Sony Group NWZA820 Digital Media Player User Manual NWZ A826 A828 A829

Sony Corporation Digital Media Player NWZ A826 A828 A829

Manual 3

83
83
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Establishing Bluetooth connection from the Home menu
Bluetooth
5-way button
BACK/HOME
button
Set up the Bluetooth device to prepare for Bluetooth connection.
For details about setting up the device, refer to the operation instruction
manual of the device.
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Bluetooth), and then press
the button to conrm.
Press the /// button to select “Bluetooth Devices,” and then
press the button to conrm.
The list of Bluetooth devices appears.
Paired Bluetooth devices
The Bluetooth icon is displayed next to the currently connected device.
Press the /// button to select the device for Bluetooth
connection, and then press the button to conrm.
The screen that informs of establishing process appears. The player also
indicates connection status by the Bluetooth indicator ( page 85).
Continued
Table of
Contents
Menu
Index
Please see Users Manual 4 for FCC and IC manual statements
84
84
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
To end Bluetooth connection from the Home menu
Select “Bluetooth Off” from the Bluetooth menu. You can also turn off the
Bluetooth function by pressing and holding the BLUETOOTH button.
Hint
If you end Bluetooth connection from the Bluetooth device, the player enters the
standby status for establishing a connection. If a connection is not established within 10
minutes, the Bluetooth function turns off automatically.
Note
The connection needs to be established within about 10 minutes.
Continued
Table of
Contents
Menu
Index
85
85
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
About the Bluetooth indicator
Bluetooth indicator Status
Off The Bluetooth function is off
Blinks quickly While pairing is in progress
Blinks continuously While establishing the connection
During “Connection Standby”
While turning off the Bluetooth function
Blinks slowly and continuously While holding Bluetooth connection when the
player stops playing back songs or video
sound, or is in standby mode
Blinks continuously in faint light While playing back songs or video sound
through Bluetooth communication
Blinks twice When the Bluetooth function turns on
When pairing completes
When Bluetooth connection is established
Blinks once When the Bluetooth function turns off
Hint
While the player holds Bluetooth connection without playing back songs or video
sound, the Bluetooth indicator keeps blinking slowly and continuously. The player keeps
this status for about a day. The time that the player can keep this status varies depending
on the connected device.
Table of
Contents
Menu
Index
86
86
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Listening to Songs or Video Sound from a
Bluetooth Device
You can listen to songs or video sound from a paired device.
Notes
Check the following before operating the player.
The Bluetooth device is turned on.
Pairing of the player and the Bluetooth device has been completed ( page 78).
The Bluetooth device supports same profiles as the player does ( page 154).
While the player holds Bluetooth connection, you cannot listen to songs or video sound
from non-wireless headphones or the accessories connected through WM-PORT.
Establish Bluetooth connection ( page 81, 83).
Play back songs or videos on the player.
Hints
While the player holds Bluetooth connection without playing back songs or video
sound, the Bluetooth indicator keeps blinking slowly and continuously. The player keeps
this status for about a day. The time that the player can keep this status varies depending
on the connected device.
The following wireless operations are available from the Bluetooth device:
Play back
Pause (Stop)
Fast forward/backward
Skip to the beginning of the next song/Skip to the currently playing song
Skip to the first listed song of the next folder/Skip to the fist listed song of the current
folder
You can control wirelessly the volume (VOL +/–) of certain devices using the VOL +/-
button of the player.
Continued
Table of
Contents
Menu
Index
87
87
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Incompatible operations with the Bluetooth function
Operations or features Results
Connecting an accessory to the
player through WM-PORT:
Accessories that provides
electricity
Other accessories
USB connection
The player accepts charging and keeps
Bluetooth communication.
The player ignores WM-PORT connection
and keeps Bluetooth communication.
The player responds to the USB connection
and stops Bluetooth communication.
Using non-wireless
headphones
The non-wireless headphones are not
compatible with the Bluetooth communication.
Beep sound The player does not transmit the beep sounds in
Bluetooth communication.
Table of
Contents
Menu
Index
88
88
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Selecting a Device for Quick Connection
You can establish Bluetooth connection simply by pressing and holding the
BLUETOOTH button of the player (Quick Connection) ( page 81). You can
designate a device for this operation.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Bluetooth Settings,” and then
press the button to conrm.
Press the /// button to select “Quick Connection,” and then
press the button to conrm.
The list of Bluetooth devices appears.
Press the /// button to select a device, and then press the
button to conrm.
The selected device is set for “Quick Connection.”
By default setting, the first paired device is designated for “Quick
Connection.”
Table of
Contents
Menu
Index
89
89
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Checking the Information of Bluetooth Devices
You can check the information of the paired devices, such as, device name,
device address, and support profiles.
OPTION/PWR
OFF button
BACK/HOME
button
5-way button
Bluetooth
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Bluetooth), and then press
the button to conrm.
Press the /// button to select “Bluetooth Devices,” and then
press the button to conrm.
The list of Bluetooth device appears.
Press the /// button to select a device, and then press the
OPTION/PWR OFF button.
The option menu appears.
Press the /// button to select “Device Information,” and then
press the button to conrm.
The information of the Bluetooth device appears. The information to be
appeared varies depending on the devices.
Table of
Contents
Menu
Index
90
90
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
 
Listening to Songs through Bluetooth Communication
Deleting a Paired Bluetooth Device from the
Player
The player can be paired with up to 8 different devices ( page 78). If you
want to pair the player with additional devices, delete an unnecessary
Bluetooth device from the list of Bluetooth devices.
OPTION/PWR
OFF button
BACK/HOME
button
5-way button
Bluetooth
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Bluetooth), and then press
the button to conrm.
Press the /// button to select “Bluetooth Devices,” and then
press the button to conrm.
The list of Bluetooth devices appears.
Press the /// button to select a device, and then press the
OPTION/PWR OFF button.
The option menu appears.
Press the /// button to select “Delete,” and then press the
button to conrm.
Press the /// button to select “Yes,” and then press the
button to conrm.
The selected device will be deleted from the player.
Table of
Contents
Menu
Index
91
91
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Setting the Sound Quality
(Sound Quality Mode)
You can adjust the sound quality for Bluetooth communication by adjusting
the bit rate (A2DP audio streaming).
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Bluetooth Settings,” and then
press the button to conrm.
Press the /// button to select “Sound Quality Mode,” and then
press the button to conrm.
The list of sound quality appears.
Press the /// button to select the desired setting, and then
press the button to conrm.
“Normal Mode”: (Default setting)
“High Quality Mode”: Songs or video sound are transmitted at high
sound quality, but the connection status may become unstable.
“Connect Priority”: The sound quality may not be as good as the other
modes, but songs or video sound are transmitted with a stable
connection. If the connection is unstable, “Connect Priority” is
recommended.
Table of
Contents
Menu
Index
92
92
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Applying Sound Eects Setting
You can choose whether or not to apply the sound effects (“Equalizer,”
“VPT(Surround),” “DSEE(Sound Enhancer),” “Dynamic Normalizer”). If you
choose to apply, all of the sound effects are set.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Bluetooth Settings,” and then
press the button to conrm.
Press the /// button to select “Sound Eect Preset,” and then
press the button to conrm.
The list of Bluetooth devices with the check box appears.
The check box is checked when the sound effect setting is applied (Default
setting.)
Press the /// button to select the desired device, and then
press the button to check the check box on or o.
The sound effects applied or disabled for Bluetooth communication.
Press the /// button to select “Close,” and then press the
button to conrm.
Notes
You cannot change the sound effects settings of Bluetooth devices from the player.
“Clear Stereo” does not work during Bluetooth communication.
Table of
Contents
Menu
Index
93
93
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
 
Listening to Songs through Bluetooth Communication
Check the Bluetooth Information of the Player
(Bluetooth Information)
You can check the Bluetooth information of the player, such as, version, model
name, BD address, or support profiles.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Bluetooth Settings,” and then
press the button to conrm.
Press the /// button to select “Bluetooth Information,” and
then press the button to conrm.
The Bluetooth information of the player appears.
“Bluetooth Version:”: Displays the Bluetooth version.
“Device Name:”: Displays the model name.
“Device Address:”: Displays BD address.
“Profile•Version:”: Displays the support profiles and their version.
Table of
Contents
Menu
Index
94
94
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Turning o the Bluetooth Function
(Bluetooth O)
You can turn off the Bluetooth function from the Home menu as well as using
the Bluetooth button ( page 81).
Bluetooth
5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Bluetooth), and then press
the button to conrm.
Press the /// button to select “Bluetooth O,” and then press
the button to conrm.
The Bluetooth function turns off.
Hints
In the following cases, the Bluetooth function is also turned off.
When the OPTION/PWR OFF button is pressed and held
When the BLUETOOTH button is pressed and held
When the battery is empty
If you end Bluetooth connection from the Bluetooth device, the player enters the
standby status for establishing a connection. If a connection is not established within 10
minutes, the Bluetooth function turns off automatically.
Table of
Contents
Menu
Index
95
95
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Entering Connection Standby
(Connection Standby)
You can establish Bluetooth connection from the Bluetooth device. Before you
operate the device, the player needs to enter the standby status for establishing
connection (Connection Standby).
Bluetooth
5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Bluetooth), and then press
the button to conrm.
Press the /// button to select “Connection Standby,” and then
press the button to conrm.
“Connection Standby” appears. The player can keep this status for about
10 minutes. The player indicates the status of the Bluetooth function by the
Bluetooth indicator ( page 85).
Table of
Contents
Menu
Index
96
96
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
Precautions on Bluetooth communication
Bluetooth wireless technology operates within a range of about 10 meters
(about 30 feet). Maximum communication range may vary depending on
obstacles (person, metal, wall, etc.) or electromagnetic environment.
The Bluetooth antenna (aerial) is built into the player ( page 10). The
sensitivity of Bluetooth communication will improve by turning the direction
of the built-in Bluetooth antenna (aerial) to the connected Bluetooth device.
The communication distance shortens when the obstacles are between the
connected device and the player.
The following conditions may cause noise, sound break or playback speed
change.
When using inside the metal bag.
When using inside the backpack or shoulder bag.
A device using 2.4 GHz frequency, such as a wireless LAN device, cordless
telephone, or microwave oven, is in use near the player or the device.
Because Bluetooth devices and wireless LAN (IEEE802.11b/g) use the same
frequency, microwave interference may occur and resulting in
communication speed deterioration, noise, or invalid connection if Bluetooth
communication is performed near a wireless LAN device. In such a case,
perform the following.
Perform Bluetooth communication at least 10 meters (about 30 feet) away
from the wireless LAN device.
Install the player and Bluetooth device as near to each other as possible.
When performing Bluetooth communication within about 10 meters (about
30 feet) of a wireless LAN device, turn off the wireless LAN device first.
Due to the characteristic of Bluetooth wireless technology, the sound played on
the Bluetooth device is slightly delayed from the sound played on the player.
Microwaves emitting from a Bluetooth device may affect the operation of
electronic medical devices. Turn off the player and other Bluetooth device in
the following locations, as it may cause an accident.
where inflammable gas is present, in a hospital, train, airplane, or a petrol
station.
near automatic doors or a fire alarm.
Continued
Table of
Contents
Menu
Index
97
97
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Listening to Songs through Bluetooth Communication
The player supports security capabilities that comply with the Bluetooth
standard to provide a secure connection when the Bluetooth wireless
technology is used, but security may not be enough depending on the setting.
Be careful when communicating using Bluetooth wireless technology.
We do not take any responsibility for leakage of information during
Bluetooth communication.
Connection with all Bluetooth devices cannot be guaranteed.
A device featuring Bluetooth function is required to conform to the Bluetooth
standard specified by Bluetooth SIG, and be authenticated.
Even if the connected device conforms to the above mentioned Bluetooth
standard, some devices may not be connected or work correctly, depending
on the features or specifications of the device.

Depending on the device to be connected, communication may take some time.
Table of
Contents
Menu
Index
98
98
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
 
Listening to Songs through Bluetooth Communication
Displaying the Bluetooth Option Menu
You can display the Bluetooth option menu by pressing the OPTION/PWR
OFF button on the list of Bluetooth devices. You can change the settings from
the menu.
The option items shown on the option menu vary, depending on the screen
from which you display the option menu.
Option items appear on the list screen
Option items Descriptions/reference page
Now Playing Displays the “Now Playing” screen.
Device Information Displays the information of the paired devices
( page 89).
Delete Deletes Bluetooth device from the player (
page 90).
Go to the song play back
screen
The “Now Playing” screen of the last played
song appears.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
Settings
99
99
Limiting the Volume
(AVLS (Volume Limit))
You can set “AVLS (Volume Limit)” (Automatic Volume Limiter System) to
limit the maximum volume to prevent auditory disturbance or distraction.
With “AVLS (Volume Limit),” you can listen to music at a comfortable volume
level.
“Off” is set by default.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “AVLS (Volume Limit),” and then
press the button to conrm.
Press the /// button to select “On,” and then press the
button to conrm.
The volume is kept to a moderate level.
To set this item to off
Select “Off” in step , and then press the button to confirm.
Note
“AVLS (Volume Limit)” cannot work during Bluetooth communication.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
100
100
Turning O the Beep Sound
You can turn off the beep sounds of the player.
“On” is set by default.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Beep Settings,” and then press
the button to conrm.
Press the /// button to select “O,” and then press the
button to conrm.
To set this item to on
Select “On” in step , and then press the button to confirm.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
101
101
Setting a Screensaver Type
You can set the screensaver to either a “Clock” or “Blank” for when there is no
operation for a while during song playback. You can also select “None” for no
screensaver.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” appears.
Press the /// button to select “Screensaver,” and then press
the button to conrm.
Press the /// button to select “Type,” and then press the
button to conrm.
The list of screensaver types appears.
Press the /// button to select a desired type, and then press
the button to conrm.
After confirming, the screen in step appears again.
“Clock”: When there is no operation for a while, a clock appears as a
screensaver. (Default setting)
“Blank”: When there is no operation for a while, the screen goes off.
“None”: The screen does not change to a screensaver.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
102
102
Setting a Screensaver Time
You can set the time for the screensaver to activate to 15, 30, or 60 seconds.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” appears.
Press the /// button to select “Screensaver,” and then press
the button to conrm.
Press the /// button to select “Screensaver Timing,” and then
press the button to conrm.
The list of screensaver time appears.
Press the /// button to select a desired type, and then press
the button to conrm.
After confirming, the screen in step appears again.
You can select the setting time as “After 15 sec,” “After 30 sec” (default
setting) or “After 60 sec.”
Hints
While characters are scrolling on the screen, the screen does not change to the
screensaver.
If you select “None” from “Type” of “Screensaver,” you cannot set “Screensaver Timing.”
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
103
103
Adjusting the Brightness of the Screen
(Brightness)
You can set the display brightness to one of 5 levels.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” appears.
Press the /// button to select “Brightness,” and then press the
button to conrm.
The brightness adjustment screen appears.
Press the /// button to select a level, and then press the
button to conrm.
“3” is set by default.
After you have adjusted the setting level, be sure to press the button to
confirm. If you press the BACK/HOME button before you confirm, the
setting will be canceled.
Hints
You can adjust the brightness of the screen while you are playing a video or photo. Press
the OPTION/PWR OFF button, and then select “Brightness” from the option menu.
If you adjust the brightness of the screen to a lower level, the charge will last longer (
page 115).
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
104
104
Setting the Current Time
(Set Date-Time)
You can set the current time by adjusting it manually.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Set Date-Time,” and then press
the button to conrm.
The screen used to set the date and time appears.
Press the / button to select a year, and press the / button to
increment/decrement the value, and then press the button to
conrm.
As you did in step , adjust the settings for month, date, hour, and
minute.
Continued
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
  Settings
105
105
To display the current time
Press the OPTION/PWR OFF button on the “Now Playing” screen and select
“Clock Display” from the option menu.
Hint
You can select the date format from among “YYYY/MM/DD,” “MM/DD/YYYY,” and
“DD/MM/YYYY.” Furthermore, you can select the time format from either “12-hour”
or “24-hour.” For details, see “Setting the Date Format” (Date Display Format) ( page
106), or “Setting the Time Format” (Time Display Format) ( page 107).
Notes
If the battery power is used up, for example, when the player is not used for a long time,
your settings for date and time may be reset and “-” will be displayed instead of the
current date and time.
The clock may gain or lose up to 60 seconds per month. In this case, set the clock again.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
106
106
Setting the Date Format
You can set the date format displayed for the current time ( page 104) as
“YYYY/MM/DD,” “MM/DD/YYYY,” or “DD/MM/YYYY.”
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Date Display Format,” and then
press the button to conrm.
The screen used to set the display format appears.
Press the /// button to select the desired setting, and then
press the button to conrm.
You can select the format from the following 3 types.
“YYYY/MM/DD”: The date appears as year/month/day.
“MM/DD/YYYY”: The date appears as month/day/year.
“DD/MM/YYYY”: The date appears as day/month/year.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
107
107
Setting the Time Format
You can select the time format displayed for the current time ( page 104)
from either a “12-hour” or “24-hour” display.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Time Display Format,” and
then press the button to conrm.
The screen used to set the display format appears.
Press the /// button to select the desired setting, and then
press the button to conrm.
“12-hour”: Displays the current time in the 12-hour format.
“24-hour”: Displays the current time in the 24-hour format.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
108
108
Displaying the Player Information
(Unit Information)
Information such as model name, firmware version, etc., can be displayed.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Unit Information,” and then
press the button to conrm.
The list of available player information options appears.
Available player information
Option Description
Model: Displays the model name of the player.
Firmware: Displays version information for the player’s firmware.
Total songs: Displays the total number of songs stored on the player.
Total videos: Displays the total number of videos stored on the player.
Total photos: Displays the total number of photos stored on the player.
WM-PORT: Displays the version information for WM-PORT.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
109
109
Resetting to Factory Settings
(Reset all Settings)
You can reset the player to the default settings. Resetting the player does not
delete data such as audio and photo data.
Settings 5-way button
BACK/HOME
button
Notes
This function is only available in the pause mode.
This function is not available while the Bluetooth function is turned on.
Press and hold the BACK/HOME button in the pause mode until the
Home menu appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Reset all Settings,” and then
press the button to conrm.
The confirmation screen to set back to the factory settings appears.
Press the / button to select “Yes,” and then press the button
to conrm.
“Restored factory settings.” appears.
To cancel the operation
Select “No” in step and press the button to confirm. You can also cancel
the operation by pressing the BACK/HOME button in step .
The setting procedure is canceled, and the list of the “Common Settings”
options reappears.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
110
110
Formatting Memory
(Format)
You can format the built-in flash memory of the player.
If the memory is formatted, all data and settings will be erased. Be sure to
verify the data stored in memory prior to formatting and export any important
data to the hard disk of your computer.
Settings 5-way button
BACK/HOME
button
Notes
This function is only available in the pause mode.
This function is not available while the Bluetooth function is turned on.
Press and hold the BACK/HOME button in the pause mode until the
Home menu appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Common Settings,” and then
press the button to conrm.
The list of “Common Settings” options appears.
Press the /// button to select “Format,” and then press the
button to conrm.
“All data including songs will be deleted. Proceed?” appears.
Press the / button to select “Yes,” and then press the button
to conrm.
“All data will be deleted. Proceed?” appears.
Press the / button to select “Yes,” and then press the button
to conrm.
While the memory is being formatted, an animated display appears.
When initialization finishes, “Memory formatted.” appears.
Continued
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
111
111
To cancel the operation
Select “No” in step or and press the button to confirm. You can also
cancel the operation by pressing the BACK/HOME button in step or .
Note
Do not format the built-in flash memory using software or Windows Explorer.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
112
112
Selecting the Display Language
You can select from a variety of languages for the display of menus and
messages on the player.
Settings 5-way button
BACK/HOME
button
Press and hold the BACK/HOME button until the Home menu
appears.
Press the /// button to select (Settings), and then press
the button to conrm.
Press the /// button to select “Language Settings,” and then
press the button to conrm.
Press the /// button to select a language ( page 113), and
then press the button to conrm.
Continued
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Settings
113
113
Display language settings
Setting Description
Deutsch Messages and menus are displayed in German.
English Messages and menus are displayed in English.
Español Messages and menus are displayed in Spanish.
Français Messages and menus are displayed in French.
Italiano Messages and menus are displayed in Italian.
Português Messages and menus are displayed in Portuguese.
Русский Messages and menus are displayed in Russian.
*1Messages and menus are displayed in Japanese.
Messages and menus are displayed in Korean.
Messages and menus are displayed in Simplified
Chinese.
Messages and menus are displayed in Traditional
Chinese.
*1 Japanese display may not be available, depending on the release region of the player.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
Useful Facts
114
114
Recharging the Player
The player’s battery is recharged while the player is connected to a running
computer.
When you connect the player to your computer, use the supplied USB cable.
When the remaining battery indication of the display shows: , charging is
completed (charging time is approx. 3 hours).
When you use the player for the first time, or if you have not used the player
for a long time, recharge it fully (to in the remaining battery indication of
the display).
On the remaining battery indication
The battery icon in the display changes as shown below. See page 157 on
battery duration.
As the battery power gets lower, the bar of the icon decreases. If “LOW
BATTERY. Please Charge.” appears, you cannot use the player. In this case,
charge the battery by connecting to your computer.
Notes
Charge the battery in an ambient temperature of between 5 to 35 ºC (41 to 95 ºF).
The number of times the battery can be recharged before it is used up is approximately
500 times. This number may vary, depending on the conditions under which you use the
player.
The battery indicator on the display is only an estimate. For example, one section of
black in the indicator will not always indicate exactly one-fourth of the battery’s charge.
“Do not disconnect.” appears in the display while the player accesses the computer. Do
not disconnect the supplied USB cable while “Do not disconnect.” appears or the data
being transferred may be damaged.
The control buttons on the player are all disabled while it is connected to a computer.
Some USB devices connected to the computer may interfere with the proper operation
of the player.
We do not guarantee the recharge of the battery using personally assembled computers
or modified computers.
If the computer enters a power saving mode, such as the sleep or hibernation mode,
while the player is connected via the USB cable, the player’s battery is not charged.
Instead, the player continues to draw power from the battery, discharging it.
Do not leave the player connected for extended periods to a laptop computer that is not
connected to AC power, because the player may discharge the computer’s battery.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
115
115
Maximizing Battery Life
By adjusting the settings or managing the power supply properly, it is possible
to save the battery power and use the player for a longer time.
Turn off the player manually
If you press and hold the OPTION/PWR OFF button, the player enters standby
mode and the screen turns off to save battery power. Furthermore, if standby
mode continues for more than about a day, the player turns completely off
automatically.
Changing the settings
You can save battery power by setting as follows.
Settings for screen “Brightness” ( page 103) “1”
“Type” of “Screensaver” ( page 101) “Blank”
“Screensaver Timing” ( page 102) “After 15 sec”
“New Song Pop Up” ( page 33) Deactivate.
Settings for sound
effect
“Equalizer” ( page 43)
Deactivate.
“VPT(Surround)” ( page 46)
“DSEE(Sound Enhancer)” ( page 49)
“Clear Stereo” ( page 48)
“Dynamic Normalizer” ( page 51)
Settings for video “On-Hold Display” ( page 61) “No”
Bluetooth function ( page 75) Turns off.
Adjust data format and bit rate
Playing time will vary, as battery charge can be affected by the format and bit
rate of songs, videos or photos that are played.
For details on charging time and usage time, see page 156, 157.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
116
116
About Data Transferring
You can directly transfer data by dragging and dropping using Windows
Explorer on your computer.
Playable data hierarchy has rules. To transfer data properly, see the following
instructions.
For details about the bundled software that can transfer data, see page 9.
Hints
Some computers that already have Windows Media Player 10 installed may encounter
file limitation (AAC, video files, etc.) that can be transferred by dragging and dropping.
If you install Windows Media Player 11 (for details, see “Installing the Operation Guide
and software” of “Quick Start Guide”) from the supplied CD-ROM, you can solve
this problem, then you can transfer by dragging and dropping again. Before installing
Windows Media Player 11 on your computer, make sure to check whether your software
or service corresponds to Windows Media Player 11.
Data hierarchy may differ, depending on your computer environment.
Notes
Do not disconnect the USB cable while “Do not disconnect.” appears on the
player or the data being transferred may be damaged.
You cannot change folder names or delete the “MUSIC,” “MP_ROOT,”
“VIDEO,” “PICTURES” and “PICTURE” folders.
Do not change folder or file names directly under the “MP_ROOT” folder or
“MPE_ROOT” folder. Otherwise, they will not be displayed on the player.
Continued
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
117
117
For songs
(On Windows Explorer)
Drag and drop files or folders into the “MUSIC” folder.
However, beyond the 8th level, neither files nor folders will be
recognized.
(On the player)
Folders are displayed in the folder name order first, then files
are displayed in the file name order. In this case, upper or
lower case letters are not distinguished.
Continued
1st
8th
7th
9th
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
118
118
For videos
(On Windows Explorer)
Drag and drop files or folders into the “VIDEO” folder.
On the 1st level, the “VIDEO” folder will recognize either a file
or a folder. Files on the 2nd level will be recognized. However,
folders beyond the 1st level and files beyond the 2nd level will
not be recognized.
(On the player)
Video files are displayed in the order they are transferred
by dragging and dropping. (The latest data is at the top.)
Hint
You can set JPEG files as a thumbnails of video files, by placing JPEG
files in the corresponding video folders. When you display the video
list, you can see the thumbnails (small pictures to display on the
menu) for the video files on the player.
To display a thumbnail for a video file, create a JPEG file (horizontal 160 × vertical 120
dots, extension: .jpg) and name it the same as the desired video file, then store it in the
video file folder.
Continued
1st
3rd
2nd
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
119
119
For photos
(On Windows Explorer)
Drag and drop files or folders into the “PICTURE”
folder.
On the 1st level, the “PICTURE” folder will recognize
either a file or a folder. Only files on the 2nd level will
be recognized by “PICTURE” folder. However, beyond
the 2nd level, neither files nor folders will be
recognized.
(On the player)
Folders under the “PICTURE” folder is displayed in
alphabetical order. Files in the 1st level of the “PICTURE”
folder are stored in the <PICTURE> folder.
1st
3rd
2nd
*1 Data hierarchy of
“PICTURES” is the same
as the “PICTURE” folder.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
120
120
What are Format and Bit Rate?
What is audio format?
Audio format refers to the method used when importing audio data from the
Internet or audio CDs to a computer and saving it as an audio file.
Common formats include MP3 and WMA, etc.
MP3: MP3 (MPEG-1 Audio Layer3) is a common audio compression
technology developed by the MPEG working group of the ISO (International
Organization for Standardization).
MP3 can compress audio files to about 1/10 the size of standard CD audio files.
WMA: WMA (Windows Media Audio) is a common audio compression
technology developed by Microsoft Corporation. The WMA format produces
the same sound quality as that of the MP3 format with a smaller file size.
AAC: AAC (Advanced Audio Coding) is a common audio compression
technology developed by the MPEG working group of the ISO (International
Organization for Standardization). The AAC format produces the same sound
quality as that of the MP3 format, with a smaller file size.
Linear PCM: Linear PCM is an audio recording format without digital
compression. You can listen to the sound with the same quality as CD music by
recording with this format.
What is bit rate?
Bit rate refers to the amount of data used to store each second of audio.
Generally, higher bit rates provide better sound quality, but require more storage
space for the same length of audio.
What is the relationship between bit rate, sound quality, and storage size?
Generally, higher bit rates provide better sound quality, but require more storage
space for the same length of audio, so you can store fewer songs on the player.
Lower bit rates enable you to store more songs, but at a lower sound quality.
Note
If you import a song from a CD to your computer at a low bit rate, you cannot improve
the song’s sound quality by selecting a high bit rate when transferring the song from the
computer to the player.
Continued
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
121
121
What is video format?
Video format refers to the method used when importing video and audio data
to a computer and saving it as a video file.
Common formats include MPEG-4 and AVC, etc.
MPEG-4: MPEG-4 refers to Moving Picture Experts Group phase 4, developed
by the MPEG working group of the ISO (International Organization for
Standardization). The compression format is for video and audio data.
AVC: AVC refers to Advanced Video Coding, developed by the MPEG working
group of the ISO (International Organization for Standardization). It enables
production of more vivid images at a lower bit rate. AVC files include four
profiles, and “AVC Baseline Profile” is one of them. AVC format is based on the
MPEG-4 AVC standard of the ISO (International Organization for
Standardization), and since AVC is standardized as the MPEG-4 Part 10
Advanced Video Coding, it is commonly referred to as MPEG-4 AVC/H.264 or
H.264/AVC.
What is photo format?
Photo format refers to the method used when importing images to a computer
and saving them as image files.
Common formats include JPEG, etc.
JPEG: JPEG (Joint Photographic Experts Group) is a common image
compression format developed by the JPEG. JPEG can compress an image file
to about 1/10 to 1/100 the size of original image files.
For details on acceptable formats and bit rates for this player
For details on supported file formats and bit rates, see page 154.
Table of
Contents
Menu
Index
NWZ-A826 / A 828 / A829.GB.3-289-807-11(1)
Useful Facts
122
122
Storing Data
You can store computer data into the built-in flash memory of the player by
transferring the data from your computer using Windows Explorer, or another
transfer capable software. If the player is connected to the computer, the built-
in flash memory appears in Windows Explorer as [WALKMAN.]
Notes
Do not use the supplied software while using Windows Explorer to interact with the
built-in flash memory of the player.
Do not disconnect the supplied USB cable while “Do not disconnect.” that appears
during data transfer is displayed. The data could be damaged.
Do not format the built-in flash memory using Windows Explorer. If you format the
built-in flash memory, format it on the player ( page 110).
You cannot change folder names or delete the “MUSIC,” “MP_ROOT,” “VIDEO,”
“PICTURES,” and “PICTURE” folders.
Do not change folder or file names directly under the “MP_ROOT” or “MPE_ROOT”
folder. Otherwise, they will not be displayed on the player.
Table of
Contents
Menu
Index

Navigation menu
