Invisity Remote Control
User manual
The invisity remote control is a waterproof handheld keyring format
device. It is used to discretely change the frequency/channel on the
invisity 4 channel device. To ensure an optimal result, the remote
control should be activated with a distance of maximum 60cm from
the receiver (Fig.1).
The invisity remote control requires to be programmed together
with the invisity receiver. To program both devices, please follow the
user manual of the invisity programming unit (IPU).
Fig.1
Operation
Flip to open the remote control. The push-buttons are used for the
following functions.
Programming mode Simultaneously push key #2 and #3 for
a short time (< 1 sec) to get the red
light. The programming mode is now
active either for 3 minutes or till you
push one of the keys for a short time.
Place the RC Invisity into the
Programmer Unit (IPU) as indicated on
your screen. Start the programming
procedure.
Change of channel Push key #1 equal times to set the
required channel (e.g. push 3x for
channel 3, 4x for channel 4).
Key #1
Key
#3
Key
#2
~60cm
(23inches)
P:\r&d\projekte\Project - WFS\Phase4 Prototypes & Tools\Documents\User
Manual remote control E V1.1.doc
Scan frequency Push key #1 more than 2 sec to initiate
scan mode, invisity will stop on the first
frequency scanned (only programmed
frequencies are recognized), push 2 sec
again to continue scan.
.
Battery end of live control Push simultaneously key #2 and #3 for
3 sec to get red LED light. Constant
light means the battery is OK. Blinking
light means the battery is weak. To
change the battery, please contact your
Phonak distributor.
Warning : do not use your RC invisity close to hospital or in airplane.
Phonak Communications AG CE
Längasse 17
CH-3280 Murten
Switzerland
Phone +41 (0)26 672 9672
Fax +41 (0)26 672 9677
E-mail info@phonakcom.ch
www.phonakcom.ch
029-3048
