Users Manual Part 3

Installing driver over the network

101

2. Using a Network-Connected Machine

Command- line Definition Description

/s or

Starts silent installation. Installs machine drivers

without prompting any UIs

or user intervention.

/p”<port name>” or

/P”<port name>”

Specifies printer port.

Network Port will be

created by use of

Standard TCP/IP

Port monitor. For

local port, this port

must exist on

system before

being specified by

command.

Printer port name can be

specified as IP address,

hostname, USB local port

name or IEEE1284 port

name.

For example:

• /p”xxx.xxx.xxx.xxx” in

where, “xxx.xxx.xxx.xxx”

means IP address for

network printer. /

p”USB001”, /P”LPT1:”, /

p”hostname”

/a”<dest_path>” or

/A”<dest_path>”

Specifies destination path

for installation.

The destination

path should be a

fully qualified path.

Since machine drivers

should be installed on the

OS specific location, this

command applies to only

application software.

/n”<Printer name>”

/N”<Printer name>”

Specifies printer name.

Printer instance shall be

created as specified printer

name.

With this parameter, you

can add printer instances as

you wish.

/nd or

/ND

Commands not to set the

installed driver as a default

machine driver.

It indicates installed

machine driver will not be

the default machine driver

on your system if there are

one or more printer drivers

installed. If there is no

installed machine driver on

your system, then this

option won’t be applied

because Windows OS will

set installed printer driver as

a default machine driver.

/x or

Uses existing machine

driver files to create printer

instance if it is already

installed.

This command provides a

way to install a printer

instance that uses installed

printer driver files without

installing an additional

driver.

Command- line Definition Description

Installing driver over the network

102

2. Using a Network-Connected Machine

Mac

1Make sure that the machine is connected to your computer and

powered on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Select the CD-ROM volume that appears on Finder.

4 Double-click the Install Software icon.

5 Read the license agreement and check installation agreement button.

6 Click Next.

7 Select Network on the printer connection type screen.

8 Click Next.

9 Follow the instructions in the installation window.

Linux

You need to download Linux software packages from the Samsung website to

install the printer software (http://www.samsung.com > find your product >

Support or Downloads).

/up”<printer

name>” or

/UP”<printer

name>”

Removes only specified

printer instance and not the

driver files.

This command provides a

way to remove only

specified printer instance

from your system without

effecting other printer

drivers. It will not remove

printer driver files from your

system.

/d or

Uninstalls all device drivers

and applications from your

system.

This command will remove

all installed device drivers

and application software

from your system.

/v”<share name>” or

/V”<share name>”

Shares installed machine

and add other available

platform drivers for Point &

Print.

It will install all supported

Windows OS platform’s

machine drivers to system

and share it with specified

<share name> for point and

print.

/o or

Opens Printers and Faxes

folder after installation.

This command will open

Printers and Faxes folder

after the silent installation.

/h, /H or /? Shows Command-line Usage.

Command- line Definition Description

Installing driver over the network

103

2. Using a Network-Connected Machine

1Make sure that the machine is connected to your network and powered

on. Also, your machine’s IP address should have been set.

2 Copy Unified Linux Driver package to your system.

3 Open Terminal program and go to the folder that you copied the

package to.

4 Extract the package.

5 Move to uld folder.

6 Execute ” ./install.sh“ command (If you are not logged in as root,

execute the command with “sudo” as “sudo ./install.sh”).

7 Proceed with installation.

8 When installation finished, launch Printing utility (Go to System >

Administration > Printing or execute “system-config-printer“

command in Terminal program).

9 Click Add button.

10 Select AppSocket/HP JetDirect and enter your machine’s IP address.

11 Click Forward button and add it to your system.

104

2. Using a Network-Connected Machine

IPv6 configuration

IPv6 is supported properly only in Windows Vista or higher.

If the IPv6 network seems to not be working, set all the network setting to

the factory defaults and try again using Clear Setting.

The machine supports the following IPv6 addresses for network printing and

managements.

•Link-local Address: Self-configured local IPv6 address (Address starts with

FE80).

•Stateless Address: Automatically configured IPv6 address by a network

router.

•Stateful Address: IPv6 address configured by a DHCPv6 server.

•Manual Address: Manually configured IPv6 address by a user.

In the IPv6 network environment, follow the next procedure to use the IPv6

address.

From the control panel

Activating IPv6

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > IPv6 Activate.

3 Select On and press OK.

4 Turn the machine off and turn it on again.

When you install the printer driver, do not configure both IPv4 and

IPv6. We recommend to configure either IPv4 or IPv6 (see "Installing

driver over the network" on page 99).

DHCPv6 address configuration

If you have a DHCPv6 server on your network, you can set one of the following

options for default dynamic host configuration.

1Press the (Menu) button on the control panel.

2 Press Network > TCP/IP (IPv6) > DHCPv6 Config.

IPv6 configuration

105

2. Using a Network-Connected Machine

3 Press OK to select the required value you want.

•DHCPv6 Addr.: Always use DHCPv6 regardless of router request.

•DHCPv6 Off: Never use DHCPv6 regardless of router request.

•Router: Use DHCPv6 only when requested by a router.

From the SyncThru™ Web Service

Activating IPv6

1Access a web browser, such as Internet Explorer, from Windows. Enter

the machine IP address (http://xxx.xxx.xxx.xxx) in the address field and

press the Enter key or click Go.

2 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

3 When the SyncThru™ Web Service window opens, move the mouse

cursor over the Settings of the top menu bar and then click Network

Settings.

4 Click TCP/IPv6 on the left pane of the website.

5 Check the IPv6 Protocol check box to activate IPv6.

6 Click the Apply button.

7 Turn the machine off and turn it on again.

• You can also set the DHCPv6.

• To manually set the IPv6 address:

Check the Manual Address check box. Then, the Address/Prefix text

box is activated. Enter the rest of the address

(e.g.,:3FFE:10:88:194::AAAA. “A” is the hexadecimal 0 through 9, A

through F).

IPv6 address configuration

1Start a web browser, such as Internet Explorer, that supports IPv6

addressing as a URL.

2 Select one of the IPv6 addresses (Link-local Address, Stateless

Address, Stateful Address, Manual Address) from Network

Configuration Report (see "Printing a network configuration report" on

page 96).

•Link-local Address: Self-configured local IPv6 address (Address

starts with FE80).

•Stateless Address: Automatically configured IPv6 address by a

network router.

IPv6 configuration

106

2. Using a Network-Connected Machine

•Stateful Address: IPv6 address configured by a DHCPv6 server.

•Manual Address: Manually configured IPv6 address by a user.

3 Enter the IPv6 addresses (e.g.,: http://[FE80::215:99FF:FE66:7701]).

Address must be enclosed in '[ ]' brackets.

107

2. Using a Network-Connected Machine

Wireless network setup

• Wireless networking may not be available depending on the model (see

"Features by model" on page 6).

Wireless networks require higher security, so when an access point is first set up,

a network name (SSID), the type of security used, and a Network Password are

created for the network. Ask your network administrator about this information

before proceeding with the machine installation.

Introducing wireless set up methods

You can set wireless settings either from the machine or the computer. Choose

the setting method from the below table.

• Some wireless network installation types may not be available

depending on the model or country.

• It is strongly recommended that you set the password on Access Points.

If you do not set the password on Access Points, they might be exposed

to illegal access from unknown machines including PCs, smart phones

and printers. Refer to the Access Point user' guide for password settings.

Set up

method

Connecting

method Description & Reference

With Access

Point

From the

computer

See "Setting up via USB cable" on page 110

for Window.

See "Access point without a USB cable" on

page 112 for Window.

See "Setting up via USB cable" on page 114

for Mac.

See "Access point without a USB cable" on

page 115 for Mac.

See "Using a network cable" on page 116.

From the

machine’s control

panel

See "Using the WPS Settings menu" on

page 108.

See "Using the Wi-Fi Networks" on page

109.

Wi-Fi Direct setup See "Setting the Wi-Fi Direct for mobile

printing" on page 118.

Wireless network setup

108

2. Using a Network-Connected Machine

Using the WPS Settings menu

If your machine and access point (or wireless router) support Wi-Fi Protected

Setup™ (WPS), then you can easily configure the wireless network settings

through the WPS button menu without the need for a computer.

• If you want to use the wireless network using the infrastructure mode,

make sure that the network cable is disconnected from the machine.

Using the WPS (PBC) button or entering the PIN from the computer to

connect to the access point (or wireless router) varies depending on the

access point (or wireless router) you are using. Refer to the user's guide

of the access point (or wireless router) you are using.

• When using the WPS button to set the wireless network, security settings

may change. To prevent this, lock the WPS option for the current wireless

security settings. The option name may differ depending on the access

point (or wireless router) you are using.

Items to prepare

• Check if the access point (or wireless router) supports Wi-Fi Protected

Setup™ (WPS).

• Check if your machine supports Wi-Fi Protected Setup™ (WPS).

• Networked computer (PIN mode only)

Choosing your type

There are two methods available to connect your machine to a wireless network.

• The Push Button Configuration (PBC) method allows you to connect your

machine to a wireless network by pressing both the WPS button menu on

the control panel of your machine and the WPS (PBC) button on a Wi-Fi

Protected Setup™ WPS-enabled access point (or wireless router)

respectively.

• The Personal Identification Number (PIN) method helps you connect your

machine to a wireless network by entering the supplied PIN information on

a Wi-Fi Protected Setup™ WPS-enabled access point (or wireless router).

Wireless network setup

109

2. Using a Network-Connected Machine

Connecting WPS

Factory default in your machine is PBC mode, which is recommended for a

typical wireless network environment.

Connecting in PBC mode

1Press the (Menu) button on the control panel and select Network >

Wireless > WPS Settings > Connect via PBC.

2 Press the WPS (PBC) button on the access point (or wireless router).

3 Follow the instruction on the display screen.

The messages are displayed on the display screen

Connecting in PIN mode

1Press Network > Wireless > WPS Settings > Connect via PIN.

2 The eight-digit PIN appears on the display.

You need to enter the eight-digit PIN within two minutes on the

computer that is connected to the access point (or wireless router).

3 Follow the instruction on the display screen.

The messages are displayed on the display screen

Using the Wi-Fi Networks

Before starting, you will need to know the network name (SSID) of your wireless

network and the network key if it is encrypted. This information was set when

the access point (or wireless router) was installed. If you do not know about your

wireless environment, please ask the person who set up your network.

1Press the (Menu) button on the control panel and select Network

>Wi-Fi ON/OFF then ON from the display screen.

2 The machine will display a list of available networks from which to

choose. After a network is chosen then printer will prompt for the

corresponding security key.

3 Select the Wi-Fi network option you want.

Setup using Windows

Shortcut to the Samsung Easy Wireless Setup program without the CD: If

you have installed the printer driver once, you can access the Samsung

Easy Wireless Setup program without the CD.

Wireless network setup

110

2. Using a Network-Connected Machine

Setting up via USB cable

Items to prepare

• Access point

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

Creating the infrastructure network

1Check wheter the USB cable is connected to the machine.

2 Turn on your computer, access point, and machine.

3 Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs >

Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD-

ROM drive and click OK.

• For Windows 8,

If the installation window does not appear, from Charms, select

Search > Apps and search for Run. Type in X:\Setup.exe, replacing

“X” with the letter that represents your CD-ROM drive and click OK.

If “Tap to choose what happens with this disc.” pop-up window

appears, click the window and select Run Setup.exe.

4 Review and accept the installation agreements in the installation

window. Then, click Next.

5 Select Wireless on the Printer Connection Type screen. Then, click

Next.

Wireless network setup

111

2. Using a Network-Connected Machine

6 On the Are you setting up your printer for the first time? screen, select

Yes, I will set up my printer's wireless network. Then, click Next.

If your printer is already connected on the network, select No, my

printer is already connected to my network.

7 Select Using a USB cable on the Select the Wireless Setup Method

screen. Then, click Next.

8 After searching, the window shows the wireless network devices. Select

the name (SSID) of the access point you want to use and click Next.

If you cannot find the network name you want to choose, or if you want to

set the wireless configuration manually, click Advanced Setting.

•Enter the wireless Network Name: Enter the SSID of the access point

(SSID is case-sensitive).

•Operation Mode: Select Infrastructure.

•Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may

not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key

can access the network.

WPA Personal or WPA2 Personal: Select this option to authenticate the

print server based on a WPA Pre-Shared Key. This uses a shared secret key

(generally called Pre Shared Key pass phrase), which is manually

configured on the access point and each of its clients.

•Encryption: Select the encryption (None, WEP64, WEP128, TKIP, AES,

TKIP AES).

•Network Password: Enter the encryption network password value.

•Confirm Network Password: Confirm the encryption network

password value.

•WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

The wireless network security window appears when the access point has

security settings.

Enter the Network Password of the access point (or router).

Wireless network setup

112

2. Using a Network-Connected Machine

9 If your printer supports Wi-Fi Direct, the following screen appears.

Click Next.

• Wi-Fi Direct option appears on the screen only if your printer supports

this feature.

• Can start to build Wi-Fi Direct by using Samsung Easy Printer Manager

(see "Setting up Wi-Fi Direct" on page 118).

•Wi-Fi Direct Name: The default Wi-Fi Direct Name is the model name

and the maximum length is 22 characters.

•Password setting is the numeric string, and the size is 8 ~ 64 characters.

10 When the wireless network set up is completed, disconnect the USB

cable between the computer and machine. Click Next.

11 Select the components to be installed.

12 Follow the instructions in the installation window.

Access point without a USB cable

Items to prepare

• WiFi-enabled PC running Windows 7 or higher and an access point (router)

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

While setting the wireless network, the machine uses PC's wireless LAN. You

might not be able to connect to the Internet.

Wireless network setup

113

2. Using a Network-Connected Machine

Creating the infrastructure network

1Turn on your computer, access point, and machine.

2 Insert the supplied software CD into your CD-ROM drive.

If the installation window does not appear, click Start > All programs >

Accessories > Run.

X:\Setup.exe replacing “X” with the letter, which represents your CD-

ROM drive and click OK.

• For Windows 8,

If the installation window does not appear, from Charms, select

Search > Apps and search for Run. Type in X:\Setup.exe, replacing

“X” with the letter that represents your CD-ROM drive and click OK.

If “Tap to choose what happens with this disc.” pop-up window

appears, click the window and select Run Setup.exe.

3 Review and accept the installation agreements in the installation

window. Then, click Next.

4 Select Wireless on the Printer Connection Type screen. Then, click

Next.

5 On the Are you setting up your printer for the first time? screen, select

Yes, I will set up my printer's wireless network. Then, click Next.

If your printer is already connected on the network, select No, my

printer is already connected tomy network.

6 Select Using a direct wireless connection on the Select the Wireless

Setup Method screen. Then, click Next.

• Even if your computer is running Windows 7 or higher, you cannot use

this feature if your PC does not support wireless network. Set the wireless

network using a USB cable (see "Setting up via USB cable" on page 110).

• If below screen appears, press the (WPS) button from the control

panel within 2 minutes.

Wireless network setup

114

2. Using a Network-Connected Machine

7 When the wireless network set up is completed, click Next.

8 Follow the instructions in the installation window.

Setup using Mac

Items to prepare

• Access point

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• USB cable

Setting up via USB cable

1Make sure that the machine is connected to your computer and

powered on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Select the CD-ROM volume that appears on Finder.

4 Double-click Install Software icon.

5 Read the license agreement and check installation agreement button.

6 Click Next

7 Select Wireless on the Printer Connection Type

8 Click Next

9 If the installer asks you to allow access to the keychain, click Deny.

If you clicked Always Allow in this step, the Select a wireless printer

window appears without asking for access to the keychain. If this occurs,

click Cancel in the Select a wireless printer window.

10 On the Select the Wireless Setup Method screen, select Using a USB

cable, and then click Next.

If the screen dose not appear, go to step 14.

11 After searching, the window shows the wireless network devices. Select

the name (SSID) of the access point you want to use and click Next.

When you set the wireless configuration manually, click Advanced Setting.

•Enter the wireless Network Name: Enter the SSID of the access point

(SSID is case-sensitive).

•Operation Mode: Select Infrastructure.

Wireless network setup

115

2. Using a Network-Connected Machine

•Authentication: Select an authentication type.

Open System: Authentication is not used, and encryption may or may

not be used, depending on the need for data security.

Shared Key: Authentication is used. A device that has a proper WEP key

can access the network.

WPA Personal or WPA2 Personal: Select this option to authenticate the

print server based on the WPA Pre-Shared Key. This uses a shared secret

key (generally called Pre Shared Key pass phrase) that is manually

configured on the access point and each of its clients.

•Encryption: Select the encryption. (None, WEP64, WEP128, TKIP, AES)

•Network Key: Enter the encryption network key value.

•Confirm Network Key: Confirm the encryption network key value.

•WEP Key Index: If you are using WEP Encryption, select the appropriate

WEP Key Index.

The wireless network security window appears when the access point has

security enabled.

Enter the Network Key of the access point (or router).

12 The window showing the wireless network setting appears. Check the

settings and click Next.

• Can start to build Wi-Fi Direct by using Samsung Easy Printer Manager

(see "Setting up Wi-Fi Direct" on page 118).

•Wi-Fi Direct Name: The default Wi-Fi Direct Name is the model name

and the maximum length is 22 characters.

•Password setting is the numeric string, and the size is 8 ~ 64 characters.

13 The Wireless Network Setting Complete window appears. Click Next.

14 When the wireless network settings are completed, disconnect the USB

cable between the computer and machine. Click Next.

15 Follow the instructions in the installation window.

Access point without a USB cable

Items to prepare

• WiFi-enabled Mac running Mac OS 10.7 or higher and an access point

(router)

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

1Make sure that the machine is connected to your computer and

powered on.

2 Insert the supplied software CD into your CD-ROM drive.

3 Select the CD-ROM volume that appears on Finder.

4 Double-click Install Software icon.

5 Read the license agreement and check installation agreement button.

6 Click Next.

Wireless network setup

116

2. Using a Network-Connected Machine

7 Select Wireless on the Printer Connection Type screen.

8 Click Next.

9 If the installer asks you to allow access to the keychain, click Allow.

10 If the Select a wireless printer window appears, select the printer

named DIRECT-xxx.

If the Press WPS button on your printer screen appears, press the

(WPS) button from the control panel within 2 minutes.

11 When the wireless network set up is complete, follow the instructions in

the installation window.

Using a network cable

See your network administrator, or the person that set up your wireless

network, for information about your network configuration.

Your machine is a network compatible machine. To enable your machine to

work with your network, you will need to perform some configuration

procedures.

Items to prepare

• Access point

• Network-connected computer

• Software CD that was provided with your machine

• A machine installed with a wireless network interface

• Network cable

Printing a network configuration report

You can identify the network settings of your machine by printing a network

configuration report.

See "Printing a network configuration report" on page 96.

IP setting using SetIP Program (Windows)

This program is used to manually set the network IP address of your machine

using its MAC address to communicate with the machine. The MAC address is

the hardware serial number of the network interface and can be found in the

Network Configuration Report.

See "Printing a network configuration report" on page 96.

Wireless network setup

117

2. Using a Network-Connected Machine

Configuring the machine’s wireless network

Before starting you will need to know the network name (SSID) of your wireless

network and the network key if it is encrypted. This information was set when

the access point (or wireless router) was installed. If you do not know about your

wireless environment, please ask the person who set up your network.

To configure wireless parameters, you can use SyncThru™ Web Service.

Using SyncThru™ Web Service

Before starting wireless parameter configuration, check the cable connection

status.

1Check whether or not the network cable is connected to the machine. If

not, connect the machine with a standard network cable.

2 Start a web browser such as Internet Explorer, Safari, or Firefox and enter

your machine’s new IP address in the browser window.

For example,

3 Click Login on the upper right of the SyncThru™ Web Service website.

4 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec0000

5 When the SyncThru™ Web Service window opens, click Network

Settings.

6 Click Wi-Fi > Wizard.

7 Select the one Network Name(SSID) in the list.

8 Click Next.

If the wireless security setting window appears, enter the registered

password (network password) and click Next.

9 The confirmation window appears, please check your wireless setup. If

the setup is right, click Apply.

Wireless network setup

118

2. Using a Network-Connected Machine

Turning the Wi-Fi network on/off

1Check whether the network cable is connected to the machine. If not,

connect the machine with a standard network cable.

2 Start a web browser such as Internet Explorer, Safari, or Firefox and enter

your machine’s new IP address in the browser window.

For example,

3 Click Login on the upper right of the SyncThru™ Web Service website.

4 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

5 When the SyncThru™ Web Service window opens, click Network

Settings.

6 Click Wi-Fi.

7 You can turn the Wi-Fi network on/off.

Setting the Wi-Fi Direct for mobile printing

Wi-Fi Direct is a secure and easy-to-use peer-to-peer connection between a Wi-

Fi Direct-enabled printer and mobile device.

With Wi-Fi Direct, you can connect your printer to a Wi-Fi Direct network while

concurrently connecting to an access point. You can also use a wired network

and a Wi-Fi Direct network simultaneously so multiple users can access and print

documents both from Wi-Fi Direct and from a wired network.

• You cannot connect your mobile device to the internet through the

printer’s Wi-Fi Direct.

• The supported protocol list may differ from your model, Wi-Fi Direct

networks do NOT support IPv6, network filtering, IPSec, WINS, and SLP

services.

• The maximum number of devices that can be connected via Wi-Fi Direct

is 4.

Setting up Wi-Fi Direct

You can enable Wi-Fi Direct feature by one of the following methods.

Wireless network setup

119

2. Using a Network-Connected Machine

From the machine

1Press the (Menu) button on the control panel and select Network >

Wireless >Wi-Fi Direct from the display screen.

2 Tap Wi-Fi Direct.

3 Enable Wi-Fi Direct.

From the network-connected computer

If your printer is using a network cable or a wireless access point, you can enable

and configure Wi-Fi Direct from SyncThru™ Web Service.

1Access SyncThru™ Web Service and select Settings > Network

Settings > Wi-Fi > Wi-Fi Direct™.

2 Enable Wi-Fi Direct™ and set other options.

Setting up the mobile device

• After setting up Wi-Fi Direct from the printer, refer to the user manual of the

mobile device you are using to set its Wi-Fi Direct.

• After setting up Wi-Fi Direct, you need to download the mobile printing

application (For example: Samsung Mobile printer) to print from your

smartphone.

• When you have found the printer you want to connect to from your

mobile device, select the printer and the printer's LED will blink. Press the

WPS button on the printer and it will be connected to your mobile

device.

• If your mobile device does not support Wi-Fi Direct, you need to enter

the "Network Key" of a printer instead of pushing the WPS button.

Troubleshooting

Problems during setup or driver installation

Printers Not Found

• Your machine may not be turned on. Turn on your computer and the

machine.

• USB cable is not connected between your computer and machine. Connect

the machine to your computer using the USB cable.

• The machine does not support wireless networking. Check the machine's

user's guide included on the software CD supplied with your machine and

prepare a wireless network machine.

Wireless network setup

120

2. Using a Network-Connected Machine

Connecting Failure - SSID Not Found

• The machine is unable to find the network name (SSID) you have selected or

entered. Check the network name (SSID) on your access point and try

connecting again.

• Your access point is not turned on. Turn on your access point.

Wireless network setup

121

2. Using a Network-Connected Machine

Connecting Failure - Invalid Security

• Security is not configured correctly. Check the configured security on your

access point and machine.

Connecting Failure - General Connection Error

• Your computer is not receiving a signal from your machine. Check the USB

cable and your machine’s power.

Connecting Failure - Connected Wired Network

• Your machine is connected with a wired network cable. Remove the wired

network cable from your machine.

Connecting Failure - Assigning the IP address

• Cycle the power for the access point (or wireless router) and machine.

PC Connection Error

• The configured network address is unable to connect between your

computer and machine.

- For a DHCP network environment

The receives the IP address automatically (DHCP) when computer is

configured to DHCP.

If the printing job is not working in DHCP mode, the problem may be caused

by the automatically changed IP address. Compare the IP address between

the product's IP address and the printer port's IP address.

How to compare:

1 Print the network information report of your printer, and then check the

IP address (see "Printing a network configuration report" on page 96).

2 Check the printer port's IP address from your computer.

a Click the Windows Start menu.

• For Windows 8, from the Charms, select Search > Settings.

b For Windows XP Service Pack 3/Server 2003, select Printer and Faxes.

• For Windows Server 2008/Vista, select Control Panel > Hardware

and Sound > Printers.

• For Windows Server 2008 R2, select Control Panel > Hardware >

Devices and Printers.

• For Windows 7/ Windows 8, select Control Panel > Devices and

Printers.

c Right-click your machine.

d For Windows XP Service Pack 3/2003/2008/Vista, press Properties.

For Windows 7/ Windows 8 or Windows Server 2008 R2, from context

menus, select the Printer properties.

If Printer properties item has ► mark, you can select other printer

drivers connected with selected printer.

e Click Port tab.

f Click Configure Port.. button.

g Check if Printer Name or IP Address: is the IP address on the network

configuration Sheet.

3 Change the printer port's IP address if it is different from the network

information report's.

If you want to use the software installation CD to change the port IP,

connect to a network printer. Then reconnect the IP address.

Wireless network setup

122

2. Using a Network-Connected Machine

- For a Static network environment

The machine uses the static address when the computer is configured

to static address.

For example,

If the computer’s network information is as shown below:

▪IP address: 169.254.133.42

▪Subnet Mask: 255.255.0.0

Then the machine’s network information should be as below:

▪IP address: 169.254.133.43

▪Subnet Mask: 255.255.0.0 (Use the computer’s subnet mask.)

▪Gateway: 169.254.133.1

Other problems

If problems occur while using the machine on a network, check the following:

For information on the access point (or wireless router), refer to its own

user's guide.

• You cannot enable wired and wireless networks at the same time.

• Your computer, access point (or wireless router), or machine may not be

turned on.

• Check the wireless reception around the machine. If the router is far from

the machine or there is an obstacle, you might have difficulty receiving the

signal.

• Cycle the power for the access point (or wireless router), machine, and

computer. Sometimes cycling the power can recover network

communication.

• Check whether firewall software (V3 or Norton) is blocking the

communication.

If the computer and the machine are connected on the same network and it

cannot be found when searching, firewall software might be blocking the

communication. Refer to the user's guide for the software to turn it off and

try searching for the machine again.

• Check whether the machine's IP address is allocated correctly. You can

check the IP address by printing the network configuration report.

• Check whether the access point (or wireless router) has a configured

security (password). If it has a password, refer to the access point (or wireless

router) administrator.

• Check the machine's IP address. Reinstall the machine driver and change the

settings to connect to the machine on the network. Due to the

characteristics of DHCP, the allocated IP address could change if the

machine is not used for a long time or if the access point has been reset.

on the access point (or wireless router). Then you can always use the IP

address that is set with the MAC address. You can identify the Mac address

of your machine by printing a network configuration report (see "Printing a

network configuration report" on page 96).

Wireless network setup

123

2. Using a Network-Connected Machine

• Check the wireless environment. You might not be able to connect to the

network in the infrastructure environment where you need to type in a

user's information before connecting to the access point (or wireless router).

• This machine only supports IEEE 802.11 b/g/n and Wi-Fi. Other wireless

communication types (e.g., Bluetooth) are not supported.

• You cannot use infrastructure mode at the same time for Samsung wireless

network machines.

• The machine is within the range of the wireless network.

• The machine is located away from obstacles that could block the wireless

signal.

Remove any large metal objects between the access point (or wireless

router) and the machine.

Make sure the machine and wireless access point (or wireless router) are not

separated by poles, walls, or support columns containing metal or concrete.

• The machine is located away from other electronic devices that may

interfere with the wireless signal.

Many devices can interfere with the wireless signal, including a microwave

oven and some Bluetooth devices.

• Whenever the configuration of your access point (or wireless router)

changes, you must do the product's wireless network setup again.

• The maximum number of device that can be connected via Wi-Fi Direct is 3.

•If Wi-Fi Direct is ON, this machine only supports IEEE 802.11 b/g.

• If the access point is set to work with the 802.11n standard only, it may not

connect to your machine.

124

2. Using a Network-Connected Machine

Samsung Mobile Print

What is Samsung Mobile Print?

Samsung Mobile Print is a free application that enables users to print photos,

documents, and web pages directly from your smartphone or tablet. Samsung

Mobile Print is not only compatible with your Android and iOS smart phones

but also with your iPod Touch and tablet PC. It connects your mobile device to a

network connected Samsung printer or to a wireless printer through a Wi-Fi

access point. Installing a new driver or configuring network settings isn’t

necessary – just simply install the Samsung Mobile Print application, and it will

automatically detect compatible Samsung printers. Besides printing photos,

web pages, and PDFs, scanning is also supported. If you have a Samsung

multifunction printer, scan any document into a JPG, PDF, or PNG format for

quick and easy viewing on your mobile device.

Downloading Samsung Mobile Print

To download Samsung Mobile Print, go to the application store (Samsung

Apps, Play Store, App Store) on your mobile device, and just search for

“Samsung Mobile Print.” You can also visit iTunes for Apple devices on your

computer.

Supported Mobile OS

• Android OS 2.3 or higher

• iOS 4.0 or higher

125

2. Using a Network-Connected Machine

Using the NFC feature

The NFC(Near Field Communication) printer allows you to directly print from

your cell phone just by holding your cell phone over the NFC tag on your printer.

It does not require installing print driver or connecting to an access point. You

just need NFC supported cell phone. In order to use this feature, Samsung

Mobile Print app needs to be installed on your cell phone.

• Depending on the material of the cell phone cover, NFC recognition may

not work properly.

• Depending on the cell phone you are using, the tranmission speed may

differ.

Requirements

• NFC and Wi-Fi Direct enabled, Mobile Print app installed cell phone with

Android OS 4.0 or higher.

Only Android OS 4.1 or higher will automatically enable the Wi-Fi Direct

feature on your cell phone when you enable the NFC feature. We

recommend you to upgrade your cell phone to Android OS 4.1 or higher to

use the NFC feature.

• Wi-Fi Direct feature enabled printer. Wi-Fi Direct feature is enabled by

default.

Printing

1Check that NFC and Wi-Fi Direct feature are enabled on your cell phone

and Wi-Fi Direct feature is enabled on your printer (see "Setting up Wi-Fi

Direct" on page 118).

2 Tag the NFC antenna on your cell phone (usually located on the back of

the cell phone) over the NFC tag( ) on your printer.

Wait few seconds for the Samsung Mobile Print app to start.

• For some cell phones, NFC antenna might not be located at the back of

the cell phone. Check the location of the NFC antenna on your cell phone

before tagging.

• If error message about changed PIN number appears, enter a changed

PIN number and press OK. Follow the instruction on the app screen to

update the PIN number.

• If you do not have Samsung Mobile Print app installed on your cell

phone, it automatically connects to Samsung Mobile Print app

download page. Download the app and try again.

Using the NFC feature

126

2. Using a Network-Connected Machine

3 Select the content you want to print.

If neccessary, change the print option by pressing the .

4 Tag the NFC antenna on your cell phone(usually located on the back of

the cell phone) over the NFC tag( ) on your printer.

Wait few seconds for the cell phone to connect to the printer.

• For some cell phones, NFC antenna might not be located at the back of

the cell phone. Check the location of the NFC antenna on your cell phone

before tagging.

• If error message about changed PIN number appears, enter a changed

PIN number and press OK. Follow the instruction on the app screen to

update the PIN number.

5 The printer starts printing.

Registering Google Cloud Printer

1Check that NFC and Wi-Fi Direct features are enabled on your mobile

device and Wi-Fi Direct feature is enabled on your printer.

2 Tag the NFC tag on your mobile device (usually located on the back of

the mobile device) over the NFC tag( ) on your printer.

Wait a few seconds for the Samsung Mobile Print app to start.

• For some mobile devices, NFC tag might not be located at the back of the

mobile device. Check the location of the NFC antenna on your mobile

device before tagging.

• If error message about changed PIN number appears, enter a changed

PIN number and press OK. Follow the instruction on the app screen to

update the PIN number.

• If your do not have Samsung Mobile Print app installed on your mobile

devices, it automatically connects to Samsung Mobile Print app

download page. Download the app and try again.

Using the NFC feature

127

2. Using a Network-Connected Machine

3 Select device status icon.

4 Select Google Cloud Print > Register Google Cloud Printer.

5 Tag the NFC tag on your mobile device (usually located on the back of

the mobile device) over the NFC tag( ) on your printer.

Wait a few seconds for the mobile device to connect to the printer.

• For some mobile devices, NFC tag might not be located at the back of the

mobile device. Check the location of the NFC antenna on your mobile

device before tagging.

• If error message about changed PIN number appears, enter a changed

PIN number and press OK. Follow the instruction on the app screen to

update the PIN number.

6 Confirm your printer in pop-up window.

Now your printer is registered with Google Cloud Print™ service

128

2. Using a Network-Connected Machine

Mopria™

Only Mopria-certified machines can use the Mopria feature. Check the box

that your machine came in for the Mopria-certified logo.

Setting up the machine for Mopria printing

Bonjour(mDNS) and IPP protocols are required on your machine to use the

Mopria feature. Perform the following steps to enable the Mopria feature.

1Ensure that the machine is connected to the network.

2 On your computer, open a web browser (Internet Explorer, Safari, or

Firefox) and type the IP address of the machine in the address bar. Then,

press Enter.

For example,

3 Click Login in the upper right corner of the SyncThru™ Web Service

website.

4 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and Password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

5 When the SyncThru™ Web Service window opens, click Settings >

Network Settings > Standard TCP/IP, LPR, IPP > IPP. Then, select

Enable.

6 Click Settings > Network Settings > mDNS. Then, select Enable.

7 Click Security > System Security > Feature Management > Mopria.

Then, select Enable.

Setting up Mopria on your mobile device

If you do not have Mopria Print Service app installed on your mobile device,

open to the app store (Play Store, App Store) on your mobile device, search

for,Mopria Print Service, and then download and install the app.

Mopria™ Print Service is a mobile printing solution that enhances

the new print functionality on any Android phone or tablet

(Android version 4.4 or later). With this service, you can connect

and print to any Mopria-certified printer on the same network as

your mobile device without additional set-up. Many native

Android apps support printing, including Chrome, Gmail, Gallery,

Drive and Quickoffice.

Mopria™

129

2. Using a Network-Connected Machine

1In the Settings menu of your Android device, tap Printing.

The location of this option may differ depending on your mobile device. If

you cannot locate the Printing option, refer to the user's manual for your

mobile device.

2 Under Print Services, tap Mopria Print Service.

3 Tap the On/Off slider to enable the Mopria Print Service.

Printing via Mopria

To print via Mopria on an Android device:

1Open the email, photo, web page, or document that you want to print.

2 Tap Print on the menu in the app.

3 Select your printer, and then configure the print options.

4 Touch Print again to print the document.

To cancel a print job: Select and delete the document from the print queue

in the Notification Bar.

130

2. Using a Network-Connected Machine

AirPrint

Only AirPrint certified machines can use the AirPrint feature. Check the box

your machine came in for the AirPrint certified mark.

Setting up AirPrint

Bonjour(mDNS) and IPP protocols are required on your machine to use the

AirPrint feature. You can enable the AirPrint feature by one of the following

methods.

1Check whether the machine is connected to the network.

2 Start a web browser such as Internet Explorer, Safari, or Firefox and enter

your machine’s new IP address in the browser window.

For example,

3 Click Login in the upper right of the SyncThru™ Web Service website.

4 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and Password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

5 When the Embedded Web Service window opens, click Settings >

Network Settings.

6 Click Raw TCP/IP, LPR, IPP or mDNS.

You can enable the IPP protocol or mDNS protocol.

Printing via AirPrint

For example, the iPad manual provides these instructions:

1Open your email, photo, web page, or document you want to print.

2 Touch the action icon( ).

3 Select your printer driver name and option menu to set up.

4 Touch Print button. Print it out.

AirPrint allows you to wirelessly print directly from iPhone, iPad and

iPod touch running the latest version of iOS.

AirPrint

131

2. Using a Network-Connected Machine

Cancelling print job: To cancel the printing job or view the print summary,

click the print center icon ( ) in multitasking area. You can click cancel in

the print center.

132

2. Using a Network-Connected Machine

Samsung Cloud Print

Samsung Cloud Print is a free cloud service that allows you to print or scan from

your smartphone or tablet to your Samsung printer or MFP. After installing the

Samsung Cloud Print app, you can register with the Samsung Cloud Print service

just using your mobile number for authentication. No other account login is

required, although you can link the app to your Samsung Account if you wish.

If you press the ( ) button from Samsung Cloud Print app, Your mobile

device and printer or MFP can be paired , QR code, or by manually entering

its MAC address. Once paired, you can print or scan from anywhere and

everywhere.

Registering your Printer to Samsung Cloud server

Registering from Web Browser

Make sure the printer machine is turned on and connected to a wired or

wireless network that has access to the Internet.

1Open Web browser.

2 Enter your printer’s IP address in the address field and press the Enter key

or click Go.

3 Click Login in the upper right corner of the SyncThru™ Web Service

website.

4 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and Password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

If you want to create a new user or change the password, see "Security tab"

on page 160.

5 When the SyncThru™ Web Service window opens, click Settings >

Network Settings > Samsung Cloud Print.

6 Enable Samsung Cloud Print Protocol.

7 Now your printer is registered with Samsung Cloud Print service.

Samsung Cloud Print

133

2. Using a Network-Connected Machine

Printing with Samsung Cloud Print

Make sure the printer is turned on and connected to a wired or wireless

network that has access to the Internet.

Registering a printer from an application on mobile

device

The following steps are an example of using the Samsung Cloud Print app from

Android mobile phone.

1Open Samsung Cloud Print app.

If you do not have Samsung Cloud Print app installed on your cellphone,

go to the application store (Samsung Apps, Play Store, App Store) on your

mobile device, and just search for download the app and try again.

2 Press the ( ) button from Samsung Cloud Print app.

3 Your mobile device and printer or MFP can be paired NFC tapping, QR

code or by manually entering its MAC address.

Printing from an application on mobile device

The following steps are an example of using the Samsung Cloud Print app from

Android mobile phone.

1Open Samsung Cloud Print app.

If you do not have Samsung Cloud Print app installed on your cellphone,

go to the application store (Samsung Apps, Play Store, App Store) on your

mobile device, and just search for download the app and try again.

2 Tap the option check button of the document that you want to print.

3 Set the printing options if you want.

4 Tap Send Job.

134

2. Using a Network-Connected Machine

Google Cloud Print™

Google Cloud Print™ is a service that allows you to print to a printer using your

smart phone, tablet, or any other web-connected devices. Just register your

Google account with the printer, and you are ready to use the Google Cloud

Print service. You can print your document or email with Chrome OS, Chrome

browser, or a Gmail™/ Google Docs™ application on your mobile device, so you

don’t need to install the printer driver on the mobile device. Refer to the Google

website (http://support.google.com/cloudprint) for more information about

Google Cloud Print.

Registering your Google account to the printer

• Make sure the printer machine is turned on and connected to a wired or

wireless network that has access to the Internet.

•You should create your Google account in the advance.

1Open the Chrome browser.

2 Visit www.google.com.

3 Sign in to the Google website with your Gmail address.

4 Enter your printer’s IP address in the address field and press the Enter key

or click Go.

5 Click Login in the upper right corner of the SyncThru™ Web Service

website.

6 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and Password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

If the network environment is using a proxy server, you need to configure

the proxy’s IP and port number from Settings > Network Settings >

Google Cloud Print > Proxy Setting. Contact your network service

provider or network administrator for more information.

7 When the SyncThru™ Web Service window opens, click Settings >

Network Settings > Google Cloud Print.

8 Enter your printer’s name and description.

9 Click Register.

The confirmation pop-up window appears.

If you set the browser to block pop-ups, the confirmation window will not

appear. Allow the site to show pop-ups.

Google Cloud Print™

135

2. Using a Network-Connected Machine

10 Click Finish printer registration.

11 Click Manage your printers.

Now your printer is registered with Google Cloud Print service.

Google Cloud Print-ready devices will appear in the list.

Printing with Google Cloud Print™

The printing procedure varies depending on the application or the device you

are using. You can see the application list that supports Google Cloud Print

service.

Make sure the printer is turned on and connected to a wired or wireless

network that has access to the Internet.

Printing from an application on mobile device

The following steps are an example of using the Google Docs app from Android

mobile phone.

1Install the Cloud Print application on your mobile device.

If you do not have the application, download it from the application store

such as Android Market or App Store.

2 Access the Google Docs application from your mobile device.

3 Tap the option button of the document that you want to print.

4 Tap the send button.

5 Tap the Cloud Print button.

6 Set the printing options if you want.

7 Tap Click here to Print.

Printing from the Chrome browser

The following steps are an example of using the Chrome browser.

1Run Chrome.

2 Open the document or email that you want to print.

3 Click the wrench icon in the browser’s top right corner.

4 Click Print. A new tab for printing appears.

Google Cloud Print™

136

2. Using a Network-Connected Machine

5 Select Print with Google Cloud Print.

6 Click the Print button.

3. Special Features

This chapter explains special printing features.

• Altitude adjustment 138

• Printing features 139

The procedures in this chapter are mainly based on Windows 7.

138

3. Special Features

Altitude adjustment

Print quality is affected by atmospheric pressure, which is determined by the

height of the machine above sea level. The following information will guide you

on how to set your machine for the best print quality.

Before you set the altitude value, determine the altitude where you are.

•Normal: 0-1,000 m(3,280 ft)

•High1: 1,000 m(3,280 ft)-2,000 m(6,561 ft)

•High2: 2,000 m(6,561 ft)-3,000m(9,842 ft)

•High3: 3,000 m(9,842 ft)-4,000 m(13,123 ft)

•High4: 4,000 m(13,123 ft)-5,000 m(16,404 ft)

• For Windows and Mac users, you set from Samsung Easy Printer Manager

Advanced Setting

> Device Settings. See "Using Samsung Easy Printer

Manager" on page 162.

If your machine is connected to the network, you can set the altitude via

SyncThru™ Web Service (see "Using SyncThru™ Web Service" on page 159).

139

3. Special Features

Printing features

• For basic printing features, refer to the Basic Guide (see "Basic printing"

on page 35).

• This feature may not be available depending on model or optional goods

(see "Features by model" on page 6).

Changing the default print settings

1Click the Windows Start menu.

• For Windows 8, from the Charms, select Search > Settings.

2 For Windows XP/Server 2003, select Printer and Faxes.

• For Windows Server 2008/Vista, select Control Panel > Hardware

and Sound > Printers.

• For Windows Server 2008 R2, select Control Panel > Hardware >

Devices and Printers.

• For Windows 7/8, select Control Panel > Devices and Printers.

3 Right-click on your machine.

4 For Windows XP/Server 2003/Server 2008/Vista, select Printing

Preferences.

For Windows 7/8 or Windows Server 2008 R2, from context menus, select

Printing preferences.

If Printing preferences has a ►, you can select other printer drivers

connected to the selected printer.

5 Change the settings on each tab.

6 Click OK.

If you want to change the settings for each print job, change it in Printing

Preferences.

Setting your machine as a default machine

1Click the Windows Start menu.

• For Windows 8, from the Charms, select Search > Settings.

2 For Windows XP/Server 2003, select Printer and Faxes.

• For Windows Server 2008/Vista, select Control Panel > Hardware

and Sound > Printers.

• For Windows Server 2008 R2, select Control Panel > Hardware >

Devices and Printers.

• For Windows 7/8, select Control Panel > Devices and Printers.

Printing features

140

3. Special Features

3 Select your machine.

4 Right-click your machine and select Set as Default Printer.

For Windows 7 or Windows Server 2008 R2, if Set as default printer has a

►, you can select other printer drivers connected to the selected printer.

Using advanced print features

XPS printer driver: used to print XPS file format.

• See "Features by model" on page 6.

• The XPS printer driver can be installed only on Windows Vista OS or

higher.

• For models that provide XPS driver from the Samsung website, http://

www.samsung.com > find your product> Support or downloads.

Printing to a file (PRN)

You will sometimes need to save the print data as a file.

1Check the Print to file box in the Print window.

2 Click Print.

3 Type in the destination path and the file name, and then click OK.

For example, c:\Temp\file name.

If you type in only the file name, the file is automatically saved in My

Documents, Documents and Settings, or Users. The saved folder may

differ, depending on your operating system or the application you are

using.

Printing features

141

3. Special Features

Understanding special printer features

You can use advanced printing features when using your machine.

To take advantage of the printer features provided by your printer driver, click Properties or Preferences in the application’s Print window to change the print

settings. The machine name that appears in the printer properties window may differ depending on the machine in use.

• Some menus may not appear on the display depending on options or models. If so, it is not applicable to your machine.

• Select the Help menu or click the button from the window or press F1 on your keyboard and click on any option you want to know about (see "Using help"

on page 38).

Item Description

Multiple Pages per

Side

Selects the number of pages to print on a single sheet of paper. To print more than one page per sheet, the pages will be reduced in size and

arranged in the order you specify. You can print up to 16 pages on one sheet.

Printing features

142

3. Special Features

Poster Printing

Prints a single-page document onto 4 (Poster 2x2), 9 (Poster 3x3), or 16 (Poster 4x4) sheets of paper, for the purpose of pasting the sheets

together to form one poster-size document.

Select the Poster Overlap value. Specify Poster Overlap in millimeters or inches by selecting the radio button on the upper right of Basic tab

to make it easier to paste the sheets together.

Booklet Printing

Prints your document on both sides of a sheet of paper and arranges the pages so that the paper can be folded in half after printing to produce

a booklet.

• This option is available only when you use the PCL/SPL printer driver. This option is not available when you use XPS driver.

• The Booklet Printing option is not available for all paper sizes. Select the available paper Size option under the Paper tab to see what

paper sizes are available.

• If you select an unavailable paper size, this option can be automatically canceled. Select only available paper (paper without or

mark).

Item Description

Printing features

143

3. Special Features

Double-sided

Printing (Manual)

Print on both sides of a sheet of paper (duplex). Before printing, decide how you want your document oriented.

• This option is available only when you use the PCL/SPL printer driver. This option is not available when you use XPS driver.

• If your machine does not have a duplex unit, you should complete the printing job manually. The machine prints every other page of

the document first. After that, a message appears on your computer.

•Skip Blank Pages feature does not work when you select the duplex option.

•None: Disables this feature.

•Long Edge: This option is the conventional layout used in bookbinding.

•Short Edge: This option is the conventional layout used in calendars.

Paper Options Changes the size of a document to appear larger or smaller on the printed page by entering in a percentage by which to enlarge or decrease the

document.

Item Description

Printing features

144

3. Special Features

Watermark The watermark option allows you to print text over an existing document. For example, you use it when you want to have large gray letters

reading “DRAFT” or “CONFIDENTIAL” printed diagonally across the first page or all pages of a document.

Watermark

(Creating a

watermark)

a To change the print settings from your software application, access Printing Preferences (see "Opening Printing Preferences" on page 36).

b From the Advanced tab, select Edit... from the Watermark drop-down list.

c Enter a text message in the Watermark Message box. You can enter up to 256 characters.

When the First Page Only box is checked, the watermark prints on the first page only.

d Select watermark options.

You can select the font name, style, size, and shade from the Font Attributes section, as well as set the angle of the watermark from the

Watermark Alignment and Angle section.

e Click Add to add a new watermark to the Current Watermarks list.

f When you finish editing, click OK or Print until you exit the Print window.

Watermark

(Editing a watermark)

a To change the print settings from your software application, access Printing Preferences (see "Opening Printing Preferences" on page 36).

b Click the Advanced tab, select Edit... from the Watermark drop-down list.

c Select the watermark you want to edit from the Current Watermarks list and change the watermark message and options.

d Click Update to save the changes.

e Click OK or Print until you exit the Print window.

Watermark

(Deleting a

watermark)

a To change the print settings from your software application, access Printing Preferences.

b Click the Advanced tab, select Edit... from the Watermark drop-down list.

c Select the watermark you want to delete from the Current Watermarks list and click Delete.

d Click OK or Print until you exit the Print window.

Item Description

Printing features

145

3. Special Features

Overlaya

This option is available only when you use the PCL/SPL printer driver. This option is not available when you use XPS driver

An overlay is text and/or images stored in the computer hard disk drive (HDD) as a special file format that can be printed on any document.

Overlays are often used to take the place of letterhead paper. Rather than using preprinted letterhead, you can create an overlay containing

exactly the same information that is currently on your letterhead. To print a letter with your company’s letterhead, you do not need to load

preprinted letterhead paper in the machine: just print the letterhead overlay on your document.

To use a page overlay, you must create a new page overlay containing your logo or image.

• The overlay document size must be the same as the document you print with the overlay. Do not create an overlay with a watermark.

• The resolution of the overlay document must be the same as that of the document you will print with the overlay.

Overlaya

(Creating a new page

overlay)

a Create or open a document containing text or an image for use in a new page overlay. Position the items exactly as you wish them to appear

when printed as an overlay.

b To save the document as an overlay, access Printing Preferences.

c Click the Advanced tab, and select Create from the Overlay drop-down list.

d In the Save As window, type a name up to eight characters in the File name box. Select the destination path, if necessary (The default is

C:\Formover).

e Click Save.

f Click OK or Print until you exit the Print window.

When a confirming message window appears, click Yes.

g The file is not printed. Instead, it is stored on your computer hard disk drive.

Item Description

Printing features

146

3. Special Features

Overlaya

(Using a page overlay)

a Create or open the document you want to print.

b To change the print settings from your software application, access Printing Preferences.

c Click the Advanced tab.

d Select the Print Overlay from the Overlay drop-down list.

e If the overlay file you want does not appear in the Overlay File 1 or Overlay File 2 drop-down list, select Load from the Overlay List. Select

the overlay file you want to use.

If you have stored the overlay file you want to use in an external source, you can also load the file when you access the Load window.

After you select the file, click Open. The file appears in the Overlay List box and is available for printing. Select the overlay from the Overlay

List box.

f If necessary, check Confirm Page Overlay When Printing box. If this box is checked, a message window appears each time you submit a

document for printing, asking you to confirm your wish to print an overlay on your document.

If this box is not checked and an overlay has been selected, the overlay automatically prints with your document.

g Click OK or Print until you exit the Print window.

The selected overlay prints on your document.

Overlaya

(Deleting a page

overlay)

a In the Printing Preferences window, click the Advanced tab.

b Select Edit in the Text drop down list.

c Select the overlay you want to delete from the Overlay List box.

d Click Delete.

e When a confirming message window appears, click Yes.

f Click OK or Print until you exit the Print window. You can delete page overlays that you no longer use.

a. This option is not available when you use XPS driver.

Item Description

Printing features

147

3. Special Features

Mac printing

Some features may not be available depending on models or options. It

means that the features are not supported.

Printing a document

When you print with a Mac, you need to check the printer driver settings in each

application you use. Follow the steps below to print from a Mac:

1Open the document to print.

2 Open the File menu and click Page Setup (Document Setup in some

applications).

3 Choose your paper size, orientation, scaling, other options, and make

sure that your machine is selected. Click OK.

4 Open the File menu and click Print.

5 Choose the number of copies and indicate which pages to print.

6 Click Print.

Changing printer settings

You can use advanced printing features when using your machine.

Open an application and select Print from the File menu. The machine name,

which appears in the printer properties window, may differ depending on the

machine in use. Except for the name, the composition of the printer properties

window is similar to the following.

Printing multiple pages on one sheet

You can print more than one page on a single sheet of paper. This feature

provides a cost-effective way to print draft copies.

1Open an application, and select Print from the File menu.

2 Select Layout from the drop-down list under Orientation. In the Pages

per Sheet drop-down list, select the number of pages you want to print

on one sheet of paper.

3 Select the other options to use.

4 Click Print.

The machine prints the selected number of pages to print on one sheet

of paper.

Printing features

148

3. Special Features

Printing on both sides of the paper

Some features may not be available depending on models or options. It

means that the features are not supported (see "Variety feature" on page 8).

Before printing in the duplex mode, decide on which edge you will be binding

your finished document. The binding options are, as follows:

•Long-Edge Binding: This option is the conventional layout used in book

binding.

•Short-Edge Binding: This option is the type often used with calendars.

1From your Mac application, select Print from the File menu.

2 Select Layout from the drop-down list under Orientation.

3 Select a binding orientation from the Two-Sided option.

4 Select the other options to use.

5 Click Print and the machine prints on both sides of the paper.

If you print more than 2 copies, the first copy and the second copy might

print on the same sheet of paper. Avoid printing on both sides of paper

when you are printing more than 1 copy.

Using help

Click the question mark on the bottom-left corner of the window and click on

the topic you want to know about. A pop-up window appears with information

about that option's feature, which is provided from the driver.

Printing features

149

3. Special Features

Linux printing

Some features may not be available depending on models or options. It

means that the features are not supported.

Printing from applications

There are a lot of Linux applications that allow you to print using Common UNIX

Printing System (CUPS). You can print on your machine from any such

application.

1Open the document to print.

2 Open the File menu and click Page Setup (Print Setup for some

applications).

3 Choose your paper size, orientation, and make

sure that your machine is selected. Click Apply.

4 Open the File menu and click Print.

5 Select your machine to print.

6 Choose the number of copies and indicate which pages to print.

7 Change other printing options in each tab, if necessary.

8 Click Print.

Automatic/manual duplex printing may not be available depending on

models. You can alternatively use the lpr printing system or other

applications for odd-even printing (see "Features by model" on page 6).

Printing files

You can print text, image, pdf files on your machine using the standard

CUPS directly from the command line interface. The CUPS lp or lpr utility allows

you to do that. You can print these files by using below command format.

"lp -d <printer name> -o <option> <file name>"

Please refer to lp or lpr man page on your system for more details.

Printing features

150

3. Special Features

Configuring Printer Properties

You can change the default printing options or connection type with Printing

utility supplied by o/s.

1Launch Printing utility(Go to System > Administration > Printing

menu or execute "system-config-printer" command in Terminal

program).

2 Select your printer and double-click it.

3 Change default printing options or connection type.

4 Click Apply button.

4. Useful Management

Tools

This chapter introduces management tools provided to help you make full use of your machine.

• Accessing management tools 152

• Easy Capture Manager 153

• Samsung Easy Color Manager 154

• Easy Eco Driver 155

• Using Samsung Printer Center 156

• Using SyncThru™ Web Service 159

• Using Samsung Easy Printer Manager 162

• Using Samsung Printer Status 164

• Using Samsung Printer Experience 166

152

4. Useful Management Tools

Accessing management tools

Samsung provides a variety of management tools for Samsung printers.

1Make sure that the machine is connected to your computer and powered on.

2 From the Start menu, select Programs or All Programs.

• For Windows 8, from the Charms, select Search > Apps.

3 Find Samsung Printers.

4 Under Samsung Printers, you can see installed management tools.

5 Click the management tool you want to use.

• After installing the driver, for some management tools, you can access them directly from the Start menu > Programs or All Programs.

• For Windows 8, after installing the driver, for some management tools, you can access them directly from the Start screen by clicking on the corresponding tile.

153

4. Useful Management Tools

Easy Capture Manager

• This feature may not be available depending on model or optional goods (see "Software" on page 7).

• Available for Windows OS users only (see "Software" on page 7).

Capture your screen and launch Easy Capture Manager by simply pressing the Print Screen key on the keyboard. Now you can easily print your captured screen as

captured or edited.

154

4. Useful Management Tools

Samsung Easy Color Manager

Samsung Easy Color Manager helps users do fine adjustments with 6 color tones and other properties, such as brightness, contrast, and saturation. Color tone

changes can be saved as a profile and can be used from the driver or from inside of the machine.

• This feature may not be available depending on model or optional goods (see "Software" on page 7).

• Available for Windows and Mac OS users only (see "Software" on page 7).

Helps Samsung color laser printer users to adjust color as they like.

Download the software from the Samsung website then unpack and install it: (http://www.samsung.com > find your product > Support or Downloads).

155

4. Useful Management Tools

Easy Eco Driver

• Available for Windows OS users only (see "Software" on page 7).

• To use the Easy Eco Driver features, the Eco Driver Pack must be installed.

With the Easy Eco Driver, you can apply Eco features to save paper and toner before printing.

Easy Eco Driver also allows you simple editing such as removing images and texts, and more. You can save frequently used settings as a favorite.

How to use:

1 Open a document to print.

2 Open printing preference window (see "Opening Printing Preferences" on page 36).

3 From the Favorites tab, select Eco Printing Preview.

4 Click OK > Print in the window. A preview window appears.

5 Select the options you want to apply to the document.

You can see the preview of the applied features.

6 Click Print.

•If you want to run Easy Eco Driver every time you print, check Start Easy Eco Driver before printing job checkbox in the Basic tab of the printing preference

window.

• To use this feature on Stylish User Interface, click Samsung Printer Center > Device Options and then select Stylish User Interface (see "Using Samsung Printer

Center" on page 156).

156

4. Useful Management Tools

Using Samsung Printer Center

• Available for Windows users only.

The Samsung Printer Center allows you to manage all the printer drivers

installed on your computer from a single integrated application. You can use the

Samsung Printer Center to add and remove printer drivers, check the status of

printers, update printer software, and configure printer driver settings.

Understanding Samsung Printer Center

To open the program:

For Windows,

Select Start > Programs or All Programs > Samsung Printers > Samsung

Printer Center.

Printers tab

The screenshot may differ depending on operating system you are using.

Printer list Displays the printer drivers installed on your computer. To add a

printer driver to the list, click the button.

Using Samsung Printer Center

157

4. Useful Management Tools

Scanner & Fax Tab

• The screenshot may differ depending on operating system you are using.

• Available for multifunction products only.

Quick links Displays links to various printer driver management functions.

The quick links in the Printers tab link to the following functions:

•Settings: Allows you to configure the settings for individual

printer driver.

-Set as default printer: Sets the selected printer driver as

the default printer. If the selected printer driver is already

set as the default printer, then this option is not activated.

-Printing preferences: Allows you to configure the default

print settings.

-Device options: Allows you to configure advanced

options, such as the settings for optional devices and

additional features.

The option allows you to modify the Printer Status

and Stylish User Interface settings.

-Change device: Allows you to change the device into

another device.

-Properties: Allows you to configure the printer driver

properties, such as the name of the printer driver and its

location, or add comments about the printer driver .

•Actions: Allows you to use the scan feature (this option is

enabled only if the selected device supports the scan feature).

•Management: Allows you to manage the devices registered

in the program.

-Add a new printer / Remove printer: Adds a new device

or removes an existing device.

-Diagnose printer: Diagnoses problems in the selected

device and suggests solutions.

-Update software: Downloads and applies the applicable

software updates.

3Printer

information

Provides general information about the selected device, such as

its model, IP address, port number, and status.

Printer list Displays the fax and scanner driver installed on your

computer. To add a fax or scanner driver to the list, click the

(Add Fax) or (Add Scanner) button.

Using Samsung Printer Center

158

4. Useful Management Tools

Quick links Displays links to the functions available for managing fax or

scanner drivers. The quick links in the Scanner & Fax tab offer

the following features:

To use this feature, the scanner driver and fax driver

must be installed on the computer.

•Settings: Allows you to configure the settings for fax or

scanner dirvers.

-Address Book (fax only): Opens the Address Book.

-Fax Transmission History (fax only): Opens the fax

transmission history.

-Fax preferences (fax only): Allows you to configure the

default fax settings.

-Change device: Allows you to change the devices into

another device.

-Properties: Allows you to configure the properties of a

device, such as location and add comments about the

device.

•Actions: Allows you to use the scan feature.

•Management: Allows you to manage the devices

registered in the program.

-Remove fax or Remove scan: Removes the selected fax

or scan driver.

-Update software: Downloads and applies the

applicable software updates.

3Printer

information

Provides general information about the selected device, such

as the model, IP address, port number, and machine status.

159

4. Useful Management Tools

Using SyncThru™ Web Service

• Internet Explorer 6.0 or higher is the minimum requirement for

SyncThru™ Web Service.

•SyncThru™ Web Service explanation in this user’s guide may differ from

your machine depending on its options or models.

• Network model only.

Accessing SyncThru™ Web Service

1Access a web browser, such as Internet Explorer, from Windows.

Enter the machine IP address of your printer (http://xxx.xxx.xxx.xxx) in

the address field and press the Enter key or click Go.

2 Your machine’s embedded website opens.

Logging into SyncThru™ Web Service

Before configuring options in SyncThru™ Web Service, you need to log-in as an

administrator. You can still use SyncThru™ Web Service without logging in but

you won’t have access to Settings tab and Security tab.

1Click Login on the upper right of the SyncThru™ Web Service website.

2 If it’s your first time logging into SyncThru™ Web Service you need to

log-in as an administrator. Type in the below default ID and password.

We recommend you to change the default password for security

reasons.

•ID: admin

•Password: sec00000

SyncThru™ Web Service overview

Some tabs may not appear depending on your model.

Using SyncThru™ Web Service

160

4. Useful Management Tools

Information tab

This tab gives you general information about your machine. You can check

things, such as remaining amount of toner. You can also print reports, such as an

error report.

•Active Alerts: Shows the alerts that have occurred in the machine and their

severity.

•Supplies: Shows how many pages are printed and amount of toner left in

the cartridge.

•Usage Counters: Shows the usage count by print types: simplex and

duplex.

•Current Settings: Shows the machine’s and network’s information.

•Print information: Prints reports such as system related reports and font

reports.

Settings tab

This tab allows you to set configurations provided by your machine and

network. You need to log-in as an administrator to view this tab.

•Machine Settings tab: Sets options provided by your machine.

•Network Settings tab: Shows options for the network environment. Sets

options such as TCP/IP and network protocols.

Security tab

This tab allows you to set system and network security information. You need to

log-in as an administrator to view this tab.

•System Security: Sets the system administrator’s information and also

enables or disables machine features.

•Network Security: Sets settings for IPv4/IPv6 filtering.

Maintenance tab

This tab allows you to maintain your machine by upgrading firmware and

setting contact information for sending emails. You can also connect to

Samsung website or download drivers by selecting the Link menu.

•Firmware Upgrade: Upgrade your machine’s firmware.

•Contact Information: Shows the contact information.

•Link: Shows links to useful sites where you can download or check

information.

Setting the system administrator’s information

This setting is necessary for using the e-mail notification option.

Using SyncThru™ Web Service

161

4. Useful Management Tools

1Start a web browser, such as Internet Explorer, from Windows.

Enter the machine IP address (http://xxx.xxx.xxx.xxx) in the address field

and press the Enter key or click Go.

2 Your machine’s embedded website opens.

3 From the Security tab, select System Security > System Administrator

4 Enter the name of the administrator, phone number, location, and email

address.

5 Click Apply.

162

4. Useful Management Tools

Using Samsung Easy Printer Manager

• Available for Windows and Mac OS users only.

• For Windows, Internet Explorer 6.0 or higher is the minimum

requirement for Samsung Easy Printer Manager.

Samsung Easy Printer Manager is an application that combines Samsung

machine settings into one location. Samsung Easy Printer Manager combines

device settings as well as printing environments, settings/actions and

launching. All of these features provide a gateway to conveniently use your

Samsung machine. Samsung Easy Printer Manager provides two different user

interfaces for the user to choose from: the basic user interface and the advanced

user interface. Switching between the two interfaces is easy: just click a button.

Understanding Samsung Easy Printer Manager

To open the program:

For Windows,

Select Start > Programs or All Programs > Samsung Printers > Samsung

Easy Printer Manager .

For Mac,

Open the Applications folder > Samsung folder > Samsung Easy Printer

Manager.

The Samsung Easy Printer Manager interface is comprised of various basic

sections as described in the table that follows:

The screenshot may differ depending on operating system you are using.

Printer list The Printer list displays printers installed on your computer

and network printers added by network discovery (Windows

only).

Using Samsung Easy Printer Manager

163

4. Useful Management Tools

Select the Help menu or click the button from the window and click on

any option you want to know about.

Advanced

Setting

The advanced user interface is intended to be used by the person

responsible for managing the network and machines.

Some menus may not appear in the display depending

on options or models. If so, it is not applicable to your

machine.

•

Device Settings:

You can configure various machine settings

such as machine setup, paper, layout, emulation, network, and

print information.

If you connect your machine to a network, the SyncThru™

Web Service icon is enabled.

•

Scan to PC Settings:

This menu includes settings to create or

delete scan to PC profiles.

Scan Activation:

Determines whether or not scanning is

enabled on the device.

Basic

tab

Contains settings related general scan and

device

settings.

•

Alert Settings

(Windows only)

This menu includes settings

related to error alerting.

Printer Alert:

Provides settings related to when alerts will

be received.

Email Alert:

Provides options relating to receiving alerts

via email.

Alert History:

Provides a history of device and toner

related alerts.

Application

information

Includes links for changing to the refresh, preference setting,

help, and about.

Printer

information

This area gives you general information about your machine. You

can check information, such as the machine’s model name, IP

address (or Port name), and machine status.

This button opens the

Troubleshooting Guide

when an

error occurs. You can directly open the troubleshooting

section in the user’s guide.

Quick links

Displays

Quick links

to machine specific functions. This section

also includes links to applications in the advanced settings.

If you connect your machine to a network, the SyncThru™

Web Service icon is enabled.

Contents

area

Displays information about the selected machine, remaining

toner level, and paper. The information will vary based on the

machine selected. Some machines do not have this feature.

Order

supplies

Click on the

Order

button from the supply ordering window. You

can order replacement toner cartridge(s) from online.

164

4. Useful Management Tools

Using Samsung Printer Status

The Samsung Printer Status is a program that monitors and informs you of the

machine status.

• The Samsung Printer Status window and its contents shown in this user’s

guide may differ depending on the machine or operating system in use.

• Check the operating system(s) that are compatible with your machine

(see "System requirements" on page 71).

• Available for Windows OS users only.

Samsung Printer Status overview

If an error occurs while operating, you can check the error from the Samsung

Printer Status. Samsung Printer Status is installed automatically when you install

the machine software.

You can also launch Samsung Printer Status manually. Go to the Printing

Preferences, click the Basic tab > Printer Status button.

These icons appear on the Windows task bar:

Icon Mean Description

Normal The machine is in ready mode and experiencing no

errors or warnings.

Warning The machine is in a state where an error might

occur in the future. For example, it might be in

toner low status, which may lead to toner empty

status.

Error The machine has at least one error.

456

Using Samsung Printer Status

165

4. Useful Management Tools

Device

Information

You can see the device status , current printer model

name, connected port name in this area.

User’s Guide You can view the online User’s Guide.

This button opens the Troubleshooting Guide

when an error occurs. You can directly open the

troubleshooting section in the user’s guide.

Supplies

Information

You can view the percentage of toner remaining in

each toner cartridge. The machine and the number of

toner cartridge(s) shown in the above window may

differ depending on the machine in use. Some

machines do not have this feature.

Option You can set printing job alert related settings.

Order Supplies You can order replacement toner cartridge(s) from

online.

Cancel Print

•Cancel Print : If print job is waiting in the print

queue or printer, cancel all user's print jobs in the

print queue or the printer.

•Close : Depending on the status of the machine or

the supported functions, the Close button may

appear to close the status window.

7Toner/Paper

Information

This button areas for paper and toner info will be

available based on the device.

166

4. Useful Management Tools

Using Samsung Printer Experience

Samsung Printer Experience is a Samsung application that combines

Samsung machine settings and machine management into one location. You

can set device settings, order supplies, open troubleshooting guides, visit

Samsung’s web site, and check connected machine information. This

application will be automatically downloaded from the Windows Store if the

machine is connected to a computer with an Internet connection.

Understanding the Samsung Printer Experience

To open the application,

From the Start screen, select the Samsung Printer Experience () tile.

The Samsung Printer Experience interface comprises various useful features as

described in the following table:

The screenshot may differ depending on the model you are using.

Printer

Information

This area gives you general information about your

machine. You can check information, such as the

machine’s status, location, IP address, and remaining

toner level.

126

Using Samsung Printer Experience

167

4. Useful Management Tools

Adding/Deleting Printers

If you do not have any printer added to the Samsung Printer Experience, or if

you want to add/delete a printer, follow the instructions below.

You can only add/delete network connected printers.

Adding a printer

1From the Charms, select Settings.

Or, right-click the Samsung Printer Experience page and select

Settings.

2 Select Add Printer

3 Select the printer you want to add.

You can see the added printer.

If you see mark, you can also click mark to add printers.

2User’s Guide You can view the online User’s Guide. You need to be

connected to the Internet to use this feature.

This button opens the Troubleshooting Guide

when an error occurs. You can directly open the

troubleshooting section in the user’s guide.

Order Supplies Click on this button to order replacement toner

cartridges online. You need to be connected to the

Internet to use this feature.

4Visit Samsung Links to Samsung printer website. You need to be

connected to the Internet to use this feature.

Printer Settings You can configure various machine settings such as

machine setup, paper, layout, emulation, networking,

and print information through SyncThru™ Web Service.

Your machine needs to be connected to a network. This

button will be disabled if your machine is connected via

USB cable.

Device List &

Latest Scanned


The scan list displays devices that supports Samsung

Printer Experience. Under the device, you can see the

latest scanned images. Your machine needs to be

connected to a network to scan from here.

This section is for the users with multi-functional printers.

Using Samsung Printer Experience

168

4. Useful Management Tools

Deleting a printer

1From the Charms, select Settings.

Or, right-click the Samsung Printer Experience page and select

Settings.

2 Select Remove Printer

3 Select the printer you want to delete.

4 Click Yes.

You can see that the deleted printer is removed from the screen.

Printing from Windows 8

This section explains common printing tasks from the Start screen.

Basic printing

1Open the document to print.

2 From the Charms, select Devices.

3 Select your printer from the list

4 Select the printer settings, such as the number of copies and orientation.

5 Click the Print button to start the print job.

Cancelling a print job

If the printing job is waiting in the print queue or print spooler, cancel the job as

follows:

• You can access this window by simply double-clicking the machine icon

( ) in the Windows task bar.

• You can also cancel the current job by pressing (Cancel or Stop/Clear)

button on the control panel.

Using Samsung Printer Experience

169

4. Useful Management Tools

Opening more settings

The screen may appear somewhat different depending on the model or

options.

You can set up more printing parameters.

1Open the document you want to print.

2 From the Charms, select Devices.

3 Select your printer from the list

4 Click More settings.

Basic tab

Basic

This option allows you to choose the basic printing settings such as copies,

orientation, and document type.

Eco settings

This option allows you to choose multiple pages per side to save media.

Using Samsung Printer Experience

170

4. Useful Management Tools

Advanced tab

Paper settings

This option allows you to set the basic paper handling specifications.

Layout settings

This option allows you to set the various ways to layout your documents.

Security tab

Some features may not be available depending on the model or options. If

this tab is not shown or disabled, it means that these features are not

supported.

Job Accounting

This option allows you to print with the given permission.

Confidential Printing

This option is used for printing confidential documents. You need to enter a

password to print using it.

Using Samsung Printer Experience

171

4. Useful Management Tools

Using the sharing feature

Samsung Printer Experience allows you to print from other applications

installed on the computer using the sharing feature.

This feature is only available for printing jpeg, bmp, tiff, gif, and png file

formats.

1Select the content you want to print from other application.

2 From the Charms, select Share > Samsung Printer Experience .

3 Select the printer settings, such as the number of copies and orientation.

4 Click the Print button to start the print job.

5. Troubleshooting

This chapter gives helpful information for what to do if you encounter an error.

• Paper feeding problems 173

• Power and cable connecting problems 174

• Printing problems 175

• Printing quality problems 179

• Operating system problems 187

173

5. Troubleshooting

Paper feeding problems

Condition Suggested solutions

Paper jams during printing. Clear the paper jam.

Paper sticks together. • Check the maximum paper capacity of the tray.

• Make sure that you are using the correct type of paper.

• Remove paper from the tray and flex or fan the paper.

• Humid conditions may cause some paper to stick together.

Multiple sheets of paper do not feed. Different types of paper may be stacked in the tray. Load paper of only one type, size, and weight.

Paper does not feed into the machine. • Remove any obstructions from inside the machine.

• Paper has not been loaded correctly. Remove paper from the tray and reload it correctly.

• There is too much paper in the tray. Remove excess paper from the tray.

• The paper is too thick. Use only paper that meets the specifications required by the machine.

The paper keeps jamming. • There is too much paper in the tray. Remove excess paper from the tray. If you are printing on special materials, feed

manually in the tray.

• An incorrect type of paper is being used. Use only paper that meets the specifications required by the machine.

• There may be debris inside the machine. Open the top cover and remove any debris.

174

5. Troubleshooting

Power and cable connecting problems

Reboot the power. If the problem persists, please call for service.

Condition Suggested solutions

The machine is not receiving power,

or the connection cable between the

computer and the machine is not

connected properly.

1 Connect the machine to the electricity supply first.

2 Check the USB cable or network cable in the machine’s rear.

3 Disconnect the USB cable or network cable in the machine’s rear and then, reconnect it.

175

5. Troubleshooting

Printing problems

Condition Possible cause Suggested solutions

The machine does not

print.

The machine is not receiving power. Check the power cord connections. Check the power switch and the power source.

The machine is not selected as the default

machine.

Select your machine as your default machine in Windows.

Check the machine for the following:

• The top cover is not closed. Close the top cover.

• Paper is jammed. Clear the paper jam (see "Clearing paper jams" on page 59).

• No paper is loaded. Load paper (see"Loading paper in the tray" on page 28).

• The toner cartridge is not installed. Install the toner cartridge (see "Replacing the toner cartridge" on page 48).

• Make sure the protect cover and sheets are removed from the toner cartridge (see "Replacing the toner cartridge" on page 48).

If a system error occurs, contact your service representative.

The connection cable between the computer and

the machine is not connected properly.

Disconnect the machine cable and reconnect it (see "Rear view" on page 19).

The connection cable between the computer and

the machine is defective.

If possible, attach the cable to another computer that is working properly and print a job.

You can also try using a different machine cable.

The port setting is incorrect. Check the Windows printer settings to make sure that the print job is sent to the correct

port. If the computer has more than one port, make sure that the machine is attached to

the correct one.

The machine may be configured incorrectly. Check the Printing Preferences to ensure that all of the print settings are correct.

Printing problems

176

5. Troubleshooting

The machine does not

print.

The printer driver may be incorrectly installed. Uninstall and reinstall the machine’s driver.

The machine is malfunctioning. Check the display message on the control panel to see if the machine is indicating a

system error. Contact a service representative.

The document size is so big that the hard disk

space of the computer is insufficient to access the

print job.

Get more hard disk space and print the document again.

The output tray is full. Once the paper is removed from the output tray, the machine resumes printing.

The machine selects print

materials from the wrong

paper source.

The paper option that was selected in the

Printing Preferences may be incorrect.

For many software applications, the paper source selection is found under the Paper tab

within the Printing Preferences (see "Opening Printing Preferences" on page 36).

Select the correct paper source. See the printer driver help screen (see "Using help" on

page 38).

A print job is extremely

slow.

The job may be very complex. Reduce the complexity of the page or try adjusting the print quality settings.

Half the page is blank. The page orientation setting may be incorrect. Change the page orientation in your application (see "Opening Printing Preferences" on

page 36). See the printer driver help screen (see "Using help" on page 38).

The paper size and the paper size settings do not

match.

Ensure that the paper size in the printer driver settings matches the paper in the tray.

Or, ensure that the paper size in the printer driver settings matches the paper selection

in the software application settings you use (see "Opening Printing Preferences" on

page 36).

Condition Possible cause Suggested solutions

Printing problems

177

5. Troubleshooting

The machine prints, but

the text is wrong,

garbled, or incomplete.

The machine cable is loose or defective. Disconnect the machine cable and reconnect. Try a print job that you have already

printed successfully. If possible, attach the cable and the machine to another computer

that you know works and try a print job. Finally, try a new machine cable.

The wrong printer driver was selected. Check the application's printer selection menu to ensure that your machine is selected.

The software application is malfunctioning. Try printing a job from another application.

The operating system is malfunctioning. Exit Windows and reboot the computer. Turn the machine off and back on again.

Pages print, but they are

blank.

The toner cartridge is defective or out of toner. Redistribute the toner, if necessary.

If necessary, replace the toner cartridge.

• See "Redistributing toner" on page 46.

• See "Replacing the toner cartridge" on page 48.

The file may have blank pages. Check the file to ensure that it does not contain blank pages.

Some parts, such as the controller or the board,

may be defective.

Contact a service representative.

The machine does not

print PDF files correctly.

Some parts of graphics,

text, or illustrations are

missing.

Incompatibility between the PDF file and the

Acrobat products.

Printing the PDF file as an image may enable the file to print. Turn on Print As Image

from the Acrobat printing options.

It will take longer to print when you print a PDF file as an image.

The print quality of

photos is not good.

Images are not clear.

The resolution of the photo is very low. Reduce the photo size. If you increase the photo size in the software application, the

resolution will be reduced.

Condition Possible cause Suggested solutions

Printing problems

178

5. Troubleshooting

Before printing, the

machine emits vapor near

the output tray.

Using damp/wet paper can cause vapor [white

smoke] during printing.

This is not a problem, just keep printing. If you are bothered by the smoke [vapor], then

replace the paper with fresh paper from an unopened ream.

The machine does not

print special-sized paper,

such as billing paper.

Paper size and paper size setting do not match. Set the correct paper size in the Custom in Paper tab in Printing Preferences (see

"Opening Printing Preferences" on page 36).

The printed billing paper

is curled.

The paper type setting does not match. Change the printer option and try again. Go to Printing Preferences, click Paper tab,

and set type to Thick (see "Opening Printing Preferences" on page 36).

Condition Possible cause Suggested solutions

179

5. Troubleshooting

Printing quality problems

If the inside of the machine is dirty or paper has been loaded improperly, there might be a reduction in print quality. See the table below to clear the problem.

Condition Suggested Solutions

Light or faded print • If a vertical white streak or faded area appears on the page, the toner supply is low. Install a new toner cartridge (see "Replacing the

toner cartridge" on page 48).

• If a vertical white streak or faded area still appears on the page even though the machine has enough toner supply, open and close

the front door 3 ~ 4 times (see "Machine overview" on page 17).

• The paper may not meet paper specifications; for example, the paper may be too moist or rough.

• If the entire page is light, the print resolution setting is too low or the toner save mode is on. Adjust the print resolution and turn

the toner save mode off. See the help screen of the printer driver.

• A combination of faded or smeared defects may indicate that the toner cartridge needs cleaning. Clean the inside of your machine

(see "Cleaning the machine" on page 54).

• The surface of the LSU part inside the machine may be dirty. Clean the inside of your machine (see "Cleaning the machine" on page

54). If these steps do not correct the problem, contact a service representative.

The top half of the paper is

printed lighter than the rest of

the paper

The toner might not adhere properly to this type of paper.

• Change the printer option and try again. Go to Printing Preferences, click the Paper tab, and set the paper type to Recycled (see

"Opening Printing Preferences" on page 36).

Printing quality problems

180

5. Troubleshooting

Toner specks • The paper may not meet specifications; for example, the paper may be too moist or rough.

• The transfer roller may be dirty. Clean the inside of your machine (see "Cleaning the machine" on page 54).

• The paper path may need cleaning. Contact a service representative (see "Cleaning the machine" on page 54).

Dropouts If faded areas, generally rounded, occur randomly on the page:

• A single sheet of paper may be defective. Try reprinting the job.

• The moisture content of the paper is uneven or the paper has moist spots on its surface. Try a different brand of paper.

• The paper lot is bad. The manufacturing processes can cause some areas to reject toner. Try a different kind or brand of paper.

• Change the printer option and try again. Go to Printing Preferences, click the Paper tab, and set type to Thick or Thicker (see

"Opening Printing Preferences" on page 36).

If these steps do not correct the problem, contact a service representative.

White Spots If white spots appear on the page:

• The paper is too rough and a lot of dirt from paper falls to the inner components within the machine, so the transfer roller may be

dirty. Clean the inside of your machine (see "Cleaning the machine" on page 54).

• The paper path may need cleaning. Clean the inside of your machine (see "Cleaning the machine" on page 54).

If these steps do not correct the problem, contact a service representative.

Condition Suggested Solutions

AaBbCc

AaBbC

Printing quality problems

181

5. Troubleshooting

Vertical lines If black vertical streaks appear on the page:

• The surface (drum part) of the imaging unit inside the machine has probably been scratched. Remove the toner cartridge and install

a new one (see "Replacing the imaging unit" on page 52).

If white vertical streaks appear on the page:

• The surface of the LSU part inside the machine may be dirty. Clean the inside of your machine (see "Cleaning the machine" on page

54). If these steps do not correct the problem, contact a service representative.

Black background If the amount of background shading becomes unacceptable:

• Change to a lighter weight paper.

• Check the environmental conditions: very dry conditions or a high level of humidity (higher than 80% RH) can increase the amount

of background shading.

• Remove the old imaging unit and install a new one (see "Replacing the imaging unit" on page 52).

• Thoroughly redistribute the toner (see "Redistributing toner" on page 46).

Toner smear • Clean the inside of the machine (see "Replacing the toner cartridge" on page 48).

• Check the paper type and quality.

• Remove the old imaging unit and install a new one (see "Replacing the imaging unit" on page 52).

Condition Suggested Solutions

Printing quality problems

182

5. Troubleshooting

Vertical repetitive defects If marks repeatedly appear on the printed side of the page at even intervals:

• The imaging unit may be damaged. If you still have the same problem, remove the imaging unit and, install a new one (see

"Replacing the imaging unit" on page 52).

• Parts of the machine may have toner on them. If the defects occur on the back of the page, the problem will likely correct itself after

a few more pages.

• The fusing assembly may be damaged. Contact a service representative.

Background scatter Background scatter results from bits of toner randomly distributed on the printed page.

• The paper may be too damp. Try printing with a different batch of paper. Do not open packages of paper until necessary so that

the paper does not absorb too much moisture.

• If background scatter covers the entire surface area of a printed page, adjust the print resolution through your software application

or in Printing Preferences (see "Opening Printing Preferences" on page 36). Ensure the correct paper type is selected. For example:

If Thicker Paper is selected, but Plain Paper actually used, an overcharging can occur causing this copy quality problem.

• If you are using a new toner cartridge, redistribute the toner first (see "Redistributing toner" on page 46).

Toner particles are around bold

characters or pictures

The toner might not adhere properly to this type of paper.

• Change the printer option and try again. Go to Printing Preferences, click the Paper tab, and set the paper type to Recycled (see

"Opening Printing Preferences" on page 36).

• Ensure the correct paper type is selected. For example: If Thicker Paper is selected, but Plain Paper actually used, an overcharging

can occur causing this copy quality problem.

Condition Suggested Solutions

Printing quality problems

183

5. Troubleshooting

Misformed characters • If characters are improperly formed and producing hollow images, the paper stock may be too slick. Try different paper.

Page skew • Ensure that the paper is loaded properly.

• Check the paper type and quality.

• Ensure that the guides are not too tight or too loose against the paper stack.

Curl or wave • Ensure that the paper is loaded properly.

• Check the paper type and quality. Both high temperature and humidity can cause paper curl.

• Turn the stack of paper over in the tray. Also try rotating the paper 180° in the tray.

Condition Suggested Solutions

Printing quality problems

184

5. Troubleshooting

Wrinkles or creases • Ensure that the paper is loaded properly.

• Check the paper type and quality.

• Turn the stack of paper over in the tray. Also try rotating the paper 180° in the tray.

Back of printouts are dirty • Check for leaking toner. Clean the inside of the machine (see "Cleaning the machine" on page 54).

Solid color or black pages • The imaging unit may not be installed properly. Remove the imaging unit and reinsert it.

• The imaging unit may be defective. Remove the imaging unit and install a new one (see "Replacing the imaging unit" on page 52).

• The machine may require repairing. Contact a service representative.

Condition Suggested Solutions

Printing quality problems

185

5. Troubleshooting

Loose toner • Clean the inside of the machine (see "Cleaning the machine" on page 54).

• Check the paper type and quality.

• Remove the imaging unit and then, install a new one (see "Replacing the imaging unit" on page 52).

If the problem persists, the machine may require repair. Contact a service representative.

Character voids Character voids are white areas within parts of characters that should be solid black:

• You may be printing on the wrong surface of the paper. Remove the paper and turn it around.

• The paper may not meet paper specifications.

Horizontal stripes If horizontally aligned black streaks or smears appear:

• The imaging unit may be installed improperly. Remove the imaging unit and reinsert it.

• The imaging unit may be defective. Remove the imaging unit and install a new one (see "Replacing the imaging unit" on page 52).

If the problem persists, the machine may require repairing. Contact a service representative.

Condition Suggested Solutions

Printing quality problems

186

5. Troubleshooting

Curl If the printed paper is curled or paper does not feed into the machine:

• Turn the stack of paper over in the tray. Also try rotating the paper 180° in the tray.

• Change the printer’s paper option and try again. Go to Printing Preferences, click the Paper tab, and set type to Thin (see

"Opening Printing Preferences" on page 36).

•An unknown image

repetitively appears on a few

sheets

•Loose toner

•Light print or contamination

occurs

Your machine is probably being used at an altitude of 1,000 m (3,281 ft) or above.

The high altitude may affect the print quality, such as loose toner or light imaging. Change the altitude setting for your machine (See

"Altitude adjustment" on page 138).

Condition Suggested Solutions

187

5. Troubleshooting

Operating system problems

Common Windows problems

Refer to the Microsoft Windows User’s Guide that came with your computer for further information on Windows error messages.

Condition Suggested solutions

“File in Use” message appears

during installation.

Exit all software applications. Remove all software from the startup group, then restart Windows. Reinstall the printer driver.

“General Protection Fault”,

“Exception OE”, “Spool 32”, or

“Illegal Operation” messages

appear.

Close all other applications, reboot Windows and try printing again.

“Fail To Print”, “A printer

timeout error occurred”

message appear.

These messages may appear during printing. Just keep waiting until the machine finishes printing. If the message appears in ready

mode or after printing has completed, check the connection and/or whether an error has occurred.

Samsung Printer Experience is

not shown when you click more

settings.

Samsung Printer Experience is not installed. Download the app. from the Windows Store and install it.

Machine information is not

displayed when you click the

device in the Devices and

Printers.

Check the Printer properties. Click the Ports tab.

(Control Panel > Devices and Printers > Right-click on your printer icon and select Printer properties)

If the port is set to File or LPT, uncheck them and select TCP/IP, USB, or WSD.

Operating system problems

188

5. Troubleshooting

Common Mac problems

Refer to the Mac User’s Guide that came with your computer for further information on Mac error messages.

Condition Suggested solutions

The machine does not print PDF files

correctly. Some parts of graphics, text, or

illustrations are missing.

Printing the PDF file as an image may enable the file to print. Turn on Print As Image from the Acrobat printing options.

It will take longer to print when you print a PDF file as an image.

Some letters are not displayed normally

during cover page printing.

Mac OS cannot create the font while printing the cover page. The English alphabet and numbers are displayed normally on

the cover page.

When printing a document in Mac with

Acrobat Reader 6.0 or higher, colors

print incorrectly.

Make sure that the resolution setting in your machine driver matches the one in Acrobat Reader.

Operating system problems

189

5. Troubleshooting

Common Linux problems

Refer to the Linux User’s Guide that came with your computer for further information on Linux error messages.

Condition Suggested solutions

Unchecking the collate option

in the Print Dialog does not

work.

For some distributions, GNOME Print Dialog has an issue handling the collate option. As workaround, set the default value of collate

option to False using the system's printing utility(execute "system-config-printer" in the Terminal program).

Printing always works with

duplex.

This duplex issue was in Ubuntu 9.10 CUPS package. Update CUPS version to 1.4.1-5ubuntu2.2.

Printer is not added through

system's printing utility.

The problem occurs on Debian 7 due to the defect in 'system-config-printer' package of the Debian 7 (http://bugs.debian.org/cgi-bin/

bugreport.cgi?bug=662813 in Debian bug tracking system). Please use another way to add printer (CUPS WebUI for example)

Paper size and orientation are

disabled in the Print Dialog

when opening text files.

The problem occurs on Fedora 19 and it's related to 'leafpad' text editor on Fedora 19. Please use other text editors like 'gedit'.

Printing produces divided

images.

This issue exists in openSUSE 13.2 due to wrong ghostscript provided by the system. Update 'cups-filters-ghostscript' package with the

command "zypper install --force cups-filters-ghostscript" or with "Install/Remove Software" utility.

190

Contact SAMSUNG worldwide

If you have any comments or questions regarding Samsung products, contact

the Samsung customer care center.

Country/Region Customer Care Center WebSite

ALGERIA 021 36 11 00 www.samsung.com/

n_africa/support

ARGENTINE 0800-555-SAMSUNG

(0800-555-7267)

www.samsung.com/

ar/support

ARMENIA 0-800-05-555 www.samsung.com/

support

AUSTRALIA 1300 362 603 www.samsung.com/

au/support

AUSTRIA

0800-SAMSUNG (0800-7267864)

[Only for Premium HA] 0800-

366661

[Only for Dealers] 0810-112233

www.samsung.com/

at/support

AZERBAIJAN 0-88-555-55-55 www.samsung.com/

support

BAHRAIN

8000-GSAM (8000-4726) www.samsung.com/

ae/support (English)

www.samsung.com/

ae_ar/support (Arabic)

BELARUS 810-800-500-55-500 www.samsung.com/

support

BANGLADESH 09612300300 www.samsung.com/

in/support

BELGIUM

02-201-24-18 www.samsung.com/

be/support (Dutch)

www.samsung.com/

be_fr/support (French)

BOLIVIA 800-10-7260

[HHP] 4828210

www.samsung.com/

cl/support

BOSNIA 055 233 999 www.samsung.com/

support

BOTSWANA 8007260000 www.samsung.com/

support

BRAZIL

0800-124-421 (Demais cidades e

regiões)

4004-0000 (Capitais e grandes

centros)

www.samsung.com/

br/support

BULGARIA 800 111 31 , Безплатна

телефонна линия

www.samsung.com/

bg/support

BURUNDI 200 www.samsung.com/

support

CAMEROON 7095- 0077 www.samsung.com/

africa_fr/support

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

191

Contact SAMSUNG worldwide

CANADA

1-800-SAMSUNG (726-7864) www.samsung.com/

ca/support(English)

www.samsung.com/

ca_fr/support (French)

CHILE 800-SAMSUNG (726-7864)

[HHP] 02-24828200

www.samsung.com/

cl/support

CHINA 400-810-5858 www.samsung.com/

cn/support

COLOMBIA

Bogotá 600 12 72

Gratis desde cualquier parte del

país 01 8000 112 112 ó desde su

celular #SAM(726)

www.samsung.com/

co/support

COSTA RICA

0-800-507-7267

00-800-1-SAMSUNG (726-7864)

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

CROATIA 072 726 786 www.samsung.com/

hr/support

Cote D’ Ivoire 8000 0077 www.samsung.com/

africa_fr/support

Country/Region Customer Care Center WebSite

CYPRUS 8009 4000 only from landline, toll

free

www.samsung.com/

gr/support

CZECH 800-SAMSUNG (800-726786) www.samsung.com/

cz/support

DENMARK 70 70 19 70 www.samsung.com/

dk/support

DOMINICAN

REPUBLIC

1-800-751-2676 www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

DRC 499999 www.samsung.com/

support

ECUADOR

1-800-10-7267

1-800-SAMSUNG (72-6786)

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/

support(English)

EGYPT 08000-7267864

16580

www.samsung.com/

eg/support

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

192

Contact SAMSUNG worldwide

EIRE 0818 717100 www.samsung.com/

ie/support

EL SALVADOR

800-6225

800-0726-7864

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

ESTONIA 800-7267 www.samsung.com/

ee/support

FINLAND 030-6227 515 www.samsung.com/fi/

support

FRANCE 01 48 63 00 00 www.samsung.com/

fr/support

GERMANY

0180 6 SAMSUNG bzw.

0180 6 7267864*

[HHP] 0180 6 M SAMSUNG bzw.

0180 6 67267864* (*0,20 €/Anruf

aus dem dt. Festnetz, aus dem

Mobilfunk max. 0,60 €/Anruf)

www.samsung.com/

de/support

GEORGIA 0-800-555-555 www.samsung.com/

support

Country/Region Customer Care Center WebSite

GHANA 0800-10077

0302-200077

www.samsung.com/

africa_en/support

GREECE

80111-SAMSUNG (80111 726

7864) only from land line

(+30) 210 6897691 from mobile

and land line

www.samsung.com/

gr/support

GUATEMALA

1-800-299-0013

1-800-299-0033

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

HONDURAS

800-2791-9267

800-2791-9111

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

HONG KONG

(852) 3698 4698 www.samsung.com/

hk/support (Chinese)

www.samsung.com/

hk_en/support

(English)

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

193

Contact SAMSUNG worldwide

HUNGARY 0680SAMSUNG (0680-726-786)

0680PREMIUM (0680-773-648)

www.samsung.com/

hu/support

INDIA 1800 3000 8282 - Toll Free

1800 266 8282 - Toll Free

www.samsung.com/

in/support

INDONESIA 021-56997777

08001128888

www.samsung.com/

id/support

IRAN 021-8255 [CE]

021-42132 [HHP]

www.samsung.com/

iran/support

ITALIA

800-SAMSUNG (800.7267864)

[HHP] 800.Msamsung

(800.67267864)

www.samsung.com/

it/support

JAMAICA

1-800-234-7267

1-800-SAMSUNG (726-7864)

www.samsung.com/

latin_en/support

(English)

JAPAN 0120-363-905 www.samsung.com/

jp/support

JORDAN

0800-22273

06 5777444

www.samsung.com/

levant/support

(English)

KAZAKHSTAN 8-10-800-500-55-500 (GSM:7799,

VIP care 7700)

www.samsung.com/

support

Country/Region Customer Care Center WebSite

KENYA 0800 545 545 www.samsung.com/

support

KUWAIT

183-CALL (183-2255) www.samsung.com/

ae/support (English)

www.samsung.com/

ae_ar/support (Arabic)

KYRGYZSTAN 00-800-500-55-500 www.samsung.com/

kz_ru/support

LATVIA 8000-7267 www.samsung.com/

lv/support

LITHUANIA 8-800-77777 www.samsung.com/

lt/support

LUXEMBURG 261 03 710 www.samsung.com/

support

MACAU 0800 333 www.samsung.com/

support

MACEDONIA 023 207 777

MALAYSIA

1800-88-9999

603-77137477 (Overseas

contact)

www.samsung.com/

my/support

MAURITIUS 23052574020 www.samsung.com/

support

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

194

Contact SAMSUNG worldwide

MEXICO 01-800-SAMSUNG (726-7864) www.samsung.com/

mx/support

MOLDOVA 0-800-614-40 www.samsung.com/

support

MONGOLIA +7-495-363-17-00 www.samsung.com/

support

MONTENEGRO 020 405 888 www.samsung.com/

support

MOROCCO 080 100 2255 www.samsung.com/

n_africa/support

MOZAMBIQUE 847267864 / 827267864 www.samsung.com/

support

MYANMAR +95-01-2399-888 www.samsung.com/

support

NAMIBIA 08 197 267864 www.samsung.com/

support

NIGERIA 0800-726-7864 www.samsung.com/

africa_en/support

NETHERLANDS 0900-SAMSUNG (0900-7267864)

(€ 0,10/Min)

www.samsung.com/

nl/support

NEW ZEALAND 0800 726 786 www.samsung.com/

nz/support

Country/Region Customer Care Center WebSite

NICARAGUA

001-800-5077267 www.samsung.com/

latin/support(Spanish)

www.samsung.com/

latin_en/support

(English)

NORWAY 815 56480 www.samsung.com/

no/support

OMAN

800-SAMSUNG (800 - 726 7864) www.samsung.com/

ae/support (English)

www.samsung.com/

ae_ar/support (Arabic)

PAKISTAN 0800-Samsung (72678) www.samsung.com/

pk/support

PANAMA

800-7267

800-0101

www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

195

Contact SAMSUNG worldwide

PARAGUAY

009-800-542-0001 www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

PERU 0800-777-08 www.samsung.com/

pe/support

PHILIPPINES

1-800-10-7267864 [PLDT]

1-800-8-7267864 [Globe landline

and Mobile]

02-4222111 [Other landline]

www.samsung.com/

ph/support

POLAND

801-172-678* lub +48 22 607-93-

33 *

[HHP] 801-672-678* lub +48 22

607-93-33*

* (koszt połączenia według taryfy

operatora)

www.samsung.com/

pl/support

PORTUGAL 808 20 7267 www.samsung.com/

pt/support

Country/Region Customer Care Center WebSite

PUERTO RICO

1-800-682-3180 www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

QATAR

800-CALL (800-2255) www.samsung.com/

ae/support (English)

www.samsung.com/

ae_ar/support (Arabic)

REUNION 262508869 www.samsung.com/

support

RWANDA 9999 www.samsung.com/

support

ROMANIA

08008 726 78 64 (08008

SAMSUNG )

Apel GRATUIT

www.samsung.com/

ro/support

RUSSIA 8-800-555-55-55 (VIP care 8-800-

555-55-88)

www.samsung.com/

ru/support

SAUDI ARABIA

8002474357 www.samsung.com/

sa/support

www.samsung.com/

sa_en/support

(English)/

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

196

Contact SAMSUNG worldwide

SENEGAL 800-00-0077 www.samsung.com/

africa_fr/support

SERBIA 011 321 6899 www.samsung.com/

rs/support

SINGAPORE 1800-SAMSUNG (726-7864) www.samsung.com/

sg/support

SLOVENIA 080 697 267 (brezplačna številka)

090 726 786 (0,39 EUR/min)

www.samsung.com/

rs/si

SLOVAKIA 0800 - SAMSUNG(0800-726 786) www.samsung.com/

sk/support

SOUTH AFRICA 0860 SAMSUNG (726 7864) www.samsung.com/

support

SPAIN 0034902172678

[HHP] 0034902167267

www.samsung.com/

es/support

SRI LANKA 94117540540 www.samsung.com/

support

SUDAN 1969 www.samsung.com/

support

SWEDEN 0771 726 7864 (0771-SAMSUNG) www.samsung.com/

se/support

Country/Region Customer Care Center WebSite

SWITZERLAND

0800 726 78 64 (0800-SAMSUNG) www.samsung.com/

ch/support (German)

www.samsung.com/

ch_fr/support (French)

SYRIA

18252273 www.samsung.com/

levant/support

(English)

TADJIKISTAN 8-10-800-500-55-500 www.samsung.com/

support

TAIWAN 0800-329999 www.samsung.com/

tw/support

TANZANIA 0800 755 755

0685 889 900

www.samsung.com/

support

THAILAND 0-2689-3232,

1800-29-3232

www.samsung.com/

th/support

TRINIDAD &

TOBAGO

1-800-SAMSUNG (726-7864) www.samsung.com/

latin/support

(Spanish)

www.samsung.com/

latin_en/support

(English)

TURKEY 444 77 11 www.samsung.com/

tr/support

Country/Region Customer Care Center WebSite

Contact SAMSUNG worldwide

197

Contact SAMSUNG worldwide

TUNISIA 80-1000-12 www.samsung.com/

n_africa/support

U.A.E

800-SAMSUNG (800 -726 7864) www.samsung.com/

ae/support (English)

www.samsung.com/

ae_ar/support (Arabic)

UK 0330 SAMSUNG (7267864) www.samsung.com/

uk/support

U.S.A

-Consummer

Electonics

1-800-SAMSUNG (726-7864) www.samsung.com/

us/support

U.S.A

(Mobile Phones)

1-800-SAMSUNG (72-6786)

[HHP] 1-888-987-HELP(4357)

www.samsung.com/

us/support

UGANDA 0800 300 300 www.samsung.com/

support

UKRAINE

0-800-502-000 www.samsung.com/

ua/support (Ukrainian)

www.samsung.com/

ua_ru/support

(Russian)

Country/Region Customer Care Center WebSite

URUGUAY

000- 405-437-33 www.samsung.com/

latin/support(Spanish)

www.samsung.com/

latin_en/

support(English)

UZBEKISTAN 8-10-800-500-55-500 (GSM:

7799)

www.samsung.com/

support

VENEZUELA 0-800-SAMSUNG (726-7864) www.samsung.com/

ve/support

VIETNAM 1800 588 889 www.samsung.com/

vn/support

ZAMBIA 0211 350370 www.samsung.com/

support

Country/Region Customer Care Center WebSite

198

Glossary

The following glossary helps you get familiar with the product by

understanding the terminologies commonly used with printing as well as

mentioned in this user’s guide.

802.11

802.11 is a set of standards for wireless local area network (WLAN)

communication, developed by the IEEE LAN/MAN Standards Committee (IEEE

802).

802.11b/g/n

802.11b/g/n can share same hardware and use the 2.4 GHz band. 802.11b

supports bandwidth up to 11 Mbps, 802.11n supports bandwidth up to 150

Mbps. 802.11b/g/n devices may occasionally suffer interference from

microwave ovens, cordless telephones, and Bluetooth devices.

Access point

Access Point or Wireless Access Point (AP or WAP) is a device that connects

wireless communication devices together on wireless local area networks

(WLAN), and acts as a central transmitter and receiver of WLAN radio signals.

ADF

An Automatic Document Feeder (ADF) is a scanning unit that will automatically

feed an original sheet of paper so that the machine can scan some amount of the

paper at once.

AppleTalk

AppleTalk is a proprietary suite of protocols developed by Apple, Inc for

computer networking. It was included in the original Mac (1984) and is now

deprecated by Apple in favor of TCP/IP networking.

BIT Depth

A computer graphics term describing the number of bits used to represent the

color of a single pixel in a bitmapped image. Higher color depth gives a broader

range of distinct colors. As the number of bits increases, the number of possible

colors becomes impractically large for a color map. 1-bit color is commonly

called as monochrome or black and white.

BMP

A bitmapped graphics format used internally by the Microsoft Windows

graphics subsystem (GDI), and used commonly as a simple graphics file format

on that platform.

Glossary

199

Glossary

BOOTP

Bootstrap Protocol. A network protocol used by a network client to obtain its IP

address automatically. This is usually done in the bootstrap process of

computers or operating systems running on them. The BOOTP servers assign

the IP address from a pool of addresses to each client. BOOTP enables 'diskless

workstation' computers to obtain an IP address prior to loading any advanced

operating system.

CCD

Charge Coupled Device (CCD) is a hardware which enables the scan job. CCD

Locking mechanism is also used to hold the CCD module to prevent any damage

when you move the machine.

Collation

Collation is a process of printing a multiple-copy job in sets. When collation is

selected, the device prints an entire set before printing additional copies.

Control Panel

A control panel is a flat, typically vertical, area where control or monitoring

instruments are displayed. They are typically found in front of the machine.

Coverage

It is the printing term used for a toner usage measurement on printing. For

example, 5% coverage means that an A4 sided paper has about 5% image or text

on it. So, if the paper or original has complicated images or lots of text on it, the

coverage will be higher and at the same time, a toner usage will be as much as

the coverage.

CSV

Comma Separated Values (CSV). A type of file format, CSV is used to exchange

data between disparate applications. The file format, as it is used in Microsoft

Excel, has become a de facto standard throughout the industry, even among

non-Microsoft platforms.

DADF

A Duplex Automatic Document Feeder (DADF) is a scanning unit that will

automatically feed and turn over an original sheet of paper so that the machine

can scan on both sides of the paper.

Default

The value or setting that is in effect when taking a printer out of its box state,

reset, or initialized.

Glossary

200

Glossary

DHCP

A Dynamic Host Configuration Protocol (DHCP) is a client-server networking

protocol. A DHCP server provides configuration parameters specific to the DHCP

client host requesting, generally, information required by the client host to

participate on an IP network. DHCP also provides a mechanism for allocation of

IP addresses to client hosts.

DIMM

Dual Inline Memory Module (DIMM), a small circuit board that holds memory.

DIMM stores all the data within the machine like printing data, received fax data.

DLNA

The Digital Living Network Alliance (DLNA) is a standard that allows devices on

a home network to share information with each other across the network.

DNS

The Domain Name Server (DNS) is a system that stores information associated

with domain names in a distributed database on networks, such as the Internet.

Dot Matrix Printer

A dot matrix printer refers to a type of computer printer with a print head that

runs back and forth on the page and prints by impact, striking an ink-soaked

cloth ribbon against the paper, much like a typewriter.

DPI

Dots Per Inch (DPI) is a measurement of resolution that is used for scanning and

printing. Generally, higher DPI results in a higher resolution, more visible detail

in the image, and a larger file size.

DRPD

Distinctive Ring Pattern Detection. Distinctive Ring is a telephone company

service which enables a user to use a single telephone line to answer several

different telephone numbers.

Duplex

A mechanism that will automatically turn over a sheet of paper so that the

machine can print (or scan) on both sides of the paper. A printer equipped with

a Duplex Unit can print on both sides of paper during one print cycle.

Duty Cycle

Duty cycle is the page quantity which does not affect printer performance for a

month. Generally the printer has the lifespan limitation such as pages per year.

The lifespan means the average capacity of print-outs, usually within the

warranty period. For example, if the duty cycle is 48,000 pages per month

assuming 20 working days, a printer limits 2,400 pages a day.

Glossary

201

Glossary

ECM

Error Correction Mode (ECM) is an optional transmission mode built into Class 1

fax machines or fax modems. It automatically detects and corrects errors in the

fax transmission process that are sometimes caused by telephone line noise.

Emulation

Emulation is a technique of one machine obtaining the same results as another.

An emulator duplicates the functions of one system with a different system, so

that the second system behaves like the first system. Emulation focuses on exact

reproduction of external behavior, which is in contrast to simulation, which

concerns an abstract model of the system being simulated, often considering its

internal state.

Ethernet

Ethernet is a frame-based computer networking technology for local area

networks (LANs). It defines wiring and signaling for the physical layer, and frame

formats and protocols for the media access control (MAC)/data link layer of the

OSI model. Ethernet is mostly standardized as IEEE 802.3. It has become the most

widespread LAN technology in use during the 1990s to the present.

EtherTalk

A suite of protocols developed by Apple Computer for computer networking. It

was included in the original Mac (1984) and is now deprecated by Apple in favor

of TCP/IP networking.

FDI

Foreign Device Interface (FDI) is a card installed inside the machine to allow a

third party device such as a coin operated device or a card reader. Those devices

allow the pay-for-print service on your machine.

FTP

A File Transfer Protocol (FTP) is a commonly used protocol for exchanging files

over any network that supports the TCP/IP protocol (such as the Internet or an

intranet).

Fuser Unit

The part of a laser printer that fuses the toner onto the print media. It consists of

a heat roller and a pressure roller. After toner is transferred onto the paper, the

fuser unit applies heat and pressure to ensure that the toner stays on the paper

permanently, which is why paper is warm when it comes out of a laser printer.

Glossary

202

Glossary

Gateway

A connection between computer networks, or between a computer network

and a telephone line. It is very popular, as it is a computer or a network that

allows access to another computer or network.

Grayscale

A shades of gray that represents light and dark portions of an image when color

images are converted to grayscale; colors are represented by various shades of

gray.

Halftone

An image type that simulates grayscale by varying the number of dots. Highly

colored areas consist of a large number of dots, while lighter areas consist of a

smaller number of dots.

HDD

Hard Disk Drive (HDD), commonly referred to as a hard drive or hard disk, is a

non-volatile storage device which stores digitally-encoded data on rapidly

rotating platters with magnetic surfaces.

IEEE

The Institute of Electrical and Electronics Engineers (IEEE) is an international

non-profit, professional organization for the advancement of technology

related to electricity.

IEEE 1284

The 1284 parallel port standard was developed by the Institute of Electrical and

Electronics Engineers (IEEE). The term "1284-B" refers to a specific connector

type on the end of the parallel cable that attaches to the peripheral (for example,

a printer).

Intranet

A private network that uses Internet Protocols, network connectivity, and

possibly the public telecommunication system to securely share part of an

organization's information or operations with its employees. Sometimes the

term refers only to the most visible service, the internal website.

IP address

An Internet Protocol (IP) address is a unique number that devices use in order to

identify and communicate with each other on a network utilizing the Internet

Protocol standard.

Glossary

203

Glossary

IPM

The Images Per Minute (IPM) is a way of measuring the speed of a printer. An IPM

rate indicates the number of single-sided sheets a printer can complete within

one minute.

IPP

The Internet Printing Protocol (IPP) defines a standard protocol for printing as

well as managing print jobs, media size, resolution, and so forth. IPP can be used

locally or over the Internet to hundreds of printers, and also supports access

control, authentication, and encryption, making it a much more capable and

secure printing solution than older ones.

IPX/SPX

IPX/SPX stands for Internet Packet Exchange/Sequenced Packet Exchange. It is a

networking protocol used by the Novell NetWare operating systems. IPX and

SPX both provide connection services similar to TCP/IP, with the IPX protocol

having similarities to IP, and SPX having similarities to TCP. IPX/SPX was

primarily designed for local area networks (LANs), and is a very efficient protocol

for this purpose (typically its performance exceeds that of TCP/IP on a LAN).

ISO

The International Organization for Standardization (ISO) is an international

standard-setting body composed of representatives from national standards

bodies. It produces world-wide industrial and commercial standards.

ITU-T

The International Telecommunication Union is an international organization

established to standardize and regulate international radio and

telecommunications. Its main tasks include standardization, allocation of the

radio spectrum, and organizing interconnection arrangements between

different countries to allow international phone calls. A -T out of ITU-T indicates

telecommunication.

ITU-T No. 1 chart

Standardized test chart published by ITU-T for document facsimile

transmissions.

JBIG

Joint Bi-level Image Experts Group (JBIG) is an image compression standard with

no loss of accuracy or quality, which was designed for compression of binary

images, particularly for faxes, but can also be used on other images.

JPEG

Joint Photographic Experts Group (JPEG) is a most commonly used standard

method of lossy compression for photographic images. It is the format used for

storing and transmitting photographs on the World Wide Web.

Glossary

204

Glossary

LDAP

The Lightweight Directory Access Protocol (LDAP) is a networking protocol for

querying and modifying directory services running over TCP/IP.

LED

A Light-Emitting Diode (LED) is a semiconductor device that indicates the status

of a machine.

MAC address

Media Access Control (MAC) address is a unique identifier associated with a

network adapter. MAC address is a unique 48-bit identifier usually written as 12

hexadecimal characters grouped in pairs (e. g., 00-00-0c-34-11-4e). This address

is usually hard-coded into a Network Interface Card (NIC) by its manufacturer,

and used as an aid for routers trying to locate machines on large networks.

MFP

Multi Function Peripheral (MFP) is an office machine that includes the following

functionality in one physical body, so as to have a printer, a copier, a fax, a

scanner and etc.

Modified Huffman (MH) is a compression method for decreasing the amount of

data that needs to be transmitted between the fax machines to transfer the

image recommended by ITU-T T.4. MH is a codebook-based run-length

encoding scheme optimized to efficiently compress white space. As most faxes

consist mostly of white space, this minimizes the transmission time of most

faxes.

MMR

Modified Modified READ (MMR) is a compression method recommended by ITU-

T T.6.

Modem

A device that modulates a carrier signal to encode digital information, and also

demodulates such a carrier signal to decode transmitted information.

Modified Read (MR) is a compression method recommended by ITU-T T.4. MR

encodes the first scanned line using MH. The next line is compared to the first,

the differences determined, and then the differences are encoded and

transmitted.

Glossary

205

Glossary

NetWare

A network operating system developed by Novell, Inc. It initially used

cooperative multitasking to run various services on a PC, and the network

protocols were based on the archetypal Xerox XNS stack. Today NetWare

supports TCP/IP as well as IPX/SPX.

OPC

Organic Photo Conductor (OPC) is a mechanism that makes a virtual image for

print using a laser beam emitted from a laser printer, and it is usually green or

rust colored and has a cylinder shape.

An imaging unit containing a drum slowly wears the drum surface by its usage

in the printer, and it should be replaced appropriately since it gets worn from

contact with the cartridge development brush, cleaning mechanism, and paper.

Originals

The first example of something, such as a document, photograph or text, etc,

which is copied, reproduced or translated to produce others, but which is not

itself copied or derived from something else.

OSI

Open Systems Interconnection (OSI) is a model developed by the International

Organization for Standardization (ISO) for communications. OSI offers a

standard, modular approach to network design that divides the required set of

complex functions into manageable, self-contained, functional layers. The layers

are, from top to bottom, Application, Presentation, Session, Transport, Network,

Data Link and Physical.

PABX

A private automatic branch exchange (PABX) is an automatic telephone

switching system within a private enterprise.

PCL

Printer Command Language (PCL) is a Page Description Language (PDL)

developed by HP as a printer protocol and has become an industry standard.

Originally developed for early inkjet printers, PCL has been released in varying

levels for thermal, dot matrix printer, and laser printers.

PDF

Portable Document Format (PDF) is a proprietary file format developed by

Adobe Systems for representing two dimensional documents in a device

independent and resolution independent format.

Glossary

206

Glossary

PostScript

PostScript (PS) is a page description language and programming language used

primarily in the electronic and desktop publishing areas. - that is run in an

interpreter to generate an image.

Printer Driver

A program used to send commands and transfer data from the computer to the

printer.

Print Media

The media like paper, labels, and transparencies which can be used in a printer,

a scanner, a fax or, a copier.

PPM

Pages Per Minute (PPM) is a method of measurement for determining how fast

a printer works, meaning the number of pages a printer can produce in one

minute.

PRN file

An interface for a device driver, this allows software to interact with the device

driver using standard input/output system calls, which simplifies many tasks.

Protocol

A convention or standard that controls or enables the connection,

communication, and data transfer between two computing endpoints.

See PostScript.

PSTN

The Public-Switched Telephone Network (PSTN) is the network of the world's

public circuit-switched telephone networks which, on industrial premises, is

usually routed through the switchboard.

RADIUS

Remote Authentication Dial In User Service (RADIUS) is a protocol for remote

user authentication and accounting. RADIUS enables centralized management

of authentication data such as usernames and passwords using an AAA

(authentication, authorization, and accounting) concept to manage network

access.

Resolution

The sharpness of an image, measured in Dots Per Inch (DPI). The higher the dpi,

the greater the resolution.

Glossary

207

Glossary

SMB

Server Message Block (SMB) is a network protocol mainly applied to share files,

printers, serial ports, and miscellaneous communications between nodes on a

network. It also provides an authenticated Inter-process communication

mechanism.

SMTP

Simple Mail Transfer Protocol (SMTP) is the standard for e-mail transmissions

across the Internet. SMTP is a relatively simple, text-based protocol, where one

or more recipients of a message are specified, and then the message text is

transferred. It is a client-server protocol, where the client transmits an email

message to the server.

SSID

Service Set Identifier (SSID) is a name of a wireless local area network (WLAN). All

wireless devices in a WLAN use the same SSID in order to communicate with

each other. The SSIDs are case-sensitive and have a maximum length of 32

characters.

Subnet Mask

The subnet mask is used in conjunction with the network address to determine

which part of the address is the network address and which part is the host

address.

TCP/IP

The Transmission Control Protocol (TCP) and the Internet Protocol (IP); the set of

communications protocols that implement the protocol stack on which the

Internet and most commercial networks run.

TCR

Transmission Confirmation Report (TCR) provides details of each transmission

such as job status, transmission result and number of pages sent. This report can

be set to print after each job or only after failed transmissions.

TIFF

Tagged Image File Format (TIFF) is a variable-resolution bitmapped image

format. TIFF describes image data that typically come from scanners. TIFF

images make use of tags, keywords defining the characteristics of the image that

is included in the file. This flexible and platform-independent format can be

used for pictures that have been made by various image processing

applications.

Toner Cartridge

A kind of bottle or container used in a machine like a printer which contains

toner. Toner is a powder used in laser printers and photocopiers, which forms

the text and images on the printed paper. Toner can be fused by a combination

of heat/pressure from the fuser, causing it to bind to the fibers in the paper.

Glossary

208

Glossary

TWAIN

An industry standard for scanners and software. By using a TWAIN-compliant

scanner with a TWAIN-compliant program, a scan can be initiated from within

the program. It is an image capture API for Microsoft Windows and Apple Mac

operating systems.

UNC Path

Uniform Naming Convention (UNC) is a standard way to access network shares

in Window NT and other Microsoft products. The format of a UNC path is:

\\<servername>\<sharename>\<Additional directory>

URL

Uniform Resource Locator (URL) is the global address of documents and

resources on the Internet. The first part of the address indicates what protocol to

use, the second part specifies the IP address or the domain name where the

resource is located.

USB

Universal Serial Bus (USB) is a standard that was developed by the USB

Implementers Forum, Inc., to connect computers and peripherals. Unlike the

parallel port, USB is designed to concurrently connect a single computer USB

port to multiple peripherals.

Watermark

A watermark is a recognizable image or pattern in paper that appears lighter

when viewed by transmitted light. Watermarks were first introduced in Bologna,

Italy in 1282; they have been used by papermakers to identify their product, and

also on postage stamps, currency, and other government documents to

discourage counterfeiting.

WEP

Wired Equivalent Privacy (WEP) is a security protocol specified in IEEE 802.11 to

provide the same level of security as that of a wired LAN. WEP provides security

by encrypting data over radio so that it is protected as it is transmitted from one

end point to another.

WIA

Windows Imaging Architecture (WIA) is an imaging architecture that is originally

introduced in Windows Me and Windows XP. A scan can be initiated from within

these operating systems by using a WIA-compliant scanner.

WPA

Wi-Fi Protected Access (WPA) is a class of systems to secure wireless (Wi-Fi)

computer networks, which was created to improve upon the security features of

WEP.

Glossary

209

Glossary

WPA-PSK

WPA-PSK (WPA Pre-Shared Key) is special mode of WPA for small business or

home users. A shared key, or password, is configured in the wireless access point

(WAP) and any wireless laptop or desktop devices. WPA-PSK generates a unique

key for each session between a wireless client and the associated WAP for more

advanced security.

WPS

The Wi-Fi Protected Setup (WPS) is a standard for establishing a wireless home

network. If your wireless access point supports WPS, you can configure the

wireless network connection easily without a computer.

XPS

XML Paper Specification (XPS) is a specification for a Page Description Language

(PDL) and a new document format, which has benefits for portable document

and electronic document, developed by Microsoft. It is an XML-based

specification, based on a new print path and a vector-based device-

independent document format.

210

Index

AirPrint 130

cleaning

inside 54

outside 54

cleaning a machine 54

control panel 20

convention 10

eco printing 38

favorites settings, for printing 37

features 4

print media feature 68

front view 18

general icons 10

glossary 198

google cloud printing 134

jam

clearing paper 59

tips for avoiding paper jams 58

LED

machine status 63

Linux

common Linux problems 189

driver installation for network connected

102

driver installation for USB cable connected

driver reinstallation for USB cable connected

printer properties 150

printing 149

using SetIP 97

paper in the tray1 28

special media 32

Mac

common Mac problems 188

driver installation for network connected

102

driver installation for USB cable connected

driver reinstallation for USB cable connected

printing 147

system requirements 72

using SetIP 97

maintenance parts 43

manual feeder/multi-purpose tray

using special media 32

Mopria 128

network

driver installation

Linux 102

Mac 102

Windows 99

installing environment 73

Index

211

Index

introducing network programs 95

IPv6 configuration 104

SetIP program 96, 97, 116

wired network setup 96

wireless network setup 107

n-up printing

Mac 147

overlay printing

create 145

delete 146

print 146

placing a machine

adjusting the altitude 138

mobile OS 124

mobile print 124

print media

card stock 33

labels 33

output support 68

preprinted paper 34

special media 32

printer preferences

Linux 150

printer status

general information 164

Printing 35

printing

changing the default print settings 139

Linux 149

Mac 147

multiple pages on one sheet of paper

Mac 147

printing a document

Windows 35

printing on both sides of paper

Mac 148

printing to a file 140

setting as a default machine 139

special printer features 141

printing a document

Linux 149

Mac 147

printing feature 139

problem

operating system problems 187

problems

paper feeding problems 173

power problems 174

printing problems 175

printing quality problems 179

rear view 19

regulatiory information 74

safety

information 11

symbols 11

samsung cloud printing 132

samsung printer experience 166

Samsung Printer Status 164

service contact numbers 190

SetIP program 96, 116

special print features 137

specifications 66

print media 68

Index

212

Index

stop button 21

supplies

available supplies 42

estimated toner cartridge life 45

ordering 42

replacing toner cartridge 48

SyncThru Web Service

general information 159

toner cartridge

estimated life 45

handling instructions 45

non-Samsung and refilled 45

redistributing toner 46

replacing the cartridge 48

storing 44

tray

adjusting the width and length 27

changing the tray size 27

understanding the status LED 62

Unix

system requirements 72

USB cable

driver installation 23, 25, 90, 92

driver reinstallation 91, 93

using help 38, 148

watermark

create 144

delete 144

edit 144

Windows

common Windows problems 187

driver installation for network connected 99

driver installation for USB cable connected

23, 25

system requirements 71

using SetIP 96, 116

wireless

WPS

disconnecting 109

PBC mode 109

wireless network

network cable 116

Samsung Electronics Co SLC430 Printer User Manual Part 3

Samsung Electronics Co Ltd Printer Users Manual Part 3

Contents

Users Manual Part 3

Navigation menu

Namespaces

Views

Navigation
