Sharp BSC0001 Wireless Module User Manual

Sharp Corporation Wireless Module

User manual

26-Aug.-2016 Ver.0.3
SHARP CORPORATION 1/7
RUITZ0004MPZZ
Bluetooth ® low energy Module
Bluetooth® 4.2 low energy
RUITZ0004MPZZ
Data Report
Please note that this manual should not be provided to end-users.
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 2/7
RUITZ0004MPZZ
Control No.
HD-AG-A150049 (1/5)
Control name
General Items
Scope
This specification (“Specification”) applies to the hybrid IC “RUITZ0004MPZZ”, a Bluetooth® 4.2 low
energy module (“Product”).
1. Type: RUITZ0004MPZZ
2. Function:
Radio frequency module. Bluetooth® standard Ver 4.2 low energy conformity
3. Application: Health & Fitness Equipment, Sensor, Toys
4. Note:
a. Regulatory information:
Compliance with each radio law and/or regulation in below listed countries has been
confirmed under the conditions follows:
- Company name of Manufacturer: SHARP CORPORATION
- Equipment name/ Model name: Wireless Module / RUITZ0004MPZZ
- Manufacturing date: traceable from “lot number” shown on device
- Country of origin: JAPAN
- Countries: Canada, Japan, U.S.A.
To maintain the compliance, please install RUITZ0004MPZZ into your final product within the
scope of the specification and regulation of each country.
Japan Regulatory Information
This module is approved with the specific antenna on this module.
a) Please ensure that your product can bear a label with the following information. If the
product is so small that it is not practicable to place the label, please place it in the
instruction manual and package. The mark diameter shall be equal or greater than 3mm.
This product installs a radio system which has been approved as a radio station in a
low power data communication system based on the Radio Law.
RUITZ0004MPZZ : 001-A05676
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 3/7
RUITZ0004MPZZ
Control No.
HD-AG-A150049 (2/5)
Control name
General Items
Canada Regulatory Information
a) This device complies with Industry Canada license-exempt RSS standards. Operation
is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
L'utilisation de ce dispositif est autorisée seulement aux conditions suivantes: (1) il ne
doit pas produire de brouillage et (2) l'utilisateur du dispositif doit être prêt à accepter
tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de
compromettre le fonctionnement du dispositif.
b) This product is certified as type of the portable device with Industry Canada Rules. To
maintain compliance with RF Exposure requirement,please use within specification of
this product.
- IC: 548B-RUITZ0004MP
Ce produit est certifié comme type de l'appareil portable avec Industrie Règles de
Canada. Pour maintenir l'acquiescement avec exigence Exposition de RF, veuillez
utiliser dans spécification de ce produit.
- IC: 548B-RUITZ0004MP
c) Please notify certified ID by either one of the following method on your product.
Specifiez ID certifiée dans votre produit par une de méthode suivante.
-Contains Transmitter module IC : 548B-RUITZ0004MP
-Contains IC : 548B-RUITZ0004MP
Pecifiez ID certifiée dans votre produit par une de méthode suivante.
-Contains Transmitter module IC : 548B-RUITZ0004MP
-Contains IC : 548B-RUITZ0004MP
FCC Regulatory Information
a) This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
b) Please notify certified ID by either one of the following method on your product.
-Contains Transmitter Module FCC ID: APYBSC0001
-Contains FCC ID: APYBSC0001
c) CAUTION: changes or modifications not expressly approved by the party responsible
for compliance could void the use’s authority to operate the equipment.
d) This product is certified as type of the portable device with FCC Rules. To maintain
compliance with RF Exposure requirement, please use within specification of this
product.
- FCC ID: APYBSC0001
e) The antenna used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 4/7
RUITZ0004MPZZ
Control No.
HD-AM-A150049 (1/1)
Control name
Absolute maximum ratings
Absolute maximum ratings
Symbol Parameter Min. Max. Units
VCC_NRF -0.3 +3.6 V
GND 0 V
VIO -0.3 VCC_NRF+ 0.3 V
Storage temperature -40 +85 Deg-C
MSL Moisture Sensitivity Level 3
ESD HBM Human Body Model 1 kV
ESD MM Machine Model 100 V
Endurance Flash Memory Endurance 20000
write/erase
cycles
Retention Flash Memory Retention 10 years At 40 deg-C
Number of times an
address can be written
between erase cycles
2 times
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 5/7
RUITZ0004MPZZ
Control No.
HD-AE-A150049 (1/7)
Control name
Electrical characteristics
Electrical characteristics
Recommendation operating range
Symbol Parameter Min. Typ. Max. Units
VCC_NRF Supply voltage, normal mode 1.8 3.0 3.6 V
VCC_NRF Supply voltage, normal mode,
DC/DC converter output voltage 1.9 V 2.1 3.0 3.6 V
tR_VCC_NRF Supply rise time (0V to 1.8V)*1 100 ms
TA Operation temperature -25 25 75 Deg-C
*1 The on-chip power-on reset circuitry may not function properly for rise times outside the specified
interval. Also after power off, please start up from below 0.3V.
RF Specifications
Symbol Description Min. Typ. Max. Units
Fop Operating frequencies 2402 2480 MHz
PLLres PLL programming resolution 1 MHz
Df Frequency deviation +/-225 +/-250 +/-275 kHz
PRF Maximum output power 4 dBm
PRFC RF power control range 20 24 dB
PRFCR RF power accuracy
+/-4 dB
PWHISP RF power whisper mode -30 dBm
PBW 20 dB bandwidth for modulated carrier 950 1100 kHz
PRF1 1st Adjacent Channel Transmit Power 1 MHz -20 dBc
PRF2 2nd Adjacent Channel Transmit Power 2 MHz -45 dBc
PRXMAX Maximum received signal strength at < 0.1% PER 0 dBm
PSENS IT Receiver sensitivity (0.1% BER) Ideal transmitter -93 dBm
PSENS DT Receiver sensitivity (0.1% BER) dirty transmitter -91 dBm
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 6/7
RUITZ0004MPZZ
Control No.
HD-BA-A150049 (1/2)
Control name
Pin Layout
Pin Descriptions
Pin Pin name Pin
function Description
1 GND Ground Ground (0 V)
2
P0.27
AIN1
XL1
Digital I/O
Analog input
Analog input
General purpose I/O pin
ADC input 1
Crystal connection for 32.768kHz crystal oscillator or
external 32.768kHz crystal reference
3
P0.26
AIN0
XL2
Digital I/O
Analog input
Analog
output
General purpose I/O pin
ADC input 0
Crystal connection for 32.768kHz crystal oscillator
4 P0.21 Digital I/O General purpose I/O pin
5 VCC_NRF Power Power supply
6 AVDD Power Analog Power supply
7 P0.23 Digital I/O General purpose I/O pin
8 P0.17 Digital I/O General purpose I/O pin
9 GND Ground Ground (0 V)
10 DEC2 Power Power supply for low voltage mode
11 P0.19 Digital I/O General purpose I/O pin
12 GND Ground Ground (0 V)
13 OUT_ANT Antenna
In/Out
Internal antenna. It should be connected to Pin 14 OUT_MOD for
normal operation.
14 OUT_MOD RF In/Out
RF I/O pin. It should be connected to Pin 13 OUT_ANT for normal
operation.
15 GND Ground Ground (0 V)
16 SWDIO Digital I/O System reset (active low). Also HW debug and flash programming
I/O
17 SWDCLK Digital input HW debug and flash programming I/O
18 P0.25 Digital I/O General purpose I/O pin
19
P0.03
AIN4
Digital I/O
Analog input
General purpose I/O pin
ADC input 4
20 GND Ground Ground (0 V)
21 P0.01
AIN2
Digital I/O
Analog input
General purpose I/O pin
ADC input 2
22 P0.02
AIN3
Digital I/O
Analog input
General purpose I/O pin
ADC input 3
26-Aug.-2016 Ver.0.3
SHARP CORPORATION 7/7
RUITZ0004MPZZ
Control No.
HD-BA-A150049 (2/2)
Control name
Pin Layout
Pin Pin name Pin
function Description
23 P0.00
AREF0
Digital I/O
Analog input
General purpose I/O pin
ADC Reference voltage
24 DCC Power DC/DC output
25 P0.05
AIN6
Digital I/O
Analog input
General purpose I/O pin
ADC input 6
26
P0.06
AIN7
AREF1
Digital I/O
Analog input
Analog input
General purpose I/O pin
ADC input 7
ADC Reference voltage
27 P0.04
AIN5
Digital I/O
Analog input
General purpose I/O pin
ADC input 5
28 GND Ground Ground (0 V)
