Appendix/External Devices/Troubleshooting
*1 Up to 50 entries can be saved in the FOMA card.
*2 Total number of the timers for starting and recording programs.
*3 Save a national holiday besides holidays already saved.
*4 For SMS, up to 20 received and sent messages can be saved in
the FOMA card (nP. 228).
*5
Capacity may decrease depending on the available memory (
n
P. 348).
*6 Pre-installed data is included.
*7 Set up to five dictionaries.
*8 Pre-installed folder is included.
This model phone FOMA SH906i meets the MIC’s* technical
regulation for exposure to radio waves.
The technical regulation established permitted levels of radio frequency
energy, based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of
scientific studies. The regulation employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit is 2 watts/
kilogram (W/kg)
**
averaged over ten grams of tissue. The limit includes
a substantial safety margin designed to assure the safety of all persons,
regardless of age and health. The value of the limit is equal to the
international guidelines recommended by ICNIRP
***
.
All phone models should be confirmed to comply with the regulation,
before they are available for sale to the public. The highest SAR value
for this model phone is 0.457 W/kg. It was taken by the Telecom
Engineering Center (TELEC), a Registered Certification Agency on the
Radio Law. The test for SAR was conducted in accordance with the
MIC testing procedure using standard operating positions with the
phone transmitting at its highest permitted power level in all tested
frequency bands. While there may be differences between the SAR
levels of various phones and at various positions, they all meet the
MIC’s technical regulation. Although the SAR is determined at the
highest certified power level, the actual SAR of the phone during
operation can be well below the maximum value.
For further information about SAR, please see the following websites:
i-appli 100*5 –
Mail-type i-appli 5 –
Still picture 1,000*5 –
User folder 20 –
Movie/i-motion 100*5 –
User folder 20 –
Kisekae Tool 50*5 –
User folder 20 –
Machi-chara 50*5 –
User folder 20 –
Chara-den 50*5 –
User folder 20 –
Melody 500*5 –
User folder 20 –
PDF data 50*5 –
User folder 20 –
ToruCa 200*5 –
User folder 20 –
e-book/e-dictionary/e-comic 1,000*5, 6 –
User folder 400*8 –
Data type
Number of
applicable
entries to be
saved/registered
Number of
applicable
entries to be
protected
Specific Absorption Rate (SAR)
World Health Organization (WHO)
http://www.who.int/peh-emf/
ICNIRP
http://www.icnirp.de/
MIC
http://www.tele.soumu.go.jp/e/ele/body/index.htm
e23_dv55_7e.fm 515 ページ ２００８年４月１８日　金曜日　午後３時３８分
516
e23_dv55_7e.fm
[516/518]
Appendix/External Devices/Troubleshooting
TELEC
http://www.telec.or.jp/ENG/Index_e.htm
NTT DoCoMo
http://www.nttdocomo.co.jp/english/product/
SHARP Corporation
http://www.sharp.co.jp/products/menu/phone/cellular/sar/index.html
* Ministry of Internal Affairs and Communications
** The technical regulation is provided in Article 14-2 of the Ministry
Ordinance Regulating Radio Equipment.
***International Commission on Non-Ionizing Radiation Protection
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves recommended
by international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety
margins designed to assure the protection of all persons, regardless
of age and health.
The guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg
and the highest SAR value for this device when tested at the ear was
0.813 W/kg*.
As SAR is measured utilizing the devices highest transmitting power
the actual SAR of this device while operating is typically below that
indicated above. This is due to automatic changes to the power level
of the device to ensure it only uses the minimum level required to
reach the network.
The World Health Organization has stated that present scientific
information does not indicate the need for any special precautions for
the use of mobile devices. They note that if you want to reduce your
exposure then you can do so by limiting the length of calls or using a
hands-free device to keep the mobile phone away from the head.
* The tests are carried out in accordance with international
guidelines for testing.
FCC Notice
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver.
It is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The guidelines are based on standards that were developed by
independent scientific organisations through periodic and thorough
evaluation of scientific studies. The standards include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
Hereby, Sharp Telecommunications of Europe Ltd, declares
that this FOMA SH906i is in compliance with the essential
requirements and other relevant provisions of Directive
1999/5/EC.
A copy of the original declaration of conformity can be
found at the following Internet address:
http://www.sharp.co.jp/k-tai/
Declaration of Conformity
e23_dv55_7e.fm 516 ページ ２００８年４月１８日　金曜日　午後３時３８分
517
e23_dv55_7e.fm
[517/518]
Appendix/External Devices/Troubleshooting
The Japan Export Control Regulations (“Foreign Exchange
and International Trade Law” and its related laws) will be
applied to this product and its accessories under certain
conditions. The Export Administration Regulations are also
applied. To export or reexport this terminal and its
accessories, conduct all legally required procedures at your
own risk and expense. For details on the procedures, contact
the Ministry of Economy, Trade and Industry or the US
Department of Commerce.
The tests are performed in positions and locations (e.g., at the ear
and worn on the body) as required by the FCC for each model. The
highest SAR value for this model handset when tested for use at the
ear is 0.615 W/kg and when worn on the body, as described in this
user guide, is 0.442 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the back of the handset kept 1.5 cm from the body.
To maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5 cm separation distance between the
user’s body and the back of the handset. The use of beltclips,
holsters and similar accessories should not contain metallic
components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
The FCC has granted an Equipment Authorization for this model
handset with all reported SAR levels evaluated as in compliance with
the FCC RF emission guidelines. SAR information on this model
handset is on file with the FCC and can be found under the Display
Grant section of http://www.fcc.gov/oet/fccid after searching on FCC
ID APYHRO00066.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Website at http://www.phonefacts.net.
Export Control Regulations
