Solectek 58WAN1 DIGITAL TRANSCEIVER SYSTEM User Manual 26 dBi antenna
Solectek Corporation DIGITAL TRANSCEIVER SYSTEM 26 dBi antenna
Solectek >
Contents
26 dBi antenna
REVISION RECORD
REV
ECO
DESCRIPTION
APVD
DATE
A CW67
RELEASED YAEL H. 6.3.03
SHEET
REV
SHEET
REV
SHEET
REV
SHEET
REV A A A
THIS DOCUMENT AND THE INFORMATION CONTAINED IN IT ARE PROPRIETARY AND CONFIDENTIAL TO MTI. NO PERSON
IS ALLOWED TO COPY REPRINT REPRODUCE OR PUBLISH ANY PART OF THIS DOCUMENT NOR, DISCLOSE ITS CONTENTS TO
OTHERS, NOR MAKE ANY USE OF IT NOR ALLOW OR ASSIST OTHERS TO MAKE ANY USE OF IT,- UNLESS BY THE PRIOR
WRITTEN EXPRESS AUTHORIZATION OF MTI AND THEN ONLY TO THE EXTENT AUTHORIZED.
(C) COPYRIGHT – MTI WIRELESS EDGE LTD.
PRODUCT STATUS:
PROPOSAL, INDEVELOPMENT
PREPRODUCTION, PRODUCTION WIRELESS EDGE LTD.
ACTION
NAME SIGN DATE
PREP Y.HARASH Y.H 25.12.02 TITLE
CHKD D.FAINER D.F 3.3.03 SPECIFICATION FOR MT – 486004/N
DSGN A.HVIV A.H 28.2.03 SUBSCRIBER ANTENNA
PROJ M.ROSTMY M.R 25.2.03 5.15 - 5.875 GHz ,26 dBi
SIZE
A MTI WIRELESS EDGE DWG NO
RD41262600C
REV
A
SCALE NONE SHEET 2 OF 3
MFG SIZE CLASSIFICATION DWG NO
QA M.MOTOVICH MOTI 25.2.03 A NONE RD41262600C
MARK. D.SHANI D.S 3.3.03 SCALE NONE SHEET 1 OF 3
961-7/96
SIZE
A MTI WIRELESS EDGE DWG NO
RD41262600C
REV
A
SCALE NONE SHEET 3 OF 3
SPECIFICATION
FLAT PANEL SUBSCRIBER ANTENNA
MTI PART NUMBER MT – 486004/N
REGULATORY COMPLIANCE ETSI EN 302 085 V1.1.2,(2001-02) Range 1
1. ELECTRICAL
FREQUENCY RANGE 5.15 - 5.875 GHz
GAIN 26 dBi (min)
VSWR 1.7:1 (max),1.5:1 (typ)
3 dB BEAMWIDTH 6° (typ)
POLARIZATION Linear (Vertical or Horizontal)
SIDELOBES LEVEL ETSI EN 302 085 V1.1.2, TS1-TS5
CROSS POLARIZATION ETSI EN 302 085 V1.1.2, TS1-TS5
-20 db (max)
F/B RATIO ETSI EN 302 085 V1.1.2, TS1-TS5
-30 db (max)
INPUT IMPEDANCE 50 (ohm)
INPUT POWER 6W (max)
LIGHTNING PROTECTION
DC Grounded
2. MECHANICAL
DIMENSIONS (LxWxD) 450 x 450 x 30mm (max)
WEIGHT 3 (kg) (max)
CONNECTOR N-TYPE Female
RADOME Plastic
BASE PLATE Aluminum with chemical conversion coating
OUTLINE DRAWING RD41262700C
3. MOUNTING KIT See RD41191800C
SIZE
A MTI WIRELESS EDGE DWG NO
RD41262600C
REV
A
SCALE NONE SHEET 4 OF 3
4. ENVIRONMENTAL
TEST STANDARD DURATION TEMPERTURE NOTES
LOW TEMPERATURE IEC 68-2-1 72 h -55°C -
HIGH TEMPERATURE IEC 68-2-2 72 h +71°C -
TEMP. CYCLING IEC 68-2-14 1 h -45°C +70°C 3 Cycles
VIBRATION IEC 60721-3-4 30
min/axis - Random
4M5
SHOCK MECHANICAL IEC 60721-3-4 - - 4M5
HUMIDITY ETSI EN300-2-4
T4.1E 144 h - 95%
WATER TIGHTNESS IEC 529 - - IP67
SOLAR RADIATION ASTM G53 1000 h - -
SALT SPRAY IEC 68-2-11 Ka 500 h - -
ICE AND SNOW - - - 25mm
Radial
WIND SPEED SURVIVAL
OPERATION
-
-
-
-
-
-
220 Km/h
160 Km/h
WIND LOAD (SURVIVAL):
FRONT THRUST
SIDE THRUST
-
-
-
-
-
-
58.3 kg
3.9 kg
