![4Screen displays 1. Connect the narrow end (A) of the USB cable to the USB port of the speaker. 2. Connect the wide end (B) of the USB cable to the USB port ( ) of your PC.It may take about 3 hours to fully charge the battery. However, the charging time can vary depending on the PC specifi cation.Using the BatteryCharge and store the battery within the temperature range of 40°F~95°F (5°C~35°C).Do not charge the battery for more than 12 hours. Over- charging /-/ over-discharging the battery can reduce the battery life.The battery is consumable and can reduce the usable life over time.1(A)2(B)ChargingIf you are using the product for the fi rst time after the purchase or have not been using it for an extended time, fully charge the battery before using the product. The product has equipped with a built-in battery pack.When the battery capacity is less than 30%, the status LED blinks red.If you use the speaker during the charging process, the status LED can not turn green when the charging is complete.Charging: RedCharged: GreenLess than 30% in capacity: RedBetween 30% and 60% in capacity: PurpleMore than 60% in capacity: BlueYou can check the remaining battery capacity by pressing and releasing the [ ] button in the power-on condition. Power buttonPlay / Pause buttonNext / Previous Track buttonOperation Status LEDCharging Status LEDVolume Control buttonDNSe buttonReset holeLine-in cable portUSB cable portCall/End call buttonNeck chain loopMicrophoneBuilt-in speakerNotes](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-6.png)
![5Using BluetoothWhat is Bluetooth?Bluetooth is a computing and telecommunications industry specifi cation that describes how MP3 players, hands-free (mobile phones) and computers can easily interconnect with each other and with home and business phones and computers using a short wireless connection.The Bluetooth device can cause noise or malfunction, depending on the conditions of use.Physical signal interference, for instance, if you carry a mobile phone in the back pocket and wear the speaker in the neck, or if you hold the speaker in the one hand and the mobile phone in the other handPhysical contact on the transmitting or receiving system of an external deviceElectrical variation from electrical jamming by a wall, corner or offi ce partitioningElectrical interference from the same frequency-band devices including medical equipment, microwave oven and wireless LANThe longer the distance between the speaker and the MP3 player or the hands free mobile phone is, the quality will be deteriorated in proportion Besides, if the distance exceeds a certain range, the wireless networking is disconnected.When pairing the Bluetooth device with the product, ensure that the distance is as short as possible.The Bluetooth features of the speaker are optimised with Samsung products. If used with third party products, some of the Bluetooth features may not work properly.Turning on/off the SpeakerIf you want to turn on the stereo speaker, press and hold the [ ] button for more than 2 seconds.The indicator blinks blue.If you want to turn off the stereo speaker, press and hold the [ ] button for more than 2 seconds.Paring the Stereo SpeakerYou must pair the speaker with external devices you use before you can connect it to a Bluetooth mobile phone or other Bluetooth device.When pairing the speaker, it is recommended to maintain the distance of less than 1 meter between the devices.1. In the power-off condition, press and hold the [ ] button for 5 seconds.The left LED blinks blue and red alternately.The pairing standby status lasts about 3 minutes. In those 3 minutes, you should turn off and restart the speaker.2. Select the Bluetooth menu on the Bluetooth device you use.3. Search for Bluetooth devices available on the device you are using and select <YA-BS300> from the search results.When selecting a device to connect, select <Stereo Headset> so that you can listen to music from the speaker.For more information, refer to the device user manual.yyBefore you start!Note](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-7.png)
![64. If you are prompted to enter a pin code or password, enter <0000>.The pairing of the speaker is completedOnce you paired this product, you don’t need to pair it again.Check and remember the pin code of an audio dongle if you connect this product to an audio dongle. If the pin code is other than <0000>, the connection will not be made.If the Bluetooth connection is not made in 5 minutes since its start, the speaker will automatically turn off.You can check the Bluetooth connection status with the indicator.NotesBluetooth Status LED IndicatorPairing Standby Blinks red and greenConnection Standby Blinks red at intervals of 2.5 secondsConnected Blinks blue at intervals of 4 secondsListening to MusicCheck if the speaker is turned on.Check if the speaker is connected to a Bluetooth device.1. Play a music fi le on the connected Bluetooth device. You can also play the music by pressing the [ ] button on the speaker. You don’t need to play the music directly on the connected Bluetooth device.2. Press the [ ] button. You can listen to music through the speaker.During music playback, press and release the [ ] button to pause the playback. Press and hold it for more than 2 seconds to stop playing. Button OperationVolume Control: use the [] button to adjust the volume.You can adjust the volume level from 00 to 15. Previous / Next Track: press the [ ] button.Rewind / Fast Forward: press and hold the [ ] button during music playback.In Bluetooth connection mode, the Bluetooth connection can be terminated if the distance between speaker and Bluetooth device exceeds a certain range. When the distance is narrowed down to a certain range or you restart the speaker, the Bluetooth connection will be automatically be restored.If the speaker has been paired with the Bluetooth device, you can press the [] button to automatically restore the Bluetooth connection even in case of disconnection.yyBefore you start!Notes](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-8.png)
![7Using Call FunctionsCheck if the speaker is turned on.Check if the speaker is connected to a Bluetooth device.Check if your mobile phone supports the appropriate functions before you can use the speaker to make phone conversations. Mobile phones that do not support the voice call function will not allow you to make a voice call through the speaker.Answering a CallPress the [ ] button when you receive an incoming call.You can make phone conversations through the speaker. Call Volume ControlIf you want to adjust the call volume during the conversation, press the [ ] button.Ending a CallWhen the conversation is over, press the [ ] button.Rejecting a CallPress and hold the [ ] button for more than 2 seconds when you receive an incoming call.yyyyBefore you start!DiallingDialling a recent call Press the [ ] button. The most recent call number will be dialled.Making a Call by NumberPress a desired call number on your mobile phone.Press the [ ] button on the speaker. That number will be dialled.Voice DiallingPress and hold the [ ] button for more than 2 seconds and speak out the name after a beep.Switching a CallIf you want to switch a call from mobile phone to speaker, or speaker to mobile phone, press and hold the [ ] button for more than 2 seconds.Depending on the mobile phone model, the most recent call number may be dialed without display on the screen. yyyNote](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-9.png)
![8Making Phone Conversations While Listening to MusicWhen you are listening to music on a MP3 player through the speaker set as <Stereo Headset>, your mobile phone should have been connected as <Handsfree>. If your mobile phone has been connected as <Stereo Headset>, you can answer an incoming call while listening to music.Answering a Call While Listening to Music Press the [ ] button when you hear a ring from the speaker.The music stops and the number will be dialled.Ending a Call When the conversation is over, press the [ ] button.Making a Call While Listening to Music1. Press and hold the [ ] button for more than 2 seconds while listening to music.The player stops playing.2. Press the [ ] button.The most recent call number will be dialled.When the music is stopped, some mobile phones may move to the playlist depending on the model.To exit the playlist, press and hold the [ ] button for more than 2 seconds again.yyyyNoteAnswering Another CallCheck if your mobile phone supports the appropriate function.Normally, this function is available only in GSM phones.Call WaitingPress and release the [ ] button during the conversation.You can put the current call on hold. Press the [ ] button again to disconnect from the waiting person.Answering Another Call During ConversationsIf you receive another call during the conversation, press and release the [ ] button.You can put the current call on hold and answer the second call.If you want to send busy signal to the second call, press and release the [ ] button. If you want to end the current call and answer the second call, press and release the [ ] button.yyyBefore you start! Before you start!](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-10.png)
![9DNSe Sound EffectRepeat pressing the [ ] button until a desired sound effect is selected.Press and hold the [ ] button for more than 2 seconds to check the current sound effect setting. Sound Effect LED IndicatorStandard Blinks once3D Sound Mode Blinks twiceBass Boost Mode Blinksthree times3D & Bass Boost Mode Blinks four times DNSe is a 3D surround sound effect technology developed by Samsung. The 3D technology enhances the surround sound effect, and the bass boost mode reinforces the bass to provide profound sound. DNSe is not enabled if you are listening to music by using the Line-in cable to connect to an external device. Using the Speaker with an External DeviceYou can use the Line-in cable to listen to music through the stereo speaker from an external device that does not even support the Bluetooth functions.1. Use the Line-in cable to connect the output port (or Line-out port) of the external music player to the Line-in port of the speaker.2. Press the Play button on the external music player.You can listen to music through the speaker. Press the [ ] button if you want to make a call or answer an incoming call from the Bluetooth-connected mobile phone while you are listening to music through the speaker using the Line-in cable.NoteNotes](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-11.png)
![10Checklist before Contacting UsPlease check the followings before contacting us if you have a problem with the product.If the problem persists, contact us at the local Samsung Customer Care.Problem Check & ActionThe player does not turn on.If the player runs out of battery, it does not turn on.Charge the battery and try again.Press the [RESET] button to reset the system.No button works properly.Check if you have turned on the product.Press the [RESET] button to reset the player.The battery usable time is different from the specifi cation in the user manual.The battery is consumable and can reduce the usable life over time.The usable time may differ, depending on the sound mode you set.A recharged battery can have less usable time if it is exposed to low or high temperature for an extended time.Music is not playing. Check if the music fi les on the connected mobile phone or the MP3 player are supported by the appropriate device. Problem Check Point & ActionBluetooth connection is not made.Check if the Bluetooth device to use is paired with your player.The Bluetooth connection can be terminated if you turn off and restart the speaker, MP3 player or the mobile phone. In this case, try to connect again.In Bluetooth connection mode, the Bluetooth connection can be terminated if the interval between speaker and Bluetooth device exceeds a certain distance. If the distance is narrowed down to the effective range or you restart the speaker, the Bluetooth connection can be restored.Check if the Line-in cable is properly connected.Some disturbance is heard during phone conversations.Adjust the volume of the speaker or the mobile phone.Move to another place and try again.No phone call is made even when the speaker has been connected to the mobile phone as <Stereo Headset>.Check if the simultaneous connection function is selected in the Bluetooth setting of the mobile phone.](https://usermanual.wiki/Samsung-Electronics-Co/YABS300/User-Guide-823081-Page-12.png)
