Secure Wireless EV-F319 Wireless Remote Control Transmitter User Manual 6658 SW Evol Manual
Secure Wireless, Inc Wireless Remote Control Transmitter 6658 SW Evol Manual
User Manual
LOW BATTERY INDICATION
LED will flash to indicate that Low Battery Supervision
has been sent and the battery should be replaced.
WARRANTY
Secure Wireless offers a Lifetime Warranty on this
product. Secure Wireless agrees to repair or replace this
product at no cost to the user. For return authorization
please contact: Secure Wireless
1185 Park Center Drive, Suite A/B
Vista, CA 92083
(760) 727-0601
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
4 Button Wireless Transmitter
For use with Part #s: EV-F319/EV- F345/EV-F433
USER MANUAL
Button 1
Button 3
Button 2
Button 4
6658-SW-Evol Manual 10/7/02 10:05 PM Page 1
Caution: Any changes or modifications not expressly
approved by Secure Wireless could void user's authority
to operate the equipment.
I . Programming the Remote
into the Alarm System
Refer to the programming guide that came with your
alarm system for programming a wireless device
(KEYFOB) into the security system.
II. Changing Panic Operation
to Delay Mode or Instant Mode
Note: To use this feature you must have programmed
button 4 into the alarm panel as “PANIC”. The 3 second
delay is the factory default.
SETTING PANIC BUTTON FOR
DELAY TRANSMISSION MODE
(By selecting this feature, the user must hold down panic
button for 3 seconds before transmission is sent.)
1. Press all 4 button at the same time until the LED
begins to flash. (This will take approximately
3 seconds before LED flashes.)
2. Release all 4 buttons
3. Press Button 2 (TOP RIGHT BUTTON)
4. LED should stop flashing
SETTING PANIC BUTTON INTO
INSTANCE TRANSMISSION MODE
1. Press all 4 button at the same time until the
LED begins to flash. (This will take
approximately 3 seconds before LED flashes.)
2. Release all 4 buttons
3. Press Button 1 (TOP LEFT BUTTON)
4. LED should stop flashing
6658-SW-Evol Manual 10/7/02 10:05 PM Page 2
