3EM21522AAAA

Front Matter

Issue 1, March 2008

DTR-0200-SA-SIRIUS

FM-

FRONT MA

TTER:

Inc

ludes the general manual la

yout by section,

customer service cen

ter information,

telephone tec

hnical support information,

safety precautions

and

arranty/repair information.

GENERAL

– SECTION 1:

Provides a general description of the system to inc

lude its pur

pose and a high level breakdown of components

ables list physical,

environmental,

and electrical c

haracteristics;

equipment supplied;

optional equipment;

and equip

ment required but not supplied.

FUNCTIONAL DESCRIPTION

– SECTION 2:

Describes operation of the overall equipment,

any subsystems/sub functions

and the purpose/function of eac

h module/unit.

INSTALLATION

– SECTION 3:

Contains instructions for the installation of the SIRIUS

repeater;

also references supporting engineering dra

wings

TURNUP AND TEST – SECTION 4:

Procedures to turn-up the DTR-0200-SA-SIRIUS

repeater after installation.

Also provides post-installation and post-maintenance sys

tem test procedures

OPERA

TION

– SECTION 5:

Provides procedures/information for normal operation,

use

of graphical user interface

and all controls

indicators

test points

and connectors

used for installation,

operation,

and maintenance

MAINTENANCE – SECTION 6:

Describes the maintenance philosophy and method

applicable to the equipment,

lists recommended test equipment,

identiﬁ

es and

inc

ludes recommended periodic c

hec

inc

ludes troubleshooting/analysis informa

tion,

identiﬁ

es actions required after module replacement,

and inc

ludes post-

repair/replacement c

hec

k and adjustment procedures

APPENDIX A:

Contains repeater dra

wings to support information presented in this

Operation and Maintenance (O & M) manual.

APPENDIX B:

Contains

Alcatel-Lucent part numbers

APPENDIX C:

Lists locally correctable alarms

their probable causes

and suggested

responses

NORTH AMERICA CUSTOMER SERVICE CENTER

24 HOURS PER DAY, 7 DAYS PER WEEK

PHONE the Call Center at

888-252-2832 (US and Canada)

613-784-6100 (International)

ALCATEL-LUCENT’S PRIMARY MISSION IS

SATISFYING OUR CUSTOMERS' QUALITY EXPECTATIONS.

The Call Center Agent (CSA)

Will help connect you with Technical Assistance (TAC)

Or assist you with a Repair and Return

• Phone-based technical support

• After-hour emergencies

• On-site technical support

• E-mail support ml-tac.support@alcatel-lucent.com

• Software and hardware upgrades

TAC

• Module repair

Repair and Return

• Training http://www.alcatel-lucent.com>support

– Technical Training

Other Services Offered

• Field Services

– Installation and test

• Customized and Comprehensive Service Agreements

• Registration http://www.alcatel-lucent.com>MyAccess

– Once registered

– From “MyAlcatel” go to “Alcatel Support Documentation”

–

For Product Change Notices (PCN), Product Documentations, etc.

– Software and Hardware upgrade documentation

Telephone Assistance, Normal Working Hours (CST 8am 5pm M-F)

TAC supports all Alcatel North America Microwave products. This includes routine questions and

emergency service.

Telephone Assistance, Emergency After-Hours

• Defined as loss of traffic, standby equipment, or network visibility on traffic-bearing systems.

• Available through our Customer Service Agents (CSA).

Contact Information Ask the Customer Service Agent (CSA) for a Microwave (MW) or a Network

Management Service engineer (NMS).

Please provide the following information to the Customer Service Agent (CSA):

• Last and First name

• Company name

• Telephone number

• City and state (Street address if applicable) or Site Name and Location

• Equipment type

• A brief description of the problem affecting their equipment

• Customer Priority: High, Medium, or Low.

• TL-9000 Severity as described below.

Creating a TAC Action Request (AR)

Critical

TL-9000 Severities Defined

Major

Minor Problems not classified as critical or major.

Problems severely affecting service, traffic, capacity, or network

management. They require immediate corrective action. (Ex.

Loss of network management capability, loss of traffic imminent

or existing).

Conditions seriously affecting system operation. They require

immediate attention. (Ex. processor outage, loss of standby

equipment, loss of remote access, or network managers).

TAC

Technical Assistance Center

Telephone Assistance, Normal Working Hours (CST 8am 5pm M-F)

TAC supports all Alcatel North America Microwave products. This includes routine questions and

emergency service.

Telephone Assistance, Emergency After-Hours

• Defined as loss of traffic, standby equipment, or network visibility on traffic-bearing systems.

• Available through our Customer Service Agents (CSA).

Contact Information Ask the Customer Service Agent (CSA) for a Microwave (MW) or a Network

Management Service engineer (NMS).

Please provide the following information to the Customer Service Agent (CSA):

• Last and First name

• Company name

• Telephone number

• City and state (Street address if applicable) or Site Name and Location

• Equipment type

• A brief description of the problem affecting their equipment

• Customer Priority: High, Medium, or Low.

• TL-9000 Severity as described below.

Creating a TAC Action Request (AR)

Critical

TL-9000 Severities Defined

Major

Minor Problems not classified as critical or major.

Problems severely affecting service, traffic, capacity, or network

management. They require immediate corrective action. (Ex.

Loss of network management capability, loss of traffic imminent

or existing).

Conditions seriously affecting system operation. They require

immediate attention. (Ex. processor outage, loss of standby

equipment, loss of remote access, or network managers).

TAC

Technical Assistance Center

Front Matter

3EM21522AAAA

DTR-0200-SA-SIRIUS

Issue 1, March 2008

FM-

SAFETY PRECAUTIONS

ersonnel should use caution when installing, testing, operating, and servicing this

equipment.

As with all electronic equipment, care should be taken t avoid electrical shock where

substantial currents or voltages may be present.

Deﬁnitions of Danger, Warnings, Cautions, and Notes used throughout this manual

are described below.

An operating pr

ocedure, practice, etc., which, if not correctly

followed could result in personal injury or loss of life.

An operating pr

ocedure, practice, etc., which, if not strictly

observed, could result in damage to equipment.

An operating procedure, practice, etc., which, if not strictly

observed, could result in an interruption of service.

An operating procedure

, condition, etc., which is essential to highlight.

3EM21522AAAA

Front Matter

Issue 1, March 2008

DTR-0200-SA-SIRIUS

FM-

ELECTRICAL SAFETY

: GENERAL RULES

Carefully observe the speciﬁ

c procedures for installation, turnup, and mainte-

nance where AC or DC power is present and observe the following general infor-

mation/rules.

• Remove rings, watches, and other metal jewelry. Short circuits in low-voltage, low-

impedance DC circuits can cause severe arcing that my result in burns or eye

injury. Exercise caution to avoid shorting power input terminals.

•

This equipment is intended for installation in a RESTRICTED ACCESS

LOCATION ONLY.

•

Installation and maintenance are to be performed only by technically qualiﬁed

professional personnel.

ATIC ELECTRICITY

When the above symbol or letters are displayed, observe special precautions.

An electrostatic-sensitive device can be weakened, damaged or destroyed even by a

minute discharge that would even go unnoticed by a technician.

Common plastics, clothing, and paper or cardboard are the most common sources of

static charges.

Common plastic, white foam, cellophane and masking adhesive tapes must not come

in contact with ESS devices or their packaging.

Front Matter 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

FM-6

MODULE HANDLING

To minimize risk of damage to an ESS device:

• All modules should be handled as static sensitive devices

• Heel straps are only effective while standing on conductive or static dissipative

surfaces

• Ground straps, either wrist (PN 055-9357-010) or heel (PN 055-9357-020), should

be worn prior to and while touching or handling modules containing ESS devices.

• Surfaces (with resistance to ground in excess of 100 Meg-ohms), such as ordinary

tile, should be covered with properly grounded static dissipative runners or waxed

with a static dissipative wax (PN 057-4000-006)

• Modules (even temporarily) should be stored, packed, or shipped in antistatic bags

or containers

• Do not handle modules by touching the electrical components and circuit board.

Use the plastic handle or other outside casing

• Use only ESS rated cleaning devices to clean modules

• Be sure to handle failed modules with the same precautions as good modules

WARRANTY/REPAIR INFORMATION

GENERAL WARRANTY PROVISIONS

Alcatel-Lucent guarantees to repair or replace, or refund the complete purchase

price of any equipment, accessories or parts manufactured by Alcatel-Lucent, which

are defective as to workmanship, or material, provided that:

• Notice of the claimed defect or unsuitability is given in writing to Alcatel-Lucent

within the warranty period after delivery, acceptance, or use, whichever is earlier.

• The defective or unsuitable equipment, accessory, or part is returned to Alcatel-

Lucent at its factory (transportation prepaid), in accordance with the instructions

given in the Module Return section below.

• An inspection of the returned goods by Alcatel-Lucent at its factory indicates that

the defect was not caused by abuse or improper use, maintenance, repair, or alter-

ation by other than Alcatel-Lucent or its authorized service center.

3EM21522AAAA Front Matter

Issue 1, March 2008 DTR-0200-SA-SIRIUS

FM-7

MODULE RETURN

Call Repair and Return Customer Service Agent (CSA) at 1-888-252-2832

• To receive a Return Authorization (RA) number

• For Emergency Orders

• For Advance Replacement

Please follow this procedure when returning equipment:

For the unit(s) to be repaired, include the following information

• Serial Number of the part

• Company name, billing and shipping address, phone number, and contact

name(s)

• Description of all known facts as to the nature of the failure(s)

• Purchase order number or requisition number

• Type number, part number, description of unit, and quantity to be repaired

• Description of any additional repair instructions

Note: With any correspondence the RA number must be prominently noted or

marked on all shipping labels, packing lists, and other communications.

FM--8 This page intentionally left blank.

3EM21522AAAA Genera

Issue 1, March 2008 DTR-0200-SA-SIRIUS

1-1

1GENERAL

1.1

INTRODUCTION

The Terrestrial Satellite Repeater is a modular solid-state device that receives audio/

video multiplexed data transmissions via a SIRIUS Satellite. The repeater then pro-

cesses the received

data and retransmits it through tower mounted antennas to end

users’

receivers.

Figure 1 - 1 is a simpliﬁed diagram of a SIRIUS Terrestrial Repeater broadcast system.

A repeater site (part of the broadcast system) includes a Very Small Aperture Termi-

nal (VSAT) antenna with a Low Noise Block converter (LNB) attached, a Global

Positioning System (GPS) antenna, a repeater unit, and tower mounted transmitting

antennas.

The repeater site interfaces to a SIRIUS Network Management Center (NMC) via

TELCO lines to monitor repeater operational status.

Figure 1 - 2

illustrates a typical repeater site layout.

Figure 1 - 1 Typical Sirius Terrestrial Repeater Broadcast System

CDDS

Over RS-422

Multiplex Source

VSAT Uplink

Studio

Intelsat 6 Ku Band

COFDM

Mobile Receivers

DTR-1000

02/22/07

Terrestrial Repeater

DVB-S

DVB-S2

Duration: 347.38 mSec

COFDM Clock Rate: 8.1921375 Mbaud

Terrestrial Broadcasting

COFDM Transmission Frame

Guard

Interval

184 Bits

2048 Bits

Guard

Interval

184 Bits

2048 Bits

Guard

Interval

184 Bits

2048 Bits

1275 Segments

Guard

Interval

184 Bits 2048 Bits

Genera

3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

1-2

Figure 1 - 2 Typical Sirius Terrestrial Repeater Site

1.2

REPEATER MAIN COMPONENT BREAKDOWN

The terrestrial repeater can be divided into the following main components:

• Signal Processing Unit (SPU)

• High Power Ampliﬁer (HPA)

• Power Distribution Unit (PDU)

The cabinet also contains the following

• Output Band Pass Filter

• Output Coupler

Each of these components is addressed in the Functional Description section of this

manual.

CDDS Signal

From Satellite

VSAT + LNB

Antenna

COFDM RF Signal

To Customer

DTR-1001

02/22/07

REPEATER

TRANSMIT ANTENNA

Customer Equipment

GPS

Antenna PSTN

Alarms

to NMS

3EM21522AAAA Genera

Issue 1, March 2008 DTR-0200-SA-SIRIUS

1-3

1.3

REPEATER COMPOSITION

The repeater functional components comprise the following:

•HPA (located at the top level of the cabinet)

Power Ampliﬁer

Module Pre-Driver

Splitter

Combiner

Power Supply

HPA Controller

• SPU (located at the middle level of the cabinet)

VSAT Receiver Module

Modulator Module

Main Controller Module

Up-Converter Module

Uninterruptible Power Supply (UPS)

• PDU (located t the bottom level of the cabinet)

Main power distribution source for the repeater

• Utility Compartment (shared with PDU)

Band Pass Filter

Output Coupler

Input/Output Junction Box

RF Detectors

The repeater cabinet contains hinged and lockable front and rear doors which provide

access to the internals of the repeater. The cabinet, designed to protect the repeater

internal components against adverse environmental conditions, is provided with ven-

tilating fans and heater units.

See

Figure 1 - 3

and

Figure 1 - 4

for front and rear views of the repeater cabinet.

Genera

3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

1-4

Figure 1 - 3 Front View of the Terrestrial Repeater

Figure 1 - 4 Rear View of the Terrestrial Repeater

3EM21522AAAA Genera

Issue 1, March 2008 DTR-0200-SA-SIRIUS

1-5

1.4

DIGITAL TERRESTRIAL REPEATER NAMING CONVENTION

DTR-0200-SA-SIRIUS

Mobile TV Standard

DVB-T/H DAB

DMB-S/T/H Eurika 147

ISDBT

FLO

CUST (Custom COFDM Waveform)

SIRIUS… Proprietary Signal

Method of Cooling

A = Air Cooled

L = Liquid Cooled

Frequency Band

V =

VHG Band III (174 to 230 MHz)

U = UHF (470 to 862 MHz)

L = L-Band (~1.4 to 1.7 GHz)

S = S-Band (~2.1 to 2.7 GHz)

Output Power in Watts

0200 = 200 Watts

1000 = 1000 Watts

Digital Terrestrial Repeater

DTR-1002

02/22/07

Genera

3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

1-6

1.5

SYSTEM CONFIGURATIONS

At the selected site the repeater can be mounted one of three ways:

• ground mount

• roof mount

• shelf mount

The repeater electrical and physical conﬁguration is the same for either mounting.

1.6

TERRESTRIAL REPEATER TECHNICAL SPECIFICATIONS

Table 1-1 Physical, Electrical, and Environmental Speciﬁcations

Weight Approx. 121 kg (266 lbs.)

Dimensions 60.10 x 102.55 x 67.63 cm / 26.81 x 36 x

40.38 x 26.63 in.

Cooling Forced Air

Power Requirements 188-250VAC, 208 VAC NOMINAL, 57-63 HZ

Power Consumption 2.0 KW, TYPICAL

UPS Duration For Main Controller 5 minutes

Operating Temperature -25ºC to +55ºC / -13ºF to +131ºF

Storage Temperature -50ºC to +65ºC / -58ºF to +149ºF

Humidity 95% Non-condensing

Ratings/Circuit Breaker Max Effective Load/Circuit Breaker

CB1 – SPU: 240V, 5A – 1.20kW

@ MAX 55ºC Max current 0.75A

CB2 - HPA: 240V, 25A – 6.00 kW

@ MAX 55ºC Max current 12.5A

CB3 - FANS: 240V, 5A – 1.20 kW

@ MAX 55ºC4 fans, 80W each – 320W total

Max. current 1.5A

CB4 - EXTERNAL

HEATER: 120V, 5A – 0.240 kW

@ MAX 55ºCMax. power 200W

Max. current 1.7A

CB5 - AUXILIARY

POWER: 120V, 10A – 0.600

kW @ MAX 55ºC Max. current 5A

CB6 – INTERNAL

HEATER: 240V, 5A – 1.20 kW

@ MAX 55ºC2 Heaters 500W (nominal)

Max total. current @ 240VAC, 4.2A

CB0 – MAIN

CIRCUIT BREAKER: LINE 1 - 240V, 32A

@ MAX 55ºC

LINE 2 - 240V, 32A

@ MAX 55ºC

NEUTRAL - 32A

@ MAX 55ºC

Max. load per Line and Neutral:

LINE 1: Max current 25.7A

LINE 2: Max current 19A

NEUTRAL: Max current 6.7A

3EM21522AAAA Genera

Issue 1, March 2008 DTR-0200-SA-SIRIUS

1-7

Table 1-2 Transmitter RF Output Performance

Operating Frequency 2326.25 MHz

Bandwidth 4.012 MHz

Rated Output Power +53.0 dBm

Output Power Set Point Range 10 dB

Step Size 0.5 dB

Output Level Stability vs. Time ≤ -0.25 dB/24 hrs. max

Output Level Accuracy ≤ ±0.5 dB about selected level (+47 to +53 dBm range)

Spectral Re-growth See Note 1 and Note 2

In-Band Carrier to Intermodulation Ratio >25 dB

Spurious Level Outside Channel < -60 dBm

Amplitude Flatness Center Frequency ±2.006 MHz, ±0.5 dB

Connector Type 7/16'' DIN, female, 50 ohm

Output VSWR ≤ 1.3:1

Note 1:The total RMS power in a bandwidth of 4.20 MHz centered around 2322.255 MHz, measured at

the input to the antenna/cable system, is better than 40 dB down with respect to the RMS power in the

transmitter COFDM signal measured at the same reference point.

Note 2:The total RMS power in a bandwidth of 4.20 MHz centered around 2330.245 MHz, measured at

the input to the antenna/cable system, is better than 40 dB down with respect to the RMS power in the

transmitter COFDM signal measured at the same reference point.

Table 1-3 Control Interfaces

NOC Interface

Connector RJ11

Standard V90

Protocol SNMP, WEB Interface

Ethernet Interface

Connector RJ45, 10/100/1000 Base T

Protocol SNMP, WEB Interface

RS 232

Connector DB9 (M)

Protocol Local Console Interface

GPS Antenna

Connector N-Type, female, 50 ohms, with bias voltage

Genera

3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

1-8

Table 1-4 Repeater Signal Inputs

VSAT Ku Band (L-Band after LNB)

Frequency Range 950 – 2150 MHz

Nominal Input Level -65 to -25 dBm

Waveform S1, S2

LNB Bias Provided

Connector F-type, female, 75 ohms

Ethernet Input

Signal IP multicast, standard 10/100 Base T interface

Connector RJ45

ASI Input

Connector BNC, 75 ohms

Table 1-5 Signal Processing

Aggregate Data Rate 7.340625 Mbps

COFDM nominal bandwidth used 4.012 MHz

Modulation Type Pi/4 Differential QPSK with adjustable amplitude

and phase offset for hierarchical modulation

Number of Active Carriers 1000 (+2 unmodulated pilots +1 central null)

Intercarrier Spacing 4 kHz

FFT Size 2048 points (2 times oversampling)

COFDM Sampling Rate (1/T_COFDM) 4.096 MHz (with no oversampling)

COFDM FFT Rate (1/T_FFT) 3.6703125 kHz

Total Symbol Duration 272.4564 us

Useful Symbol Duration 250 us

Guard Interval 22.4564 us

COFDM Demodulator Output Symbol Rate (1/Ts) 3.6703125 Mbaud QPSK

Time and Clock Reference Internal GPS

Phase Noise SSB 100Hz: < -72 dBc/Hz

1kHz: < -77 dBc/Hz

4kHz < -81 dBc/Hz

10kHz: < -84 dBc/Hz

100kHz: < -112 dBc/Hz

1MHz: < -123 dBc/Hz

Sirius Transmission Frame Buffering (terrestrial

signal time delay) Up to 17 frames (approx. 6 sec.)

3EM21522AAAA Genera

Issue 1, March 2008 DTR-0200-SA-SIRIUS

1-9

1.7

REPEATER COMPONENTS LOCATION

The repeater enclosure cabinet contains ﬁeld replaceable subassemblies called “Least

Replaceable Units (LRUs)” as listed in Table 1-8.

Figure 1 - 5

locates the repeater components including the LRUs.

The part number for the entire repeater enclosure cabinet with all electronics and

internal equipment is P/N 3EM04000AA.

Table 1-6 Repeater Test Ports

Repeater Out Forward Power Connector: N-type, female, 50 ohms, Coupling: -50 dB

Repeater Out Reflected Power Connector: N-type, female, 50 ohms, Coupling: -40 dB

HPA RF Monitor Connector: N-type, female, 50 ohms, Coupling: -50 dB

Upconverter RF Out Monitor Connector: SMA, female, 50 ohms, Coupling: -20 dB

Table 1-7 Repeater Test Modes

CW Signal COFDM spectrum replaced by a single carrier 4kHz aside from the

center frequency. The RMS level of the single carrier is equivalent to

average RMS level of normal COFDM spectrum. The signal is

intended for testing of in-band signal-to-noise ratio.

Notch Signal Movable group-of-carriers hole for test of intermodulation and quanti-

zation noise

PRBS Signal Empty DARS frames (PRBS sequence)

Table 1-8 Repeater Least Replaceable Units (LRUs)

Signal Processing Unit (SPU)

Refer to Appendix B

for part numbers

High Power Amplifier (HPA)

RF Output Coupler

RF Detector (Two; one forward, one reflected)

Cabinet Exhaust Fan (two exhaust fans under roof)

Cabinet Exhaust Fan Relay

Cabinet Intake Fan (two intake fans in rear door)

Cabinet Intake Fan Relay

PDU Circuit Breakers

Genera

3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

1-10

Figure 1 - 5 Components Location (Sheet 1 of 2)

Figure 1 - 5 Components Location (Sheet 2 of 2)

DTR-1074

07/30/07

Front View

PDU

SPU

HPA

DTR-1075

07/30/07

Rear View

RF Coupler

and Detectors

BP Filter Filter Assembly

(inside of door)

Junction

Box

HPA

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-1

2FUNCTIONAL DESCRIPTION

2.1

GENERAL

This section presents a functional description of the Sirius Terrestrial Repeater.

2.2

SYSTEM FUNCTIONAL OVERVIEW

Figure 2 - 1

shows the basic Repeater Simpliﬁed Functional Block Diagram.

The Sirius Terrestrial Repeater transmits at the 2.3265 GHz frequency with a 4.012

MHz signal bandwidth. Refer to the tables in Section 1 for the technical characteris-

tics and the major components.

2.2.1

SIGNAL FLOW

The Sirius Terrestrial Repeater receives the video/audio Complex Digital Data

Stream (CDDS) signal in a TDM format at the KuBand from the satellite by means

of a Very Small Aperture Terminal (VSAT) parabolic antenna.

The CDDS signal passes through a Low Noise Block (LNB) converter to the DVB-S

L-Band satellite receiver; an integral part of the Signal Processing Unit (SPU). The

satellite receiver demodulates the incoming stream and outputs the processed data

via the Asynchronous serial Interface (ASI) to the SIRIUS modulator stage.

The output of the modulator is an Orthogonal Frequency Division Multiplexed IF

(I and Q signals).

The IF is up-converted to an S-band frequency for insertion into the High Power

Ampliﬁer (HPA). The output of the HPA goes through the output bandpass ﬁlter

(BPF) where “out of band” generated signals are removed.

The output BPF signal (200W RF) goes through the output RF coupler to the tower

mounted antennas and is transmitted to the end user

2-2 This page intentionally left blank.

Figure 2 - 1 Repeater Simpliﬁed Functional Block Diagram

DTR-1008

03/04/08

DVB-S/S2

Receiver

Power Distribution

Unit

(with breakers)

Relay

Group

Ext

Heater

Aux 115V AC

Fans/Temperature Sensors/

Contactors

SPU Compartment

Heater

Modulator

IF I

IF Q

RF Test

SMA-F

RF Fwd Test

N (F)

RF Refl Test

N (F)

RF Out (200W)

To Antenna

IF Test I & Q

BNC 50 Ohm

VSAT

ASI

Local CLI (serial)

DB8

POTS

Up-Converter Control

HPA Control

Output Power Level Control

208V AC

Main Controller

Board

Main

Controller Supervisor

Processor

Modulator Control

Internal UPS

GPS

Receiver

Ethernet

Switch

Dial-up

Modem

Control

Core Up-

Converter BPF

Output

Coupier

Fwd RF

Fwd

HPA

DSP

Core

208V AC

HPA

Compartment

Utility

Compartment

SPU

Repeater Cabinet

GPS

F Type

N(F)

Local Ethernet

RJ-45

Local CLI (serial)

DB-9

RJ-11

Power

Supply

7-16 DIN (F)

2-4

This page intentionally left blank.

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-5

2.3

MAIN FUNCTIONS

The Sirius Terrestrial Repeater consists of the following main functions:

•

Receiver

– Receives the down converted input signal from the VSAT Antenna/

LBN via coax cable. Processes the received signal for transmission to the modula-

tor.

•

Transmitter

– (modulator, up converter, HPA, bandpass ﬁlter, and output

coupler) Transmits the received and processed RF signal, via tower mounted

antenna, to the end user’s equipment.

•

Timing

– A GPS receiver provides signals for synchronization within the Signal

Processing Unit (SPU).

•

Monitor and Control

– This function is primarily performed by the main con-

troller board which receives information from all external devices, including

temperature, power to antenna, output signal control parameters, and equipment

condition.

•

Power Distribution

– Power is controlled and distributed by a power distribu-

tion unit (PDU) and a relay control group.

Functional description of the components involved in these main functions follows.

2.3.1

SIGNAL PROCESSING UNIT (SPU) SUB-ASSEMBLY

Figure 2 - 2

and

Figure 2 - 3

respectively show a physical representation and functional

block diagram of the SPU.

The primary function of the SPU is to receive the complex digital data stream

(CDDS) from the VSAT satellite, modulate the received signal into a COFDM wave-

form, up-convert the waveform to the assigned S-Band frequency within the user’s

frequency plan, and forward this waveform to the HPA in the transmitter portion of

the repeater.

The SPU contains the L-Band satellite receiver, modulator, up-converter, main con-

troller, and Uninterruptible Power Supply (UPS).

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-6

Figure 2 - 2 Signal Processing Unit (SPU)

Figure 2 - 3 Sirius Signal Processing Unit (SPU) Functional Block Diagram

2-8

This page intentionally left blank.

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-9

2.3.1.1

L-Band (VSAT) Receiver

The VSAT L-Band receiver connector panel is shown in Figure 2-4.

The receiver module is located on the SPU sub-assembly.

The module receives the DVB-S/S2 signal data stream (which carries the SIRIUS

proprietary CDDS) from the L-band LNB module located on the Ku-band VSAT

antenna.

The receiver processes the down-converted L-band signal by DVB-S/S2 transport

stream removal and data recovery

The ﬁnal receiver output is a stream of CDDS encapsulated into pseudo MPEG TS

packets.

Figure 2 - 4 VSAT (L-Band) Receiver Panel

2.3.1.2

Modulator

The modulator panel is shown in

Figure 2 - 5

The modulator, located on the SPU sub-assembly, converts the digital coded stream

to an IF.

It receives Sirius CDDS stream input data from the L-band receiver in the form of

MPEG TS packets transferred by DVB-ASI.

The modulator also receives reference system clock signals in the form of 10MHz and

1PPs from the GPS distribution ampliﬁers. These clock signals enter the modulator

at J17A and J17B and synchronize the modulator clock and, in turn, the modulator

output.

COFDM converts the MPEG TS frames to an IF in the form of I and Q signals with a

center frequency of 76.25 MHz ready for up conversion.

The modulator contains a DB-9 serial port wired as a DTE device and requires a null

modem cable to communicate with the serial port on a PC.

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-10

Figure 2 - 5 Modulator Module

2.3.1.3

Up-Converter

Figure 2 - 6 shows the up-converter panel. The up-converter converts the modulator

IF (I and Q channels) output to S-Band.

An up converter controller applies DAC-controlled DC offset to each IF channel,

attenuates and ﬁlters the channels, and then sends them to the up-converter for

S-Band frequency con-version.

The 2.32625 GHz S-Band output of the up-converter feeds into the pre-driver of the

HPA.

Figure 2 - 6 Up-Converter Module Panel

2.3.1.4

SPU Main Controller Board

See Figure 2 - 7 and Figure 2 - 8 connector panel and functional block diagram.

The main controller supports the repeater site operation, conﬁguration, manage-

ment, and status reporting. It manages power-up, power-down and RF control pro-

cesses. The controller provides capability for remote upgrade of repeater software,

and provides local and remote interfacing for all command and status functions

(including digital, thermal, power, and RF performance of the repeater).

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-11

Control commands for status requests and operating parameter modiﬁcations from

the operator interfaces are received and processed by the main controller.

The controller reports problem conditions through dedicated interfaces and also indi-

cates current status and alarms via front panel LEDs.

Repeater identity can be conﬁgured remotely or locally via the controller. Conﬁgura-

tion includes repeater identity (repeater name, password, local IP address, two

remote NMS IP addresses, and SNMP security variables).

The functional software components of the controller are:

• Repeater protection via continuous local monitoring of all main blocks.

The output coupler, HPA, and HPA power supply are continually monitored. If any

monitored parameter exceeds its threshold, the RF is shut down and the Network

Management Center (NMC) is notiﬁed. Hazardous conditions shut down the

repeater. Under certain conditions clearing the event will automatically restart the

repeater.

• HPA RF output Automatic Power Level Control (APLC).

The APLC loop checks RF output level reported by the RF output coupler and

changes the up converter out-put level.

• Performance of two-way communication with the NMC.

Communication can be via either of the following:

Dial-up modem through a PSTN line

Ethernet to the Management Center via WAN

Forward channel using the input channel and satellite return channel.

• Load, initialize, and monitor the supervisor controller, the GPS receiver, the up

converter, the VSAT receiver, the modem, and the modulator.

• Perform software upgrade for the main controller, supervisor controller, and mod-

ulator.

• Monitor RF subsystems; HPA, HPA power supply, and RF coupler

• Event Logging is written to the EEPROM and accessible from WEB/embedded

FTP server via NMC.

• Self monitoring and environment monitoring (temperature, fans, voltage, cur-

rent)

Power-up Test

– on power-up the main controller performs a self-test (POST) and

waits for all other subsystems to perform POST of their major components and

report results. Any main block problem causes the repeater to shut down and an

attempt is made to notify the NMC. Notiﬁcation is attempted via the modem or

Ethernet to the NMC.

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-12

Back-up Test

– continuous self-monitoring of controller and all subsystems. Anoma-

lies are reported to NMC. Major faults cause the controller to shut down the repeater

Heartbeat

– a special trap/message is transmitted regularly (transmission inter-val

set by user via GUI, See Figure 5-34 in Section 5) to the NMC. This message indi-

cates to the NMC operator that the repeater is alive; a valid connection exists

between the repeater and the NMC, and the repeater main controller is operational.

• Local/remote software upgrade – software upgrade is initiated via a web browser

by directly uploading the upgrade ﬁle to the controller. When the ﬁle is success-

fully received, the web server task will invoke the upgrade procedure. Upgrade

applies to any of the controller software components or any of the other system

components.

• Parameter database clearing in EEPROM will return to default settings.

The functional physical components of the controller are:

• Main Controller microprocessor chip MPC860x

• Supervisor Processor microprocessor chip ATmega2560

• GPS receiver

• Dial-up modem

• Ethernet Switch

• Internal UPS

Figure 2 - 7 Controller Board Panel

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-13

Figure 2 - 8 Main Controller Board Functional Block Diagram

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-14

2.3.1.4.1

Main Controller Microprocessor Chip

The MPC860 microprocessor performs all site management to include control of the

GPS receiver, modem, and L-band DVB-S/S2 receiver. The controller also communi-

cates with the SPU modules and on-board components via dedicated interfaces using

soft-ware deﬁned protocols. The MPC860 chip connects to the Ethernet, to an exter-

nal monitoring/controlling console (PC), to the VSAT receiver, the internal modem, to

the upconverter, to the power ampliﬁer, and to the following front panel components:

the status LED, the Local/Remote switch, and the Reset switch. The MPC860 also

connects, via the module internal I2C bus, to the ATmega256 control processor

(supervisor controller).

• Ethernet connection-via an internal Ethernet controller connected to an internal

Ethernet switch and terminating at four RJ-45 connectors (J115A, J115B, J115C,

and J115D). External Console connection via a UART (UART0) internal to the

MPC860 chip and connected to module internal connector J129 (DB9-F).

• VSAT Receiver- connects to the MPC860 chip via the module internal I2C bus

and internal connector J129.

• Internal Modem connection-from UART2 in the MPC860 chip to the modem and

then to the RJ-11 connector at J119.

• The Upconverter-connected to the MPC860 chip via the module internal I2C bus.

• Power Ampliﬁer connection-to the MPC860 chip via RS485 bus. This is a full

duplex PA control line.

• Front panel components-the status LED, the Local/Remote switch, and the Reset

switch connect to the J129 internal connector on to the I_C bus and into the main

processor chip.

2.3.1.4.2

Supervisor or Control Processor

The ATmega256 chip monitors status, temperature, and RF power. The chip also con-

trols output digital relays required for interface with the external equipment.

• Relay Control – The ATmeg a256 connects to the Relay Control Group via back

panel DB25 connector P18 for fan control (four channels).

• Fan Speed & Door Monitoring – The processor connects to DB25 back panel con-

nector P17A to receive digital inputs (up to 12 lines). Four channels are for fan

speed monitoring, and two for front and back door monitoring. Six additional

switches can be connected as required.

• Temperature Sensing – There are three temperature sensing thermistors (ambi-

ent, HPA compartment and SPU) connected to terminal board 3 (TB3). The pro-

cessor provides +5 VDC to each thermistor and reads the temperature from -55˚C

to + 180˚C of each thermistor. The TB3 connections to the processor are via DB9-

F panel connector P7B.

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-15

•RF Power: Monitoring is two channel and RS485 full duplex. The path is from the

reﬂected power and forward power detectors through DB9-M panel connector

P6B into the processors UART1 and UART2. The Atmega256 processor initial-

izes the GPS Receiver, makes all necessary settings and then monitors important

stats (refer to GPS Receiver below).

2.3.1.4.3

GPS Receiver

The GPS receiver provides 10 MHz and 1 pps signals for synchronization purposes.

The signals’ exact alignment to a UTC/GPS second is monitored via a message

received by the controller as a response to the correspondent’s request. The receiver

supports proprietary binary messages and also NMEA formatted message protocol.

A subset of the protocols is used by the MPC860 microprocessor to control receiver

operation. After initialization, the GPS starts tracking the satellites to determine its

position; the accuracy of the GPS output signals depends on the GPS satellite recep-

tion. The Controller communicates continuously with the GPS to deter-mine if the

GPS is still operating correctly and still receiving the satellite signals, etc., or if it

has any alarm (malfunction) to report. The output of the GPS (1 pps and 10MHz

pulses) is to the Distribution Ampliﬁers, which in turn feed the pulses to the Modula-

tor and Up-converter via internal connector J130.

2.3.1.4.4

Dial-up Modem

Two chips, Si2457 and Si3018, make up an internal modem and provide the required

connectivity to POTS (PSTN). The phone line connection is via an RJ11connector

(J119 on the front panel). This telephone communication channel provides the main

control interface for repeater monitoring by the Sirius repeater NMS. Information

exchange between site and NMS is via SNMP.

2.3.1.4.5

Ethernet Switch

The Ethernet switch is a built-in 10/100 Base-T switch and provides four RJ-45

Ethernet ports allowing the controller to communicate with other Ethernet devices.

2.3.1.4.6

Uninterruptible Power Supply (UPS)

See

Figure 2 - 9

. The UPS monitors the AC line status and if the AC voltage drops, it

provides +5V and +3.3V for CPU backup. The UPS provides CPU back-up power for

up to 5 minutes, enough time to store the current state of the repeater, store param-

eters in volatile memory, notify NMS, and completely and safely shut down the

repeater. The unit comprises a bank of ﬁve Ultra Capacitors, 350F/2.5V each, a DC/

DC converter, over-voltage protection and charging/discharging circuitry. During

repeater power-up, the capacitors charge through a current limiting resistor with

the bulk of the power going to the SPU and no interruption of power during this

period. When power is interrupted, the capacitors discharge to the load through the

DC/DC converter at a steady ﬁve volts until they reach approximately seven volts at

which time the SPU power is terminated.

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-16

A manual ON/OFF control switch is located on the front panel of the UPS and

allows the unit to be manually switched on or off. This is used primarily by mainte-

nance technicians when servicing the repeater.

An internal automatic ON/OFF switch switches the unit off when the +5 or 3.3

input voltages drop. This prevents back current feed to the power supply. The UPS

has a 3-wire interface for connection of an optocoupled AC sensor.

Figure 2 - 9 Uninterruptible Power Supply (UPS)

2.3.1.4.7

SPU Power Supply

The power supply is 208VAC, 30-50 W brick power supply AC/DC converter and pro-

vides all required voltages for the SPU:

+5V @ 3A

+3.3V@1A

+12V@2A

-12V@0.5A

+24V@1A

The power supply input is 208VAC/50-60 Hz.

2.3.1.4.8

SPU Compartment Heater

The SPU compartment heater protects the SPU enclosure from freezing and/or con-

densation.

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-17

2.4

HIGH POWER AMPLIFIER (HPA)

See

Figure 2 - 10

and

Figure 2 - 11

for the HPA sub-assembly front and rear panels and

the HPA functional block diagram.

The HPA ampliﬁes the S-Band terrestrial signal to an output level of 200 watts

(after the output ﬁlter). The HPA is a solid-state device operating in Class A/B linear

mode over a frequency range of 2305 MHz to 2360 MHz and is fully protected against

input overdrive, temperature, and output load VSWR conditions. The protection cir-

cuitry is self-correcting and allows restoration of the HPA to normal operation upon

removal of the fault.

The HPA is a separate sub-assembly Least Replaceable Unit (LRU) installed on slid-

ing rails in the repeater enclosure. It contains an integrated AC/DC power supply, a

pre--driver, a driver, a 5-way splitter, ﬁve individual power ampliﬁer modules, a 5-

way combiner, and an HPA controller.

Figure 2 - 10 HPA Panels

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-18

Figure 2 - 11 HPA Functional Block Diagram

RF Output

Coupler

RF INPUT J3

RF OUTPUT J4

CONTROL

FWR PWR

MONITOR

50dB

5-WAY OUTPUT COMBINER

SIRIUS HPA BLOCK DIAGRAM

40dB

50dB

DTR-1013

03/10/07

Output Pwr

DC BIAS OUT

DC & CONTROL RS422

DC IN

HPA

CONTROLLER

Preamplifier

Power Supply

Temperature

Sensing

AC INPUT

Monitor

Output Pwr

Monitor &

Control

3-WAY SPLITTER

20dB

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-19

2.4.1

HPA CONTROLLER

The HPA Controller monitors various parameters and reports current values and

summary alarms to the repeater main controller via the RS485 interface. The vari-

ous monitored parameters and statuses are the power modules working conditions

(DC voltages and currents), the temperature inside the HPA assembly, the HPA for-

ward and reﬂected power levels, input power and gain, RF power inhibit, HPA power

supply enabled/disabled, input/output overdrive alarm, over-temp alarm (announced

prior to shut-down), over-temp fault, HPA shut-down alarm, output device failure

alarm, driver device failure alarm, HPA low gain alarm, power supply AC fault, and

power supply DC fault.

The HPA Controller also performs HPA pre-driver control, provides the HPA power-

up and shut-down procedure, and interfaces the HPA to the host (SPU Main Control-

ler). If the HPA controller detects a problem with a speciﬁc PA module, it shuts down

the entire HPA. The SPU main controller can restart the HPA utilizing the remain-

ing operational PAs. If the number of faulty PAs exceeds a predetermined threshold,

the HPA can not be restarted by the host.

Since the HPA is a constant gain block, it is individually calibrated to maintain RF

performance under varying operating conditions. Calibration is performed on the

forward, reﬂected, and input power sensors. A calibration table dependent on tem-

perature and frequency is stored in the internal EEPROM of the HPA controller.

The HPA controller reports alarms to the main controller and maintains a log of

alarms. Alarm entries contain the alarm ID and monitored parameters prior to

alarm activation. The alarm log is stored in an internal EEPROM. The HPA control-

ler can enable/disable the output RF and also turn the integrated power supply DC

power ON and OFF.

2.4.2

HPA POWER SUPPLY

The HPA Power Supply is a high performance power source that delivers appropri-

ate voltages and current necessary to operate the HPA at its required performance

level. The power supply resides in a separate compartment inside the HPA module

and employs four independent AC-to-DC converters operating in parallel. The con-

verters’ outputs are combined on a single bus and connect to the input terminal of

the Power Distribution/Controller board located in the power supply compartment.

The Power Supply contains supervisory circuitry to report the status of the AC input

voltage and DC/DC converters operation status to the Power Distribution/Controller

module. This Controller module also monitors the Power Supply DC output voltage

and the current draw of each of the HPA sub-modules, and reports these parameters

back to the Main System Controller via the serial port. In addition, the Power Sup-

ply has the ability to enable/disable the power to the HPA when so commanded by

the Main System Controller.

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-20

2.4.3

HPA PREAMPLIFIER (PREDRIVER)

The pre-driver is the ﬁrst amplifying stage of the HPA. It employs three stages of

ampliﬁcation-a Monolithic Microwave Integrated Circuit (MMIC) ampliﬁer and two

LDMOS transistors. The pre-driver raises the output power of the RF from the up-

converter by 38 dB and feeds the ampliﬁed RF into the HPA driver ampliﬁer. The RF

signal from the pre-driver input is also coupled to the RF detector circuit which pro-

vides detected RF to the HPA controller for monitoring and gain control. The coupled

RF signal is routed through a PIN diode attenuator to maintain the HPA gain con-

trol loop. The pre-driver ampliﬁer, via a Gallium Arsenide (GaAs) MMIC RF switch,

can turn the RF signal on or off by way of a logic level HIGH RF Shutdown TTL con-

trol signal.

2.4.4

HPA DRIVER AMPLIFIER

The driver ampliﬁer, employing two parallel ampliﬁers, receives the RF output from

the pre-driver and ampliﬁes it by 13.3 dB. The output of the driver ampliﬁer is fed

into a ﬁve-way splitter at a power level of 43 dBm.

2.4.5

HPA POWER SPLITTER

The ﬁve-way power splitter is connects directly to the HPA driver ampliﬁer RF out-

put. The splitter evenly distributes this RF power to the ﬁve individual output power

ampliﬁer modules.

2.4.6

POWER AMPLIFIER MODULES

The ﬁve power ampliﬁer modules are identical to the driver ampliﬁer module. These

modules are paralleled and receive equal inputs from the ﬁve-way power splitter.

The ampliﬁers each contribute a gain of 13.3 dB to their respective input, the ﬁve-

way combiner/coupler.

2.4.7

COMBINER/COUPLER

The ﬁve RF power ampliﬁer outputs are combined into one via a zero-degree star

combiner. Two stripline couplers provide output signal sampling. One coupler’s out-

puts are terminated with SMA connectors and are used to provide external forward

and reﬂected RF monitoring ports. The other coupler’s outputs are detected using

true-type RF detectors installed on a coupler printed circuit board. These detected

signals are fed to the HPA Controller for control and monitoring purposes. The

detected signals and DC power for the on-board detectors are routed through 6-pin

Molex connectors installed on a coupler board. The 5-way combiner/coupler requires

external +5VDC ± 0.5 volts. When the combiner/coupler is installed on the HPA chas-

sis, the inputs are connected directly to the power modules’ output pins. The output

of the combiner is connected to the central conductor of the HPA output connector.

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-21

2.5

S-BAND OUTPUT FILTER

The output ﬁlter is a bandpass ﬁlter and provides attenuation of the out-of-band

emissions generated by the HPA. The attenuation is to comply with the require-

ments of TN-SPEC-2.1.0, Terrestrial Network Technical Speciﬁcation, Transmitter

RF Emissions.

2.6

OUTPUT COUPLER

The output coupler, connected to the output port of the transmit ﬁlter, is the ﬁnal

component in the transmitter chain. The coupler samples the composite RF power

level at the repeater RF output. The RF levels at the FWD and REF ports are mea-

sured with the RF detectors and reported to the repeater main controller via the

RS485 interface. The output coupler provides test ports for connection to external

test equipment.

2.7

POWER DISTRIBUTION

See

Figure 2 - 12

and

Figure 2 - 13

for a simpliﬁed block diagram and an isometric view

of the Power Distribution Unit (PDU). The PDU is mounted on the bottom of the

repeater cabinet (see

Figure 1 - 5

), receives the input commercial 208VAC power, and

distributes required power to the repeater modules.

The PDU is comprised of seven circuit breakers, two surge protectors, two RFI power

line ﬁlters, two latching relays, forty two-stage feed through terminal blocks, and one

double grounding terminal. The front panel of the PDU houses the seven circuit

breakers and one power outlet.

The circuit breakers are as follows:

MAIN POWER – one 32A, 250VAC, 3-pole circuit breaker controls the incoming

208VAC to the repeater from the commercial source. Throwing this breaker will

remove all power from the repeater.

FANS – one 5A, 250VAC, 2-pole breaker powers the axial fans.

HPA – one 25A, 250VAC, 2-pole breaker supplies the HPA power supply. SPU – one

5A, 250VAC, 2-pole breaker supplies the SPU power supply

EXT HEATER – one 5A, 250VAC, 2-pole breaker powers the external heater

INT HEATER – one 5A, 250VAC, 2-pole breaker powers the internal heater

AUX POWER – one 10A, 250VAC, 2-pole breaker supplies 120VAC, 5A, to the AUX

OUTLET

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-22

Figure 2 - 12 Simpliﬁed Block Diagram of Main Power Paths

HPA POWER SUPPLY

AUX PWR

AUX OUTLET

EXT HTR

INT HTR

FANS

HPA

VSAT RX

UPS

SPU

MAIN PWR

MODULATOR

MAIN CONTROLLER

UP-CONVERTER

DTR-1009

03/06/07

3EM21522AAAA Functiona

Description

Issue 1, March 2008 DTR-0200-SA-SIRIUS

2-23

Figure 2 - 13 Power Distribution Unit (Sheet 1 of 2)

Functiona

Description 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

2-24

Figure 2 - 13 Power Distribution Unit (Sheet 2 of 2)

2.8

JUNCTION BOX ASSEMBLY

The junction box is mounted on the ﬂoor of the cabinet just behind the rear door.

It is the interface for the external connections for the AC power line, the VSAT

antenna, the GPS antenna, and the telephone line. It also houses the input power

(208VAC) terminal block, lightning protectors for the VSAT receiver and GPS

receiver, and the cable glands for Ethernet and telephone cables.

Figure 2 - 14 Junction Box Assembly

3EM21522AAAA Insta

ation

Issue 1, March 2008 DTR-0200-SA-SIRIUS

3-1

3INSTALLATION

3.1

INTRODUCTION

This section describes the installation of Alcatel-Lucent’s Sirius Digital Terrestrial

Repeater, DTR-0200-SA-SIRIUS, Alcatel-Lucent part number 3EM04000AA and

associated antennas at a designated site. This equipment is to be installed in a

restricted access location.

3.2

SAFETY ON SITE

3.2.1

Installation Safety

Installation shall be performed by trained, qualiﬁed personnel. For installation and

wiring of the SIRIUS Terrestrial Repeater and associated antennas in the USA, the

installer will adhere to the applicable clauses of the National Electric Code and all

applicable local codes. For installation in Canada, the installer will adhere to the

applicable National Canadian Electric Code and all applicable local codes.

3.2.2

Grounding

Grounding will be in accordance with MOTOROLA STANDARDS AND GUIDE-

LINES FOR COMMUNICATION SITES, 68P81089E50-B, 9/1/05 — UP, local codes

and requirements, SIRIUS requirements, and Alcatel-Lucent construction/installa-

tion drawings in the order stated. Ensure that the grounding wire of the wiring con-

duit is properly attached to the customer-supplied service panel ground bar.

3.2.3

Electrical Safety

A readily accessible disconnect device shall be incorporated in the build-

ing installation wiring.

A capital letter “N” located adjacent to an electrical terminal indicates

that terminal is intended exclusively for connection of the primary power

neutral conductor.

Personnel will obey all safety/hazard/warning signs and labels.

All repeater equipment electrical power must be off during installation.

Ensure that the main power switch to the repeater equipment is turned

off and a “DANGER-DO NOT TURN ON - Personnel Working” sign is hung

on the switch prior to working on internal parts of the repeater.

Ensure that all repeater circuit breakers are turned off prior to working

on internal parts or connecting cables of the repeater.

Ensure that the main power cable to the repeater PDU is the last cable

to be connected to the repeater when installing repeater cables.

Insta

ation 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

3-2

3.2.4

Physical Safety

The repeater will be secured to the building/pad before operation.

Installation crew members must wear hard hats during installation.

A minimum of two technicians is required for any lifting and/or position-

ing of the repeater cabinet.

3.3

INSTALLATION OVERVIEW

Site conﬁguration, antenna conﬁgurations and locations, electrical service location,

phone line service location, and SIRIUS Repeater location, will all be in accordance

with Alcatel-Lucent provided construction/installation drawings that have been

approved for building permits and zoning and have been A&E stamped.

3.4

SITE POWER

Figure 3 - 1 depicts the recommended site ac power wiring:

Figure 3 - 1 AC Wiring (Sheet 1 of 2)

Notes:

1. Refer to Sheet 2 for ac power wiring schematic.

2. Conduit or BX cable will be routed to a single gang junction box installed on the

repeater pedestal or in close proximity to the repeater enclosure.

3. 4-conductor #8 power cable will be installed between the junction box and the

repeater power terminal block. Refer to Sheet 2, note 3. DTR-1076

03/16/08

Figure 3 - 1 AC Wiring (Sheet 2 of 2)

DTR-1079

03/16/08

Notes:

1. The repeater must be powered directly from a 240v ac service panel with 40 amp UL listed circuit breakers.

2. The green ground wire is to be connected to a safety ground derived from a copper ground plane or rod.

3. A 4-conductor #8 power cable with rubber jacket rated at 90 C will be used.

4. The ac power wiring design and installation must conform to all local and national electrical codes.

4 This page intentionally left blank.

3EM21522AAAA Insta

ation

Issue 1, March 2008 DTR-0200-SA-SIRIUS

3-5

3.5

REPEATER UNPACKING AND INSPECTION

The repeater equipment containers and the Fibergrate platform containers (or what-

ever platform is being utilized) should be unpacked and inspected at the earliest date

to ensure that all required material has been received and is in good condition.

Equipment should be checked against packing lists and site drawings.

3.5.1

Freight Damage

Any damage to material while in transit should be immediately directed to the

freight carrier. The carrier will issue instructions regarding freight damage claims.

3.5.2

Material Missing or Damaged

Questions pertaining to missing or damaged materials not due to the carrier should

be directed to Alcatel-Lucent at Longview, Texas, telephone number 1-903-236-5200.

Ask for Product Engineering.

3.6

SUGGESTED TOOL LIST

3.6.1

Installation Tools

No special tools are required to install DTR-0200-SA-SIRIUS (3EM04000AA)

Repeater equipment.

3.7

ANTENNA INSTALLATION

All antenna Installation, alignment, adjustment, and connecting procedures will be in

accordance with the antenna manufacturer’s instruction manual, A&E stamped Alca-

tel-Lucent construction/installation drawings, and tower owner speciﬁc requirements.

3.8

REPEATER CABINET INSTALLATION

3.8.1

Support Base

The support base to be used will depend on the individual site and the required

mounting position. Speciﬁc information is contained in the A&E Construction Draw-

ings for the particular site.

3.9

CABLE CONNECTIONS

(See

Figure 3 - 2

)

3.9.1

Module Connecting Cables and Module Connection Points

Refer to

Appendix B

for cable to-from descriptions and cable part numbers.

Insta

ation 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

3-6

3.9.2

External Cables and Connections

Prior to making any external connections, ensure that main

power to the repeater is turned off at the source and a

“

Warning, Do Not Turn On, Personnel Working

” sign is hang-

ing on the main source power switch.

3.9.2.1

External Connection Current Ratings

3.9.2.2

Chassis Ground Connection

The PDU chassis ground connecting wire will connect to the grounding terminal on

the repeater junction block.

3.9.2.3

Satellite Dish Receiving Antenna (VSAT) to Repeater

The feed cable from the VSAT antenna will connect to the Repeater Junction Box

VSAT IN connector. The actual cable type, length, connectors, etc., will be speciﬁed

on the construction drawings.

3.9.2.4

GPS Receiving Antenna to Repeater

The feed cable from the GPS antenna will connect to the Repeater Junction Box GPS

IN connector. The actual cable type, length, connectors, etc., will be speciﬁed on the

construction drawings.

3.9.2.5

Repeater to Tower Mounted Transmit Antenna

The feed cable to the transmit antenna will connect to the repeater RF output con-

nector on the underside of the repeater cabinet. The actual cable type, length, con-

nectors, etc., will be speciﬁed on the construction drawings.

EXTERNAL CONNECTION MAX CURRENT

External Heater Connection Max. Current 1.7A @ 120 VAC

Auxiliary Power Outlet Max. Current 5A @ 120 VAC

3EM21522AAAA Insta

ation

Issue 1, March 2008 DTR-0200-SA-SIRIUS

3-7

3.9.2.6

Telephone Line (TELCO) Connections

To reduce the risk of ﬁre, use only No. 26 AWG or larger (e.g.,

24 AWG) UL Listed or CSA Certiﬁed Telecommunication Line

Cord.

TELCO will determine the type and length of cable to be used. Connection will be to

the TELCO connector located on the rear panel of the SPU.

3.9.2.7

Electrical Service Connection

Refer to

Paragraph 3.4, SITE POWER

3-8 This page intentionally left blank.

Figure 3 - 2 Repeater Interconnection Diagram

10 This page intentionally left blank.

3EM21522AAAA Insta

ation

Issue 1, March 2008 DTR-0200-SA-SIRIUS

3-11

3.10

POST-INSTALLATION INSPECTION/TEST

Post installation inspecting/testing is described below as phase one, two, and three

inspecting and/or testing. Phase one and two inspecting/testing is to satisfy the site

owner that the system conforms to the owner’s requirements. Phase three testing is

the Alcatel-Lucent SIRIUS ﬁeld test performed after installation or major equipment

maintenance to ensure that the repeater is performing according to SIRIUS require-

ments. An inspection/test form template is provided at the end of this section. A ﬁeld

test report form template is provided at the end of the Turn-up and Testing section of

this manual.

3.10.1

Inspection/Test Phases

Post installation inspection/testing will normally consist of three phases involving

the site owner’s representative, Alcatel-Lucent’s representative, and SIRIUS

Radio’s representative. A written record of each phase will be made identifying the

speciﬁc inspections and/or test(s) accomplished and the satisfactory or unsatisfac-

tory result(s) of each. A copy of the results will be furnished to each participating

representative.

3.10.1.1

Phase One Inspection/Testing

Phase one inspection/testing will be performed at the discretion of the site owner’s

representative. The purpose is to ensure that Alcatel-Lucent installed equipment

meets all requirements established by the site owner. The site owner’s representa-

tive

(s) in conjunction with the Alcatel-Lucent representative and the SIRIUS Radio

representative will be involved in the inspection/testing process. Deﬁciencies will be

identiﬁed, recorded, and presented to the Alcatel-Lucent representative for correction.

3.10.1.2

Phase Two Inspection/Testing

Phase two will only be required if there were discrepancies found during the phase

one inspection/testing. After correction of the discrepancies, the site owner’s repre-

sentative, Alcatel-Lucent’s representative, and SIRIUS Radio’s representative will

once again be involved in an inspection/test to ensure satisfactory correction. Results

of the phase two inspection/testing will be recorded and signed by all representatives

and a copy distributed to each.

3.10.1.3

Phase Three Testing

Phase three testing consists of The Alcatel-Lucent representative in conjunction with

a SIRIUS Radio representative performing repeater system ﬁeld testing to ensure

satisfactory system operation. Final test results will be recorded and signed by each

representative who in turn will receive a signed copy.

3.10.2

Repeater System Field Testing

Refer to

Section 4, Turn-Up and Testing

in this manual for the system ﬁeld test proce-

dure and

Paragraph 3.11, Post Installation Inspection/Test Form

template.

3-12 This page intentionally left blank.

3EM21522AAAA Insta

ation

Issue 1, March 2008 DTR-0200-SA-SIRIUS

3-13

3.11

POST INSTALLATION INSPECTION/TEST FORM

3-14 This page intentionally left blank.

3EM21522AAAA Turn-Up an

Testing

Issue 1, March 2008 DTR-0200-SA-SIRIUS

4-1

4TURN-UP AND TESTING

4.1

GENERAL

This section describes the procedures required to turn-up and test the DTR-0200-SA-

SIRIUS repeater (ALU Part Number 3EM04000AA) after replacement of the Signal

Processor Unit (SPU), software upgrading, and/or other maintenance. These proce-

dures consist of repeater provisioning and ﬁeld testing.

These procedures require GUI software screen access. For screen access pro-

cedures, refer to the Operations section of this manual.

4.2

TEST EQUIPMENT REQUIRED

Refer to Table 4-1 for required test equipment. Become familiar with the operation of

any test equipment before using it. Operating instructions for test equipment are not

included in this manual except for precautionary notes or special instrument settings

required for performance of a test procedure. When further information regarding test

equipment is required, refer to the equipment manufacturer’s instructional data.

Table 4-1 Test Equipment Required

Type

Power Meter

Power Meter Test Sensor

PC/Laptop

Turn-Up an

Testing 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

4-2

4.3

REPEATER PROVISIONING

Provisioning is the process of checking, changing, and/or installing parameter values

to allow the repeater to operate from its assigned location. Normally, no parameter

changes will be required except after replacement of the SPU.

Turn on repeater power

Connect computer to repeater controller Ethernet port

Access repeater GUI

Set repeater to Standby mode

Provision Repeater (check, change, install parameters as indicated by GUI

screen readings and consistent with local network engineering require-

ments)

Return repeater to Broadcast mode

Connect repeater to NMC.

4.4

FIELD TESTS

The purpose of the ﬁeld test is to verify that the repeater meets speciﬁcations after

on-site repair. The ﬁeld test will be performed with the Ku-Band Receive Chain of the

speciﬁc site.

A ﬁeld test report form is provided to record the operating conditions and critical per-

formance parameters of the repeater after repair. This report should be kept on ﬁle

and referred to whenever the repeater is retested (after maintenance, etc.).

4.4.1

Test Set-Up

Remove power from repeater by opening repeater main power circuit

breaker on the PDU (see Figure 4 - 1).

Figure 4 - 1 PDU Circuit Breaker Panel

3EM21522AAAA Turn-Up an

Testing

Issue 1, March 2008 DTR-0200-SA-SIRIUS

4-3

Set up the test system as shown in Figure 4 - 2.

Figure 4 - 2 Field Test Setup For Terrestrial Repeater

• Connect the power meter to the FWD RF MONITOR connector on the

junction box panel.

• Enter into the power meter the dB offset value listed at the FWD RF

MONITOR connector. See Figure 4 - 3.

Figure 4 - 3 RF Monitor Connectors on Junction Box Panel

Sirius Repeater

LNB

Ethernet

Test PC

Fw MON

RF OutVSAT In

DTR-1070

03/16/08

DVB/S Signal

Ku Band

Antenna

208V AC

Power

Meter

Antenna

The input power value can be anywhere from 188 to 250

VAC depending on the available site power.

Turn-Up an

Testing 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

4-4

• The Ethernet connection for the PC is on the back panel of the Main

Controller (one of the Ethernet ports in the four port block). See

Figure 4 - 4.

Figure 4 - 4 Ethernet Ports on Main Controller Back Panel

• The input power value can be anywhere from 188 to 250 VAC depend-

ing on the available site power.

4.4.2

Operating Mode

Power up the repeater.

Wait 5 minutes (after the Main Controller ﬁnishes initialization).

Start GUI.

Access the Repeater Operating Mode screen and set repeater to Standby

Mode (see Figure 4 - 5).

Figure 4 - 5 Repeater Operating Mode

3EM21522AAAA Turn-Up an

Testing

Issue 1, March 2008 DTR-0200-SA-SIRIUS

4-5

4.4.3

Alarm Checking

Access to Alarm Log and read system faults/alarms from controller (see

Figure 4 - 6).

No fault/alarm shall be reported other than Cabinet Rear Door Open. This

alarm will appear because of the PC connection to the rear panel of the

Main Controller.

Figure 4 - 6 GUI Alarm Log

Turn-Up an

Testing 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

4-6

4.4.4

Software/Firmware Conﬁguration Test

Access the Global Status screen.

Check and record software/ﬁrmware versions used in the repeater.

Figure 4 - 7 Global Status Screen

The version numbers shall match those deﬁned by the repeater

conﬁguration.

3EM21522AAAA Turn-Up an

Testing

Issue 1, March 2008 DTR-0200-SA-SIRIUS

4-7

4.4.5

VSAT Receiver Test

View the Global Status screen.

Conﬁrm that the receive antenna is correctly pointed at the satellite (deter-

mined by VSAT Receiver Signal Strength reading on GUI screen).

Ensure that the receive antennas are correctly pointed at the satellite

(determined by signal strength reading on GUI screen).

If necessary, reconﬁgure the repeater VSAT receiver to match the satellite

signal.

Default settings are in place for the repeater for DVBS Standard (DVBS1),

Polarization (Horizontal), Band (Low) and Symbol Rate (8417361). In the

factory VSAT Frequency is set to 1222.000 MHz. All of the settings are based

on the SIRIUS satellite broadcast signal and are made in the factory. The

only settings that could need to be changed in the ﬁeld based on a change in

the SIRIUS satellite broadcast signal would be Frequency and Symbol Rate.

Verify that the TDM lock is present, and that the VSAT SNR is better than

10 dB.

4.4.6

GPS Receiver Test

Verify from the GUI Global Status screen that 1 PPS and 10 MHz signals are present.

4.4.7

Output Power Test

Access the Repeater Operating Mode screen (see Figure 4 - 5).

Set the Repeater Operating Mode to Broadcast.

Access the Modulator Mode screen (Figure 4 - 8).

Set the Modulator Operating Mode to CW.

Turn-Up an

Testing 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

4-8

Figure 4 - 8 Modulator Mode Screen

Set RF output power to +53.0 dBm, and measure the RF output power at

the junction box forward coupled jack, CPL FWR, with power meter. The

measured RF power level shall be within ±0.5 dB from the set RF power

level indicated on the GUI Global Status screen.

Remove the power meter from the FWD RF MONITOR connector.

No alarm shall be reported other than door(s) open.

4.5

CONNECT REPEATER SYSTEM TO NMC

Coordinate with NMC and place repeater in remote operating condition.

3EM21522AAAA Turn-Up an

Testing

Issue 1, March 2008 DTR-0200-SA-SIRIUS

4-9

4.6

FIELD TEST REPORT

DTR-1073

05/16/08

SITE:

Test Requirement Result

DATE OF TEST:

TEST TECHNICIAN

Printed Name:

COMPANY:

Printed Name:

Alarm Check

Firmware Configuration

VSAT Receiver

GPS Receiver

Output Power

No fault/alarm

Match versions in SPU, Controller,

and HPA

S/N ratio>10dB

1 ppm and 10MHz present

Within ±0.5 dB of set power level

COMPANY:

FIELD TEST REPORT

4-10 This page intentionally left blank.

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-1

5OPERATION

5.1

GENERAL

This section addresses control, communication, and parameter modiﬁcations of the

DTR-0200-SA-SIRIUS terrestrial repeater. It also provides descriptions of controls,

indicators, test points, and connectors for the repeater.

Refer to Paragraph 5.7 for repeater operating procedures.

Refer to Paragraph 5.8 for controls and indicators.

5.2

CONTROL AND COMMUNICATION

The DTR-0200-SA-SIRIUS terrestrial repeater can operate in either of two condi-

tions; remote control condition or local control condition

5.2.1

Remote Control Condition

In the remote control condition the Network Management Center (NMC) operator can

control and monitor the repeater from his/her position via telephone line dial-up, and

by use of WEB and SNMP interfaces to perform network management.

5.2.2

Local Control Condition

In the local control condition the technician can control and monitor the repeater from

the terrestrial site location. The technician uses a laptop PC for local control and

maintenance procedures. The PC communicates with the repeater via Ethernet and

Graphical User Interface (using Internet Explorer) or Command Line Interface (CLI)

protocol using the RS-232 Comm Port.

5.2.3

Control and Communication Interfaces

There are three interface ports provided for control and communication. They are:

• RS-232 Serial Port (DB9) –used for local control, status information, initial setup,

and troubleshooting. Access is local via laptop PC and the supported protocol is

Command Line Interface (CLI).

• V90 Modem Port (RJ11) – used for remote control and status information. Access

is from the NMC via dial-up modem and telephone and the supported protocols

are SNMP

, WEB Interface, and Telnet.

• Ethernet Port (RJ45) – used for local control and LAN access. Access is local and

the supported protocols are SNMP, WEB Interface, and Telnet.

5.2.4

Remote/Local Control Switching

The normal condition for repeater operation is the remote control condition. For a tech-

nician to perform testing and maintenance from the local terrestrial site, the repeater

must be switched to the local control condition. Switching is activated by the use of an

SPU front panel push-button switch. LEDs on either side of the switch identify the

repeater control condition as being in local or remote. Placing the repeater in the local

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-2

mode prevents a remote operator from accidentally turning on the HPA from the

remote site and applying high RF level from the repeater. This could seriously injure

the technician working on the repeater at the local site and/or damage the repeater.

5.3

MODES OF OPERATION

There are two main parameter groups which determine the operating mode. They are

the Repeater Operating Mode parameter group and the Modulator Operating Mode

parameter group.

5.3.1

Repeater Operating Modes

The three repeater operating modes are Broadcast, Standby, and Manual. The

repeater’s normal operating mode is Broadcast. Under normal, no-fault, conditions if

the repeater has an AC power shut-down, upon return of power its AC power-up algo-

rithm will restore operation to the same mode of operation prior to the loss of power.

5.3.1.1

Broadcast Mode

This mode allows the repeater to transmit real signals or test signals, run all the pro-

tection loops and ALC. This is the normal operating mode for the repeater. It receives

its input signal from the satellite, or generates a test signal, and transmits an orthog-

onal frequency division multiplexing (OFDM) signal for terrestrial broadcast. In this

mode, the Main Controller automatically maintains all repeater functions. To operate

in the Broadcast mode, the following conditions must be met:

• The repeater must be receiving an input signal and be locked to the input

stream (if the modulator is in the test mode, the VSAT satellite signal

presence is ignored).

• The ALC loop must be running.

• There must be good GPS signal quality (if the modulator is in the test

mode, the GPS signal presence is ignored).

• There must be no modulator alarms.

• There must be no VSAT alarms (if the modulator is in the test mode, the

VSAT satellite signal presence is ignored).

• There must be no GPS alarms (if the modulator is in the test mode, the

GPS signal presence is ignored).

• There must be no Up-converter alarms.

• There must be no Reﬂected Power alarms.

5.3.1.2

Standby Mode

In this mode the repeater is off the air and afﬁrms that the HPA is off while all other

components are operating normally. The up-converter output is muted, ALC is off, and

the HPA is switched off by disabling the HPA power supply.

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-3

The operating conditions in the Standby mode are:

• AC power is applied to the SPU, HPA, and fans.

• The HPA power supply is disabled.

• The HPA RF switch is OFF.

• The Up-converter output is muted.

• The cabinet fans are turned on.

5.3.1.3

Manual Mode

This mode allows manual control of the repeater for the technician to perform mainte-

nance and/or testing or troubleshooting. In the Manual Mode most commands can

only be accessed through the “administrator” login. The operator must log in as a sys-

tem administrator using the default password “ipradmin”. The operator now has

authority to alter parameters.

The manual mode must be used with caution. If parameters

are changed indiscriminately, unintentional damage to the

repeater and loss of factory settings could occur.

When the repeater is switched to the Manual Mode, it maintains all its system set-

tings which were in effect prior to the switchover. The RF output DAC last value will

remain until changed by the operator. The range of DAC values is limited to those

within the minimum and maximum permitted values required to maintain the up-

converter output power.

5.3.2

Modulator Operating Modes

• The modulator has seven operating modes:

• Standby Mode

• Run Mode

• CW Mode

• Two Tones Mode

• Notch Mode

• Comb Mode

• PRBS Mode

Of these seven operating modes, the technician will only use Standby Mode and Run

Mode. All other modes are for factory use only.

WARNING

Possibility of

Damage

to Equipment

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-4

5.4

GRAPHICAL USER INTERFACE (GUI)

The GUI WEB interface uses a PC for maintenance and support of the repeater,

and for fault and status reporting. The interface uses a simple hierarchical menu

structure which is user friendly and provides access to parameters. The parameters

are classiﬁed in ﬁve categories; Status, Conﬁguration, Alarms, NMS User, and System

Parameter. Figure 5 - 1 shows the GUI Main Menu which, in addition to providing cur-

rent repeater operating information, provides access to set up or change parameters as

required. The parameter categories and their pull down submenus are accessed from

the

GUI Main Menu. These submenu screens are self-explanatory and subdivide the

repeater’s status and parameters according to their functionalities. See

Figure 5 - 2

Figure 5 - 1 GUI Main Menu

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-5

Figure 5 - 2 GUI Pull-Down Menus

5.5

GUI MENU DESCRIPTIONS

5.5.1

Status Sub-Menu Breakdown

Status shows the repeater current operating status.

To access the Status sub-menu; GUI Main Menu => Status

The Status sub-menus are divided as follows:

Global Status

GPS Status

Up Converter

Cabinet

Status

Global Status

GPS Status

Up-Converter

Cabinet

Modulator

VSAT

Repeater Output Level

Coupler

GPS

Temperature

Repeater Operating Mode

PPP Dial In Parameters

PPP Dial Out Parameters

PPP Misc Parameters

Site

Alarms

Identification

Access Control

Network Parameters

SNMP Parameters

Heartbeat Time

System Reset

Upgrade

User Properties

Alarm Properties

Clear Logs

Alarm Status

Config NMS Users System Parameters

DTR-1016

06/11/07

GUI CONTROLLER MAIN MENU

Repeater ID

Modulator Mode

Overlay

Delays

Modulator IP

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-6

Their individual GUI screens follow.

Figure 5 - 3 Global Status Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-7

Figure 5 - 4 GPS Status Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-8

Figure 5 - 5 Up-Converter Status Screen

Figure 5 - 6 Cabinet Status Screen

5.5.2

Conﬁguration (Conﬁg) Sub-Menu Breakdown

Conﬁguration screens allow modiﬁcation of the parameters according to operator

requirements. To access the Conﬁguration sub-menu; GUI Main Menu =>Conﬁg

The Conﬁguration sub-menus are divided as follows:

Modulator

VSAT

Repeater Output Level

Coupler

GPS

Temperature

Repeater Operating Mode

PPP Dial In Parameters

PPP Dial Out Parameters

PPP Misc Parameters

Site

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-9

Figure 5 - 7 GUI Main Menu Conﬁg Drop-Down Menu

Conﬁg Modulator breaks down into a further sub-menu as follows:

Repeater ID

Modulator Mode

Overlay

Delays

Modulator IP

To access the Modulator sub-menu; GUI Main Menu=>Conﬁg=>Modulator=> (sub-

menu selection). See Figure 5 - 8.

Figure 5 - 8 Conﬁg Modulator Sub-Menu

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-10

Figure 5 - 9 through Figure 5 - 13 show the individual screens accessed via the Conﬁg

Modulator sub- menu.

Figure 5 - 9 Repeater ID Screen

The Modulator Mode screen, Figure 5 - 10, allows changeover from Repeater Operat-

ing Mode to Modulator Operating Mode (refer to para Paragraph 5.3.2). Mode selec-

tion is from the Modulator Mode drop-down screen and allows access to the following

modes (only Standby and Run are used in the ﬁeld, the remaining ﬁve are for factory

use only):

Standby

Run

Two Tones

Notch

Comb

PRBS Spectrum

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-11

Figure 5 - 10 Modulator Mode Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-12

Figure 5 - 11 Overlay Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-13

Figure 5 - 12 Delays Screen

Figure 5 - 13 Modulator IP Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-14

The remainder of the Conﬁg menu displays the following screens:

VSAT

Repeater Output Level

Coupler

GPS

Temperature

Repeater Operating Mode

PPP Dial In Parameters

PPP Dial Out Parameters

PPP Misc Parameters

Site

Figure 5 - 14 through Figure 5 - 23 show the individual aforementioned screens

accessed via the Conﬁg menu.

Figure 5 - 14 VSAT Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-15

Figure 5 - 15 Repeater Output Level Screen

Figure 5 - 16 Coupler Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-16

Figure 5 - 17 GPS Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-17

Figure 5 - 18 Temperature Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-18

Figure 5 - 19 Repeater Operating Mode Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-19

Figure 5 - 20 PPP Dial In Parameters Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-20

Figure 5 - 21 PPP Dial Out Parameters Screen

DTR-1098

03/06/08

Phone Number String – Always begin with ATDT then add phone number of NMC. If required, precede

number with external line prefix.

Modem Connection Timeout – For dial out reliability do not use less then 120.

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-21

Figure 5 - 22 PPP Misc Parameters Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-22

Figure 5 - 23 Site Screen

5.5.3

Alarms Sub-Menu Breakdown

Alarms shows the repeater current alarm status, alarm log, and allows the user to

conﬁgure alarms according to user requirements.

To access the Alarms sub-menu; GUI Main Menu => Alarms

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-23

The Alarm sub-menus are divided as follows:

Alarm Properties

Clear Log File

Alarm Status

The individual GUI screens follow.

Figure 5 - 24 Alarm Properties Screen

Figure 5 - 25 Clear Log File Screen

DTR-1100

03/06/08

Integration Time = Time in seconds that the repeater software will sample the condition

causing the alarm - to make sure the cause is present during the whole period of time. This is

used when the alarm changes from Cleared to Set. Value 0 means that the first time the condi-

tion is detected, the alarm will be set.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-24

Figure 5 - 26 Alarm Status Screen

5.5.4

NMS Users Sub-Menu Breakdown

The NMS Users screen shows identiﬁcation and authorization parameters. To access

the NMS Users sub-menu; GUI Main Menu => NMS Users => User Properties. See

Figure 5 - 27.

Figure 5 - 27 Access to User Properties Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-25

5.5.5

System Parameters Menu

To access the System Parameters sub-menu: GUI Main Menu=>System Parameters.

See Figure 5 - 28.

Figure 5 - 28 Access to System Parameters Sub-Menu

The System Parameters sub-menu is divided as follows:

Identiﬁcation

Access Control

Network Parameters

SNMP Parameters

System Time

Heartbeat Time

System Reset

Upgrade

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-26

The individual GUI screens follow:

Figure 5 - 29 System Parameters Identiﬁcation Screen

Figure 5 - 30 System Parameters Access Control Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-27

Figure 5 - 31 System Parameters Network Parameters Screen

Figure 5 - 32 System parameters SNMP Parameters Screen

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-28

Figure 5 - 33 System Parameters System Time Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-29

Figure 5 - 34 System Heartbeat Time Screen

DTR-1090

03/05/08

The Heartbeat screen allows the user to set the Heartbeat transmission inter-

val to the NMC

Heartbeat Hour Start*

Reference hour from the current day

Heartbeat Minute Start*

Reference minute

Heartbeat Pace

Interval in minutes that the heartbeat traps are generated.

Warning

A Heartbeat pace of less than 10 minutes could prevent remote dial-in and

possibly require local access in order to perform any reconfiguration.

* Hour and minute define a reference point from which the heartbeat alarm will

be generated. Changes to the heartbeat alarm property require a reset.

Refer to Section 2, Functional Description, Paragraph 2.3.1.4, SPU Main

Controller Board, for Heartbeat information.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-30

Figure 5 - 35 System Parameters System Reset Screen

The Upgrade screen allows the operator to upgrade system components by using the

Browse button to select the proper upgrade ﬁle (e.g.; Main Controller, Supervisor Con-

troller, VSAT Controller, Modulator [PPCO, PPCI, DSP, FPGA], Up-Converter, HPA).

After ﬁle selection, click on “Start Download”. See Figure 5 - 36.

Figure 5 - 36 System Parameters Upgrade Screen

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-31

As upgrade starts, a pop-up dialog box displays with the current upgrade status infor-

mation. See Figure 5 - 37.

Screen may be slow to display status.

Figure 5 - 37 Upgrade Dialog Box (Sheet 1 of 2)

Figure 5 - 38 Upgrade Dialog Box (Sheet 2 of 2)

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-32

The web server is a single threaded server, and as such, allows only one

connection at a time. This means an upgrade via phone line can take 10

minutes or more for ﬁle transfer. This is dependent upon speed and ﬁle

size. During transfer, the pop-up dialog box remains blank and only

starts showing information after the ﬁle is completely transferred.

5.6

COMMAND LINE INTERFACE (CLI)

The CLI can be accessed via the serial RS-232 port located on the SPU front panel.

(COMM PORT setting= 9600-8-n-1) or the telnet (port 26).

To use CLI, after system boot, establish connection to the RS-232 or TELNET interface.

Press “Enter” to obtain the Login prompt. See Figure 5 - 39.

Figure 5 - 39 CLI Login Prompt

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-33

At login, the default password is “admin.” This can be changed through the Web pass-

word parameter.

Figure 5 - 40 CLI Main Menu Screen

5.7

REPEATER OPERATING PROCEDURES

5.7.1

Local/Remote Operation

The repeater can be controlled and monitored either locally on site or remotely from a

network management center (NMC). The SPU front panel LOCAL REMOTE switch

controls the operating mode of the repeater.

All locally performed actions require the repeater to be in

the LOCAL operating condition. Prior to switching the

repeater to LOCAL, the on-site technician will coordinate

with the NMC operator. This will prevent conﬂicting actions

between the NMC and on-site operators and preclude possi-

ble personnel injury and/or equipment damage.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-34

5.7.1.1

Local Operation

For repeater local control (during initial setup and/or maintenance sessions, etc.) and

status information, a PC can be connected to the LAN and established via the Ether-

net (RJ45) port which provides access to the Web and GUI interface. This is the pre-

ferred method.

An alternate access method is via the RS-232 (DB9) serial port using the Command

Line Interface (CLI) protocol. The RS-232 provides access to CLI and allows the oper-

ator to perform initial setup and/or troubleshooting when network connectivity may

not be available or desired.

5.7.1.2

Setting to Local Operating Condition

1. Coordinate with the NMC operator.

2. Press the SPU front panel LOCAL/REMOTE switch to change to the

LOCAL position (see Figure 5 - 41).

3. Wait for the LOCAL LED to switch from Red to Green (approximately 2.5

minutes).

Figure 5 - 41 SPU Front Panel Local/Remote Switch

SYS ALARM

OUT POWER

ALARM

CABINET

HPA

LOCAL REMOTE RESET

DTR-1039A

04/20/07

REFL Power

AC MAIN

UPCONVERTER

SPU

ALARMS

MODULATION

INPUT INTERFACE

1PPS/10MHZ STATUS

SFN TIMING

SYNCH

STREAM LOCK

TEMPERATURE

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-35

5.7.1.3

Steps to Access the Repeater in Local Operating Condition via Ethernet

1. Connect the PC to the Ethernet (RJ45) port on the back panel of the con-

troller. See Figure 5 - 42.

Figure 5 - 42 Main Controller Back Panel Ethernet Connection

2. Access the repeater using the Internet Explorer browser and the repeater

IP address. When the repeater ﬁnishes booting, the Login screen displays.

See Figure 5 - 43.

Figure 5 - 43 Login Screen

3. On the Login screen, enter the repeater password (default = admin).

4. To access the repeater status information or to modify parameters, use

the GUI Web interface.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-36

5.7.1.4

Steps to Access the Repeater in Local Operating Condition via RS-232

1. Connect PC to RS-232 Console Port (SPU front panel) using a straight

cable.

2. Access the repeater via the HyperTerminal and using CLI commands.

The Modulator can also be directly accessed using an RS-232 Null

Modem cable connected to the Modulator RS-232 LOCAL PORT connec-

tor on the modulator back panel, and using CLI commands.

5.7.1.5

Remote Operation

Remote repeater access and communication is via V90 modem (RJ11) and a dial up

telephone line connected to the Network Management Center (NMC).

When an alarm occurs, the repeater’s main controller attempts to establish communi-

cation with the NMC through the dial up modem. If the phone line is busy, the con-

troller will retry after a pre-determined time period. Once the main controller ﬁnishes

sending all the traps to the NMC, the controller switches to a slave mode. In the slave

mode, the controller waits for a connection to be established with the NMC using pre-

conﬁgured SNMPv3 parameters. This allows NMC to poll its parameters/status or

make changes to various system parameters.

5.7.2

Operating Modes

Operating mode conﬁguration can occur in either of two main parameter groups;

Repeater Operating Mode parameters or Modulator Operating Mode parameters.

5.7.2.1

Repeater Operating Modes

In general, under no fault conditions, the repeater AC power up algorithm will restore

repeater operation to the existing mode condition prior to AC shutdown (if the

repeater was in Standby prior to AC shut down, upon reapplication of AC the repeater

would return to Standby). There are three repeater operating modes:

1). Standby mode

2). Broadcast mode

3). Manual mode

Mode selection is via the GUI Main Menu. From the Main Menu select Conﬁg =>

Repeater Operating Mode => Standby

, Broadcast, or Manual. See Figure 5 - 44.

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-37

Figure 5 - 44 Repeater Operating Mode Screen

5.7.2.1.1

Standby Mode

The Standby Mode is used to take the repeater off the air without removing all power.

The up-converter output is muted, ALC is off, and the HPA is switched off by dis-

abling the HPA power supply.

Following are the repeater operating conditions when in the Standby Mode:

• AC power is applied to the SPU, HPA, and fans

• HPA power supply is disabled

• HPA RF switch is off

• Up-converter output is muted

• Cabinet fans are turned on

5.7.2.1.2

Broadcast Mode

The Broadcast Mode is the normal operating mode for the repeater and allows the

repeater to transmit either real (satellite input) or internally generated test signals,

transmit OFDM signals for terrestrial broadcast, and run all the protection loops/

ALC. In this mode, all repeater functions are automatically maintained by the Main

Controller.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-38

5.7.2.1.3

Manual Mode

The Manual Mode is for testing and troubleshooting. Refer to the Maintenance sec-

tion of this manual for use of the Manual Mode. When switched to the Manual mode,

the repeater maintains all the system settings that were in effect in the previous

mode.

Table 5-1 summarizes the repeater status under the three modes of operation.

Table 5-1 Summary of Repeater Status Under the Three Modes of Operation

Standby Mode Broadcast Mode

(Real Signal) Broadcast Mode

(Test)) Manual Mode

Satellite Input On or Off On On or Off On or Off (if no satellite input)

Up Converter

Output Muted On On On

HPA RF Output Muted On On On or Off (user must turn HPA

on or off as required).

ALC Off On On Off

SPU AC & DC

Power On On On On

HPA AC & DC

Power Off On On On or Off

Fans Assemblies

(Rear door fans

will not operate

with cabinet rear

door open).

On On On On

IF Output On or Off

(depends on state

of modulator)

On On

On or Off

(user must unmute IF

as required).

GPS On or Off On On or Off On or Off

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-39

5.7.2.2

Modulator Modes

There are seven modulator operating modes but only two are used in the ﬁeld; the

remainder are factory modes. The two modes used by the operator/technician are:

1). Standby mode

2). Run

Mode selection is via the GUI Main Menu. From the Main Menu select Conﬁg =>Mod-

ulator => Modulator Mode => Standby or Run. See Figure 5 - 45.

Figure 5 - 45 Modulator Mode Screen

5.8

CONTROLS, INDICATORS, AND CONNECTORS

Controls, indicators, and connectors used in normal operation or referenced in proce-

dures are shown in Figure 5 - 46 through Figure 5 - 53.

5.8.1

Signal Processing Unit (SPU) Controls and Indicators

The SPU front panel has a series of LED indicators to warn of SPU Alarms, Sync con-

ditions, and HPA alarms and conditions. Speciﬁc alarms appear on the GUI ALARM

screen and are addressed in Appendices D and E. Also on the front panel is the Local

Remote push-button switch and its related indicator LEDs. Front panel indicators are

addressed in Figure 5 - 46.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-40

Figure 5 - 46 Signal Processing Unit (SPU) Front Panel (Sheet 1 of 3)

SYS ALARM

OUT POWER

ALARM

CABINET

HPA

LOCAL REMOTE RESET

DTR-1039A

04/20/07

REFL Power

AC MAIN

UPCONVERTER

SPU

ALARMS

MODULATION

INPUT INTERFACE

1PPS/10MHZ STATUS

SFN TIMING

SYNCH

STREAM LOCK

TEMPERATURE

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-41

Figure 5 - 46 Signal Processing Unit (SPU) Front Panel (Sheet 2 of 3)

SPU ALARMS

INDICATOR COMMENTS INDICATION

AC Fault occurs when 12 Vdc is out of limits Normal = Green

Fault Alarm = Red

MODULATOR Caused by any alarm from the modulator includ-

ing Communication error with the modulator Normal = Green

Fault Alarm = Red

UPCONVERTER This LED is red when there is a communication

error with the upconverter or the upconverter’s

LO PLL is not locked

Normal = Green

Fault Alarm = Red

INPUT INTERFACE VSAT Communication error or any error coming

from the VSAT Normal = Green

Fault Alarm = Red

SYNCHRONIZATION ALARMS

1 PPS/10MHz STATUS PLD not locked or 1PPS/10MHz alarms on the

modulator Normal = Green

Fault Alarm = Red

STREAM LOCK No lock to input stream alarm from the modulator Normal = Green

Fault Alarm = Red

SFN TIMING An alarm from the modulator indicating that the

Single Frequency Network margins are violated Normal = Green

Fault Alarm = Red

HPA ALARMS

OUT POWER HPA Forward Power Fault Normal = Green

Fault Alarm = Red

REFL POWER HPA Reflected power fault or Repeater Reflected

power fault Normal = Green

Fault Alarm = Red

ALARM Any alarm from the HPA will cause the LED to go

red Normal = Green

Fault Alarm = Red

AC MAINS Any summary alarm from the HPA power supply

modules will cause the LED to go red Normal = Green

Fault Alarm = Red

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-42

Figure 5 - 46 Signal Processing Unit (SPU) Front Panel (Sheet 3 of 3)

5.8.2

High Power Ampliﬁer (HPA) Controls and Indicators

5.8.2.1

The HPA front panel houses four status LEDs; AC ON, RF ON, DC ON, and SUM

FAULT. The panel also houses a type DB-9 RS-232 connector and a 15A Fuse Holder.

See

Figure 5 - 47

SUMMARY ALARMS

INDICATOR COMMENTS INDICATION

TEMPERATURE Alarm when Ambient temperature goes too high

over the Operating Temperature Threshold. Normal = Green

Fault Alarm = Red

SYS ALARM LED goes red for any alarm in the system Normal = Green

Fault Alarm = Red

CABINET Currently behaves the same way as Temperature

LED Normal = Green

Fault Alarm = Red

OTHER CONTROLS / CONNECTORS / INDICATORS

CONTROL/

CONNECTOR/

INDICATOR COMMENTS INDICATION

UPS ON/OF Push-button switch When the SPU is pow-

ered off, holding the

push-button keeps the

UPS off

CONSOLE RS-232 connector for external console

LOCAL/REMOTE Mode switch and mode indicators. Press twice to

switch to Local and disconnect the HPA Individual LEDs indicate

mode

RESET Push-button to reset controller

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-43

Figure 5 - 47 HPA Front Panel

CONTROL/INDICATOR COMMENTS INDICATION

AC ON Indicates 204VAC into HPA power supply LED Green

RF ON HPA internal RF switch is enabled and RF

power is present at HPA output LED Green

DC ON HPA power supply is enabled and DC voltage

is applied to the amplifier LED Green

SUM FAULT Internal fault. Specific fault message sent via

RS-485 interface to Main Controller LED Red

(only on during fault)

RS-232 Future connecting point for external console

FUSE 20A

RF ON

DC ON

AC ON

RS-232 DTR-1042

08/08/07

SUM FAULT

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-44

5.8.2.2

The HPA rear panel houses ﬁve connectors; AC IN, RF MONITOR, RF OUT, CON-

TROL IF, and RF IN. See Figure 5 - 48.

Figure 5 - 48 HPA Rear Panel

CONNECTORS COMMENTS

AC IN Connects to PDU for AC power

RF MONITOR For monitoring/testing. Terminated with 50 ohm load

RF OUT Connects to output bandpass filter

CONTROL I/F Connects to Main Controller PA Control connector

RF IN Connects to Up-Converter RF OUT connector

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-45

5.8.3

Power Distribution Unit (PDU) Front Panel Controls

The PDU front panel houses seven circuit breakers for controlling repeater electrical

power. There is also an auxiliary power receptacle for future use. See Figure 5 - 49.

Figure 5 - 49 Power Distribution Unit Front Panel

CONTROL COMMENTS

MAIN POWER Removes all power from the entire repeater cabinet.

FANS Removes power from the four axial fans; two on the top of

the HPA and two on the back door of the cabinet.

HPA Removes input power from the HPA drawer.

SPU Removes input power from the SPU drawer.

AUX POWER Removes power from the AUX receptacle.

EXTERNAL HEATER This is an optional connection for use by the customer as

desired.

INTERNAL HEATER Removes power from the SPU area heater. The heater is

not part of the SPU.

AUX OUTLET Controlled by AUX POWER CB. Supplies 120v, 5A.

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-46

5.8.4

VSAT Receiver Rear Panel Connectors

The

VSAT

Receiver rear panel has three connectors;

ASI OUT 1, ASI OUT

2, and

VSAT ANTENNA

. See Figure 5 - 50.

Figure 5 - 50 VSAT Receiver Rear Panel

5.8.5

Up-Converter Rear Panel Connectors

The Up-converter rear panel has two connectors;

RF OUT

and

RF MON

. See Figure 5 - 51.

Figure 5 - 51 Up-Converter Rear Panel

CONNECTOR COMMENTS

ASI OUT 1 Not connected

ASI OUT 2 Connects to ASI B on Main Controller

VSAT ANTENNA Connects to VSAT antenna signal cable

CONNECTOR COMMENTS

RF OUT Connects to HPA RF IN

RF MON Not connected

3EM21522AAAA OPERATION

Issue 1, March 2008 DTR-0200-SA-SIRIUS

5-47

5.8.6

Modulator Rear Panel Connectors

The Modulator rear panel has ﬁve connectors;

IF MON I, IF MON Q, LOCAL PORT,

ETHERNET

, and

ASI IN MON

. See Figure 5 - 52.

Figure 5 - 52 Modulator Rear Panel

CONNECTOR COMMENTS

IF MON I Not connected

IF MON Q Not connected

LOCAL PORT RS-232 Serial Port (DB9 connector) for PC

direct connection to Modulator via null

modem cable. Used to access parameters

and status via CLI protocol.

ETHERNET Connects to Main Controller ETHERNET

connection to allow communication between

Main Controller and Modulator.

ASI IN MON Not connected

OPERATION 3EM21522AAAA

DTR-0200-SA-SIRIUS Issue 1, March 2008

5-48

5.8.7

Main Controller Rear Panel Connectors

The Main Controller rear panel has 20 connectors;

MODEM

, spare (3),

FWD RF

DETECTOR, REFL RF DETECTOR, PA CONTROL, TEMP.SENSOR, STATUS IN,

RELAY CONTROL, 10MHZ, 1PPS, ASI A, ASI B, ETHERNET 10/100/1000 BASE T (4),

GPS ANT, DIAL-UP

. See Figure 5 - 53.

Figure 5 - 53 Main Controller Rear Panel

CONNECTOR COMMENTS

MODEM Not connected

FWD RF DETECTOR Connects to RF forward power detector for RF monitoring

REFL. RF DETECTOR Connects to RF reflected power detector for RF monitoring

PA CONTROL Connects to HPA Control I/F

TEMP.SENSOR Connects to PDU

STATUS IN Connected to Status Cable inside repeater and indicates Door Status

RELAY CONTROL

Connected to Relay Cable inside repeater and indicates Relay Status

10 MHZ Not connected

1 PPS Not connected

ASI A Not connected

ASI B Connected to VSAT RX ASI OUT 2

ETHERNET 10/100 BASE T There are four Ethernet connectors. Any one of the four must connect

by cable to the Modulator back panel Ethernet connector. This pro-

vides communication between the Modulator and Main Controller.

The remaining three Ethernet connectors connect to external equip-

ment such as a PC (for troubleshooting, parameter monitoring, etc.).

GPS ANT Connects to GPS Antenna cable.

DIAL-UP Phone cable connection

Sirius XM Radio DTR0200 ALU Repeater User Manual 00 DTR Iss 1

Sirius XM Radio Inc. ALU Repeater 00 DTR Iss 1

Contents

Users Manual Part 1

Navigation menu

Namespaces

Views

Navigation
