi le is played to the end, the next fi le will be played automatically.
To play the next fi le, select a fi le to play in the list screen of the iPod player.
No other screen than the playback one will appear on the TV screen. Check other screens on
the iPod player.
If connected iPod does not support video playback, “Cannot play video fi les saved on this iPod”
message appears when you select the Video menu.
1.
2.
3.
•
4.
5.
6.
•
7.
•
8.
•
•
1.
•
2.
•
M
► Video
Music
Setup
►
B
Playlist
Page
MOVIE 001 ►
MOVIE 002
MOVIE 003
MOVIE 004
MOVIE 005
MOVIE 006
MOVIE 007
◄
CD
CD
Nodisc
Nodisc
HT-BD8200_XAA_0528-3.indd 80HT-BD8200_XAA_0528-3.indd 80 2009-05-30 3:00:042009-05-30 3:00:04
81
ENG ● PC STREAMING FUNCTION
pc streaming function
CONNECTING TO A PC AND PLAYING MP3, JPEG OR DIVX CONTENT
The shared folder setup method may be different, depending on the PC operating system.
You can connect the Blu-ray Home Theater to a PC and play mp3, jpeg or DivX fi le content in a shared folder.
(Refer to pages 28~29 for the connection)
Use a router and LAN cable or wireless LAN adapter to
connect between the PC and Blu-ray Home Theater.
Create a shared folder in the PC and store desired mp3,
jpeg or DivX fi les there.
- For more detailed information about setting a shared
folder, visit the Samsung website and download the
"Setting the shared folder" manual from the Download
center.
Press the MENU button.
Press the RED(A) button.
You will see a window where you can select a network search
type.
Use the ◄ ► button to select a network search type.
A list of shared servers will appear.
Auto : Automatically searches for an available PC.
Manual : You must enter the IP address, folder name,
windows user name and password before you can fi nd a
desired PC.
To search a shared folder
There are 2 methods to access shared folders on a PC.
(If you search a folder in Auto mode. it must contain less than
12 characters. You must select manual to search for folders with 12
or more characters.)
Auto Mode
Press the
▲▼
button to select a desired PC and press
the ENTER button.
(When fi rst connected, you must enter the window user
name and password to display the shared folder.)
Enter the PC’s user name in the window.
Enter the PC’s password in the window.
The shared folder will be displayed.
1.
2.
3.
4.
5.
•
•
6.
•
1.
2.
3.
Nodisc
Nodisc
◄
DISC
a
Network Search
Video
Music
Setup
e-Contents
Nodisc
Nodisc
◄
DISC
a
Network Search
Video
Music
Setup
e-Contents
Network Search Type
s
Select
²
Return
Please select natwork search type
Auto Manual
Nodisc
Nodisc
◄
DISC
a
Network Search
Music
Setup
B
C
e-Contents
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Password
«
Number
s
Select
²
Return
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
gh i j k lmnopqr s tuv
wxyz1234567890−_
+=.~!@#$%^&() /?|
a
Back Space
b
Space
c
Clear
d
Save
_
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Music
Setup
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
gh i j k lmnopq r s t uv
wxyz1234567890−_
+=.~!@#$%^&( ) / ?|
a
Back Space
b
Space
c
Clear
d
Save
_
User
«
Number
s
Select
²
Return
HT-BD8200_XAA_0528-3.indd 81HT-BD8200_XAA_0528-3.indd 81 2009-05-30 3:00:072009-05-30 3:00:07
82
pc streaming function
82
Press the ▲▼ button to select a desired folder.
Manual Mode
Enter in the IP address of the PC that has the shared
folders.
Type in the name of the shared folder in the window then
press the BLUE (D) button to Save.
Type in the PC’s password then press the BLUE (D)
button to Save.
4.
•
1.
2.
3.
Press the
►
button, then press the
▲▼
button to select Video, Music or Photo.
(For playing a Video, Music or Photo, refer to pages 68~70)
The PC name should be in English, excluding characters such as symbols.
You can search up to 4 PCs connected to the network to play content over.
You may experience connection problems depending on your PC environment.
- If you encounter a problem with "Auto Mode", please try to "Manual Mode".
If a confl ict occurs between Windows XP simple fi le sharing and the PC streaming function of the Blu-ray Home
Theater, please disable the simple fi le sharing.
- For more detailed information, visit the Samsung website and download the "Setting the shared folder"
manual from the Download center.
If you experience PC streaming function problems when using a shared folder on the desktop of windows vista,
visit the operating system's technical support site to change a setting or change the directory.
7.
M
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Select Folder
s
Save
²
Return
ADMIN$
CS
DS
FS
GS
print$
SharedD
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Manual Search
«
Number
s
Select
²
Return
Please input IP address
. . .
0000
2341
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Manual Search
«
Number
s
Select
²
Return
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
gh i j k lmnopq r s t uv
wxyz1234567890−_
+=.~!@#$%^&( ) / ?|
a
Back Space
b
Space
c
Clear
d
Save
_
Please input shared folder name
2341
a
Network Search
►
B
C
No disc
No disc
DISC
e-Contents
Manual Search
«
Number
s
Select
²
Return
ABCDEFGH I JKLMNOP
QRSTUVWXYZabcde f
gh i j k lmnopqr s tuv
wxyz1234567890−_
+=.~!@#$%^&( ) / ?|
a
Back Space
b
Space
c
Clear
d
Save
_
Please input password
2341
HT-BD8200_XAA_0528-3.indd 82HT-BD8200_XAA_0528-3.indd 82 2009-05-30 3:00:142009-05-30 3:00:14
83
ENG
SLEEP TIMER FUNCTION
You can set the time that the Blu-ray Home Theater will shut itself off.
Press the SLEEP button.
Each time the button is pressed, the preset time changes as follows :
SLP 10 ➞ 20 ➞ 30 ➞ 60 ➞ 90 ➞ 120 ➞ 150 ➞ OFF.
To confi rm the sleep timer setting, press the SLEEP button.
The remaining time before the Blu-ray Home Theater will shut itself off
is displayed.
Pressing the button again changes the sleep time from what you have
set earlier.
To cancel the sleep timer, press the SLEEP button until OFF appears on the display.
ADJUSTING DISPLAY BRIGHTNESS
You can adjust the brightness of the display on the main unit so it won't
interfere with your movie viewing.
Press the DIMMER button.
Each time the button is pressed, the brightness of front display will be
adjusted.
MUTE FUNCTION
This is useful when answering a doorbell or telephone call.
Press the MUTE button.
MUTE appears in the display.
To restore the sound, press the MUTE button again.
•
•
•
•
•
•
Convenient function
HT-BD8200_XAA_0528-3.indd 83HT-BD8200_XAA_0528-3.indd 83 2009-05-30 3:00:162009-05-30 3:00:16
84
Troubleshooting
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed
below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact
Samsung Electronics at 1-800-SAMSUNG.
SYMPTOM Check/Remedy
I cannot eject the disc. • Is the power cord plugged securely into the outlet?
• Turn off the power and then turn it back on.
The iPod fails to connect. • Check the condition of the iPod connector and Dock.
• Keep the iPod S/W version up to date.
Playback does not start. • Check the region number of the BD/DVD.
BD/DVD discs purchased from abroad may not be playable.
• CD-ROMs and DVD-ROMs cannot be played on this Blu-ray Home Theater.
• Make sure that the rating level is correct.
Playback does not start
immediately when the
Play/Pause button is pressed.
• Are you using a deformed disc or a disc with scratches on the surface?
• Wipe the disc clean.
Sound is not produced. •
No sound is heard during fast playback, slow playback, and step motion playback.
•
Are the speakers connected properly? Is the speaker setup correctly customized?
• Is the disc severely damaged?
Sound can be heard only from a few
speakers and not all 3.
• On certain BD/DVD discs, sound is output from the front speakers only.
• Check if the speakers are connected properly.
• Adjust the volume.
• When listening to a CD or radio, sound is output to the front speakers only.
The remote control does not work. •
Is the remote control being operated within its operation range of angle and distance?
• Are the batteries drained?
•
Have you selected the mode(TV/BD) functions of the remote control (TV or BD) correctly?
• Disc is rotating but no
picture is produced.
• Picture quality is poor and
picture is shaking.
• Is the TV power on?
• Are the video cables connected properly?
• Is the disc dirty or damaged?
• A poorly manufactured disc may not be playable.
Audio language and subtitles do not work.
•
Audio language and subtitles will not work if the disc does not contain them.
Menu screen does not appear even
when the menu function is selected.
• Are you using a disc that does not contain menus?
HT-BD8200_XAA_0528-3.indd 84HT-BD8200_XAA_0528-3.indd 84 2009-05-30 3:00:162009-05-30 3:00:16
85
ENG ● TROUBLESHOOTING
SYMPTOM Check/Remedy
Aspect ratio cannot be changed. • You can play 16:9 BD/DVDs in 16:9 Wide mode, 4:3 Letter Box mode, or
4:3 Pan - Scan mode, but 4:3 BD/DVDs can be seen in 4:3 ratio only.
Refer to the Blu-ray Disc jacket and then select the appropriate function.
• The main unit is not working.
(Example: The power goes out or a
strange noise is heard.)
•
The Blu-ray Home Theater is not working
normally.
• Turn off the power and hold the STOP ( ■ ) button on the main unit for
longer than 5 seconds.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
The password for rating level has been
forgotten.
• While (NO DISC) message appears on the display of main unit, hold the
main unit's STOP ( ■ ) button for longer than 5 seconds. INITIAL
appears on the display and all settings will return to the default values.
• Press the POWER button.
Using the RESET function will erase all stored settings.
Do not use this unless necessary.
Can't receive radio broadcasts. • Is the antenna connected properly?
• If the antenna's input signal is weak, install an external FM antenna in an
area with good reception.
While listening to TV audio through the
Blu-ray Home Theater, no sound is
heard.
•
If the EJECT button is pressed while listening to TV audio using the
D.IN or AUX functions, the BD/DVD functions are turned on and this mutes
the TV audio.
The icon appears on screen. • The features or action cannot be completed at this time because:
1. The BD/DVD’s software restricts it.
2. The BD/DVD’s software doesn’t support the feature (e.g., angles)
3. The feature is not available at the moment.
4.
You’ve requested a title or chapter number or search time that is out of range.
If the HDMI output is set to a resolution your
TV cannot support (for example, 1080p), you
may not see a picture on your TV.
• Press the STOP ( ■ ) utton (in front panel) for more than 5 seconds with
no disc inside. All settings will revert to the factory settings.
No HDMI output. • Check the connection between the TV and the HDMI jack of the Blu-ray
Home Theater.
• Check if your TV supports 480p/720p/1080i/1080p HDMI input
resolution.
Abnormal HDMI output screen. • If random noise appears on the screen, it means that TV does not support
HDCP (High-bandwidth Digital Content Protection).
Cannot search for other access points
using USB wireless
• Check the Proxy is Off(Setup -> Network Setup -> Proxy)
HT-BD8200_XAA_0528-3.indd 85HT-BD8200_XAA_0528-3.indd 85 2009-05-30 3:00:162009-05-30 3:00:16
86
Appendix
CAUTIONS ON HANDLING AND STORING DISCS
Small scratches on the disc may reduce sound and picture quality or cause skipping.
Be especially careful not to scratch discs when handling them.
Handling discs
Do not touch the playback side of the disc.
Hold the disc by the edges so that fingerprints will not get on the surface.
Do not stick paper or tape on the disc.
Disc Storage
Do not keep in direct sunlight Keep in a cool
ventilated area
Keep in a clean Protection jacket.
Store vertically.
Do not allow the discs to become contaminated with dirt.
Do not load cracked or scratched discs.
Handling and Storing Discs
When you get fingerprints or dirt on the disc, clean it with a mild detergent diluted in water and wipe with
a soft cloth.
When cleaning, wipe gently from the inside to the outside of the disc
Condensation may form if warm air comes into contact with cold parts inside the player.
When condensation forms inside the player, the player may not operate correctly. If this
occurs, remove the disc and let the player stand for 1 or 2 hours with the power on.
M
•
M
HT-BD8200_XAA_0528-3.indd 86HT-BD8200_XAA_0528-3.indd 86 2009-05-30 3:00:172009-05-30 3:00:17
87
ENG ● APPENDIX
SPECIFICATIONS
General
Power Requirements AC 120V, 60Hz
Power Consumption 100 W
Weight 7.0 Ibs
Dimensions 18.1 (W) x 7.6 (D) x 4.3 (H) inches
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10 % to 75 %
FM Tuner
Signal / noise ratio 70 dB
Usable sensitivity 10 dB
Total harmonic distortion 0.5 %
Disc
BD (Blu-ray Disc) Reading Speed : 4.917m/sec
DVD (Digital Versatile Disc) Reading Speed : 3.49 ~ 4.06 m/sec.
Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.
CD : 5 inches (COMPACT DISC) Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
CD : 3 1/2 inches (COMPACT DISC) Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 20 min.
Video Output Composite Video 1 channel : 1.0 Vp-p (75 Ω load)
Blu-ray Disc : 480i DVD : 480i
Video/Audio HDMI 1080p, 1080i, 720p, 480p
PCM multichannel audio, Bitstream audio, PCM audio
Amplifier
Main unit output 100W/CH. 3
Ω
,THD=10%, 1KHz
Subwoofer speaker output 100W/CH, 3
Ω
, THD = 10%, 120Hz
Frequency response
Analog input 20Hz~20kHz (±3dB)
Digital input/48kHz PCM 20Hz~44kHz (±3dB) ... based on TV
S/N Ratio 70dB
Channel separation 60dB
Input sensitivity 400mV
Subwoofer
Impedance 47KΩ
Frequency range 140Hz~20kHz
Output sound pressure level 88dB/W/M
Dimensions (W x H x D) 11.4 x 14.6 x11.6 inches
Weights 16.1 lbs
*: Nominal specifi cation
- Samsung Electronics Co., Ltd reserves the right to change the specifi cations without notice.
- Weight and dimensions are approximate.
HT-BD8200_XAA_0528-3.indd 87HT-BD8200_XAA_0528-3.indd 87 2009-05-30 3:00:172009-05-30 3:00:17
This product uses parts of the software from the Independent JPEG Group.
This product uses parts of the software owned by the Freetype Project (www.freetype.org).
This product uses some software programs which are distributed under the GPL/LGPL license.
This Product uses some software programs which are distributed under the OpenSSL license.
Accordingly, the following GPL and LGPL software source codes that have been used in this product can be
provided after asking to vdswmanager@samsung.com.
GPL
software
: Linu Kernel, Busybox, Binutilis
LGPL
software
: uClibc, directfb
❖
❖
❖
❖
The GNU General Public License (GPL)
Version 2, June 1991
Copyright (C) 1989, 1991 Free Software Foundation, Inc.
59 Temple Place, Suite 330, Boston, MA 02111-1307 USA
Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.
Preamble
The licenses for most software are designed to take away your freedom to share and change it. By contrast, the
GNU General Public License is intended to guarantee your freedom to share and change free software--to make
sure the software is free for all its users. This General Public License applies to most of the Free Software
Foundation’s software and to any other program whose authors commit to using it. (Some other Free Software
Foundation software is covered by the GNU Library General Public License instead.) You can apply it to your
programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed
to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish),
that you receive source code or can get it if you want it, that you can change the software or use pieces of it in new
free programs; and th at you know you can do these things.
To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to
surrender the rights. These restrictions translate to certain responsibilities for you if you distribute copies of the
software, or if you modify it.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all
the rights that you have. You must make sure that they, too, receive or can get the source code. And you must
show them these terms so they know their rights.
We protect your rights with two steps: (1) copyright the software, and (2) offer you this license which gives you legal
permission to copy, distribute and/or modify the software.
Also, for each author’s protection and ours, we want to make certain that everyone understands that there is no
warranty for this free software. If the software is modifi ed by someone else and passed on, we want its recipients to
know that what they have is not the original, so that any problems introduced by others will not refl ect on the original
authors’ reputations.
Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that
redistributors of a free program will individually obtain patent licenses, in effect making the program proprietary. To
prevent this, we have made it clear that any patent must be licensed for everyone’s free use or not licensed at all.
The precise terms and conditions for copying, distribution and modifi cation follow.
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION
0. This License applies to any program or other work which contains a notice placed by the copyright holder saying
it may be distributed under the terms of this General Public License. The “Program”, below, refers to any such
program or work, and a “work based on the Program” means either the Program or any derivative work under
copyright law: that is to say, a work containing the Program or a portion of it, either verbatim or with modifi cations
and/or translated into another language. (Hereinafter, translation is included without limitation in the term
“modifi cation”.) Each licensee is addressed as “you”.
Activities other than copying, distribution and modifi cation are not covered by this License; they are outside its
scope. The act of running the Program is not restricted, and the output from the Program is covered only if its
contents constitute a work based on the Program (independent of having been made by running the Program).
Whether that is true depends on what the Program does.
HT-BD8200_XAA_0528-3.indd 88HT-BD8200_XAA_0528-3.indd 88 2009-05-30 3:00:172009-05-30 3:00:17
Activities other than copying, distribution and modifi cation are not covered by this License; they are outside its
scope. The act of running the Program is not restricted, and the output from the Program is covered only if its
contents constitute a work based on the Program (independent of having been made by running the Program).
Whether that is true depends on what the Program does.
You may copy and distribute verbatim copies of the Program’s source code as you receive it, in any
medium, provided that you conspicuously and appropriately publish on each copy an appropriate copyright
notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the absence of
any warranty; and give any other recipients of the Program a copy of this License along with the Program.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.
You may modify your copy or copies of the Program or any portion of it, thus forming a work based on
the Program, and copy and distribute such modifi cations or work under the terms of Section 1 above,
provided that you also meet all of these conditions:
a) You must cause the modifi ed fi les to carry prominent notices stating that you changed the fi les and the date of
any change.
b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the
Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this
License.
c) If the modifi ed program normally reads commands interactively when run, you must cause it, when started
running for such interactive use in the most ordinary way, to print or display an announcement including an
appropriate copyright notice and a notice that there is no warranty (or else, saying that you provide a warranty)
and that users may redistribute the program under these conditions, and telling the user how to view a copy of
this License. (Exception: if the Program itself is interactive but does not normally print such an announcement,
your work based on the Program is not required to print an announcement.)
These requirements apply to the modifi ed work as a whole. If identifi able sections of that work are not derived from
the Program, and can be reasonably considered independent and separate works in themselves, then this License,
and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute
the same sections as part of a whole which is a work based on the Program, the distribution of the whole must be
on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each
and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather,
the intent is to exercise the right to control the distribution of derivative or collective works based on the Program.
In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on
the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this
License.
You may copy and distribute the Program (or a work based on it, under Section 2) in object code or
executable form under the terms of Sections 1 and 2 above provided that you also do one of the following:
a) Accompany it with the complete corresponding machine-readable source code, which must be distributed
under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,
b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more
than your cost of physically performing source distribution, a complete machine-readable copy of the
corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium
customarily used for software interchange; or,
c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This
alternative is allowed only for noncommercial distribution and only if you received the program in object code or
executable form with such an offer, in accord with Subsection b above.)
The source code for a work means the preferred form of the work for making modifi cations to it. For an executable
work, complete source code means all the source code for all modules it contains, plus any associated interface
defi nition fi les, plus the scripts used to control compilation and installation of the executable. However, as a special
exception, the source code distributed need not include anything that is normally distributed (in either source or
binary form) with the major components (compiler, kernel, and so on) of the operating system on which the
executable runs, unless that component itself accompanies the executable.
1.
2.
3.
HT-BD8200_XAA_0528-3.indd 89HT-BD8200_XAA_0528-3.indd 89 2009-05-30 3:00:172009-05-30 3:00:17
If distribution of executable or object code is made by offering access to copy from a designated place, then offering
equivalent access to copy the source code from the same place counts as distribution of the source code, even
though third parties are not compelled to copy the source along with the object code.
You may not copy, modify, sublicense, or distribute the Program except as expressly provided under this
License. Any attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will
automatically terminate your rights under this License. However, parties who have received copies, or
rights, from you under this License will not have their licenses terminated so long as such parties remain in
full compliance.
You are not required to accept this License, since you have not signed it. However, nothing else grants
you permission to modify or distribute the Program or its derivative works. These actions are prohibited by
law if you do not accept this License. Therefore, by modifying or distributing the Program (or any work
based on the Program), you indicate your acceptance of this License to do so, and all its terms and
conditions for copying, distributing or modifying the Program or works based on it.
Each time you redistribute the Program (or any work based on the Program), the recipient automatically
receives a license from the original licensor to copy, distribute or modify the Program subject to these
terms and conditions. You may not impose any further restrictions on the recipients’ exercise of the rights
granted herein. You are not responsible for enforcing compliance by third parties to this License.
If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not
limited to patent issues), conditions are imposed on you (whether by court order, agreement or otherwise)
that contradict the conditions of this License, they do not excuse you from the conditions of this License. If
you cannot distribute so as to satisfy simultaneously your obligations under this License and any other
pertinent obligations, then as a consequence you may not distribute the Program at all. For example, if a
patent license would not permit royalty-free redistribution of the Program by all those who receive copies
directly or indirectly through you, then the only way you could satisfy both it and this License would be to
refrain entirely from distribution of the Program.
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the
section is intended to apply and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest
validity of any such claims; this section has the sole purpose of protecting the integrity of the free software
distribution system, which is implemented by public license practices. Many people have made generous
contributions to the wide range of software distributed through that system in reliance on consistent application of
that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other
system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.
If the distribution and/or use of the Program is restricted in certain countries either by patents or by
copyrighted interfaces, the original copyright holder who places the Program under this License may add
an explicit geographical distribution limitation excluding those countries, so that distribution is permitted
only in or among countries not thus excluded. In such case, this License incorporates the limitation as if
written in the body of this License.
The Free Software Foundation may publish revised and/or new versions of the General Public License
from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to
address new problems or concerns.
Each version is given a distinguishing version number. If the Program specifi es a version number of this License
which applies to it and “any later version”, you have the option of following the terms and conditions either of that
version or of any later version published by the Free Software Foundation. If the Program does not specify a version
number of this License, you may choose any version ever published by the Free Software Foundation.
If you wish to incorporate parts of the Program into other free programs whose distribution conditions
are different, write to the author to ask for permission. For software which is copyrighted by the Free
Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our
decision will be guided by the two goals of preserving the free status of all derivatives of our free software
and of promoting the sharing and reuse of software generally.
4.
5.
6.
7.
8.
9.
10.
HT-BD8200_XAA_0528-3.indd 90HT-BD8200_XAA_0528-3.indd 90 2009-05-30 3:00:172009-05-30 3:00:17
NO WARRANTY
BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE
PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN
WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS”
WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU. SHOULD
THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR
OR CORRECTION.
IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY
COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE
PROGRAM AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL,
SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE THE PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED
INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM
TO OPERATE WITH ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
END OF TERMS AND CONDITIONS
How to Apply These Terms to Your New Programs
If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to
achieve this is to make it free software which everyone can redistribute and change under these terms.
To do so, attach the following notices to the program. It is safest to attach them to the start of each source fi le to
most effectively convey the exclusion of warranty; and each fi le should have at least the “copyright” line and a
pointer to where the full notice is found.
One line to give the program’s name and a brief idea of what it does.
Copyright (C) <year> <name of author>
This program is free software; you can redistribute it and/or modify it under the terms of the GNU General Public
License as published by the Free Software Foundation; either version 2 of the License, or (at your option) any
later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the
implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General
Public License for more details.
You should have received a copy of the GNU General Public License along with this program; if not, write to the
Free Software Foundation, Inc., 59
Temple Place, Suite 330, Boston, MA 02111-1307 USA
Also add information on how to contact you by electronic and paper mail.
If the program is interactive, make it output a short notice like this when it starts in an interactive mode:
Gnomovision version 69, Copyright (C) year name of author Gnomovision comes with ABSOLUTELY NO
WARRANTY; for details type `show w’. This is free software, and you are welcome to redistribute it under certain
conditions; type `show c’ for details.
The hypothetical commands `show w’ and `show c’ should show the appropriate parts of the General Public
License. Of course, the commands you use may be called something other than `show w’ and `show c’; they could
even be mouse-clicks or menu items--whatever suits your program.
You should also get your employer (if you work as a programmer) or your school, if any, to sign a “copyright
disclaimer” for the program, if necessary. Here is a sample; alter the names:
Yoyodyne, Inc., hereby disclaims all copyright interest in the program `Gnomovision’ (which makes passes at
compilers) written by James Hacker.
signature of Ty Coon, 1 April 1989
Ty Coon, President of Vice
This General Public License does not permit incorporating your program into proprietary programs. If your program
is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If
this is what you want to do, use the GNU Library General Public License instead of this License.
11.
12.
HT-BD8200_XAA_0528-3.indd 91HT-BD8200_XAA_0528-3.indd 91 2009-05-30 3:00:172009-05-30 3:00:17
GNU Lesser General Public License (LGPL)
Version 2.1, February 1999
Copyright (C) 1991, 1999 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is
not allowed.
[This is the fi rst released version of the Lesser GPL. It also counts as the successor of the GNU Library Public
License, version 2, hence the version number 2.1.]
Preamble
The licenses for most software are designed to take away your freedom to share and change it. By contrast, the
GNU General Public Licenses are intended to guarantee your freedom to share and change free software--to make
sure the software is free for all its users.
This license, the Lesser General Public License, applies to some specially designated software packages--typically
libraries--of the Free Software Foundation and other authors who decide to use it. You can use it too, but we
suggest you fi rst think carefully about whether this license or the ordinary General Public License is the better
strategy to use in any particular case, based on the explanations below.
When we speak of free software, we are referring to freedom of use, not price. Our General Public Licenses are
designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if
you wish); that you receive source code or can get it if you want it; that you can change the software and use pieces
of it in new free programs; and that you are informed that you can do these things.
To protect your rights, we need to make restrictions that forbid distributors to deny you these rights or to ask you to
surrender these rights. These restrictions translate to certain responsibilities for you if you distribute copies of the
library or if you modify it.
For example, if you distribute copies of the library, whether gratis or for a fee, you must give the recipients all the
rights that we gave you. You must make sure that they, too, receive or can get the source code. If you link other
code with the library, you must provide complete object fi les to the recipients, so that they can relink them with the
library after making changes to the library and recompiling it. And you must show them these terms so they know
their rights.
We protect your rights with a two-step method: (1) we copyright the library, and (2) we offer you this license, which
gives you legal permission to copy, distribute and/or modify the library.
To protect each distributor, we want to make it very clear that there is no warranty for the free library. Also, if the
library is modifi ed by someone else and passed on, the recipients should know that what they have is not the
original version, so that the original author’s reputation will not be affected by problems that might be introduced by
others.
Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a
company cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent
holder. Therefore, we insist that any patent license obtained for a version of the library must be consistent with the
full freedom of use specifi ed in this license.
Most GNU software, including some libraries, is covered by the ordinary GNU General Public License. This license,
the GNU Lesser General Public License, applies to certain designated libraries, and is quite different from the
ordinary General Public License. We use this license for certain libraries in order to permit linking those libraries into
non-free programs.
When a program is linked with a library, whether statically or using a shared library, the combination of the two is
legally speaking a combined work, a derivative of the original library. The ordinary General Public License therefore
permits such linking only if the entire combination fi ts its criteria of freedom.
The Lesser General Public License permits more lax criteria for linking other code with the library.
We call this license the “Lesser” General Public License because it does Less to protect the user’s freedom than the
ordinary General Public License. It also provides other free software developers Less of an advantage over
competing non-free programs. These disadvantages are the reason we use the ordinary General Public License for
many libraries. However, the Lesser license provides advantages in certain special circumstances.
For example, on rare occasions, there may be a special need to encourage the widest possible use of a certain
library, so that it becomes a de-facto standard. To achieve this, non-free programs must be allowed to use the
library. A more frequent case is that a free library does the same job as widely used non-free libraries. In this case,
there is little to gain by limiting the free library to free software only, so we use the Lesser General Public License.
HT-BD8200_XAA_0528-3.indd 92HT-BD8200_XAA_0528-3.indd 92 2009-05-30 3:00:172009-05-30 3:00:17
In other cases, permission to use a particular library in non-free programs enables a greater number of people to
use a large body of free software. For example, permission to use the GNU C Library in non-free programs enables
many more people to use the whole GNU operating system, as well as its variant, the GNU/Linux operating system.
Although the Lesser General Public License is Less protective of the users’ freedom, it does ensure that the user of
a program that is linked with the Library has the freedom and the wherewithal to run that program using a modifi ed
version of the Library.
The precise terms and conditions for copying, distribution and modifi cation follow. Pay close attention to the
difference between a “work based on the library” and a “work that uses the library”. The former contains code
derived from the library, whereas the latter must be combined with the library in order to run.
TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION
0. This License Agreement applies to any software library or other program which contains a notice placed by the
copyright holder or other authorized party saying it may be distributed under the terms of this Lesser General Public
License (also called “this License”). Each licensee is addressed as “you”.
A “library” means a collection of software functions and/or data prepared so as to be conveniently linked with
application programs (which use some of those functions and data) to form executables.
The “Library”, below, refers to any such software library or work which has been distributed under these terms. A
“work based on the Library” means either the Library or any derivative work under copyright law: that is to say, a
work containing the Library or a portion of it, either verbatim or with modifi cations and/or translated straightforwardly
into another language. (Hereinafter, translation is included without limitation in the term “modifi cation”.)
“Source code” for a work means the preferred form of the work for making modifi cations to it. For a library,
complete source code means all the source code for all modules it contains, plus any associated interface defi nition
fi les, plus the scripts used to control compilation and installation of the library.
Activities other than copying, distribution and modifi cation are not covered by this License; they are outside its
scope. The act of running a program using the Library is not restricted, and output from such a program is covered
only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing
it). Whether that is true depends on what the Library does and what the program that uses the Library does.
You may copy and distribute verbatim copies of the Library’s complete source code as you receive it, in
any medium, provided that you conspicuously and appropriately publish on each copy an appropriate
copyright notice and disclaimer of warranty; keep intact all the notices that refer to this License and to the
absence of any warranty; and distribute a copy of this License along with the Library.
You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty
protection in exchange for a fee.
You may modify your copy or copies of the Library or any portion of it, thus forming a work based on the
Library, and copy and distribute such modifi cations or work under the terms of Section 1 above, provided
that you also meet all of these conditions:
a) The modifi ed work must itself be a software library.
b) You must cause the fi les modifi ed to carry prominent notices stating that you changed the fi les and the date of
any change.
c) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this
License.
d) If a facility in the modifi ed Library refers to a function or a table of data to be supplied by an application
program that uses the facility, other than as an argument passed when the facility is invoked, then you must
make a good faith effort to ensure that, in the event an application does not supply such function or table, the
facility still operates, and performs whatever part of its purpose remains meaningful.
(For example, a function in a library to compute square roots has a purpose that is entirely well-defi ned
independent of the application. Therefore, Subsection 2d requires that any application-supplied function or table
used by this function must be optional: if the application does not supply it, the square root function must still
compute square roots.)
1.
2.
HT-BD8200_XAA_0528-3.indd 93HT-BD8200_XAA_0528-3.indd 93 2009-05-30 3:00:172009-05-30 3:00:17
These requirements apply to the modifi ed work as a whole. If identifi able sections of that work are not derived from
the Library, and can be reasonably considered independent and separate works in themselves, then this License,
and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute
the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be
on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each
and every part regardless of who wrote it.
Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather,
the intent is to exercise the right to control the distribution of derivative or collective works based on the Library.
In addition, mere aggregation of another work not based on the Library with the Library (or with a work based on
the Library) on a volume of a storage or distribution medium does not bring the other work under the scope of this
License.
You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a
given copy of the Library. To do this, you must alter all the notices that refer to this License, so that they refer
to the ordinary GNU General Public License, version 2, instead of to this License. (If a newer version than
version 2 of the ordinary GNU General Public License has appeared, then you can specify that version instead
if you wish.) Do not make any other change in these notices.
Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License
applies to all subsequent copies and derivative works made from that copy.
This option is useful when you wish to copy part of the code of the Library into a program that is not a library.
You may copy and distribute the Library (or a portion or derivative of it, under Section 2) in object code or
executable form under the terms of Sections 1 and 2 above provided that you accompany it with the complete
corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and
2 above on a medium customarily used for software interchange.
If distribution of object code is made by offering access to copy from a designated place, then offering equivalent
access to copy the source code from the same place satisfi es the requirement to distribute the source code, even
though third parties are not compelled to copy the source along with the object code.
A program that contains no derivative of any portion of the Library, but is designed to work with the Library
by being compiled or linked with it, is called a “work that uses the Library”. Such a work, in isolation, is not a
derivative work of the Library, and therefore falls outside the scope of this License.
However, linking a “work that uses the Library” with the Library creates an executable that is a derivative of the Library
(because it contains portions of the Library), rather than a “work that uses the library”. The executable is therefore
covered by this License. Section 6 states terms for distribution of such executables.
When a “work that uses the Library” uses material from a header fi le that is part of the Library, the object code for the
work may be a derivative work of the Library even though the source code is not. Whether this is true is especially
signifi cant if the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true
is not precisely defi ned by law.
If such an object fi le uses only numerical parameters, data structure layouts and accessors, and small macros and
small inline functions (ten lines or less in length), then the use of the object fi le is unrestricted, regardless of whether it
is legally a derivative work. (Executables containing this object code plus portions of the Library will still fall under
Section 6.)
Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of
Section 6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with
the Library itself.
As an exception to the Sections above, you may also combine or link a “work that uses the Library” with
the Library to produce a work containing portions of the Library, and distribute that work under terms of your
choice, provided that the terms permit modifi cation of the work for the customer’s own use and reverse
engineering for debugging such modifi cations.
You must give prominent notice with each copy of the work that the Library is used in it and that the Library and its
use are covered by this License. You must supply a copy of this License. If the work during execution displays
copyright notices, you must include the copyright notice for the Library among them, as well as a reference directing
the user to the copy of this License. Also, you must do one of these things:
3.
4.
5.
6.
HT-BD8200_XAA_0528-3.indd 94HT-BD8200_XAA_0528-3.indd 94 2009-05-30 3:00:172009-05-30 3:00:17
a) Accompany the work with the complete corresponding machine-readable source code for the Library including
whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the
work is an executable linked with the Library, with the complete machinereadable “work that uses the Library”, as
object code and/or source code, so that the user can modify the Library and then relink to produce a modifi ed
executable containing the modifi ed Library. (It is understood that the user who changes the contents of defi nitions
fi les in the Library will not necessarily be able to recompile the application to use the modifi ed defi nitions.)
b) Use a suitable shared library mechanism for linking with the Library. A suitable mechanism is one that (1) uses
at run time a copy of the library already present on the user’s computer system, rather than copying library
functions into the executable, and (2) will operate properly with a modifi ed version of the library, if the user installs
one, as long as the modifi ed version is interface-compatible with the version that the work was made with.
c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials
specifi ed in Subsection 6a, above, for a charge no more than the cost of performing this distribution.
d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access
to copy the above specifi ed materials from the same place.
e) Verify that the user has already received a copy of these materials or that you have already sent this user a
copy.
For an executable, the required form of the “work that uses the Library” must include any data and utility programs
needed for reproducing the executable from it. However, as a special exception, the materials to be distributed
need not include anything that is normally distributed (in either source or binary form) with the major components
(compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself
accompanies the executable.
It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not
normally accompany the operating system. Such a contradiction means you cannot use both them and the Library
together in an executable that you distribute.
You may place library facilities that are a work based on the Library side-by-side in a single library
together with other library facilities not covered by this License, and distribute such a combined library,
provided that the separate distribution of the work based on the Library and of the other library facilities is
otherwise permitted, and provided that you do these two things:
a) Accompany the combined library with a copy of the same work based on the Library, uncombined with any
other library facilities. This must be distributed under the terms of the Sections above.
b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and
explaining where to fi nd the accompanying uncombined form of the same work.
You may not copy, modify, sublicense, link with, or distribute the Library except as expressly provided
under this License. Any attempt otherwise to copy, modify, sublicense, link with, or distribute the Library is
void, and will automatically terminate your rights under this License. However, parties who have received
copies, or rights, from you under this License will not have their licenses terminated so long as such parties
remain in full compliance.
You are not required to accept this License, since you have not signed it. However, nothing else grants
you permission to modify or distribute the Library or its derivative works. These actions are prohibited by
law if you do not accept this License. Therefore, by modifying or distributing the Library (or any work based
on the Library), you indicate your acceptance of this License to do so, and all its terms and conditions for
copying, distributing or modifying the Library or works based on it.
Each time you redistribute the Library (or any work based on the Library), the recipient automatically
receives a license from the original licensor to copy, distribute, link with or modify the Library subject to
these terms and conditions. You may not impose any further restrictions on the recipients’ exercise of the
rights granted herein. You are not responsible for enforcing compliance by third parties with this License.
If, as a consequence of a court judgment or allegation of patent infringement or for any other reason
(not limited to patent issues), conditions are imposed on you (whether by court order, agreement or
otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this
License. If you cannot distribute so as to satisfy simultaneously your obligations under this License and any
other pertinent obligations, then as a consequence you may not distribute the Library at all. For example, if
a patent license would not permit royalty-free redistribution of the Library by all those who receive copies
directly or indirectly through you, then the only way you could satisfy both it and this License would be to
refrain entirely from distribution of the Library.
7.
8.
9.
10.
11.
HT-BD8200_XAA_0528-3.indd 95HT-BD8200_XAA_0528-3.indd 95 2009-05-30 3:00:172009-05-30 3:00:17
If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the
section is intended to apply, and the section as a whole is intended to apply in other circumstances.
It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest
validity of any such claims; this section has the sole purpose of protecting the integrity of the free software
distribution system which is implemented by public license practices. Many people have made generous
contributions to the wide range of software distributed through that system in reliance on consistent application of
that system; it is up to the author/donor to decide if he or she is willing to distribute software through any other
system and a licensee cannot impose that choice.
This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.
If the distribution and/or use of the Library is restricted in certain countries either by patents or by
copyrighted interfaces, the original copyright holder who places the Library under this License may add an
explicit geographical distribution limitation excluding those countries, so that distribution is permitted only
in or among countries not thus excluded. In such case, this License incorporates the limitation as if written
in the body of this License.
The Free Software Foundation may publish revised and/or new versions of the Lesser General Public
License from time to time. Such new versions will be similar in spirit to the present version, but may differ in
detail to address new problems or concerns.
Each version is given a distinguishing version number. If the Library specifi es a version number of this License which
applies to it and “any later version”, you have the option of following the terms and conditions either of that version
or of any later version published by the Free Software Foundation. If the Library does not specify a license version
number, you may choose any version ever published by the Free Software Foundation.
If you wish to incorporate parts of the Library into other free programs whose distribution conditions are
incompatible with these, write to the author to ask for permission. For software which is copyrighted by the
Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
Our decision will be guided by the two goals of preserving the free status of all derivatives of our free
software and of promoting the sharing and reuse of software generally.
NO WARRANTY
BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE
LIBRARY, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN
WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE LIBRARY “AS IS”
WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE LIBRARY IS WITH YOU. SHOULD
THE LIBRARY PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR
OR CORRECTION.
IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY
COPYRIGHT HOLDER, OR ANY OTHER PARTY WHO MAY MODIFY AND/OR REDISTRIBUTE THE LIBRARY
AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE
LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE
OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE LIBRARY TO OPERATE WITH
ANY OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
END OF TERMS AND CONDITIONS
How to Apply These Terms to Your New Libraries
If you develop a new library, and you want it to be of the greatest possible use to the public, we recommend making
it free software that everyone can redistribute and change. You can do so by permitting redistribution under these
terms (or, alternatively, under the terms of the ordinary General Public License).
To apply these terms, attach the following notices to the library. It is safest to attach them to the start of each source
fi le to most effectively convey the exclusion of warranty; and each fi le should have at least the “copyright” line and a
pointer to where the full notice is found.
12.
13.
14.
15.
16.
HT-BD8200_XAA_0528-3.indd 96HT-BD8200_XAA_0528-3.indd 96 2009-05-30 3:00:172009-05-30 3:00:17
<one line to give the library’s name and an idea of what it does.> Copyright (C) <year> <name of author>
This library is free software; you can redistribute it and/or modify it under the terms of the GNU Lesser General
Public License as published by the Free Software Foundation; either version 2.1 of the License, or (at your
option) any later version.
This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the
implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License along with this library; if not, write
to the Free Software Foundation, Inc., 59
Temple Place, Suite 330, Boston, MA 02111-1307 USA
Also add information on how to contact you by electronic and paper mail.
You should also get your employer (if you work as a programmer) or your school, if any, to sign a “copyright
disclaimer” for the library, if necessary. Here is a sample; alter the names:
Yoyodyne, Inc., hereby disclaims all copyright interest in the library `Frob’ (a library for tweaking knobs) written by
James Random Hacker.
signature of Ty Coon, 1 April 1990
Ty Coon, President of Vice
That’s all there is to it!
OpenSSL License
Copyright (c) 1998-2007 The OpenSSL Project. All rights reserved.
Redistribution and use in source and binary forms, with or without modifi cation, are permitted provided that the
following conditions are met:
Redistributions of source code must retain the above copyright notice, this list of conditions and the
following disclaimer.
Redistributions in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
All advertising materials mentioning features or use of this software must display the following
acknowledgment:
"This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http://
www.openssl.org/)"
The names "OpenSSL Toolkit" and "OpenSSL Project" must not be used to endorse or promote products
derived from this software without prior written permission. For written permission, please contact openssl-
core@openssl.org.
Products derived from this software may not be called "OpenSSL" nor may "OpenSSL" appear in their
names without prior written permission of the OpenSSL Project.
Redistributions of any form whatsoever must retain the following acknowledgment: "This product
includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.
org/)"
THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY EXPRESSED OR IMPLIED
WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE OpenSSL PROJECT OR
ITS CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND
ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING
NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
1.
2.
3.
4.
5.
6.
HT-BD8200_XAA_0528-3.indd 97HT-BD8200_XAA_0528-3.indd 97 2009-05-30 3:00:172009-05-30 3:00:17
WARRANTY
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG) and delivered new,
in the originalcarton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and
workmanship for a limited warranty period of:
One (1) Year Parts and Labor*
(*90 Days Parts and Labor for Commercial Use)
This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States.
To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty
service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon
request as proof of purchase to SAMSUNG or SAMSUNG's authorized service center. Transportation of the product to and from
the service center is the responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts
or products if found to be defective during the limited warranty period specified above. All replaced parts and products become
the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original
warranty, or ninety (90) days, whichever is longer.
SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG brand name are set forth in the
applicable end user license agreement. Non-SAMSUNG hardware and software products, if provided, are on an “AS IS” basis.
Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and except to the extent
otherwise expressly provided for in this statement, noncommercial use of this product, and shall not apply to the following, including,
but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not
intended; altered product or serial numbers; cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or
other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations,
repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product or result in service
problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow operating instructions,
cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal
or reinstallation; reception problems and distortion related to noise, echo, interference or other signal transmission and delivery
problems. SAMSUNG does not warrant uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES
WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE,
AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO
THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS,
FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH
THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL
RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT
SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES
ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS
AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT
CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER
THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
To obtain warranty hardware service, please contact SAMSUNG at:
Samsung Electronics America, Inc.
105 Challenger Road Ridgefield Park, NJ 07660-0511
1-800-SAMSUNG (726-7864) and www.samsung.com/us
HT-BD8200_XAA_0528-3.indd 98HT-BD8200_XAA_0528-3.indd 98 2009-05-30 3:00:172009-05-30 3:00:17
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer
care center.
Region Country Customer Care Center Web Site
North America
CANADA 1-800-SAMSUNG(726-7864) www.samsung.com/ca
MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com/mx
U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com/us
Latin America
ARGENTINE 0800-333-3733 www.samsung.com/ar
BRAZIL 0800-124-421, 4004-0000 www.samsung.com/br
CHILE 800-SAMSUNG(726-7864) www.samsung.com/cl
NICARAGUA 00-1800-5077267 www.samsung.com/latin
HONDURAS 800-7919267 www.samsung.com/latin
COSTA RICA 0-800-507-7267 www.samsung.com/latin
ECUADOR 1-800-10-7267 www.samsung.com/latin
EL SALVADOR 800-6225 www.samsung.com/latin
GUATEMALA 1-800-299-0013 www.samsung.com/latin
JAMAICA 1-800-234-7267 www.samsung.com/latin
PANAMA 800-7267 www.samsung.com/latin
PUERTO RICO 1-800-682-3180 www.samsung.com/latin
REP. DOMINICA 1-800-751-2676 www.samsung.com/latin
TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) www.samsung.com/latin
VENEZUELA 0-800-100-5303 www.samsung.com/latin
COLOMBIA 01-8000112112 www.samsung.com.co
Europe
BELGIUM 02 201 2418
www.samsung.com/be (Dutch)
www.samsung.com/be_fr (French)
CZECH REPUBLIC 800-SAMSUNG(800-726786) www.samsung.com/cz
DENMARK 8-SAMSUNG(7267864) www.samsung.com/dk
FINLAND 30-6227 515 www.samsung.com/fi
FRANCE 01 4863 0000 www.samsung.com/fr
GERMANY 01805 - SAMSUNG(726-7864 € 0,14/Min) www.samsung.de
HUNGARY 06-80-SAMSUNG(726-7864) www.samsung.com/hu
ITALIA 800-SAMSUNG(726-7864) www.samsung.com/it
LUXEMBURG 02 261 03 710 www.samsung.com/lu
NETHERLANDS
0900-SAMSUNG (0900-7267864) (€ 0,10/Min)
www.samsung.com/nl
NORWAY 3-SAMSUNG(7267864) www.samsung.com/no
POLAND
0 801 1SAMSUNG(172678), 022-607-93-33
www.samsung.com/pl
PORTUGAL 80820-SAMSUNG(726-7864) www.samsung.com/pt
SLOVAKIA 0800-SAMSUNG(726-7864) www.samsung.com/sk
SPAIN 902-1-SAMSUNG (902 172 678) www.samsung.com/es
SWEDEN 075-SAMSUNG(726 78 64) www.samsung.com/se
U.K 0845 SAMSUNG (7267864) www.samsung.com/uk
EIRE 0818 717 100 www.samsung.com/ie
AUSTRIA 0810-SAMSUNG(7267864, € 0.07/min) www.samsung.com/at
SWITZERLAND 0848-SAMSUNG(7267864, CHF 0.08/min) www.samsung.com/ch
CIS
RUSSIA 8-800-555-55-55 www.samsung.ru
KAZAKHSTAN 8-10-800-500-55-500 www.samsung.com/kz_ru
UZBEKISTAN 8-10-800-500-55-500 www.samsung.com/kz_ru
KYRGYZSTAN 00-800-500-55-500
TADJIKISTAN 8-10-800-500-55-500
UKRAINE 8-800-502-0000 www.samsung.ua
LITHUANIA 8-800-77777 www.samsung.com/lt
LATVIA 8000-7267 www.samsung.com/lv
ESTONIA 800-7267 www.samsung.com/ee
Asia Pacifi c
AUSTRALIA 1300 362 603 www.samsung.com/au
NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com/nz
CHINA 800-810-5858, 400-810-5858, 010-6475 1880 www.samsung.com/cn
HONG KONG 3698-4698 www.samsung.com/hk
INDIA 3030 8282, 1800 110011, 1-800-3000-8282 www.samsung.com/in
INDONESIA 0800-112-8888 www.samsung.com/id
JAPAN 0120-327-527 www.samsung.com/jp
MALAYSIA 1800-88-9999 www.samsung.com/my
PHILIPPINES
1-800-10-SAMSUNG(726-7864)
1-800-3-SAMSUNG(726-7864), 02-5805777
www.samsung.com/ph
SINGAPORE 1800-SAMSUNG(726-7864) www.samsung.com/sg
THAILAND 1800-29-3232, 02-689-3232 www.samsung.com/th
TAIWAN 0800-329-999 www.samsung.com/tw
VIETNAM 1 800 588 889 www.samsung.com/vn
Middle East &
Africa
TURKEY 444 77 11 www.samsung.com/tr
SOUTH AFRICA 0860-SAMSUNG(726-7864 ) www.samsung.com/za
U.A.E 800-SAMSUNG (726-7864), 8000-4726 www.samsung.com/ae
HT-BD8200_XAA_0528-3.indd 99HT-BD8200_XAA_0528-3.indd 99 2009-05-30 3:00:172009-05-30 3:00:17
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT WRITE
IN THE US 1-800-SAMSUNG
(7267864) www.samsung.com/us
Samsung Electronics America, Inc.
105 Challenger Road Ridgefi eld Park,
NJ 07660-0511
Code No. AH68-02196R
HT-BD8200_XAA_0528-3.indd 100HT-BD8200_XAA_0528-3.indd 100 2009-05-30 3:00:172009-05-30 3:00:17
