Safety recommendations
Carefully read all of the cautions and warnings before using the
radio:
•Do not use the radio equipment for uses different than
those indicated in the present guide.
•For a correct use of the radio read what is listed in this
guide.
•Protect the radio from sprinklings of water and/or other
liquids and from dust.
•Do not bring the radio close to heat sources.
•Do not place the hand-held radio above the airbags or
in their area of action. If the airbag is activated, it may
not swell correctly and/or hurl the portable unit, with
great force, inside the passenger compartment where
are located the vehicle occupants.
•The external antenna connector, not used during normal
operations, must be protected by proper cover.
•First and second maintenance level interventions on
the equipment are to be carried out by authorized
technicians only. Third maintenance level interventions
are to be carried out by SELEX technicians only. The
maintenance levels are defined in the technical manual.
•Use only original accessories and spare parts,
approved by the manufacturer, suitable for the PUMA
T3 PLUS. The use of different accessories and/or spare
parts (earphone, antenna, etc.) makes the safety and
electromagnetic compatibility certifications to be valid
no more and it could lower the user safety level and/or
generate electromagnetic fields that exceed the
accepted limits.
•Follow the battery charger instructions in order to use
it correctly.
•During voice calls, the PUMA T3 PLUS use with its
proper leather bag is recommended in environments
whith temperature greater than 45 °C.
•The emergency call is a priority type call. The hand-
held radio, like all mobile telephony equipment, operates
with radio frequency signals, therefore, the forwarding
of the call depends on the network coverage at the
moment of the call.
•If you need send an emergency call, keep pressed the
emergency button for at least 2 seconds, when the
radio is switched on. In fact, a switched off radio can
be turned on by keeping pressed the emergency key,
but for an outgoing emergency call a new pressure of
the related button must be done.
Relating to the radio setting (from PRP), two cases may
occur if the transmission is inhibit:
a) the emergency call is not sent; it is necessary to
disable the Tx Inhibit function from radio menu to
forward a call (even if the call is an emergency
call).
b) the emergency call is sent and automatically the Tx
Inhibit function is disabled; from radio menu it is
possible to recover the Tx Inhibit function again.
WARNING
This equipment is marked
According to the requirements specified in the R&TTE directive
1999/5/EC and the Commission Decision 6th April 2000, the
EC marking is accompanied by the Class II equipment class
identifier.
The equipment (in the 380÷430 MHz and 410÷470 MHz
versions) is intended for sell and use in AT, BE, CY, CZ, DK, EE,
FI, FR, DE, GR, HU, IE, IT, LV, LT, LU, MT, NL, PL, PT, SK, SI, ES,
SE, GB.
This equipment requires authorization or license for use.
This equipment operates on frequency bands non-harmonised
in the EU.
This equipment can also be used worldwide where the
equipment is approved for use.
FCC APPROVAL
For US owners only
FCC approval
PUMA T3 Plus/806-870 Hand Held equipment complies with
Part 15 of the FCC/Federal Communication Commission
regulations.
Operation is governed by the following:
FCC ID: X5Y774-0788
FCC ID: X5Y774-0788NB
These devices comply with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
- these devices may not cause harmful interference, and
- these devices must accept any interference received,
including interference that may cause undesired
operation.
Any unauthorized modifications or changes to these
devices could void the user's authority to operate these
devices.
Note:
FCC ID X5Y774-0788 and FCC ID X5Y774-0788NB apply to
PUMA T3 Plus/806-870 versions only.
• Hold the radio in a vertical position in front of face with the
microphone (and the other parts of the radio, including the
antenna) at least one inch (2.5 cm) away from the nose. Keeping
the radio at the proper distance is important because RF
exposures decrease with distance from the antenna. Antenna
should be kept away from eyes.
• When worn on the body, always place the radio in a SELEX
Elsag approved clip, holder, holster, case, or body harness for
this product. Using approved body-worn accessories is
important because the use of Selex Elsag or other
manufacturer's non-approved accessories may result in
exposure levels, which exceed the FCC's occupational/
controlled environment RF exposure limits.
• If you are not using a body-worn accessory and are not using
the radio in the intended use position in front of the face, then
ensure the antenna and the radio are kept at least 2.5 cm (one
inch) from the body when transmitting. Keeping the radio at the
proper distance is important because RF exposures decrease
with increasing distance from the antenna.
• Use only SELEX Elsag approved supplied or replacement
antennas, batteries, and accessories. Use of non-manufacturer-
name approved antennas, batteries, and accessories may
exceed the FCC RF exposure guidelines.
• For a list of SELEX Elsag approved accessories (see the user
manual), or (visit the following website which lists approved
accessories: http://intranet.selexelsag.com, or (contact the radio
manufacturer at customer.care@selexelsag.com)
Contact Information
For additional information on exposure requirements or other
information, contact
customer.care@selexelsag.com
P/N MAN-0696/01.01 P/N MAN-0696/01.01 P/N MAN-0696/01.01P/N MAN-0696/01.01
•Carry out the maintenance interventions on the hand held
radio following the instructions given in the technical
manual.
•Follow all accident prevention standards when carrying
out maintenance interventions on the hand held radio
equipment and use the proper tools (spanners,
screwdrivers,…..).
•Do not use the radio if the antenna is damaged.
•Turn off the radio or inhibit transmission, if the equipment
allows it, in electromagnetically sensitive environments
(ex. hospitals, airports, etc.).
•The electronic devices are sensitive to electromagnetic
interference (EMI) if not adequately shielded, designed or
configured differently for electromagnetic fields immunity.
If electromedical equipment (ex. pace-makers, acoustical
equipment, etc.) is used together with the hand held radio,
make sure that it is adequately shielded from external
electromagnetic fields.
•Use only battery chargers recommended by manufacturer
and follow the instructions reported in the manual to
recharge the battery.
•Replace the batteries with equivalent batteries approved
by the manufacturer.
•Replace the batteries following the instructions given in
the technical manual.
•Make sure that batteries are not damaged.
•Do not use the radio if the battery is damaged.
•Position the battery charger far from heat sources and in
such a way as to guarantee its correct aeration as well
as safe accessibility to the network power supply outlet.
Do not use the battery charger outside of the environments
for which it was specified (ex. use in indoor environments
only).
•Do not use the battery charger if the power supply cable
and/or the plug are damaged.
•Do not cause short circuits between the battery terminals,
even if the terminals are provided of protection against
accidental short circuits.
•Do not take the radio into environments that have a
potentially explosive atmosphere (ex. fuel storage sites,
filling stations, etc.). Even when it is off, the radio, being
equipped with battery, might casually trigger fires and/or
explosions.
•Do not use the battery charger in environments that have
a potentially explosive atmosphere (ex. fuel storage sites,
filling stations, etc.). The use of battery charger might
trigger fires and/or explosions.
•The danger of explosion exist if the battery is incorrectly
replaced.
•Even if the battery is discharge, the danger of explosion
exist if the battery is disposed on fire.
•It is advisable the use of the connector covers, when the
connectors are not used during normal operations.
The radio complies with all product specifications and great care
is taken by the manufacturer so that user safety, as far as the
effects of electromagnetic waves on health are concerned, is
guaranteed within the limits established by the international
specifications.In order to further increase the level of user safety,
we invite you to take into consideration the following additional
precautions:
•The radio is equipped with an automatic system to control
the power transmitted so that the radio transmits at the
maximum power only in cases of radio coverage limit or
emergency call. Avoid touching the antenna when the
radio is on and especially during transmission because
the ability of transmitting power gets worse. When the
antenna is touched, the radio automatically transmits at a
greater power level than that required, nevertheless the
communication may be broken down or get qualitatively
worse.
•Avoid touching the equipment during data transmission.
•During voice communications in earphone mode hold the
hand-held radio with the antenna straight and above your
shoulder and speak directly into the microphone.
•Hold the hand-held radio in the vertical position and always
at least 3 cm away from your head during voice
communications in loudspeaker mode.
•Earphone kit (and/or tube audio kit) is recommended when
using the equipment in full-duplex mode for a long time.
•When using the earphone do not allow the cable to twist
up around the radio forming spirals.
WARNING
WARNING
WARNING
PRECAUTION
PRECAUTION
RF energy exposure
RF ENERGY EXPOSURE AWARENESS AND CONTROL
INFORMATION, AND OPERATIONAL INSTRUCTIONS FOR FCC
OCCUPATIONAL USE REQUIREMENTS
BEFORE USING YOUR PORTABLE 2-WAY RADIO, READ THIS
IMPORTANT RF ENERGY AWARENESS AND CONTROL
INFORMATION AND OPERATIONAL INSTRUCTIONS TO ENSURE
COMPLIANCE WITH THE FCC'S RF EXPOSURE GUIDELINES.
NOTICE: This radio is intended for use in occupational/controlled
conditions, where users have full knowledge of their exposure
and can exercise control over their exposure to meet FCC limits.
This radio device is NOT authorized for general population,
consumer, or any other use.
This 2-way radio uses electromagnetic energy in the radio
frequency (RF) spectrum to provide communications between
two or more users over a distance. It uses radio frequency (RF)
energy or radio waves to send and receive calls. RF energy is
one form of electromagnetic energy. Other forms include, but are
not limited to, electric power, sunlight and x-rays. RF energy,
however, should not be confused with these other forms of
electromagnetic energy, which when used improperly can cause
biological damage. Very high levels of x-rays, for example, can
damage tissues and genetic material.
Experts in science, engineering, medicine, health and industry
work with organizations to develop standards for exposure to RF
energy. These standards provide recommended levels of RF
exposure for both workers and the general public. These
recommended RF exposure levels include substantial margins of
protection. All 2-way radios marketed in North America are
designed, manufactured and tested to ensure they meet
government established RF exposure levels. In addition,
manufacturers also recommend specific operating instructions to
users of 2-way radios. These instructions are important because
they inform users about RF energy exposure and provide simple
procedures on how to control it. Please refer to the following
websites for more information on what RF energy exposure is
and how to control your exposure to assure compliance with
established RF exposure limits.
http://www.fcc.gov/oet/rfsafety/rf-faqs.html
http://www.osha.gov/SLTC/radiofrequencyradiation/index.html
Federal Communications Commission Regulations
The FCC rules require manufacturers to comply with the FCC RF
energy exposure limits for portable 2-way radios before they can
be marketed in the U.S. When 2-way radios are used as a
consequence of employment, the FCC requires users to be fully
aware of and able to control their exposure to meet occupational
requirements. Exposure awareness can be facilitated by the use
of a product label directing users to specific user awareness
information. Your SELEX Elsag 2-way radio has a RF exposure
product label. Also, your SELEX Elsag user manual, or product
manual, or separate safety booklet includes information and
operating instructions required to control your RF exposure and to
satisfy compliance requirements.
Compliance with RF Exposure Standards
Your SELEX Elsag 2-way radio is designed and tested to comply
with a number of national and international standards and
guidelines (listed below) for human exposure to radio frequency
electromagnetic energy. This radio complies with the IEEE and
ICNIRP exposure limits for occupational/controlled RF exposure
environment at operating duty factors of up to 25% transmitting
and is authorized by the FCC for occupational use only. In terms of
measuring RF energy for compliance with the FCC exposure
guidelines, your radio radiates measurable RF energy only while it
is transmitting (during talking), not when it is receiving (listening)
or in standby mode.
Note: The approved batteries supplied with this radio are rated for
a 5-5-90 duty factor (5% talk-5% listen - 90% standby), even
though this radio complies with the FCC occupational RF exposure
limits and may operate at duty factors of up to 25% talk.
Your SELEX Elsag 2-way radio complies with the following RF
energy exposure standards and guidelines:
• United States Federal Communications Commission, Code of
Federal Regulations; 47 CFR §§ 1.1307, 1.1310, 2.1091 and
2.1093
• American National Standards Institute (ANSI)/Institute of Electrical
and Electronic Engineers (IEEE) C95. 1-1992
• Institute of Electrical and Electronic Engineers (IEEE) C95.1-
1999 Edition
RF Exposure Compliance and Control Guidelines and
Operating Instructions
To control your exposure and ensure compliance with the
occupational/controlled environment exposure limits always adhere
to the following procedures.
Guidelines:
• Do not remove the RF Exposure Label from the device.
• User awareness instructions should accompany device when
transferred to other users.
• Do not use this device if the operational requirements described
herein are not met.
Operating Instructions:
• Transmit no more than the rated duty factor of 100% of the time.
To transmit (talk), push the Push-To-Talk (PTT) button. To receive
calls, release the PTT button. Transmitting 100% of the time, or
less, is important because this radio generates measurable RF
energy exposure only when transmitting (in terms of measuring
for standards compliance).

Navigation menu
