Revised System Specification Output levels
Nemko EESI, Inc. 11696 Sorrento Valley Road, Suite. F, San Diego, CA 92121
Phone (858) 793-9911 Fax (858) 259-7170
DATE DOCUMENT NAME SUBMITTAL # FCC ID PAGE
3/15/00 Solectek Corporation SkyWay Wireless LAN Bridge
FCC ‘C’ Certification Report 99-244 (Rev. A) KA324WAN5 4
2.2 Solectek SkyWay Transceiver System Specifications
Product Name: SkyWay Wireless LAN Bridge
Serial Number: N/A (Pre-production)
Type of Equipment: DSSS Transceiver
Modulation: 2 Mbits/s QPSK, 5.5 Mbits/s MOBK, 11 Mbits/s CCK
Chip Rate: 11Mchips/s
Operating Frequency: 2407 – 2470 MHz
Number of Channels: 11 Channels
Channel Spacing: 6 MHz
Bandwidth (6dB OBW): 12MHz maximum
Power Rating: 26dBm direct (High Power)
16dBm direct (Low Power)
Antenna Gain: Accommodates Solectek issued antennas with gains ranging from
6dBi to 24dBi
Emission Designation: Direct Sequence Spread Spectrum, 2.4GHz ISM Band
Emission Designator: 22MOX7D
Oscillator Frequencies: 32.768KHz, 44MHz, 50MHz, 560MHz (IF LO), 2160MHz (RF
LO) 280MHz (IF), 2440MHz (RF)
