Instruction manual

Mode d'emploi

PSP-1001

filename C:\DataDisk\#Saggyou\1024\835900S

PSP1001K_USFR\2649166121_PSP1001K_US\01EN01CO

V.fm

model name1PSP-1001

2-657-883-12(2)

masterpage:Right

Encontrará un manual de instrucciones en español en nuestro sitio Web en

http://www.us.playstation.com/psp/manuals.aspx

01EN01COV.fm Page 1 Monday, October 24, 2005 1:32 PM

masterpage:Left

filename C:\DataDisk\#Saggyou\1024\835900S

PSP1001K_USFR\2649166121_PSP1001K_US\01EN02WA

R.fm

model name1PSP-1001

2-657-883-12(2)

2WARNINGS

To avoid electrical shock, do not open the cabinet. Refer

servicing to qualified personnel only.

Use the supplied AC adaptor only. If you use other types,

it may cause fire, electrical shocks or a malfunction.

For customers in the U.S.A. and Canada

Caution

Use of controls or adjustments or performance of

procedures other than those specified herein may result

in hazardous radiation exposure.

The use of optical instruments with this product will

increase eye hazard.

This appliance is classified as a CLASS 1 LASER product under IEC60825-1:

2001.

WARNINGS

01EN02WAR.fm Page 2 Monday, October 24, 2005 1:33 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN02WAR.fm

model name1PSP-1001

2-657-883-12(1)

WARNINGS

masterpage:Right

For customers in the U.S.A.

NOTE:

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

If you have questions about this product, call our technical support line at

1-800-345-7669, or write to:

Sony Computer Entertainment America

Consumer Services/Technical Support

PO Box 5888, San Mateo, CA 94402-0888 U.S.A.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Declaration of Conformity

Trade Name :

Model No. :

Responsible Party :

Address :

Telephone No. :

SONY

PSP-1001

Sony Electronics Inc.

16450 W. Bernardo Dr.

San Diego, CA 92127 U.S.A.

858-942-2230

01PSP-1001 EN.book Page 3 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN02WAR.fm

model name1PSP-1001

2-657-883-12(1)

4WARNINGS

You are cautioned that any changes or modifications not expressly approved in

this manual could void your authority to operate this equipment.

FCC Radiation Exposure Statement

This transmitter complies with FCC radiation exposure limit set forth for an

uncontrolled environment. To comply with the FCC RF exposure compliance

requirements, no change to the antenna or the device is permitted. Any changes

to the antenna or the device could result in the device exceeding the RF

exposure requirements and void user authorization to operate the equipment. In

addition, this transmitter must not be co-located or operating in conjunction

with any other antenna or transmitter.

Owner's Record

The model and serial numbers are located inside the battery compartment of the

unit. Record the serial number in the space provided below. Refer to the number

whenever you call for technical assistance at 1-800-345-7669.

Model No. PSP-1001

Serial No.______________

For customers in Canada

This Class B digital apparatus complies with Canadian ICES-003.

The term "IC" before the equipment certification number only signifies that the

Industry Canada technical specifications were met.

Operation is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

IC Radiation Exposure Statement

This transmitter complies with IC radiation exposure limit set forth for an

uncontrolled environment. To comply with the IC RF exposure compliance

requirements, no change to the antenna or the device is permitted. Any changes

to the antenna or the device could result in the device exceeding the RF

exposure requirements and void user authorization to operate the equipment. In

addition, this transmitter must not be co-located or operating in conjunction

with any other antenna or transmitter.

01PSP-1001 EN.book Page 4 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN02WAR.fm

model name1PSP-1001

2-657-883-12(1)

WARNINGS

masterpage:Right

Photosensitivity

A very small percentage of individuals may experience epileptic seizures when

exposed to certain light patterns or flashing lights. Exposure to certain patterns

or backgrounds on a television screen or while playing video games, including

games played on the PSP™ system, may trigger an epileptic seizure in these

individuals. Certain conditions may trigger previously undetected epileptic

symptoms even in persons who have no history of prior seizures or epilepsy. If

you, or anyone in your family, has an epileptic condition, consult your

physician prior to playing. If you experience any of the following symptoms

while playing a video game - dizziness, altered vision, eye or muscle twitches,

loss of awareness, disorientation, any involuntary movement or convulsions -

IMMEDIATELY discontinue use and consult your physician before resuming

play.

Radio waves

Radio waves may affect electronic equipment or medical devices (for example,

pacemakers), which may cause malfunctions and possible injuries.

• If you use a pacemaker or other medical device, consult your physician or the

manufacturer of your medical device before using the wireless networking

feature.

• Keep the PSP™ system at least 9 inches (23 cm) away from a pacemaker or

other medical devices when using the wireless networking feature.

• Do not use the wireless networking feature in the following locations:

– Areas where its use is prohibited, such as in airplanes or hospitals. Abide by

medical institution regulations when using the PSP™ system on their

premises. Additionally, you may be violating air safety regulations

punishable by fines by using the wireless networking feature in an airplane

or by using the PSP™ system during takeoff or landing.

– Crowded areas.

– Areas near fire alarms, automatic doors and other types of automated

equipment.

• Use caution when using the wireless networking feature in a vehicle, as radio

waves may affect electronic equipment in some vehicles.

01PSP-1001 EN.book Page 5 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN03HOM.fm

model name1PSP-1001

2-657-883-12(1)

GAME page 42

• Playing games

• Managing saved data

VIDEO page 46

• Playing UMD™VIDEO

• Playing videos saved on a Memory Stick Duo™

MUSIC page 59

• Playing UMD™MUSIC

• Playing music saved on a Memory Stick Duo™

PHOTO page 72

• Displaying images saved on a Memory Stick

Duo™

• Playing slideshows

SETTINGS page 90

• Adjusting PSP™ system settings

• Creating video, photo or network settings

• Connecting to devices using the USB connector

NETWORK page 86

• Using the Internet

• Using the LocationFree™ Player

01PSP-1001 EN.book Page 6 Friday, October 7, 2005 6:12 PM

masterpage:Right

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN03HOM.fm

model name1PSP-1001

2-657-883-12(1)

Basic button operations

This manual includes instructions for the basic features of the PSP™ system. For

additional information and answers to frequently asked questions about the PSP™

system, visit our Web site at http://www.us.playstation.com/psp

For more information on the use of Memory Stick Duo™ media,

visit http://www.memorystick.com/psp

Select a cate

elect an ite

ng t

ome menu

The basic operation of the PSP™ system starts from the home menu. Press the

home button to display the home menu and use the directional buttons to

navigate the horizontal and vertical icon bars.

POWER

HOLD

SELECT

HOME VOL START

Directional buttons:

Home button:

button:

Used to select on-screen items

Displays the options

menu for selected items

button: Cancels selected

operations

button: Confirms selected items

Displays the home menu

01PSP-1001 EN.book Page 7 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN04TOC.fm

model name1PSP-1001

2-657-883-12(1)

8Table of contents

WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Battery pack precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 17

xPreparation

Checking the package contents . . . . . . . . . . . . . . . . . . . . . 19

Part names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Preparing the PSP™ system for use . . . . . . . . . . . . . . . . . 25

Connecting the headphones with remote control . . . . . . . . 28

xBasic operations

Turning the PSP™ system on and off . . . . . . . . . . . . . . . . 29

Using sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Inserting a UMD™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Inserting a Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . 34

Avoiding unintended operation of the PSP™ system . . . . . 35

Using the sound button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Using the display button . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

xGame

Playing a game . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Game options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Copying and deleting saved data . . . . . . . . . . . . . . . . . . . . 45

xVideo

Watching a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Operating with PSP™ system buttons

or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Video options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Saving videos on a Memory Stick Duo™ . . . . . . . . . . . . . . 57

Table of contents

01PSP-1001 EN.book Page 8 Friday, October 7, 2005 6:12 PM

masterpage:Right

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN04TOC.fm

model name1PSP-1001

2-657-883-12(1)

Table of contents

xMusic

Listening to music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Operating with PSP™ system buttons

or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Music options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Transferring and saving music on a

Memory Stick Duo™ . . . . . . . . . . . . . . . . . . . . . . . . . . 69

xPhoto

Viewing images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Using the control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Operating with PSP™ system buttons

or the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Photo options menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Playing slideshows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Saving images on a Memory Stick Duo™ . . . . . . . . . . . . . 84

xNetwork

Using the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Connecting to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . 87

01PSP-1001 EN.book Page 9 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN04TOC.fm

model name1PSP-1001

2-657-883-12(1)

10 Table of contents

xSettings

Settings for the PSP™ system . . . . . . . . . . . . . . . . . . . . . . 90

Video Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Photo Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Theme Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Date & Time Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Power Save Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106

Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Network Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

How to use the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . 118

xAdditional information

PSP™ updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Compatible media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

01PSP-1001 EN.book Page 10 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

Precautions

masterpage:Right

Before using this product, carefully read this manual and retain it for future

reference.

Safety

This product has been designed with the highest concern for safety. However,

any electrical device, if used improperly, has the potential for causing fire,

electrical shock or personal injury. To help ensure accident-free operation,

follow these guidelines:

• Observe all warnings, precautions and instructions.

• Regularly inspect the AC adaptor and AC power cord for damage and for dust

build-up around the power plug or electrical outlet.

• Stop use, unplug the AC power cord from the electrical outlet and disconnect

any other cables immediately if the device functions in an abnormal manner,

produces unusual sounds or smells or becomes too hot to touch.

• Call SCEA Consumer Services at 1-800-345-7669 if the device does not

operate properly.

Use and handling

• Use in a well-lit area and keep the screen a safe distance from your face.

• Avoid prolonged use of the PSP™ system. To help prevent eyestrain, take a

break of about 15 minutes during every hour of play.

• If you experience any of the following health problems, discontinue use of the

system immediately. If symptoms persist, consult with your physician.

– Dizziness, nausea, fatigue or symptoms similar to motion sickness

– Discomfort or pain in a part of the body, such as eyes, ears, hands or arms

• Keep the system and accessories out of the reach of small children.

Small children may swallow the Memory Stick Duo™ or wrap the cables/

straps around themselves, which may inflict injury or cause an accident or a

malfunction.

• Do not use the system while driving or riding a bicycle. Looking at the screen

or operating the system while driving an automobile or riding a bicycle may

result in a traffic accident.

• Take extra care when using the system while walking.

• Be careful not to pinch your fingers when closing the disc cover.

Precautions

01PSP-1001 EN.book Page 11 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

12 Precautions

• Do not use the system or accessories near water.

• Use only attachments/accessories specified by the manufacturer.

• Do not use the headphones if they cause discomfort to your skin.

If the supplied headphones cause discomfort to your skin, discontinue use

immediately. If symptoms do not subside even after discontinuing use, seek

medical attention.

• Do not expose the system or accessories to high temperatures, high humidity,

or direct sunlight.

• Do not leave the system or accessories in a car with the windows closed

(particularly in summer).

• Do not expose the system or accessories to dust, smoke or steam.

• Do not allow liquid or small particles to get into the system or accessories.

• Do not place the system or accessories on surfaces that are tilted, unstable or

subject to vibration.

• Do not throw, drop or step on the system or accessories, and do not subject

the devices to strong physical shock. Sitting down with the PSP™ system in

a pocket or placing the system in the bottom of a backpack along with heavy

objects may cause damage to the system.

• Do not forcibly twist the PSP™ system or expose the system to strong

physical shock during gameplay, as doing so can damage the system or cause

the disc cover to open, ejecting the disc. Handle the analog stick with care.

• Do not put heavy objects on the system or accessories.

• Do not touch or insert foreign objects into the connectors of the system or

accessories.

• Do not place the system close to items with a magnetic strip, such as credit

cards.

• Do not touch the system or AC adaptor for an extended period of time while

in use. Depending on the conditions of use, the system or AC adaptor may

reach temperatures of 40°C/104°F or more. Extended contact under these

conditions may cause low-temperature burns*.

* Low-temperature burns are burns that occur when the skin is in contact with objects of

relatively low temperatures (40°C or more/104°F or more) for an extended period of time.

AC adaptor and AC power cord use

• Do not touch the plug of the AC power cord with wet hands.

• Do not touch the AC power cord, AC adaptor or the system, if connected to

an electrical outlet, during an electrical storm.

• Do not use a power source other than the supplied battery pack, AC adaptor

and AC power cord.

01PSP-1001 EN.book Page 12 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

Precautions

masterpage:Right

• Do not allow dust or foreign matter to build up around the system or accessory

connectors. If there is dust or foreign matter on the system's connectors or the

AC power cord, wipe it off with a dry cloth before connecting. Dust or other

matter on the connectors can result in fire or electrical shock.

• Unplug the AC power cord from the electrical outlet and remove the battery

pack from the system before cleaning or when you do not intend to use the

system for an extended period of time.

• Protect the AC power cord from being walked on or pinched particularly at

plugs, convenience receptacles and the point where they exit from the system.

• When disconnecting the AC power cord, hold it by the plug and pull straight

out from the electrical socket. Never pull by the cord and do not pull at an

angle.

• Do not use the system to play games or video when the system is covered with

any type of fabric. If you want to pause or temporarily store the system while

playing games or video, put the system in sleep mode before placing it in the

pouch. Also do not use the AC adaptor when covered with fabric. This may

help to avoid overheating.

• Do not connect the AC power cord to a voltage transformer or inverter.

Connecting the AC power cord to a voltage transformer for overseas travel or

an inverter for use in an automobile may cause heat to build up in the AC

adaptor and may cause burns or a malfunction.

LCD screen

• The LCD screen is made of glass and may crack if subjected to excessive

force.

• Red, blue or green spots (bright spots) or black spots (dark spots) may appear

in certain locations on the LCD screen. The appearance of such spots is a

normal occurrence associated with LCD screens and is not a sign of a

malfunction. LCD screens are made using highly precise technology.

However, a very small number of dark pixels or continuously lit pixels exist

on each screen. Also, a distorted image may remain on the screen for several

seconds after the system has been turned off.

• Direct exposure to sunlight may damage the system's LCD screen. Be careful

when using the system outdoors or near a window.

• When using the system in a cold environment, you may notice shadows on

the graphics or the screen may appear darker than usual. This is not a

malfunction, and the screen will return to normal when the temperature goes

up.

01PSP-1001 EN.book Page 13 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

14 Precautions

• Do not leave still images displayed on the screen for an extended period of

time. This may cause a faint image to be left permanently on the screen.

Memory Stick Duo™

For best results, follow these guidelines:

• Do not touch the connector area (A) with your hands or with metal objects.

• Do not press hard when writing on the memo area (B).

• Do not insert a Memory Stick Duo™ into a device designed to accept only

standard-size Memory Stick™ media.

• Do not use or store a Memory Stick Duo™ in the following:

– Places subject to high temperatures, such as in a hot vehicle

– Locations exposed to direct sunlight

– Locations that are very humid or conducive to corrosion

• Use the supplied case to carry or store the Memory Stick Duo™.

• When using Memory Stick Duo™ media without an erasure prevention

switch, take care not to overwrite or delete data by accident. If your Memory

Stick Duo™ media has an erasure prevention switch, you can prevent data

from being saved, edited, or deleted by setting the switch in the LOCK

position.

xRecorded data

Do not use the Memory Stick Duo™ in the following ways, as doing so may

result in data loss or corruption:

• Removing the Memory Stick Duo™ or turning off the system while it is

loading or saving data or being formatted.

• Using it in a location that is exposed to static electricity or electrical

interference.

If, for any reason, software or data loss or corruption occurs, it is usually

not possible to recover the software or data. It is recommended that you

regularly back up software and data. Sony Computer Entertainment Inc.

and its subsidiaries and affiliates will not be held liable for any damages or

injury in the case of software or data loss or corruption.

01PSP-1001 EN.book Page 14 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

Precautions

masterpage:Right

Pouch

• If you want to pause or temporarily store the system while playing games or

video, put the system in sleep mode before placing it in the pouch. This may

help to avoid overheating.

• Put both the PSP™ system and the remote control in hold mode to help

prevent unintended operation.

Never disassemble the system or supplied accessories

Use the PSP™ system and accessories according to the instructions in this

manual. No authorization for the analysis or modification of the system, or the

analysis and use of its circuit configurations, is provided. Disassembling will

void the system warranty. Additionally, there is a risk of fire, electrical shock

or malfunction. The LCD screen, in particular, contains dangerous, high-

voltage parts, and the laser beam for reading UMD™ may cause visual

impairment if exposed directly to the eyes.

Using the access point

When using the PSP™ system's 'Scan' function to select the wireless LAN

access point, access points that are not intended for public use may be

displayed. Only connect to a personal access point that you are authorized to

use, or one that is available through a public wireless LAN or hotspot service.

Overseas use

Depending on the country, there are limitations on the use of certain types of

radio waves. In some cases, use of the system may lead to a fine or other

penalty.

Moisture condensation

If the PSP™ system or UMD™ is brought directly from a cold location to a

warm one, moisture may condense on the lens inside the system or on the

UMD™. Should this occur, the system may not operate properly. In this case,

remove the UMD™ and turn off and unplug the system. Do not put the UMD™

In accordance with copyright law, no recorded data may be used for

purposes other than personal enjoyment without permission from the

01PSP-1001 EN.book Page 15 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

16 Precautions

back in until the moisture evaporates (this may take several hours). If the

system still does not operate properly, contact our technical support line at

1-800-345-7669 for assistance.

UMD™ handling

• Do not touch the opening on the rear of the disc (recorded surface of the disc)

with your fingers.

• Do not allow dust, sand, foreign objects or other types of dirt to get on the

disc.

• If the UMD™ becomes dirty, gently wipe the exterior and recorded surfaces

of the UMD™ using a soft cloth. Do not use solvents or other chemicals.

Cleaning

For safety reasons, unplug the AC power cord from the electrical outlet and

remove the battery pack from the system before cleaning.

xCleaning the exterior surface

Wipe gently with a soft cloth. Do not use solvents or other chemicals to clean

the exterior of the PSP™ system.

xCleaning the LCD screen

Wipe gently with a soft cloth.

xCleaning the connectors

• Do not use when the connectors of the system, AC adaptor or the AC power

cord are not clean. Remove the dirt with a dry cloth or cotton swab. If used

when dirty, the flow of electrical current may be obstructed.

• If the headphones or remote control connectors become dirty, this could cause

noise or interruptions in sound. Wipe the connectors with a dry, soft cloth to

keep in clean condition.

01PSP-1001 EN.book Page 16 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

Precautions

masterpage:Right

Battery pack precautions

Do not handle a damaged or leaking battery pack.

Contact with the material can result in injury or burns to the eyes or skin. Even

if foreign substances are not immediately visible, chemical changes in the

material can result in injuries occurring at a later time.

Handle the battery pack with care.

The battery pack may explode or present a fire or chemical burn hazard if it is

not handled carefully.

• Do not allow the battery pack to come into contact with fire or subject it to

extreme temperatures such as in direct sunlight, in a vehicle exposed to the

sun or near a heat source.

• Do not cause the battery pack to short-circuit.

• Do not disassemble or tamper with the battery pack.

• Prevent damage to the battery pack. Do not carry or store the battery pack

with metal items such as coins or keys. If damaged, discontinue use.

• Do not throw or drop the battery pack or subject it to strong physical shock.

• Do not put heavy objects on or apply pressure to the battery pack.

• Do not allow the battery pack to come into contact with liquids. If it becomes

wet, discontinue use until it is completely dry.

• Keep the battery pack out of the reach of small children.

• If the PSP™ system will not be used for an extended period of time, remove

the battery pack and store it in a cool, dry place out of the reach of children.

• Use only the supplied battery pack or a replacement marked for use with the

PSP™ system.

• Use only the designated AC adaptor to charge the battery pack.

Warnings

If you come into contact with material from a leaking battery pack, take the

following actions:

• If the material gets into the eyes, do not rub. Immediately flush the eyes

with clean water and seek medical attention.

• If the material comes into contact with the skin or clothes, immediately

rinse the affected area with clean water. Consult your physician if

inflammation or soreness develops.

01PSP-1001 EN.book Page 17 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN05PCT.fm

model name1PSP-1001

2-657-883-12(1)

18 Precautions

Recycling Lithium-Ion Batteries

Lithium-Ion batteries are recyclable.

You can help preserve our environment by returning

your used rechargeable batteries to the collection and

recycling location nearest you.

For more information regarding recycling of

rechargeable batteries, call toll free 1-800-822-8837,

or visit http://www.rbrc.org/

Caution

Do not handle damaged or leaking Lithium-Ion batteries.

01PSP-1001 EN.book Page 18 Friday, October 7, 2005 6:12 PM

filename C:\DataDisk\#Saggyou\1024\835900S

PSP1001K_USFR\2649166121_PSP1001K_US\01EN06PPT

.fm

Preparation

model name1PSP-1001

2-657-883-12(2)

Checking the package contents

masterpage:Right

Check that you have all of the following items. If any items are missing, contact

our technical support line at 1-800-345-7669 for assistance.

Preparation

Checking the package contents

POWER

HOLD

SELECT

HOME

VOL

START

sBattery pack

sPSP™ (PlayStation®Portable) system

sAC adaptor

sAC power cord sMemory Stick Duo™ (32 MB)

sWrist strap

sPouch

sCloth

sPrinted materials

Supplied with the Value Pack:

sMemory Stick PRO Duo™ (1 GB)

sStand

sUSB cable

Supplied with the Giga Pack:

sHeadphones with remote control

01EN06PPT.fm Page 19 Monday, October 24, 2005 1:33 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

model name1PSP-1001

2-657-883-12(1)

20 Part names and functions

System front

Part names and functions

AL button

BDirectional buttons

CMemory Stick Duo™ access

indicator

Lights up when saving and loading

data

DWLAN access indicator

Lights up when using the wireless

networking feature

EAnalog stick

Can be used with games that

support analog operation.

To optimize the analog stick's

functionality, with the "System

Information" screen under "System

Settings" ( page 96) displayed,

you can rotate the analog stick in a

circular motion to adjust its range of

movement.

FStrap holder

Attach as shown in the diagram.

GLeft speaker

HHome button

Displays the home menu

IVolume - button

Turns the volume down

JVolume + button

Turns the volume up

POWER

HOLD

SELECT

HOME VOL START

HOME VOL

01PSP-1001 EN.book Page 20 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

Preparation

model name1PSP-1001

2-657-883-12(1)

Part names and functions

masterpage:Right

System rear

KLCD screen

LDisplay button

Adjusts screen brightness

( page 38)

MSound button

Adjusts the tone ( page 36)

NSelect button

OStart button

PR button

Qbutton

Rbutton

Sbutton

Tbutton

UPower indicator

Lights up, flashes or changes color

to indicate system status

(page29)

VHold indicator

Turns yellow when in hold mode

(page35)

WRight speaker

ABattery cover CDisc cover

BPush button

PUSH

UMD

01PSP-1001 EN.book Page 21 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

model name1PSP-1001

2-657-883-12(1)

22 Part names and functions

System top

System bottom

AIR port COpen latch

BUSB connector

AHeadset connector CDC IN 5V connector

BCharging terminals

OPEN

DC IN

01PSP-1001 EN.book Page 22 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

Preparation

model name1PSP-1001

2-657-883-12(1)

Part names and functions

masterpage:Right

System left side

System right side

* References in this manual to "Memory Stick Duo™" apply to both Memory Stick Duo™

and Memory Stick PRO Duo™ unless otherwise noted. Also, the PSP™ system messages

use "Memory Stick" as a general reference to Memory Stick Duo™ and Memory Stick

PRO Duo™. Note that standard-size Memory Stick™ media cannot be used with the

PSP™ system.

AMemory Stick Duo™ slot*BWLAN switch

Turns on the wireless networking

feature

APower/hold switch

Turns the system on and off, puts in

sleep mode ( pages 29, 31) and

locks the system buttons

( page 35)

R:WLAN on

r:WLAN off

R:Power switch

r:Hold switch

01PSP-1001 EN.book Page 23 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

model name1PSP-1001

2-657-883-12(1)

24 Part names and functions

Headphones with remote control

A. button

B> button

CVolume + button

Turns the volume up

DVolume - button

Turns the volume down

Eu button

AHold switch

Locks the operation of the remote

control. Note that this button does

not lock the buttons of the PSP™

system.

BClip

Stand

The stand is supplied with the Giga Pack.

VOL

Remote control side

Remote control front

Stand

Hint

Do not place the stand on unstable surfaces.

01PSP-1001 EN.book Page 24 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

Preparation

model name1PSP-1001

2-657-883-12(1)

Preparing the PSP™ system for use

masterpage:Right

Before using the PSP™ system for the first time after purchase, you must

follow these steps to charge the battery.

Before inserting the battery pack, find the serial and model numbers listed

within the battery compartment and make a record of the numbers in the spaces

provided under Owner's Record on page 4.

1Remove the battery cover.

2Insert the battery pack.

3Replace the battery cover.

Preparing the PSP™ system for use

Getting started 1: Inserting the battery pack

UMD

PUSH

Hold down the push button and slide

the battery cover open.

UMD

PUSH

Align the bottom surface of the

battery pack with the system to

attach.

UMD

PUSH

2Slide the battery cover in the

direction of the arrow until it

locks firmly into place.

1Align the tabs.

01PSP-1001 EN.book Page 25 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

model name1PSP-1001

2-657-883-12(1)

26 Preparing the PSP™ system for use

1Plug the AC power cord into the AC adaptor.

2Connect the AC adaptor to the DC IN 5V connector on the

system bottom.

Getting started 2: Charging

Caution

• The socket-outlet shall be installed near the equipment and shall be

easily accessible.

• Do not plug the AC power cord for the PSP™ system into an electrical

outlet until you have made all other connections.

AC power cord

AC adaptor

POWER

HOLD

SELECT START

DC IN

AC adaptor

01PSP-1001 EN.book Page 26 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

Preparation

model name1PSP-1001

2-657-883-12(1)

Preparing the PSP™ system for use

masterpage:Right

3Plug the AC power cord into an electrical outlet.

The power indicator lights up in orange, indicating that charging has begun. The

power indicator will turn off when the battery is fully charged.

4Unplug the AC power cord from the electrical outlet and

disconnect the AC adaptor from the system.

Hint

For information on how to charge the battery, see "Battery" ( page 39).

1Turn on the PSP™ system ( page 29).

The power indicator lights up in green, and the initial setup screen is

displayed.

2Follow the on-screen instructions to make settings for

system language, time zone, date and time and nickname.

When you have completed initial setup, the home menu ( page 7) is

displayed.

Hints

• See "How to use the keyboard" ( page 118) for information on how to enter characters.

• Settings made during initial setup can be changed in (Settings). See "System

Settings" ( page 94) and "Date & Time Settings" ( page 98) for details.

Getting started 3: Initial setup

POWER

HOLD

SELECT START

AC power cord

To electrical outlet

01PSP-1001 EN.book Page 27 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN06PPT.fm

model name1PSP-1001

2-657-883-12(1)

28 Connecting the headphones with remote control

1Connect the headphones to the PSP™ system.

Hint

The remote control is exclusively for use with the PSP™ system and accessories made

exclusively for the PSP™ system. It cannot be used with other devices. Also, remote

controls made for use with other devices cannot be used to operate the PSP™ system.

Connecting the headphones with remote

control

HOME VOL

Headphones

Remote control

1Plug the headphones into the remote control.

2Plug the headphones into the headset connector on the system bottom.

01PSP-1001 EN.book Page 28 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Turning the PSP™ system on and off

masterpage:Right

1Slide the power/hold switch up.

The power indicator lights up in green, and the home menu is displayed.

Hints

• If the PSP™ system is turned on with a UMD™ inserted, the UMD™ will begin playback

automatically.

• The system can be used with the AC adaptor connected. In this case, charging will begin

automatically. The power indicator lights up in orange while charging.

• Do not use the PSP™ system with the AC adaptor when the battery pack is not inserted

in the system. If the AC adaptor is disconnected suddenly, it may result in damage to the

system.

Power indicator

The color and condition (solid or flashing) of the light indicates system status.

Basic operations

Turning the PSP™ system on and off

Turning the system on

Solid green Power on

Solid orange Charging

Flashing green Charge level is low

Light off Power off/in sleep mode

POWER

HOLD

START

SELECT

01PSP-1001 EN.book Page 29 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

30 Turning the PSP™ system on and off

1Hold the power/hold switch in the up position for more than

three seconds.

The power indicator flashes and then turns off, indicating that the system

is turned off.

Turning the system off

01PSP-1001 EN.book Page 30 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Using sleep mode

masterpage:Right

If the PSP™ system is switched to sleep mode, the software that is playing will

be paused. When sleep mode is cleared, you can begin playback from the point

where the system entered sleep mode.

Notices

• Do not put the system in sleep mode while the Memory Stick Duo™ access indicator is

on. This may cause data loss or corruption.

• If the battery runs out while in sleep mode, when you clear sleep mode, the system will

not return to the screen that was displayed before entering sleep mode. It is recommended

that you save game data before you put the system in sleep mode.

1With the system turned on, slide the power/hold switch up.

The power indicator flashes and then turns off, and the system enters sleep

mode.

Hint

Some software cannot be put in sleep mode.

Using sleep mode

Putting into sleep mode

POWER

HOLD

START

SELECT

01PSP-1001 EN.book Page 31 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

32 Using sleep mode

1Slide the power/hold switch up again.

Sleep mode is cleared.

Hints

• You can also clear sleep mode by pressing the u (play/pause) button of the remote

control, if the system was put in sleep mode during music or video playback.

• After clearing sleep mode with video or music content, you can resume playback from the

point where the system entered sleep mode by following the steps below.

Clearing sleep mode

Video

With the icon for the video selected, do any of the following:

- Press the start button or button.

- Press the u button of the remote control.

- Select "Play" from the options menu ( page 56).

Music saved on a

Memory Stick Duo™

With the icon for the Memory Stick Duo™ selected, do any of

the following:

- Press the start button.

- Press the u button of the remote control.

- Select "Play" from the options menu ( page 67).

01PSP-1001 EN.book Page 32 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Inserting a UMD™

masterpage:Right

Notice

Do not eject a UMD™ during playback.

1Slide the open latch on the PSP™ system top.

The disc cover opens.

2Insert a UMD™.

With the disc label facing the system rear, slide the UMD™ in the direction

of the arrow until it is fully inserted.

3Close the disc cover.

Ejecting the UMD™

Slide the open latch on the system top to open the disc cover.

Hint

When ejecting, hold the PSP™ system in an upright position (as shown in the diagram

above).

Inserting a UMD™

OPEN

Do not touch the recorded

surface.

Open latch

01PSP-1001 EN.book Page 33 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

34 Inserting a Memory Stick Duo™

1Open the slot cover and insert the Memory Stick Duo™.

Ejecting the Memory Stick Duo™

Open the slot cover and press the Memory Stick

Duo™ in the direction of the arrow to eject.

Notice

When the Memory Stick Duo™ access

indicator is lit, the PSP™ system is saving or

loading data. Do not eject the Memory Stick

Duo™, turn off the system or put the PSP™

system in sleep mode while the indicator is

lit. Doing so may cause data loss or

corruption.

Inserting a Memory Stick Duo™

Warning

Keep Memory Stick Duo™ media out of the reach of small children, as the

media could be swallowed by accident.

Open the slot cover in the

direction of the arrow.

Press until fully inserted.

Front side

HOME

Memory Stick Duo™

access indicator

01PSP-1001 EN.book Page 34 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Avoiding unintended operation of the PSP™ system

masterpage:Right

1Slide the power/hold switch down.

The hold indicator turns yellow, indicating that the system buttons are

locked.

Clearing hold mode

Slide the power/hold switch to its original position.

Avoiding unintended operation of the PSP™

system

POWER

HOLD

START

SELECT

The switch locks

into place.

01PSP-1001 EN.book Page 35 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

36 Using the sound button

The sound button is used to adjust the tone and to mute the sound for audio

playback and for key tones.

Tone can only be adjusted when using the headphones.

1Press the sound button.

Each time you press the button, the tone changes as follows:

Hint

The tone setting is temporarily set to "OFF" during gameplay.

1Hold down the sound button for more than one second.

The sound will be muted.

Using the sound button

Adjusting the tone

HEAVY Strengthens both bass and treble to produce an intense sound

POPS Strengthens the mid-range; ideal for vocals

JAZZ Strengthens both bass and treble to produce a balanced sound

UNIQUE Strengthens bass, treble and mid-range sound

OFF Normal tone

Turning off the sound (mute)

POWER

HOLD

SELECT START

01PSP-1001 EN.book Page 36 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Using the sound button

masterpage:Right

Clearing mute

You can clear mute by any of the following methods:

• Pressing the sound button

• Pressing the volume + or volume - button on the system or on the remote

control

01PSP-1001 EN.book Page 37 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

38 Using the display button

The display button is used to adjust screen brightness.

1Press the display button.

Each time you press the button, the display changes as follows:

Hint

Level 4 can be selected only while the PSP™ system is plugged in using the AC adaptor.

1Hold down the display button for more than one second.

The backlight will turn off and the screen will go blank.

If you press any of the system buttons, the screen will be displayed again.

Using the display button

Adjusting screen brightness

Level 1

Level 2

Level 3

(Level 4)

Turning off the backlight

POWER

HOLD

SELECT START

Dar

Brighter

01PSP-1001 EN.book Page 38 Friday, October 7, 2005 6:12 PM

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

Basic operations

model name1PSP-1001

2-657-883-12(1)

Battery

masterpage:Right

The battery charge level is displayed on the screen.

Estimating the remaining battery power

Hints

• If the power indicator flashes green, save game progress and recharge the battery. If the

battery runs out before you save, game progress will be lost.

• The charge level display may vary slightly from the actual charge level, depending on the

usage conditions and environmental factors, such as temperature. If the display is not

correct, use the battery pack until it is completely out of power and then recharge. Note

that the display may not be accurate in the following conditions:

– if the battery is used for extended periods in conditions of high temperature

– if the battery is not used for a long time after recharging

– if the battery has been recharged many times

Battery

Battery charge level

There is plenty of power left.

The battery is getting low.

The battery has almost run out.

No battery power remains. The power indicator flashes green. Recharge

the battery.

Battery charge

level

01PSP-1001 EN.book Page 39 Friday, October 7, 2005 6:12 PM

masterpage:Left

filename H:\#Sagyocyu\#10

OCT\1007\2649166121_PSP1001K_US\01EN07BAS.fm

model name1PSP-1001

2-657-883-12(1)

40 Battery

• Battery charge level can also be checked in "Battery Information" under ""System

Settings" ( page 95).

• If the PSP™ system is left unused after the battery runs out, the date and time settings may

be reset. If this occurs, the date and time setting screen will be displayed the next time the

system is turned on.

• The battery cannot be recharged when the WLAN feature is in use.

*1 Based on tests conducted using the supplied battery pack, with the system in single

player mode, with headphones with remote control in use, and with wireless LAN not in

use.

*2 Based on tests conducted using variables of system speakers versus headphones, volume

level and screen brightness level.

Hint

Battery duration may vary depending on the type of content being played or usage

conditions such as screen brightness and environmental factors. As battery ages, anticipate

lower battery duration.

When using the supplied battery pack, it takes approximately 2 hours and 20

minutes to fully charge the battery using the AC adaptor after the battery has

run out.

Hints

• Charge in a temperature of 10°C to 30°C/50°F to 86°F. Charging may not be as effective

in other environments.

• Charging may take longer when the system is turned on during charging.

The battery pack has a limited lifespan. Battery duration will decrease with

repeated usage and age. If the battery duration becomes extremely short, it may

be time to replace the battery pack.

Estimated battery duration

Game Approximately 3 - 6 hours*1

Video playback Approximately 3 - 5 hours*2

Estimating the battery charge time

Battery pack life

01PSP-1001 EN.book Page 40 Friday, October 7, 2005 6:12 PM

Sony Group PSP1001B PSP User Manual PSP 1001

Sony Corporation PSP PSP 1001

Contents

Users Manual Part 1

Navigation menu

Namespaces

Views

Navigation
