Manual 2
37
e02_dv50_7e.fm
Before Using the Handset
Supportbook (preset) is a simple operation guide on the FOMA terminal
that uses Manga&BookReader. Use this function when unsure of
operations (nP. 375).
For example, when composing a message with Multi Assistant, press $
to use Supportbook (preset) (nP. 404).
Useful tips and functions are explained to allow for rapid comprehension.
Directly start functions that were looked up in Supportbook.
Example: When checking own address
A FOMA card is an IC card that records personal information, such as phone numbers. A
FOMA card can store phonebook data and SMS. By switching FOMA cards, multiple FOMA
terminals can be used for different purposes as needed.
If a FOMA card is not inserted, voice/Videophone calls, PushTalk transmission, i-mode, i-Channel, i-mode mail
and SMS transmission, Message R/F reception and data transmission are not available on the FOMA terminal.
In addition, 1Seg cannot be watched.
Supportbook
Displaying the Supportbook
1In stand-by, press $ ? [A メール] (Mail).
2Select [A 自分のアドレス確認] (Check your own address).
A description appears below the title.
Related Operations
Start functions from Supportbook
In the Supportbook details screen, select the function to start ? [Yes].
Note
Functions cannot be started from Supportbook when functions other than Supportbook are used simultaneously.
FOMA Card
Using a FOMA Card
Details screen
dv50_e.book 37 ページ ２００７年９月７日 金曜日 午前８時４７分
38
e02_dv50_7e.fm
Before Using the Handset
※Refer to step 1 of “Turning the Power Off” on P. 46 to turn off the power, position the back facing upwards and
remove the battery pack. Then insert or remove the FOMA card.
JInserting
Close and hold the FOMA terminal with your both hands when inserting the FOMA card.
JRemoving
Close and hold the FOMA terminal with your both hands when removing the FOMA card.
The FOMA card has a “PIN1 code” and a “PIN2 code”.
Both are set to [0000] by default but can be changed to a four- to eight-digit number by the user (
n
P. 147).
The FOMA card has built-in restriction functions as security functions for protecting personal data and files.
When the FOMA card is inserted into the FOMA terminal and data or files are retrieved using any of the following
methods or when an i-
a
ppli is running, FOMA card restriction functions are automatically set in the retrieved data or files.
When a file such as an image, melody or PDF is downloaded from a site or Internet web page
When a site or Internet web page is saved as a screen memo
When i-mode mail with a file attached is received
When an i-appli is running
Inserting and Removing a FOMA Card
1Hook a finger on the tab (1)
and pull the tray out (2).
Pull out the tray straight out until it stops.
2Hold the FOMA card with the
IC facing up, put on the tray
and set (3).
3Push the tray all the way in
(4).
1Hook a finger on the tab, pull
the guide out (1) and remove
the FOMA card (2).
Do not allow the FOMA card to fall when
removing it.
Note
Inserting or removing the FOMA card forcibly may damage the card or deform the tray. Use caution.
Refer to the FOMA card user’s guide for more information on the FOMA card.
If the FOMA card is inserted into another i-Channel supported terminal,
i-Channel tickers
do not appear. The
i-Channel tickers are automatically shown when the latest information is received or the channel list is shown.
Do not misplace the FOMA card once it is taken out.
The FOMA terminal power may turn off if the IC area of the FOMA card is dirty.
When the tray falls off, slide the tray in straight along the guide rail.
FOMA Card Security Codes
FOMA Card Restriction Functions <FOMA Card Restriction Functions>
1
2
3
4
Tray
Tab
Fit the notch of the FOMA
card to that of the tray.
Notch
IC (gold)
1
2
dv50_e.book 38 ページ ２００７年９月７日 金曜日 午前８時４７分
39
e02_dv50_7e.fm
Before Using the Handset
Data, files or software with FOMA card restriction functions run only when in use with the FOMA card inserted
at time of acquisition. Display, play, attach to i-mode mail, run software, send data using Ir function and iC
transmission function, and copy to microSD Memory Card can be executed.
The following indicates the data for which FOMA card restriction is set.
Melody Image (including animation and Flash movie) Chaku-uta®/Chaku-uta full®
Screen memo File attached to Message R/F ToruCa (details) image
Chara-den Image inserted to Deco-mail or signature Videophone picture memo
i-motion i-appli (including i-appli stand-by) Download dictionary
PDF data Contents transfer compatible data Image in Message R/F
Music&Video Channel program Kisekae Tool
Mail templates with operation restricted data
e-book/e-dictionary/e-comic saved in the [Comic] folder
File attached to i-mode mail (excluding the files listed below)
・ToruCa ・Phonebook ・Schedule ・Bookmark ・Documents
※“Chaku-uta” is a registered trademark of the Sony Music Entertainment (Japan) Inc.
The following indicates the settings saved in FOMA card.
Own number PIN setting SMS expiry
SMS center Language SSL certificates
The above operations cannot be performed if the FOMA card inserted at time of data/file retrieval or i-appli
startup is replaced with a different FOMA card.
※Explanation that follows refers to the FOMA card inserted at time of data/files retrieval as “one’s own FOMA
card” and other FOMA cards as “another’s FOMA card”.
Note
When one’s own FOMA card is replaced with another’s FOMA card, the data or files for which FOMA card
restriction functions are set cannot be set as stand-by displays or ring tones.
When a FOMA card is replaced with another’s FOMA card, FOMA card restriction functions are activated
and if data or file retrieved from a site is set as the stand-by display or ring tone, the setting is reset to the
default. When one’s own FOMA card is re-inserted, the setting returns.
Example: When setting [Melody A], for which FOMA card restriction functions are set, as a ring tone
When one’s own FOMA card is taken out or is replaced with another’s FOMA card, ring tone returns to
default setting. When one’s own FOMA card is put back, the ring tone returns to [Melody A].
FOMA card restrictions functions cannot be set for data received using Ir exchange or data transmission
functions, and still pictures/Continuous mode images/movies shot with the FOMA terminal.
It is possible to move or delete data or files for which FOMA card restriction functions are set even when
another’s FOMA card is inserted.
Running i-appli by selecting highlighted text in i-mode mail display screen cannot be performed or retrieved
when FOMA card restriction functions are set.
If the FOMA card is replaced with another’s FOMA card after i-appli stand-by is set, the set i-appli cannot
be activated in stand-by, and the image set in Stand-by display appears.
One’s own FOMA card
restriction functions are set
for downloaded data, files
attached to received mail
and i-
a
ppli that have been
run, allowing viewing and
playback of data.
When another’s FOMA
card is inserted, data with
one’s own FOMA card
restriction functions set
cannot be viewed or
played back.
One’s own FOMA card
Another’s FOMA card
Different FOMA card inserted
dv50_e.book 39 ページ ２００７年９月７日 金曜日 午前８時４７分
40
e02_dv50_7e.fm
Before Using the Handset
Note the following differences between “FOMA card (blue)” and “FOMA card (green/white)” used
on the FOMA terminal.
Use the battery pack SH14 exclusive to the FOMA terminal.
JInserting the battery pack
Close and hold the FOMA terminal in your both hands before removing.
Differences in FOMA Card Functions
Function FOMA card (blue) FOMA card (green/white) Page
Number of phone number digits
available in the FOMA card phonebook
Up to 20 digits Up to 26 digits P. 108
Client certificate operations for FirstPass Not available Available P. 202
Use of WORLD WING Not available Available P. 449
Service number Not available Available P. 447
About WORLD WING
WORLD WING is a DoCoMo FOMA international roaming service that makes it possible to use the mobile phone
number registered in Japan to make and receive calls while abroad by inserting the FOMA card (green/white) in a
supported FOMA terminal or local mobile phone (W-CDMA or GSM format).
If subscribed to the FOMA service after September 1, 2005, subscription for “WORLD WING” is not
required. However, if subscription for “WORLD WING” is canceled at or after subscription for the FOMA
service, subscription for “WORLD WING” is required again.
If subscribed to the FOMA service before August 31, 2005 but not subscribed to “WORLD WING”,
subscription for “WORLD WING” is required.
Some payment plans are not available.
When the FOMA card (green/white) is lost or stolen overseas, promptly contact NTT DoCoMo and conduct a
procedure for canceling the use of service. Refer to “General Inquiries” on the back of this manual for inquiries.
Note that transmission/calling charges after the FOMA card is lost or stolen are incurred to the subscriber.
Inserting and Removing the Battery Pack
1Lightly push back cover in the
direction of the arrow (1) and
slide approximately 2 mm (2).
2Lift the
back
cover in the
direction of the arrow (3) and
remove it.
3Insert the battery pack (4).
The battery pack has tabs that make it easy
to insert. Attach the battery pack with a
recycle mark side faced up.
4Reattach the
back
cover (5).
Position the back cover as shown in the
illustration and then push the back cover and
slide into place.
1
3
2
2
1
4
Tabs
Face the side with a
recycle mark up
5
Tabs
Battery pack
connection
terminal side
Battery pack
dv50_e.book 40 ページ ２００７年９月７日 金曜日 午前８時４７分
41
e02_dv50_7e.fm
Before Using the Handset
Continued on next page ??
JRemoving the battery pack
Turn the power off, close and hold the FOMA terminal in your both hands before removing.
The battery pack is not fully charged at the time of purchase. Be sure to charge the battery using
the exclusive AC or DC adapter (sold separately) before use.
JEstimated charge times and LED display
The following figures are estimated times for charging an empty battery pack with the FOMA
terminal turned off.
Charging LED illuminates in red when charging and turn off when charging is completed.
Check that the battery pack has been properly inserted when charging LED flashes red. The LED also flashes
red when the battery pack has reached the end of its service life.
The battery pack can also be charged with the FOMA terminal turned on (The
{
on the display flashes during charging).
When charging is complete, charging LED turns off and the { on the display changes to ".
When the battery becomes warm, charging may automatically stop even if the battery has not been fully
charged. Charging resumes after the temperature lowers to an appropriate temperature. While charging is
stopped, charging LED turns off (The { on the display flashes while stopped).
JEstimated times of use when fully charged
1Follow steps 1 and 2 of
“Inserting the battery pack” on
P. 40 to remove the back
cover.
2Remove the battery pack.
The battery pack has a tab that makes it
easy to remove. Press the tab with your
fingers without placing too much force. Lift
the battery pack to remove.
Note
Using unnecessary force when inserting or removing the battery pack may damage the battery pack and
connection terminal (charger terminal) on the FOMA terminal.
Refer to the battery pack SH14 user’s guide for details.
Firmly close the back cover. If not closed firmly, the back cover may come off and the battery pack may fall
out due to vibration.
If the battery pack connection terminal side or FOMA terminal battery pack (charger terminal) is dirty, the
FOMA terminal power may turn off. Additionally, the battery may not be sufficiently recharged. Wipe off any
dirt with a dry cloth or cotton swab.
When using the battery pack for the first time or after replacing it, battery pack must be charged. Battery
pack is not fully charged at the time of purchase.
Charging the FOMA Terminal
Cautions When Charging
Charger name Charge time
FOMA AC Adapter 01/02 Approx. $$ min
FOMA DC Adapter 01/02 Approx. $$ min
Criteria Battery pack SH14
Continuous stand-by time Approx. $$ hours (at rest)/Approx. $$ hours (when mobile)
Continuous talk (transmission) time Approx. $$ min (voice call)/Approx. $$ min (Videophone call: when
sending Chara-den)
Time for watching 1Seg Approx. $$ min
Tab
dv50_e.book 41 ページ ２００７年９月７日 金曜日 午前８時４７分
42
e02_dv50_7e.fm
Before Using the Handset
Continuous talk time is estimated as the usage time at normal transmission signal strength, and continuous
stand-by time is estimated as the usage time while moving with the FOMA terminal closed at normal signal
strength. Talk and stand-by times may be reduced by about half depending on conditions including battery
level status, stand-by display, Power saver mode, Missed call notice and New unread mail notice settings,
temperature and other environmental conditions, and signal strength (no signal or weak signal). Using i-mode
reduces talk (transmission) and stand-by times. When i-Channel is subscribed, information is automatically
received and updated. Talk (transmission) time and stand-by time will be reduced. In addition, when shooting
or editing an image, watching 1Seg, composing i-mode mail, activating the downloaded i-appli or the i-appli
stand-by, or SD-Audio or Music player, the call (transmission)/stand-by duration will be shorten even if calls or
i-mode transmission are not made. Some i-appli software may continue transmission even after downloading.
To avoid this, set not to connect in advance.
The actual usage time is a combination of stand-by time and talk time, and the longer the call duration, the
shorter the stand-by time becomes.
Time for watching 1Seg depends on conditions including battery level status, functions used, temperature and
other environmental conditions.
JBattery pack service life
Battery pack is a consumable product. Service time per charge is gradually reduced every time the battery is charged.
When service time per charge is reduced to about half of the default time, this means that the battery pack is
approaching the end of its service life. In such a case, it is recommended to replace the battery pack as soon
as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life but
this will not cause problems.
If i-appli, Videophone, or 1Seg is used while charging for a long time, the service life of the battery pack may
become shorter than estimated.
To protect the environment, return used batteries to NTT DoCoMo, any DoCoMo retailer, or a
recycling agency.
JAbout charging batteries
Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately), FOMA AC Adapter 01 for Global use (sold
separately), or FOMA DC Adapter 01/02 (sold separately).
FOMA AC Adapter 01 covers only 100 VAC. FOMA AC Adapter 02 covers from 100 VAC through 240 VAC.
FOMA AC Adapter 01 for Global use covers from 100 VAC through 240 VAC, however, the shape of the
power plug for the AC power cable is for 100 VAC (for domestic use). To use the adapter overseas, a
conversion plug adapter that is compatible with the voltage of your country of stay is required. Do not use a
transformer for use overseas to charge the battery.
JCautions when charging
Do not charge for long periods of time with the power left on. If the FOMA terminal is left on after charging is
complete, the battery pack charge decreases.
In such cases, the AC or DC adapter charges the battery again. However, depending on when the FOMA
terminal is disconnected from the AC or DC adapter, the battery charge level may be low, the battery alert
tone may sound, or the battery may only be usable for a short time.
When the battery is empty and terminal is recharging, charging LED may not illuminate immediately.
If the alert tone sounds and the power cannot be turned on, charge the battery for a while.
If the battery empty alert is displayed and charging begins within 60 seconds of the alert tone, the status
returns to normal.
While charging, terminal may not turn on even when charging LED is illuminated in red. Charge longer and try
turning power on again.
Frequently recharging the battery when power is still remaining enough may shorten the life of the battery
pack. It is recommended to use the battery to a certain level before recharging.
The battery pack cannot be charged by itself.
[Read “FOMA AC adapter 01/02 (sold separately) and FOMA DC adapter
01/02 (sold separately) user’s guide” carefully.]
Battery pack can be charged with FOMA terminal open and in the viewer position.
Charging Using the AC Adapter/DC Adapter
dv50_e.book 42 ページ ２００７年９月７日 金曜日 午前８時４７分
43
e02_dv50_7e.fm
Before Using the Handset
Continued on next page ??
1Open the external connector
terminal cover.
2Check the direction (see
diagram) of the AC or DC
adapter connector and insert
horizontally into the external
connector terminal.
Check the direction of the connector, keep it
parallel with the FOMA terminal and firmly
push all the way in until it clicks.
3For an AC adapter, lift the
power plug and insert into a
100 VAC outlet.
For a DC adapter, insert the
power plug into a car cigarette
lighter socket.
Charge start sound is heard and charging
LED illuminate in red. When a call is received
while charging, the call is notified with set
called LED color.
While the stand-by display is shown in the
viewer position, Desktop clock appears on the
display (
n
P. 132).
4When Charge end sound is
heard and charging LED turns
off, charging is complete.
When removing the connector, always hold
the release buttons on both sides (1) and
unplug it by pulling out horizontally (2). Pull
by force may cause a malfunction.
After removing the connecter, close the
external connector terminal cover.
Pull the adapter out of the outlet or cigarette
lighter socket if it will not be used for a long time.
Note
Check the direction and angle (see diagram) of connector, such as an AC adapter, and connect carefully without
using unnecessary force. Do not forcibly insert or remove. May cause damage to the external connector terminal.
Do not forcefully pull the rubber covers on the external connector terminal. May damage the cover.
Do not place objects near the FOMA terminal when charging. The FOMA terminal may be damaged. In
addition, a display may be damaged when charged in the viewer position.
When using a DC adapter
Do not use with the car engine shut off. May drain the car battery.
The DC adapter should only be used in negative grounded vehicles (12 and 24 VDC).
The DC adapter power is interlocked with the car ignition switch, but the interlock may not work with some
vehicles. Make sure that the power is turned off before leaving the car.
Note that even if the FOMA terminal is turned on, turning off the ignition or pulling the DC adapter out of the
cigarette lighter socket will turn the FOMA off. To make a call or stay in stand-by, first disconnect the
connector from the FOMA terminal.
100 VAC outlet
For AC adapter
3
For DC adapter
Cigarette
lighter socket
3
Connector
(Face the side with the arrows up)
2
Release
buttons
1Cover
Charging/Called LED
External connector
terminal
1
2
1
Connector
(Face the side with the arrows up)
4
dv50_e.book 43 ページ ２００７年９月７日 金曜日 午前８時４７分
44
e02_dv50_7e.fm
Before Using the Handset
[Read “Desktop holder SH16 (sold separately) user’s guide” carefully.]
Battery pack can be charged with FOMA terminal open and in the viewer position.
The DC adapter fuse (2A) is a consumable. For replacement, purchase a new fuse at a local automobile
supply shop.
Charging Using the Desktop Holder
1
Face the side with the arrows of
the AC adapter connector up
and insert it into the connector
terminal of the desktop holder.
Keeping the connector parallel with the desktop
holder, firmly push it all the way in until it clicks.
2Lift the AC adapter power plug
and insert into a 100 VAC
outlet.
3Place the FOMA terminal into
the desktop holder.
Place the FOMA terminal as shown in 1 on
the left, and push in the direction of the arrow
shown in 2 until it clicks.
Charge start sound is heard and Charging
LED illuminates in red. When a call is
received while charging, the call is notified
with set called LED color.
While the stand-by display is shown in the
viewer position, Desktop clock appears on
the display (n
P. 132
).
4When Charge end sound is
heard and charging LED turns
off, charging is complete.
Hold the desktop holder and lift the FOMA
terminal out.
Pull the AC adapter out of the outlet when left
unused for a long period of time.
Note
When Charge start sound is not heard (except when Charge start sound is set to [Silent], Manner mode is
set or when terminal is turned off) or when charging LED do not illuminate, check that the FOMA terminal is
placed securely in the desktop holder.
Note
Connector
(Face the side with the arrows up)
FOMA AC
adapter 01/02
100 VAC
outlet
1
2
Connector terminal
Charging/Called LED
3
1
2
Making the desktop holder stand up
Make the stand behind the desktop holder stand up until it clicks so that charging becomes
available with the desktop holder stood up.
Stand
dv50_e.book 44 ページ ２００７年９月７日 金曜日 午前８時４７分
45
e02_dv50_7e.fm
Before Using the Handset
Continued on next page ??
Check the approximate battery level in the display.
[Battery empty. Unsaved data will be lost. Ending current operation] appears if
battery starts to run out (Press t to clear the message).
After a while, an alert tone sounds. The screen on the right appears, handset
operations are disabled and power turns off after approximately 60 seconds.
During a voice/Videophone call, the alert tone sounds and [Battery empty. Unsaved data will be lost. Ending
current operation] appears. The call is disconnected after approximately 20 seconds. At the same time, the
screen above appears and after approximately 60 seconds, the power turns off.
Alert tone does not sound when Manner mode or Public mode (Drive mode) is set (Alert tone sounds during a call).
When H is pressed during a call, the call is disconnected. Turn off the power and recharge the battery.
Before turning the power on, check that the FOMA card is properly inserted (nP. 38).
If the FOMA card is not inserted, [Insert UIM] and a FOMA card error appear (nP. 30).
When placing the FOMA terminal in the desktop holder, be careful that the strap is not caught in between the
handset and the desktop holder.
Battery Level
How to Check the Battery Level
Checking the Battery Level with Sound and Display
1In stand-by, press t ? [Settings] ? [General settings] ? [Check
status] ? [Battery level].
Graphic for battery level appears (A different sound is heard for each battery level).
The battery level sound is heard at the volume set in Key/Standby i-motion (nP. 125).
Wait approximately 2 seconds or press c/t and the previous menu reappears.
If the Battery Runs Out
Power ON/OFF
Turning the Power On and Off
Turning the Power On
Note
When battery icons have been changed (nP. 138), the above icons may differ.
"Battery level is still sufficient.
#Battery level is low.
$Battery is almost empty. Charge the battery.
%Battery is empty (Power will turn off soon).
{Battery pack is being charged.
Graphic
Sound Three beeps Two beeps One beep
Status Battery is sufficiently full. Battery is running low. Battery is almost empty.
Charge the battery.
dv50_e.book 45 ページ ２００７年９月７日 金曜日 午前８時４７分
46
e02_dv50_7e.fm
Before Using the Handset
Switch display language between Japanese and English for functions, messages, and menu items.
1Press H (Power) for 2+ seconds.
It may take some time for the wakeup screen to appear.
The wakeup screen appears followed by the initial settings
screen. Proceed to initial settings (nP. 47). If initial
settings are not yet completed, the setting screen appears
every time the power is turned on.
If initial settings have been completed, the screen shown
on the right appears when power is turned on. This screen
is called the “stand-by display”.
When [Enter PIN1 code] appears, enter the PIN1 code
(nP. 146).
When A (Out of service area) appears, the handset is
outside the service area or in a place with no signal. Move
to a place where the icon disappears.
Note
When a FOMA card is replaced with a new card, the terminal security code (four to eight digits) must be
entered after turning on the terminal. If a correct terminal security code is entered, stand-by display appears.
When a wrong terminal security code is entered five times, the power is turned off. However, turning on the
power again is possible.
Turning the Power Off
1Press H (Power) for 2+ seconds.
It may take some time for the power to be turned off (The end screen appears on the display until the
power is turned off).
Note
Before connecting to an external device, make sure that all transmissions are complete and then turn off the
FOMA terminal.
Select Language
Switching Display to English
1In stand-by, press t ? [Settings] ? [General settings] ? [Select
language] ? [English].
To switch display language from English to Japanese, in stand-by, press t and select [Settings] b
[General settings] b [Select language] b [日本語].
Note
If a FOMA card is inserted, settings are saved to the FOMA card. Select language settings are saved to
FOMA terminal handset and inserted FOMA card. When each setting varies, the setting in FOMA card is
prioritized.
Stand-by display
Japanese display English display
dv50_e.book 46 ページ ２００７年９月７日 金曜日 午前８時４７分
47
e02_dv50_7e.fm
Before Using the Handset
Continued on next page ??
The initial settings screen appears automatically when the power is turned on for the first
time. Each setting item can also be set from Menu (When the initial settings are complete,
the stand-by display appears).
Date and time settings Change terminal security code Key/Standby i-motion
Location provision Font size settings
When items that have not been set remain, the setting screen appears every time the power is turned on.
Set the date and time on the FOMA terminal. Set to automatically correct the date and time.
For overseas use, the settings are automatically corrected to the local date and time.
Initial Settings
Making the Initial Settings
1Set the date and time (nP. 47).
Alternatively, press t in stand-by and select [Settings] b [Initial setting] to perform initial settings.
Set date and time from 00:00 January 1, 2001 to 23:59 December 31, 2050.
2Register a terminal security code (nP. 145).
3Set the Key/Standby i-motion (nP. 125).
Select [ON]/[OFF].
4Set GPS Location provision ON/OFF (nP. 283).
Select [on]/[off].
5Set font size (nP. 141).
Select [Normal]/[Enlarge].
When the initial settings are complete, the software update function confirmation screen appears.
Read the description and select [Agree] (When the initial settings are made from the menu or the
software update is set to other than [auto-update], the confirmation screen does not appears).
Note
Canceling the initial settings
Press H while setting. Date settings are set even if canceled.
Date Settings
Setting the Date and Time
1In stand-by, press t ? [Settings] ? [General settings] ? [Date
settings].
When Limit settings is set to [Enable], terminal security code is required to set
date and time.
Times appear in 24-hour format.
dv50_e.book 47 ページ ２００７年９月７日 金曜日 午前８時４７分
48
e02_dv50_7e.fm
Before Using the Handset
Display your number (caller ID) on the other party’s phone (display) when making a voice/
Videophone call or transmission PushTalk.
Handset number (caller ID) is important personal information. Be very careful about your caller ID setting.
The Notify caller ID function is available only on compatible phone devices.
Set whether or not to send your caller ID using the methods below.
2Select [Auto time correction] ? [ON]/[OFF].
Related Operations
Change the time zone manually <City>
1In stand-by, press t ? [Settings] ? [General settings] ? [Date settings] ? select
[Auto time correction] ? [OFF].
2Press C (City) ? select a time zone ? select a city ? i.
Note
The date and time that are set are saved even if the battery pack is removed, but if the battery pack remains
removed for approximately a week or more or the battery remains empty, the settings may be reset. When
this happens, set again after charging the battery.
If the date and time are not set correctly, date and time are not correctly recorded for Redial, Received
calls, Record message (voice), Record message (Videophone calls), and camera image titles/shooting
date. In addition, functions that use the clock, such as Auto power ON/OFF, Alarm, Schedule, SSL
(authentication), i-appli Auto start, starting i-appliDX, Reception, Recording, and playback or view of
i-motion/music data/e-comic with replay restrictions, cannot be used properly.
When Auto time correction is set to [ON]
The FOMA automatically adjusts the time by connecting to the DoCoMo network’s time information.
When time difference is adjusted, [Time adjusted] appears.
When Auto time correction is set to [ON], the time is sometimes not adjusted for a while. To activate Auto
time correction, turn off FOMA terminal power and restart.
Time is not adjusted depending on the signal status.
Time may be off by a few seconds.
When time difference is adjusted overseas, the local time and date appear in Redial, Received calls,
Received messages (excluding i-mode mail) and Received messages list, and ! appears. The received
messages are not displayed in order of the displayed time and date but the mail reception.
!
does not appear in the
Outbox
and
Unsent messages
for mail messages. If the date order display is set for
the Outbox or Unsent messages, sent messages are displayed in the order of the displayed time and date.
Time correction may not be performed depending on the overseas network.
When Auto time correction is set to [ON] and time correction information is being received from an overseas
network during overseas use, Japan time and local time appear (dual display). When Auto time correction is
set to [OFF], only manually set time appears.
Notify Caller ID
Sending Your Own Phone Number to the Other Party
Method Notify caller ID Do not notify caller ID
To set up in
advance
In stand-by, press t and select [Settings] b
[NW Services] b [Notify caller ID] b [Notify
caller ID]
[Yes] [No]
To automatically correct date and time
[ON] b i
To enter date and time [OFF] b select [Date] b enter date and press t b select [Time]
b enter time and press t b i
Use 24-hour format. When entering month, day and time, add 0
before numbers one through nine (example: 01, 02, 03, etc.).
Alternatively, select numbers with u. If you make a mistake,
move the cursor using v and re-enter.
dv50_e.book 48 ページ ２００７年９月７日 金曜日 午前８時４７分
49
e02_dv50_7e.fm
Before Using the Handset
Notify caller ID cannot be set while A (Out of service area) appears on the screen.
To check the Notify caller ID setting, press t in stand-by, select [Settings] b [NW Services] b [Notify caller
ID] b [Status request].
Specifications made when making a call take priority over the Notify caller ID setting. If no specifications are
made when a call is made, the Notify caller ID setting is followed.
The method for making specifications when making a voice call is enabled for PushTalk. However, specifications
are not made by adding
186
or
184
.
To set up when
making a call
Add 186/184 before a phone number Add 186 Add 184
Enter the phone number and select from the
Submenu (nP. 62)
Press C and
select [Caller ID
setting] b [Send
own no.]
Press C and select
[Caller ID setting] b [No
caller ID]
Own Number
Checking Your Phone Number
1In stand-by, press t0.
Own number screen
If during a voice/Videophone call, press C and select [Own number].
While Function lock is applied to phonebook, enter terminal security code and
press t.
When the 2in1 mode is set to [Dual mode], press i to switch between [Number
A] and [Number B] and view your number.
Refer to P. 418 for details on confirming, saving or changing owner information.
Note
When “Change for the Number B of 2in1” or “FOMA card exchange (2in1 subscriber b 2in1 subscriber)” is
performed while the 2in1 is used, set 2in1 function OFF once and then set the 2in1 setting to ON again or
check 2in1 registration (nP. 419) to receive the correct Number B. Also, when “FOMA card exchange (2in1
subscriber b 2in1 nonsubscriber)” is performed, set 2in1 function OFF to update the correct owner
information.
Method Notify caller ID Do not notify caller ID
dv50_e.book 49 ページ ２００７年９月７日 金曜日 午前８時４７分
509
e23_dv50_7e.fm
Appendix/External Devices/Troubleshooting
Continued on next page ??
This model phone FOMA SH905i meets the MIC’s* technical regulation for exposure to radio waves.
The technical regulation established permitted levels of radio frequency energy, based on standards
that were developed by independent scientific organizations through periodic and thorough evaluation
of scientific studies. The regulation employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)
**
averaged over ten grams of tissue. The limit
includes a substantial safety margin designed to assure the safety of all persons, regardless of age
and health. The value of the limit is equal to the international guidelines recommended by ICNIRP
***
.
All phone models should be confirmed to comply with the regulation, before they are available for sale
to the public. The highest SAR value for this model phone is $$ W/kg. It was taken by the Telecom
Engineering Center (TELEC), a Registered Certification Agency on the Radio Law. The test for SAR
was conducted in accordance with the MIC testing procedure using standard operating positions with
the phone transmitting at its highest permitted power level in all tested frequency bands. While there
may be differences between the SAR levels of various phones and at various positions, they all meet
the MIC’s technical regulation. Although the SAR is determined at the highest certified power level,
the actual SAR of the phone during operation can be well below the maximum value.
For further information about SAR, please see the following websites:
Specific Absorption Rate (SAR)
World Health Organization (WHO)
http://www.who.int/peh-emf/
ICNIRP http://www.icnirp.de/
MIC http://www.tele.soumu.go.jp/e/ele/body/index.htm
TELEC http://www.telec.or.jp/ENG/Index_e.htm
NTT DoCoMo http://www.nttdocomo.co.jp/english/product/
SHARP Corporation
http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.html
* Ministry of Internal Affairs and Communications
**
The technical regulation is provided in Article 14-2 of the Ministry Ordinance Regulating Radio Equipment.
*** International Commission on Non-Ionizing Radiation Protection
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines were developed by the independent scientific organization
ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile
devices is 2 W/kg and the highest SAR value for this device when tested at the ear was $$ W/kg*.
As SAR is measured utilizing the devices highest transmitting power the actual SAR of this device while operating is
typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only
uses the minimum level required to reach the network.
The World Health Organization has stated that present scientific information does not indicate the need for any special
precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so by
limiting the length of calls or using a hands-free device to keep the mobile phone away from the head.
* The tests are carried out in accordance with international guidelines for testing.
Hereby, Sharp Telecommunications of Europe Ltd, declares
that this FOMA SH905i is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original declaration of conformity can be
found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Declaration of Conformity
dv50_e.book 509 ページ ２００７年９月７日 金曜日 午前８時４７分
0.146 W/kg*.
0.298 W/kg.
510
e23_dv50_7e.fm
Appendix/External Devices/Troubleshooting
The Japan Export Control Regulation (“Foreign Exchange and International Trade Law” and its
related laws) will be applied to this product and its accessories under certain conditions. The Export
Administration Regulation is also applied. To export or reexport this terminal and its accessories,
conduct all legally required procedures at your own risk and expense. For details on the procedures,
contact the Ministry of Economy, Trade and Industry or the US Department of Commerce.
FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the
user's authority to operate the equipment.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government.
The guidelines are based on standards that were developed by independent scientific organisations through periodic
and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless handsets employs a unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg.
The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for
each model. The highest SAR value for this model handset when tested for use at the ear is $$ W/kg and when worn on
the body, as described in this user guide, is $$ W/kg.
Body-worn Operation; This device was tested for typical body-worn operations with the back of the handset kept 1.5 cm
from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 1.5 cm
separation distance between the user’s body and the back of the handset. The use of beltclips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements,
and should be avoided.
The FCC has granted an Equipment Authorization for this model handset with all reported SAR levels evaluated as in
compliance with the FCC RF emission guidelines. SAR information on this model handset is on file with the FCC and
can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID APYHRO00061.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet
Association (CTIA) Website at http://www.phonefacts.net.
Japan Export Control Regulation/Export Administration Regulation
dv50_e.book 510 ページ ２００７年９月７日 金曜日 午前８時４７分
0.577 W/kg
0.307 W/kg.
522
e25_dv50_7e.fm
Index/Quick Manual
Remove the Quick Manual attached to the end of this manual by cutting along the dotted
line and fold it as shown below.
Carry the Quick Manual “Overseas Use” when the mobile phone is used with the
international roaming (WORLD WING) overseas.
JFolding the Quick Manual
This manual is produced of recyclable material. Please recycle when no longer needed.
Quick Manual
How to Use the Quick Manual
Warning
Be careful of injuries when cutting out Quick Manual.
FOMA SH905i
FOMA SH905i
FOMA SH905i
FOMA SH905i
<Cut here>
(Completed)
Cut along the dotted line.
dv50_e.book 522 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
FOMA SH905i
General Inquiries <DoCoMo Information Center>
(In English)
s 0120-005-250 (toll free)
※
Can be called from mobile phones and PHSs.
(In Japanese only)
r (No prefix) 151 (toll free)
※
Can only be called from DoCoMo mobile phones and PHSs.
Please confirm the phone number before you dial.
(In Japanese only)
r (No prefix) 113 (toll free)
※
Can only be called from DoCoMo mobile phones and PHSs.
(In Japanese only)
s 0120-800-000 (toll free)
※
Can be called from mobile phones and PHSs.
Please confirm the phone number before you dial.
For further information, refer to the “Service Station List”
included with your FOMA terminal and other devices.
1
In stand-by, press
a
for 1+ seconds
?
[Phone]/[UIM].
2
Enter name
?
t
?
9
/
S
*
?
t
?
phone
number
?
t
?
phone number type (not
applicable for FOMA card)
?
t
?
S
/
T
*
?
t
?
mail address
?
t
?
mail address type (not
applicable for FOMA card)
?
t
.
*
For FOMA cards
3
Press
i
(Complete)
?
memory number (not
applicable for FOMA card).
4
Select PushTalk phonebook entry (not
applicable for FOMA card).
1
In stand-by, press
q
(
M
)
?
phone number
?
C
?
[Add to phonebook].
To save from Redial: In stand-by, press
r
(
I
)
?
phone
number
?
C
?
[Add to phonebook].
2
Select [Save new to phone]
?
save
phonebook.
To save to FOMA card phonebook: Select [Save new to UIM].
To add/overwrite: Select [Add/overwrite].
To add to PushTalk phonebook: Select [PushTalk phonebook].
To add to PushTalk group: Select [Add PushTalk group].
* Cannot be saved to FOMA card.
1
In stand-by, press
a
?
name
?
C
?
[Edit
data]
?
[Edit]
?
item
?
t
?
edit.
1
In stand-by, press
a
.
To change search method: Press
C
in phonebook list
?
[Search by]
?
search method
?
t
.
2
Select name
?
t
?
s
or
t
.
Quick Manual
Registration/Contacts
If you have problems with your FOMA
Add to Phonebook
Saving to Phonebook from Redial and
Received Calls
Items to add
Icon Item
=
Name
B
Reading
Q
Group
9 S
Phone number
9
y
R
u
A
3T
Y
Z
Phone number type
*
S T
Mail address
S c v 7 B U
Mail address type
*
a
Company/School
*
q
Department
*
r
Title
*
N
Postal code
*
O
Postal address
*
j
Location info
*
P
Birthday
*
G
Memo
*
;
Secret
*
F
Secret code
*
<
Select ring tone
*
V
Mail ring tone
*
q
Called LED color
*
-
Called LED pattern
*
:
Mail LED color
*
+
Mail LED pattern
*
8
Picture call set
*
1
Substitute image settings
*
Editing Entries
Making Calls from Phonebook Entries
Icon Item
1
In text input screen, press
a
.
Press
a
to switch from
}
(single-byte numbers)
b
U
(kuten code)
b
>
(kanji/hiragana)
b
[
(double-byte
katakana)
b
^
(single-byte katakana)
b
X
(double-byte
alphanumerics)
b
d
(single-byte alphanumerics).
1
In double-byte/single-byte alphanumeric
mode, press
m
.
Lower case mode is enabled.
To convert to lower case after entering text: Press
m
.
1
After entering text, press
o
.
1
Move the cursor to text and press
c
.
To erase all text: Press
c
for 1+ seconds at the end.
1
In text input screen, press
a
for 1+ seconds
?
categorize phrase
?
t
?
phrase
?
t
?
t
.
1
In text input screen, press
i
(Pict/Sym).
Pictograph mode is activated.
To enter Deco-mail pictographs: Press
i
in pictograph
mode.
The input mode switches between Pictograph and
Pictograph D (Deco-mail pictograph).
To switch symbol mode: Press
C
in pictograph mode.
Press
C
in symbol mode to switch between
upper case and lower case.
1
In text input screen, press
m
for 1+ seconds
?
emoticon
?
t
.
1
In text input screen, move cursor to the first
character to cut
?
press
#
for 1+ seconds.
To copy: In text input screen, press
C
?
[Copy]
?
move
cursor to the first character to copy
?
t
.
2
Move the cursor to the last character to cut/
copy
?
t
.
3
Move the cursor to the paste location
?
press
*
for 1+ seconds.
Ex.)
今日のテニス
3
時
t
1
In text input screen, press
2
twice
?
p
?
[
今
日
]
?
t
.
2
Press
p
?
[
の
]
?
t
.
3
Press
453
?
o
?
[
テニス
]
?
t
.
Use
o
for 1-touch conversion.
4
Press
a
five times
?
3
.
5
Press
a
twice
?
3
twice
?
*
?
p
?
[
時
]
?
t
.
Use
*
for dakuten mark.
6
Press
i
(Pict/Sym)
?
p
?
t
?
t
.
1
In stand-by, press
t
?
[Settings]
?
[Disp/
LED/Power saver]
?
[Font style]
?
[Font style
setting]
?
font.
To set to LC Gothic : Select [LC Gothic].
To set to SH Heisei Mincho: Select [SH Heisei Mincho].
To set to SH Crystal Touch: Select [SH crystal touch].
1
In stand-by, press
t
?
[Settings]
?
[Disp/
LED/Power saver]
?
[Font style]
?
[Font size]
?
[Input]
?
[Maximum]/[Large]/[Normal]/[Small]
?
[Yes].
For Collective setting: Press
5
for 1+ seconds in stand-by.
Text Input
Changing input mode
Entering lower case letters
1-touch conversion
Deleting text
Using phrases
Entering pictographs/symbols/Deco-mail pict
Entering emoticons
Cutting/Copying/Pasting text
Example
Enter hiragana with the dial key.
Every time the key is pressed,
the character changes.
Closest entry appears after
each character is entered.
Select conversion candidates.
Press
m
for lower case.
To enter multiple characters
assigned to the same key,
press
r
to move the
cursor, or after entering a
character, press the same
key for 1+ seconds.
Press
a
five times for
single-byte alphanumeric
mode.
Changing font (font style)
Changing font size
-3--2--1-
-6--5--4- -7-
dv50_e.book 523 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
1
In stand-by, press
C
?
t
(
Y
)
?
t
(Save).
JShoot panoramic pictures
1
In stand-by, press
m
(Panorama)
?
t
(
Y
)
?
move the FOMA terminal to either
direction of left or right
?
t
(End)
?
t
(Save).
1
In still picture shooting screen, press
C
?
[Switch camera-mode]
?
[Movie]
?
t
(Rec)
?
(record)
?
t
(Stop)
?
[Save].
1
In stand-by, press
t
?
[Data box]
?
[My
picture]
?
folder
?
t
?
still picture
?
t
.
1
In stand-by, press
t
?
[Data box]
?
[i-motion]
?
folder
?
t
?
movie
?
t
.
1
In stand-by, press
t
?
[1Seg]
?
[Channel
setting].
2
Select the destination No.
?
C
?
[Auto
channel set]
?
[Yes].
3
Select a region
?
t
?
prefecture/district
?
t
.
4
Press
t
?
[Yes].
1
In stand-by, press
t
?
[1Seg]
?
[Channel
setting]
?
Channel list
?
t
(Set).
1
In stand-by, press
<
(
&
).
To record a movie of 1Seg programs: Press
i
for 1+
seconds while watching 1Seg
?
(record)
?
i
(Stop).
To record 1Seg programs as a still picture: Press
i
for 1+
seconds while watching 1Seg.
1
In stand-by, press
t
?
[Data box]
?
[1Seg]
?
video file
?
t
.
1
In stand-by, press
t
?
[Data box]
?
[MUSIC]
?
data type.
To select from Sent/Received messages history: Select
[Sent messages]/[Rcvd messages]
?
recipient
?
t
?
t
.
To select from mail members: Select [Mail members]
?
member
?
t
.
3
Select [Sub]
?
t
?
enter subject
?
t
?
[Msg]
?
t
?
enter message
?
t
?
i
(Send).
J
Paste Position location URL to i-mode mail text
1
In message entry screen, press
C
?
[Location info]
?
[From position loc.]
?
location information
?
t
?
[Yes].
Camera
Shoot still picture
Shoot movie
Viewing still pictures
Viewing movies
Watching 1Seg
Performing the Automatic Channel Setting
Selecting a Channel List
Watching 1Seg
Watching Video
Music Playback
Playing back with Music player
Chaku-uta full
®
[i-mode]
?
music data
?
t
WMA file [WMA]
?
folder type
?
t
?
folder
?
t
?
music data
?
t
Data in [Multimedia] [i-mode]
?
m
(
b
microSD)
?
[Multimedia]
?
music data
?
t
Playlist [Playlist]
?
playlist
?
m
(Play)
Key operations during playback
To pause
t
To st o p
m
To adjust volume
p
/
o
To play previous
song/To return to
beginning of song
q
To play next song
r
To end Music player
c
/
H
?
[Yes]
Mail
Composing/Sending i-mode Mail
1
In stand-by, press
m
for 1+ seconds
?
[To]
?
t
.
2
Select [Direct input]
?
enter address
?
t
.
To select from phonebook:
Select [Search phonebook]
?
recipient
?
t
.
1
In message entry screen, press
C
?
[Decorate
mail]
?
select decoration
?
enter text
?
C
?
[Preview]
?
t
(Agree)
?
t
?
i
(Send).
1
In stand-by, press
m
for 1+ seconds
?
attachment entry field
?
t
?
file to attach.
1
In stand-by, press
m
?
[Compose SMS]
?
[To]
?
t
?
[Direct input]
?
enter address
?
t
?
[Msg]
?
t
?
enter message
?
t
?
i
(Send).
1
In stand-by, press
m
?
[Mail setting]
?
[Receive opt. setting]
?
[ON]
?
[Yes].
1
In stand-by, press
m
?
[Check new
message].
For SMS: Press
m
?
[SMS check].
1
Open i-mode mail
?
C
?
[Reply/Forward].
2
Select [Reply].
To quote message and reply: Select [Reply with quote].
3
Compose and send i-mode mail.
1
Open i-mode mail
?
C
?
[Reply/Forward]
?
[Forward].
2
Compose and send i-mode mail.
1
In stand-by, press
t
?
select menu from
Custom menu
?
t
?
function
?
t
.
1
In Custom menu screen, press
m
(Basic).
For Basic menu: Press
m
(Custom).
1
In stand-by, press
t
?
function number in
Basic menu.
Sending Deco-mail
Attaching a file
[Image]
?
folder
?
t
?
?
i
[Melody]
?
folder
?
t
?
melody
?
i
[i-motion]
?
folder
?
t
?
movie/i-motion
?
i
[ToruCa]
?
folder
?
t
?
Tor u C a
?
i
[PDF]
?
folder
?
t
?
PDF data
?
i
[Phonebook]
?
[phone]
?
name
?
t
[Schedule]
?
[phone]
?
date
?
i
?
schedule
?
t
[Bookmark]
?
[i-mode]/[Full Browser]
?
folder
?
t
?
bookmark
?
t
[Document]
?
file
?
i
[Other]
?
file
?
t
Composing/Sending SMS (Short Messages)
Auto receive
1
i-mode mail is
automatically
received.
2
Select [Mail]
?
t
?
folder
?
t
?
mail
?
t
.
Received mail appears.
Receive option setting
Check new messages
Replying to i-mode mail
Forwarding i-mode mail
Menu List
Selecting from Custom menu
Switching Custom menu/Basic menu
Recalling function number
Sound
U
Snd/
Vibrator/
Manner
U
Select volume phone ring vol, Mail ring
vol, PushTalk tone vol,
Key/Standby i-motion,
Charge start sound,
Charge end sound, Timer
sound, GPS volume
V
Select sound Select ring tone, Select
mail tone, PushTalk tone,
Shutter sound, Timer
sound, GPS tone
W
Vibrator Vibration mode, Mail
vibration, GPS vibrator
X
Manner mode ON (Normal, Silent,
Original), OFF
Y
Earphone setting
Z
Ring time
setting
Mail ring time set, PT ring
time set, GPS ring time set
[
Set mute ring time
\
Hold/On hold
tone
Set on hold tone, Set hold
tone
]
Sound plybck
(melody)
Stereo effects, Equalizer,
Run music settings
-9- -10- -11--8-
-13- -14- -15--12-
dv50_e.book 524 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
Display
V
Disp/
LED/
Power
saver
U
Set screen Stand-by display, Clock
display, Calendar display,
Desktop clock
V
Font style Font style setting, Font size
W
Themes Kisekae Tool, Call/Rcv
display, Send/Rcv display,
Submenu image, Dial
image set, Animate notices,
Signal/batt/s clock, Color
theme setting
X
LED settings Called LED, Mail LED,
In-call LED, Alarm/Timer
LED, IC card LED, Open/
close LED, Notice LED,
GPS LED
Y
Display img
quality
Vibrant image mode,
Control by scene
Z
Power saver
set
Normal(auto bright),
Normal(fixed bright), Eco
mode (Pwr saver), Original
Eco mode
[
Private filter Linked manner, Filter
density
\
Menu priority
General Settings
W
General
settings
U
Check status Owner Information, Check
memory, Battery level,
Check settings
V
Text input
setting
User dictionary, Dwnld
dictionary, Edit phrase,
Clear memory terms
W
Auto power
ON/OFF
Auto power ON, Auto
power OFF, Link alarm/
power ON
X
Date settings
Y
Select language
Z
TOUCH
CRUISER set
Usage settings, Pointer
speed, Scroll speed,
Double tap speed
[
USB mode setting
\
Scanning
function
Update, Set auto-update,
Set scan, Version
]
Software update
T
Reset settings
NW Services
X
NW
Services
U
Voice Mail Check messages, Play
Messages, Activate
VoiceMail, Set ring time,
Deactivate VoiceMail,
Status(Voice Mail), Voice
Mail setting, Notification
setting, Notification
V
Call waiting Activate, Deactivate, Status
request
W
Call
forwarding
Activate, Deactivate,
Register number,
Forwarding No. busy,
Status request
X
Bar nuisance
calls
Register caller, Register
selected No, Delete all
entries, Delete last entry,
Check No of entries
Y
Notify caller
ID
Status request, Notify caller ID
Z
Caller ID
request
Activate, Deactivate, Status
request
[
Talk time/cost
X
NW
Services
\
2in1 setting Mode switching,
Phonebook 2in1 set,
Stand-by display, Set call/
receive No., 2in1 function
OFF, Receive avoidance
]
In-call arrival
act
Set arrival act, Arrival Call
Act
Other NW Services
Y
Other
NW
Services
U
Remote
control
Activate, Deactivate, Status
request
V
Dual network Switching, Status request
W
English
guidance
Guidance setting, Status
request
X
Service
number
ドコモ故障問合せ
,
ドコモ
総合案内・受付
Y
Additional
service
USSD, Reply message
Z
Multi number Set multi number, Status
request, Number setting
[
Chaku-moji Create message, Message
display
\
Roaming
guidance
Activate, Deactivate, Status
request
Phone settings
Z
Phone
settings
U
In-call settings Noise reduction,
Reconnect, Quality alarm
V
Headset sw to call
W
Incoming
settings
Any key answer, Set auto
answer, Melody Call setting
X
Videophone
set
Redial voice call, Set
sending image, Display
setting, Subscreen
position, Visual preference,
Notify switch mode,
Hands-free V.phone,
Packet trans arr act
Y
Record
message
Record message,
Answering duration, Reply
message, V.phone reply
Z
Set PushTalk Set PT arrival act,
Hands-free PT
[
Set when
folded
Phone/Videophone,
PushTalk
\
Self mode
]
Other settings Int’l prefix, Sub address,
Int’l dial assist, International
Roam., In-area status
Security
[
Security
U
Secret mode
V
UIM Settings PIN1 code input set,
Change PIN1 code,
Change PIN2 code
W
Accept/Reject
calls
Accept calls, Reject calls,
Reject unknown, Reject user
unset, Reject payphone,
Reject not support
X
Show call/
received
Show rcvd calls, Show
redial
Y
Show sent/
received
Show sent messages,
Show rcvd messages
Z
Lock settings All lock, Keypad dial lock,
Function lock, IC card lock,
Multi easy lock set, Multi
lock auto-set
[
Change security code
\
Writing authentic
]
Delete all data Delete user data, Del
secret data
Other settings
\
Initial settings
T
Own number
Data box
]U
Data
box
U
My picture
V
MUSIC
W
Music&Video ch
X
i-motion
Y
1Seg
Z
Melody
[
My Documents
\
Kisekae Tool
]
Chara-den
T
Print setting(DPOF)
LifeKit
]V
LifeKit
U
Bar code reader
V
Receive Ir data
W
microSD
manager
View microSD data,
Backup/restore, Import,
New manager info, Format,
USB mode setting
]V
LifeKit
X
GPS menu Position location, i-
a
ppli,
Location history, Set
position loc.,
Loc.notification/set, Loc.
request menu
Y
Card reader
Z
Schedule
[
Calculator
\
Text memo
]
Timer/Alarm Timer, Alarm, Wakeup TV
T
Voice memo/Rec msg
R
Character reader
S
Data Sec. Service
Media tool
]W
Media
tool
U
Voice recorder
V
Manga&BookReader
W
Document Viewer
X
PDF Viewer
]X
MUSIC menu
]Y
Osaifu-Keitai menu
]Z
1Seg menu
-17- -18- -19--16-
-21- -22- -23--20-
dv50_e.book 525 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
※
In the confirmation screen, select [Yes] and press
t
.
Voice Mail Service is a paid option (monthly fees apply) that
requires subscription.
1
In stand-by, press
t
?
[Settings]
?
[NW
Services]
?
[Voice Mail].
2
Select [Activate VoiceMail]
?
[Activate
VoiceMail].
To deactivate: Select [Deactivate VoiceMail].
To play message: Select [Play Messages].
To check for messages: Select [Check messages].
Call Waiting is a paid option (monthly fees apply) that
requires subscription.
1
In stand-by, press
t
?
[Settings]
?
[NW
Services]
?
[Call waiting].
2
Select [Activate].
To deactivate: Select [Deactivate].
To request status: Select [Status request].
J
Place current call on hold and answer a voice
call
1
Beeps during call
?
s
?
call
?
H
?
s
?
call.
Call Forwarding Service is a free option that requires
subscription.
1
In stand-by, press
t
?
[Settings]
?
[NW
Services]
?
[Call forwarding].
2
Select [Activate].
To deactivate: Select [Deactivate].
To request status: Select [Status request].
3
Select [Forwarding number]
?
[Input directly]
?
enter forwarding number
?
t
?
[Set ring
time]
?
enter ringing time
?
t
?
[Activate].
Subscription is not required (no monthly fees).
1
In stand-by, press
t
?
[Settings]
?
[NW
Services]
?
[Caller ID request].
2
Select [Activate].
To deactivate: Select [Deactivate].
To request status: Select [Status request].
Other Functions
Manner mode enable/
disable Press
#
for 1+ seconds
Public mode (Drive mode)
activate/deactivate Press
*
for 1+ seconds
Multi easy lock
activate/deactivate Press
t
for 1+ seconds
Show Redial
r
Show Received calls
q
Show i-Channel properties Press
c
(
J
)/
c
(
J
) for
1+ seconds
Show Active marker
p
Show i-mode menu
i
Show i-
a
ppli software list
screen
Press
i
(
,
) for 1+
seconds
Activate Record message/
Voice memo Press
7
for 1+ seconds
Font Size
Collective setting/Individual
setting
Press
5
for 1+ seconds
Display Mail menu
m
View phonebook
a
Activate camera
(still picture mode)
C
Activate camera
(movie mode)
In still picture shooting
screen, press
C
?
[Switch
camera-mode]
?
[Movie]
Display Data box Press
C
for 1+ seconds
Supportbook (preset) In stand-by, press
$
Activate Multi Assistant
(Multitask)
$
while running an
application
Display Shortcut menu
o
Register Shortcut menu Press
$
for 1+ seconds
when
m
appears
Earpiece Volume During call, press
o
/
p
Side Key Guard Set/
Disable
Press
&
(
q
) for 1+
seconds
Private filter ON/OFF Press
:
(
N
) for 1+
seconds
Activate Music player Press
:
(
r
) for 1+
seconds in the viewer
position/when FOMA
terminal is closed
Network Services
Voice Mail Service
Call Waiting
Call Forwarding Service
Caller ID Request Service
※
Refer to P. 28 to P. 30 of Manual for detailed
explanations on displayed icons.
Icon List
Upper Part of the Main Display
123456789a b
v
efg hi jkd
u wt
l m
pq so r
cxy n
z
1]
Signal strength indicator
2"
/
{
Battery level/Charging
37=AAB
NO
i-mode/Full Browser
4o
SSL indicator
5GNIQ
i-
a
ppli indicator
6AB
GPS indicator
7m
Shortcut menu registration indicator
8UhHv[
i-mode mail/SMS Area mail
received
9AB
GISTz8
<9>07!
Message R/F icon
a^
microSD Memory Card indicator
b
Clock display
c
Multitask
d\
Alarm
e;
Hands-free
fRSTU
VWKX
Restriction enabled
gY
IC Card lock
hWX
Storage status of i-mode center
i_
Public mode (Drive mode)
jZ
Manner mode active
kb
Vibrator enabled
l[
Silent
m]
D
to
Pk
Record message
nP
Private filter
oR
/
B
FOMA card error
pg
Self mode enabled
qa
PushTalk in progress
r45
3G/GSM setting
sJtu
Ir exchange/External device indicator
tx
FOMA USB cable is connected
us
Earphone/Microphone connected
v=;
i-mode mail send reservation
w0
Music&Video Channel program
reservation
xQ
View ToruCa
yIH
Status of Comics setting
za
1Seg being recorded
<Emergency contacts in case
of loss or other accidents>
Omakase Lock
※
Omakase Lock is a paid service.
If Omakase Lock is subscribed while or at the
same time as when the use of FOMA terminal is
suspended, the usage fee of Omakase Lock is
not charged.
Enable/Disable Omakase Lock
s 0120-524-360
Office hours: 24hours
Other contacts
<Contacts: >
<Contacts: >
<Contacts: >
※Please confirm the phone number before
you dial.
-25- -26- -27--24-
-29- -30- -31--28-
dv50_e.book 526 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
FOMA SH905i
For DoCoMo mobile phones
*
Communication charges to Japan will apply when you
make a call from a fixed-line telephone.
※
If you use the SH905i, you should dial the number
+81-3-5366-3114 (to dial “+”, press the “0” key for over a
second).
For fixed-line telephones
<Universal number>
*
Communication charges or other charges to your country
of stay will apply.
※
See P.13 and P.14 for international call access codes of
major countries (Table1) and international prefix number for
the universal number (Table2).
For DoCoMo mobile phones
*
Communication charges to Japan will apply when you
make a call from a fixed-line telephone.
※
If you use the SH905i, you should dial the number
+81-3-6718-1414 (to dial “+”, press the “0” key for over a
second).
For fixed-line telephones
<Universal number>
*
Communication charges or other charges to your country
of stay will apply.
※
See P.13 and P.14 for international call access codes of
major countries (Table1) and international prefix number for
the universal number (Table2).
1
In stand-by, press
i
?
[iMenu]
?
[English
iMenu]
?
[Options]
?
[International Settings]
?
[i-mode services Settings]
?
[Yes]
?
enter
i-mode password
?
[OK]
?
t
.
1
In stand-by, press
t
?
[Settings]
?
[Other NW
Services]
?
[Remote control]
?
[Yes].
1
In stand-by, press
t
?
[Settings]
?
[General
settings]
?
[Date settings]
?
[Auto time
correction]
?
[ON]
?
i
.
1
In stand-by, press
t
?
[Settings]
?
[General
settings]
?
[Date settings]
?
[Auto time
correction]
?
[OFF].
2
Press
C
(City)
?
time zone
?
t
?
city
?
t
?
i
.
1
In stand-by, press
t
?
[Settings]
?
[Phone
setting]
?
[Other settings]
?
[International
Roam.]
?
[3G/GSM setting]
?
[Automatic]/[3G]/
[GSM/GPRS].
Quick Manual “Overseas Use”
Loss or theft of FOMA terminal or payment of
cumulative cost overseas
<DoCoMo Information Center>
(24-hour service)
International call access code
of your country of stay (Table 1)
-81-3-5366-3114
*
(toll free)
International prefix number for
the universal number (Table 2)
-800-0120-0151*
Failures encountered overseas
<Network Technical Operation Center>
(24-hour service)
International call access code
of your country of stay (Table 1)
-81-3-6718-1414
*
(toll free)
International prefix number for
the universal number (Table 2)
-800-5931-8600*
Preparing for Oversea Use
Setting i-mode
Setting Remote Access
Correct the Date and Time
Automatically
Set the Time Zone Manually
Available Network
3G network Available
GSM network Available
GPRS network Available
Setting Network Communication System
Default setting: [Auto] (Automatically switches to a
telecommunications carrier)
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Network search mode].
2
Select [Auto]
?
[Yes].
To manually switch telecommunications carriers: Select
[Manual]
?
telecommunications carrier
?
t
.
JSearching the host network again
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Network search mode]
?
[Network re-search].
When Network search setting is [Auto], automatically
switches an available carrier.
When Network search setting is [Manual], displays the
list of carriers. Select a carrier.
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Network search mode]
?
[PLMN
setting]
?
numbers of carriers in the priority
order
?
C
.
2
Select [UPLMN manual]
?
enter country code
(MCC)
?
t
?
enter network code (MNC)
?
t
?
[Yes].
To select from a telecommunications carrier list: Select
[UPLMN by list]
?
telecommunications carrier
?
t
?
[Yes].
To save the telecommunications carrier currently
connected to: Select [Set VPLMN to PLMN]
?
[Yes].
To change priority: Select [Change priority]
?
destination
?
t
?
[Yes]. If Network search mode is set to [Auto], reset Network search
mode to the FOMA network (DoCoMo) automatically when the
power is turned on.
JSetting to the FOMA network (DoCoMo)
manually
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Network search mode].
2
Select [Manual]
?
[DoCoMo].
Services Available Overseas
Communication
service
Explanation
Voice call Make or receive calls in your country
of stay or make international calls to
Japan or to other countries with the
same phone number as used in Japan
while abroad.
Videophone Make international Videophone calls to
users of the specified 3G carriers
overseas and FOMA users in Japan.
i-mode mail Send/receive i-mode mail overseas with
the same address as used in Japan.
i-mode Use i-mode overseas.
i-Channel Use i-Channel overseas.
SMS (Short
Messages)
Send/receive SMS overseas with the
same phone number as used in Japan.
Data
communication
Data communication (Packet
transmission and 64K data
communications), which are performed
by connecting the FOMA terminal to a
PC, are available.
Setting a Search Method of Carrier
Network search mode
Setting a Carrier to Preferentially
Connect to
Displaying a Carrier on the Stand-by
Setting After Homecoming
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other
settings]
?
[International Roam.]
?
[Operator name disp]
?
[display ON]
?
[Yes].
A carrier
-3--2--1-
-6--5--4- -7-
dv50_e.book 527 ページ ２００７年９月７日 金曜日 午前８時４７分
<Cut here>
JUse + to make an international call
1
In stand-by, press
0
1+ seconds
?
enter
country code, area code (city code) and
other party’s phone number
?
s
(Phone)/
i
(V.phone)
?
[Yes].
Enter
81
as a country code to make an international call to Japan.
When the area code (city code) begins with
0
, omit the
0
when dialing. However, include
0
when making a call to
some countries or regions such as Italy.
JMaking an international call outside your
country of stay using country code
conversion
0
at the beginning of a phone number is automatically
converted to the country code set in Country code
conversion.
Example : Make a call from phonebook
1
In stand-by, press
a
?
select person to call
?
s
(Phone)/
i
(V.phone)
?
[Call].
JInternational call
Save a country number using Set country code to select a
country code before making an international call.
The following operation is available overseas only.
1
In stand-by, enter phone number
?
C
?
[Add prefix setting]
?
[International Call]
?
select country code
?
t
?
s
(Phone)/
i
(V.phone).
1
In stand-by, enter phone number
?
s
(Phone)/
i
(V.phone).
JMaking a call to the phone in your country
of stay using phonebook
1
In stand-by, press
a
?
select person to
call
?
s
(Phone)/
i
(V.phone)
?
[Original
number]
?
t
.
JMaking a call to a WORLD WING subscriber
overseas
Even when making a call to the phone in your country of
stay, make an international call to Japan if the call recipient
is a “WORLD WING” subscriber.
1
In stand-by, press
0
1+ seconds
?
81
?
enter the other party’s phone number
excluding 0
?
s
(Phone)/
i
(V.phone)
?
[Yes].
1
Press
s
to answer an incoming call.
JHaving calls to your FOMA phone made
from Japan
Enter the phone number in the same way as it is entered in
Japan and make a call.
JHaving calls to your FOMA phone made
from countries other than Japan
Enter international access code of the country of the
caller-81-user’s phone number excluding
0
and make a call.
Set only in Japan.
1
In stand-by, press
t
?
[Settings]
?
[Phone settings]
?
[Other NW Services]
?
[Roaming guidance].
2
Select [Activate].
To deactivate: Select [Deactivate].
To request status: Select [Status request].
Set only in Japan.
1In stand-by, press t ? [Settings] ?
[Phone
settings]
?
[Other settings]
? [International
Roam.] ? [Call barring].
2
Select [Activate]
?
[Bar all incoming]/[Bar
V.phone/64K]
?
enter network security code
?
t
.
To deactivate: Select [Deactivate]
?
enter network security
code
?
t
.
To request status: Select [Status request].
Operate according to voice guidance.
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Voice Mail(Int.)].
2
Select [Activate Voice Mail].
To deactivate: Select [Deactivate VoiceMail].
To play message: Select [Play Messages].
To set Voice Mail Service: Select [Voice Mail settings].
Operate according to voice guidance.
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Call Forward (Int.)].
2
Select [Activate Call Forwarding].
To deactivate: Select [Deactivate Call Forwarding].
1
In stand-by, press
t
?
[Settings]
?
[Phone
settings]
?
[Other settings]
?
[International
Roam.]
?
[Roam. guidance(Int.)]
?
operate
according to voice guidance.
Making Calls
Making a call to other countries from your
country of stay (includes Japan)
Making a call to the phone in your country of stay
Receiving Calls
Setting Roaming Guidance
Call Barring
Using Network Service
Voice Mail (Int.)
Call Forwarding (Int.)
Roaming guidance (Int.)
The following shows “Country code” used when making
international calls or setting International dial assist.
(As of $$ 2007)
※
For other country codes and details, refer to the “DoCoMo
global service web page”.
The following shows the International call access codes of
major countries.
(As of $$ 2007)
The following shows the International prefix number for the
universal number of each country.
(As of $$ 2007)
For lost, stolen, and cost settlement, or
malfunction of the FOMA terminal overseas,
refer to “Loss or theft of FOMA terminal or
payment of cumulative cost overseas” on the
cover of Quick Manual “Overseas Use” or
“Failures encountered overseas” on P.1.
Add “international call access code” of your country of stay
that is assigned to your country of stay, or the “international
prefix number for the universal number”, to the head of
your phone number for inquiries.
Country Codes of Major Countries
Country/region Code Country/region Code
Australia 61 Maldives 960
Austria 43 Netherlands 31
Belgium 32 New Caledonia 687
Brazil 55 New Zealand 64
Canada 1 Norway 47
China 86 Peru 51
Czech 420 Philippines 63
Egypt 20 Russia 7
Fiji 679 Singapore 65
Finland 358 South Korea 82
France 33 Spain 34
Germany 49 Sweden 46
Greece 30 Switzerland 41
Hong Kong 852 Tahiti (French
Polynesia)
689
Hungary 36
India 91 Taiwan 886
Indonesia 62 Thailand 66
Italy 39 Turkey 90
Japan 81 U.K. 44
Macao 853 U.S.A. 1
Malaysia 60 Vietnam 84
International Call Access Codes of
Major Countries (Table 1)
Country/region Code Country/region Code
Australia 0011 Malaysia 00
Belgium 00 Monaco 00
Brazil 0041/
0021/
0023
Netherlands 00
New Zealand 00
Norway 00
Canada 011 Philippines 00
China 00 Poland 00
Czech 00 Portugal 00
Denmark 00 Russia 810
Finland 00/990 Singapore 001
France 00 South Korea 001
Germany 00 Spain 00
Greece 00 Sweden 00
Hong Kong 001 Switzerland 00
Hungary 00 Taiwan 002
India 00 Thailand 001
Indonesia 001 Turkey 00
Ireland 00 U.A.E. 00
Italy 00 U.K. 00
Luxemburg 00 U.S.A. 011
Macao 00 Vietnam 00
International Prefix Number for the
Universal Number (Table 2)
Country/region Code Country/region Code
Argentina 00 Luxemburg 00
Australia 0011 Malaysia 00
Austria 00 Netherlands 00
Belgium 00 New Zealand 00
Brazil 0021 Norway 00
Canada 011 Philippines 00
China 00 Singapore 001
Columbia 009 South Korea 001
Denmark 00 Spain 00
France 00 Sweden 00
Germany 00 Switzerland 00
Hong Kong 001 Taiwan 00
Ireland 00 Thailand 001
Israel 014 U.K. 00
Italy 00 U.S.A. 011
About Inquiries Overseas
-9- -10- -11--8-
-13- -14- -15--12-
dv50_e.book 528 ページ ２００７年９月７日 金曜日 午前８時４７分
e25_dv50_7e.fm
Please Follow Proper Etiquette
When using your FOMA terminal, please be considerate of those around you.
■
When in an area where use is prohibited
There are places where the use of mobile phones is prohibited. Be sure to turn off your FOMA
terminal in the following places.
★
On an airplane
★
In a hospital
※
There are people outside hospital wards who also use electric medical equipment. Please make
sure that your FOMA terminal is turned off in the lobby and waiting room.
■
While driving
Talking on FOMA terminal while driving is dangerous and may result in an accident.
※
Please pull over to a safe place and use your FOMA terminal or set Public mode (Drive mode).
■
When in crowded places such as rush-hour trains in case somebody nearby is
using an implanted cardiac pacemaker or implanted cardioverter-defibrillator
Your FOMA terminal may affect the operation of such equipment.
■
When in public places such as theaters, movie theaters, or museums
Use of your FOMA terminal in quiet public places will annoy others.
■
When using your FOMA terminal in a restaurant or a hotel lobby, lower your voice.
■
In crowded places, be careful not to obstruct other pedestrians.
Turn Off Your FOMA Terminal in the Following Places
Be Careful of Where You Use Your FOMA Terminal and the Volume of
Your Voice and the Ring Tone
Be Considerate of the Privacy of the Individuals Around You
tPlease be considerate of the privacy of individuals around you when taking and sending images
using camera-equipped mobile phones.
There are useful functions you can use to set your FOMA terminal not to answer
incoming calls, and to silence all sounds.
●
Manner mode (
n
P. 129)/Original manner mode (
n
P. 130)
Silences the Key/Standby i-motion sound and all the sounds from the FOMA terminal, and
Record message is set (Manner mode). When in Manner mode, automatically set functions
(Record message, Vibrator, Mic sensitivity up, Ring tone, Mail ring tone, alarm tone, Key/
Standby i-motion sound, and Low battery alarm) can be set to ON (enable)/OFF (disable)
(Original manner mode).
●
Public mode (Drive mode) (
n
P. 72)
The caller hears a guidance message that informs the receiver is driving and unable to
answer. The call then disconnects. Your FOMA terminal does not sound even when it
receives calls, so you can drive safely.
●
Vibration mode (
n
P. 127)
Notifies incoming calls by vibration.
●
Record message (
n
P. 76)
When you are unable to take a call, the Record message function records the caller’s message.
※
You can also use optional services such as Voice Mail Service (
n
P. 440) and Call Forwarding
Service (
n
P. 443).
The Following Functions Will Help You to Keep Your Manners in Public
dv50_e.book 529 ページ ２００７年９月７日 金曜日 午前８時４７分
