Before Using the Handset
※Key illustrations are examples and may look different from actual keys.
Component names and functions
r
f
e
g
d
c
3
1
8
6
7
5
u
t
2
b
q
l
a
9h
k
j
jp
o
m
is
n
4
dv55_E.book 30 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[31/58]
31
Continued on next page
Before Using the Handset
1Earpiece
Listen to the other party’s voice.
Listen to Record message/Voice memo.
2Brightness sensor (nP. 118)
The sensor detects the light of the surrounding area and
automatically adjusts the display brightness and turns on/off the
keypad backlight.
Do not cover the sensor area with your hand or a sticker. May
interfere with the sensor.
3Display/Touch panel (nP. 34, P. 41)
4Optical TOUCH CRUISER , (nP. 39)
Slide the finger to perform the same operations as those for w
of Multi-guide key.
5i-mode/Operation guidance key i (,)
Press to use i-mode (nP. 170).
Press to execute the functions of the operation guidance
(nP. 34).
Press for 1+ seconds to display the i-appli software list screen
(nP. 231).
6External connector terminal
Connect to an external device such as AC adapter/DC adapter,
FOMA USB Cable with Charge Function 01/02 (sold separately)
(nP. 52, P. 342).
Use a flat-plug earphone/microphone with switch (sold
separately), etc. by connecting to an Earphone Plug Adapter for
External connector terminal (nP. 400).
7Mail/Operation guidance key m
Press to use mail functions (nP. 196).
Press to execute the functions of the operation guidance
(nP. 34).
Press twice to check new messages (nP. 207).
Press for 1+ seconds to display a compose message screen
(nP. 196).
8Start/Hands-free key s
Press to make or receive a voice call.
Press to use Hands-free (nP. 61).
Press for 1+ seconds to use the Eco mode (Power saver)
(nP. 117).
9Charger terminal (nP. 53)
Terminal for recharging with the desktop holder.
amicroSD Card slot (nP. 333)
bMouthpiece
Sends out your own voice.
cMulti-guide key wt
Move the cursor to select an item and execute or set (nP. 34).
Press to display Menu, Redial list screen, Received calls list
screen, Shortcut menu and Quick search.
Press t for 1+ seconds to use Multi easy lock (nP. 136).
Press r for 1+ seconds to use IC card lock (nP. 263).
Press q for 1+ seconds to use Side key guard (nP. 137).
Press u for 1+ seconds to adjust the earpiece volume
(nP. 110).
dCamera/Operation guidance key C
Press to activate the camera (nP. 151).
Press to execute the functions of the operation guidance
(nP. 34).
Press for 1+ seconds to activate 1Seg (nP. 285).
ePhonebook/Operation guidance key a
Press to use the phonebook (nP. 96).
Press to execute the functions of the operation guidance
(nP. 34).
Press for 1+ seconds to display the phonebook entry screen
(nP. 97).
fi-Channel/Clear key c (J)
Press to show the channel list (nP. 192).
Press to return to the previous screen.
Use to delete phone numbers and text.
gPower/End key H
Press for 2+ seconds to turn the power on/off (nP. 55).
Use to end the function being used and return to stand-by
display.
dv55_E.book 31 ページ ２００８年４月１７日　木曜日　午後２時１２分
32
e02_dv55_7e.fm
[32/58]
Before Using the Handset
hDial/Text entry keys 1 to 9, 0, *, #
Press to enter a phone number or text.
Press * for 1+ seconds to use the Public mode (Drive mode)
(nP. 74).
Press # for 1+ seconds to use the Manner mode (nP. 113).
Press 1 to 3 for 1+ seconds to use assigned functions
(nP. 393).
Press 5 for 1+ seconds to set font size collectively (nP. 125).
Press 6 for 1+ seconds to place the Bluetooth on stand-by
(nP. 406).
Press 7 for 1+ seconds to record Voice memos or play Voice
memos/Recorded messages (nP. 79, P. 396).
Press 8 for 1+ seconds to start to use 2in1 or switch modes
(nP. 435, P. 436).
Press 9 for 1+ seconds to reset Kisekae Tool settings
(nP. 120).
iMulti/GPS/Supportbook key $
Press to view Supportbook (nP. 46).
Press to use Multi Assistant (nP. 382).
Press for 1+ seconds to check your present location (nP. 266).
jSpeakers
Emits ring tones, music, etc.
Emits the other party’s voice during hands-free operation.
k/lCalled LED/Charging LED
Flashes while receiving a call, etc. (nP. 123).
Only l stays lit while charging (nP. 51).
mShutter/PushTalk key < (q)
Press to use the PushTalk phonebook (nP. 90).
Press for 1+ seconds with the FOMA terminal closed to turn on/
off the picture light.
Press in the viewer position to activate the camera (nP. 151).
Press for 1+ seconds in the viewer position to activate 1Seg
(nP. 286).
nFOMA antenna
An antenna is built in. To speak in better conditions, do not cover
the antenna area by hand.
o1Seg antenna (nP. 283)
Use to receive 1Seg.
pCamera
Use to shoot still pictures or movies (nP. 144).
Use to send a camera image shot during a Videophone call to
the other party (nP. 60).
qPicture light
Lights while activating the camera (nP. 151).
Lights/Flashes during shooting (nP. 153, P. 155).
rInfrared port
Use for the Ir exchange (nP. 349).
Use for the Ir remote control (nP. 353).
sStrap ring
tFeliCa mark
The IC card is included (The IC card cannot be removed). Use
Osaifu-Keitai holding the FeliCa mark up to the scanning device
(nP. 255).
Use to send and receive data via the iC transmission
(nP. 354).
uBack cover (nP. 50)
A radio frequency-preventing sticker is attached on the back of
the back cover. Do not peel off this sticker.
dv55_E.book 32 ページ ２００８年４月１７日　木曜日　午後２時１２分
33
e02_dv55_7e.fm
[33/58]
Before Using the Handset
To use the FOMA terminal, open it (normal position) or use it in the
viewer position.
When carrying, keeping the FOMA terminal closed as shown in the
diagram for step 1 is recommended.
■Viewer position
How to open the FOMA terminal
1
Open carefully with both
hands.
2
Open the display until it
stops midway.
3
Rotate the display 180°
to the right.
4
Flip the display forward.
5
Note
Note the following when rotating the FOMA terminal display.
Do not hit the key surface, etc. May damage the key surface
(See “Cautions when rotating” above).
Do not rotate in the opposite direction or further than 180°.
Cautions when rotating
dv55_E.book 33 ページ ２００８年４月１７日　木曜日　午後２時１２分
34
e02_dv55_7e.fm
[34/58]
Before Using the Handset
Use to select or execute the menus that appear in the operation
guidance. The following shows the keys allotted to select or execute
the menus items that appear in the guidance.
■Operation guidance menu
In the operation guidance, menus appear according to the used
function and situation.
The following table describes examples of the main operation
guidance menus that appear.
1Signal status
When A appears, the handset is outside the service area or in
a place with no signal. Signal icon can be changed (nP. 121).
How to use the Multi-guide key and Operation
guidance key
OK Sets the selected item
Submenu Displays the Submenu
Agree Checks selected image, music, etc.
Back Returns to the previous screen
Play/Stop Plays/Stops i-motion, music, etc.
Full Displays selected images, etc. in full screen
Show all Displays sorted files, etc. as a list
1/1 or ZoomeDisplays selected images, etc. in actual/reduced
size
Mail Displays the compose message screen
Send Sends a message
Cancel
Cancels the operation such as receiving a message
ituC
avm
SelAll/ClrAll Selects/Disables all selectable items
(Up to 50 items can be selected/disabled
depending on the function)
Page
▲
/Page
▼
Scrolls the display by page
Close Closes the Submenu, etc.
Viewing the display
]Indication of the signal strength
]no p
Strong Weak
dv55_E.book 34 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[35/58]
35
Continued on next page
Before Using the Handset
2Battery level/Charging (nP. 54)
Battery icon can be changed (nP. 121).
3i-mode/Full Browser (nP. 170, P. 303)
4SSL (nP. 171)
When o appears while Multi Assistant is used, function such as
i-mode, Full Browser, i-appli or Software update is being used
with Multi Assistant.
5i-appli (nP. 231)
* Indicates that i-appli is set as the stand-by display, but cannot be
used.
6GPS (nP. 266, P. 273)
7Shortcut menu (nP. 393)
8i-mode mail/SMS/Area Mail received (nP. 205)
9Message R/F (nP. 221)
The status may not always be indicated even if messages are
held at the i-mode center.
amicroSD Card (nP. 332)
bClock display (nP. 57)
Small clock icon can be changed (nP. 121).
c1Seg being recorded (nP. 291)
dRecord message (nP. 77)
When there are messages, D to P appears, indicating the total
number of both types of messages. When there are three Record
messages (voice calls) and two Record messages (Videophone),
k appears.
"Battery level
{Charging
7 = A A
B N OIndicates i-mode/Full browser status
oSSL compatible sites are viewed
SSL compatible Internet web pages are viewed
Gi-appli is being activated
i-appli stand-by is being activated
Ni-appli stand-by is set*
Ii-appliDX is being activated
i-appliDX stand-by is being activated
Qi-appliDX stand-by is set*
A (blue)
Location request menu is set to [Loc. provision:ON]
Location request menu is set to [Permission sched.]
and Location provision is permitted
A (black) Location request menu is set to [Permission sched.]
and Location provision is rejected
BGPS positioning
mAppears when the function can be added to the
Shortcut menu
U h H
v [
Indicates the status of the i-mode mail/SMS/Area
Mail reception
Indicates the status of the memory to store received
mail
ABGIST
z8<9>0
7!
Indicates the reception status of the Message
R/F
Indicates the storage status of the Message
R/F
^ (gray) microSD Card is inserted
^ (pink) microSD Card is being used
a1Seg is being recorded
]Record message is set
dv55_E.book 35 ページ ２００８年４月１７日　木曜日　午後２時１２分
36
e02_dv55_7e.fm
[36/58]
Before Using the Handset
eSilent (nP. 109)
fVibrator (nP. 111)
gManner mode (nP. 113)
hPublic mode (Drive mode) (nP. 74)
iStorage status of i-mode center (nP. 205)
jIC card lock (nP. 263)
kRestriction indicator (nP. 132, P. 138)
lHands-free (nP. 61, P. 81, P. 87, P. 407)
mAlarm (nP. 293, P. 294, P. 385, P. 390)
* Appears only when an Alarm is set for that day.
nMusic&Video Channel program reservation (nP. 365)
oi-mode mail send reservation (nP. 204)
pEarphone/microphone connection (nP. 401)
Appears when Auto answer for PushTalk is set even if a flat-plug
earphone/microphone with switch is not connected.
qUSB mode (nP. 342)
[The phone ring volume [Silent] is set
bVibration mode is set
ZManner mode is set
_Public mode (Drive mode) is set
WMail being held at the center
XMail being held at the center full
HIC card is locked
RSecret mode is set
SSecret data is being edited
TKeypad dial lock
UAll lock is set
VFunction lock is set
WKeypad dial lock and Function lock are set
K (red) Secret mode, Function lock and Keypad dial lock are
set
K (blue) Side key guard, Secret mode, Function lock and
Keypad dial lock are set
XSide key guard is set
; (red) Hands-free in progress
; (green) USB hands-free in progress
lMute in progress (only when rotated the display)
MBluetooth hands-free in progress
\
Alarm is set
Schedule alarm is set*
Reception reserve alarm is set*
Recording reserve alarm is set*
Wakeup TV is set*
0Appears 12 hours before Music&Video Channel
program distribution
=Mail with send reservation
;Mail failed to be automatically sent
s
When voice/Videophone call in Auto answer setting is
set to [ON] and while a flat-plug earphone/microphone
with switch (sold separately) is connected
When PushTalk in Auto answer setting is set to [ON]
xFOMA USB Cable with Charge Function 01/02 (sold
separately) is connected in the Communication
mode
dv55_E.book 36 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[37/58]
37
Continued on next page
Before Using the Handset
rFOMA card error
sSelf mode (nP. 134)
tPushTalk (nP. 87)
uBluetooth (nP. 404)
The Bluetooth icon does not appear during SSL page display.
vIr exchange/Bluetooth communication/External device
wVeilView (nP. 125)
The VeilView icon does not appear during International roaming
or while 1Seg is recorded.
x3G/GSM (nP. 453)
yStatus of Comics setting (nP. 359)
Status of Comics setting icon does not appear during hands-free
operation.
zToruCa (nP. 257)
The ToruCa icon does not appear during hands-free operation or
e-comic display.
<Multitask (nP. 382)
Indicates functions that are running.
RAppears when FOMA card is malfunctioning or not
inserted
BAppears when a card other than the FOMA card is
inserted
gSelf mode is set
aDuring PushTalk transmission
LStand-by for Bluetooth registration
Stand-by for Bluetooth connection
Connected to Bluetooth
JData is communicated with another device using the
Ir exchange function (nP. 349)
Data is sent using the Ir remote control (nP. 353)
#Data is communicated with another device using the
Bluetooth function (nP. 409)
NConnected to commercially available Bluetooth
compatible keyboard (nP. 408)
t (green)
Connected to an external device and transmitting packets
t (red) Connected to an external device and sending/
receiving packet data
uConnected to an external device and transmitting
64K data
PVeilView is set
4 (green) 3G network (Packet transmission available)
4 (red) 3G network (Packet transmission not available)
KGSM/GPRS network (Packet transmission available)
JGSM/GPRS network (Packet transmission not
available)
IFrame display is set
HPage display is set
QUnread ToruCa
gFour or more applications
are running
2Camera (still picture)
3Camera (movie)
*Videophone 4Character reader (OCR)
hVoice call 5Bar code reader
tPhonebook ]Card reader
kPushTalk/PushTalk
phonebook
vVoice recorder
wSchedule
dv55_E.book 37 ページ ２００８年４月１７日　木曜日　午後２時１２分
38
e02_dv55_7e.fm
[38/58]
Before Using the Handset
Display stock icons in stand-by when a call is missed or new mail is
received. In stand-by, select stock icons to check notice details.
Stock icon type
#Modem transmission
(appears during data
transmission)
yText memo
zCalculator
iSoftware update 6Manga&BookReader
CGPS =Quick search
)Shotdeco nFull Browser, Internet
movie player
(Bluetooth function
jReceive via Ir exchange,
iC transmission, USB and
Bluetooth communication
>ToruCa
{Alarm
li-appli 8Timer
mi-mode, i-Channel, WEB
mail
}microSD manager
9General settings
pMail, SMS, Message R/F,
Check new message
0
Record message/Voice memo
7Document Viewer
qMail/Decome-Anime/SMS
being composed
"Own number
f1Seg
|Received calls/Received
messages history ^
Reception reserve/Recording
reserve alarm sounds
!Redial/Sent messages
history uData box, Music&Video
Channel
Note
microSD Card is referred to as [microSD] or [SD] on the FOMA
terminal (nP. 332).
Some of the screen shots in this manual have been modified or
abbreviated.
The display for the FOMA terminal is manufactured using
high-precision technology, but it may occasionally contain dots that
fail to light or that remains permanently lit. This is not a malfunction.
Checking notices with stock icon
Icon Message Page
Bxx missed call*1 P. 76
FRecorded messages Fxx message/
Axx message P. 79
Exx voice mail*1 P. 427
Cxx mail message*2
P. 205, P. 227
Lxx New Message R P. 222
Qxx New Message F P. 222
Dxx new ToruCa P. 257
5New auto send result P. 204
6
Update complete P. 508
Check update P. 508
Update required P. 505
Check for update
P. 506
DUSB mode setting P. 342
tDownload successful (Music&Video
Channel) P. 365
gDownload failed (Music&Video Channel) P. 365
Stock icon
Message
Number of entries
dv55_E.book 38 ページ ２００８年４月１７日　木曜日　午後２時１２分
39
e02_dv55_7e.fm
[39/58]
Before Using the Handset
*1 When the 2in1 mode is set to [Dual mode], the number of [A mode]
and [B mode] appears each.
*2 When the 2in1 mode is set to [Dual mode], the total number of [A
mode] and [B mode] appears.
*3 The message that appears differs depending on the menu screen.
1In stand-by, a stock icon appears/t.
2Select the stock icon/t.
After the details are checked, the stock icon and message
disappear.
Use the Optical TOUCH CRUISER to perform the same
operations as those for w of Multi-guide key (e.g. moving
the cursor or scrolling the screen).
Move the pointer or cursor just as covering the whole operating
range of the Optical TOUCH CRUISER with finger.
The pointer or cursor moves in conjunction with sliding of the finger.
@Send loc - No resp P. 276
Send loc - Resp P. 276
Send loc - Failed P. 276
4Charge limit exceeded P. 397
GCustom menu/Basic menu/Menu*3 P. 45
Note
Stock icons do not appear while the i-motion set as stand-by is
played or the i-appli stand-by is being activated.
In the viewer position, the messages and the notice details can be
checked by using Bluetooth compatible keyboard.
Icon Message Page Optical TOUCH CRUISER
Note
In the following cases (screens), the Optical TOUCH CRUISER is
not available. However, when the Submenu appears, the pad can
be operated.
Stand-by i-appli Dial input screen
Character reader, Bar code reader, Card reader screen
While making, receiving or during the voice call/Videophone
call/PushTalk, etc.
Operating range of
Optical TOUCH
CRUISER
dv55_E.book 39 ページ ２００８年４月１７日　木曜日　午後２時１２分
40
e02_dv55_7e.fm
[40/58]
Before Using the Handset
■Moving the pointer
In the Custom menu screen or while i-mode or
Full Browser is connected, move the pointer (L,
M, K, etc.) up/down, left/right or diagonally to
select an item.
In some Custom menus, the pointer shape
varies or the pointer is not supported.
Move the pointer to the edge of the screen
while i-mode or Full Browser is connected to
show
G
,
R
/
\
,
Z
and scroll the screen to the
direction of the arrow. If Link is set,
M
appears,
and press
t
to move to the linked page.
The pointer moving speed varies depending
on the finger sliding speed.
■Moving the cursor
In the Basic menu or Submenu, move the cursor
up/down and left/right in the same way as w of
Multi-guide key.
When there are multiple pages, move the
cursor to switch the pages.
■Setting whether to use the Optical TOUCH
CRUISER
1In the Custom menu, select [Settings]/[General
settings]/[TOUCH CRUISER set]/[Usage
settings].
2Select the setting/t.
■Setting the pointer speed/scroll speed
1In the Custom menu, select [Settings]/[General
settings]/[TOUCH CRUISER set].
2Select an item/t.
3Select the speed/t.
When using the Optical TOUCH CRUISER
Do not operate the Optical TOUCH CRUISER using a pointed
metallic object such as a pen tip. May cause scratches or a failure
of the sensor.
Note that putting a sticker, etc. to the operating range may cause
a malfunction.
e.g.) Custom
menu screen
e.g.) Basic menu
screen
Setting the Optical TOUCH CRUISER
<TOUCH CRUISER set>
dv55_E.book 40 ページ ２００８年４月１７日　木曜日　午後２時１２分
41
e02_dv55_7e.fm
[41/58]
Before Using the Handset
If the screen is switched from the normal position to the
viewer position, operate by putting your finger on the touch
panel (screen).
The operations differ depending on the function and screen in use.
When the touch panel is touched, the tone sounds and the vibrator
is activated (excluding while activating a camera (still picture/
movie)).
• For details on setting the volume nP. 110
• For details on setting the vibrator nP. 111
• The tone cannot be changed.
■Selecting keys
In the touch menu, control keys and others, touch the displayed keys
to select it.
■Selecting data and items
In list and data list screens, select the data or items by touching,
moving the cursor and re-touching them.
When scrolling the screen or when switching the page in the folder
list screen or the data list screen, slide the finger up/down or touch
A/B at the bottom of the screen to move pages.
■Canceling the selection
When having touched data by mistake, keep the finger on the touch
panel and slide it away from the selected data to cancel the selection.
Touch the “CLR” key to return to the previous screen.
Touch panel
Note
The message indicating the operation is not available appears
when the touch panel cannot be used.
Example: Selecting
Touch the touch panel.
Example: Adjusting the zoom
Touch the touch panel and slide
the finger left/right.
Other than the viewer position, the touch panel is available in the
following cases.
During Videophone (nP. 81)
During Writing authentication entry (nP. 130)
When using the touch panel
This product is designed to be operated with one finger. In the
following cases, the touch panel is not activated.
When operated with a gloved finger
When operated with two or more fingers
When operated with a fingernail
When operated with a pen, ballpoint pen, pencil, etc.
When operated with foreign objects placed on the operation
pad
Note that the following cases may cause a malfunction.
When operated with a wet finger
When operated with the touch panel pressed forcefully
When putting a sticker to the touch panel (display)
dv55_E.book 41 ページ ２００８年４月１７日　木曜日　午後２時１２分
42
e02_dv55_7e.fm
[42/58]
Before Using the Handset
The following functions can be activated from the touch menu.
Full Browser 1Seg Camera Mail
Manga&BookReader Data box
For details on touch menu nP. 46, P. 476
Set or change the channel using the
control key while the camera is
activated, 1Seg is watched, etc.
Touch the touch panel and the
control key appears.
If no operations are performed for
approximately 6 seconds with the
control key shown, the control
key disappears. Also, touch other
than the control key to hide the control key (excluding 1Seg).
For Full Browser, touch D and the control key appears. Touch
the display area other than control keys to hide.
When the control keys appear, only those are available. However,
in the camera (still picture/movie) shooting screen, adjusting the
brightness and digital zoom are available by using the touch panel
even while the control keys are displayed.
■Using the control keys
The control key appears when the following functions are activated.
Common keys for all functions
*1 While multiple windows are displayed in Full Browser, close the
displayed window.
*2 This key does not appear when there is no extra key.
While the camera (still picture/movie) is activated
*1 Touch after selecting the size (For still pictures, QCIF: 176×144
cannot be selected).
*2 Select a mode from < (Standard)/| (Def (people first)) (only for
still pictures)/> (Spot AF) (only for still pictures)/{ (Closeup)/}
(Manual focus) to touch.
•
When
|
is touched, touch the face detection frame and adjust the focus.
• When > is touched, touch the focus area and adjust the focus.
• When } is touched, touch the touch panel, slide the finger left/
right and adjust the focus.
*3 White balance appears only for still pictures, and the Common
replay mode appears only for movies.
*4 Appears even in the movie shooting screen.
The settings other than AF mode and image size change each time
the key is touched.
In the preview screen after shooting, the following keys appear.
*1 Only still picture is displayed.
*2 Only movie is displayed.
While 1Seg is being watched
Touch menu
Control key
E/T*1 To end the running function/return to a data list screen
FTo view the following keys*2
9To return to previous
Control key
JImage size*1 P
Fix camera shake
GAF mode*2 HTo zoom in*4
KPicture light ITo zoom out*4
QShoot by scene RSwitch phone#SD
NWhite balance*3 LTo turn up the brightness*4
OCommon replay mode*3 M
To turn down the brightness
*4
RSwitch phone#SD*1 UTo play*2
STo save 9To delete
VTo turn up the volume*Z
To select a station with DOWN
WTo turn down the volume*[To select a station by
searching a frequency (UP)
dv55_E.book 42 ページ ２００８年４月１７日　木曜日　午後２時１２分
43
e02_dv55_7e.fm
[43/58]
Before Using the Handset
* Keep key touched to adjust the volume continuously.
While an image is displayed from My picture/1Seg of Data box
For JPEG images, ( (zoom in)/) (zoom out) appears
when touching = which is displayed at the bottom of the
screen simultaneously with the control key.
• In the image display screen, which was zoomed up by touching
(, touch the touch panel and slide the finger up/down/left/
right to change the display position.
While i-motion is displayed from i-motion of Data box/
While a video is played back from 1Seg of Data box
*1 Keep key touched to adjust the volume continuously.
*2 Appears only for i-motion.
*3 Appears only for video.
While e-book, etc. is displayed
While Full Browser is displayed
*1 Touch the history screen on the right/left or touch the touch panel
and slide the finger right/left to move the cursor to next/previous
history in the Visual history screen.
•
Touch the tab on the upper part of the screen or touch the touch panel and
slide the finger up/down to switch windows in the Visual history screen.
*2 Touch #/$ or touch the touch panel and slide the finger right/left
to view the next/previous page in the Bookmark list screen.
*3 Check the site URL, touch [OK], select a folder and touch it to save
to bookmark.
*4 x (Keitai mode) and y (PC mode) are switched.
Zoom bar appears at the bottom of the screen simultaneously with the
control key. Touch the slider of zoom bar and slide the finger left/right or
touch +/- on the both ends of the zoom bar to zoom up/down the screen.
While a PC movie is played back
* Keep key touched to adjust the volume continuously.
While a message details screen is displayed
*1 Does not appear when there is no next/previous mail or message
and unread mail.
*2 Appears only for Decome-Anime.
*3 Appears only for received mail.
XTo display ChannelView \To select a station by
searching a frequency
(DOWN)
YTo select a station with UP
a
To rotate (excluding Flash movie)
1To retry (Flash movie)
gTo play/stop (Flash movie) ]To next
b
To display in actual size/full
screen (excluding Flash movie)
^To previous
VTo turn up the volume*1 hTo fast forward*3
WTo turn down the volume*1 kTo previous*2
gTo pause/play iTo fast rewind*3
jTo next*2
cTo return to the previous
line/frame 5To the top page
dTo go to the next line/frame
mTo cancel connection oTo save Bookmark*3
zVisual history*1 xDisplay Mode*4
nTo view Bookmark list*2
gTo pause/play WTo turn down the volume*
VTo turn up the volume*
]To the next mail/message*1 rTo the next unread mail*1, 3
^To the previous mail/
message*1 sTo the previous unread
mail*1, 3
9To play Decome-Anime*2, 3
dv55_E.book 43 ページ ２００８年４月１７日　木曜日　午後２時１２分
44
e02_dv55_7e.fm
[44/58]
Before Using the Handset
Set, change or save functions from the menu screens.
Set the start menu that displayed when t is pressed in stand-by.
1In stand-by, press t/[Settings]/[Disp/LED/
Power saver]/[Menu priority].
In the Custom menu/Basic menu: Press C/[Menu priority].
2Select the start menu/t/[Yes].
■Switching the set start menu temporarily
Switch the start menu temporarily. When the stand-by display
reappears, the start menu returns to the one set in Menu priority.
Use the Shortcut menu to retrieve saved functions quickly. Other
functions can also be saved in the Shortcut menu (nP. 393).
Menu settings and selections
The explanations in this manual are based on how to retrieve a
function from the Custom menu.
Setting the start menu <Menu priority>
Start menu Characteristics
Custom menu
The preset Kisekae Tool (nP. 119) can be selected
and set. Each Kisekae Tool consists of different
functions and designs. Kisekae Tools can be
downloaded from sites and used.
Preset Kisekae Tools
White Black Pink Blue
拡大メニュー (Large) シンプル (Simple)
ダイレクトメニュー
※Preset Kisekae Tools differ depending on the
FOMA terminal handset color.
Basic menu In the Basic menu, input the function number, which is
assigned to each function, to quickly retrieve the
function to be used.
Assigned function numbers nP. 458
Stand-by
t
Shortcut menu
a
Basic menuCustom menu
o
dv55_E.book 44 ページ ２００８年４月１７日　木曜日　午後２時１２分
45
e02_dv55_7e.fm
[45/58]
Before Using the Handset
For details on the available functions nP. 458
Use w and the Optical TOUCH CRUISER in either start menu.
Press the dial key corresponding to the menu item number (U, V,
W, etc.) to select a function. However, in the Custom menu, a
function may not be selected by using the menu item numbers.
The method for selecting functions may differ depending on the
Kisekae Tool set for the Custom menu.
Press c to re-select a function, and the previous screen
reappears. Press H to return to stand-by.
■Retrieving from the Custom menu
Example: Activating 1Seg with Multi guide key or Optical TOUCH
CRUISER
For the ,, use the Optical TOUCH CRUISER to select an item.
The following shows the screen operated with the Optical TOUCH
CRUISER.
■Retrieving from the Basic menu
Example: Activating 1Seg by entering function numbers
Retrieving a function from each start menu
When a stock icon (nP. 38) appears in stand-by, select G to
show the start menu.
,
t
Custom menu When [1Seg] is
displayed When 1Seg is
activated
,
t
or
w
t
or
w
t
Note
When the Custom menu image is changed by Kisekae Tool, the
operation may differ from the description in this manual. In this
case, switch the menu screen to the Basic menu (nP. 44) or
perform Reset menu screen (nP. 120).
Basic menu When 1Seg is
activated
961
dv55_E.book 45 ページ ２００８年４月１７日　木曜日　午後２時１２分
46
e02_dv55_7e.fm
[46/58]
Before Using the Handset
If the screen is switched from the normal position to the viewer position
in the stand-by display, Custom menu, Basic menu, Shortcut menu or
others, the touch menu appears.
When the stand-by display appears in the viewer position, touch the
touch panel to show the touch menu.
Touch the touch panel to select a menu.
Available functions to select from the touch menu are limited
(nP. 476).
The images and items in the touch menu cannot be changed.
Touch the “CLR” key to return to the previous screen and re-select
the function.
Example: Activating 1Seg by touching the touch panel
Use this function for unsure operations.
After the Supportbook appears, check the
explanation and operation procedures of
each function. In addition, directly start
functions that were looked up in the
Supportbook.
1In stand-by, press $.
2Select a menu or item/t.
Menu (touch menu) when in the viewer position
When 1Seg is activated
Touch menu
Supportbook
Displaying the Supportbook
Related Operations
Start functions directly from the Supportbook
In the details screen, select the function to start/t/
[Yes].
dv55_E.book 46 ページ ２００８年４月１７日　木曜日　午後２時１２分
47
e02_dv55_7e.fm
[47/58]
Before Using the Handset
A FOMA card is an IC card that records personal information,
such as phone numbers. A FOMA card can store phonebook
data and SMS. By switching FOMA cards, multiple FOMA
terminals can be used for different purposes as needed.
If a FOMA card is not inserted, transmission functions such as
voice/Videophone calls, PushTalk transmission, i-mode, mail
transmission and packet transmission are not available on the
FOMA terminal. In addition, 1Seg cannot be watched.
Before inserting or removing the FOMA card, turn off the power,
position the back facing upwards and remove the battery pack.
Close and hold the FOMA terminal firmly with your both hands.
■Inserting
1Hook a finger on the tab and pull the tray out (1).
Pull out the tray straight until it stops.
2Hold the FOMA card with the IC
facing up and set on the tray (2).
3Push the tray all the way in (3).
■Removing
1Hook a finger on the tab, pull the tray out (1) and
remove the FOMA card (2).
Do not allow the FOMA card to fall when removing it.
The FOMA card has a “PIN1 code” and a “PIN2 code”.
Both are set to [0000] by default but can be changed to a four- to
eight-digit number by the user (nP. 131).
FOMA card
Using a FOMA card
Inserting and removing
Notch
IC (gold)
2
Tray
3
Fit the notch of the FOMA card
to that of the tray.
1Tab
Note
Inserting or removing the FOMA card forcibly may damage the
card or deform the tray. Use caution.
Refer to the FOMA card user’s guide for more information on the
FOMA card.
Do not misplace the FOMA card once it is taken out.
When the tray falls off, slide the tray in straight along the guide rail.
Security codes
12
dv55_E.book 47 ページ ２００８年４月１７日　木曜日　午後２時１２分
48
e02_dv55_7e.fm
[48/58]
Before Using the Handset
The FOMA terminal has built-in FOMA card security functions (FOMA
card restriction functions) as functions for protecting personal data and
files.
When the FOMA card is inserted into the FOMA terminal and data
or files are retrieved using any of the following methods or when
i-appli is running, FOMA card security functions are automatically
set in the retrieved data or files.
When a file such as an image, melody or PDF is downloaded
from a site or Internet web page
When a site or Internet web page is saved as a screen memo
When i-mode mail with a file attached is received
When i-appli is running
Data, files or software with FOMA card security functions run only
when in use with the FOMA card inserted at time of acquisition.
Display, play, attach to i-mode mail, run software, send data using Ir
function and iC transmission function, and copy to microSD Card
can be executed.
The following indicates the data for which FOMA card security is set.
File attached to i-mode mail other than the following
• ToruCa ・Phonebook ・Schedule
•Bookmark ・Documents
※“Chaku-uta” is a registered trademark of the Sony Music
Entertainment (Japan) Inc.
The following indicates the settings saved in FOMA card.
The above operations cannot be performed if the FOMA card
inserted at time of data/file retrieval or i-appli startup is replaced
with a different FOMA card.
Explanation that follows refers to the FOMA card inserted at time of
data/files retrieval as “one’s own FOMA card” and other FOMA
cards as “another’s FOMA card”.
FOMA card security functions
<FOMA card security functions>
Melody
Image (including animation and Flash movie)
Screen memo Chaku-uta®/Chaku-uta full®
Chara-den File attached to Message R/F
i-motion ToruCa (details) image
PDF data Image inserted to Deco-mail or signature
Kisekae Tool Videophone picture memo
Machi-chara i-appli (including i-appli stand-by)
Download dictionary
Contents transfer compatible data
Image in Message R/F
Music&Video Channel program
Deco-mail template with data which FOMA card security
functions are set
Decome-Anime Template
e-book/e-dictionary/e-comic saved in the [Comic] folder
Own number PIN setting
Select language SSL certificates
SMS center SMS expiry
SMS input character
One’s own FOMA
card security
functions are set for
downloaded data,
files attached to
received mail and
i-
a
ppli that have been
run, allowing viewing
and playback of data.
When another’s
FOMA card is
inserted, data with
one’s own FOMA
card security
functions set cannot
be viewed or played
back.
One’s own
FOMA card
Another’s
FOMA card
Different FOMA card
inserted
dv55_E.book 48 ページ ２００８年４月１７日　木曜日　午後２時１２分
49
e02_dv55_7e.fm
[49/58]
Before Using the Handset
Note the following differences between “FOMA card (blue)” and
“FOMA card (green/white)” used on the FOMA terminal.
Note
When one’s own FOMA card is replaced with another’s FOMA
card, the data or files for which FOMA card security functions are
set cannot be set as stand-by displays or ring tones.
When a FOMA card is replaced with another’s FOMA card, FOMA
card security functions are activated and if data or file retrieved
from a site is set as the stand-by display or ring tone, the setting is
reset to the default. When one’s own FOMA card is re-inserted,
the setting returns.
Example: When setting [Melody A], for which FOMA card
security functions are set, as a ring tone
When one’s own FOMA card is taken out or is replaced with
another’s FOMA card, ring tone returns to default setting. When
one’s own FOMA card is put back, the ring tone returns to [Melody
A].
FOMA card security functions cannot be set for data received
using Ir exchange or data transmission functions, and still pictures/
movies, etc. shot with the FOMA terminal.
It is possible to move or delete data or files for which FOMA card
security functions are set even when another’s FOMA card is
inserted.
Running i-appli by selecting highlighted text in i-mode mail details
screen cannot be performed or retrieved when FOMA card
security functions are set.
If the FOMA card is replaced with another’s FOMA card after
i-appli stand-by is set, the set i-appli cannot be activated in
stand-by, and the image set in Stand-by display appears.
FOMA card type
Function FOMA card
(blue)
FOMA card
(green/white)
Page
Number of phone number
digits available in the FOMA
card phonebook Up to 20 digits Up to 26 digits P. 97
Client certificate operations
for FirstPass Not available Available P. 188
Use of WORLD WING Not available Available P. 448
Service number Not available Available P. 433
About WORLD WING
WORLD WING is a DoCoMo FOMA international roaming service
that makes it possible to use the mobile phone number registered in
Japan to make and receive calls even overseas by the FOMA card
(green/white) and supported FOMA terminal.
If subscribed to the FOMA service after September 1, 2005,
subscription for “WORLD WING” is not required. However, if
subscription for “WORLD WING” is canceled at or after
subscription for the FOMA service, subscription for “WORLD
WING” is required again.
If subscribed to the FOMA service before August 31, 2005 but not
subscribed to “WORLD WING”, subscription for “WORLD WING”
is required.
Some payment plans are not available.
When the FOMA card (green/white) is lost or stolen overseas,
promptly contact DoCoMo and conduct a procedure for canceling
the use of service. Refer to General Inquiries on the back of this
manual for inquiries. Note that transmission/calling charges after
the FOMA card is lost or stolen are incurred to the subscriber.
dv55_E.book 49 ページ ２００８年４月１７日　木曜日　午後２時１２分
50
e02_dv55_7e.fm
[50/58]
Before Using the Handset
Use the battery pack SH17 exclusive to the FOMA terminal.
Turn off the power, close the FOMA terminal, and hold it in your
both hands before inserting or removing the battery pack.
■Inserting
1Lightly push the back cover in the direction of the
arrow (1), slide approximately 2 mm (2) and
remove the back cover (3).
2Insert the battery pack (4).
The battery pack has tabs that make it easy to insert. Attach the
battery pack with a recycle mark side faced up.
3Reattach the back cover (5).
Position the back cover as shown in the illustration and then
push the back cover and slide into place.
■Removing
1Follow step 1 of “Inserting” to remove the back
cover.
2Remove the battery pack.
The battery pack has a tab that makes it easy to remove. Press
the tab with your fingers without placing too much force. Lift the
battery pack to remove.
Inserting and removing the battery
pack
1
3
2
Face the side with
a recycle mark up
4
Tabs
Tabs Battery pack
Battery pack connector terminal side
Note
Using unnecessary force when inserting or removing the battery
pack may damage the connector terminal for the battery pack
(charger terminal) on the FOMA terminal.
Firmly close the back cover. If not closed firmly, the back cover
may come off and the battery pack may fall out due to vibration.
5
Tab
dv55_E.book 50 ページ ２００８年４月１７日　木曜日　午後２時１２分
51
e02_dv55_7e.fm
[51/58]
Before Using the Handset
The battery pack is not fully charged at the time of purchase. Be sure
to charge the battery using the exclusive AC or DC adapter (sold
separately) before use.
■Estimated charge times and LED display
The following figures are estimated times for charging an empty
battery pack with the FOMA terminal turned off.
Charging LED illuminates in red when charging and turn off when
charging is completed.
Check that the battery pack has been properly inserted when
charging LED flashes red. The LED also flashes red when the
battery pack has reached the end of its service life.
The battery pack can also be charged with the FOMA terminal
turned on ({ on the display flashes during charging).
When charging is complete, charging LED turns off, and { on the
display changes to ".
When the battery becomes warm, charging may automatically stop
even if the battery has not been fully charged. Charging resumes
after the temperature lowers to an appropriate temperature. While
charging is stopped, charging LED turns off ({ on the display
flashes while stopped).
■Estimated times of use when fully charged
Continuous talk time is estimated as the usage time at normal
transmission signal strength, and continuous stand-by time is
estimated as the usage time while moving with the FOMA terminal
folded at normal signal strength. Talk/stand-by time may be
reduced by about half depending on conditions including battery
level status, stand-by display, Power saver mode, Missed call
notice and New unread mail notice settings, temperature and other
environmental conditions, and signal strength (no signal or weak
signal). Using i-mode reduces talk (transmission)/stand-by time.
When i-Channel is subscribed, information is automatically received
and updated, so talk (transmission)/stand-by time will be reduced.
In addition, when shooting or editing an image, watching 1Seg,
composing i-mode mail, activating the downloaded i-appli or the
i-appli stand-by, or using MUSIC Player or Bluetooth function, the
talk (transmission)/stand-by time will be shorten even if calls or
i-mode transmission are not made. Some i-appli software may
continue transmission even after downloading. To avoid this, set
not to connect in advance.
The actual usage time is a combination of stand-by time and talk
time, and the longer the talk time, the shorter the stand-by time
becomes.
1Seg watching time depends on conditions including battery level
status, functions used, temperature and other environmental
conditions.
Charging
Cautions when charging
FOMA AC Adapter 01/02 Approx. $$ min
FOMA DC Adapter 01/02 Approx. $$ min
Continuous
talk time FOMA/3G Voice call: Approx. $$ min
Videophone call: Approx. $$ min
GSM Voice call: Approx. $$ min
Continuous
stand-by
time
FOMA/
3G 3G/GSM setting:
3G When mobile: Approx. $$ hr
3G/GSM setting:
AUTO When mobile: Approx. $$ hr
At rest: Approx. $$ hr
GSM 3G/GSM setting:
AUTO At rest: Approx. $$ hr
1Seg watching time Approx. $$ min
dv55_E.book 51 ページ ２００８年４月１７日　木曜日　午後２時１２分
52
e02_dv55_7e.fm
[52/58]
Before Using the Handset
■Battery pack service life
Battery pack is a consumable product. Service time per charge is
gradually reduced every time the battery is charged.
When service time per charge is reduced to about half of the default time,
this means that the battery pack is approaching the end of its service life.
In such a case, it is recommended to replace the battery pack as soon as
possible. Depending on usage, the battery pack may swell as it
approaches the end of its service life but this will not cause problems.
If i-appli, Videophone, or 1Seg is used while charging for a long
time, the service life of the battery pack may become shorter than
estimated.
To protect the environment, return used batteries to NTT
DoCoMo, any DoCoMo retailer, or a recycling agency.
■About charging batteries
Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately),
FOMA AC Adapter 01 for Global use (sold separately), or FOMA
DC Adapter 01/02 (sold separately).
FOMA AC Adapter 01 covers only 100 VAC. FOMA AC Adapter 02/
FOMA AC Adapter 01 for Global use covers from 100 VAC to 240 VAC.
The shape of the plug for the AC adapter is for 100 VAC (for
domestic use). To use the AC adapter of 100 VAC to 240 VAC
overseas, a conversion plug adapter that is compatible with the
voltage of your country of stay is required. Do not use a transformer
for use overseas to charge the battery.
■Cautions when charging
Do not charge for long periods of time with the power left on. If the
FOMA terminal is left on after charging is complete, the battery pack
charge decreases.
In such cases, the AC or DC adapter charges the battery again.
However, depending on when the FOMA terminal is disconnected from
the AC or DC adapter, the battery charge level may be low, the battery
alert tone may sound, or the battery may only be usable for a short time.
When the battery is empty and terminal is recharging, charging LED
may not illuminate immediately.
If the alert tone sounds and the power cannot be turned on, charge
the battery for a while.
If the battery empty alert is displayed and charging begins within 60
seconds of the alert tone, the status returns to normal.
While charging, terminal may not turn on even when charging LED
is illuminated in red. Charge longer and try turning power on again.
Frequently recharging the battery when its power is still remaining
enough may shorten the life of the battery pack. It is recommended
to use the battery to a certain level before recharging.
The battery pack cannot be charged by itself.
[Read “FOMA AC adapter 01/02 (sold separately) and FOMA
DC adapter 01/02 (sold separately) user’s guide” carefully.]
Battery pack can be charged with FOMA terminal open or in the
viewer position.
1
Open the external connector terminal cover (
1
) and
insert the AC or DC adapter connector horizontally
into the external connector terminal (
2
).
Check the direction (see
diagram) of the connector, keep it
parallel with the FOMA terminal
and firmly push all the way in
until it clicks.
Charging using the AC adapter/DC adapter
Connector (Face the side with the arrows up)
2
Release
buttons
1
External
connector terminal cover
Charging/Called LED
External connector
terminal
dv55_E.book 52 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[53/58]
53
Continued on next page
Before Using the Handset
2When insert the AC adapter power plug into an
outlet or insert the DC adapter power plug into a
car cigarette lighter socket, charge start sound is
heard, charging LED illuminates, and charging
starts.
3When Charge end sound is heard and charging
LED turns off, charging is complete.
When removing the connector, always hold the release buttons
on both sides (1) and unplug it by pulling out horizontally (2).
[Read “Desktop holder SH19 (sold separately) user’s
guide” carefully.]
Battery pack can be charged in the viewer position.
Charging is not available with the FOMA terminal open.
1Face the side with the arrows of the AC adapter
connector up and insert it into the connector
terminal of the desktop holder.
Keeping the connector parallel with the desktop holder, firmly
push it all the way in until it clicks.
2Insert the AC adapter power plug into an outlet.
Note
Do not forcibly insert or remove. May cause damage to the
external connector terminal and the connector.
100 VAC
outlet
For AC adapter
2
For DC adapter
Cigarette
lighter socket
2
1
2
1
Pull the adapter out of the outlet or cigarette lighter socket if it will
not be used for a long time.
Do not forcefully pull the external connector terminal cover. May
damage the cover.
Do not place objects near the FOMA terminal when charging. The
FOMA terminal may be damaged. In addition, a display may be
damaged when charged in the viewer position.
When using a DC adapter
The DC adapter should only be used in negative grounded
vehicles (12 and 24 VDC).
Do not use with the car engine shut off. May drain the car battery.
The DC adapter fuse (2A) is a consumable. For replacement,
purchase a new fuse at a local automobile supply shop.
Refer to the FOMA DC Adapter 01/02 user’s guide for details.
Charging using the desktop holder
dv55_E.book 53 ページ ２００８年４月１７日　木曜日　午後２時１２分
54
e02_dv55_7e.fm
[54/58]
Before Using the Handset
3Place the FOMA terminal into the desktop holder.
Charge start sound is heard, Charging LED
illuminates, and charging starts.
Keeping the connector parallel with the desktop holder as
shown below, firmly push it all the way in until it clicks.
Do not open the FOMA terminal with the terminal placed in the
desktop holder.
4When Charge end sound is heard and charging
LED turns off, charging is complete.
Hold the desktop holder and lift the FOMA terminal out.
3
Connector
(Face the side with the arrows up)
1
2
FOMA AC Adapter 01/02
100 VAC outlet
Charging/Called LED
Note
Pull the AC adapter out of the outlet when left unused for a long
period of time.
When Charge start sound is not heard or when charging LED does
not illuminate, check that the FOMA terminal is placed securely in
the desktop holder (except when terminal is turned off, Manner
mode is set or Charge start sound is Silent).
When placing the FOMA terminal in the desktop holder, be careful
that the strap is not caught in between the handset and the
desktop holder.
Battery level
How to check the battery level
Making the desktop holder stand up
Make the stand behind the desktop holder stand up so that
charging becomes available with the desktop holder stood up.
Do not force to make the stand behind stand up.
"Battery level is still sufficient.
#Battery level is low.
$Battery is almost empty. Charge the
battery.
%Battery is empty (Power will turn off
soon).
{Battery pack is being charged.
dv55_E.book 54 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[55/58]
55
Continued on next page
Before Using the Handset
1In the Custom menu, select [Settings]/[General
settings]/[Check status]/[Battery level].
Wait approximately 2 seconds and the display disappears.
The battery level sound is heard at the volume set in Key/
Standby i-motion (nP. 110).
[Battery empty. Unsaved data will be lost. Ending
current operation] appears if battery starts to run out
(Press t to clear the message). After a while, an
alert tone sounds. The warning screen stating that
the battery runs out appears, handset operations are disabled and
power turns off after approximately 60 seconds.
During a voice/Videophone call, the alert tone sounds and [Battery
empty. Unsaved data will be lost. Ending current operation]
appears. The call is disconnected after approximately 20 seconds.
At the same time, the screen above appears and after
approximately 60 seconds, the power turns off.
Alert tone does not sound when Manner mode or Public mode
(Drive mode) is set (Alert tone sounds during a call).
1Press H (for 2+ seconds).
It may take some time for the wakeup
screen to appear.
The wakeup screen appears followed by the
initial settings screen. Proceed to Initial
setting (nP. 56).
If initial settings have been completed, the
screen shown on the right appears when
power is turned on. This screen is called the
“stand-by display”.
Welcome mail
“Welcome$SH906i%&” is saved by
default.
To check a welcome mail: In stand-by, press
t/select the stock icon C (mail
message)/t.
• For details on the following operations
nP. 209
1Press H (for 2+ seconds).
It may take some time for the power to be turned off (The end
screen appears on the display until the power is turned off).
Checking the battery level with sound and display
Graphic
Sound Three beeps Two beeps One beep
Status Battery is
sufficiently full. Battery is
running low.
Battery is almost
empty. Charge
the battery.
If the battery runs out
Power ON/OFF
Turning the power on and off
Turning the power on
Turning the power off
Initial settings
screen
Stand-by display
dv55_E.book 55 ページ ２００８年４月１７日　木曜日　午後２時１２分
56
e02_dv55_7e.fm
[56/58]
Before Using the Handset
1In the Custom menu, select [Settings]/[一般設
定]/[Bilingual]/[English].
To switch the display language from English to Japanese: In the
Custom menu, select [Settings]/[General settings]/[Select
language]/[日本語].
The initial settings screen appears automatically when the
power is turned on for the first time. Each setting item can
also be set from Menu (When the initial settings are
complete, the stand-by display appears).
When items that have not been set remain, the setting screen
appears every time the power is turned on.
1Set the date and time (nP. 57).
Set the date and time from 00:00 January 1, 2001 to 23:59
December 31, 2050.
2Register a terminal security code (nP. 129).
3Set the Key/Standby i-motion (nP. 110).
4Set GPS Location provision ON/OFF (nP. 273).
5Set the font size (nP. 124).
When the initial settings are complete, the software update
function confirmation screen appears. Read the description and
select [Agree] (When the initial settings are made from the
menu or the software update is set to other than [auto-update],
the confirmation screen does not appear).
Note
If initial settings are not yet completed, the setting screen appears
every time the power is turned on.
If the FOMA card is not inserted, [Insert UIM] and a FOMA card
error appear (nP. 37).
When [Enter PIN1 code] appears, enter the PIN1 code
(nP. 131).
When a FOMA card is replaced with a new card, the terminal
security code (four to eight digits) must be entered after turning on
the terminal. If a correct terminal security code is entered,
stand-by display appears. When a wrong terminal security code is
entered five times, the power is turned off. However, turning on the
power again is possible.
When A appears, the handset is outside the service area or in a
place with no signal. Move to a place where the icon disappears.
Select language
Switching the display to English
Note
If a FOMA card is inserted, settings are saved to the FOMA card
as well. When the setting of the FOMA terminal handset and the
setting of the inserted FOMA card are different, the setting in the
FOMA card is prioritized.
Initial setting
Making the initial setting
Date and time settings Change terminal security code
Key/Standby i-motion Location provision
Font size settings
Note
Press H to cancel the initial settings.
dv55_E.book 56 ページ ２００８年４月１７日　木曜日　午後２時１２分
e02_dv55_7e.fm
[57/58]
57
Continued on next page
Before Using the Handset
Set the date and time on the FOMA terminal. Set to
automatically correct the date and time.
1In the Custom menu, select
[Settings]/[General settings]/
[Date settings].
2Select the [Auto time correction] field/t/select
the setting.
Select [ON]/i.
Select [OFF]/select the [Date] field/t/enter the date/
t/select the [Time] field/t/enter the time (24-hour
format)/t/i.
When entering month, day and time, add 0 before numbers one
through nine (example: 01, 02, 03, etc.).
Date settings
Setting the date and time
Note
The date and time that are set are saved even if the battery pack is
removed, but if the battery pack remains removed for
approximately a week or more or the battery remains empty, the
settings may be reset. When this happens, set again after
charging the battery.
If the date and time are not set correctly, the following functions
cannot be used properly.
Redial, Received calls Auto power ON/OFF
Alarm Schedule
SSL (authentication) i-appli Auto start
Starting i-appliDX Reception, Recording
Machi-chara
Record message (voice), Record message (Videophone calls)
Camera image titles/shooting date
Playback or view of i-motion/music data/e-comic with replay
restrictions
When Auto time correction is set to [ON]
The FOMA automatically adjusts the time by connecting to the
DoCoMo network’s time information.
When time difference is adjusted, [Time adjusted] appears. When
Auto time correction is set to [ON], the time is sometimes not
adjusted for a while. To activate Auto time correction, turn off
FOMA terminal power and restart.
Time is not adjusted depending on the signal status.
Time may be off by a few seconds.
When time difference is adjusted overseas, the local time and date
and ! appear in Redial, Received calls, Received/Sent messages
history (SMS only), and Received/Sent messages list. The
received/sent messages are not displayed in order of the
displayed time and date but the mail reception/send.
! does not appear in the Unsent messages for mail messages. If
the date order display is set for the Unsent messages, unsent
messages are displayed in the order of the displayed time and
date.
Time correction may not be performed depending on the overseas
network.
dv55_E.book 57 ページ ２００８年４月１７日　木曜日　午後２時１２分
58
e02_dv55_7e.fm
[58/58]
Before Using the Handset
Display your number (caller ID) on the other party’s phone
(display) when making a voice/Videophone call or
transmission PushTalk.
Handset number (caller ID) is important personal information. Be
very careful about your caller ID setting.
The Notify caller ID function is available only on compatible phone
devices.
1In the Custom menu, select [Settings]/[NW
Services]/[Notify caller ID]/[Notify caller ID].
2Select the setting.
To notify caller ID: Select [Yes].
To not notify caller ID: Select [No].
1In the Custom menu, press 0.
During overseas use, Japan time and local time (or time set in
City) appear in the dual display except for the following cases.
When Auto time correction is set to [ON] and time correction
information is not being received from an overseas network
When Auto time correction is set to [OFF] and City is set to the
city in the same time zone as Japan
Related Operations
Change the time zone manually <City>
In the Date settings screen, select the [Auto time
correction] field/t/[OFF]/C/select a time zone/
t/select a city/t/i.
Notify caller ID
Sending your own phone number to
the other party
Setting up Notify caller ID/No caller ID in advance
Note
Notify caller ID cannot be set from outside the service area.
Related Operations
Check the Notify caller ID setting
In the Custom menu, select [Settings]/[NW Services]/
[Notify caller ID]/[Check setting].
Own number
Checking your phone number
Note
When a change for the Number B of 2in1 or a FOMA card
exchange (2in1 subscriber b 2in1 subscriber) is performed, use
any of the following methods to obtain the correct Number B.
Set 2in1 function OFF and then perform 2in1 setting again to
set 2in1 function ON
Check the 2in1 subscription
When a FOMA card exchange (2in1 subscriber b 2in1
nonsubscriber) is performed, set 2in1 function OFF.
Related Operations
Show a phone number during voice call
During a voice call, press C/[Own number].
Show a phone number during a Videophone call
During a Videophone call, press C/[Own number].
In the Dual mode (while using 2in1), switch between
own numbers of Number A and Number B
In the Own number screen, press i.
dv55_E.book 58 ページ ２００８年４月１７日　木曜日　午後２時１２分
e16_dv55_7e.fm
[353/362]
353
Continued on next page
Data Display/Edit/Management
During Ir exchange, if a signal to activate i-appli is received from
devices supporting Ir exchange, software can be activated.
1In the Custom menu, select [LifeKit]/[Receive Ir
data]/[Receive]/[Yes].
The FOMA terminal waits to receive data. Software is activated
when signal to activate i-appli is received from the sender’s
FOMA terminal.
Use the FOMA terminal’s Infrared port from i-appli software
to operate equipment supporting the infrared remote control
such as TVs and VCRs.
To use the infrared remote control function, download compatible
i-appli software.
Start i-appli software that supports Ir remote control functions, point
the FOMA terminal’s Ir port to the front of the remote control sensor on
the TV, VCR or other device to operate, and perform remote control
operations.
Actual operational methods will differ with each i-
a
ppli software application.
Control devices from a distance of up to approximately 4 m (Distance will
vary depending on the device, the ambient brightness and other factors).
Use iC transmission to send and receive data to and from
other FOMA terminals which also support iC transmission
function.
Activating i-appli from Ir exchange
Note
When i-appli To is set to [No], i-appli is not activated from Ir
exchange.
Cannot be activated as i-appli stand-by.
Infrared remote control
Using the infrared remote control
function
Remote control operation
Note
When in the Self mode, the Ir remote control function cannot be
used.
Depending on the device, operation may not run properly.
Remote control operation may not run properly directly under
fluorescent lights, near other equipment using infrared signals, or
in areas of direct sunlight.
iC transmission
iC transmission
15°
Approx. 4 m
15°
Infrared port
dv55_E.book 353 ページ ２００８年４月１７日　木曜日　午後２時１２分
354
e16_dv55_7e.fm
[354/362]
Data Display/Edit/Management
During iC transmission, the FOMA terminal status is the same as
when outside the service area, such that making/receiving calls,
i-mode, and data communications are not possible.
iC transmission is not available while a call is in progress or the IC
card is locked.
Data that can be sent and received or operations when various lock
functions are set are same as for Ir exchange (nP. 349).
For details on starting iC transmission from i-appli nP. 251
Use while placing FeliCa mark (b) of receiving side FOMA
terminal on that of sending side FOMA terminal as shown above.
Do not move the FOMA terminal until all data are sent and received.
Sending and receiving data may be difficult according to other
party’s FOMA terminal. In such cases, make the clearance between
the FeliCa marks (b) closer or farther, or move them up/down/left/
right alternately.
During iC transmission, FOMA terminal called LED flashes
(nP. 123).
Example: Phonebook
1In stand-by, press a.
2Select a name/C/[Send data]/[iC
transmission]/[Send]/[Yes].
In the details screen: Press C/[Send data]/[iC
transmission]/[Send]/[Yes].
3Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
1Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
2Select [Yes].
Precautions for using iC transmission function
FeliCa mark
Sending and receiving data
individually
Sending a single data item <Send>
Receiving a single data item <Receive>
Note
When receiving phonebook, a confirmation message to store in
PushTalk phonebook appears. To store, select [Yes]. When
multiple phone numbers are stored, select the phone number.
However, if the 2in1 mode is set to [B mode], the PushTalk
phonebook confirmation screen does not appear.
dv55_E.book 354 ページ ２００８年４月１７日　木曜日　午後２時１２分
e16_dv55_7e.fm
[355/362]
355
Continued on next page
Data Display/Edit/Management
Terminal security code and authentication password entry are
required for sending or receiving all data items. The authentication
password is a password exclusively for iC transmission. Before
starting data transfer, the sender and receiver must enter the same
user-specified four-digit password.
Example: Phonebook
1In stand-by, press a/C/[Send data]/[iC
transmission]/[Send all].
2Enter the terminal security code/t.
3Enter the authentication password/t/[Yes].
4Place FeliCa mark (b) on that of the other party’s
FOMA terminal.
1In stand-by, place the FeliCa mark (b) on that of
the other party’s FOMA terminal.
2Select [Yes].
3Enter the terminal security code/t.
4Enter the authentication password/t/[Yes].
To cancel Receive: While receiving data, press C.
Use the FOMA terminal as a voice recorder.
Save up to 400 recordings on the [Multimedia] folder of microSD
Card (Actual number varies depending on recording time). Record
up to 6 hours per recording.
When recording is attempted after the 400th recording, the
message stating that recording is failed appears and Voice recorder
ends.
Record up to approximately 10 hours when saving to a 64 MB
microSD Card.
Recording within a distance of approximately 1.5 m is
recommended.
Play back recorded voice or audio with i-motion player (nP. 324).
Recording start sound is heard and recording starts. The picture
light flashes during recording.
1In the Custom menu, select [Media tool]/[Voice
recorder]/t/<.
To pause/play: Press i.
2Press t/< to end recording.
Recording stops automatically in the following circumstances.
When the remaining time goes to 00:00:00
When recording time reaches approximately 6 hours
When microSD Card has no available space
3Select [Save].
Recorded voice is saved.
To play back recorded voice: Select [Play].
To cancel recorded voice: Select [Cancel]/[Yes].
Sending and receiving all data items
Sending all data items <Send all>
Receiving all data items <Receive all>
Voice recorder
Using the FOMA terminal handset
as a voice recorder
Recording
dv55_E.book 355 ページ ２００８年４月１７日　木曜日　午後２時１２分

Navigation menu
