Secure Wireless, Inc Wireless Glass Break
User manual
SW-NAP-GB
Glass Break
NAPCO COMPATIBLE
INSTALLATION MANUAL
TECHNICAL SUPPORT
Secure Wireless 866-908-Tech
www.mysecurewireless.com
GLASS BREAK ENROLLMENT PROGRAMMING
For a detail programming guide, the instruction manual
should be consulted for that panel. The below guide
should only be used as a reference and not as a
replacement for using the programming instructions.
1. ENTER Panel Programming
2. SELECT Zone #
3. ENTER 6 Digit Id Number ( located on back
of unit)
4. ENTER Check sum (0-9 ; A-F) (located on
back on unit. Digit that follows “:” on the
Serial ID
5. ENTER Point “3” – for Glass Break
6. Push On/Off to Save
Alpha Chart
A - *0
C - *2
E - *4
B - *1
D- * 3
F - * 5
Glass Type and Thickness
Plate
1/8 in to ¼ in
Tempered
1/8 in to ¼ in
Sealed Insulating
1/8 to ¼ in
REPLACING THE BATTERY
Remove the detector from the base by turning
counterclockwise. Replace with 2 CR123A batteries.
Observe the polarity when replacing the batteries
FCC Compliance
This device complies with Part 15 FCC Rules. Operation
complies with the following 2 conditions (1) This device
may not cause harmful interference and (2) this device
must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
MODEL
SW-NAP-GB
FCC ID
QNP-GB319
FREQUENCY
319.5 MHz
WARRANTY
Limited Life Time
BATTERY
(2) CR123A Panasonic
MANUAL PART #
200-10008 Rev C
MOUNTING INSTRUCTIONS
1. Place the Glass Break Detector base on the
opposite wall or adjacent wall to the window
being protected (Distance 15 Ft maximum)
2. Attach to the wall using the supplied screws.
The test button should be facing the floor
3. When attaching the detector to the base, match
up to the alignment mark and turn clockwise
FUNCTIONAL TEST:
Push the test button for 2 seconds and then release. The
red LED will light while the button is pressed. The green
LED will blink once to indicate that the unit is in auto test
mode for 90 seconds.
1. Use a glass break simulator to test the unit. LED
will flash green first then will flash LED to
indicate the glass breaking.
WIRELESS RANGE TEST:
Push and hold the test button for 5 seconds and release,
The LED will flash while the button is pressed. The green
LED will blink twice to indicate that the unit is in RF test
mode for 90 seconds.
