Samsung Electronics Co WEG720B Wi-Fi Transmitter User Manual Operation description WEG720B
Samsung Electronics Co Ltd Wi-Fi Transmitter Operation description WEG720B
User Manual
Manual For WEG720B
Wi-Fi module(2.4 GHz, 5GHz, a/b/g/n, AC)
- Model name : WEG720B
- Operation Temperature : 0℃ ~ +70℃
- Power : +5V ±5% (+4.75V ~ +5.25V)
1. Introduction
WEG720B is a USB embedded module compliant with IEEE802.11ac standard.
The core chipset is from Broadcom, part number is BCM43526KMLG.
And WEG720B automatically discontinue transmission in case of either absence of information
to transmit or operational failure.
Technical Information for FCC
Freq.
(MHz) CH Support
IEEE802.11 and BW Active
Scan Passive
Scan Client
Only DFS Mobile
Hop spot Wi-Fi
Direct
Peer
to
Peer Ad-hoc Radar
Detection
2412 1
802.11b/g/n(HT20)
&
BW = 20MHz YES NO YES NO NO YES YES YES NO
2417 2
2422 3
2427 4
2432 5
2437 6
2442 7
2447 8
2452 9
2457 10
2462 11
2422 3
802.11n(HT40)
&
BW = 40MHz
YES NO YES NO NO YES YES YES NO
2427 4
2432 5
2437 6
2442 7
YES NO YES NO NO YES YES YES NO
2447 8
2452 9
Freq.
(MHz) CH Support
IEEE802.11 and BW Active
Scan Passive
Scan Client
Only DFS Mobile
Hop spot Wi-Fi
Direct
Peer
to
Peer Ad-hoc Radar
Detection
5745 149
802.11a/n(HT20)
/ac(VHT20)
&
BW = 20MHz
YES NO YES NO NO YES YES YES NO
5765 153
5785 157
5805 161
5825 165
5755 151 802.11n(HT40)
/ac(VHT40)
&
BW = 40MHz
YES NO YES NO NO YES YES YES NO
5795 159
5775 155
802.11/ac(VHT80)
&
BW = 80MHz YES NO YES NO NO YES YES YES NO
Freq.
(MHz) CH Support
IEEE802.11 and BW Active
Scan Passive
Scan Client
Only DFS Mobile
Hop spot Wi-Fi
Direct
Peer
to
Peer Ad-hoc Radar
Detection
5180 36
802.11a/n(HT20)
/ac(VHT20)
&
BW=20MHz
YES NO YES NO NO NO NO NO NO
5200 40
5220 44
5240 48
5260 52
NO YES YES YES NO NO NO NO NO
5280 56
5300 60
5320 64
5500 100
NO YES YES YES NO NO NO NO NO
5520 104
5540 108
5560 112
5580 116
5600 120 N/A
This device does not support these channel.
5620 124
5640 128
5660 132
NO YES YES YES NO NO NO NO NO
5680 136
5700 140
5190 38
802.11a/n(HT40)
/ac(VHT40)
&
BW=40MHz
YES NO YES NO NO NO NO NO NO
5230 46
5270 54 NO YES YES YES NO NO NO NO NO
5310 62
5510 102 NO YES YES YES NO NO NO NO NO
5550 110
5590 118 N/A
This device does not support these channel.
5630 126
5670 134 NO YES YES YES NO NO NO NO NO
5210 42
802.11ac(VHT80)
&
BW=80MHz
YES NO YES NO NO NO NO NO NO
5290 58 NO YES YES YES NO NO NO NO NO
5530 106 NO YES YES YES NO NO NO NO NO
Approval Statement
CE Statement
Hereby, we declare that this device is in compliance with the essential requirements and other relevant provisions of directive
1999/5/EC.
FCC Statement
To satisfy FCC exterior labeling requirements, the following text must be placed on the exterior of the end product.
Contains Transmitter module FCC ID: A3LWEG720B
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
This device complies with Part 15 of the FCC`s Rules. Operation is subject to the following two Conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesirable operation.
IC Information
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L'opération est soumise aux deux conditions
suivantes:
(1) cet appareil ne peut causer d'interférences, et
(2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de
l'appareil.
The end product must be labeled to display the Industry Canada certification number of the module.
Contains transmitter module IC: 649E-WEG720B
Le dispositif d'accueil doivent être étiquetés pour afficher le numéro de certification d'Industrie Canada du module.
Contient module émetteur IC : 649E-WEG720B
User Information
This device complies with FCC & IC radiation exposure limits set forth for an uncontrolled environment. This device should be installed
and must not be co-located or operating in conjunction with any other antenna or transmitter.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20cm is maintained between the antenna and users.
2) This module may not be co-located with any other transmitters or antennas.
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for
testing their end-product for any additional compliance requirements with this module installed. In the event that these conditions
cannot be met, then the FCC & IC authorizations are no longer considered valid and the FCC ID cannot be used on the final product. In
these circumstances, the OEM integrator will be responsible for re-evaluating the end product including this module and obtaining
separate FCC & IC authorizations.
Cet appareil est conforme aux limites d'exposition rayonnement de la FCC et IC définies pour un environnement non contrôlé . Cet
appareil doit être installé et ne doit pas être co- localisées ou opérant en conjonction avec une autre antenne ou émetteur .
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes :
1 ) L' antenne doit être installée de telle sorte que 20 cm est maintenue entre l'antenne et les utilisateurs .
2 ) Ce module ne peut pas être co-localisé avec d'autres émetteurs ou des antennes .
Tant que deux conditions ci-dessus sont remplies , nouvel essai de l'émetteur ne sera pas tenu . Cependant , l'intégrateur OEM est
toujours responsable de tester leur produit final pour les exigences de conformité supplémentaires avec ce module installé .Dans le
cas où ces conditions ne peuvent être remplies, les autorisations de la FCC et IC ne sont plus considérés comme valides et l'ID FCC
ne peuvent pas être utilisés sur le produit final . Dans ces circonstances , l'intégrateur OEM sera chargé de réévaluer le produit final
incluant ce module et l'obtention des autorisations de la FCC et IC distincts .
Any changed or modifications not expressly approved by the party responsible for compliance could void the user`s authority to operate
this equipment.
Toute changé ou modifications non expressément approuvés par la partie responsable de la conformité pourraient annuler l'utilisateur
`autorité de faire fonctionner cet équipement.
This device is restricted to indoor use only within the 5.15 ~ 5.25GHz Band.
Cet appareil est restreint à l'utilisation à l'intérieur seulement dans la bande 5.15 ~ 5.25GHz.
