Spectrum 450241CBR Z-Wave Plus Module User Manual 914 Z Wave Plus indd

Spectrum Brands, Inc. Z-Wave Plus Module 914 Z Wave Plus indd

Users Manual 914

1 / 4
66073001
Rev 01
ZWave® Plus
Installation and User Guide
ENGLISH
If drilling a new door, use the supplied template and the complete
door drilling instructions available at www.kwikset.com/doorprep.
Note: Additional door preparation may be
required for doors with 11/2" (38 mm) holes.
Consult the deadbolt drilling instructions at
www.kwikset.com/doorprep.
or
backset
Measure to conirm that the hole in
the door is either 21/8" (54 mm) or
11/2" (38 mm).
Measure to conirm that the backset is
either 23/8" or 23/4" (60 or 70 mm).
23/8" or 23/4"
60 or 70 mm 13/8" – 2"
35 – 51 mm
Measure to conirm that the hole in
the door edge is 1" (25 mm).
Measure to conirm that the door is
between 13/8" and 2" (35 mm and
51 mm) thick.
A B C D
21/8"
54 mm
11/2"
38 mm
1"
25 mm
1Prepare the door and check dimensions
Required tools
Ruler4 AA Batteries
Hammer Wood block
Phillips head screwdriver
Additional Tools (depending on application)
A
N or P
(2x)
NP
S
Q
A
B
B
A D
Is the door edge chiseled? Which latch are you installing?
YES NO
Use latch “A”. If the
latch bolt is not already
extended, extend the
latch bolt as shown.
wood
block
actual
size
Use latch “B” (not
included). If the latch
bolt is not already
extended, extend the
latch bolt as shown.
Latch “A” Latch “B”
S (2x) C
Q (2x)
Longer screws
install closest to
the door jamb.
door frame
EInstall strike on the door frame.
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
or
chiseled not
chiseled
or
2Install the latch and strike
Kwikset
Technical Support
1-866-863-6584
www.kwikset.com
A
B
AB
B
CIs the D-shaped hole centered in the door hole?
Hold the latch in front of the door hole, with the latch
face lush against the door edge.
YES NO
No adjustment is required.
Proceed to next step.
D-shaped hole D-shaped hole
Rotate latch face as
shown to extend latch.
or
Latch
“B” is not included. If needed,
please contact Kwikset to order
a drive-in latch for your lock.
Strike
C
Keys
E
A
B
Exterior Assembly
Adapter
Ring
D
Mounting
Plate
Parts in the box
Fasteners
03809 46780
N Q
S
P
48654 64109
T
V
49191
U
Contemporary
Interior Assembly
SmartKey
Tool
H
Traditional
M
M
Traditional
F F
Contemporary
K L
G
U
actual
size
21/8"
54 mm
11/2"
38 mm
K
2 / 4
U
(2x)
What is the diameter of the hole in the door?
Remove battery cover and battery pack from interior assembly.
Install 4 AA batteries in battery pack.
Install interior assembly onto mounting plate.
Press and HOLD the Lock button
while installing battery pack.
Hold button until the latch bolt
starts moving on its own.
Did the latch bolt retract and extend on its own
when the battery pack was installed?
Locate screws for step 3C and keep them within reach.
Install exterior keypad and mounting plate.
A
A
A
B
B C
B
C
Diameter is 21/8"
(54 mm)
YES
Diameter is 11/2"
(38 mm)
NO
or
or
“D” is required for installation.
Install “D” on “F”.
“D” is not needed for
installation. Discard “D”. Cable goes
underneath latch.
Support exterior
assembly during
mounting plate
installation.
Route cable through
center hole, then push
cable into bottom hole.
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
inished and make
sure the latch bolt
is fully extended.
Keep parallel to
edge of door.
Tighten
screws evenly.
a
a
c
c
b
b
d
d
Make sure turnpiece is in
the vertical position.
Door handing process
was successful! Proceed
to next step after latch
bolt stops moving.
Remove battery pack,
wait 15 seconds, then
attempt the process again.
Note: Latch
bolt will only
retract half way.
Make sure
turnpiece shaft is
rotated as shown.
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
Do not install
batteries
until step 5.
Ensure tight cable
connection.
Lay excess cable lat inside the
bottom of the interior housing.
align
L
a
c
b
d
actual
size
T
bottom
hole
D
D
F
F
G
TT (2x)
T
E
M
L
LL
K
3Install the exterior keypad
4Install the interior assembly
5Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
1x
green
3x
red
Initiate the pairing process at
your smart home controller.
Refer to your smart home
system instructions for
more information.
When prompted by your smart home system
to initiate pairing at the lock, press button “A”
on the lock interior one time. The red LED will
illuminate when pairing mode has been entered.
If the pairing process is successful, re-name
the lock in your system (if applicable).
If pairing is unsuccessful, follow your system's
instructions to remove the lock from the controller
and any other network, then press button “A” on the
lock one time.
Perform steps 6A6C again.
If pairing is still unsuccessful, consult the
Programming and Troubleshooting Guide on the
SmartCode 914 page at www.kwikset.com.
A B C
D
Pair the lock with your smart home system
Mastercode
For enhanced security,
a mastercode may
be used when adding
and deleting user
codes. For more
information about the
mastercode, download
the Programming and
Troubleshooting Guide
on the SmartCode 914
page at kwikset.com.
button “A”
Please allow time for the controller to pair with the lock.
Tip: You can press the
Lock button before
entering your user
code to light up the
keypad at night.
3 / 4
Conirm that the code(s) added in previous step can unlock the door.
One green lash with one beep Three red lashes with three beeps
or
Make sure the door is open. Press
the Program button once.
Locking the Door Unlocking the Door
Enter user code. A total of 30 user
codes may be programmed.
Press Lock button once.
A B C
What lights and sounds does the lock produce?
D
Each user code
must be a unique
code between
4 and 8 digits,
depending on
your smart
home system.
Programming was successful. Programming was unsuccessful.
Make sure not to pause for more than 5 seconds during programming.
Make sure the user code is not a duplicate and that it is between 4 and 8 digits
during your next attempt. Make sure the lock has room for an additional code.
If all user code positions are illed, delete a code to make room for this one.
Press Lock button once. Enter user code.
It is recommended that you add and
delete all user codes through your smart
home control system. If your system
does not allow this, codes may be added
directly to the lock as shown here.
Programming Timeout
During programming, if no button is
pressed for ive seconds, the system will
time out (indicated by three beeps and a
red lashing keypad), and you will need to
restart the procedure.
*Beeping sound will only be heard if switch #3 (on the lock interior) is in the on positon. See “Switches and Status LED Colors” on page 4.
Re-key the lock (if needed). Install the battery cover.
A B
IMPORTANT:
Remove battery
pack before
re-keying.
actual
size
M
V (3x)
V
K
H
K
a a
b b
c
Re-key the lock
to work with your
existing key. See
the supplied
SmartKey Re-key
instructions for
more information.
Reinstall
battery
pack.
If your controller is S2-compatible, please refer to the S2 Pairing Guide on the SmartCode 914 page at www.kwikset.com.
6
7
8
9
Add user codes (30 max)
Re-key the lock (if needed) and install the battery cover
Test the lock (review normal operation)
Alert Reason Solution
Keypad lashes red once with
one beep*. One incorrect code entered. Re-enter code.
Keypad lashes red three
times with three beeps*.
No user code programmed. Program at least one user code.
Programming timeout after ive
seconds. Attempt programming procedure again.
Unsuccessful programming.
Keypad lashes red 15 times
with 15 beeps*
Three incorrect codes entered
within one minute.
Re-enter code after 60 second keypad
lockout.
Keypad lashes red with fast
beeping sound for three to
four seconds.
Low battery. Replace batteries.
Keypad lashes green with
continuous beeping sound
for two seconds.
Door jammed while attempting
to lock.
Manually re-lock door. If needed,
reposition strike.
Lock beeps continuously. Interior assembly is
disconnected from exterior.
Remove battery pack, reconnect the interior
to the exterior, then reinstall battery pack.
*Beeping sound will only be heard if switch #3 is on.
© 2016 Spectrum Brands, Inc.
1. Read all instructions in their entirety.
2. Familiarize yourself with all warning and caution statements.
3. Remind all family members of safety precautions.
4. Protect your user codes and mastercode.
5. Dispose of used batteries according to local laws and regulations.
CAUTION: Prevent unauthorized entry. Since anyone with access to the back panel
can change the user codes, you must restrict access to the back panel and routinely
check the user codes to ensure they have not been altered without your knowledge.
The use of a mastercode can help protect your system’s settings.
WARNING: This Manufacturer advises that no lock can provide complete security
by itself. This lock may be defeated by forcible or technical means, or evaded by
entry elsewhere on the property. No lock can substitute for caution, awareness of
your environment, and common sense. Builder’s hardware is available in multiple
performance grades to suit the application. In order to enhance security and reduce
risk, you should consult a qualiied locksmith or other security professional.
Important Safeguards
If no button is pressed for ive seconds, the system will time out, and
you will need to restart the procedure.
1 Keep door open.
Press Program
button once.
5 Re-enter user code. 6 Press Lock
button once. If unsuccessful
Make sure to enter
the same valid code
in steps 3 and 5.
Test code
While the door is
open, test the user
code to make sure
it no longer unlocks
the door.
2 Press Lock
button once.
4 Press Lock
button once.
3 Enter user code
to be deleted.
Network Information
ZWave System Notes
This product is a security enabled Z-wave Plus product and must be used with a Security
Enabled ZWave controller to be fully utilized. ZWave is a “Wireless mesh network,” and
results may vary based on building construction and communication path, with 35 feet+
being typical installed distance from smart home controller. It may be necessary to install
additional ZWave beaming capable devices that can serve as repeaters to enhance the
communication path between the lock and controller for a more robust ZWave network.
To assure interoperability, each ZWave product must pass a stringent conformance test to
assure that it meets the ZWave standard for complete compliance with all other devices and
controls. The ZWave identity mark assures consumers, integrators, dealers and manufacturers
that their products will reliably perform with any other ZWave device. And, regardless of the
vendor, always powered nodes may act as a repeater for Kwikset/Weiser/Baldwin products.
ZWave Coniguration and Association Parameters are available
on the SmartCode 914 page at www.kwikset.com.
Removing the lock from the network
Follow your smart home system’s instructions
to remove the lock from the network. When
prompted by the system, press button A” on the
lock interior once.
4 / 4
SmartCode at a Glance
Deleting a single user code
Note: All codes may be deleted at once if the mastercode is enabled. For more information about the
mastercode, consult the Programming and Troubleshooting Guide.
Reference Guide
Exterior
Back
panel
Program
button
Status
LED
Switches
Turnpiece
shaft
Note: When the cover is removed,
the turnpiece shaft can be used to
manually lock and unlock the door.
Interior (cover removed)
Switches and Status LED colors Troubleshooting
Switch Function
1Door lock status LED blinks every 6
seconds
2
Lock automatically re-locks door 30
seconds after unlocking. Disabled if no
codes are programmed.
3 Audio
4 Not used.
Color Lock Status
Blinking green Unlocked
Blinking amber Locked
Blinking red Low battery
Solid red
Door handing process
did not work properly.
See the online
Programing and
Troubleshooting Guide.
1 2 3 4
On
Switches
Status
LED
O
System Alerts
Factory Reset
A factory reset will delete all codes associated with the lock,
and it will remove it from your smart home system.
Status
LED
1 Remove
battery pack.
2 Press and HOLD the Program
button while reinserting
the battery pack.
Keep holding the button for 30
seconds until the lock beeps
and the status LED lashes red.
Keypad
Lock
button
Keyway
SmartKey
tool hole
Button “A” Button “B”
3 Press the Program button
once more. When the LED
lashes green and you
hear one beep, the lock
has been reset.
4 Perform the door handing process again
to teach the lock the orientation of the
door, pair the lock with your smart home
system, and add user codes to your lock.
A complete Programming and Troubleshooting Guide is
available on the SmartCode 914 page at www.kwikset.com.

Navigation menu
