Users Manual 2
98
Section 7
messages you have saved in each folder.
For Multimedia Message, My MEdia and Games the
displays show the total memory amount, including the
amount of memory available and used for storing
messages. It also shows the memory amount used for
each message folder.
4. When you have finished, press the key.
x497.book Page 98 Tuesday, June 14, 2005 5:32 PM
Section 8
Section 8: Changing Your Settings 99
Section 8: Changing Your Settings
Topics Covered
•Time & Date
• Phone Settings
• Display Settings
• Sound Settings
• Network Settings
• Security Settings
• Resetting Your Phone
This section explains how to customize your settings for
your phone.
x497.book Page 99 Tuesday, June 14, 2005 5:32 PM
Section 8
100
Time & Date
This menu allows you to change the current time and date
displayed.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings and highlight Time & Date. Press the
Select soft key or the key. Select a menu and then
change the setting. If the menu has submenus, repeat as
necessary.
3. When you have finished, press the key
Set Time
Allows you to enter the current time. You can choose the
time format in the Time format menu.
Set Date
Allows you to enter the month, day, and year.
Time Format
Allows you to change the time format to 12 hours or
24 hours.
Auto Update
Allows you to receive time information from your service
provider’s network.
• Off: you need to manually set the time and date according to the
current time zone using the Set time menu (Menu 9.1.1).
• On: the phone automatically updates the time and date
according to the current time zone using the network service.
x497.book Page 100 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 101
Phone Settings
Section 8
• Confirm first: the phone asks for a confirmation before the
update.
Note: Automatic updates of time and date does not change the time you
have set for alarm settings or calendar memos.
Phone Settings
To customize the settings for your phone use the
following steps:
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings and highlight Phone Settings. Press the
Select soft key or the key.
3. Select a menu and then change the setting. If the menu
has submenus, repeat as necessary.
4. When you have finished, press the key
Language
You can select a display or text messaging language.
When the language option is set to Automatic, the
language is automatically selected according to the
language of the SIM card used.
Depending on your country, service provider, or the
software version of the phone, the Automatic option may
not display.
Greeting Message
This menu allows you to set a greeting to be displayed
briefly when the phone is switched on.
x497.book Page 101 Tuesday, June 14, 2005 5:32 PM
Section 8
102
Extra Settings
You can turn the automatic redial or answer features on or
off.
1. From the Phone Settings menu, Select Extra Settings
2. To turn a feature on, press the Select soft key or the
key. A check mark displays in front of the option.
3. To turn a feature off, press the Select soft key or the
key. The check mark no longer displays.
The following options are available:
Note: The interval between call attempts varies.
• Auto redial: when this option is checked, the phone makes up to
ten attempts to redial a phone number after an unsuccessful
call.
• Anykey answer: when this option is checked, you can answer
an incoming call by pressing any key, except the key or the
Reject soft key. To reject the call, press the key or the
Reject soft key.
• Open to Answer: when this option is checked, you can simply
open the phone to answer a call. When it is unchecked, you
must open the phone and press a key to answer a call,
depending on the setting of the Anykey answer option. See
below.
When this option is unchecked, you must press the key
or Accept soft key to answer a call.
x497.book Page 102 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 103
Display Settings
Section 8
Display Settings
In this menu, you can change various settings for the
display or backlight.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings and highlight Display Settings and
press the Select or key.
3. Select a menu and then change the setting. If the menu
has submenus, repeat this step.
For the details of each menu, see the next sections.
4. When you have finished, press the key
Wallpaper
This menu allows you to change the background image or
the color of the text to be displayed in Idle mode.
The following options are available:
• Shop Graphics: allows you to access the web site preset by your
service provider to download images. Once you have
downloaded images, they are saved in the Graphics folder.
• Animations: allows you to choose the multi-media or pictures
that appear in your phone’s display when you turn it on, turn it
off, and while in standby mode (wallpaper)
• Graphics: allows you to select a graphic that appear in your
phone’s display when you turn it on, turn it off, and while in
standby mode.
• Text Position: you can specify the positioning of the text in the
display.
• Text Color: you can specify whether or not the phone displays
the time and date on the Idle screen.
x497.book Page 103 Tuesday, June 14, 2005 5:32 PM
Section 8
104
Skin
This menu allows you to select the menu display style.
You can choose either Pattern 1 or Pattern 2.
Back Light Time
You can select the length of time the backlight is on. The
backlight turns on when you press a key, when you open
the phone or you receive a call or message, and remains on
for the specified length of time.
Brightness Control
You can adjust the display brightness to see it better in
different lighting conditions.
Press the Up or Down key or press the Vo lum e keys to
adjust the brightness.
Main LCD
You can adjust the Main LCD display brightness to see it
better in different lighting conditions.
Press the Up or Down key or press the Vo lum e keys to
adjust the brightness.
External LCD
You can adjust the external LCD display brightness to see
it better in different lighting conditions.
Press the Up or Down key or press the Vo lum e keys to
adjust the brightness.
Dialing Font Color
Dialing Font Color adjust the color of the numbers as they
are entered into the display.
x497.book Page 104 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 105
Sound Settings
Section 8
Press the Select soft key to select Black or Rainbow.
Sound Settings
You can customize the settings related to various sounds
for the phone, such as the call ringer, key tone, power on/
off tone, slider tone, and so on.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings. Highlight Sound Settings and press the
Select soft key or the key.
3. Select a menu and then change the setting. If the menu
has submenus, repeat as necessary.
4. When you have finished, press the key.
Incoming Calls
This menu allows you to specify how you are to be
informed of incoming calls.
The following options are available:
• Shop Ringtones: allows you to access the web site preset by
your service provider to download melodies. Once you have
downloaded melodies, they are saved in the Audio folder.
• Default Ringtones: allows you to use the preloaded ringtones
that come with your phone.
• My Audio: allows you to use recorded audio files.
• Ring Volume: allows you to adjust the ring volume to one of 5
levels.
• Alert Type: allows you to specify how you are to be informed of
incoming calls. The following options are available:
x497.book Page 105 Tuesday, June 14, 2005 5:32 PM
Section 8
106
• Melody: the phone rings using the ring melody selected in the
Ring Tone menu.
• Vibration: the phone vibrates but does not ring.
• Vibration then Melody: the phone first vibrates three times and
then starts ringing.
Keypad Tone
This menu allows you to select the tone that the phone
sounds when you press a key. To turn off the sound, select
Off.
Message Tone
This menu allows you to set up the ringer for incoming
messages, text messages, multimedia messages, and
broadcast messages
Text Message
This menu allows you to select how the phone informs
you that a new text message has been received.
The following options are available:
• Tone: allows you to use one of several message tones.
• Alert Type: allows you specify how you are informed of any
incoming messages.
• Silent: only the text notification appears; the phone neither rings
nor vibrates.
• Tone: the phone rings using the tone selected under the Tone
option.
• Vibration: the phone vibrates.
• Vibration Then Tone: the phone vibrate then selected tone
sounds.
x497.book Page 106 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 107
Sound Settings
Section 8
• Repetition: allows you to specify how often the phone informs
you of a new message. The following options are available:
• Once: the phone alerts you to a new message just once at the
time of receipt.
• Periodic: the phone alerts you to a new message every 2
minutes until you open the message.
Multimedia Message
This menu allows you to select how the phone informs
you that a new multimedia message has been received.
The following options are available:
• Tone: allows you to use one of several message tones.
• Alert Type: allows you specify how you are informed of any
incoming messages.
• Silent: only the text notification appears; the phone neither rings
nor vibrates.
• Tone: the phone rings using the tone selected under the Tone
option.
• Vibration: the phone vibrates.
• Vibration Then Tone: the phone vibrates then selected tone
sounds.
• Repetition: allows you to specify how often the phone informs
you of a new message. The following options are available:
• Once: the phone alerts you to a new message just once at the
time of receipt.
• Periodic: the phone alerts you to a new message every 2
minutes until you open the message.
x497.book Page 107 Tuesday, June 14, 2005 5:32 PM
Section 8
108
Power On/Off
This menu allows you to select the melody that the phone
sounds when it is switched on and off.
To turn off the sound, select Off.
Silent Mode
This menu allows you to choose whether or not the phone
informs you when you receive a new message or when the
time for an alarm comes during a call.
The following options are available:
• Vibration: the phone alerts you with a vibration and displays the
corresponding notification.
• Mute: the phone doesn’t actively alert you to incoming
messages or alarms. It only displays the corresponding
notification.
Extra Tone
You can customize additional tones for the phone.
1. To turn a given tone on, press the Select soft key or the
key. A check mark displays in front of the option.
2. To turn a given tone off, press the Select soft key or the
key. The check mark no longer displays in front of the
option.
Network Services
For more information about Network Services,
‘Section 11: Network Services” on page 145
x497.book Page 108 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 109
Security Settings
Section 8
Security Settings
The Security feature enables you to restrict the use of your
phone by the others and to restrict the types of calls.
Various codes and passwords are used to protect the
features of your phone.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings. Highlight Security and press the Select
soft key or the key.
3. Select a menu and then change the setting. If the menu
has submenus, repeat as necessary.
4. When you have finished, press the key.
PIN Check
When the PIN Check feature is enabled, you must enter
your PIN each time you switch on the phone.
Consequently, any person who does not have your PIN
cannot use your phone without your approval.
Note: Before disabling the PIN Check feature, you must enter your PIN.
The following options are available:
• Disable: the phone connects directly to the network when you
switch it on.
• Enable: you must enter the PIN each time the phone is switched
on.
x497.book Page 109 Tuesday, June 14, 2005 5:32 PM
Section 8
110
Change PIN
This feature allows you to change your current PIN,
provided that the PIN Check feature is enabled. You must
enter the current PIN before you can specify a new one.
Once you have entered a new PIN, you are asked to
confirm it by entering it again.
Phone Lock
When the Phone Lock feature is enabled, the phone is
locked and you must enter the 4- to 8-digit phone
password each time the phone is switched on.
Once the correct password has been entered, you can use
the phone until you switch it off.
The following options are available:
• Disable: you are not asked to enter the phone password when
you switch on the phone.
• Enable: you are required to enter the phone password when you
switch on the phone.
Change Password
The Change Password feature allows you to change your
current phone password to a new one. You must enter the
current password before you can specify a new one.
Privacy
Using this menu, you can lock your media contents, such
as picture messages, Voice messages, Voice list, images,
and sounds. Once you have locked the contents, you must
enter the phone’s password to access the associated
menus.
x497.book Page 110 Tuesday, June 14, 2005 5:32 PM
Section 8: Changing Your Settings 111
Security Settings
Section 8
1. To select an item to lock, press the Up or Down key. To
lock all of the contents, select All.
2. To place a check mark, press the key.
3. To remove a check mark, press the key.
4. To lock the marked items, press the OK soft key.
5. When the phone asks for the password, enter the
password and press the OK soft key or the key.
SIM Lock
When the SIM Lock feature is enabled, your phone only
works with the current SIM. You must enter the SIM lock
code to unlock the SIM so you can use a different SIM card.
Once you have entered the lock code, you are asked to
confirm your entry.
FDN Mode
FDN (Fixed Dial Number) mode, if supported by your
SIM card, allows you to restrict your outgoing calls to a
limited set of phone numbers.
The following options are available:
• Disable: you can call any number.
• Enable: you can only call phone numbers stored in Phone book.
You must enter your PIN2.
Note: Not all SIM cards have a PIN2. If your SIM card does not, this menu
does not display.
Change PIN2
The Change PIN2 feature allows you to change your
current PIN2 to a new one. You must enter the current
x497.book Page 111 Tuesday, June 14, 2005 5:32 PM
Section 8
112
PIN2 before you can specify a new one. Once you have
entered a new PIN2, you are asked to confirm it by
entering it again.
Note: Not all SIM cards have a PIN2. If your SIM card does not, this menu
does not display.
Resetting Your Phone
You can easily reset your phone to its’ default settings.
1. In Idle mode, press the Menu sot key to access Menu
mode.
2. Select Settings. Highlight Reset Settings and press the
Select soft key or the key.
3. Select All or a specific setting to reset.
• All
• Phone Settings
• Display Settings
• Sound Settings
Press the Yes soft key to confirm reset.
Press the No soft key to return to Reset Settings screen.
4. Enter the 4 to 8-digit password and press the OK soft key
or the key.
x497.book Page 112 Tuesday, June 14, 2005 5:32 PM
Section 9: WAP 113
Section 9
Section 9: WAP
Topics Covered
• Launching the WAP Browser
• Accessing a WAP site
• Navigating the WAP Browser
• Using Favorites
• Downloading Multimedia Files
• Clearing the Cache
Your phone is equipped with a WAP (Wireless
Application Protocol) browser which allows you to
access Internet specified for mobile phones. This section
explains how to access the WAP services of your service
provider and navigate the WAP browser.
x497.book Page 113 Tuesday, June 14, 2005 5:32 PM
114
Section 9
Launching the WAP Browser
1. In Idle mode, press the key to launch the WAP
browser.
or
Press the Menu soft key to access menu mode and
select MEdia Net and press the Select soft key or the
key.
2. Highlight MEdia Net Home and press the Connect soft
key or the key.
Your phone is connected to the network and loads the
homepage of the Wireless Web service provider. The
content of the start-up homepage depends on your
Wireless Web service provider.
3. To scroll through the screen, use the Up and Down
Navigation keys.
4. To exit the browser at any time, simply press the
key.
Access a WAP Site
There are several ways to access a WAP site:
• Selecting a link on the browser
• Using a bookmark item in the Favorites folder; use the
Bookmarks option on the browser menu list or Favorites menu.
• Entering a URL address manually; use the Go To URL option on
the browser menu list or http:// menu.
x497.book Page 114 Tuesday, June 14, 2005 5:32 PM
Section 9: WAP 115
Navigating the WAP Browser
Section 9
Navigating the WAP Browser
1. To scroll through browser items, press the Up or Down
Navigation keys.
2. To select a browser item, press the key or press the
Options soft key and choose Select.
3. To select a numbered item, press the corresponding
numeric key.
4. To return to the previous page, press the key, or
press the Options soft key and choose Back.
5. To access the browser menu list, press the Menu soft
key.
6. To return to the start-up homepage, press and hold the
key for more than two seconds, or press the Menu
soft key and select the Home option.
Entering Text in the WAP Browser
When you are prompted to enter text, the currently active
text input mode is indicated on the screen. To change the
text input mode, press the key one or more times.
The following modes are available:
Upper-Case Alphabet Mode (A)
allows you to enter upper-case characters.
Lower-Case Alphabet Mode (a)
allows you to enter lower-case characters.
Note: You can enter symbols in upper or lower case alphabet mode by
pressing the key.
x497.book Page 115 Tuesday, June 14, 2005 5:32 PM
116
Section 9
T9 Mode (T9)
allows you to enter characters by pressing one key per
letter. In this mode, you can use only the key to
display alternative words. To change case, press the
key.
Number Mode (1)
allows you to enter numbers.
Selecting and Using Menu Options
Various menus are available when you are using the WAP
Browser to navigate the Wireless Web.
To access a menu option, press the menu soft key. A menu
list displays.
Note: The menus may vary, depending on your version of the WAP
Browser.
The following options are available:
• Favorite: shows the bookmarks list. You can bookmark the
current page or access previously book marked pages.
• Reload: reloads the current page.
• Home: takes you back at any time to the homepage of the
Wireless Web service provider.
• Go to URL: allows you to manually enter the URL address of a
WAP site. After entering an address, press the OK soft key to go
there directly.
• Show URL: displays the URL address of the page to which you
are currently connected. It also enables you to set the current
site as the startup homepage.
x497.book Page 116 Tuesday, June 14, 2005 5:32 PM
Section 9: WAP 117
Using Favorites
Section 9
• Cache: deletes the information stored in the cache. The cache
stores the most recently accessed pages.
• Inbox: allows you to read messages received from a WAP
server.
• Text Messages: allows you to send messages using the WAP
server.
• Show Images: shows the image on the current page. Press the
Next soft key to view the next images.
• Certificates: shows the security information when you access
the Wireless Web with the secured WAP setting activated.
Using Favorites
While navigating the WAP browser, you can bookmark
the site to quickly and easily access it at a future time. The
URL addresses of the book marked sites are stored in the
Favorites folder, wherein you can use the 5-preset URL
addresses and store your favorite URL addresses.
Accessing a WAP Site Using Favorites
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Highlight MEdia Net and press the Select soft key or the
key.
3. Select Favorites.
4. Select a bookmark item from the Favorite list and press
the Select soft key or the key.
5. Select the option Go. You are accessed to the
corresponding WAP site.
Storing a URL Address
1. In Idle mode, press the Menu soft key to access Menu
x497.book Page 117 Tuesday, June 14, 2005 5:32 PM
118
Section 9
mode.
2. Highlight MEdia Net and press the Select soft key or the
key.
3. Select Favorites.
4. Select an Empty location, and press the Select soft key
or key.
5. Enter the address and press the OK soft key or the
key.
6. Enter a name for the bookmark and press the OK soft key
or the key. The bookmark name displays in the
selected location.
7. When you have finished, press the key.
Editing a Bookmark
1. From the Favorite list, select the bookmark you want to
change.
2. Select Edit.
3. Change the address and the name, as you would when
storing a new one.
4. When you have finished, press the key.
Deleting a Bookmark
1. From the Favorites list, select the bookmark you want to
delete.
2. Select Delete.
3. Press the Yes soft key or the key to confirm the
deletion.
4. When you have finished, press the key.
x497.book Page 118 Tuesday, June 14, 2005 5:32 PM
Section 9: WAP 119
Downloading Multimedia Files
Section 9
Downloading Multimedia Files
You can buy a variety of multimedia files, such as
ringtones, graphics, applications, Multimedia contents,
and so on from the WAP browser and download them to
your phone’s memory. Your phone has embedded links to
the WAP sits providing you with download services,
preset by your service provider.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select MEdia Mall. Highlight Shop Ringtones, Shop
Games, Shop Graphics, Shop Multimedia, or Shop
Applications, depending on the type of items you want
to buy.
To access homepage of the online shopping mall, select
MEdia Home.
3. Find the item you want to download and follow the
instructions on the screen to purchase it.
Note: This content is delivered to you in Multimedia messages. You can
retrieve the messages from the server and then save the items in your
phone’s memory. you cannot forward these messages to other people or
add the saved items to an Multimedia message.
Clearing the Cache
The cache is the phone’s temporary memory in which the
most recently accessed WAP pages are stored. You can
clear the cache at anytime.
1. In Idle mode, press the Menu soft key to access Menu
mode.
x497.book Page 119 Tuesday, June 14, 2005 5:32 PM
120
Section 9
2. Highlight MEdia Net and press the Select soft key or the
key.
3. Select Clear Cache.
4. Press the Yes soft key or the key to confirm deletion.
5. When you have finished, press the key
Changing the WAP Profiles
You can set up 5 server profiles for the WAP browser.
1. In Idle mode, press the Menu soft key to access menu
mode and select MEdia Net and press the Select soft
key or the key.
2. Using the Up or Down Navigation key scroll to Browser
Profiles and press the Select soft key or the key.
3. Scroll to Profile Settings and press the Select soft key
or the key.
4. Select the profile you want.
For each profile, the following options are available:
• Profile Name: enter a name that you wish to assign to the HTTP
proxy server.
• Home URL: set the address of your startup homepage. When
the default homepage displays, you can delete it using the
key and enter your own choice.
• Bearer: select the bearer to be used for each type of network
address accessed: GPRS First, GPRS Only or GSM Only.
• Proxy Use: enter the WAP gateway address required to connect
to the Internet.
x497.book Page 120 Tuesday, June 14, 2005 5:32 PM
Section 9: WAP 121
Clearing the Cache
Section 9
• GPRS Setting:
• Proxy Address: enter the WAP gateway address required to
connect to the Internet.
• Proxy Port: enter the Proxy port required to connect to the
Internet.
• APN: enter the access point name used for the address of the
GPRS network gateway.
• Login ID: enter the Login ID required to connect to the GPRS
network.
• Password: enter the password required to connect to the
GPRS network.
• GSM Setting:
• Proxy Address: enter the WAP gateway address required to
connect to the Internet.
• Proxy Port: enter the Proxy port required to connect to the
Internet.
• Dial Number: enter the server phone number.
• Login ID: enter the Login ID required to connect to the GSM
network.
• Password: enter the password required to connect to the
GSM network.
• Data Call Type: select the data call type: ISDN or Analog.
Note: The WAP settings may vary depending on the service provider.
x497.book Page 121 Tuesday, June 14, 2005 5:32 PM
122
Section 9
x497.book Page 122 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 123
Section 10
Section 10: Personal Organizer
Topics Covered
•Alarms
•Organizer
• Using the Calendar
• Using the To Do List
• Using the Calculator
• Record Audio
• Unit Conversion
• Using the Timer
• Stopwatch
•World Time
The topics covered in this section allow you to schedule
appointments, view the calendar, create To-Do lists, set
an alarm, and perform simple math calculations.
x497.book Page 123 Tuesday, June 14, 2005 5:32 PM
124
Section 10
Alarms
You can set the alarm to ring at a specific time. You can also
set the phone to switch on automatically and ring the
alarm even if the phone is switched off.
Setting an Alarm
1. In Idle mode, press the Menu soft key and select Games
& Applications.
2. Highlight Alarm and press the Select soft key or the
key.
3. Select an Alarm Type
• Wake-up Call: the alarm rings to wake you up at the specified
time.
• Alarm 1: primary alarm setting.
• Alarm 2: secondary alarm setting.
• Auto Power: the alarm rings even when the phone is turned off.
4. Press the Select soft key or the key.
Note: Your phone is preset to a 12-hour format.
If you want to use the alarm options, press the Options
soft key. The following options are available:
• Alarm Day: select the day or days the alarm will sound.
• Alarm Time: select the time the alarm will sound
• Alarm Tone: select the sound of the alarm
• Remove Alarm: removes alarm settings.
5. Highlight Alarm Day and press the Select soft key.
x497.book Page 124 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 125
Alarms
Section 10
6. Highlight the days you want the alarm to sound and
press the Select soft key or the key. Press the OK
soft key when finish. The Alarm Time screen displays.
7. Enter the time for the alarm to sound using the
alphanumeric keypad. Press the OK soft key or the
key.
8. Select AM or PM and press the Select soft key or the
key.
To stop the alarm when it rings, open the phone and
press the Confirm soft key.
Setting Autopower Alarms
You can set the phone to ring the alarm when the time for
an alarm comes, if the phone is switched off.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Alarm and
press the Select soft key or the key.
3. Select Autopower.
4. Select On to activate the Autopower feature. The phone
will automatically switch on to ring the alarm when the
alarm time comes.
If the menu option is set to Off, and the phone is
switched off at the specified time, the alarm does not
ring.
5. When you have finished, press the key.
x497.book Page 125 Tuesday, June 14, 2005 5:32 PM
126
Section 10
Deactivating Alarms
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Alarm and
press the Select soft key or the key.
3. Select Alarm Type and press the Select soft key or the
key.
4. Press the Options soft key and highlight Remove Alarm
and press the Select soft key or the key.
A pop-up message displays confirming Alarm
Deactivate. Press Yes to remove or No to exit.
5. When you have finished, press the key.
Using Organizer
Organizer is a suite of PIM (Personal Information
Management) applications such as a Calendar, To Do List,
and Memo Pad. Schedule events, set reminders, create to
do lists, perform calculations, and more with the digital
assistant functionality of this useful feature.
1. Press the Menu soft key and select Games &
Applications.
2. Highlight Organizer and press the Select soft key or the
key. The following appear in the display.
• New Memo: Enter a memo, which can be viewed at any time.
Memos do not have an alarm setting.
• Calendar: Schedule events for any day by indicating each
event’s start and end time.
• To Do List: Enter up to 25 tasks and set an alarm for each.
x497.book Page 126 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 127
Using Organizer
Section 10
3. Use the Navigation key to highlight an application. Press
the Select soft key or the to enter the highlighted
application’s sub menu. The following sections provide a
detailed description on each application and its function.
Writing a Memo
Create and store notes in Memo Pad. You can’t prioritize
or set an alert for stored notes. Return to Memo Pad
anytime to review and edit your notes.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight New Memo and press the Select soft key or
the key.
4. Add a new memo.
5. While entering a memo, press the right soft key Options
to display a the following text entry modes:
• ABC Mode
• T9 Mode
• Symbolic
• Number
• Add Word
• Language Select
6. Highlight the text mode and press the Select soft key or
the key.
x497.book Page 127 Tuesday, June 14, 2005 5:32 PM
128
Section 10
7. When you’re finished entering details for the memo,
press the left soft key OK. The Save to sub menu appear
in the display.
8. Highlight Save to option and press the Select soft key or
the key. The calendar displays with today’s date
highlighted.
9. Using the Navigation key select a date and press the
Select soft key or the key.
10. Using the keypad enter the memo time and press the OK
soft key or the key.
11. Select AM or PM, press the Select soft key or the
key. The Alarm Time screen appear in the display.
12. Press the Yes soft key to set alarm.
Press the No soft key to save memo.
13. Using the keypad enter the Alarm time and press the OK
soft key or the key
14. Select AM or PM, press the Select soft key or the
key. The Alarm Tone screen displays.
15. Using the Navigation key scroll alarm tones.
16. Select alarm tone using the Select soft key or the
key.
Using Memo Pad Options
You can access the following options by pressing the
Options soft key:
• Add: allows you to add a memo.
• Delete: deletes a memo.
x497.book Page 128 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 129
Using the Calendar
Section 10
• Edit: allows you to edit the content of your memo.
• Move: allows you to move a memo.
• Copy: allows you to copy a memo.
Using the Calendar
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight Calendar and press the Select soft key or the
key. The calendar displays with today’s date
highlighted.
4. Scroll to a date on the calendar by pressing the
Navigation key and the Select soft key or the key.
Alternatively, press the Options soft key and select Go
to Date. You can enter manually a specific date and
press the OK soft key or the key.
An empty memo screen displays allowing you to enter
your memo.
5. While entering your memo, press the right soft key
Options to display a pop-up menu with the following
text entry modes:
•ABC Mode
•T9 Mode
• Symbolic
• Number
• Add Word
• Language Select
x497.book Page 129 Tuesday, June 14, 2005 5:32 PM
130
Section 10
6. Highlight the text mode and press the Select soft key or
the key.
7. When you’re finished entering details for the memo,
press the left soft key OK. The Save to sub menu appear
in the display.
• Scheduler
• To Do List
•Call
•Anniversary
8. Highlight Save to option and press the Select soft key or
the key.
9. Using the keypad enter the memo time and press the OK
soft key or the key.
10. Select AM or PM, press the Select soft key or the
key. The Alarm Time screen appear in the display.
The color of the date on the calendar changes to blue to
indicate that a memo exist for that date.
11. If you want an alarm to ring on the chose day press the
Yes soft key or the key to set alarm. If not, Press the
No soft key. The memo is saved.
12. Using the keypad enter the Alarm time and press the OK
soft key or the key
13. Select AM or PM, and press the Select soft key or the
key. The Alarm Tone screen displays.
14. Using the Navigation key scroll through alarm tones.
15. Select alarm tone using the Select soft key or the
key.
x497.book Page 130 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 131
Using the Calendar
Section 10
16. When you have finished, press the key.
Consulting the Calendar
Viewing Memos on the Selected Date
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight Calendar and press the Select soft key or the
key. The calendar displays with today’s date
highlighted.
4. Select the date you want to view its memo(s).
If there is more than one memo for that date, the latest
memo displays
5. Press the Up or Down key to scroll to the previous or
next memo
If you want to make a new memo for that date, press the
Options soft key.
• Add Memo: allows you to add new memo.
• Go to Date: allows you to go directly to a specified date. Enter
the date using the keypad.
• View All: allows you to view all memos in the calendar.
• Delete Day: allows you to delete the memo for that day.
• Delete All: allows you to delete all memos in the calendar.
6. When you have finished, press the key.
Viewing All of the Memos on the Calendar
1. In Idle mode, press the Menu soft key to access menu
x497.book Page 131 Tuesday, June 14, 2005 5:32 PM
132
Section 10
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight Calendar and press the Select soft key or the
key. The calendar displays with today’s date
highlighted.
4. Press the Options soft key and select View All. The
phone displays the latest memo. You can view all of the
memos, starting with the oldest, regardless of the date.
5. To scroll through the memos, press the Left or Right
Navigation key
6. When you have finished, press the key.
Deleting Memos
You can delete memos on the calendar one by one or all at
one time.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight Calendar and press the Select soft key or the
key. The calendar displays with today’s date
highlighted.
4. Select the date you want to view its memo(s),
If there is more than one memo for that date, the latest
memo displays.
5. Press the Left or Right Navigation key to scroll to the
previous or next memo.
x497.book Page 132 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 133
Using the To Do List
Section 10
6. Press the Options soft key and select Delete.
7. Press the Yes soft key to confirm deletion.
8. When you have finished, press the key.
Deleting All Memos
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight Calendar and press the Select soft key or the
key. The calendar displays with today’s date
highlighted.
4. Press the Options soft key and select Delete All.
5. Press the Yes soft key to confirm deletion.
6. When you have finished, press the key.
Using the To Do List
The To Do List allows you to
• enter a list of task to be done
• assign a priority and a deadline to each task
• sort the tasks by priority and status
Creating a To Do List
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
x497.book Page 133 Tuesday, June 14, 2005 5:32 PM
134
Section 10
3. Highlight To Do List and press the Select soft key or the
key. You’re prompted to add a new memo.
4. While entering a memo, press the right soft key Options
to display a pop-up menu with the following text entry
modes
• ABC Mode
•T9 Mode
•Symbolic
• Number
•Add Word
• Language Select
5. Highlight the text mode and press the Select soft key or
the key.
6. When you’re finished entering details for the memo,
press the OK soft key. The Calendar displays.
7. Using the Navigation key select a date and press the
Select soft key or the key.
8. Using the keypad enter the memo time and press the OK
soft key or the key.
9. Select AM or PM, press the Select soft key or the
key. The Alarm Time screen appear in the display.
10. Press the Yes soft key to set alarm.
Press the No soft key to save memo.
11. Using the keypad enter the Alarm time and press the OK
soft key or the key
12. Select AM or PM, press the Select soft key or the
key. The Alarm Tone screen displays.
x497.book Page 134 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 135
Using the To Do List
Section 10
13. Using the navigation key scroll alarm tones.
14. Select alarm tone using the Select soft key or the
key.
Adding Tasks to the To Do List
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight To Do List and press the Select soft key or the
key.
4. Press the Options soft key and Select Add. Continue
using steps in "Creating a To Do List" on page 133.
Viewing the To Do List
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Organizer and
press the Select soft key or the key.
3. Highlight To Do List and press the Select soft key or the
key. The tasks displays.
4. You can scroll through the task using the Up and Down
Navigation key, if necessary.
5. When you have finished, press the key.
Using To Do List Options
You can access the following options by pressing the
Options soft key
• Add: allows you to add a new task
x497.book Page 135 Tuesday, June 14, 2005 5:32 PM
136
Section 10
• Mark: allows you to change the status of a task. Select
appropriate status (Done or Undo)
• Edit: allows you to edit a task. You can change the text priority,
and/or deadline for the task.
• Move: allows you to move a task.
• Copy: allows you to copy a task.
• Delete: deletes a task.
• Delete All: allows you to delete all tasks.
Using the Calculator
You can use the phone as a calculator. The calculator
provides basic arithmetic functions: addition,
subtraction, multiplication, and division using your
phone.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Calculator and
press the Select soft key or the key.
3. Enter the first number in your equation using the keypad.
• Press the to enter a decimal point
• Press the to set the type of calculation you that you
wish to perform. Your choices are as follows
• [+ ] Addition
• [ - ] Subtraction
• [ x ] Multiplication
•[ ÷ ] Division
•[ % ] Percentage
• [ ( ] Open Parenthesis
x497.book Page 136 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 137
Record Audio
Section 10
•[ ) ] Closed Parenthesis
4. Use the keypad to enter the second number into your
equation.
5. Press the Equal soft key or the key to perform the
operation and view your results in the Answer field of
the Calculator screen.
6. Repeat steps 3 to 5 as many times as required.
7. When you have finished, press the key.
Record Audio
This menu allows you to record a new memo.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. The following sub menu
displays.
3. Highlight Record Audio and press the Select soft key or
the key.
4. Highlight Record and press the Select soft key or the
key. The following icons appear in the bottom of the
display:
• Record
• Stop
• Play
• Rewind
• Fast Forward
5. Press the Select soft key or the to start recording.
Record a memo by speaking into the microphone.
x497.book Page 137 Tuesday, June 14, 2005 5:32 PM
138
Section 10
6. When you press the Select soft key or the key to stop
recording or the time expires. The audio is automatically
saved and the play icon is highlighted in red.
7. Press the Select soft key or the key to play recording.
During playback the following playback options are
available.
• Stop
• Play
• Rewind
• Fast Forward
• Pause
8. Press the Options soft key to display the following
• Send: allows you to send the recorded audio to other people by
using the MMS feature. For details about sending a multimedia
message, see "Creating and Sending a Multimedia Message"
on page 89
• Rename: allows you to rename the recording.
• Delete: deletes the recording.
• Properties: displays detailed information about the recorded
audio message such as name, size and format.
9. When you have finished, press the key.
Reviewing a Recorded Audio
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. The following sub menu
displays.
3. Highlight Record Audio and press the Select soft key or
the key.
x497.book Page 138 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 139
Record Audio
Section 10
4. Highlight Recorded Audio and press the Select soft key
or the key. A list of recorded audios display.
5. Scroll to an audio file. Press the Select soft key or the
key to play audio.
6. Press the Options soft key to display the following.
• Send: allows you to send the recorded audio to other people by
using the MMS feature. For details about sending a multimedia
message, see "Creating and Sending a Multimedia Message"
on page 89
• Rename: allows you to rename the recording.
• Delete: deletes the recording.
• Properties: displays detailed information about the recorded
audio message such as name, size and format.
7. When you have finished, press the key.
Deleting Recorded Audios
You can delete your recorded audios one by one or all at
one time.
1. Access the Recorded Audio menu and select the audio
file you want to delete.
2. Press the Select soft key or the key.
3. Press the Options soft key and then select Delete.
4. Press the Yes soft key or the key to confirm deletion.
5. When you have finished, press the key.
Delete All Recorded Audios
1. In Idle mode, press the Menu soft key to access menu
mode.
x497.book Page 139 Tuesday, June 14, 2005 5:32 PM
140
Section 10
2. Select Games & Applications. Highlight Record Audio
and press the Select soft key or the key.
3. Scroll down using the Navigation key and highlight
Delete All and press the Select soft key or the key.
4. Press the Yes soft key or the to confirm Delete All.
5. When you have finished, press the key.
Changing Record Audio Settings
You can change the default settings for using Record
Audio.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Record Audio
and press the Select soft key or the key.
3. Select Settings and press the Select soft key or the
key.
The following options are available:
• Recording Time: allows you to set recording time.
• Volume: allows you to set the sound volume.
• Default Name: allows you to set a default name for all recorded
audio.
4. When you have finished, press the key.
Checking Memory Status
You can check the amount of memory being used and the
memory remaining for voice memos.
x497.book Page 140 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 141
Using Unit Conversion
Section 10
The display shows you the total, used, and free memory,
including the number of memos you stored and the total
number of memos you can store.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Record Audio
and press the Select soft key or the key.
3. Select Memory Status.
This display show the Total, Used and Free memory
amount for My MEdia, Games, and Multimedia
Messages.
4. When you have finished, press the key.
Using Unit Conversion
You can use the phone as a unit converter. The unit
converter provides basic conversion functions: length,
weight, volume, area, and temperature.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Unit
Conversion and press the Select soft key or the key.
The unit conversion sub menu appear display.
• Length
•Weight
•Volume
•Area
• Temperature
x497.book Page 141 Tuesday, June 14, 2005 5:32 PM
142
Section 10
3. Use the Navigation key to highlight a conversion option
and press the Select soft key or .
4. Enter the amount to convert. Use the Navigation key to
select the conversion method.
Using the Timer
Timer allows you to view the amount of time between the
current day and any event that you wish to schedule.
1. In Idle mode, press the Menu soft key to access menu
mode.
2. Select Games & Applications. Highlight Timer and
press the Select soft key or the key. The Timer
screen appear in the display.
3. Press the Set soft key to set timer.
4. Using the keypad enter the time and press the OK soft
key.
5. Press the Start soft key to start timer.
Press the Stop soft key to stop timer.
Stopwatch
You can use this menu to set a stop watch. Press the OK
soft key to start the stopwatch. Press the Reset soft key to
erase all stop watch times recorded.
World Time
World Time allows you to view the time of day or night in
any part of the world.
1. In Idle mode, press the Menu soft key to access menu
mode.
x497.book Page 142 Tuesday, June 14, 2005 5:32 PM
Section 10: Personal Organizer 143
World Time
Section 10
2. Select Games & Applications. Highlight World Time
and press the Select soft key or the key.
3. Use the Navigation key to display the city (or cities), date,
and time that you wish to view. The following cities are
supported.
•Chicago
•New York
• Caracas
•Rio
• GMT
• London
•Paris
•Cairo
•Moscow
•Dubai
• Karachi
•Delhi
• Dacca
•Bangkok
• Beijing/H.K.
•Seoul
• Sydney
•Noumea
•Wellington
•Honolulu
• Anchorage
•LA
•Denver
x497.book Page 143 Tuesday, June 14, 2005 5:32 PM
144
Section 10
x497.book Page 144 Tuesday, June 14, 2005 5:32 PM
Section 11: Network Services 145
Section 11
Section 11: Network Services
Topics Covered
• Network Services
• Call Forwarding
• Call Waiting
•Network Selection
•Caller ID
This section allows set up the network functions
supported by your carrier. Some of these services may not
be available due to coverage area or service plans. If you
have any questions, please contact the Customer Support
center.
x497.book Page 145 Tuesday, June 14, 2005 5:32 PM
146
Section 11
Network Services
You can customize the settings for network features, such
as call forwarding, and call waiting.
1. In Idle mode, press the Menu soft key to access Menu
mode.
2. Select Settings and highlight Network Services. Press
the Select soft key or the key.
3. Select a menu and then change the setting. If the menu
has submenus, repeat as necessary.
4. When you have finished, press the key
Call Forwarding
This network service enables incoming calls to be
rerouted to the number that you specify.
For example, you may wish to forward your business calls
to a colleague while you are on vacation.
1. From the Network Services menu screen, select Call
Forwarding and press the Select soft key or the key.
2. Select one of the following call forwarding options.
• Forward Always: all calls are forwarded
• Busy: calls are forwarded when you are already on another call
• No Reply: calls are forwarded when you do not answer the
phone.
• Unreachable: calls are forwarded when you are not in an area
covered by your service provider or when your phone is
switched off.
• Cancel All: all call forwarding options are canceled.
x497.book Page 146 Tuesday, June 14, 2005 5:32 PM
Section 11: Network Services 147
Call Waiting
Section 11
3. Select the type of calls, Voice Calls or Data Calls. The
current status displays. If the option has already been
set, the number to which the calls are forwarded
displays.
4. Press the Activate soft key or the key.
5. Using the keypad enter the forwarding number and press
the OK soft key or the key.
Call Waiting
This network service informs you when someone is trying
to reach you during another call. You can specify
individual call waiting options for voice calls and/or data
calls.
Setting Call Waiting Options
1. From the Network Services menu screen, select Call
Waiting.
2. Select the type of calls, Voice Calls or Data Calls. The
screen informs you whether call waiting is activated or
deactivated.
3. Press the Activate soft key or the key to activate the
call waiting feature.
4. The phone sends your settings to the network and the
network’s acknowledgement displays.
x497.book Page 147 Tuesday, June 14, 2005 5:32 PM
148
Section 11
Deactivating Call Waiting Settings
1. From the Network Services menu screen, select Call
Waiting.
2. Select the type of calls, Voice Calls or Data Calls. The
screen informs you whether call waiting is activated or
deactivated.
Select Cancel All to cancel all call waiting options.
3. Press the Deactivate soft key or the key.
4. The phone sends your settings to the network and the
network’s acknowledgement displays.
Network Selection
The Network Selection feature enables you to
automatically or manually select the network used when
roaming outside of your home area.
Note: You can select a network other than your home network only if there
is a valid roaming agreement between the two.
1. From the Network Services menu screen, select
Network Selection.
2. Select the options you want.
If you select Automatic, you are connected to the first
available network when roaming.
If you select Manual, go to step 3.
3. Select the network you want. The phone will scan for
that network and you will be connected.
x497.book Page 148 Tuesday, June 14, 2005 5:32 PM
Section 11: Network Services 149
Caller ID
Section 11
Caller ID
You can prevent your phone number from being
displayed on the phone of the person you are calling.
Note: Some networks do not allow you to change this setting.
The following options are available:
• Default: the default setting provided by the network is used.
• Hide Number: you number does not display on the other
person’s phone.
• Send Number: your number is sent each time you make a call.
x497.book Page 149 Tuesday, June 14, 2005 5:32 PM
150
Section 11
x497.book Page 150 Tuesday, June 14, 2005 5:32 PM
Section 12
Section 12: Games 151
Section 12: Games
Topics Covered
• Shop Games
•My Games
• Settings
• Memory Status
This section outlines the available gaming options and
accessories for your phone. For more information, contact
your service provider.
x497.book Page 151 Tuesday, June 14, 2005 5:32 PM
Section 12
Section 12: Games 152
Shop Games
Your phone is equipped with a WAP (Wireless
Application Protocol) browser to allow you to access and
navigate the Wireless Web using your phone. For more
information, see ‘Section 9: WAP” on page 113
You can download MIDlets (Java applications that run on
mobile phones) from various sources using the WAP
browser and store them in your phone. When you access
the Games menu, the list of default games appears. Once
you have downloaded games, they are added to the list.
Note: Java services may not be available, depending on your service plan
and phone model.
My Games
My Games stores all downloaded games.
Settings
You can customize the profiles containing the settings for
connecting your phone to the network. These settings are
also used for the WAP browser or Instant Messenger, or
sending Multimedia messages or Emails.
• APN: enter the access point name used for the address of the network.
• Login ID: enter the user ID required to connect to the network.
• Password: enter the password required to connect to the network.
• DNS Settings: enter the DNS (Domain Name System) address.
x497.book Page 152 Tuesday, June 14, 2005 5:32 PM
Section 12
Section 12: Games 153
Memory Status
You can check the amount of memory being used and
memory remaining for games, multimedia messages,
and My MEdia.
x497.book Page 153 Tuesday, June 14, 2005 5:32 PM
Section 12
154
x497.book Page 154 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 155
Section 13
Section 13: Health and Safety
Information
Topics Covered
• Health and Safety Information
This section outlines the safety precautions associated
with using your phone. These safety precautions should
be followed to safety use your phone.
x497.book Page 155 Tuesday, June 14, 2005 5:32 PM
156
Section 13
Health and Safety Information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
government. These FCC exposure limits are derived from
the recommendations of two expert organizations, the
National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientific and
engineering experts drawn from industry, government,
and academia after extensive reviews of the scientific
literature related to the biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of
the rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The
FCC requires wireless phones to comply with a safety
limit of 1.6 watts per kilogram (1.6 W/kg). The FCC
exposure limit incorporates a substantial margin of safety
to give additional protection to the public and to account
for any variations in measurements.
x497.book Page 156 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 157
Health and Safety Information
Section 13
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined
at the highest certified power level, the actual SAR level of
the phone while operating can be well below the
maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the
power required to reach the network. In general, the
closer you are to a wireless base station antenna, the
lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC. Body-worn operations are
restricted to Samsung-supplied, approved, or non-
Samsung designated accessories that have no metal and
must provide at least 1.5 cm separation between the
device, including its antenna (whether extended or
retracted) and the user's body. Non-compliance with the
above restrictions may result in violation of FCC RF
exposure guidelines.
The FCC has granted an Equipment Authorization for
this mobile phone with all reported SAR levels evaluated
as in compliance with the FCC RF exposure guidelines.
The maximum SAR values for this model phone as
reported to the FCC are :(FCC ID : A3LSGHX497)
x497.book Page 157 Tuesday, June 14, 2005 5:32 PM
158
Section 13
• Head: 1.4 W/Kg, Body-worn:1.42 W/Kg in GSM 850.
• Head: 0.510 W/Kg, Body-worn: 0.295 W/Kg in GSM 1900.
SAR information on this and other model phones can be
viewed on-line at www.fcc.gov/oet/fccid. To find
information that pertains to a particular model phone,
this site uses the phone FCC ID number which is usually
printed somewhere on the case of the phone. Sometimes
it may be necessary to remove the battery pack to find the
number. Once you have the FCC ID number for a
particular phone, follow the instructions on the website
and it should provide values for typical or maximum SAR
for a particular phone. Additional product specific SAR
information can also be obtained at www.fcc.gov/cgb/
sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes the
following information:
What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called "cell,"
"mobile," or "PCS" phones. These types of wireless
phones can expose the user to measurable radio
frequency energy (RF) because of the short distance
between the phone and the user's head. These RF
exposures are limited by Federal Communications
Commission safety guidelines that were developed with
the advice of FDA and other federal health and safety
x497.book Page 158 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 159
Consumer Information on Wireless Phones
Section 13
agencies. When the phone is located at greater distances
from the user, the exposure to RF is drastically lower
because a person's RF exposure decreases rapidly with
increasing distance from the source. The so-called
"cordless phones," which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range
while being used. They also emit very low levels of RF
when in the stand-by mode. Whereas high levels of RF
can produce health effects (by heating tissue), exposure to
low level RF that does not produce heating effects causes
no known adverse health effects. Many studies of low
level RF exposures have not found any biological effects.
Some studies have suggested that some biological effects
may occur, but such findings have not been confirmed by
additional research. In some cases, other researchers have
had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new drugs
x497.book Page 159 Tuesday, June 14, 2005 5:32 PM
160
Section 13
or medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard no
longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• "Support needed research into possible biological effects of RF
of the type emitted by wireless phones;
• "Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device function;
and
• "Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• "National Institute for Occupational Safety and Health
• "Environmental Protection Agency
• "Federal Communications Commission
• "Occupational Safety and Health Administration
• "National Telecommunications and Information Administration
x497.book Page 160 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 161
Consumer Information on Wireless Phones
Section 13
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations are
thus not the primary subject of the safety questions
discussed in this document.
What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy (RF)
exposures characteristic of wireless phones have yielded
conflicting results that often cannot be repeated in other
laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer-causing chemicals so as
to be pre-disposed to develop cancer in absence of RF
exposure. Other studies exposed the animals to RF for up
x497.book Page 161 Tuesday, June 14, 2005 5:32 PM
162
Section 13
to 22 hours per day. These conditions are not similar to the
conditions under which people use wireless phones, so
we don't know with certainty what the results of such
studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phones RF exposures. However,
none of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be
needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide
data that is directly applicable to human populations, but
ten or more years' follow-up may be needed to provide
answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a
cancer-causing agent and the time tumors develop - if
they do - may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
x497.book Page 162 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 163
Consumer Information on Wireless Phones
Section 13
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a detailed
agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research
on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
x497.book Page 163 Tuesday, June 14, 2005 5:32 PM
164
Section 13
What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products - and at this point we
do not know that there is - it is probably very small. But
if you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
• "If you must conduct extended conversations by wireless phone
every day, you could place more distance between your body
and the source of the RF, since the exposure level drops off
dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body or
use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones.
Reducing the time of wireless phone use and increasing
the distance between the user and the RF source will
reduce RF exposure.
x497.book Page 164 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 165
Consumer Information on Wireless Phones
Section 13
Some groups sponsored by other national governments
have advised that children be discouraged from using
w i r e l e s s p h o n e s a t a l l . F o r e x a m p l e , t h e g o v e r n m e n t i n t h e
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
Do wireless phone accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
x497.book Page 165 Tuesday, June 14, 2005 5:32 PM
166
Section 13
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised.
Unlike "hand-free" kits, these so-called "shields" may
interfere with proper operation of the phone. The phone
may be forced to boost its power to compensate, leading
to an increase in RF absorption. In February 2002, the
Federal trade Commission (FTC) charged two companies
that sold devices that claimed to protect wireless phone
users from radiation with making false and
unsubstantiated claims. According to FTC, these
defendants lacked a reasonable basis to substantiate their
claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI. FDA
has tested wireless phones and helped develop a
x497.book Page 166 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 167
Consumer Information on Wireless Phones
Section 13
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This standard
specifies test methods and performance requirements for
hearing aids and wireless phones so that no interference
occurs when a person uses a compatible phone and a
compatible hearing aid at the same time. This standard
was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the following
organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's (OSHA):
http://www.osha.slc.gov/SLTC/radiofrequencyradiation/
index.html
• National institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
x497.book Page 167 Tuesday, June 14, 2005 5:32 PM
168
Section 13
• Updated 4/3/2002: US food and Drug Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features, such
as speed dial and redial. If available, these features help
you to place your call without taking your attention off
the road.
2. When available, use a hands-free device. If possible, add
an additional layer of convenience and safety to your
wireless phone with one of the many hands free
accessories available today.
3. Position your wireless phone within easy reach. Be able
to access your wireless phone without removing your
eyes from the road. If you get an incoming call at an
inconvenient time, let your voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow, ice and
even heavy traffic can be hazardous.
x497.book Page 168 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 169
Road Safety
Section 13
5. Do not take notes or look up phone numbers while
driving. Jotting down a "to do" list or flipping through
your address book takes attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be stationary.
If you need to make a call while moving, dial only a few
numbers, check the road and your mirrors, then
continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Make people you are talking
with aware you are driving and suspend conversations
that have the potential to divert your attention from the
road.
8. Use your wireless phone to call for help. Dial 9-1-1 or
other local emergeny number in the case of fire, traffic
accident or medical emergencies. Remember, it is a free
call on your wireless phone!
9. Use your wireless phone to help others in emergencies. If
you see an auto accident, crime in progress or other
serious emergency where lives are in danger, call 9-1-1
or other local emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you see
a broken-down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic accident where no
x497.book Page 169 Tuesday, June 14, 2005 5:32 PM
170
Section 13
one appears injured, or a vehicle you know to be stolen,
call roadside assistance or other special non-emergency
number.
"The wireless industry reminds you to use your phone safely
when driving."
For more information, please call 1-888-901-SAFE, or visit
our web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association
Operating Environment
Remember to follow any special regulations in force in
any area
and always switch your phone off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the phone or any accessory to
another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and
for the safety of personnel, it is recommended that the
equipment should only be used in the normal operating
position (held to your ear with the antenna pointing over
your shoulder).
Using Your Phone Near Other Electronic Devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
x497.book Page 170 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 171
Using Your Phone Near Other Electronic Devices
Section 13
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of Wireless
Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm (6 inches)
from their pacemaker when the phone is switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
x497.book Page 171 Tuesday, June 14, 2005 5:32 PM
172
Section 13
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has been
added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted notices
require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots
(fuel storage and distribution areas), chemical plants or
where blasting operations are in progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include below deck
x497.book Page 172 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 173
Emergency Calls
Section 13
on boats, chemical transfer or storage facilities, vehicles
using liquefied petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to turn
off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network
services and/or phone features are in use. Check with
local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
3. Press the key.
If certain features are in use (call barring, for example),
you may
x497.book Page 173 Tuesday, June 14, 2005 5:32 PM
174
Section 13
first need to deactivate those features before you can
make an emergency call. Consult this document and your
local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut off
the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play
with it because they could hurt themselves and others,
damage the phone or make calls that increase your phone
bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane
or butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One
Batterymarch Park, Quincy, MA 02269, Attn: Publication
Sales Division.
x497.book Page 174 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 175
Other Important Safety Information
Section 13
Cautions
Any changes or modifications to your phone not
expressly approved in this document could void your
warranty for this equipment, and void your authority to
operate this equipment. Only use approved batteries,
antennas and chargers. The use of any unauthorized
accessories may be dangerous and void the phone
warranty if said accessories cause damage or a defect to
the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping,
hitting, bending or sitting on it.
Other Important Safety Information
• Only qualified personnel should service the phone or install the
phone in a vehicle. Faulty installation or service may be
dangerous and may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone equipment in your
vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or explosive
materials in the same compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including both
installed or portable wireless equipment in the area over the air
bag or in the air bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious injury
could result.
• Switch your phone off before boarding an aircraft. The use of
wireless phone in aircraft is illegal and may be dangerous to
the aircraft's operation.
x497.book Page 175 Tuesday, June 14, 2005 5:32 PM
176
Section 13
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the offender, or
legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on
the signal strength in your area. Your phone informs you
of the current signal strength by displaying a number of
bars next to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a window may give
you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15 minutes of
searching, a Power Save feature is automatically
activated. If your phone is active, it periodically rechecks
service availability or you can check it yourself by
pressing any key.
Anytime the Power Save feature is activated, a message
displays on the screen. When a signal is found, your
phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and receiver.
When it's turned on, it receives and transmits radio
frequency (RF) signals. When you use your phone, the
system handling your call controls the power level. This
power can range from 0.006 watts to 0.2 watts in digital
mode.
x497.book Page 176 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 177
Availability of Various Features/Ring Tones
Section 13
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-extended and
over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain or liquid
spills. If your phone does get wet, immediately turn the power
off and remove the battery. If it is inoperable, call Customer
Care for service.
Availability of Various Features/Ring Tones
Many services and features are network dependent and
may require additional subscription and/or usage
charges. Not all features are available for purchase or use
in all areas. Downloadable Ring Tones may be available
at an additional cost. Other conditions and restrictions
may apply. See your service provider for additional
information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
x497.book Page 177 Tuesday, June 14, 2005 5:32 PM
178
Section 13
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data, and
other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base station, it uses
less power; talk and standby time are greatly affected by the
signal strength on the cellular network and the parameters set
by the network operator.
• Battery charging time depends on the remaining battery charge
and the type of battery and charger used. The battery can be
charged and discharged hundreds of times, but it will gradually
wear out. When the operation time (talk time and standby time)
is noticeably shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will discharge itself over
time.
• Use only Samsung-approved batteries and recharge your
battery only with Samsung-approved chargers. When a charger
is not in use, disconnect it from the power source. Do not leave
the battery connected to a charger for more than a week, since
overcharging may shorten its life.
• Extreme temperatures will affect the charging capacity of your
battery: it may require cooling or warming first.
• Do not leave the battery in hot or cold places, such as in a car in
summer or winter conditions, as you will reduce the capacity
and lifetime of the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold battery may
temporarily not work, even when the battery is fully charged.
Li-ion batteries are particularly affected by temperatures below
0 °C (32 °F).
x497.book Page 178 Tuesday, June 14, 2005 5:32 PM
Section 13: Health and Safety Information 179
Care and Maintenance
Section 13
• Do not short-circuit the battery. Accidental short- circuiting can
occur when a metallic object (coin, clip or pen) causes a direct
connection between the + and - terminals of the battery (metal
strips on the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the terminals may
damage the battery or the object causing the short-circuiting.
• Dispose of used batteries in accordance with local regulations.
In some areas, the disposal of batteries in household or
business trash may be prohibited. For safe disposal options for
Li-ion batteries, contact your nearest Samsung authorized
service center. Always recycle. Do not dispose of batteries in a
fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years
• Keep the phone and all its parts and accessories out of the
reach of small children's.
• Keep the phone dry. Precipitation, humidity and liquids contain
minerals that will corrode electronic circuits.
• Do not use the phone with a wet hand. Doing so may cause an
electric shock to you or damage to the phone.
• Do not use or store the phone in dusty, dirty areas, as its
moving parts may be damaged.
• Do not store the phone in hot areas. High temperatures can
shorten the life of electronic devices, damage batteries, and
warp or melt certain plastics.
• Do not store the phone in cold areas. When the phone warms
up to its normal operating temperature, moisture can form
inside the phone, which may damage the phone's electronic
circuit boards.
x497.book Page 179 Tuesday, June 14, 2005 5:32 PM
180
Section 13
• Do not drop, knock or shake the phone. Rough handling can
break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or strong
detergents to clean the phone. Wipe it with a soft cloth slightly
dampened in a mild soap-and-water solution.
• Do not paint the phone. Paint can clog the device's moving
parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as a
microwave oven, a stove or a radiator. The phone may explode
when overheated.
• Use only the supplied or an approved replacement antenna.
Unauthorized antennas or modified accessories may damage
the phone and violate regulations governing radio devices.
• If the phone, battery, charger or any accessory is not working
properly, take it to your nearest qualified service facility. The
personnel there will assist you, and if necessary, arrange for
service.
x497.book Page 180 Tuesday, June 14, 2005 5:32 PM
Section 14: Warranty Information 181
Section 14
Section 14: Warranty Information
Topics Covered
• Standard Limited Warranty
x497.book Page 181 Tuesday, June 14, 2005 5:32 PM
182
Section 14
Standard Limited Warranty
What is Covered and For How Long? SAMSUNG
TELECOMMUNICATIONS AMERICA, L.P.
("SAMSUNG") warrants to the original purchaser
("Purchaser") that SAMSUNG's Phones and accessories
("Products") are free from defects in material and
workmanship under normal use and service for the
period commencing upon the date of purchase and
continuing for the following specified period of time after
that date:
Phone 1 Year
Batteries 1 Year
Leather Case/ Pouch 90 Days
Holster 90 Days
Other Phone Accessories 1 Year
What is Not Covered? This Limited Warranty is conditioned
upon proper use of Product by Purchaser. This Limited
Warranty does not cover: (a) defects or damage resulting
from accident, misuse, abuse, neglect, unusual physical,
electrical or electromechanical stress, or modification of
any part of Product, including antenna, or cosmetic
damage; (b) equipment that has the serial number
removed or made illegible; (c) any plastic surfaces or other
externally exposed parts that are scratched or
damaged due to normal use; (d) malfunctions resulting
from the use of Product in conjunction with accessories,
x497.book Page 182 Tuesday, June 14, 2005 5:32 PM
Section 14: Warranty Information 183
Standard Limited Warranty
Section 14
products, or ancillary/peripheral equipment not
furnished or approved by SAMSUNG; (e) defects or
damage from improper testing, operation, maintenance,
installation, or adjustment; (f) installation, maintenance,
and service of Product, or (g) Product used or purchased
outside the United States or Canada. This Limited
Warranty covers batteries only if battery capacity falls
below 80% of rated capacity or the battery leaks, and this
Limited Warranty does not cover any battery if (i) the
battery has been charged by a battery charger not
specified or approved by SAMSUNG for charging the
battery, (ii) any of the seals on the battery are broken or
show evidence of tampering, or (iii) the battery has been
used in equipment other than the SAMSUNG phone for
which it is specified.
What are SAMSUNG's Obligations? During the applicable
warranty period, SAMSUNG will repair or replace, at
SAMSUNG's sole option, without charge to Purchaser,
any defective component part of Product. To obtain
service under this Limited Warranty, Purchaser must
return Product to an authorized phone service facility in
an adequate container for shipping, accompanied by
Purchaser's sales receipt or comparable substitute proof
of sale showing the date of purchase, the serial number of
Product and the sellers' name and address. To obtain
assistance on where to deliver the Product, call Samsung
Customer Care at 1-888-987-4357. Upon receipt,
SAMSUNG will promptly repair or replace the defective
Product. SAMSUNG may, at SAMSUNG's sole option,
use rebuilt, reconditioned, or new parts or components
when repairing any Product or replace Product with a
rebuilt, reconditioned or new Product. Repaired/
x497.book Page 183 Tuesday, June 14, 2005 5:32 PM
184
Section 14
replaced leather cases, pouches and holsters will be
warranted for a period of ninety (90) days. All other
repaired/replaced Product will be warranted for a period
equal to the remainder of the original Limited Warranty
on the original Product or for 90 days, whichever is longer.
All replaced parts, components, boards and equipment
shall become the property of SAMSUNG. If SAMSUNG
determines that any Product is not covered by this
Limited Warranty, Purchaser must pay all parts,
shipping, and labor charges for the repair or return of such
Product.
WHAT ARE THE LIMITS ON SAMSUNG'S WARRANTY/LIABILITY?
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY
CONTAINED HEREIN, PURCHASER TAKES THE
PRODUCT "AS IS," AND SAMSUNG MAKES NO
WARRANTY OR REPRESENTATION AND THERE
ARE NO CONDITIONS, EXPRESS OR IMPLIED,
STATUTORY OR OTHERWISE, OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT,
INCLUDING BUT NOT LIMITED TO:
• "THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS
FOR ANY PARTICULAR PURPOSE OR USE;
• "WARRANTIES OF TITLE OR NON-INFRINGEMENT;
• "DESIGN, CONDITION, QUALITY, OR PERFORMANCE OF THE
PRODUCT;
• "THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS
CONTAINED THEREIN; OR
• "COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF
ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
THERETO.
x497.book Page 184 Tuesday, June 14, 2005 5:32 PM
Section 14: Warranty Information 185
Standard Limited Warranty
Section 14
NOTHING CONTAINED IN THE INSTRUCTION
MANUAL SHALL BE CONSTRUED TO CREATE AN
EXPRESS WARRANTY OF ANY KIND WHATSOEVER
WITH RESPECT TO THE PRODUCT. ALL IMPLIED
WARRANTIES AND CONDITIONS THAT MAY ARISE
BY OPERATION OF LAW, INCLUDING IF
APPLICABLE THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE HEREBY LIMITED TO
THE SAME DURATION OF TIME AS THE EXPRESS
WRITTEN WARRANTY STATED HEREIN. SOME
STATES/PROVINCES DO NOT ALLOW LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
IN ADDITION, SAMSUNG SHALL NOT BE LIABLE
FOR ANY DAMAGES OF ANY KIND
RESULTING FROM THE PURCHASE, USE, OR
MISUSE OF, OR INABILITY TO USE THE PRODUCT
OR ARISING DIRECTLY OR INDIRECTLY FROM THE
USE OR LOSS OF USE OF THE PRODUCT OR FROM
THE BREACH OF THE EXPRESS WARRANTY,
INCLUDING INCIDENTAL, SPECIAL,
CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS, OR FOR
DAMAGES ARISING FROM ANY TORT (INCLUDING
NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT
COMMITTED BY SAMSUNG, ITS AGENTS OR
EMPLOYEES, OR FOR ANY BREACH OF CONTRACT
OR FOR ANY CLAIM BROUGHT AGAINST
PURCHASER BY ANY OTHER PARTY. SOME STATES/
PROVINCES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
x497.book Page 185 Tuesday, June 14, 2005 5:32 PM
186
Section 14
DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH
VARY FROM STATE TO STATE/PROVINCE TO
PROVINCE. THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT AND STATES
PURCHASER'S EXCLUSIVE REMEDY. IF ANY
PORTION OF THIS LIMITED WARRANTY IS HELD
ILLEGAL OR UNENFORCEABLE BY REASON OF ANY
LAW, SUCH PARTIAL ILLEGALITY OR
UNENFORCEABILITY SHALL NOT AFFECT THE
ENFORCEABILITY FOR THE REMAINDER OF THIS
LIMITED WARRANTY WHICH PURCHASER
ACKNOWLEDGES IS AND WILL ALWAYS BE
CONSTRUED TO BE LIMITED BY ITS TERMS OR AS
LIMITED AS THE LAW PERMITS. THE PARTIES
UNDERSTAND THAT THE PURCHASER MAY USE
THIRD-PARTY SOFTWARE OR EQUIPMENT IN
CONJUNCTION WITH THE PRODUCT. SAMSUNG
MAKES NO WARRANTIES OR REPRESENTATIONS
AND THERE ARE NO CONDITIONS, EXPRESS OR
IMPLIED, STATUTORY OR OTHERWISE, AS TO THE
QUALITY, CAPABILITIES, OPERATIONS,
PERFORMANCE OR SUITABILITY OF ANY
THIRDPARTY SOFTWARE OR EQUIPMENT,
WHETHER SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT IS INCLUDED WITH THE PRODUCT
DISTRIBUTED BY SAMSUNG OR OTHERWISE,
INCLUDING THE ABILITY TO INTEGRATE ANY
SUCH SOFTWARE OR EQUIPMENT WITH THE
x497.book Page 186 Tuesday, June 14, 2005 5:32 PM
Section 14: Warranty Information 187
Standard Limited Warranty
Section 14
PRODUCT. THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE AND SUITABILITY
OF ANY SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT LIE SOLELY WITH THE PURCHASER
AND THE DIRECT VENDOR, OWNER OR SUPPLIER
OF SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT, AS THE CASE MAY BE.
This Limited Warranty allocates risk of Product failure
between Purchaser and SAMSUNG, and SAMSUNG's
Product pricing reflects this allocation of risk and the
limitations of liability contained in this Limited Warranty.
The agents, employees, distributors, and dealers of
SAMSUNG are not authorized to make modifications to
this Limited Warranty, or make additional warranties
binding on SAMSUNG. Accordingly, additional
statements such as dealer advertising or presentation,
whether oral or written, do not constitute warranties by
SAMSUNG and should not be relied upon.
Samsung Telecommunications America, L.P.
1301 East Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
©2005 Samsung Telecommunications America. All rights
reserved.
No reproduction in whole or in part allowed without
prior
written approval. Specifications and availability subject
to change without notice.
x497.book Page 187 Tuesday, June 14, 2005 5:32 PM
188
Section 14
Intellectual Property Statement
All Intellectual Property, as defined below, owned by or
which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone,
including but not limited to, accessories, parts, or
software relating thereto (the "Phone System"), is
proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions.
Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade
secrets, copyrights, software, computer programs, and
related documentation and other works of authorship.
You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover, you agree
that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile,
disassemble, or otherwise attempt to create source code
from the software. No title to or ownership in the
Intellectual Property is transferred to you. All applicable
rights of the Intellectual Property shall remain with
SAMSUNG and its suppliers.
x497.book Page 188 Tuesday, June 14, 2005 5:32 PM
Section 14: Warranty Information 189
Samsung Telecommunications America (STA), L.P.
Section 14
Samsung Telecommunications America (STA),
L.P.
Internet Address: http://www.samsungusa.com
©2005 Samsung Telecommunications America. Samsung
is a registered trademark of Samsung Electronics
America, Inc. and its related entities.
Printed in South Korea
GH68-06772A
Openwave® is a registered Trademark of Openwave, Inc.
RSA® is a registered Trademark RSA Security, Inc.
Headquarters Customer Care Center
1301 East Lookout Dr. 1601 E. Plano Parkway,
Suite 150
Richardson, TX 75082
Plano, TX 75074Tel: 972.761.7000
Toll Free Tel:
1.888.987.HELP (4357)
x497.book Page 189 Tuesday, June 14, 2005 5:32 PM
190
Section 14
x497.book Page 190 Tuesday, June 14, 2005 5:32 PM
191
Index
A
Add New Words to T9 Dic-
tionary 61
Address Book 65
Searching for a Number
36
Alphabet mode 58
B
Backlight
description 22
Battery
charging 12
installing 12
low indicator 13
removing 10
C
Call Functions 23
Adjusting the Call Volume
26
Answering a Call 26
Call Log 27
Correcting the Number
24
Making a Call 24
Redialing Last Number
24
Silent Mode 32
Call Waiting 37
Charging battery 12
Create 84
Creating and Sending New
Messages 84
D
Dialing a Number
Address Book
72
SIM Card 72
Display
backlight 22
icons 21
Display Settings
Back Light 104
Brightness Control 104
Menu Style 104
Wallpaper 103
E
Entering Text 57
Changing the Text Entry
Mode 58
Using Alphabet Mode 61
Using Numbers 63
Using Symbols 63
Using T9 Mode 60
External Display 22
F
Functions and Options 32
G
Games
Memory Status 153
My Games 152
Settings 152
x497.book Page 191 Tuesday, June 14, 2005 5:32 PM
192
Shop Games 152
Getting Started 9
Activating Your Phone 10
Voicemail 15
H
Health and Safety Infor-
mation 155
I
Icons, description 21
Instant Messenger 82
International Call 24
L
Low battery indicator 13
M
Making a Call
Address Book 25
Menu Navigation 41
Menu Outline 45
Messaging 81
Multimedia Files
Downloading 119
Multimedia Message
Creating and Sending 89
Multi-Party Call 37
Dropping One Participant
38
Private Conversation 38
Mute 35
N
Network Services 145, 146
Call Forwarding 146
Call Waiting 147
Caller ID 149
Network Selection 148
Number mode 58
O
On/off switch, phone 14
Options
During a Call 34
Putting a Call on Hold 34
Own Number 76
P
Personal Organizer 123
Phone
icons 21
switching on/off 14
Phone Settings 101
R
Recent Calls 27
Call Time 31
Data Call Time 31
Data Volume 31
Delete All 30
Viewing Calls Made 29
Viewing Calls Received
28
Viewing Missed Calls 27
Voice Mail 30
Record Audio 137
S
Setting Alarms 124
Settings 99
Display Settings 103
x497.book Page 192 Tuesday, June 14, 2005 5:32 PM
193
Resetting Your Phone
112
Security Settings 109
Sound Settings 105
Shortcuts 42
SIM card
installing 10
Skin 104
Soft Keys 32
Speed Dial
Edit List 74
Setting Up Entries 73
Standard Limited Warran-
ty
Standard Limited War-
ranty 182
Switching on/off
phone 14
T
T9 mode 58
Text Input Mode
Changing 59
Text Messages 83
Time & Date 100
Travel adapter 12
U
Understanding Your Ad-
dress Book
Editing an Existing Ad-
dress Book Entry 72
Finding an Address book
Entry 71
Understanding Your Phone
17
Features of Your Phone
18
Front View of Your Phone
19
Using Organizer 126
Using the Calculator 136
Using the Timer 142
V
Voice Mail 15
changing number 16
W
WAP 113
Warranty Information 181
x497.book Page 193 Tuesday, June 14, 2005 5:32 PM
194
x497.book Page 194 Tuesday, June 14, 2005 5:32 PM
