USERS MANUAL
Instruction Manual October 2007
LR260 (HART)
sitrans
SSTB/August 28,07
© Siemens Milltronics Process Instruments Inc. 2007
Safety Guidelines: Warning notices must be observed to ensure personal safety as well as that of
others, and to protect the product and the connected equipment. These warning notices are
accompanied by a clarification of the level of caution to be observed.
Qualified Personnel: This device/system may only be set up and operated in conjunction with this
manual. Qualified personnel are only authorized to install and operate this equipment in accordance with
established safety practices and standards.
Unit Repair and Excluded Liability:
• The user is responsible for all changes and repairs made to the device by the user or the user’s
agent.
• All new components are to be provided by Siemens Milltronics Process Instruments Inc.
• Restrict repair to faulty components only.
• Do not reuse faulty components.
Warning: This product can only function properly and safely if it is correctly transported, stored,
installed, set up, operated, and maintained.
Note: Always use product in accordance with specifications.
Copyright Siemens Milltronics Process
Instruments Inc. 2007. All Rights Reserved
Disclaimer of Liability
This document is available in bound version and in
electronic version. We encourage users to purchase
authorized bound manuals, or to view electronic versions
as designed and authored by Siemens Milltronics Process
Instruments Inc. Siemens Milltronics Process Instruments
Inc. will not be responsible for the contents of partial or
whole reproductions of either bound or electronic
versions.
While we have verified the contents of this
manual for agreement with the
instrumentation described, variations
remain possible. Thus we cannot
guarantee full agreement. The contents of
this manual are regularly reviewed and
corrections are included in subsequent
editions. We welcome all suggestions for
improvement.
Technical data subject to change.
MILLTRONICS®is a registered trademark of Siemens Milltronics Process Instruments Inc.
Contact SMPI Technical Publications at the following address:
Technical Publications
Siemens Milltronics Process Instruments Inc.
1954 Technology Drive, P.O. Box 4225
Peterborough, Ontario, Canada, K9J 7B1
Email: techpubs.smpi@siemens.com
• For a selection of Siemens Milltronics level measurement manuals, go to:
www. siemens.com/processautomation. Under Process Instrumentation, select
Level
Measurement
and then go to the manual archive listed under the product family.
• For a selection of Siemens Milltronics weighing manuals, go to:
www. siemens.com/processautomation. Under Weighing Technology, select
Continuous
Weighing Systems
and then go to the manual archive listed under the product family.
i
mmmmm
Table of Contents
Table of Contents
Table of Contents ...............................................................................................................i
Safety Notes ...........................................................................................................................................1
Safety marking symbols ............................................................................................................1
FCC Conformity ......................................................................................................................................1
The Manual ............................................................................................................................................2
Technical Support .................................................................................................................................2
SITRANS LR260 Overview ................................................................................................4
Specifications ....................................................................................................................5
Power............................................................................................................................................. 5
Performance................................................................................................................................. 5
Interface ........................................................................................................................................ 6
Mechanical................................................................................................................................... 6
Environmental .............................................................................................................................. 7
Process.......................................................................................................................................... 7
Approvals ...................................................................................................................................... 7
Programmer (infrared keypad) ................................................................................................ 7
Dimensions .............................................................................................................................................8
Flanged Horn ................................................................................................................................8
Installation ..........................................................................................................................9
Mounting location ...............................................................................................................................10
Nozzle design .............................................................................................................................10
Nozzle location ..........................................................................................................................10
Orientation in a vessel with obstructions ............................................................................11
Easy Aimer ............................................................................................................................................12
Air Purging System (Optional) .........................................................................................................13
Universal Slotted Flange .........................................................................................................14
Optional Dust Cap ...............................................................................................................................15
Wiring ................................................................................................................................17
Power .....................................................................................................................................................17
Connecting SITRANS LR260 .............................................................................................................17
Wiring setup for hazardous area installations (UNDER REVISION) .......................................19
Instructions specific to hazardous area installations ......................................................19
Quick Start via local operation .....................................................................................21
Activating SITRANS LR260 ...............................................................................................................21
The LCD Display ........................................................................................................................21
Handheld Programmer (Part No. 7ML1930-1BK) ..............................................................23
Programming SITRANS LR260 ...............................................................................................24
Quick Start Wizard via the handheld programmer .....................................................................28
Level application example ................................................................................................................30
Auto False Echo Suppression ..........................................................................................................30
Operating via SIMATIC PDM .........................................................................................31
Functions in SIMATIC PDM ..............................................................................................................31
Device Description (DD) ..........................................................................................................32
Configuring a new device .......................................................................................................32
ii
mmmmm
Table of Contents
Quick Start Wizard via SIMATIC PDM ..........................................................................................32
Changing parameter settings using SIMATIC PDM .........................................................36
Parameters accessed via pull-down menus ......................................................................36
Parameter Reference .....................................................................................................42
Pull-down menus via SIMATIC PDM ...................................................................................42
Quick Start Wizard ..............................................................................................................................43
Quick Start ............................................................................................................................................ 43
Setup ......................................................................................................................................................45
Device .......................................................................................................................................... 45
Input ..............................................................................................................................................45
Output ...........................................................................................................................................56
Fail-safe .......................................................................................................................................59
Diagnostics ...........................................................................................................................................60
Echo Profile ................................................................................................................................60
Measured Values (MEAS. VALUES)..................................................................................... 60
Remaining Device Lifetime (REMAIN. DEV. LIFE.) ............................................................61
Remaining Sensor Lifetime (REMAIN SENS. LIFE.) ..........................................................63
Service ...................................................................................................................................................65
Device Reset .............................................................................................................................. 65
Manufacture Date (MANUF. DATE) .....................................................................................65
LCD Fast Mode ..........................................................................................................................65
LCD Contrast ..............................................................................................................................66
Powered Hours ..........................................................................................................................66
Power-on Resets....................................................................................................................... 66
Memory Test (MEM. TEST) .................................................................................................... 66
Service Interval.......................................................................................................................... 66
Calibration Interval (CALIB. INTERVAL) ...............................................................................68
Communication ....................................................................................................................................70
Device Address ......................................................................................................................... 70
Communication Control ...........................................................................................................70
Security .................................................................................................................................................71
Lock .............................................................................................................................................. 71
Unlock value ...............................................................................................................................71
Language ..............................................................................................................................................71
Appendix A: Alphabetical Parameter List ..................................................................73
Appendix B: Troubleshooting .......................................................................................76
Communication Troubleshooting ....................................................................................................76
Generally: ....................................................................................................................................76
Specifically: .................................................................................................................................76
Device Status Icons ...........................................................................................................................77
General Fault Codes ...........................................................................................................................78
Operation Troubleshooting ...............................................................................................................82
Appendix C: Maintenance .............................................................................................85
Unit Repair and Excluded Liability ..................................................................................................85
Appendix D: Technical Reference ...............................................................................86
Principles of Operation ......................................................................................................................86
Echo Processing .................................................................................................................................86
Process Intelligence .................................................................................................................86
iii
mmmmm
Table of Contents
Time Varying Threshold (TVT) Curves .................................................................................87
Echo Lock ....................................................................................................................................87
Echo Position Detection ..........................................................................................................87
Auto False Echo Suppression ................................................................................................88
Measurement Range .........................................................................................................................88
Near Range ................................................................................................................................88
Far Range ....................................................................................................................................89
Measurement Response ...................................................................................................................89
mA Output .............................................................................................................................................89
Damping ................................................................................................................................................90
Loss of Echo (LOE) ..............................................................................................................................90
Fail-safe Mode .....................................................................................................................................90
Fail-safe Timer ...........................................................................................................................91
Fail-safe Material Level ...........................................................................................................91
Fail-safe Level ............................................................................................................................91
Maximum Process Temperature Chart (UNDER REVISION) ...................................................92
Process Pressure/Temperature derating curves .......................................................................93
Horn Antenna (UNDER REVISION) .......................................................................................94
Loop power ...........................................................................................................................................96
Typical Connection Drawing ..................................................................................................96
Allowable operating area of SITRANS LR260 ....................................................................97
Startup Behavior .......................................................................................................................97
Appendix E: Application Example ................................................................................98
Flour in steel storage vessel, level measurement ............................................................98
Appendix F: HART Communications .........................................................................100
SIMATIC PDM ...................................................................................................................................100
HART Device Description (DD) ......................................................................................................100
HART Communicator 375 Menu Structure .................................................................................101
Supported HART Commands .........................................................................................................104
Universal and Common Practice Commands ..................................................................104
Device Specific Commands ..................................................................................................104
Appendix G: Software Revision History ....................................................................105
Glossary ..........................................................................................................................107
Index ................................................................................................................................111
LCD menu structure ......................................................................................................115
iv
mmmmm
Table of Contents
Notes
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 1
mmmmm
SITRANS LR260
Safety Notes
Special attention must be paid to warnings and notes highlighted from the rest of the text
by grey boxes.1
Safety marking symbols
FCC Conformity
US Installations only: Federal Communications Commission (FCC) rules
WARNING: relates to a caution symbol on the product, and means
that failure to observe the necessary precautions can result in death,
serious injury, and/or considerable material damage.
WARNING1: means that failure to observe the necessary
precautions can result in death, serious injury, and/or considerable
material damage.
Note: means important information about the product or that part of the operating
manual.
1. This symbol is used when there is no corresponding caution symbol on the product.
In manual On product Description
Earth (ground) Terminal
Protective Conductor Terminal
(Label on product: yellow background.) WARNING: refer
to accompanying documents (manual) for details.
WARNING: Changes or modifications not expressly approved by
Siemens Milltronics could void the user’s authority to operate the
equipment.
Notes:
• This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
• This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference to radio communications, in which case
the user will be required to correct the interference at his own expense.
Page 2 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SITRANS LR260
The Manual
This manual will help you set up your SITRANS LR260 for optimum performance. We
always welcome suggestions and comments about manual content, design, and
accessibility. Please direct your comments to techpubs.smpi@siemens.com.
For other Siemens Milltronics level measurement manuals, go to:
www.siemens.com/level and look under Level Measurement.
Application Examples
The application examples used in this manual illustrate typical installations using
SITRANS LR260 (see
Appendix E: Application Example
on page 98). Because there is
often a range of ways to approach an application, other configurations may also apply.
In all examples, substitute your own application details. If the examples do not apply to
your application, check the applicable parameter reference for the available options.
Technical Support
Support is available 24 hours a day.
To find your local Siemens Automation Office address, phone number, and fax number go
to:
www.siemens.com/automation/partner
• Click on the tab Contacts by Product and then find your product group (+Process
Automation > +Process Instrumentation > +Level Measuring Instruments).
• Select the team Technical Suppor t . Click Next.
• Click the appropriate continent, then select the country followed by the city.
Click Next.
For on-line technical support go to:
www.siemens.com/automation/support-request
• Enter the device name (SITRANS LR260) or order number, then click on Search,
and select the appropriate product type. Click Next.
• You will be prompted to enter a keyword describing your issue. Then either
browse the relevant documentation, or click Next to email a detailed description
of your issue to Siemens Technical Support staff.
Siemens A&D Technical Support Center: phone +49 180 50 50 222
fax +49 180 50 50 223
Notes:
• Please follow the installation and operating procedures for a quick, trouble-free
installation and to ensure the maximum accuracy and reliability of your SITRANS LR260.
• This manual applies to the SITRANS LR260 (HART) only.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 3
mmmmm
SITRANS LR260
Abbreviations and Identifications
Short form Long Form Description Units
A/D Analog to digital
CE / FM / CSA Conformité Européenne / Factory Mutual /
Canadian Standards Association safety approval
CiInternal capacitance F
D/A Digital to analog
DAC Digital Analog Converter
DCS Distributed Control System control room
apparatus
dK dielectric constant
FV Full Vacuum
ESD Electrostatic Discharge
HART Highway Addressable Remote Transducer
IiInput current mA
IoOutput current mA
IS Intrinsically Safe safety approval
LiInternal inductance mH
mH milliHenry 10-3 H
µFmicroFarad 10-6 F
µs microsecond 10-6 s
PED Pressure Equipment Directive safety approval
pF pico Farads 10-12 F
ppm parts per million
PV Primary Variable measured value
SV Secondary Variable equivalent value
TVT Time Varying Threshold sensitivity
threshold
UiInput voltage V
UoOutput voltage V
Page 4 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SITRANS LR260
SITRANS LR260 Overview
SITRANS LR260 is a 2-wire 25 GHz pulse radar level transmitter for continuous monitoring
of solids in storage vessels including extreme levels of dust and high temperatures, to a
range of 30 m (98.4 ft).
The instrument consists of an electronic component coupled to a horn antenna with an
integral Easy Aimer and flange for quick and easy positioning. A dust cover or air purging
are available as options.
SITRANS LR260 supports HART1 communication protocol, and SIMATIC PDM software.
Signals are processed using Process Intelligence which has been field-proven in over
1,000,000 applications worldwide (ultrasonic and radar).
Programming
SITRANS LR260 is very easy to install and configure via a graphical local user interface
(LUI). You can modify the built-in parameters either locally via the Siemens infrared
handheld programmer, or from a remote location via SIMATIC PDM.
Applications
• cement powder, pastic powder/pellets, grain, flour, coal, and other applications
• solids bulk storage vessels
Approvals and Certificates
SITRANS LR260 is available with General Purpose approval, or for hazardous areas. For
details, see
Approvals
on page 7.
1. HART® is a registered trademark of the HART Communication Foundation
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 5
mmmmm
Specifications
Specifications
Power
• Maximum 30 V DC
• 4 to 20 mA
• Max startup current see
Startup Behavior
on page 97
Performance
Reference operating conditions according to IEC 60770-1
• ambient temperature +15 to +25 °C (+59 to +77 °F)
• humidity 45% to 75% relative humidity
• ambient pressure 860 to 1060 mbar g (86000 to 106000 N/m2 g)
Measurement Accuracy (measured in accordance with IEC 60770-1)
• Maximum measured error =10 mm (0.39") (including hysteresis and non-
repeatability)
Frequency K-band (25 GHz nominal)
Max. measurement range 30 m (98.4 ft)
Min. measurement range10.05 m (1.97") from end of horn
Update time minimum 2 seconds, depending on settings for
Response Rate (2.2.7.1) and LCD Fast Mode (4.3)
Influence of ambient temperature < 0.003%/K (average over full temperature range,
referenced to maximum range)
Dielectric constant of material measured
• Minimum dK = 1.6 (depending on antenna and application type)
Memory:
• non-volatile EEPROM
• no battery required.
Note: Siemens Milltronics makes every attempt to ensure the accuracy of these
specifications but reserves the right to change them at any time.
Nominal 24 V DC with
max. 550 Ohm loop resis-
tance:
For other configurations, see the chart under
Loop
power
on page 96
1. See
Dimensions
on page 8 and
Flanged Horn
on page 8.
Page 6 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Specifications
Interface
Analog output
• signal range 4 to 20 mA (±0.02 mA accuracy)
upper limit 20 to 23 mA adjustable
• fail signal 3.6 mA to 23 mA; or last value
• load Max. 600 Ω
Communication: HART
• Load 230 to 600 Ω, 230 to 500 Ω when connecting a coupling
module
• Max. Line Length multi-wire: ≤ 1500 m (4921 ft)
• Protocol HART1, Version 5.1
Configuration Siemens SIMATIC PDM (PC), or
Siemens Milltronics infrared handheld programmer, or
HART handheld communicator
Display (local)2graphic LCD, with bar graph representing level
Mechanical
Process Connections:
• universal flanges 2"/50 mm, 3"/75 mm, 4"/100 mm, 6"/150 mm
• materials flange and horn: 304 stainless steel
Horn:
• 2" horn 1.93" (49.0 mm) diameter
• 3" horn 2.93" (74.5 mm) diameter
• 4" horn 3.84" (97.5 mm) diameter
Enclosure
• construction aluminum, polyester powder-coated
• conduit entry 2 x M20x1.5, or 2 x ½" NPT
• ingress protection Type 4X/NEMA 4X, Type 6/NEMA 6, IP 67 (see note below)
Dust cap (optional)
• 2" PTFE, pipe clamp connection, O.D. 70 mm (2.76")
• 3" PTFE, pipe clamp connection, O.D. 95 mm (3.74")
• 4" PTFE, pipe clamp connection, O.D. 120 mm (4.72")
Air Purge Connection
• equipped with female 1/8" NPT fitting
Weight
• standard model < 8.14 kg (17.9 lb) including 4" flange and standard Easy
Aimer with 4" horn antenna
1. HART® is a registered trademark of HART Communication Foundation.
2. Display quality will be degraded in temperatures below –25 °C (–13 °F) and above +65 °C (+149 °F).
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 7
mmmmm
Specifications
Environmental
• location indoor/ outdoor
• altitude 2000 m (6562 ft) max.
• ambient temperature −40 to +80 °C (−40 to +176 °F)
• relative humidity suitable for outdoor
Type 4X/NEMA 4X, Type 6/NEMA 6, IP67 enclosure (see
note below)
• installation category I
• pollution degree 4
Process
•temperature
1-40 to 200 °C (-40 to 392 °F)
(at process connection with FKM O-ring)
• pressure (vessel)1Refer to
Process Pressure/Temperature derating curves
on
page 93.
Approvals
•General CSA
US/C, FM, CE
• Radio Europe (R&TTE), FCC, Industry Canada
• Hazardous FM/CSA Class II, Div. 1, Groups E, F, G, Class III
ATEX II 1D; 1/2D, 2D T85 deg C
Programmer (infrared keypad)
Siemens Milltronics Infrared IS (Intrinsically Safe) Hand Programmer for hazardous and
all other locations (battery is non-replaceable)
• approval ATEX II 1 G, EEx ia IIC T4, certificate SIRA 01ATEX2147
FM/CSA: Class I, Div. 1, Groups A, B, C, D
• ambient temperature −20 to 40 °C (−5 to 104 °F)
• interface proprietary infrared pulse signal
• power 3 V lithium battery
• weight 150 g (0.3 lb)
• color black
• Part Number 7ML1930-1BK
Notes:
• Check
Approvals
on page 7, for the specific configuration you are about to use or
install.
• Use appropriate conduit seals to maintain IP or NEMA rating.
1. The maximum temperature is dependent on the ambient temperature and vessel pressure. For
more detail, or for other configurations, see
Maximum Process Temperature Chart (UNDER
REVISION)
on page 92, and
Process Pressure/Temperature derating curves
on page 93.
Note: The device nameplate lists the approvals that apply to your device.
Page 8 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Specifications
Dimensions
Flanged Horn
Notes:
• Process temperature and pressure capabilities are dependent upon information on
the process device tag. Reference drawing listed on the Tag is available on our
website at www.siemens.com/processautomation, on the product page for
SITRANS LR260, under Process Connection Specifications.
• Signal amplitude increases with horn diameter, so use the largest practical size.
enclosure/electronics
name-plate
universal slotted
flange
horn
sensor
reference
point
retaining collar
process device tag
268 mm
(10.6")
49 mm
(1.9")
74.5 mm
(2.9")
97.5 mm
(3.8")
2" horn
3" horn
4" horn
2" horn: 163 mm (6.4")
3" horn: 228 mm (9.0")
4" horn: 285 mm (11.2")
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 9
mmmmm
Installation
Installation
1
WARNINGS:
• Installation shall only be performed by qualified personnel and in
accordance with local governing regulations.
• SITRANS LR260 is to be used only in the manner outlined in this manual,
otherwise protection provided by the device may be impaired.
• Never attempt to loosen, remove, or disassemble process connection
or instrument housing while vessel contents are under pressure.
• This product is designated as a Pressure Accessory per Directive
97/23/EC and is not intended for use as a safety device.
• Materials of construction are chosen based on their chemical
compatibility (or inertness) for general purposes. For exposure to
specific environments, check with chemical compatibility charts
before installing.
• The user is responsible for the selection of bolting and gasket materials
which will fall within the limits of the flange and its intended use and
which are suitable for the service conditions.
• Improper installation may result in loss of process pressure.
Notes:
• For European Union and member countries, installation must be according to ETSI
EN 302372.
• Refer to the device nameplate for approval information.
• The Process Device Tag shall remain with the process pressure boundary
assembly1. In the event the instrument package is replaced, the Process Device Tag
shall be transferred to the replacement unit.
• SITRANS LR260 units are hydrostatically tested, meeting or exceeding the
requirements of the ASME Boiler and Pressure Vessel Code and the European
Pressure Equipment Directive.
• The serial numbers stamped in each process connection body provide a unique
identification number indicating date of manufacture.
Example: MMDDYY – XXX (where MM = month, DD = day, YY = year, and
XXX= sequential unit produced)
Further markings (space permitting) indicate flange configuration, size, pressure
class, material, and material heat code.
1. The process pressure boundary assembly comprises the components that act as a
barrier against pressure loss from the process vessel: that is, the combination of
process connection body and emitter, but normally excluding the electrical enclosure.
Page 10 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Installation
Mounting location
Nozzle design
• The end of the horn must protrude
a minimum of 10 mm (0.4”) to avoid
false echoes being reflected from
the nozzle.
• Optional antenna extensions:
100 mm (3.93"), 200 mm (70.9"),
500 mm (19.69"), 1000 mm (39.4")
Nozzle location
• Keep emission cone free of
interference from ladders,
pipes, I-beams or filling
streams.
• Avoid central locations on
tall, narrow vessels.
• Align the antenna so that the
radar cone is perpendicular
to the surface of the
monitored material, if
possible. (See
Easy Aimer
on page 12.)
Notes:
• Correct location is key to a successful application.
• Avoid reflective interference from vessel walls and obstructions by following the
guidelines below
Notes:
• Beam width depends on horn size:
see below.
• For details on avoiding false echoes,
see
Auto False Echo Suppression
on
page 88.
Min. clearance:
10 mm (0.4")
beam width:
2" horn = 15°
3" horn = 10°
4" horn = 8°
emission
cone
min. 1 m (39")
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 11
mmmmm
Installation
Nozzle location (continued)
• Provide easy access for viewing the display and programming via the hand
programmer.
• Provide an environment suitable to the housing rating and materials of construction.
• Provide a sunshield if the instrument will be mounted in direct sunlight.
Orientation in a vessel with obstructions
Polarization reference point
ambient temperature –40 °C
to 80 °C (–40 °F to 176 °F)
process temperature (with FKM O-ring)
–40 to +200 °C (–40 to +392 °F)
polarization
reference
point
polarization
axis
display
For best results on a vessel with
obstructions, orient the front or back of
the device toward the obstructions.
Page 12 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Installation
Easy Aimer
1. Holding the electronics enclosure firmly,
loosen the Easy Aimer ball locking bolts and
gently reposition the enclosure.
2. Direct SITRANS LR260 so the horn antenna is
pointed at an angle perpendicular to the
material surface, if possible. (As a guide, aim
the beam at a point approximately 2/3 of the
way across the tank diameter.)
3. When the desired position is reached, re-
tighten the 5 bolts to 15-23 N m (11 to 17 Lbf-ft).
Note: When the Easy Aimer ball is loosened, the device is free to tilt to a maximum of
30°.
top clamping plate (upper socket)
bottom clamping plate
(lower socket)
customer gasket as
required [recommended
thickness 1.5 to 1.8 mm (0.06
to 0.07")]
customer mounting plate,
as required
ø 4" (102 mm) min.,
central opening
30°
max.
285 mm
(11.22")
0.38"
(10 mm)
Easy Aimer ball locking bolts
Easy Aimer
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 13
mmmmm
Installation
Air Purging System (Optional)
For more frequent cleaning, a purging system can be installed between the flange and the
horn antenna. The system provides an 1/8" inlet (female thread) on the flange where
cooling air or cleaning fluid passes through the flange and exits the inside of the horn to
clean it. The customer will supply the purging medium by a manual or automatic valve
system.
This option is only available with the universal flange for purging shown on page 14. 1
• The purge connection is closed
by the manufacturer, using a 1/8"
plug.
• When the plug is removed to
connect a purging system, the
operator is responsible for
ensuring that the purging circuit
conforms to "Ex" requirements:
for example, by fitting an NRV
valve.
Notes:
• The Air Purge feature should not be activated with a dust cap in place.
• Purge duration, pressure, and interval, will vary with each application. It is the user’s
responsibility to determine the requirements depending on the application and
cleaning required.
• Short duration bursts of high pressure provide more effective cleaning than
continuous low pressure air.
• Some dust particles are highly abrasive and can be drawn into the inside of the horn
during purge cleaning, damaging the internal PTFE emitter of the antenna. A
replacement kit is available from your local Siemens Milltronics representative.
• It is the customer’s responsibility to ensure that any vacuum or pressure in the
measured vessel is maintained, considering the hole that passes through the
process connection and SITRANS LR260 antenna system.
Recommendation for
effective cleaning
Air Consumption
(Flow rate versus applied pressure)
Pressure: 90 to 110 psi
Air Pressure Approx. inlet volume flow rate
20 5 SCFM
40 6 SCFM
Inlet flow: 10 SCFM 1
60 8 SCFM
80 9 SCFM
90 10 SCFM
1. SCFM (standard cubic feet/minute) referenced to 14.7 psia, 68°F and 36% relative humidity (RH).
purged process
connection with factory-
installed 1/8" NPT plug
Page 14 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Installation
Universal Slotted Flange
Slotted Flange Dimensions (see above)1
WARNING: The user is responsible for the selection of bolting and
gasket materials which will fall within the limits of the flange and its
intended use and which are suitable for the service conditions.
Pipe
Size
Flange
O.D.
Thick-
ness (s)
Bolt Hole
Circle Max Ø
Bolt Hole
Circle Min Ø
Bolt Hole
radius
No. of
Slotted
Holes
3" or
80 mm
7.87"
(200 mm)
0.38"
(9.65 mm)
6.30"
(160 mm)
5.91"
(150 mm)
0.38"
(9.5 mm)
8
4" or
100 mm
9.00"
(229 mm)
0.38"
(9.65 mm)
7.52"
(191 mm)
6.89"
(175 mm)
0.38"
(9.5 mm)
8
6" or
150 mm
11.22"
(285 mm)
0.38"
(9.65 mm)
9.53"
(242 mm)
9.45"
(240 mm)
0.45"
(11.5 mm)
8
1.Universal flange mates with EN 1092-1 / ASME B16.5 / JIS B2238 bolt hole pattern.
flange O.D.
bolt hole circle
min. diameter
number of slotted bolt holes
section A-A
thickness
bolt hole circle max. diameter
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 15
mmmmm
Installation
Optional Dust Cap
The dust cap fits onto the end of the horn and prevents the buildup of dust and other
process material inside the horn.
• It is particularly useful for applications in areas of high humidity, or with bulk solids
with a high moisture content.
• Three sizes are available, to fit the standard 2", 3" and 4" horns.
Installation
1. Thoroughly clean inside the horn. If you remove the horn for easier cleaning, take
care not to damage or bend the plastic emitter.
2. Press the cap firmly onto the horn until the ridge inside the cap snaps into position in
the groove on the outside of the horn.
3. Hand tighten the adjustable clamp supplied to secure the cap.
4. Use a screwdriver or nut driver to tighten the clamp screw until the clamp provides
an air-tight seal.
Note: The dust cap must be removed before using the Air Purge feature (see
Air
Purging System (Optional)
on page 13).
Note: It is critical to ensure no moisture can be trapped inside.
plastic emitter
groove ridge dust cap
clamp screw
Page 16 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Installation
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 17
mmmmm
Wiring
Wiring
Power
Connecting SITRANS LR260
1
WARNINGS:
The DC input terminals shall be supplied from a source providing
electrical isolation between the input and output, in order to meet
the applicable safety requirements of IEC 61010-1.
All field wiring must have insulation suitable for rated voltages.
WARNINGS:
• Check the nameplate on your instrument, to verify the approval rating.
• Use appropriate conduit seals to maintain IP or NEMA rating.
•Read
Instructions specific to hazardous area installations
on page 19.
Notes:
• Use twisted pair cable: AWG 22 to 14 (0.34 mm2 to 2.5 mm2).
• Separate cables and conduits may be required to conform to standard
instrumentation wiring practices or electrical codes.
1. Depending on the approval rating, glands and plugs may be supplied with your
instrument.
Use a 2 mm Allen key to loosen the lid-lock set screw.
Unscrew the cover for access to the terminals. Use a
screwdriver for added leverage, if necessary.
cable gland1
(or NPT cable entry)
plug1
Page 18 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Wiring
1. Strip the cable jacket for approximately
70 mm (2.75") from the end of the cable, and
thread the wires through the gland1.
2. Connect the wires to the terminals as
shown: the polarity is identified on the
terminal block.
3. Ground the instrument according to local
regulations.
4. Tighten the gland to form a good seal.
Connecting HART23
1. If cable is routed through conduit, use only approved suitable-size hubs for
waterproof applications.
2. Depending on the system design, the power supply may be separate from the
PLC, or integral to it.
3. Loop resistance (total of cable resistance plus 250 Ohm [resistor]) must be less
than 550 Ohm for the device to function properly.
cable shield
(if used)
active PLC
HART modem
SITRANS LR260
power supply (2)
Typical PLC/mA configuration with HART
R= 250 Ω (3)
HART
communicator
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 19
mmmmm
Wiring
Wiring setup for hazardous area installations
(UNDER REVISION)
The nameplate shown is a typical example. In all cases, check the nameplate on your
instrument, and confirm the approval rating.
Instructions specific to hazardous area installations
(Reference European ATEX Directive 94/9/EC, Annex II, 1/0/6)
The following instructions apply to equipment covered by certificate number
Sira 06 ATEX 9218X.
1. For use and assembly, refer to the main instructions.
2. The equipment is certified for use as Category II 1D, 1/2 D & 2D equipment. The
Essential Health and Safety Requirements are assured by compliance with
IEC 61241-0: 2004 and IEC 61241-1: 2004.
3. The equipment may be used with dust and fibers with apparatus temperature
class T (see table
Thermal Data for 7ML5427 Series
on page 19).
4. Thermal Data for 7ML5427 Series
5. The equipment has not been assessed as a safety related device (as referred to by
Directive 94/9/EC Annex II, clause 1.5).
6. Installation and inspection of this equipment shall be carried out by suitably trained
personnel in accordance with the applicable code of practice (EN 61241-14 and EN
61241 –17 in Europe).
7. Repair of this equipment shall be carried out by suitably trained personnel in
accordance with the applicable code of practice.
Note: Installation shall be performed only by qualified personnel and in accordance
with local governing regulations.
Device
category
Permitted ambient
temperature at horn antenna
Permitted ambient
temperature at electronic
enclosure
1D, 1/2D, 2D –40 °C (–40 °F) ≤ Tamb ≤+200°C
(+392 °F)
–40 °C (–40 °F) ≤ Tamb ≤ +65°C
(+149 °F)
updated graphic to come
Page 20 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Wiring
8. Components to be incorporated into or used as replacements in the equipment shall
be fitted by suitably trained personnel in accordance with the manufacturer’s
documentation.
9. It is the user’s responsibility to ensure that a manual override is possible in order to
shut down the equipment, and that protective systems are incorporated within
automatic processes which deviate from the intended operating conditions,
provided that this does not compromise safety.
10. Equipment Marking: The equipment marking contains at least the information on the
product label. See
Wiring setup for hazardous area installations (UNDER REVISION)
on page 19.
11. If the equipment is likely to come into contact with aggressive substances, it is the
user’s responsibility to take suitable precautions to prevent it from being adversely
affected, and to ensure that the type of protection is not compromised.
• Aggressive substances include, for example, acidic liquids or gases that may
attack metals, or solvents that may affect polymeric materials.
• Suitable precautions include, for example, regular checks as part of routine
inspections, or establishing from the material’s data sheet that it is resistant to
specific chemicals.
SPECIAL CONDITIONS FOR SAFE USE
The ‘X’ suffix to the certificate number relates to the following special condition(s) for
safe use.
• Cable or conduit entries must meet the requirements of European Directive
94/9/EC for Group II, Category 1D, 1/2D, or 2D, as appropriate, and must
maintain the overall IP rating of the enclosure.
• For applications that require the purge feature, the user shall implement a
means to ensure that combustible dust from the hazardous area cannot enter
the purge supply in such a way as to compromise the area classification.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 21
mmmmm
Quick Start: local
Quick Start via local operation
SITRANS LR260 carries out its level measurement tasks according to settings made via
parameters. The settings can be modified locally via the Local User Interface (LUI) which
consists of an LCD display and a handheld programmer.
A Quick Start Wizard provides an easy step-by-step guide to help you configure the
device for a simple application. There are two ways to access the wizard:
•7-step
Quick Start Wizard via the handheld programmer
on page 28
•4-step
Quick Start Wizard via SIMATIC PDM
on page 32
For more complex setups, see
Appendix E: Application Example
on page 98, and for the
complete range of parameters see
Parameter Reference
on page 42.
Activating SITRANS LR260
Power up the instrument. SITRANS LR260 automatically starts up in Measurement (RUN)
mode. Press Mode to toggle between Measurement and Program Mode.
The LCD Display
Measurement mode (RUN mode)
1
Normal operation
Fault present
Note: Keep infrared devices such as laptops, cell phones, and PDAs, away from
SITRANS LR260 to prevent inadvertent operation.
1. In response to a key press request. For details, see
Key functions in Measurement mode
on
page 23.
M
[]
LEVEL
21.40 °C
DATA EXCH.
18.91
1 – toggle indicator for linear units or %
2 – selected operation: level, space, or distance
3 – measured value (level, space, or distance)
4 – units
5 – bar graph indicates level
6 – secondary region indicates on request1
electronics temperature, echo confidence,
loop current, or distance
7 – text area displays status messages
8 – device status indicator
67
8
1342
5
S: 0 LOE
7 – text area displays a fault code and an error message
8 – service required icon appears
Page 22 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML1998JE01
mmmmm
Quick Start: local
PROGRAM mode display
Navigation view
Parameter view
Edit view
Menu bar in navigation view
current item
number
pointer
current item
current
menu
menu bar
(see below
for details)
parameter
value/selection
parameter
number
parameter
name
SENSOR CAL.
HIGH CALIB. PT.
NEAR RANGE
FAR RANGE
2.2.1.6
LOW CALIB. PT.
• A visible menu bar indicates the menu list is
too long to display all items.
• The depth and relative position of the item
band on the menu bar indicates the length of
the menu list, and approximate position of the
current item in the list.
• A deeper band indicates fewer items.
• A band halfway down the menu bar indicates
the current item is halfway down the list.
menu
bar
item
band
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 23
mmmmm
Quick Start: local
Handheld Programmer (Part No. 7ML1930-1BK)
Key functions in Measurement mode
Key Function Result
Updates the loop
current. New value is displayed in LCD secondary region.
Updates internal
enclosure temperature
reading.
New value is displayed in LCD secondary region.
Updates echo
confidence value. New value is displayed in LCD secondary region.
Updates distance
measurement. New value is displayed in LCD secondary region.
Mode opens
PROGRAM mode.
Opens the menu level last displayed in this power cycle,
unless power has been cycled since exiting PROGRAM
mode or more than 30 minutes have elapsed since
PROGRAM mode was used. Then top level menu will be
displayed.
Right ARROW
opens PROGRAM
mode.
Opens the top level menu.
Up or Down ARROW
toggles between
linear units and
percent.
LCD displays measured value in either linear units or
percent.
C
The programmer is ordered separately.
Page 24 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML1998JE01
mmmmm
Quick Start: local
Programming SITRANS LR260
Change parameter settings and set operating conditions to suit your specific application.
•See
Operating via SIMATIC PDM
on page 31 for remote operation.
Programming via the handheld programmer
Parameter menus
Parameters are identified by name and organized into function groups, then arranged in a
5-level menu structure (see
LCD menu structure
on page 115).
• For the complete list of parameters with instructions, see
Parameter Reference
on page 42.
1. Enter PROGRAM mode
• Point the programmer at the display (from a
maximum distance of 500 mm [1.6 ft.]).
•Right ARROW activates PROGRAM
mode and opens menu level 1.
•Mode opens the menu level last
displayed in PROGRAM mode within the last
30 minutes, or menu level 1 if power has
been cycled since then.
Notes:
• The Quick Start wizard settings are inter-related and changes apply only after you
click on Apply at the end of the Quick Start steps.
• Do not use the Quick Start wizard to modify individual parameter: see instead
Parameter Reference
on page 42.
• Initial Quick Start parameter values are not default values and do not necessarily
reflect the current device configuration.
• SITRANS LR260 automatically returns to Measurement mode after a period of
inactivity in PROGRAM mode (between 15 seconds and 10 minutes, depending on
the menu level).
Note: SITRANS LR260 automatically returns to Measurement mode after a period of
inactivity in PROGRAM mode (between 15 seconds and 10 minutes, depending on the
menu level).
1. QUICK START
2. SETUP
2.1. DEVICE
2.2. INPUT
2.2.1. SENSOR CALIB.
2.2.4. ECHO PROC.
Note:
In Navigation mode
ARROW keys move to the
next menu item in the
direction of the arrow.
display
handheld programmer
(ordered separately)
max. 500 mm
(1.6 ft)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 25
mmmmm
Quick Start: local
2. Navigating: key functions in Navigation mode
Note: For Quick Access to parameters via the handheld programmer, press
Home , and then enter the menu number, for example: 2.2.1.
Key Name Menu level Function
Up or Down
ARROW menu or parameter Scroll to previous or next menu or
parameter.
Right ARROW menu Go to first parameter in the selected
menu, or open next menu.
parameter Open Edit mode.
Left ARROW menu or parameter Open parent menu.
Mode menu or parameter Change to MEASUREMENT mode.
Home menu or parameter Open top level menu: menu 1.
Page 26 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML1998JE01
mmmmm
Quick Start: local
3. Editing in PROGRAM mode
Selecting a listed option
a. Navigate to the desired parameter.
b. Press Right ARROW to open parameter
view.
c. Press Right ARROW again to open Edit
mode. The current selection is highlighted.
Scroll to a new selection.
d. Press Right ARROW to accept it
The LCD returns to parameter view and displays
the new selection.
Changing a numeric value
a. Navigate to the desired parameter.
b. Press Right ARROW to open parameter
view. The current value is displayed.
c. Press Right ARROW again to open Edit
mode. The current value is highlighted.
d. Key in a new value.
e. Press Right ARROW to accept it. The LCD
returns to parameter view and displays the new
selection.
Key functions in Edit mode
Key Name Function
Up or
Down
ARROW
Selecting
options Scrolls to item.
Numeric
editing
- Increments or decrements digits
- Toggles plus and minus sign
Right
ARROW
Selecting
options
- Accepts the data (writes the parameter)
- Changes from Edit to Navigation mode
Numeric
editing
- Moves cursor one space to the right
- or with cursor on Enter sign, accepts the data
and changes from Edit to Navigation mode
Left
ARROW:
Selecting
options
Cancels Edit mode without changing the
parameter
Numeric
editing
- Moves cursor to plus/minus sign if this is the
first key pressed
- or moves cursor one space to the left.
parameter name
current
value
parameter
number
parameter
number
parameter name
current
selection
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 27
mmmmm
Quick Start: local
Requesting an Echo Profile
a. In PROGRAM mode, navigate to:
LEVEL METER > DIAGNOSTICS >
ECHO PROFILE (3.1)
b. Press Right ARROW to request a
profile.
c. In the Profile screen, press Up
ARROW to select the Transmit icon,
and Right ARROW to update the
profile.
d. Press Down ARROW to select the
Exit icon, then Right ARROW to
return to previous menu.
Clear Numeric
editing Erases the display.
Decimal
point
Numeric
editing Enters a decimal point.
Plus or
minus sign
Numeric
editing Changes the sign of the entered value.
to
Numeral Numeric
editing Enters the corresponding character.
Key Name Function (Continued)
DIAGNOSTICS
MEAS. VALUES
REMAIN. DEV. LIFE
REMAIN. SENS. LIFE
3.1
ECHO PROFILE
transmit icon,
selected
exit icon,
deselected
transmit icon,
deselected
exit icon,
selected
Page 28 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML1998JE01
mmmmm
Quick Start: local
Quick Start Wizard via the handheld programmer
1. Quick Start
a. Point the programmer at the display (from a maximum distance of 500 mm [1.6 ft.]),
then press Right ARROW to activate PROGRAM mode and open menu level 1.
b. Press Right ARROW twice to navigate to menu item 1.1 and open parameter
view.
c. Press Right ARROW to open Edit mode or Down ARROW to accept default
values.
d. To change a setting, scroll to the desired item or key in a new value.
e. After modifying a value, press Right ARROW to accept it and press Down
ARROW to move to the next item.
f. Quick Start settings take effect only after you select Yes to Apply changes in step 1.7.
1.1. Application Type
1.2. Response Rate
Sets the reaction speed of the device to measurement changes in the target range.
Use a setting just faster than the maximum filling or emptying rate (whichever is
greater). Slower settings provide higher accuracy; faster settings allow for more
level fluctuation
1.3. Units
Select the units for the Quick Start variables (high and low calibration point, and level,
distance, or space)
Notes:
• The Quick Start Wizard is a complete package and the settings are inter-related.
• Do not use the Quick Start wizard to modify individual parameters: see instead
Parameter Reference
on page 42.
• Each time the Quick Start Wizard is initiated, the start-up settings are factory
defaults. The Wizard will not recall previous user-defined settings.
• Perform customization for your application after the quick start has been completed.
• Whenever the Quick Start Wizard is used, Echo Position (2.2.4.1.2) is reset to Rising
Edge.
Options STEEL Silo construction
CONCRETE
Options
SLOW 0.1 m/minute
MED 1.0 m/minute
FAST 10.0 m/minute
Options M, CM, MM, FT, IN
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 29
mmmmm
Quick Start: local
1.4. Operation
1
1.5. Low Calibration Point
Distance from Sensor Reference to Low Calibration Point: usually process empty
level. (See 1.4. Operation for an illustration.)
1.6. High Calibration Point
Distance from Sensor Reference to High Calibration Point: usually process full level.
(See 1.4. Operation for an illustration.)
1.7. Apply? (Apply changes)
In order to save the Quick Start settings it is necessary to select Yes to apply changes.
Display shows DONE when Quick Start is successfully completed.
Press Mode to return to Measurement mode. SITRANS LR260 is now ready to operate.
Operation
types
NO
SERVICE
The SITRANS LR260 stops updating measurements and
associated loop current. Last valid measurement is displayed.
LEVEL Distance to material surface referenced from Low Calibration
Point (process empty level).
SPACE Distance to material surface referenced from High Calibration
Point (process full level).
DISTANCE Distance to material surface referenced from Sensor
Reference Point.
1. The point from which High and Low Calibration points are referenced: see
Dimensions
on page 8 and
Flanged Horn
on page 8.
Values Range: 0.0000 to 30.000 m
Values Range: 0.0000 to 30.000 m
Options YES, NO, DONE
high
calibration
point
low calibration point
level
space
distance
sensor reference point
(flange face)
Page 30 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML1998JE01
mmmmm
Quick Start: local
Level application example
Fill rate = 0.09 m/minute (Low Cal Pt. minus High Cal Pt.) / fastest fill/empty time
= (16 m – 0.5 m) / 180 min.
= 15.5 m /180 min. = 0.09 m/min.
Auto False Echo Suppression
If SITRANS LR260 displays a false high level, or the reading is fluctuating between the
correct level and a false high level, you can use the Auto False Echo Suppression
parameters to prevent false echo detection. See
2.2.5. TVT (Auto False Echo Suppression)
setup (TVT SETUP)
for instructions.
Quick Start Setting Description
APPLICATION STEEL
RESPONSE RATE SLOW Response rate = 0.1 m/minute.
UNITS m
OPERATION LEVEL Material level referenced from Low Calibration Point.
LOW CALIBRATION POINT 16 Process empty level.
HIGH CALIBRATION POINT 0.5 Process full level.
APPLY? (CHANGES) YES Save new settings.
Sensor Reference Point
level
Low Calibration Point
High Calibration Point
16 m
0.5 m
SITRANS LR260
The application is a steel silo containing flour that takes an average of 3 hours to fill and
3 weeks to empty.
Using the Easy Aimer, the LR260 is oriented so that the emission cone is approximately
perpendicular to the material surface.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 31
mmmmm
SIMATIC PDM
Operating via SIMATIC PDM
SIMATIC PDM is a software package used to commission and maintain SITRANS LR260 and
other process devices. Please consult the operating instructions or online help for details on
using SIMATIC PDM. (You can find more information at www.fielddevices.com: go to Products
and Solutions > Products and Systems > Communications and Software > Process Device
Manager.)
Functions in SIMATIC PDM
SIMATIC PDM monitors the process values, alarms and status signals of the device. It allows
you to display, compare, adjust, verify, and simulate process device data.
For information on adjusting parameter values and viewing the results, see
Changing
parameter settings using SIMATIC PDM
on page 36 and
Parameters accessed via pull-down
menus
on page 36.
Features of SIMATIC PDM Rev. 6.0, SP2, HF1 (or higher)
The graphic interface in SITRANS LR260 makes monitoring and adjustments easy.
• The graphic Quick Start Wizard provides an easy 4-step guide to help you configure
the device for a simple application. See
Quick Start Wizard via SIMATIC PDM
on
page 32 for instructions.
•See
Online Display
on page 37 to monitor process variables.
•See
Echo profile saving
on page 37 for easy echo profile comparison.
•See
Trend Diagram (Level Trend over Time)
on page 38 for Level trend monitoring.
•See
Auto False Echo Suppression
on page 39 and
Manual TVT Shaper
on page 40
on adjusting the TVT curve to avoid false echoes.
Note: For a complete list of parameters with instructions, see
Parameter Reference
starting on page 42.
Notes:
• While the device is in PROGRAM MODE, the output remains active and
continues to respond to changes in the device.
• Do not use the handheld programmer at the same time as SIMATIC PDM, or
erratic operation may result.
Page 32 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SIMATIC PDM
Device Description (DD)
You can locate the DD in Device Catalog, under Sensors/Level/Echo/Siemens Milltronics/
SITRANS LR260. Check the product page of our website at: www.siemens.com/LR260, under
Downloads, to make sure you have the latest version of SIMATIC PDM, the most recent
Service Pack (SP) and the most recent hot fix (HF). If you need to install a new DD, see
Configuring a new device
on page 32.
Configuring a new device
1. Check that you have the most recent DD that applies to your device version, and if
necessary download it from the product page listed above. Save the files to your
computer, and extract the zipped file to an easily accessed location. Launch SIMATIC
PDM – Manager Device Catalog, browse to the unzipped DD file and select it.
2. Launch SIMATIC Manager and create a new project for LR260. Application Guides
for setting up HART devices with SIMATIC PDM can be downloaded from the
product page of our website at: www.siemens.com/LR260.
3. Open the Menu Device – Device Reset and click on OK to perform a reset to Factory
Defaults.
4. After the reset is complete upload parameters to the PC/PG.
5. Calibrate the device.
Quick Start Wizard via SIMATIC PDM
The graphic Quick Start Wizard provides an easy 4-step guide to help you configure the
device for a simple application.
Please consult the operating instructions or online help for details on using SIMATIC
PDM. (Application Guides for setting up Siemens HART instruments with SIMATIC PDM
are available on our website: www.siemens.com/processautomation.)
1. If you have not already done so, check that you have the most up-to-date Device
Description (DD) for your instrument. (See
Configuring a new device
above.)
2. Launch SIMATIC Manager and create a new project for LR260. Application Guides
for setting up HART and PROFIBUS PA devices with SIMATIC PDM can be
downloaded from the product page of our website at: www.siemens.com/LR260.
3. Open the menu Device – Device Reset and click on OK to perform a reset to Factory
Defaults.
4. After the reset is complete upload parameters to the PC/PG.
5. Configure the device via the Quick Start Wizard.
Note: SITRANS LR260 requires the DD for SIMATIC PDM version 6.0 with SP2 and HF1,
or higher.
Note: Clicking on Cancel during an upload from device to SIMATIC PDM will result in
some parameters being updated.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 33
mmmmm
SIMATIC PDM
Quick Start Wizard steps
Launch SIMATIC PDM, open the menu Device – Quick Start, and follow steps 1 to 4.
Step 1 – Identification
Click on NEXT to accept the default values. (Description, Message, and Installation Date
fields can be left blank.)
Notes:
• The Quick Start wizard settings are inter-related and changes apply only after you
click on Transfer at the end of step 4.
• Do not use the Quick Start Wizard to modify individual parameters: see instead
Parameter Reference
on page 42. (Perform customization only after the Quick Start
has been completed.)
• Initial Quick Start parameter values are not default values and do not necessarily
reflect the current device configuration.
• Click on BACK to return and revise setting or Cancel to exit the Quick Start.
Note: The layout of the dialog boxes shown may vary according to the resolution setting
for your computer monitor.
Page 34 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SIMATIC PDM
Step 2 – Application Type
Select the application type (level) and the operation, then click on NEXT.
Step 3 – Range Setup
Set the parameters, and click on NEXT.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 35
mmmmm
SIMATIC PDM
Step 4 – Summary
Check parameter settings, and click on BACK to return and revise values, or TRANSFER
to transfer values to the device.
The message Quick Setup was successful will appear. Click on OK, then click on OK again to
synchronize with the device.
Page 36 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SIMATIC PDM
Changing parameter settings using SIMATIC PDM
1. Launch SIMATIC PDM, connect to SITRANS LR260, and upload data from the
device.
2. Adjust parameter values in the parameter value field then press Enter. The status
fields read Changed.
3. Open the Device menu, click on Download to device, then use File – Save, to save
parameter settings. The status fields are cleared.
Parameters accessed via pull-down menus
You have access to a number of functions via pull-down menus from the menu bar under
Device or View.
For a complete list see
Pull-down menus via SIMATIC PDM
on page 42.
Notes:
• For a complete list of parameters, see
Parameter Reference
on page 42.
• Clicking on Cancel during an upload from device to SIMATIC PDM will result in some
parameters being updated.
value
fields
pull-down
menus
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 37
mmmmm
SIMATIC PDM
Online Display
To compare outputs in real time, open the menu View – Display.
Echo profile saving
Notes:
• Double click on each axis and record the Xscale and Data Scale values, so that you
can restore the default view by resetting to these values.
• You can save a profile or delete a saved profile.
• After saving a profile open menu View – Echo profile.
delete
save
Page 38 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SIMATIC PDM
Trend Diagram (Level Trend over Time)
Open the menu View – Trend
Notes:
• Double click on each axis and record the Xscale and Data Scale values, so that you
can restore the default view by resetting to these values.
trend line
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 39
mmmmm
SIMATIC PDM
Auto False Echo Suppression
SITRANS LR260 first learns the echo profile. Then the learned profile, or part of it, is used to
screen out false echoes. (See
Auto False Echo Suppression
on page 88 for a more detailed
explanation.)
1. Determine Auto Suppression Range (the distance within which the learned TVT will
replace the default TVT). Measure the actual distance from the antenna reference
point to the material surface using a rope or tape measure, and make allowances
for the actual location of the LR260. Subtract 2 m (6.56 ft) from this distance, and use
the resulting value.
2. Open the menu Device – Auto False Echo Suppression.
3. Enter the value for Auto Suppression Range and click on Set Range.
4. Click on Learn. The Learn, On, Off, and Set Range buttons may disappear while the
new curve is being learned.
5. When buttons are visible, click on Close. Auto TVT is now on, and the learned TVT
curve will be used.
6. To turn Auto False Echo Suppression off or on, reopen menu Device – Auto False
Echo Suppression and click on Off or On.
Notes:
• If possible adjust Auto False Echo Suppression parameters with an empty or almost
empty vessel. There should be a minimum distance of 2 meters from the radar
instrument to the material.
• Set Auto False Echo Suppression and Auto Suppression Range during startup, if
possible.
• Before adjusting these parameters, rotate the instrument for best signal (lower
false-echo amplitude).
Page 40 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
SIMATIC PDM
Manual TVT Shaper
This feature allows you to manually adjust the TVT curve to avoid false echoes caused by
obstructions. (For an explanation see
Auto False Echo Suppression
on page 88.)
Open the menu Device – TVT Shaper
• Press Measure to refresh the echo profile and load the current TVT curve from the
device.
• Change the position of the X cursor on the TVT curve using the Point+ and Point–
buttons: raise and lower the curve using Offset+ and Offset–.
• Alternatively, enter values for Point and Offset directly into the dialog boxes.
• Press Transfer to Device.
Note: Double click on each axis and record the Xscale and Data Scale values, so that
you can restore the default view by resetting to these values.
TVT curve
cursor
echo profile
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 41
mmmmm
SIMATIC PDM
Device Reset
Factory Defaults
Use Factory Defaults to reset all parameters excluding device addresses to the default
settings.
1. Open the menu Device – Device Reset and click on OK to perform a reset to Factory
Defaults.
2. After the reset is complete, upload parameters to the PC/PG. (If you are performing a
reset after replacing the device with a different instrument, do not upload
parameters to the PC/PG).
Configuration Flag Reset
To reset the configuration flag to zero, open the menu Device – Configuration Flag Reset
and execute a reset.
D/A (Digital/Analog) Trim
Allows you to trim the 4 mA and 20 mA points in order to calibrate the mA output.
Open the menu Device – D/A Trim. You will be prompted to attach a calibrated meter and
enter the values at 4 mA and at 20 mA.
Simulate AO (Analog Output)
Allows you to input a simulated value in order to test the functioning of the mA
connections during commissioning or maintenance of the device.
To simulate a user-defined mA value:
1. Open the menu Device – Simulate AO.
2. Select Other, enter the new value, and click on OK. The message ’Field Device
fixed at new value’ appears. Click on OK.
3. When you are ready to end simulation, select End and click on OK to return the
device to the original output level.
Set Address
The default address for the device is 0. To reset the address via the handheld programmer see
5.1.Device Address
on page 70.
Page 42 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
Parameter Reference
Parameters are identified by name and organized into function groups. Menus arranged
on up to five levels give access to associated features and options. (See
LCD menu
structure
on page 115 for a chart.)
Parameters accessible via the handheld programmer are preceded by a number.
Parameters not preceded by a number are accessible only via SIMATIC PDM.
Some parameters are accessible in SIMATIC PDM via pull-down menus. Where those
parameters can also be accessed via the handheld programmer, they are found in the
numbered list, and directions for SIMATIC PDM are given beside the individual
parameter. Page references for further information can be found under
Pull-down menus
via SIMATIC PDM
below.
Pull-down menus via SIMATIC PDM
Notes:
• See
Programming via the handheld programmer
on page 24 for detailed instructions.
• Do not use the handheld programmer at the same time as SIMATIC PDM, or erratic
operation may result.
•Mode toggles between PROGRAM and Measurement Modes.
• For Quick Access to parameters via the handheld programmer, press Home , then
enter the menu number, for example: 2.2.1.
Device menus page View menus page
Communication path - Display 37
Download to device
Upload to PC/PG
Update Diagnostic Status
-
-
-
Identification
Trend
Echo Profile
Show Echo Profile
Device Status
Wear (powered days/poweron
resets)
-
38
37
37
-
66
Quick Start
Auto False Echo Suppression
TVT shaper
43
52
54
Maintenance
Self test
Device Reset
Configuration Flag Reset
66 to 68
-
41
-
Too lbar
Status bar
Select Analog Out
D/A Trim
Simulate AO
-
41
41
HART Communication 100 Update
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 43
mmmmm
Parameters
Quick Start Wizard
The Quick Start wizard groups together all the settings you need to configure for a simple
application. You can access it either via SIMATIC PDM, or via the handheld programmer.
• The Quick Start wizard is a complete package and the settings are inter-related.
• Do not use the Quick Start wizard to modify individual parameters.
• Because the settings are inter-related, the initial Quick Start parameter values are
not default values.
• The initial Quick Start values do not necessarily reflect the current device
configuration.
• Perform customization of the device only after the Quick Start is completed.
1. Quick Start
1.1. Application Type
1.2. Response Rate
Sets the reaction speed of the device to measurement changes in the target range.
Use a setting just faster than the maximum filling or emptying rate (whichever is
greater). Slower settings provide higher accuracy; faster settings allow for more level
fluctuation.
1.3. Units
Select the units for the Quick Start variables (high and low calibration point, and level,
distance, or space).
Note: Whenever Quick Start Wizard is used, Position is reset to Rising Edge.
Options STEEL Silo construction
CONCRETE
Options
SLOW 0.1 m/minute
MED 1.0 m/minute
FAST 10.0m/minute
Options M, CM, MM, FT, IN
Page 44 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
1.4. Operation
Operation types
1.5. Low Calibration Point (LOW CALIB. PT.)
Distance from Sensor Reference to Low Calibration Point: usually process empty
level. (See Operation types for an illustration.)
1.6. High Calibration Point (HIGH CALIB. PT.)
Distance from Sensor Reference to High Calibration Point: usually process full level.
(See Operation types for an illustration.)
When setting the High Calibration Point value, note that echoes are ignored within
Near Range (2.2.1.11).
1.7. Apply? (Apply changes)
In order to save the Quick Start settings it is necessary to select Yes and apply
changes.
• Display shows DONE when Quick Start is successfully completed.
• Press Mode to return to Measurement mode.
Options
NO SERVICE
SITRANS LR260 stops updating measurements and
associated loop current. Last valid measurement value
is displayed.
LEVEL Distance to material surface referenced from Low
Calibration Point (process empty level).
SPACE Distance to material surface referenced from High
Calibration Point (process full level).
DISTANCE Distance to material surface referenced from Sensor
Reference Point.
Values Range: 0.0000 to 30.000 m
Values Range: 0.0000 to 30.000 m
Related parameters
2.2.1.11. Near Range
Options YES, NO, DONE
high
calibration
point
low calibration point
level
space
distance
sensor reference point
(flange face)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 45
mmmmm
Parameters
2. Setup
2.1. Device
2.1.1. Firmware Revision (FIRMWARE REV.)
Corresponds to the software or firmware that is embedded in the SITRANS
LR260. Read only.
2.1.2. Loader Revision (LOADER REV.)
Corresponds to the software used to update the SITRANS LR260. Read only.
2.1.3. Hardware Revision (HARDWARE REV.)
Corresponds to the electronics hardware of the SITRANS LR260. Read only.
2.2. Input
2.2.1. Sensor Calibration (SENSOR CALIB.)
You can configure each of the related parameters, to suit your particular
application.
2.2.1.1. Antenna
Sets antenna type.
2.2.1.4. Sensor Units
Units the sensor is measuring in.
2.2.1.5. Operation
Notes:
• See
Programming via the handheld programmer
on page 24 or
Operating via
SIMATIC PDM
on page 31 for instructions.
• Default settings in the parameter tables are indicated with an asterisk (*) unless
explicitly stated.
• Values shown in the following tables can be entered via the handheld programmer.
Values
(view only)
No Horn, Horn 2, Horn 3, Horn 4
Default is set by factory depending on horn size.
Values M, CM, MM, FT, IN
Default: M
Options
NO
SERVICE
SITRANS LR260 stops updating
measurements and associated loop current.
Last valid measurement value is displayed.
LEVEL
Distance to material surface referenced
from Low Calibration Point (process empty
level).
SPACE
Distance to material surface referenced
from High Calibration Point (process full
level).
*DIS-
TANCE
Distance to material surface referenced
from Sensor Reference Point.
Page 46 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
Operation types1
2.2.1.6. Low Calibration Pt. (LOW CALIB. PT.)
Distance from Sensor Reference to Low Calibration Point (corresponding to
Low Level Point). Units are defined in Sensor Units.
2
2.2.1.7. High Calibration Pt. (HIGH CALIB. PT.)
Distance from Sensor Reference to High Calibration Point (corresponding
to High Level Point). Units are defined in Sensor Units. (See Operation
types for an illustration.)
1. The point from which level measurement is referenced. For the reference point see for
each configuration, see
Dimensions
on page 8.
Values Range: 0 to 30 m. Default 30.000 m (dependent on horn
type)
2. The value produced by the echo processing which represents the distance from sen-
sor reference point to the target.
Values Range: 0 to 30 m. Default 0.000 m
Related parameters
2.2.1.11. Near Range
high
calibration
point
low calibration point
level
space
distance2
sensor reference point
(flange face)
Sensor Reference Point
(flange face)
Low Calibration Point
High Calibration Point
SITRANS LR260 with Easy Aimer
Level1
High Level Point
(typically 100%)
Low Level Point
(typically 0%)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 47
mmmmm
Parameters
When setting the High Calibration Point value, note that echoes are ignored
within Near Range (2.2.1.11).
2.2.1.11. Near Range
The range in front of the device (measured from the sensor reference point)
within which any echoes will be ignored, defined in sensor units. This is
sometimes referred to as blanking or a dead zone. The range is dependent
on the horn type and any extensions.
2.2.1.12. Far Range
Allows the material level to drop below Low Calibration Point without
generating a Loss of Echo (LOE) state. Unit is defined in Sensor units. See
2.2.1.6. Low Calibration Pt. (LOW CALIB. PT.) for an illustration.
Use this feature if the measured surface can drop below the Low Cal. Point
in normal operation.
2.2.1.24. Sensor Offset
A constant offset that can be added to Sensor value to compensate if the
sensor has been changed. Units are defined in Sensor Units.
Values
Factory Defaults
2" horn 0.214 m (8.43")
3" horn 0.278 m (10.95")
4" horn 0.335 m (13.19")
Options
Range: Min. = Low Calibration Pt.
Max. for 2" horn = 13 m (42.65 ft)
Max. for 3" horn = 23 m (75.46 ft)
Max. for 4" horn = 30 m (98.43 ft)
Default: Value for Low Calibration Pt. + 1 m (3.28 ft)
Values Default: 0 m
Page 48 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
2.2.4. Echo Processing (ECHO PROC.)
2.2.4.1. Echo select
2.2.4.1.1. Algorithm
Selects the algorithm to be applied to the echo profile to extract the true
echo.
2.2.4.1.2. Position
Defines where on the echo the distance measurement is determined.
(See
Echo Position Detection
on page 87
for more details.)
2.2.4.1.3. Echo Threshold
Sets the minimum echo confidence that the echo must meet in order to
prevent a Loss of Echo condition and the expiration of the LOE timer.
When Echo Confidence exceeds the Echo Threshold, the echo is
evaluated.
Options
ALF Area Largest First
AEcho Area
LLargest Echo
FFirst echo
AL Area Largest
AF Area First
LF Largest First
BLF Best of Largest or First echo
BL Best Largest
BF Best First
LLast echo
*tF
True First
Options
Rising Edge
* Center of Mass (COM)
Hybrid (Center and CLEF)
CLEF (Constrained Leading Edge Fit)
Note: Whenever Quick Start Wizard is used, Position is reset to Rising
Edge.
Values Range: 0 to 99
Default: 5
Related
Parameters
2.4.1. Fail-safe Timer
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 49
mmmmm
Parameters
Use this feature when an incorrect material level is reported.
2.2.4.1.5. Echo Marker
The point on the selected echo from which the measured value is taken.
2.2.4.2. Sampling
Provides a method of checking the reliability of a new echo before
accepting it as the valid reading, based on numbers of samples above or
below the currently selected echo.
2.2.4.2.1. Echo Lock
Selects the measurement verification process.
2.2.4.2.4. Up Sampling
Specifies the number of consecutive echoes that must appear above the
echo currently selected, before the measurement is accepted as valid.
2.2.4.2.5. Down Sampling
Specifies the number of consecutive echoes that must appear below the
echo currently selected, before the measurement is accepted as valid.
Values Range: 5 to 95%
Default: 70%
Related
Parameters
2.2.4.1.2. Position
Options
Lock Off
*Maximum Verification
Material Agitator
Total Lock (not recommended for radar)
Related
parameters
2.2.7.2. Fill Rate (FILL RATE/MIN)
2.2.7.3. Empty rate (EMPTY RATE/MIN)
2.2.4.2.4. Up Sampling
2.2.4.2.5. Down Sampling
2.2.4.2.6. Window
Values Range: 1 to 50
Default: 2
Values Range: 1 to 50
Default: 5
Page 50 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
2.2.4.2.6. Window
A "distance window" centered on the echo
1
, used to derive the reading.
When a new measurement is in the window, the window is re-centered
and the reading is calculated.
When the value is 0, the window is automatically calculated after each
measurement.
• For slower Measurement Response values, the window is narrow.
• For faster Measurement Response values, the window becomes
progressively wider.
2.2.4.3. Filtering
2.2.4.3.2. Damping Filter
The time constant for the damping filter. The damping filter smooths out
the response to a sudden change in level. This is an exponential filter and
the engineering unit is always in seconds. When a change occurs in the
level, the reported measurement will be at 63.2% of the change in one time
constant and will be at almost full change at the end of 5 time constants.
See Damping on page 90 for more detail.
2.2.4.3.6. Narrow Echo Filter
Filters out echoes of a specific width
To remove a false echo from the Echo Profile, take its width in mm and
multiply it by 0.013. Enter the result.
For example, to filter out a spike with 500 mm width, enter 6.5 (the product
of 500 x 0.013).
When a value is keyed in, the nearest acceptable value is entered.
1. See
Echo Lock
on page 87 for more detail.
Values Range: 0 to 30 m
Default: 0
Note: The echo lock window is stored as standard sample, but
displayed in sensor units. Any value entered for the echo lock window
will be rounded to the nearest sample.
Values Range: 0 to 1000.00 s
Default: 0 s
Values 0 = OFF
greater = wider
Related
parameters
Echo Confidence Long
2.2.4.3.7. Reform Echo
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 51
mmmmm
Parameters
2.2.4.3.7. Reform Echo
Smooths jagged peaks in the echo profile. Reforms fragmented echoes
into one echo.
2.2.4.5. Noise
2.2.4.5.1. Confidence
Measures echo reliability. It displays the echo confidence of the
measurement echo from the last shot. Echo Threshold defines the
minimum criterion for echo confidence. Confidence in the echo must be
larger than Echo Threshold for the device to select that echo.
In PDM, open the menu View – Echo Profile.
2.2.4.5.2. Strength
Displays the absolute strength (in dB referenced to 1 µV rms) of the echo
selected as the measurement echo.
In PDM, open the menu View – Echo Profile.
2.2.4.5.3. Noise Average
Displays the average ambient noise (in dB referenced to 1 µV rms) of a
noise profile. Noise level is a combination of transient noise and receiving
circuitry. After a measurement, the values from the previous noise shot
will be displayed.
Values
0 = OFF
greater = wider
Recommended range 10 to 20: higher is not
recommended.
Related
parameters
2.2.4.1.1. Algorithm
2.2.4.3.6. Narrow Echo Filter
2.2.4.1.5. Echo Marker
Values (view only) 0 to 99
---- Shot not used
Related Parameters
2.2.4.1.3. Echo Threshold
Values (view only) –20 to 99
Page 52 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
2.2.5. TVT (Auto False Echo Suppression) setup (TVT SETUP)
First SITRANS LR260 learns the echo profile. Then the learned profile, or part
of the learned profile, is used to screen out false echoes. See Before Auto
False Echo Suppression on page 53 and After Auto False Echo Suppression on
page 53 for examples.
2.2.5.1. TVT Hover Level
Defines how high the TVT (Time Varying Threshold) curve is placed above
the noise floor of the echo profile, as a percentage of the difference between
the peak of the largest echo in the profile and the noise floor. When
SITRANS LR260 is located in the center of the vessel, the TVT hover level
may be lowered to increase the confidence level of the largest echo.
(For an
illustration of the TVT curve see
Before Auto False Echo Suppression on
page 53.)
2.2.5.2. Auto False Echo Suppression
Enables a ’learned’ TVT curve to be used in place of the default TVT curve.
(See Auto False Echo Suppression on page 88 for an explanation)
a. Determine Range (the distance within which the learned TVT will
replace the default TVT). Measure the actual distance from the
antenna reference point to the material surface using a rope or tape
measure, and make allowances for the actual location of the
device.
b. Subtract 2 m (6.56 ft) from this distance, and use the resulting value.
To use Auto False Echo Suppression via SIMATIC PDM:
c. Open the menu Device – Auto False Echo Suppression and set
Range. For more detail see
Auto False Echo Suppression
on page 39.
d. Select Learn. The device will automatically revert to On (Use
Learned TVT) after a few seconds.
To set Auto False Echo Suppression via the handheld programmer:
c. Go to
2.2.5.3. Auto Suppression Range
and enter new value.
d. Press RIGHT ARROW to open Edit Mode
e. Select Learn. The device will automatically revert to On (Use
Learned TVT) after a few seconds.
Values Range: 0 to 100%
Default: 33%
Notes:
• If possible adjust Auto False Echo Suppression parameters with an
empty or almost empty vessel.
• Set Auto False Echo Suppression and Auto False Echo Range during
startup, if possible.
Options
OFF Default TVT curve will be used.
* ON ’Learned’ TVT curve will be used.
LEARN ’Learn’ the TVT curve.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 53
mmmmm
Parameters
2.2.5.3. Auto Suppression Range
Defines the endpoint of the Learned TVT distance. Units are defined in
sensor units.
a. Press RIGHT ARROW to open Edit mode.
b. Enter the new value and press RIGHT ARROW to accept it.
c. Set
2.2.5.2. Auto False Echo Suppression
.
2.2.5.4. Shaper Mode
Adjusts the TVT curve at a specified range.
Values Range: 0.00 to 30.00 m
Default: 1.00 m
Options ON
*OFF
Before Auto False Echo Suppression
default
TVT
TVT
Hover Level
Level (db)
echo
marker
After Auto False Echo Suppression
learned
TVT curve
level
Level (db)
false echo
echo
marker
Page 54 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
2.2.5.6. TVT Type
Selects the TVT shaping type to be applied to the echo profile to extract
the true echo.
2.2.6. TVT shaper
A breakpoint on the TVT curve, normalized to 0. To adjust the TVT curve
after shape definition, see Shaper Mode on page 53.
2.2.6.1. Shaper 1-9
2.2.6.2. Shaper 10-18
2.2.6.3. Shaper 19-27
2.2.6.4. Shaper 28-36
2.2.6.5. Shaper 37-40
Options
Short Curved
Short Flat
Long Flat
Long Smooth Front
Long Smooth
Slopes
Long Smooth 2
*Short Curved 2
Values Range: –50 to 50 dB
Default: 0 dB
Values Range: –50 to 50 dB
Default: 0 dB
Values Range: –50 to 50 dB
Default: 0 dB
Values Range: –50 to 50 dB
Default: 0 dB
Values Range: –50 to 50 dB
Default: 0 dB
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 55
mmmmm
Parameters
2.2.7. Rate
2.2.7.1. Response Rate
Sets the reaction speed of the device to measurement changes.
Use a setting just faster than the maximum filling or emptying rate
(whichever is faster). Slower settings provide higher accuracy; faster
settings allow for more level fluctuation.
2.2.7.2. Fill Rate (FILL RATE/MIN)
Defines the maximum rate at which the reported sensor value is allowed to
increase. Allows you to adjust the SITRANS LR260 response to increases
in the actual material level. Fill Rate is automatically updated whenever
Response Rate is altered.
Enter a value slightly greater than the maximum vessel-filling rate, in
Sensor Units per minute.
2.2.7.3. Empty rate (EMPTY RATE/MIN)
Defines the maximum rate at which the reported sensor value is allowed to
decrease. Adjusts the SITRANS LR260 response to decreases in the actual
material level. Empty Rate is automatically updated whenever Response
Rate is altered.
Note: Changing Response Rate resets Fill Rate, Empty Rate, Damping
Filter and Echo Lock.
Related
parame-
ters
Response
Rate Fill Rate Empty
Rate
Damping
Filter Echo Lock
Options
slow 0.1 m/min. 0.1 m/min. 10 s max.
verifications
medium 1 m/min. 1 m/min. 10 s max.
verifications
*fast 10 m/min. 10 m/min. 0 s max.
verifications
Values Range: 0 to 30 m / min.
Default: 10 m/min.
Altered by Response Rate
Related parameters Sensor Units
Options Meters/Minute
Slow 0.1
Medium 1
Fast 10
Values Range: 0 to 30 m / min.
Default: 10 m / min.
Altered by Response Rate
Page 56 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
Enter a value slightly greater than the vessel’s maximum emptying rate, in
Sensor Units per minute.
2.2.8. Transducer Block (TB) Values (for diagnostic purposes)
2.2.8.2. Level Measurement (LEVEL MEAS.)
The value for level. Read Only.
In SIMATIC PDM, open the menu View – Display, and select the tab
Display.
2.2.8.3. Space Measurement (SPACE MEAS.)
The value for space. Read Only.
In SIMATIC PDM, open the menu View – Display, and select the tab
Display.
2.2.8.4. Distance Measurement (DISTANCE MEAS.)
The value for distance. Read Only.
In SIMATIC PDM, open the menu View – Display, and select the tab
Display.
2.3. Output
2.3.1. mA Output
2.3.1.1. mA Output Value
The loop current value in mA. Read Only except if the Manual option is
chosen in mA Output function below (2.3.1.2).
2.3.1.2. mA Output Function (mA OUTPUT FUNC.)
Alters the mA output/measurement function and allows the output to be set
independently.
Related Sensor Units
Options Meters/Minute
Slow 0.1
Medium 1
Fast 10
Values
User Entry only if Manual option is chosen in
2.3.1.2.
Range: 3.6 mA to 22.6 mA
Options
Manual
Level
Space
*Distance
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 57
mmmmm
Parameters
2.3.1.3. 4 mA Setpoint
Sets the process level corresponding to the 4 mA value. 4 mA always
defaults to 0, and mA Output Function determines whether this is a Level,
Space, or Distance measurement. Level and Space are measured as a
percentage of the difference between High Calibration Point and Low
Calibration Point. Distance is measured as a percentage of the Low
Calibration Point.
Enter the reading that is to correspond to a 4 mA output. Units are defined
in Sensor units for Level, Space, or Distance.
Notes:
• The mA Output Function is set independently from the setting in
Operation. Set Operation first and then mA Output Function.
(Operation resets mA Output Function to the same value.)
• The mA Output Function controls the primary value and the loop
current for the STIRANS LR260. Use caution when changing the mA
Output function when connected to a HART network.
• The mA Output Function also affects the secondary, tertiary and
quaternary variables in a HART network.
• mA Output Function must be set to Manual before you can modify the
mA Output Value (2.3.1.1). Remember to restore your previous setting
after using mA Output Function.
Values
Range: 0 to 30 m
Default: 0.00 m (set to value corresponding to 0% as
defined by mA Output Function)
Related
Parameters mA Output Function
Level Space Distance
Distance
Space
Level
20 mA
100%
0%
4 mA
High
Cal.
Point
4 mA
0%
100%
20 mA
4 mA
0%
100%
20 mA
Sensor
reference
point
Low
Calibration
Point
Page 58 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
2.3.1.4. 20 mA Setpoint
Sets the process level corresponding to the 20 mA value. 20 mA always
defaults to 100%, and mA Output Function determines whether this is a
Level, Space, or Distance measurement. Level and Space are measured as
a percentage of the difference between High Calibration Point and Low
Calibration Point: Distance is measured as a percentage of Low Calibration
Point.
Enter the reading that is to correspond to a 20 mA output. Units are defined
in Sensor units for Level, Space, or Distance.
2.3.1.5. Minimum mA limit (MIN. mA LIMIT)
Prevents the mA output from dropping below this minimum level for a
measurement value. This does not restrict the Fail-safe or manual settings.
2.3.1.6. Maximum mA limit (MAX. mA LIMIT)
Prevents the mA output from rising above this maximum level for a
measurement value. This does not restrict the Fail-safe or manual settings.
2.3.1.7. 4 mA Output Trim
Calibrates the 4 mA output. The mA output of the device is pre-calibrated;
however, 4 mA Output Trim can be used to trim remote displays or inputs.
Steps:
1. Set mA Output Function Manual.
2. Set mA Output Value to 4 mA.
3. Attach a calibrated meter and check the output at the terminals; record
the remote reading in mA.
4. Enter this value in 4 mA Output Trim.
5. Restore mA Output Function to previous setting.
6. Confirm that the mA output is as expected.
Values
Range: 0 to 30 m
Default: 30 m (set to value corresponding to 100% as
defined by mA Output Function)
Related
Parameters mA Output Function
Values Range: 3.8 to 20.5 (mA)
Default: 3.8 (mA)
Values Range: 3.8 to 20.5 (mA)
Default: 20.5 (mA)
Values Range: 2.0 to 6.0 (mA)
Related
parameters 20 mA Output Trim
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 59
mmmmm
Parameters
2.3.1.8. 20 mA Output Trim
Calibrates the 20 mA output. The mA output of the device is pre-calibrated;
however, 20 mA Output Trim can be used to trim remote displays or inputs.
Steps:
1. Set mA Output Function to Manual.
2. Set mA Output Value to 20 mA.
3. Attach a calibrated meter and check the output at the terminals; record
the remote reading in mA.
4. Enter this value in 20 mA Output Trim.
5. Restore mA Output Function to previous setting.
6. Confirm that the mA output is as expected.
2.4. Fail-safe
2.4.1. Fail-safe Timer
Sets the time to elapse in minutes since the last valid reading, before Fail-safe
State activates
2.4.2. Fail-safe Material Level (FAILSAFE MAT. LEVEL)
The material level to be reported when the Fail-safe Timer expires.
2.4.4. Fail-safe Level
Defines a user-defined level to report when the Fail-safe timer expires.
Values Range: 18.0 to 24.0 (mA)
Related
parameters 4 mA Output Trim
Values Range: 0.00 to 720 min.
Default: 1.0
Note: The last valid reading is maintained until the Fail-safe timer expires.
After the timer expires, the reading is set based on Fail-safe Material Level
(next page).
Options
HI: Use 22.6 mA (max. mA Limit) as material level
LO: Use 3.6 mA (min. mA Limit) as material level
*HOLD: Level remains at last reading
VALUE: User-selected value (defined in Fail-safe Level
below)
Values Range: 3.6 mA to 22.6 mA
Default: 22.6 mA
Note: Fail-safe Material Level must be set to VALUE to use this value.
Page 60 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
3. Diagnostics
3.1. Echo Profile
Allows you to request the current echo profile either via the handheld programmer,
or via SIMATIC PDM. (For more detail see Echo Processing on page 86.)
To request a profile via SIMATIC PDM:
a. Open the menu View – Echo Profile.
b. If desired, press Save.
c. To view the saved profile, open the menu View – Show Echo Profile.
To request a profile via the handheld programmer:
a. In PROGRAM mode, navigate to LEVEL METER > DIAGNOSTICS > ECHO
PROFILE (3.1)
b. Press Right ARROW to request a profile.
c. In the Profile screen, press Up ARROW to select the Transmit icon, and
Right ARROW to update the profile.
d. Press Down ARROW to select the Exit icon, then Right ARROW to return to
previous menu.
3.14. Measured Values (MEAS. VALUES)
3.14.1. Current Internal Temperature (CURR. INTERN. TEMP.)
Read Only. Displays (in degrees C) the current temperature on the circuit board
recorded by the internal electronics.
3.14.2. Maximum Internal Temperature (MAX. INTERN. TEMP.)
Read Only. Displays (in degrees C) the maximum temperature recorded by the
internal electronics. The high and low values are maintained over a power
cycle.
transmit icon,
selected
exit icon,
deselected
exit icon, selected
transmit icon, deselected
Distance value
Algorithm selection (First echo)
TVT curve
material
level
Echo confidence
value
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 61
mmmmm
Parameters
3.14.3. Minimum Internal Temperature (MIN. INTERN. TEMP.)
Read Only. Displays (in degrees C) the minimum temperature recorded by the
internal electronics. The high and low values are maintained over a power
cycle.
3.15. Remaining Device Lifetime (REMAIN. DEV. LIFE.)
The Remaining Device/Sensor Lifetime parameters set up schedules for calibration
and maintenance. The device will track itself based on operating hours, instead of a
calendar-based schedule, and will monitor its predicted lifetime.
The maintenance warnings and alarms are communicated to the end user through
status information. This information can be integrated into any Asset Management
system. For optimal use, we recommend that you use SIMATIC PCS7 Asset
Management Software in conjunction with SIMATIC PDM.
The device monitors the predicted lifetime of the device.
3.15.1. Total Device Operating Time (TOTAL OP. TIME)
Read only. Displays the amount of time the device has been operating.
3.15.2. Remaining Device Lifetime (REMAIN. LIFETIME)
Read only. Total Expected Device Life less Total Device Operating Time.
3.15.3. Maintenance Required Limit (MAINT. REQ. LIMIT)
If the Total Expected Device Life less Total Device Operating Time is equal to
or less than this limit, a Maintenance Required status is generated.
In SIMATIC PDM, open the menu Device – Maintenance, click on Remaining
Device Lifetime.
a) Enable
3.15.5. Maintenance Alert Activation (ALERT ACTIVATION)
.
b) Modify limit values as required. Click Write to accept the changes.
Note: Performing a reset to Factory Defaults will reset all the Maintenance
Schedule parameters to their factory defaults.
Values Range: 0 to 20 years
Default: 0.164 years
Page 62 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
3.15.4. Maintenance Demanded Limit (MAINT. DEM. LIMIT)
If the Total Expected Device Life less Total Device Operating Time is equal to
or less than this limit, a Maintenance Demanded status is generated.
In SIMATIC PDM, open the menu Device – Maintenance, click on Remaining
Device Lifetime.
a) Enable
3.15.5. Maintenance Alert Activation (ALERT ACTIVATION)
.
b) Modify limit values as required. Click Write to accept the changes.
3.15.5. Maintenance Alert Activation (ALERT ACTIVATION)
Select limits to be activated.
To enable or disable Maintenance Alert Activation via PDM:
a) Open the menu Device – Maintenance, click on Remaining Device
Lifetime.
b) Select either or both of Enable Maintenance Required Alert and Enable
Maintenance Demanded Alert. Click Write to accept the changes.
3.15.6. Total Expected Device Life (TOTAL EXP. LIFE)
The device tries to predict its overall lifetime. The factory default can be reset
by the user.
To modify the value via PDM, open the menu Device – Maintenance, click on
Remaining Device Lifetime, enter the desired value then click Write to accept it.
3.15.7. Maintenance Status (MAINT. STAT.)
Read only. Displays the status of the Maintenance Alerts.
In SIMATIC PDM, open the menu View – Display Status, click on the
Maintenance tab and check the Device Lifetime Status window.
Values Range: 0 to 20 years
Default: 0.019 years
Options
Warning Limit 1 (Maintenance Required Limit)
Warning Limit 2 (Maintenance Demanded Limit)
Warning Limits 1 and 2 (Maintenance Required and
Maintenance Demanded Limits)
*OFF
Values Range: 0 to 20 years
Default: 10.00 years
Options
(view only)
Maintenance Required Alert active
Maintenance Demanded Alert Active
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 63
mmmmm
Parameters
3.15.8. Acknowledge Status (ACK STATUS)
Read only. Displays the status of the Maintenance Alerts that have been
acknowledged.
In SIMATIC PDM, open the menu View – Display Status, click on the
Maintenance tab and check the Device Lifetime Status window.
3.15.9. Acknowledge (ACK)
Allows you to acknowledge either a Maintenance Required or a Maintenance
Demanded alert.
To acknowledge an alert via PDM:
a) Open the menu View – Device Status and click on the tab Maintenance.
b) In the Device Lifetime section, click Acknowledge Warnings.
3.16. Remaining Sensor Lifetime (REMAIN SENS. LIFE.)
The device monitors the predicted lifetime of the sensor (the components exposed to
the vessel environment).
3.16.1. Total Sensor Operating Time (SENS OP. TIME)
Displays the amount of time the sensor has been operating.
Can be reset to zero via the handheld programmer (after performing a
service.)
3.16.2. Remaining Sensor Lifetime (REMAIN. LIFETIME)
Read only. Total Expected Sensor Life less Total Sensor Operating Time.
3.16.3. Maintenance Required Limit (MAINT. REQ. LIMIT)
If the Total Expected Sensor Life less Total Sensor Operating Time is equal to
or less than this limit, a Maintenance Required status is generated.
To modify the value via PDM, open the menu Device – Maintenance and click
on Remaining Sensor Lifetime.
a) Enable
3.16.5. Maintenance Alert Activation (ALERT ACTIVATION)
.
b) Modify limit values as required. Click Write to accept the changes.
Options
(view only)
Maintenance Required Alert acknowledged
Maintenance Demanded Alert acknowledged
Values Range: 0 to 20 years
Default: 0.164 years
Page 64 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
3.16.4. Maintenance Demanded Limit (MAINT. DEM. LIMIT)
If the Total Expected Sensor Life less Total Sensor Operating Time is equal to
or less than this limit, a Maintenance Demanded status is generated
To modify the value via PDM, open the menu Device – Maintenance and click
on Remaining Sensor Lifetime.
a) Enable
3.16.5. Maintenance Alert Activation (ALERT ACTIVATION)
.
b) Modify limit values as required. Click Write to accept the changes.
3.16.5. Maintenance Alert Activation (ALERT ACTIVATION)
Select limits to be activated.
To enable or disable Maintenance Alert Activation via PDM:
a) Open the menu Device – Maintenance, and click on Remaining Device
Lifetime.
b) Select either or both of Enable Maintenance Required Alert and Enable
Maintenance Demanded Alert. Click Write to accept the change.
3.16.6. Total Expected Sensor Life (TOTAL. EXP. LIFE)
The device tries to predict its overall lifetime. The factory default can be reset
by the user.
To modify the value via PDM, open the menu Device – Maintenance, click on
Remaining Sensor Lifetime, enter the desired value then click Write.
3.16.7. Maintenance Status (MAINT. STATUS)
Read only. Displays the status of the Maintenance Alerts
Via PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Sensor Lifetime Status window.
Values Range: 0 to 20 years
Default: 0.019 years
Options
Warning Limit 1 (Maintenance Required Limit)
Warning Limit 2 (Maintenance Demanded Limit)
Warning Limits 1 and 2 (Maintenance Required and
Maintenance Demanded Limits)
*OFF
Values Range: 0 to 20 years
Default: 10.00 years
Options
(view only)
Maintenance Required Alert active
Maintenance Demanded Alert Active
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 65
mmmmm
Parameters
3.16.8. Acknowledge Status (ACK. STATUS)
Read only. Displays the status of the Maintenance Alerts that have been
acknowledged.
Via PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Sensor Lifetime Status window.
3.16.9. Acknowledge (ACK.)
Allows you to acknowledge either a Maintenance Required or a Maintenance
Demanded alert.
To acknowledge an alert via PDM:
a) Open the menu View – Device Status and click on the Maintenance tab.
b) In the Device Lifetime section click on Acknowledge Warning.
4. Service
4.1. Device Reset
Resets all parameter to factory defaults, with the following exceptions:
• The Lock and Unlock values are not reset.
• The learned TVT curve is not lost.
To perform a reset to factory defaults via SIMATIC PDM, open the menu Device –
Device Reset and click on Factory Defaults.
4.2. Manufacture Date (MANUF. DATE)
The date of manufacture of the SITRANS LR260 (yy mm dd).
4.3. LCD Fast Mode
Enables a faster rate of measurement from the device by disabling most of the
display area. Only the bar graph will be refreshed when LCD Fast Mode is set to ON.
Options
(view only)
Maintenance Required Alert acknowledged
Maintenance Demanded Alert acknowledged
Note: Following a reset to factory defaults, complete reprogramming is required.
Options *Idle or Done (Return to previous menu)
Factory Defaults
Note: Affects Measurement mode only: has no effect on Navigation mode.
Values ON or OFF
Default: OFF
Page 66 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
4.4. LCD Contrast
The factory setting is for optimum visibility at room temperature and in average light
conditions. Extremes of temperature will lessen the contrast.
Adjust the value to improve visibility in different temperatures and luminosity.
Change the LCD contrast in small steps to ensure you can continue to read the
display and to prevent viewing difficulties.
4.6. Powered Hours
Displays the number of hours the unit has been powered up since manufacture.
Via PDM, open the menu View – Wear.
4.8. Power-on Resets
The number of power cycles that have occurred since manufacture.
Via PDM, open the menu View – Wear.
4.11. Memory Test (MEM. TEST)
Allows verification of the RAM, EEPROM, and Flash memory of the SITRANS LR260.
Press any numeric key from 1 to 9 to activate the test. The reading will display BUSY
followed by the test result text.
4.16. Service Interval
Allows for scheduling of service inspections.
4.16.1. Time Last Serviced (TIME LAST SERV.)
Time elapsed since device was last serviced
Can be reset to zero via the handheld programmer (after performing a service.)
Values Range: 0 (High contrast) to 20 (Low contrast). Default: Matches
factory calibration for best visual contrast.
LCD Display
IDLE No test in progress.
BUSY Test in progress.
PASS Memory test successful.
FAIL Test failed.
Err1 Test returned unexpected results.
P Oxcafe Test passed with result data.
F Oxcafe Test failed with result data.
Handheld
programmer entry to
Any numeric key from 1 to 9 activates
test.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 67
mmmmm
Parameters
4.16.2. Remaining Lifetime (REMAIN LIFETIME)
Read only. Total Service Interval less Time Elapsed since last service.
4.16.3. Maintenance Required Limit (MAINT. REQ. LIMIT)
If the time remaining until next service is equal to or less than this limit, a
Maintenance Required status is generated.
4.16.4. Maintenance Demanded Limit
If the time remaining until next service is equal to or less than this limit, a
Maintenance Demanded status is generated.
4.16.5. Alert Activation
Select limits to be activated.
4.16.6. Service Interval
Set time between scheduled service inspections
4.16.7. Maintenance Status (MAINT. STAT)
Read only. Displays the status of the Maintenance Alerts.
In PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Service Schedule Status window.
Values Range: 0 to 20 years
Default: 0.164 years
Values Range: 0 to 20 years
Default: 0.019 years
Values
* Timer off
On - no limits
On - limit 1
On - limits 1 and 2
On - limit 2
Values Range: 0 to 20 years
Default: 1.0 year
Options
(view only)
Maintenance Required Alert active
Maintenance Demanded Alert Active
Page 68 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
4.16.8. Acknowledge Status (ACK. STATUS)
Read only. Displays the status of the Maintenance Alerts that have been
acknowledged.
In PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Service Schedule Status window.
4.16.9. Acknowledge (ACK.)
Allows you to acknowledge either a Maintenance Required or a Maintenance
Demanded alert.
4.17. Calibration Interval (CALIB. INTERVAL)
Allows for scheduling of calibrations.
4.17.1. Time Last Calibrated (TIME LAST CAL.)
Time elapsed since device was last calibrated.
Can be reset to zero via the handheld programmer (after performing a service.)
4.17.2. Remaining Lifetime (REMAIN LIFETIME)
Read only. Total Calibration Interval less Time Elapsed since last calibration.
4.17.3. Maintenance Required Limit (MAINT. REQ. LIMIT)
If the time remaining until next calibration is equal to or less than this limit, a
Maintenance Required status is generated.
4.17.4. Maintenance Demanded Limit (MAINT. DEM. LIMIT)
If the time remaining until next calibration is equal to or less than this limit, a
Maintenance Demanded status is generated.
Options
(view only)
Maintenance Required Alert acknowledged
Maintenance Demanded Alert acknowledged
Values Range: 0 to 20 years
Default: 0.164 years
Values Range: 0 to 20 years
Default: 0.019 years
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 69
mmmmm
Parameters
4.17.5. Alert Activation
Select limits to be activated.
4.17.6. Total Calibration Interval (TOTAL CALIB. INTRV.)
Set time between scheduled calibrations.
4.17.7. Maintenance Status (MAINT. STAT.)
Read only. Displays the status of the Maintenance Alerts.
In PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Calibration Schedule Status window.
4.17.8. Acknowledge Status (ACK. STATUS)
Read only. Displays the status of the Maintenance Alerts that have been
acknowledged.
In PDM, open the menu View – Display Status, click on the Maintenance tab
and check the Calibration Schedule Status window.
4.17.9. Acknowledge (ACK.)
Allows you to acknowledge either a Maintenance Required or a Maintenance
Demanded alert.
Values
*Timer off
On - no limits
On - limit 1
On - limits 1 and 2
On - limit 2
Values Range: 0 to 20 years
Default: 1.0 year
Options
(view only)
Maintenance Required Alert active
Maintenance Demanded Alert Active
Options
(view only)
Maintenance Required Alert acknowledged
Maintenance Demanded Alert acknowledged
Page 70 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
5. Communication
5.1. Device Address
Sets the device address or poll ID on a HART network. Any address other than 0 will
cause the output current to be a fixed value, and the current will not indicate the
reading.
To set the address via the handheld programmer:
• Press Right ARROW to activate PROGRAM mode and open menu level 1.
• Press Down ARROW repeatedly to navigate to COMMUNICATION (menu
item 5).
• Press Right ARROW to display the parameter list.
• Scroll to DEVICE ADDRESS and press Right ARROW to open parameter
view.
• Press Right ARROW to open Edit mode. Key in a new value and press Right
ARROW to accept it.
5.2. Communication Control
Enables /disables the read/write access to parameters via remote communications.
Values Range: 0 to 15
Default: 0
Note: SITRANS LR260 can only reset this parameter via the handheld
programmer.
Options
Read Only No changes are permitted via remote
communications.
*Read Write Changes are permitted.
Restricted
Sets the status to Read Only, with the potential
for another HART device to change this via
remote communications.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 71
mmmmm
Parameters
6. Security
6.1. Lock
Prevents any changes to parameters via the handheld programmer.
Note: This lock applies only to the handheld programmer: it does not lock through
communications. A remote master can change configuration if 5.2 Communication
Control is set to allow this.
To secure the programming lock: Key in any value other than the unlock value.
Parameters are now locked and cannot be changed.
To unlock the device and enable handheld programming changes: Key in the unlock
value. Parameters are now unlocked and may be changed.
6.2. Unlock value
Stores the value to be entered in 6.1. Lock to unlock programming. If Lock is on,
Unlock Value will not display the unlocked value
7. Language
Selects the language to be used on the LCD.
Note: Do not lose this number value.
Handheld
programmer
Values
Range: 1 to 9999
1954 (unlock value) Off (enables local programming)
Any other value On (disables local programming)
Notes:
• Default setting for 6.1 (Lock) is Unlocked.
• After a new value is stored in Unlock Value (6.2), that value will be recalled
after a reset to Factory Defaults.
• Consult your Siemens Milltronics representative if you have forgotten the
unlock value.
Handheld
programmer
Values
Range: 1 to 9999
Factory Default: 1954
– – – – Display when Lock is on
Options
*English
German
French
Spanish
Page 72 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Parameters
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 73
mmmmm
A: Parameter List
Appendix A: Alphabetical Parameter
List
Note: Maintenance Parameters are not listed below. See
Remaining Device Lifetime
(REMAIN. DEV. LIFE.)
on page 61,
Remaining Sensor Lifetime (REMAIN SENS. LIFE.)
on
page 63,
Service Interval
on page 66, and
Calibration Interval (CALIB. INTERVAL)
on
page 68 for those parameters.
Parameter Name (Parameter Number) Page Number
20 mA Output Trim
(2.3.1.8.) 59
20 mA Setpoint
(2.3.1.4.) 58
4 mA Output Trim
(2.3.1.7.) 58
4 mA Setpoint
(2.3.1.3.) 57
Algorithm
(2 . 2 . 4 .1.1.) 48
Application Type
(1.1.) 43
Auto False Echo Suppression
(2.2.5.2.) 52
Auto Suppression Range
(2.2.5.3.) 53
Communication Control
(5.2.) 70
Confidence
(2.2.4.5.1.) 51
Current Internal Temperature (CURR. INTERN. TEMP.)
(3.14.1.)
60
Damping Filter
(2.2.4.3.2.) 50
Device Address
(5.1.) 70
Device Reset
(4.1.) 65
Distance Measurement (DISTANCE MEAS.)
(2.2.8.4.) 56
Down Sampling
(2.2.4.2.5.) 49
Echo Lock
(2.2.4.2.1.) 49
Echo Marker
(2.2.4.1.5.) 49
Echo Profile
(3.1.) 60
Echo Threshold
(2.2.4.1.3.) 48
Empty rate (EMPTY RATE/MIN)
(2.2.7.3.) 55
Fail-safe Level
(2.4.4.) 59
Fail-safe Material Level (FAILSAFE MAT. LEVEL)
(2.4.2.) 59
Fail-safe Timer
(2.4.1.) 59
Far Range
(2.2.1.12.) 47
Page 74 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
A: Parameter List
Fill Rate (FILL RATE/MIN)
(2.2.7.2.) 55
Firmware Revision (FIRMWARE REV.)
(2.1.1.) 45
Hardware Revision (HARDWARE REV.)
(2.1.3.) 45
High Calibration Pt. (HIGH CALIB. PT.)
(2.2.1.7.) 46
Language
(7.) 71
LCD Contrast
(4.4.) 66
LCD Fast Mode
(4.3.) 65
Level Measurement (LEVEL MEAS.)
(2.2.8.2.) 56
Loader Revision (LOADER REV.)
(2.1.2.) 45
Lock
(6.1.) 71
Low Calibration Pt. (LOW CALIB. PT.)
(2.2.1.6.) 46
mA Output Function (mA OUTPUT FUNC.)
(2.3.1.2.) 56
mA Output Value
(2.3 .1.1.) 56
Manufacture Date (MANUF. DATE)
(4.2.) 65
Maximum Internal Temperature (MAX. INTERN. TEMP.)
(3.14.2.)
60
Maximum mA limit (MAX. mA LIMIT)
(2.3.1.6.) 58
Memory Test (MEM. TEST)
(4.11.) 66
Minimum Internal Temperature (MIN. INTERN. TEMP.)
(3.14.3.)
61
Minimum mA limit (MIN. mA LIMIT)
(2.3.1.5.) 58
Narrow Echo Filter
(2.2.4.3.6.) 50
Near Range
(2.2.1.11.) 47
Noise
(2.2.4.5.) 51
Noise Average
(2.2.4.5.3.) 51
Operation
(2.2.1.5.) 45
Position
(2.2.4.1.2.) 48
Powered Hours
(4.6.) 66
Power-on Resets
(4.8.) 66
Reform Echo
(2.2.4.3.7.) 51
Response Rate
(2.2.7.1.) 55
Sensor Offset
(2.2.1.24.) 47
Sensor Units
(2.2.1.4.) 45
Shaper Mode
(2.2.5.4.) 53
Space Measurement (SPACE MEAS.)
(2.2.8.3.) 56
Parameter Name (Parameter Number) Page Number
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 75
mmmmm
A: Parameter List
Strength
(2.2.4.5.2.) 51
Transducer Block (TB) Values (for diagnostic purposes)
(2.2.8.)
56
TVT Hover Level
(2.2.5.1.) 52
TVT Type
(2.2.5.6.) 54
Unlock value
(6.2.) 71
Up Sampling
(2.2.4.2.4.) 49
Window
(2.2.4.2.6.) 50
Parameter Name (Parameter Number) Page Number
Page 76 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
B: Troubleshooting
Appendix B: Troubleshooting
Communication Troubleshooting
Generally:
1. Check the following:
• There is power at the instrument
• The LCD shows the relevant data you are expecting
• The device can be programmed using the hand programmer
2. Verify that the wiring connections are correct.
3. Check that the device address is correctly set.
4. If you continue to experience problems, go to our website at:
. www.siemens.com/processautomation, and check the FAQs for SITRANS LR260, or
contact your local Siemens Milltronics representative.
Specifically:
1. If you try to set a SITRANS LR260 parameter via remote communications, but the
parameter remains unchanged:
• Some parameters can only be changed when the device is not scanning. Try
putting the device in PROGRAM mode using the operating mode function.
• Try setting the parameter from the keypad. (First make sure that the lock
parameter [6.1] is set to the unlock value.)
• The communications control parameter 5.2 must be set to Read/Write to allow
you to write parameters to SITRANS LR260.
2. If you see unanticipated displays, for example:
• PROGRAM mode displayed instead of Measurement mode
• the wrong parameter displayed in response to a command
• a parameter displayed in response to no command
make sure no infrared-capable device is close to SITRANS LR260. Any device with
infrared capabilities (laptops, cell phones, PDAs) can cause interference which
simulates a command to the SITRANS LR260, potentially causing it to switch modes
or to change a parameter.
3. If the operation is erratic, make sure the Hand Programmer is not being used at the
same time as SIMATIC PDM.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 77
mmmmm
B: Troubleshooting
Device Status Icons
Icon Priority
Level Meaning
1 • Maintenance alarm
• Measurement values are not valid
2 • Maintenance warning: maintenance demanded immediately
• Measured signal still valid
3 • Maintenance required
• Measured signal still valid
1 • Process value has reached an alarm limit
2 • Process value has reached a warning limit
3 • Process value has reached a tolerance limit
1 • Configuration error
• Device will not work because one or more parameters/
components is incorrectly configured
2 • Configuration warning
• Device can work but one or more parameters/components is
incorrectly configured
3 • Configuration changed
• Device parameterization not consistent with parameterization in
project. Look for info text.
1 • Manual operation (local override)
• Communication is good; device is in manual mode.
2 • Simulation or substitute value
• Communication is good; device is in simulation mode or works
with substitute values.
3 • Out of operation
• Communication is good; device is out of action.
Page 78 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
B: Troubleshooting
General Fault Codes
• Data exchanged
• No data exchange
• Write access enabled
• Write access disabled
Notes:
• If more than one fault is present, the device status indicator and text for each fault
alternate at 2 second intervals.
• Some faults cause the device to go to Failsafe mode (Fault 52). These are indicated with an
asterisk (*).
General Fault Codes
Code /
Icon Meaning Corrective Action
S: 0 * The device was unable to get a mea-
surement within the LOE Fail-safe
Timer period. Possible causes: faulty
installation, material buildup, foam-
ing/other adverse process condi-
tions, invalid calibration range.
Ensure installation details are cor-
rect. Ensure no material buildup.
Clean if necessary. Adjust process
conditions to minimize foam or other
adverse conditions. Correct range
calibration. If fault persists, contact
your local Siemens representative.
S: 2 * Unable to collect profile because of
a low power condition that is outside
of the operating range of the device.
Repair required. Contact your local
Siemens representative.
S: 3 Device is nearing its lifetime limit
according to the value set in Mainte-
nance Required Limit.
Replacement is recommended.
S: 4 Device is nearing its lifetime limit
according to the value set in Mainte-
nance Demanded Limit.
Replacement is recommended.
Icon Priority
Level Meaning (Continued)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 79
mmmmm
B: Troubleshooting
S: 6 Sensor is nearing its lifetime limit
according to the value set in Mainte-
nance Required Limit.
Replacement is recommended.
S: 7 Sensor is nearing its lifetime limit
according to the value set in Mainte-
nance Demanded Limit.
Replacement is recommended.
S: 8 Service interval as defined in Main-
tenance Required Limit has expired.
Perform service.
S: 9 Service interval as defined in Main-
tenance Demanded Limit has
expired.
Perform service.
S: 11 Internal temperature sensor failure. Repair required: contact your local
Siemens representative.
S: 12 Internal temperature of device has
exceeded specifications: it is operat-
ing outside its temperature range.
Relocate device and/or lower pro-
cess temperature enough to cool
device. Inspect for heat-related
damage and contact your local Sie-
mens representative if repair is
required.
Fault code will persist until a manual
reset is performed using PDM or the
LCD interface.
S: 17 Calibration interval as defined in
Maintenance Required Limit has
expired.
Perform calibration.
S: 18 Calibration interval as defined in
Maintenance Demanded Limit has
expired.
Perform calibration.
General Fault Codes (Continued)
Code /
Icon Meaning Corrective Action
Page 80 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
B: Troubleshooting
S: 28 * Internal device failure caused by a
RAM memory error.
Repair required: contact your local
Siemens representative.
S: 29 * EEPROM damaged. Repair required: contact your local
Siemens representative.
S: 31 * Flash error. Repair required: contact your local
Siemens representative.
S: 33 * Factory calibration for the internal
temperature sensor has been lost.
Repair required: contact your local
Siemens representative.
S: 34 * Factory calibration for the device
has been lost.
Repair required: contact your local
Siemens representative.
S: 35 * Factory calibration for the device
has been lost.
Repair required: contact your local
Siemens representative.
General Fault Codes (Continued)
Code /
Icon Meaning Corrective Action
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 81
mmmmm
B: Troubleshooting
S: 36 * Unable to start microwave module. Cycle power. If error persists, con-
tact your local Siemens representa-
tive.
S: 37 * Measurement hardware problem. Cycle power. If error persists, con-
tact your local Siemens representa-
tive.
S: 38 * Microwave module hardware fail-
ure: unable to calculate distance
measurement.
Cycle power. If fault persists, contact
your local Siemens representative:
repair required.
S: 43 * Factory calibration for the radar
receiver has been lost.
Repair required: contact your local
Siemens representative.
S: 45 * No valid boot program detected:
firmware corrupt.
Repair required: contact your local
Siemens representative.
S: 48 * User configuration is invalid. One or
more of parameters: Low Calibration
Point, High Calibration Point, and/or
Auto False-Echo Suppression, are
set to invalid values.
Reconfigure the unit. Ensure the dif-
ference between High Calibration
Point and Low Calibration Point is
not less than zero; do a master
reset.
S: 49 * EEPROM corrupt. Repair required: contact your local
Siemens representative.
S: 50 * EEPROM corrupt. Repair required: contact your local
Siemens representative.
S: 51 * EEPROM corrupt. Repair required: contact your local
Siemens representative.
General Fault Codes (Continued)
Code /
Icon Meaning Corrective Action
Page 82 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
B: Troubleshooting
Operation Troubleshooting
Operating symptoms, probable causes, and resolutions.
S: 52 Fail-safe is activated. Possible
causes: 1) hardware failure; 2)
memory failure; 3) Fail-safe LOE
timer expired – possible causes:
faulty installation, material buildup,
foaming/other adverse process con-
ditions, invalid calibration range.
For 3): Correct configuration; ensure
installation is correct; no material
buildup; adjust process conditions to
minimize foaming/other adverse
conditions; correct calibration range.
If fault persists, or for 1) and 2), con-
tact your local Siemens representa-
tive.
S: 53 * Configuration lost: one or more
parameter settings have been lost.
This may occur after a firmware
upgrade causes user parameters to
be reset.
Restore user parameters using
SIMATIC PDM.
Symptom Cause Action
Display shows
S: 0 LOE
level or target is out of
range
• check specifications
• check
2.2.1.6. Low Calibration Pt.
(LOW CALIB. PT.)
• increase
2.2.4.5.1. Confidence
Display shows
S: 0 LOE
material build-up on
antenna
• clean the antenna
• re-locate SITRANS LR260
Display shows
S: 0 LOE
location or aiming:
• poor installation
• flange not level
• check to ensure nozzle is vertical
•use
2.2.5.2. Auto False Echo
Suppression
and check
2.2.5.3. Auto
Suppression Range
to ensure nozzle
protrudes from end of vessel nozzle.
Display shows
S: 0 LOE
antenna malfunction:
• temperature too high
• physical damage
• check
3.14.1. Current Internal
Temperature (CURR. INTERN.
TEMP.)
• set
2.2.4.1.1. Algorithm
to F (First
echo)
•relocate
General Fault Codes (Continued)
Code /
Icon Meaning Corrective Action
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 83
mmmmm
B: Troubleshooting
Reading does not
change, but the level
does
SITRANS LR260 process-
ing wrong echo, i.e. vessel
wall, or structural member
• re-locate SITRANS LR260
• ensure nozzle protrudes 10 mm min.
• rotate instrument 90°. See
Orientation in a vessel with
obstructions
on page 11.
•use
2.2.5.2. Auto False Echo
Suppression
and
2.2.5.3. Auto
Suppression Range
Measurement is con-
sistently off by a con-
stant amount
• setting for
2.2.1.6. Low
Calibration Pt. (LOW
CALIB. PT.)
not correct
• setting for
2.2.1.24.
Sensor Offset
not correct
• check distance from sensor
reference point to
2.2.1.6. Low
Calibration Pt. (LOW CALIB. PT.)
• check
2.2.1.24. Sensor Offset
Screen blank
power error • check nameplate rating against
voltage supply
• check power wiring or source
too much load resistance • change barrier type, or
• remove something from the loop, or
• increase supply voltage
Reading erratic
echo confidence weak • refer to
2.2.4.5.1. Confidence
•use
2.2.5.2. Auto False Echo
Suppression
and
2.2.5.3. Auto
Suppression Range
• use foam deflector or stillpipe
material filling • re-locate SITRANS LR260
Reading response
slow
2.2.7.2. Fill Rate (FILL RATE/
MIN)
setting incorrect
• increase measurement response if
possible
Reads correctly but
occasionally reads
high when vessel is
not full
• detecting close range
echo
• build up near top of
vessel or nozzle
• nozzle problem
• clean the antenna
•use
2.2.5.2. Auto False Echo
Suppression
and
2.2.5.3. Auto
Suppression Range
Level reading lower
than material level
• material is within Near
Range zone
• multiple echoes
processed
• decrease
2.2.1.11. Near Range
(minimum value depends on
antenna type)
• raise SITRANS LR260
•ensure
2.2.4.1.1. Algorithm
is set to F
(First echo)
Symptom Cause Action (Continued)
Page 84 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
B: Troubleshooting
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 85
mmmmm
H: HART Communications
Appendix C: Maintenance
SITRANS LR260 requires no maintenance or cleaning under normal operating conditions.
Under severe operating conditions, the horn antenna may require periodic cleaning. If
cleaning becomes necessary:
• Note the antenna material and the process medium, and select a cleaning
solution that will not react adversely with either.
• Remove the instrument from service and wipe the antenna clean using a cloth
and suitable cleaning solution.
Unit Repair and Excluded Liability
All changes and repairs must be done by qualified personnel, and applicable safety
regulations must be followed. Please note the following:
• The user is responsible for all changes and repairs made to the device.
• All new components must be provided by Siemens Milltronics Process Instruments
Inc.
• Restrict repair to faulty components only.
• Do not re-use faulty components.
Page 86 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
Appendix D: Technical Reference
Principles of Operation
SITRANS LR260 is a 2-wire 25 GHz pulse radar level transmitter for continuous monitoring
of solids1. Radar level measurement uses the time of flight principle to determine
distance to a material surface. The device transmits a signal and waits for the return
echo. The transit time is directly proportional to the distance from the material.
Pulse radar uses polarized electromagnetic waves. Microwave pulses are emitted from
the antenna at a fixed repetition rate, and reflect off the interface between two materials
with different dielectric constants (the atmosphere and the material being monitored).
Electromagnetic wave propagation is virtually unaffected by temperature or pressure
changes, or by changes in the vapor levels inside a vessel. Electromagnetic waves are
slightly attenuated by dust.
SITRANS LR260 consists of an enclosed electronic circuit coupled to an antenna and
process connection. The electronic circuit generates a radar signal (25 GHz) that is
directed to the horn.
The signal is emitted from the horn, and the reflected echoes are digitally converted to an
echo profile. The profile is analyzed to determine the distance from the material surface
to the reference point on the instrument. This distance is used as a basis for the display of
material level and mA output.
Echo Processing
Process Intelligence
The signal processing technology embedded in Siemens radar level devices is known as
Process Intelligence.
Process intelligence provides high measurement reliability regardless of the dynamically
changing conditions within the vessel being monitored. The embedded Process
Intelligence dynamically adjusts to the constantly changing material surfaces within
these vessels.
Process Intelligence is able to differentiate between the true microwave reflections from
the surface of the material and unwanted reflections being returned from obstructions
such as seam welds or supports within a vessel. The result is repeatable, fast and
reliable measurement. This technology was developed as result of field data gained over
some twenty years from more than 1,000,000 installations in many industries around the
world.
1. The microwave output level is significantly less than that emitted from cellular phones.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 87
mmmmm
D: Technical Reference
Higher order mathematical techniques and algorithms are used to provide intelligent
processing of microwave reflection profiles. This “knowledge based” technique
produces superior performance and reliability.
Time Varying Threshold (TVT) Curves
A Time Varying Threshold (TVT) curve hovers above the echo profile to screen out
unwanted reflections (false echoes).
In most cases the material echo is the only one which rises above the default TVT curve.
In a vessel with obstructions a large false echo may rise above the default TVT. The Auto
False Echo Suppression feature (see below) can be used to screen it out.
The device characterizes all echoes that rise above the TVT as potential good echoes.
Each peak is assigned a rating based on its strength, area, height above the TVT, amongst
other characteristics.
The true echo is selected based on the setting for the Echo selection algorithm (
2.2.4.1.1.
Algorithm
.).
Echo Lock
If the echo selected by Algorithm is within the Echo Lock window, the window is centered
about the echo, which is used to derive the measurement. In radar applications, two
measurement verification options are used:
•Lock Off:
SITRANS LR260 responds immediately to a new selected echo (within the
restrictions set by the Maximum Fill / Empty Rate), but measurement reliability is
affected.
Echo Position Detection
The echo position algorithm (
2.2.4.1.2. Position
) determines which point on the echo will
be used to calculate the precise time of flight, and calculates the range using the
calibrated propagation velocity (adjusted by a propagation factor, if necessary).
Distance [M]
0123
Profile [dB]
010 20 30 40 50 60 70
High Cal. Pt.
= 0
obstruction
at 1.2 m
material
level at
2.9 m
echo
marker
false
echo
true
echo
TVT
curve
sensor reference point
Page 88 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
The options are Center, CLEF (Constrained Leading Edge Fit), Hybid or Rising Edge. CLEF
uses the leading edge of the echo. It can be used to compensate for materials with a low
dK value, which may cause the vessel bottom to be reported as the level instead of the
actual material level, in low level conditions. CLEF range is the level below which the
CLEF algorithm will be used: above this level the Center algorithm is used.
Hybrid uses a combination of Center and CLEF, depending on the setting for CLEF range.
Auto False Echo Suppression
If an obstruction is causing a large echo before the material level echo, that echo will rise
above the default TVT curve and may be selected as the true echo. Auto False-Echo
Suppression modifies the TVT curve so that the false echo will not rise above the TVT
curve.
When you use Auto False Echo Suppression, the device first learns the echo profile at
that moment1. A learned TVT curve follows the echo profile and rises above the false
echo. You set Auto Suppression Range so that the learned profile replaces the default
TVT curve up to a point past the obstruction. From that point on, the default TVT curve is
used. The material level echo rises above this, and is selected as the true echo.
Measurement Range
Near Range
2.2.1.11. Near Range
programs SITRANS LR260 to ignore the zone in front of the antenna.
The default blanking distance is 50 mm (1.97") from end of horn antenna.
Near Range allows you to increase the blanking value from its factory default. But
2.2.5.2.
Auto False Echo Suppression
is generally recommended in preference to extending the
blanking distance from factory values.
1. Use Auto False Echo Suppression when the material level is substantially lower than pro-
cess full level (ideally when the tank is empty or almost empty).
Example after Auto False Echo Suppression
learned
TVT curve
level
Level (db)
false echo echo marker
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 89
mmmmm
D: Technical Reference
Far Range
In applications where the base of the vessel is conical or parabolic, a reliable echo may
be available below the vessel empty distance, due to an indirect reflection path.
Increasing the range extension to 30% or 40% can provide stable empty vessel readings.1
Measurement Response
The measurement response (response rate) limits the maximum rate at which the display
and output respond to changes in the measurement. Once the real process fill/empty rate
(m/s) is established, a response rate can be selected that is slightly higher than the
application rate. The response rate automatically adjusts the filters that affect the output
response rate.
There are three preset options: slow, medium, and fast.
mA Output
The mA output is proportional to the level, in the range 4 to 20 mA. Generally, the output is
set so that the output for 0% is 4 mA, and the output for 100% is 20 mA. 0 and 100% are
percentages of the full-scale reading (m, cm, mm, ft, in).
When SITRANS LR260 is put into PROGRAM mode it stops responding to the process. It
stores the most recent measurement, and holds the associated readings and mA signal
output. The instrument reverts to the parameter last addressed during the previous
program session.
1. On 30 m vessel, range extension cannot exceed 31.5 m.
2.2.7.2. Fill
Rate (FILL
RATE/MIN)
2.2.7.2. Fill Rate
(FILL RATE/MIN)
/
2.2.7.3. Empty rate
(EMPTY RATE/MIN)
2.2.4.2.1. Echo Lock
2.4.1. Fail-safe
Timer
(time in min.)
Slow 0.1 m/min MAX. VERFICATION 100
Medium 1 m/min MAX. VERFICATION 10
Fast * 10 m/min MAX. VERFICATION 1
Level Space Distance
Distance
Space
Level
20 mA
100%
0%
4 mA
High
Cal.
Point
4 mA
0%
100%
20 mA
4 mA
0%
100%
20 mA
Sensor
reference
point
Low
Calibration
Point
Page 90 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
When the instrument is returned to Measurement mode, the transceiver resumes
operation. The reading and mA output default to the last measurement taken. The reading
and associated outputs migrate to the current process level at a rate controlled by the
response rate (2.2.7.1).
If SITRANS LR260 is left in PROGRAM
mode for 10 minutes without input, it automatically
reverts to Measurement mode.
Damping
A damping filter smooths out the response to a sudden change in level. This is an
exponential filter and the engineering unit is always in seconds. The setting can be
modified in
2.2.4.3.2. Damping Filter
.
Damping example
Loss of Echo (LOE)
A loss of echo (LOE) occurs when the calculated measurement is judged to be unreliable
because the echo confidence value has dropped below the echo confidence threshold.
If the LOE condition persists beyond the time limit set in
2.4.1. Fail-safe Timer
the LCD
displays the Maintenance Required icon, and the text region displays the fault code S: 0
and the text LOE.
If two faults are present at the same time, the fault code, error text, and error icon for
each fault are displayed alternately. For example, Loss of Echo and Fail-safe High.
S: 0 LOE S: 52 FAIL-SAFE
Fail-safe Mode
The purpose of the Fail-safe setting is to put the process into a safe mode of operation in
the event of a fault or failure. The value to be reported in the event of a fault is selected so
that a loss of power or loss of signal triggers the same response as an unsafe level.
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
1234567
Series 1 Ser i es2
time constant = 2 seconds
input (level) change = 2 m
In 5 time constants the output rises
exponentially:
from 63.2% of the change in the
first time constant, to almost 100%
of the change by the end of the 5th
time constant.
Level (m)
Time (s)
smoothed output
input (level)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 91
mmmmm
D: Technical Reference
Fail-safe Timer
Fail-safe Timer determines the time to elapse after the last valid reading before a Fail-
safe state is activated. Fail-safe Material Level determines the level to be reported when
the Fail-safe timer expires. Upon receiving a reliable echo, the loss of echo condition is
aborted, the Service Required icon and error message are cleared, and the reading and
mA output return to the current level.
Fail-safe Material Level
When the
2.4.1. Fail-safe Timer
expires, the material level to be reported is determined by
2.4.2. Fail-safe Material Level (FAILSAFE MAT. LEVEL)
.
Fail-safe Level
When Fail-safe Materila level is set to Value, the Fail-safe Level defines a user-defined
level to report when the Fail-safe timer expires..
Fail-safe Material Level
HI Use Maximum mA Limit as material level
LO Use Minimum mA Limit as material level
HOLD Level remains at last reading
VALUE User-selected value as defined in Fail-safe Level
Fail-safe Level
Values 3.6 to 22.6 mA
Page 92 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
Maximum Process Temperature Chart (UNDER
REVISION)
.
Where the chart does not apply, please use your own judgement regarding the use of
SITRANS LR260. Parameter 3.14.1 is required to monitor the Internal Temperature. It gives
you an excellent indication of how reliably the product will perform thermally when
installed on your process vessel.
3.14.1 also allows you to decide whether or not attention should be focussed on
redesigning the installation. For example, if the internal temperature exceeds the
maximum allowable limit, a sun shield or a longer nozzle may be required. Engineering
will use this temperature reading (3.14.1) to gauge the extent of change required to the
installation in order to provide a reliable thermal-operating zone for the SITRANS LR260.
Note: The chart below is for guidance only:
WARNING: Internal temperature must not exceed 80 °C (176 °F).
0
10
20
30
40
50
60
70
80
90
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160
flange
tempera-
ture
process
temperature
Ambient Temperature (oC)
Process Flange Surface Temperature (oC)
Maximum Flange and Process Temperatures versus allowable
ambient for flange adapter versions of SITRANS LR260
• The chart does not represent
every possible process
connection arrangement.
For example, it will NOT
apply if you are mounting
SITRANS LR260 directly on a
metallic vessel surface.
• The chart does not take into
consideration heating from
direct sunshine exposure.
ambient temperature
process temperature
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 93
mmmmm
D: Technical Reference
Process Pressure/Temperature derating curves
1
Notes:
• The Process Device Tag shall remain with the process pressure boundary
assembly1. In the event the instrument package is replaced, the Process Device Tag
shall be transferred to the replacement unit.
• SITRANS LR260 units are hydrostatically tested, meeting or exceeding the
requirements of the ASME Boiler and Pressure Vessel Code and the European
Pressure Equipment Directive.
• The serial numbers stamped in each process connection body, (flange, threaded, or
sanitary), provide a unique identification number indicating date of manufacture.
Example: MMDDYY – XXX (where MM = month, DD = day, YY = year, and
XXX= sequential unit produced
Further markings (space permitting) indicate flange configuration, size, pressure
class, material, and material heat code.
WARNINGS:
• Never attempt to loosen, remove or disassemble process connection
or instrument housing while vessel contents are under pressure.
• This product is designated as a Pressure Accessory per Directive 97/ 23 / EC
and is not intended for use as a safety device.
• Materials of construction are chosen based on their chemical
compatibility (or inertness) for general purposes. For exposure to
specific environments, check with chemical compatibility charts
before installing.
• The user is responsible for the selection of bolting and gasket
materials which will fall within the limits of the flange and its intended
use and which are suitable for the service conditions.
• Improper installation may result in loss of process pressure and/or
release of process fluids and/or gases.
1. The process pressure boundary assembly comprises the components that act as a barrier
against pressure loss from the process vessel: that is, the combination of process connec-
tion body and emitter, but normally excluding the electrical enclosure.
Page 94 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
Horn Antenna (UNDER REVISION)
2" (50 mm), 3" (80 mm) and 4" (100 mm) Flanged Versions: JIS 10 k1
2" (50 mm), 3" (80 mm) and 4" (100 mm) Flanged Versions: PN16
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under
pressure.
1. Customer to provide adequate bolting and flat-faced gasket to retain vessel pressure and
provide sufficient sealing.
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under
pressure.
0
1
2
3
4
5
6
7
8
9
-50 0 50 100 150 200
JIS 10k
Process Connection Series:
• 51242 or 51252 series
flange.
• Ensure your instrument
has the process
identification Tag showing
one of this series, and
25546, 25547, 25580 or
25581 stamped on flange.
process temperature (°C)
JIS 10 k
pressure (bar, gauge)
0
2
4
6
8
10
12
14
16
-50 0 50 100 150 200
PN16
Process Connection Series:
• 51242 or 51252 series flange.
• Ensure your instrument has
the process identification
Tag showing one of this
series, and 25546, 25547,
25580 or 25581 stamped on
flange.
process temperature (°C)
PN16
pressure (bar, gauge)
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 95
mmmmm
D: Technical Reference
2" (50 mm), 3" (80 mm) and 4" (100 mm) Flanged Versions: PN40
2" (50 mm), 3" (80 mm) and 4" (100 mm) Flanged Versions: 150 lb
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under
pressure.
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under
pressure.
0
5
10
15
20
25
30
35
40
-50 0 50 100 150 200
PN40
Process Connection Series:
• 51242 or 51252 series
flange.
• Ensure your instrument
has the process
identification Tag showing
one of this series, and
25546, 25547, 25580 or
25581 stamped on flange.
process temperature (°C)
PN40
pressure (bar, gauge)
0
2
4
6
8
10
12
14
16
18
-50 0 50 100 150 200
Process Temperature (°C)
Pressure (bar, gauge)
150lb
Process Connection Series:
• 51242 or 51252 series
flange.
• Ensure your instrument
has the process
identification Tag showing
one of this series, and
25546, 25547, 25580 or
25581 stamped on flange.
process temperature (°C)
150 lb
pressure (bar, gauge)
Page 96 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
D: Technical Reference
2" (50 mm), 3" (80 mm) and 4" (100 mm) Flanged Versions: 300 lb
Loop power
Typical Connection Drawing
WARNING: Never attempt to loosen, remove or disassemble process
connection or instrument housing while vessel contents are under
pressure.
Note: Loop voltage is the voltage at the terminals of the power supply (not the
voltage at the terminals of the device).
0
5
10
15
20
25
30
35
40
45
-50 0 50 100 150 200
Process Temperature (°C)
Pressure (bar, gauge)
300lb
Process Connection Series:
• 51242 or 51252 series
flange.
• Ensure your instrument
has the process
identification Tag showing
one of this series, and
25546, 25547, 25580 or
25581 stamped on flange.
process temperature (°C)
pressure (bar, gauge)
300 lb
+
-
LR260
loop resistance
RL
loop current IL
loop voltage power
supply
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 97
mmmmm
D: Technical Reference
Allowable operating area of SITRANS LR260
Loop Voltage versus Loop Resistance
Startup Behavior
Notes:
• SITRANS LR260 is designed to start reliably with a power supply capable of
delivering at least 25 mA.
• When connected to a power supply with a current limit of < 25 mA, the LR260 may
not start reliably.
0
100
200
300
400
500
600
700
800
900
1000
10.00 15.00 20.00 25.00 30.00
RL=44.6*VL - 493.4
RL=272.7*VL - 4554.1
(16.7v, 0 ohms)
(17.8v, 300 ohms)
(30.0v,845 ohms)
ALLOWABLE
OPERATING AREA
Power Supply Requirements
Loop Resistance - RL
Loop Voltage -VL
0
5
10
15
20
25
30
35
40
0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34
Time (seconds)
Current (mA)
No Current Limit Current Limited Power Supply
Typical Startup Current
Time (seconds)
Current (mA)
Loop Power Supply
without Current Limit
Loop Power Supply with
25 mA Current Limit
Current-limited powerNo current limit
Page 98 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
E: Application Examples
Appendix E: Application Example
You can use this examples as setup references. Enter the values in the parameter tables
to select the corresponding functions.
Configure the basic settings using the Quick Start wizard parameters. (These parameters
are inter-related, and changes take effect only after you select YES in step 7 to apply
changes.)
In each example, after performing a Quick Start, navigate to the other required
parameters (either via the handheld programmer, or via SIMATIC PDM) and enter the
appropriate values.
Flour in steel storage vessel, level measurement
Note: In the applications illustrated below, values are for example purposes only.
Note: Minimum distance from flange face to target is limited by
2.2.1.11. Near Range
.
To obtain level measurement/
4 to 20 mA output proportional
to flour levels:
Low Calibration Pt. = vessel
bottom
High Calibration Pt.= 0.5 m
from sensor reference point.
Max.fill/empty rate = 0.1 m/
min.
In the event of a loss of echo,
SITRANS LR260 is to go into
Fail-safe High after 2 minutes.
Sensor
Reference Point
level
Low
Calibration
Point
High
Calibration
Point
16 m
0.5 m
SITRANS LR260
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 99
mmmmm
E: Application Examples
Return to Measurement: press Mode to start normal operation.
Parameter
type
Parameter No. and
Name
Options/
Values Function
Quick Start
Wizard
parameters
1.1. Application Type
STEEL
1.2. Response Rate
SLOW Slow =0.1 m/minute
1.3. Units
Mmeters
1.4. Operation
LEVEL Level
1.5. Low Calibration Point
(LOW CALIB. PT.)
16 16 m
1.6. High Calibration Point
(HIGH CALIB. PT.)
0.5 0.5 m
1.7. Apply? (Apply changes)
YES Transfers Quick Start
settings to device.
Independent
parameters
2.4.1. Fail-safe Timer
22 minutes
2.4.2. Fail-safe Material
Level (FAILSAFE MAT.
LEVEL)
HI Failsafe level set to
High
Page 100 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
F: HART Communications
Appendix F: HART Communications
Highway Addressable Remote Transducer, HART, is an industrial protocol that is
superimposed on the 4-20 mA signal. It is an open standard, and full details about HART
can be obtained from the HART Communication Foundation at www.hartcomm.org
SITRANS LR260 can be configured over the HART network using either the HART
Communicator 375 by Fisher-Rosemount, or a software package. The recommended
software package is the SIMATIC Process Device Manager (PDM) by Siemens.
SIMATIC PDM
This software package is designed to permit easy configuration, monitoring, and
troubleshooting of HART devices. The HART DD for SITRANS LR260 was written with
SIMATIC PDM in mind and has been extensively tested with this software.
For more information, see
Operating via SIMATIC PDM
on page 31.
HART Device Description (DD)
In order to configure a HART device, the configurator must have the HART Device
Description for the instrument in question. HART DDs are controlled by the HART
Communication Foundation. Please check with the HART Communication Foundation for
the availability of the HART DD for SITRANS LR260. Older versions of the library will have
to be updated in order to use all the features of SITRANS LR260.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 101
mmmmm
F: HART Communications
HART Communicator 375 Menu Structure
QUICK START
APPLICATION TYPE
RESPONSE RATE
UNITS
OPERATION
LOW CALIB. PT.
HIGH CALIB. PT.
APPLY?
SETUP
DEVICE
FIRMWARE REV
LOADER REV
HARDWARE REV
INPUT
SENSOR CALIB.
SENSOR UNITS
OPERATION
LOW CALIB. PT.
HIGH CALIB. PT.
NEAR RANGE
FAR RANGE
SENSOR OFFSET
ECHO PROC.
ECHO SELECT
ALGORITHM
POSITION
ECHO THRESHOLD
ECHO MARKER
SAMPLING
ECHO LOCK
UP SAMP.
DOWN SAMP.
WINDOW
FILTERING
DAMPING FILTER
NARROW ECHO FILTER
REFORM ECHO
NOISE
CONFIDENCE
STRENGTH
NOISE AVERAGE
TVT SETUP
TVT HOVER LEVEL
AUTO ECHO SUPP
AUTO SUPP RANGE
SHAPER MODE
TVT TYPE
Note: HART Communicator 375 is supported by SITRANS LR260 HART. The menu structure
is aligned with the menu structure of SIMATIC PDM.
Page 102 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
F: HART Communications
TVT SHAPER
SHAPER 1-9(Shaper Points 1-9)
SHAPER 10-18 (Shaper Points 10-18)
SHAPER 19-27 (Shaper Points 19-27)
SHAPER 28-36 (Shaper Points 28-36)
SHAPER 37-40 (Shaper Points 37-40)
RATE
RESPONSE RATE
FILL RATE/min
EMPTY RATE/min
TB VALUES
LEVEL MEAS.
SPACE MEAS.
DISTANCE MEAS.
OUTPUT
MA OUTPUT
MA OUTPUT VALUE
MA OUTPUT FUNC.
4 MA SETPOINT
20 MA SETPOINT
MIN. MA LIMIT
MAX. MA LIMIT
4 MA OUTPUT TRIM
20 MA OUTPUT TRIM
FAIL-SAFE
FAILSAFE TIMER
FAILSAFE MAT. LEVEL
FAILSAFE LEVEL
DIAGNOSTICS
ECHO PROFILE
MEAS. VALUES
CURR. INTERN. TEMP.
MAX. INTERN. TEMP.
MIN. INTERN TEMP.
REMAIN. DEV. LIFE
TOTAL OP--TIME
REMAIN. LIFETIME
MAINT REQ LIMIT
MAINT DEM LIMIT
ALERT ACTIVATION
TOTAL EXP. LIFE
MAINT STAT
ACK STATUS
ACK
REMAIN. SENS. LIFE
SENSOR OP--TIME
REMAIN. LIFETIME
MAINT REQ LIMIT
MAINT DEM LIMIT
ALERT ACTIVATION
TOTAL EXP. LIFE
MAINT STAT
ACK STATUS
ACK
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 103
mmmmm
F: HART Communications
SERVICE
DEVICE RESET
MANUF. DATE
LCD FAST MODE
LCD CONTRAST
POWERED HOURS
POWERON RESETS
MEM. TEST
SERVICE INTERVAL
TIME LAST SERV
REMAIN LIFETIME
MAINT REQ LIMIT
MAINT DEM LIMIT
ALERT ACTIVATION
SERVICE INTERVAL
MAINT STAT
ACK STATUS
ACK
CALIB. INTERVAL
TIME LAST CAL.
REMAIN LIFETIME
MAINT REQ LIMIT
MAINT DEM LIMIT
ALERT ACTIVATION
TOTAL CALIB.INTRV
MAINT STAT
ACK STATUS
ACK
COMMUNICATION
DEVICE ADDRESS
COMM. CONTROL
SECURITY
LOCK
UNLOCK VALUE
LANGUAGE
Page 104 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
F: HART Communications
Supported HART Commands
SITRANS LR260 conforms to HART rev. 5 and supports the following:
Universal Commands
0, 1, 2, 3, 6, 7, 8, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22
Common Practice Commands
33, 34, 35, 36, 37, 38, 40,41, 42, 44, 45, 46, 48, 50, 51, 53, 54, 59
Device Specific Commands
Command 150 Read Echo Summary
Command 151 Read Echo Data Profile
Command 160 Updated Read Echo Summary
Command 166 Read Failsafe
Command 167 Write Failsafe
Command 170 Read Echo Lock
Command 171 Write Echo Lock
Command 172 Read TVT
Command 173 Write TVT
Command 174 Read TVT Shaper
Command 175 Write TVT Shaper
Command 178 Read Analog Special
Command 179 Write Analog Special
Command 182 Read Range Calibration
Command 183 Write Range Calibration
Command 186 Read Wear
Command 206 Read Confidence
Command 207 Write Confidence Threshold
Command 208 Read Local Display Commands
Command 209 Write Local Display Commands
Universal and Common Practice Commands
For details on the Universal and Common Practice Commands, please contact the HART
Communication Foundation.
Device Specific Commands
For a document containing the Device Specific Commands, please contact Siemens
Milltronics at techpubs.smpi@siemens.com.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 105
mmmmm
G: Sorftware Revision
Appendix G: Software Revision History
Soft-
ware
Rev.
DD Rev. Date Changes
1.00.00-01 1.00.00-01 mm/dd/yyyy • Initial release
Page 106 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
G: Sorftware Revision
Notes
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 107
mmmmm
Glossary
Glossary
accuracy: degree of conformity of a measure to a standard or a true value.
algorithm: a prescribed set of well-defined rules or processes for the solution of a problem in a
finite number of steps.
ambient temperature: the temperature of the surrounding air that comes in contact with the
enclosure of the device.
antenna: an aerial which sends out and receives a signal in a specific direction. There are four
basic types of antenna in radar level measurement, horn, parabolic, rod, and waveguide.
attenuation: a term used to denote a decrease in signal magnitude in transmission from one
point to another. Attenuation may be expressed as a scalar ratio of the input magnitude to
the output magnitude or in decibels.
Auto False-Echo Suppression: a technique used to adjust the level of a TVT curve to avoid the
reading of false echoes. (See TVT.)
Auto False-Echo Suppression Distance: defines the endpoint of the TVT distance. (See TVT.)
This is used in conjunction with auto false echo suppression.
beam width: the angle diametrically subtended by the one-half power limits (-3 dB) of the
microwave beam.
beam spreading: the divergence of a beam as it travels through a medium.
blanking: a blind zone extending away from the reference point plus any additional shield
length.The instrument is programmed to ignore this zone.
capacitance: the property of a system of conductors and dielectrics that permits the storage of
electricity when potential differences exist between the conductors. Its value is
expressed as the ratio of a quantity of electricity to a potential difference, and the unit is a
Farad.
confidence: describes the quality of an echo. HIgher values represent higher quality.
Confidence threshold defines the minimum value.
damping: term applied to the performance of an instrument to denote the manner in which the
measurement settles to its steady indication after a change in the value of the level.
dB (decibel): a unit used to measure the amplitude of signals.
Page 108 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Glossary
derating: to decrease a rating suitable for normal conditions according to guidelines specified
for different conditions.
dielectric: a nonconductor of direct electric current.1
dielectric constant (dK): the ability of a dielectric to store electrical potential energy under the
influence of an electric field. Also known as Relative Permittivity. An increase in the
dielectric constant is directly proportional to an increase in signal amplitude. The value is
usually given relative to a vacuum /dry air: the dielectric constant of air is 11.
echo: a signal that has been reflected with sufficient magnitude and delay to be perceived in
some manner as a signal distinct from that directly transmitted. Echoes are frequently
measured in decibels relative to the directly transmitted signal.
echo confidence: the recognition of the validity of the echo. A measure of echo reliability.
Echo Lock Window: a window centered on an echo in order to locate and display the echo’s
position and true reading. Echoes outside the window are not immediately processed.
Echo Marker: a marker that points to the processed echo.
Echo Processing: the process by which the radar unit determines echoes.
Echo Strength: describes the strength of the selected echo in dB referred to 1 µV rms.
Echo Profile: a graphical display of a processed echo.
false echo: any echo which is not the echo from the desired target. Generally, false echoes are
created by vessel obstructions.
frequency: the number of periods occurring per unit time. Frequency may be stated in cycles
per second.
Hertz (Hz): unit of frequency, one cycle per second. 1 Gigahertz (GHz) is equal to 109 Hz.
HART: Highway Addressable Remote Transducer. An open communication protocol used to
address field instruments.
horn antenna: a conical, horn-shaped antenna which focuses microwave signals. The larger
the horn diameter, the more focused the radar beam.
inductance: the property of an electric circuit by virtue of which a varying current induces an
electromotive force in that circuit or in a neighboring circuit. The unit is a Henry.
microwaves: the term for the electromagnetic frequencies occupying the portion of the radio
frequency spectrum from 1 GHz to 300 GHz.
1. Many conductive liquids/electrolytes exhibit dielectric properties; the relative dielec-
tric constant of water is 80.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 109
mmmmm
Glossary
multiple echoes: secondary echoes that appear as double, triple, or quadruple echoes in the
distance from the target echo.
Near Blanking: see Blanking
nozzle: a length of pipe mounted onto a vessel that supports the flange.
parameters: in programming, variables that are given constant values for specific purposes or
processes.
polarization: the property of a radiated electromagnetic wave describing the time-varying
direction and amplitude of the electric field vector.
polarization error: the error arising from the transmission or reception of an electromagnetic
wave having a polarization other than that intended for the system.
propagation factor (pf): where the maximum velocity is 1.0, pf is a value that represents a
reduction in propagation velocity as a result of the wave travelling through a pipe or
medium.
pulse radar: a radar type that directly measures distance using short microwave pulses.
Distance is determined by the return transit time.
radar: radar is an acronym for RAdio Detection And Ranging. A device that radiates
electromagnetic waves and utilizes the reflection of such waves from distant objects to
determine their existence or position.
range: distance between a transmitter and a target.
range extension: the distance below the zero percent or empty point in a vessel.
relative humidity: the ratio of the actual amount of moisture in the atmosphere to the maximum
amount of moisture the atmosphere could hold (which varies depending on the air
temperature).
relative permittivity: see dielectric constant.
repeatability: the closeness of agreement among repeated measurements of the same
variable under the same conditions.
shot: one transmit pulse or measurement.
speed of light: the speed of electromagnetic waves (including microwave and light) in free
space. Light speed is a constant 299, 792, 458 meters per second.
stillpipe: a pipe that is mounted inside a vessel parallel to the vessel wall, and is open to the
vessel at the bottom.
Page 110 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Glossary
stilling-well: see stillpipe.
two wire radar: a low-energy radar. Can be loop powered, analog, intrinsically safe 4 to 20 mA,
or a digital (BUS) transmitter.
TVT (time varying threshold): a time-varying curve that determines the threshold level above
which echoes are determined to be valid.
waveguide antenna: a hollow, metallic tube that transmits a microwave signal to the product
target.
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 111
mmmmm
Index
Index
A
Abbreviations and Identifications
list 3
activating LR250 21
analog output
fail signal 6
in Measure mode 89
load 6
signal range 6
approvals 7
Auto False Echo Suppression
explanation 88
setup 52
via PDM 38
B
blanking (see Near Range) 88
C
cables
requirements 17
cleaning
instructions 85
communication
load 6
max. line length 6
conduits
requirements 17
D
device description
HART 100
E
echo confidence
parameter setup 51
echo profile viewing
via LUI 27
via PDM 37
edit mode
handheld programmer 26
key functions 26
enclosure
opening 17
F
factory defaults
device reset via LUI 65
device reset via PDM 41
Fail-safe
settings 59
Fail-safe Timer
explanation 91
Far Range
explanation 89
setup 47
function keys
measurement mode 23
navigation mode 25
H
handheld programmer
edit mode 26
measurement mode 23
navigation 25
HART
device description 100
HART Communications
details 100
HART version 6
hazardous area installations
wiring requirements 19
I
Identifications and Abbreviations
list 3
installation
hazardous area requirements 19
internal temperature
monitoring 92
K
key functions
edit mode 26
L
LCD display
contrast adjustment 66
echo profile viewing 27
fast mode 65
measurement mode 21
PROGRAM mode 22
level application example
via LUI 30
level trend viewing
via PDM 40
lid-lock set screw 17
Loss of Echo (LOE)
explanation 90
M
mA output in Measure mode 89
Page 112 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Index
maintenance
cleaning 85
maintenance settings 60
Measurement Response
explanation 89
mounting
handheld programmer access 11
housing construction 11
nozzle design 10
nozzle location 10
on vessel with obstructions 11
sunshield recommended 11
N
Near Range
explanation 88
O
operating principles 86
P
parameter settings
adjust via PDM 31
performance
specifications 5
polarization reference point 11
power 5
power source
requirements 17
process temperature
maximum 92
programmer
handheld 23
Q
Quick Start
launching via PDM 33
Quick Start Wizard
via LUI 28
via SIMATIC PDM 32
R
range extension
see Far Range 89
reset
factory defaults via LUI 65
factory defaults via PDM 41
S
settings
adjust parameters via LUI 26
adjust parameters via PDM 31
SIMATIC PDM 31
features of rev. 6.0 31
Quick Start 33
simulate analog output 41
SITRANS LR 250
overview 4
SITRANS LR250
operating principles 86
specifications 5
ambient temperature 7
antenna 6
enclosure 6
environmental 7
performance 5
power 5
pressure 7
process connections 6
process temperature 7
weight 6
T
technical support
contact information 2
temperature de-Rating
curves 93
terminals
accessing 17
trend diagram
level trend viewing 40
troubleshooting
communications 76
operation 82
TVT curve 88
TVT Shaper
manual adjustment via PDM 40
W
wiring
cables 17
connecting HART 18
hazardous areas 19
7ML19985KE01 SITRANS LR260 (HART) – INSTRUCTION MANUAL Page 113
mmmmm
Index
Notes
Page 114 SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985KE01
mmmmm
Index
Page 116 SITRANS LR260 (HART) – INSTRUCTION MANUAL SITRANS LR260 (HART) – INSTRUCTION MANUAL 7ML19985JE01
Appendix C: menu chart
LCD menu structure
1. QUICK START
1.1 APPLICATION TYPE
1.2 RESPONSE RATE
1.3 UNITS
1.4 OPERATION
1.5 LOW CALIB. PT.
1.6 HIGH CALIB. PT.
1.7 APPLY?
2. SETUP
2.1 DEVICE
2.1.1 FIRMWARE REV
2.1.2 LOADER REV
2.1.3 HARDWARE REV
2.2 INPUT
2.2.1 SENSOR CALIB.
2.2.1.4 SENSOR UNITS
2.2.1.5 OPERATION
2.2.1.6 LOW CALIB. PT.
2.2.1.7 HIGH CALIB. PT.
2.2.1.11 NEAR RANGE
2.2.1.12 FAR RANGE
2.2.1.24 SENSOR OFFSET
2.2.4 ECHO PROC.
2.2.4.1 ECHO SELECT
2.2.4.1.1 ALGORITHM
2.2.4.1.2 POSITION
2.2.4.1.3 ECHO THRESHOLD
2.2.4.1.5 ECHO MARKER
2.2.4.2 SAMPLING
2.2.4.2.1 ECHO LOCK
2.2.4.2.4 UP SAMPLING
2.2.4.2.5 DOWN SAMPLING
2.2.4.2.6 WINDOW
2.2.4.3FILTERING
2.2.4.3.2 DAMPING FILTER
2.2.4.3.6 NARROW ECHO FILTER
2.2.4.3.7 REFORM ECHO
2.2.4.5 NOISE
2.2.4.5.1 CONFIDENCE
2.2.4.5.2 STRENGTH
2.2.4.5.3 NOISE AVERAGE
2.2.5 TVT SETUP
2.2.5.1 TVT HOVER LEVEL
2.2.5.2 AUTO ECHO SUPP
2.2.5.3 AUTO SUPP RANGE
2.2.5.4 SHAPER MODE
2.2.5.6 TVT TYPE
2.2.6 TVT SHAPER
2.2.6.1 SHAPER 1-9
2.2.6.2 SHAPER 10-18
2.2.6.3 SHAPER 19-27
2.2.6.4 SHAPER 28-36
2.2.6.5 SHAPER 37-40
2.2.7 RATE
2.2.7.1 RESPONSE RATE
2.2.7.2 FILL RATE /MIN
2.2.7.3 EMPTY RATE /MIN
2.2.8 TB VALUES
2.2.8.2 LEVEL MEAS.
2.2.8.3 SPACE MEAS.
2.2.8.4 DISTANCE MEAS.
2.3 OUTPUT
2.3.1 MA OUTPUT
2.3.1.1 MA OUTPUT VALUE
2.3.1.2 MA OUTPUT FUNC.
2.3.1.3 4 MA SETPOINT
2.3.1.4 20 MA SETPOINT
2.3.1.5 MIN. MA LIMIT
2.3.1.6 MAX. MA LIMIT
2.3.1.7 4 MA OUTPUT TRIM
2.3.1.8 20 MA OUTPUT TRIM
2.4 FAIL-SAFE
2.4.1 FAILSAFE TIMER
2.4.2 FAILSAFE MAT. LEVEL
2.4.4 FAILSAFE LEVEL
3. DIAGNOSTICS
3.1 ECHO PROFILE
3.14 MEAS. VALUES
3.14.1 CURR. INTERN. TEMP.
3.14.2 MAX. INTERN. TEMP.
3.14.3 MIN. INTERN TEMP.
3.15 REMAIN. DEV. LIFE
3.15.1 TOTAL OP--TIME
3.15.2 REMAIN. LIFETIME
Notes:
• In Navigation mode ARROW keys navigate the menu in the
direction of the arrow..
• See
See Parameter Reference
on page 42.
for detailed information
and instructions.
7ML19985KE01 SITRANS LR260– INSTRUCTION MANUAL Page 117
mmmmm
LCD menus
3.15.3 MAINT REQ LIMIT
3.15.4 MAINT DEM LIMIT
3.15.5 ALERT ACTIVATION
3.15.6 TOTAL EXP. LIFE
3.15.7 MAINT STAT
3.15.8 ACK STATUS
3.15.9 ACK
3.16 REMAIN. SENS. LIFE
3.16.1 SENSOR OP--TIME
3.16.2 REMAIN. LIFETIME
3.16.3 MAINT REQ LIMIT
3.16.4 MAINT DEM LIMIT
3.16.5 ALERT ACTIVATION
3.16.6 TOTAL EXP. LIFE
3.16.7 MAINT STAT
3.16.8 ACK STATUS
3.16.9 ACK
4. SERVICE
4.1 DEVICE RESET
4.2 MANUF. DATE
4.3 LCD FAST MODE
4.4 LCD CONTRAST
4.6 POWERED HOURS
4.9 POWERON RESETS
4.11 MEM. TEST
4.16 SERVICE INTERVAL
4.16.1 TIME LAST SERV
4.16.2 REMAIN LIFETIME
4.16.3 MAINT REQ LIMIT
4.16.4 MAINT DEM LIMIT
4.16.5 ALERT ACTIVATION
4.16.6 SERVICE INTERVAL
4.16.7 MAINT STAT
4.16.8 ACK STATUS
4.16.9 ACK
4.17 CALIB. INTERVAL
4.17.1 TIME LAST CAL.
4.17.2 REMAIN LIFETIME
4.17.3 MAINT REQ LIMIT
4.17.4 MAINT DEM LIMIT
4.17.5 ALERT ACTIVATION
4.17.6 TOTAL CALIB.INTRV
4.17.7 MAINT STAT
4.17.8 ACK STATUS
4.17.9 ACK
5. COMMUNICATION
5.1 DEVICE ADDRESS
5.2 COMM. CONTROL
6. SECURITY
6.1 LOCK
6.2 UNLOCK VALUE
7. LANGUAGE
